.JET
EQUIPMENT& TOOLS
OPERATOR'S MANUAL
HVBS-7MW Bandsaw
)..,.,~..",..
..,~,:;;;:r
.
.:::::""... .
~. '''",
A~ ..~
'~~'.::.:~
""' ~'~
"'''C'''',,
''
..
~"''''01'
.", ....
".~.
JET EQUIPMENT&TOOLS,INC.
A WMH -Walter Meier Holding Company PH BOX1349 Auburn,WA98071-1349 253-351-6000
Fax[phone]
No, M-414459 3/2001

ImportantInformation
1-YEAR
LIMITED WARRANTY JET offers a one-year limited
warranty on this product
REPLACEMENT PARTS
Replacement parts for this tool are availabledirectly form JET Equipment& Tools.
To placean order, call 1-800-274-6848. Pleasehavethe followinginformationready:
1. Visa, MasterCard, or DiscoverCard number
2. Expirationdate
3. Part number listed within this manual
4. Shipping address other than a Post Office box.
REPLACEMENT PART WARRANTY
JET Equipment & Tools makes every effort to assure that parts meet high quality and durability standards
and warrants to the original retail consumer/purchaserof our parts that each such part(s) to be free from
defects in materials and workmanship for a period of thirty (30) daysfrom the date of purchase.
PROOF OF PURCHASE
Pleaseretain your dated sales receiptas proofof purchaseto validatethe warranty period.
LIMITED TOOL AND EQUIPMENT WARRANTY
JET makes every effort to assure that its products meet high quality and durability standards and warrants to the original
retail consumer/purchaser of our products that each product be free from defects in materials and workmanship as
follows: 1 YEAR LIMITED WARRANTY ON THIS JET PRODUCT. Warranty does not apply to defects due directly or
indirectly to misuse, abuse, negligence or accidents, repairs or alterations outside our facilities or to a lack of
maintenance. JET LIMITS ALL IMPLIEDWARRANTIESTO THE PERIOD SPECIFIEDABOVE FROM THE DATE THE
PRODUCT WAS PURCHASED AT RETAIL. EXCEPT AS STATED HEREIN, ANY IMPLIED WARRANTIES OR
MECHANTABILITY AND FITNESS ARE EXCLUDED. SOME STATES DO NOT ALLOW LIMITATIONS ON HOW
LONG THE IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATION MAY NOT APPLY TO YOU. JET SHALL IN
NO EVENT BE LIABLE FOR DEATH,INJURIES TO PERSONSOR PROPERYOR FOR INCIDENTAL, CONTINGENT,
SPECIAL OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE OF OUR PRODUCTS. SOME STATES DO
NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE
ABOVE LIMITATION OR EXCLUSION MAY NOT APPLY TO YOU. To take advantage of this warranty, the product or
part must be returned for examination, postage prepaid, to an authorized service station designated by our Auburn
office. Proof of purchase date and an explanation of the complaint must accompanythe merchandise. If our inspection
discloses a defect, JET will either repair or replace the product or refund the purchase price, if we cannot readily and
quickly provide a repair or replacement, if you are willing to accept such refund. JET will return repaired product or
replacement at JET's expense, but if it is determined there is no defect, or that the defect resulted from causes not
within the scope of JET's warranty, then the user must bear the cost of storing and returning the product. This warranty
gives you specific legal rights, and you have other rights,which vary, from state to state.
JET Equipment & Tools. P.O. Box 1349,Auburn, WA 98071-1349 .[phone]

~WARNING
Read and understand the entire instruction manual before operating machine.
This machine is designed and intended for use by properly trained and experienced personnel
only. If you are not familiar with the proper safe use of bandsaws, do not use this machine
until proper training and knowledge has been obtained.
"Warning: For your own safety read instruction manual before operationsaw"
(a)
(b}
(c)
(d)
(e)
Wear eye protection.
Do not remove jammed cut off pieces until blade has stopped.
Maintain proper adjustment of blade tension, blade guides, and trust bearing.
Adjust upper guide to just clear workpiece.
Hold workpiece firmly against table.
1.
2. Keep guards in placeand in working order.
Remove adjusting keys and wrenches. Form habit of checking to see that keys and adjusting
wrenches are removedfrom tool before turning it on.
Keepwork area clean. Cluttered areas and benches invite accidents.
Don't use in dangerous environment. Don't use power tools in damp or wet locations, or
expose them to rain. Keepwork area well lighted.
Keepchildren away.All visitors should be keptsafe distancefrom work area.
Makeworkshop kid proofwith padlocks, master switches,or by removingstarter keys.
Don't force tool itwill do thejob betterand safer at the ratefor which it was designed.
Use right tooldon't force tool or attachmentto do ajob for which itwas not designed.
Use proper extensioncord. Madesure yourextension cord is ingood condition.When using an
extension cords, be sure to use one heavy enough to carry the current your product will draw.
An undersized cord will cause a drop in voltage resulting in loss of power and overheating.
Table shows the correct size to use depending on cord length and nameplate ampere rating. If
in double, use the next heaviergage. The smaller the gage number,the heavierthe cord.
Wear proper apparel do not wear loose clothing, gloves, neckties, rings, bracelets, or other
jewelry which may get caught in moving parts. Nonslip footwear is recommended. Wear
protective hair coveringto contain long hair.
Always use safety glasses. Also use face or dust mask if cutting operation is dusty. Everyday
eyeglassesonly have impact resistant lenses,they are NOT safety glasses.
Secure work. Use clamp or a vise to hold work when practical. It is safer than usingyour hand
and it frees both hands to operate tool.
Don't overreach. Keep properfooting and balanceat alltimes.
Maintain tools with care. Keep tools sharp and clean for best and safest performance. Follow
instructionsfor lubricatingandchanging accessories.
Disconnect tools before servicing; when changing accessories, such as blades, bits, cutters
and the like.
Reduce the rise of unintentionalstarting. Make sure switch is in off position beforeplugging in.
Use recommended accessories. Consult the owner's manual for recommended accessories.
The use of improperaccessories may cause risk of injuryto person.
Some dust created by power sanding, sawing, grinding, drilling and other construction activities
contains chemicals known to cause cancer, birth defects or other reproductive harm. Some
examples of these chemicals are:
.Leadfrom lead based paint
.crystalline silica from bricks and cement and other masonry products, and
.arsenic and chromium from chemically-treatedlumber.
Never stand on tool serious injury could occur if the tool is tipped or if the cutting tool is
unintentionallycontacted.
Check damaged parts. Before further use the tool, a guard or other part that is damaged
should be carefully checked to determine that it will operate properlyand perform its intended
function - check for alignment of moving parts, binding of moving parts, breakage of parts,
mounting, and any other conditions that may affect its operation. A guard or other part that is
damagedshouldbeproperlyrep~iredorreplaced.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.
17.
18.
19.
20.
1

21. Direction of feed work into a blade or cutter against the direction of rotation of rotation of the
bladeor cutter only.
22. Never leave tool running unattended. Turn power off. Don't leave tool until it comes to a
complete stop.
Table
Minimum gage for cord
2
Volts Totallengthof cordinfeet
120V 25ft. 50ft. 100ft. 150ft.
AmpereRating 240V 50ft. 100ft. 200ft. 300ft.
Not
More More
Than Than AWG
06 18 16 16 14
6 10 18 16 14 12
10 12 16 16 14 12
12 16 14 12 NotRecommended
Onlythe applicableparts0theTableneedto beincluded,Forinstance,a
120-voltproductneednotincludethe240-voltheading

Gro~nding Instructions
Caution: This tool must be grounded while in use to protect the operator from electric shock.
In the event of a malfunctionor breakdown,grounding providesa path of least resistancefor electric
current to reducethe risk of electric shock. This tool is equippedwith an electric cord having an
equipment-groundingconductor anda grounding plug. The plugmust be pluggedinto a matching
outlet that is properlyinstalled and grounded in accordancewith all localcodes and ordinances.
Do not modifythe plug provided. If itwill notfit the outlet,havethe properoutlet installed bya qualified
electrician.
Improperconnection of the equipment-groundingconductorcan result in a risk of electric shock. The
conductor, with insulation havingan outer surface that is greenwith or without yellowstripes, is the
equipment-groundingconductor. If repair or replacement of the electric cord or plug is necessary,do
not connect the equipment-groundingconductor to a liveterminal.
Check with a qualified electricianor service personnelif the grounding instructionsare not completely
understood,or if indoubt as to whether the tool is properlygrounded. Use onlythreewire extension
cords that havethree-prong grounding plugs andthree-polereceptaclesthat accept the tool's plug.
Repairor replace a damaged or worn cord immediately.
This tool is intended for use on a circuit that has an outlet that looks like the one illustrated in sketch A.
The tool has a grounding that looks like the plug illustrated in sketch A. A temporary adapter, which
looks like the adapter illustrated in sketches Band C, may be used to connect this plug to a 2-pole
receptacle as show in sketch B if a properly until a properly grounded outlet can be installed by a
qualified electrician. (This adapter is not permitted in Canada) The green-colored rigid ear, lug, the like,
extending from the adapter must be connected to a permanent ground such as a properly grounded
outlet box.
This tool is intended for use on a circuit that has an outlet that looks like the one illustrated in sketch D.
The tool has a grounding that looks like the plug illustrated in sketch D. Make sure the tool is
connected to an outlet having tf;le same configuration as the plug. No adapter is available or should be
used with this tool. If the tool must be reconnected for use on a different type of electric circuit, the
reconnection should be made by qualified service personnel; and after reconnection, the tool should
comply with all local codes and ordinances.
Grounding methods
~
GROUNDINQ
PIN
(Q)
.
(Q) METAL SCRE\.!
COVER or GROUNDED
OUTLET BOX
(A)
ADAPTER
~GROUNDING
~M(ANS '''~~
~p~N~
~
~<D)
3

The conversion from 115Vto 230Voperation must be done by a qualified electrican.
1
B1ue
1t5VOft
3 2 4
Bn1wn YeliCIN White
1
Blue:
230Vote
234
Yellow 8rownWbite
U
UNI! ~E UJE UtE:
Chart 1Chart 2
4

it WARNING
.Read and understand the entire
instruction manual before attempting
assembly or operation.
This bandsaw is designed and intended
for use by properly trained and
experienced personnel only. If you are
not familiar with the proper and safe
operation of a bandsaw, do not use until
proper training and knowledge nave
been obtained.
.
.Make certain the machine is properly
grounded.
.Before operating the machine, removetie,
rings, watches, otherjewelry, and roll up
sleeves above the elbows. Remove all
loose clothing and confine long hair. Do
not wear gloves.
.Keepthe floor around the machine clean
and free of scrap material, oil andgrease.
.Keep machine guards in place at all times
when the machine is in use. If removedfor
maintenance purposes, use extreme
caution and replace the guards
immediately.
.Do not over reach. Maintaina balanced
stance at all times so that you do not fall or
lean against blades or other moving parts.
.Make all machine adjustments or
maintenance with the machine unplugged
from the power source.
.Use.theright tool. Don't force a tool or
attachment to do a job which it was not
designed for.
.Replace warning labels if they become
obscured or removed.
.Make certain the motor switch is in the off
position before connecting the machine to
the power supply.
.Give your work undivided attention.
Lookingaround,carrying on a
conversation,and "horse-play" are careless
acts that can resultin serious injury.
.Keepvisitors a safe distance from the work
area.
.Use recommendedaccessories; improper
accessories may be hazardous.
.Makea habitof checking to see that keys
and adjustingwrenches are removed
beforeturning on the machine.
.Always keep handsandfingers away from
the bladewhen the machine is running.
.Never holdthe material with the saw in the
horizontalposition. Always use the vise
and clamp it securely.
.Readand understandwarnings posted on
the machine.
.Keepthe belt guard and wheel covers in
placeand inworking order.
.Always provideadequate support for long
and heavy material.
.Usea sharp blade and keep machine clean
for best and safest performance.
.Failureto complywith all of these warnings
may cause serious injury.
.WARNING: Some dust created by power
sanding, sawing, grinding, drilling and other
construction activities contains chemicals
known to cause cancer, birth defects or other
reproductive harm.
Some examples of these chemicals are:
.Lead from lead based paint
.crystalline silica from bricks and cement
and other masonry products, and
.arsenic and chromium from chemically-
treated lumber.
.Your risk from those exposures varies,
depending on how often you do this type of
work. To reduce your exposure to these
chemicals: work in a well ventilated area,
and work with approved safety equipment,
such as those dust masks that are specifically
designed to filter out microscopic particles

Specifications HVBS-7MW
Stock Number 414459
Capacity:
Round 7"
Rectangle 7" X12"
Throat Depth '.'"'''''''''''''''''''''''''' 7"
Vertical Worktable 9-3/8"x 10"
Vise Tilts 45°
Blade Speed 86, 132, 178,260 SFPM
Motor UL Listed 3/4 HP, 1 Ph, 115/230V
Prewired 115V
Floor Space Required 49-1/2" x 17-1/32"
NetWeight (approx.) 318 Lbs.
ShippingWeight (approx.) 345 Lbs.
Table of Contents
Warning 1
Specifications 2
Table of Contents 2
Shipping Container Contents 3
Tools Requiredfor Assembly 3
Unpacking and Clean-Up ... ... ... ............... """""""""'" ..3
Assembly ... ... ... ............... 3
Vertical Cutting PlateAssembly 4
Coolant Tank Preparation 4
Electrical Connections ...5
Hydraulic Feed Selector Operation 6
Priorto Operation ...6
Changing.Blade Speed 6
Adjusting BladeGuides.. ...... ... ...... ... ... ... ... 7
Vise Adjustment 7
Adjusting Blade Tension 8
Changing Blades 9
Adjusting Blade Square to Table 10
Adjusting Blade Square to Vise ..." 10
Adjusting Blade Tracking... 11
AdjustingBladeGuideBearings ,12
Adjusting Bow Weight 12
Adjusting Automatic Shut-Off 13
Lubrication 13
Maintenance .14
Chip Cleaning Brush 14
Parts Breakdowns 15-16
Parts List .. .. 17-19
Electrical Schematic .20
The specifications in this manualare given as general informationand are not binding. JET Equipment
and Tools reserves the right to effect, at any time andwithout prior notice, changes or alterations to parts,
fittings, and accessory equipmentdeemed necessaryfor any reasonwhatsoever.
2

Shipping Container Contents
1 Saw
2 Wheel Axle
4 Wheel
4 Split Pin
1 Material Stop Bar
1 Material Stop
1 Belt Cover
1 Vertical Cutting Plate
Tools Required for Assembly
#2 Cross Point Screwdriver
Pliers
Unpacking and Clean-Up
1. Finish uncrating the saw. Inspect it for shipping
damage. If any damage has occurred, contact
your distributor.
2. Unboltthe saw from the skid and placeit on a
level surface.
3. Clean rust protected surfaceswith kerosene,
diesel oil, or a mild solvent. Do not use cellulose
based solvents such as paintthinner or lacquer
thinner. These will damage paintedsurfaces.
Assembly
1. Place blocking under the ends of the saw base
to allow wheel installation. Caution: Make sure
saw is steady while temporarily supported.
2. Slide wheel axles through the holes in the base.
3. Slide the wheels onto the axles and fastenwith
pins. Bend the pins to hold in place.
4. Slide the material stop bar (A, Fig. 1) into the
base and secure by tightening bolt (B, Fig. 1).
Slide the material stop (C, Fig. 1) onto the bar
and tighten bolt (D, Fig. 1).
5. Slide the belt cover over the pulley assemblies
and fasten with screws andwashers (A, Fig.2).
6. Close belt cover and secure with lock knob (8,
Fig. 2).
3
Fig.1
Fig.2

7. Remove transportation strap and keep for later
use should the saw be moved any distance.
Vertical Cutting Plate Assembly
Note: These steps are only necessary if using the
bandsaw in the vertical mode.
1. Disconnect the bandsaw from the power
source.
Raise the arm to the vertical positionby turning
the arm stop (A, Fig,2A) a quarterturn
clockwise, slowing bringthe arm to vertical, and
lock in place by turning the hydrauliccylinder
valve to the off position. Caution: Do not pinch
fingers between the arm stop and the arm
bracket.
3. Remove two screws (A, Fig. 3) and remove the
deflector plate (8, Fig. 3).
4. Guide the blade through the slot inthe table and
fasten with two screws. See Fig. 4.
5. To lower the arm, turn the hydraulic cylinder arm
to any of the on positions.
2.
Coolant Tank Preparation
Use of a water-soluble coolant will increasecutting
efficiency and prolong blade life. Do not use black
cutting oil as a substitute. Changecutting oil often
and follow manufacturers instructions as to its uses
and precautions.
1. Disconnect the machine from the power
source.
2. Remove the coolant return hose from the tank
cover.
3. Slide the tank out of the saw base and carefully
remove the lidcontaining the coolant pump.
Fillthe tank to approximately 80% of capacity.
Place the lid back onto the tank and placethe
tank assembly back into the base.
Replace the return hose back into the hole in the
tank lid.
4.
5.
6.
,.;.
"- ",---.
-~ \I
A
Fig.2A
A
Fig.3
Fig.4
4

Electrical Connections
The HVBS-7MW bandsaw is rated at 115/230Vand
comes from the factory prewiredat 115V. To switch
to 230V operation, follow the wiring diagramfound
on the insideof the motorjunction box. Theplug
end will have to replacedwith a plugthat is ratedat
230V. The coolant pump wiring will have to be
changed also. Followthe diagramfound on the
cooling pump headto switch to 230Voperation.
This bandsaw is designed for use on a circuitwith an
outlet that looks like (A) in Figure 5. The bandsaw
has a grounding prongas illustratedin (B). A
temporary adapter (C) may be usedto connectthe
plug to a two pole receptacle(0) if a properly
grounded outlet is not available. The temporary
adapter should only be used until a properly
grounded outlet can be installed bya qualified
electrician. The green colored lug mustbe securely
fastened to the cover platescrew.
Before hooking up to the powersource, besure the
power and coolant switches are in the off position.
Hydraulic Feed Selector Operation
The hydraulic feed selector is used to control the
bladefeed rate and to lockthe arm inthe vertical
position. To increase the feed rate,turn knob (A,
Fig.6) counter-clockwise. To decrease the feed
rate, turn knob (A, Fig.6) clockwise. Toturn off the
flow of hydraulic fluid, turn lever as infigure 6. To
turn the hydraulic cylinder on, raise lever (B, Fig.6)
to the 12o'clock position.
For a detailed discussion of properfeed rate and
cutting speed, referto the enclosed booklet"Lenox
Guide to Bandsawing"published byAmerican Saw
Manufacturing Company. Used by permission.
5
CURRENT CARRYING PRONGS
,~ IA/
GROUND PRONG
w
e
~
Fig. 5
Fig.6

Prior to Operation
1. Check to see that the blade tooth direction
matches the diagram on saw body.
2. Check to see that the bladeis properlyseated
on the wheels after propertension has been
applied.
3. Set the bladeguide roller bearingssnug against
blade. See "Adjusting Blade Guide Bearings"for
more detail.
4. Check for a slight clearance betweenthe back
up rollers and the back of the blade.
5. Position both blade guides as close to work as
possible.
6. Select proper speed and feed rate for material
being cut. See the enclosed "LenoxGuideto
Bandsawing"for further information.
7. Material to be cut must be held securelyinvise.
8. Check to see that coolant level is adequate.
9. Do not start a cut on a sharp edge.
1O. Keep the machine lubricated. See the
"Lubrication" section.
Changing Blade Speed
1. Disconnect the machinefrom the power
source.
2. Loosen the motor plate lock bolt (A, Fig. 7).
3. Loosen motor plate slide bolt (B, Fig. 7) untilthe
belt can be moved on the the pulleys.
4. Move the belt to the the desired pulley
combination.
5. Tighten the motor plateslide bolt (B, Fig.7) to
re-tension belt.
6. Tighten the motor plate lock bolt (A).
7. Connect the machine to the power source.
Fig.7
6

Adjusting the Blade Guides
1. Disconnect the machinefrom the power
source.
2. Loosen knob (A, Fig.8) and bolt (B, Fig. 8).
Slide te blade guide assembliesas closeas
possible to the the materialwithout interfering
with the cut.
3. Tighten knob (A, Fig. 8) and bolt (B, Fig. 8) and
connect machine to the power source.
Vise Adj ustment
.!..) WARNING
To set the vise for 0 to 45 degree cutting:
1. Remove the bolt and nut assemblies (C, Fig. 9).
2. Positionthe vise and re-installas picturedin Fig.
10. Pay particular attentionto the bolt hole
location.
3. Set the vise to desired angle, re-install nutsand
bolts, and tighten the nut and bolt assemblies.
4. Adjust the movable vise parallelto the fixedvise
by loosening bolt (A, Fig.10),adjustingto
parallel, and tightening bolt.
To set vise for maximumwidth of stock cutting:
1. Remove the nut and bolt assemblies.
2. Position the vise and re-installthe bolt
assemblies as pictured in Fig9.
Fig.8
"-
Fig.9
Fig.10
7

Adjusting Blade Tension
Bladetension is important to the properoperationof
the saw. Proper bladetension is 22,000 to 25,000
Ibs. per square inch as measuredon a blade tension
gauge.
To set the bladetension without the use of a blade
tension gauge:
3. Turn the blade tension knob (A, Fig. 11)one and
three quarter to two revolutionsclockwise. This
equals approximately23,000 Ibs.of blade
tension.
A
r
1. Installthe blade betweenthe wheel and insert
blade between the bearingson the bladeguides.
2. Tension the blade slightlyto removeany sag in
blade betweenthe bladewheels.
CAUTIONI
Fig.11
4. After the blade has beencompletely installed,
close the covers. connect to the power source,
and run saw for two to three minutesso the
blade can seat properly.
r
5. Disconnectthe machinefrom the power source.
Open the cover and loosen thebladejust until it
begins to sag.
6. Tighten the blade until it becomes straight
between the blade wheel and all sag has been
eliminated.
7. Tighten the blade byturning the blade tension
wheel two full revolutions. Bladeis now properly
tensioned and ready for use.
8. Close the covers and connectthe machineto
the power source.
8

Changing Blades
1. Disconnect the machinefrom the power
source.
2. Raise the saw arm to the vertical positionand
lock in place by turning the hydrauliccylinder off.
3. Remove the red blade guard assembly (A, Fig.
12) by removing two screws (B, Fig.12).
4. Remove the brush assembly (C, Fig. 12) by
removing two screws (0, Fig. 12).
5. Loosen blade tension by turningthe blade
tension knob counter-clockwise.
6. Carefully remove the old blade. Caution:
blade teeth are sharp. Handlewith care.
7. Install the new blade by placingthe blade
between blade guides first. Makesure the blade
teeth face the same direction as indicatedon the
label found on the saw arm.
8. Placethe bladearound bothwheels. Makesure
the blade edge rests near thewheel flange on
both wheels.
Fig.12
9

9. Turn the bladetension knobclockwiseto tension
the blade. Do not over tension. See section
titled "Adjusting BladeTension",
10. Close the blade cover door and securewith lock
knobs.
11. Attach the red blade guard and brushassembly.
12. Connect the machineto the power source.
13. Runthe saw and make sure bladeistracking
properly.
For a discussion on blade selection, see the
enclosed booklet entitled "Lenox Guide to
Bandsawing".
Adjusting Blade Square to Table
1. Disconnect machinefromthe powersource.
2. Place a machinist'ssquare on the table nextto
the blade as pictured in Fig. 13.
3, Check to see that the blade makescontactwith
square along the entirewidth of the blade.
4. If adjustment is necessary, loosenbolts (A, Fig.
13) and rotate the blade guide assemblies
slightly in the same direction untilthe blade
makes contact with the squarealong it'sentire
width.
5. Tighten bolts (A, Fig. 13).
6. Connect the machineto the power source.
Note: If adjustment to square blade to table is
necessary, be sure to check blade adjustments
again.
Adjusting Blade Square to Vise
1. Disconnect the machine from the power
source.
2. Place a machinist'ssquare as picturedin Figure
14. Square should lie along the entire length of
vise and blade without a gap.
----
Fig.13
Fig.14
10

3. If adjustment is necessary, loosenthe bolts
holding the vice and adjust the vise so that the
square lines up properly.Tighten bolts.
4. Connect machineto the power source.
Adjusting Blade Tracking
Note: Before making any tracking adjustments, try a
new blade. Warped blades will not track.
Blade tracking has been set at the factory and
should not require adjustment. If a tracking
problems occurs, adjust the machine as follows:
1. Move the saw arm to the vertical positionand
lock in place by shuttingoff the hydraulic
cylinder valve.
2. Confirm that bladetension is set properly. To
adjust, see section titled "AdjustingBlade
Tension".
3. Open the back cover by looseningthe lock
screws.
5. Loosen bolts (A, Fig. 15).
B
4. Run the saw and observe the blade. Blade
should run next to but nottightly againstwheel
flange.
6. Turn set screw (B, Fig. 15)while observingthe
blade tracking on the wheel. Turn the set screw
clockwise to track the bladecloser to the wheel
flange. Turn the set screw counter-clockwiseto
track blade away from the wheel flange.
7. Once tracking is set, tighten bolts (A, Fig. 15).
Fig.15
11

Adjusting Blade Guide Bearings
1. Disconnect the machine from the power
source.
2. Raise the arm to theverticalpositionand lockin
place byturningoffthe the hydrauliccylinder
valve.
3. Loosen the hex cap screw (A,Fig. 16)and
adjust assembly so that the back rollerbearing
is approximately.003"- .005"fromthe back of
the blade.
4. Turn nut (B, Fig. 16) to adjust the eccentric
bearing snug to the blade. Blade should still
move up and down freely when grasped as in
Fig. 17. Warning! Makesure power is
disconnected and hands are protected
before handling blade. ~e sure that the blade
teeth do not interferewith the roller bearings.
5. Repeatfor the other bladeguide assembly.
6. Connect machineto the power source.
Adjusting Bow Weight
Bowweightis one of the most importantadjustments
of the saw. Ifthe bow weight is not set properly, one
can expect poor performance,crooked cuts, tooth
stripping, stalling, and the blade poppingoff the
bladewheels. The hydraulicfeed rate unitwill not
compensate for improper bowweight. Bowweight
has been set at the factory and should not need
adjustment. If adjustment is necessary:
1. Disconnect the machine from the power
source.
2. Turn the hydraulic cylinder valve on and place
the the saw arm in horizontal position.
3. Turn feed ratevalve on hydrauliccylinder
counter-clockwise until it stops.
B
Fig.16
Fig.17
12

4. Place a fish-type scale under the bladetension
handle and lift the saw arm. Scale should
indicate approximately 13-15 Ibs.
5. Adjust tension to approximately 13-15 Ibs.by
turning bolt (At Fig. 18).
6. Connect the machineto the power source.
Adjusting Automatic Shutoff
The saw should stop after the cut has been
completed:
1. If the saw completes the cut and continuesto
run, adjust the stop tip (A, Fig. 19)down.
2. If the saw shuts off before the cut is complete,
adjust the stop tip (A, Fig. 19) up.
3. If the saw stops cutting but continues to run,
adjust the stop bolt (B, Fig. 19).
The saw is properly adjusted when the saw shuts off
just after the blade has finished the cut.
Lubrication
Ball bearings on the blade guide assembliesand the
bladewheels are permanently sealed and require no
lubrication.
Lightly lubricate the vise screw with #2 tube grease.
Change gear box oil after the first 90 days of
operation. There after, change every six months
To change gear box oil:
1. Disconnect the machine from the power
source.
2. Place the saw arm in the horizontalposition.
3. Remove screws (A, Fig.20) from the gear box
and remove the cover plate and gasket.
4. Hold a container under the lower right corner of
the gear box with one hand while slowly raising
the saw arm with the other.
Fig.18
}/
I
.
A
Fig.19
Fig.20
13

5. Placethe saw arm in the horizontalposition
again. Wipe out remainingoil with a rag.
6. Fill the gear box with approximately 3/4 pint of
90 weight gear oil.
7. Replace the gasket and cover. Fastenthe cover
with screws.
8. Connect machine tTthe power ~ource.
Maintenance
1. Keep all surfaces clean and free of rust, slag,
chips, and coolant build-up.
2. Do not use compressed air to clean the
bandsaw. Compressed air may force chips into
the guide bearings and other critical areasof the
saw.
3; Use a small paint brush or parts cleaning brush
to remove metal particles.
4. Wipe the saw downwith a clean, dry cloth and
oil all unpainted surfaces with light machineoil.
5. Keep the blade guides clean and free of metal
chips.
6. Checkthe guide bearings frequently to make
sure they are properly adjusted and turning
freely.
Chip Cleaning Brush
It is very important that the blade cleaning brush be
properly adjusted and kept in good working order.
Replace the brush if it becomes damaged or worn
out. Blade life will be shortened severely if the brush
is allowed to go out of adjustment, becomes
damaged, or is worn out.
14
