10" Bench Top Tablesaw
For a fast set-up and a quick cut, choose the new
JET 10" Bench Top Tablesaw. Exclusive features include the
Smooth Speed™ Belt Drive Transmission with Poly-V Belt,
which eliminates vibration to the blade, and the
Precision-Rule™ Measurement System for quick
identification of cutting capacity. Keep wood supported
through the cut by use of rapid extension wings and
a rear outfeed support, standard on both models.
708315LSB
708315BTC
BUILT BET TER TO BUILD BET TER™
Bench Top Tablesaw Sell Sheet.indd 1 8/17/05 3:30:21 PM

STOCK NUMBER 708315BTC 708315LSB
Model JBTS-10BT-3 JBTS-10LS-2
Rapid Wing Extensions 1 2
Leg Stand with Steel Storage Shelf No Yes
Dust Collection Adaptor Port No Yes
Motor 15 Amp, 120V 15 Amp, 120V
Blade Diameter (in.) 10 10
Arbor Diameter (in.) 5/8 5/8
Maximum Rip Cut Capacity (in.) 24-1/2 24-1/2
Maximum Cut Depth at 45º (in.) 2-1/2 2-1/2
Maximum Cut Depth at 90º (in.) 3 3
Maximum Width of Dado (in.) 1/2 1/2
Table Height from Surface/Ground (in.) 12 35
Table Size without Extension Wing(s) (L x W/in.) 18 x 33 18 x 33
Table Size with Extension Wing(s) (L x W/in.) 18 x 41 18 x 55
Overall Dimensions (W x D x H/in.) 33-1/2 x 18 x 14 39 x 18 x 35
Arbor Speed (RPM, no load) 5,000 5,000
Net Weight (lbs.) 52 79
jettools.com
10" BENCH TOP TABLESAW
5
YEAR
WARRANTY
10" BENCH TOP TABLESAW
See-through blade guard
with splitter and
anti-kickback fingers
Table insert for
easy blade and
dado changes
Smooth Speed™
Belt Drive Transmission
with Poly-V Belt
On-board
storage for
power cord,
rip fence,
miter gauge,
saw blade
and wrenches
Rear outfeed
support
Precision-Rule™
Measurement
System
Rapid wing
extension
708315BTC
708315LSB
■ Exclusive Design
Constructed with steel corner posts
for the toughest applications
■ Smooth Speed™ Belt Drive
Transmission with Poly-V belt
Eliminates vibrations to the blade and extends life of motor,
provides quieter operation and better transfer of power
■ Precision-Rule™ Measurement System
Provides quick identification of cutting capacity
up to 24-1/2" (when wing is fully extended)
■ Rapid Wing Extension
Expands work surface up to 41" (with single extension)
or 55" (with two extensions) for additional support
■ Leg Stand with Steel Storage Shelf
Converts tablesaw from benchtop to stationary
(standard with 708315LSB)
■ Precision Machined Miter Slots
Provides direct control of miter gauge resulting in better cuts
■ Dust Collection Adaptor Port
Connects either 2-1/2" shop vacuum or 4" dust collection
system (standard with 708315LSB)
■ Dual Function Hand Wheel
Raises and bevels blade for quick and accurate setup
■ Rear Outfeed Support
Provides outfeed support and also converts
to a left side extension
■ Contoured Side Handles
Allows easy lifting and mobility of saw
■ On-Board Storage
Convenient storage for power cord, rip fence,
miter gauge, saw blade and wrenches
Stock No. 900792
10M 08/05
©2005 WMH TOOL GROUP, Inc. All Rights Reserved.
