Jet JSS-16 User manual

GB - ENGLISH
Operating Instructions
Dear Customer,
Many thanks for the confidence you have shown in us with the purchase of your new JET-machine. This manual has been
prepared for the owner and operators of a JET JSS-16 scroll saw to promote safety during installation, operation and
maintenance procedures. Please read and understand the information contained in these operating instructions and the
accompanying documents. To obtain maximum life and efficiency from your machine, and to use the machine safely, read
this manual thoroughly and follow instructions carefully.
…Table of Contents
1. Declaration of conformity
2. JET Warranty
3. Safety
Authorized use
General safety notes
Remaining hazards
4. Machine specifications
Technical data
Noise emission
Contents of delivery
Description of the machine
5. Transport and start up
Transport and installation
Assembly
Dust connection
Mains connection
Starting operation
6. Machine operation
7. Setup and adjustments
Changing the sawblade
8. Maintenance and inspection
9. Troubleshooting
10. Available accessories
1. Declaration of conformity
On our own responsibility we hereby
declare that this product complies
with the regulations* listed on page 2.
Designed in consideration with the
standards**.
2. JET Group Warranty
The JET Group makes every effort to
assure that its products meet high
quality and durability standards and
warrants to the original retail
consumer/purchaser of our products
that each product be free from
defects in materials and workmanship
as follows:
2 YEARS ON ALL MECHANICAL
PARTS
1 YEAR ON ALL ELECTRICAL
PARTS
This Warranty does not apply to
defects due to directly or indirectly
misuse, abuse, negligence or
accidents, normal wear-and-tear,
repair or alterations outside our
facilities, or to a lack of maintenance.
The Jet group limits all implied
warranties to the period specified
above, from the date the product was
purchased at retail.
To take advantage of this warranty,
the product or part must be returned
for examination, postage prepaid, to
an authorized repair station
designated by our office.
Proof of purchase date and an
explanation of the complaint must
accompany the merchandise.
If our inspection discloses a defect,
we will either repair or replace the
product, or refund the purchase price
if we cannot readily and quickly
provide a repair or replacement, if
you are willing to accept a refund.
We will return repaired product or
replacement at JET’S expense, but if
it is determined there is no defect, or
that the defect resulted from causes
not within the scope of JET’S
warranty, then the user must bear the
cost of storing and returning the
product.
The JET Group reserves the right to
make alterations to parts, fittings, and
accessory equipment which they may
deem necessary for any reason
whatsoever.
3. Safety
3.1 Authorized use
This machine is designed for sawing
wood, wood derived materials as well
as similar to be machined hard
plastics only.
Machining of other materials is not
permitted and may be carried out in
specific cases only after consulting
with the manufacturer.
The proper use also includes
compliance with the operating and
maintenance instructions given in this
manual.
The machine must be operated only
by persons familiar with its operation
and maintenance and who are
familiar with its hazards.
The required minimum age must be
observed
The machine must only be used in a
technically perfect condition
When working on the machine, all
safety mechanisms and covers must
be mounted.
In addition to the safety requirements
contained in these operating
instructions and your country’s
applicable regulations, you should
observe the generally recognized
technical rules concerning the
operation of woodworking machines.
Any other use exceeds authorization.
In the event of unauthorized use of
the machine, the manufacturer
renounces all liability and the
responsibility is transferred
exclusively to the operator.
3.2 General safety notes
Woodworking machines can be
dangerous if not used properly.
Therefore the appropriate general
technical rules as well as the
following notes must be observed.
Read and understand the entire
instruction manual before attempting
assembly or operation.
Keep this operating instruction close
by the machine, protected from dirt
and humidity, and pass it over to the
new owner if you part with the tool.
No changes to the machine may be
made.
Daily inspect the function and
existence of the safety appliances
before you start the machine.
Do not attempt operation in this case,
protect the machine by unplugging
the mains cord.

Remove all loose clothing and
confine long hair.
Before operating the machine,
remove tie, rings, watches, other
jewellery, and roll up sleeves above
the elbows.
During machine operation the
transparent sawguard must always
be lowered to the workpiece
Insure that the workpiece does not
roll when cutting round pieces.
Use suitable table extensions and
supporting aids for difficult to handle
workpieces.
Never cut pieces that are too small.
During cutting operation the
workpiece must firmly be pressed
against the table surface.
Do not perform any operation
freehand.
Remove cut and jammed workpieces
only when motor is turned off and the
machine is at a complete standstill.
Do not reach under the scroll saw
table when the motor is running.
Install the machine so that there is
sufficient space for safe operation
and workpiece handling.
Keep work area well lighted.
The machine is designed to operate
in closed rooms and must be placed
stable on firm and levelled ground.
Make sure that the power cord does
not impede work and cause people to
trip.
Keep the floor around the machine
clean and free of scrap material, oil
and grease.
Stay alert!
Give your work undivided attention.
Use common sense.
Do not operate the machine when
you are tired.
Do not operate the machine under
the influence of drugs, alcohol or any
medication. Be aware that medication
can change your behaviour.
Keep children and visitors a safe
distance from the work area.
Never reach into the machine while it
is operating or running down.
Never leave a running machine
unattended. Before you leave the
workplace switch off the machine.
Do not operate the electric tool near
inflammable liquids or gases.
Normal brushfire might ignite.
Observe the fire fighting and fire alert
options, for example the fire
extinguisher operation and place.
Do not use the machine in a dump
environment and do not expose it to
rain.
Wood dust is explosive and can also
represent a risk to health.
Dust form some tropical woods in
particular, and from hardwoods like
beach and oak, is classified as a
carcinogenic substance.
Always use a suitable dust extraction
device
Before machining, remove any nails
and other foreign bodies from the
workpiece.
Specifications regarding the
maximum or minimum size of the
workpiece must be observed.
Do not force the power tool. It will do
a better and safer job and give you
much better service if it is used at the
rate for which it was designed.
Never operate with the guards not in
place –serious risk of injury!
Connection and repair work on the
electrical installation may be carried
out by a qualified electrician only
Always unwind any extension cords
fully.
Damaged extension cords replace
immediately.
Do not use the power tool if the
ON/OFF switch does not turn the
power tool ON and OFF.
Make all machine adjustments or
maintenance with the machine
unplugged from the power source.
Remove defective saw blades
immediately.
3.3 Remaining hazards
When using the machine according to
regulations some remaining hazards
may still exist
The moving saw bladein the work
area can cause injury.
Broken saw blades can cause
injuries.
Thrown workpieces can lead to injury
Wood chips and sawdust can be
health hazards. Be sure to wear
personal protection gear such as
safety goggles ear- and dust
protection.
Use a suitable dust exhaust system.
The use of incorrect mains supply or
a damaged power cord can lead to
injuries caused by electricity.
4. Machine specifications
4.1 Technical data
Saw blade length, pin type 127mm
Blade stroke 15mm
Blade speed 400~1600 SPM
Max cutting height at 90° 50mm
Table size 410x253mm
Table tilt 0°/45°left
Throat 406mm
Dust port diameter 35mm
Overall (LxWxH) 620x285x325mm
Weight 12 kg
Mains 230V ~1L/N/PE 50-60Hz
Motor power 90W
Reference current 0,6 A
Extension cord H05VV-F 3G1mm²
Installation fuse protection 10A
4.2 Noise emission
Determined according to EN
1807:1999 (Inspection tolerance 4 dB)
Acoustic power level (acc. EN 3746):
Idling 79,2 dB (A)
Acoustic pressure level (EN 11202):
Idling 72,1 dB (A)
The specified values are emission
levels and are not necessarily to be
seen as safe operating levels. This
information is intended to allow the
user to make a better estimation of
the hazards and risks involved.
4.3 Content of delivery
1 Scroll saw
1 Transparent blade guard
1 Air blower
1 Allen key 4mm
1 Allen key 3mm
Set of 5 saw blades
Operating manual
Spare parts list

4.4 Scroll saw description
Fig 1
A….Blade tension knob
B….Bearing covers
C….Table
D….Sawdust blower
E…..Blade and key storage area
F….Mounting holes
G….Bevel scale
H….Bevel lock knob
I…..Lower blade holder
J….Transparent sawguard
K….Blade guard lock knob
Fig 2
L…..Upper blade holder
M….Table insert
N….Dust connection port
O….ON/OFF button
P….Variable speed control knob
Q….Table 90° adjusting screw
5. Transport and start up
5.1 Transport and installation
The machine is designed to operate
in closed rooms and must be placed
stable on firm and levelled surface.
The machine can be bolted down if
required.
For packing reasons the machine is
not completely assembled.
5.2 Assembly
If you notice any transport damage
while unpacking, notify your supplier
immediately. Do not operate the
machine!
Dispose of the packing in an
environmentally friendly manner.
Clean all rust protected surfaces with
a mild solvent.
Mounting the sawdust blower:
Mount the sawdust blower (D, Fig 3)
and point it towards the cutting area.
Fig 3
The sawdust blower keeps the work
area clean.
Mounting the transparent blade
guard:
Mount the transparent sawguard
guard (J) to the vertical guide rod.
Fig 4
Note:
During machine operation the
sawguard must always be lowered
to the workpiece
5.3 Dust connection
The machine has a 35mm dust port
(N, Fig 2) where it can be connected
to a dust extractor.
5.4 Mains connection
Mains connection and any extension
cords used must comply with
applicable regulations.
The mains voltage must comply with
the information on the machine
licence plate.
The mains connection must have a
10A surge-proof fuse.
Only use power cords marked
H05VV-F
Connections and repairs to the
electrical equipment may only be
carried out by qualified electricians.
5.5 Starting operation
You can start the machine with the
ON/ OFF button.
The machine has variable speed 400-
1600 SPM for cutting various
materials.
With the variable speed control knob
(P) the cutting speed can be chosen.
6. Machine operation
Correct working position:
In front of the machine standing in the
direction of cutting.
Workpiece handling:
Insure that the workpiece does not
roll when cutting round pieces.
Use suitable table extensions and
supporting aids for difficult to handle
workpieces.
Never cut pieces that are too small.
Press the workpiece down against
the table to avoid ancontrollable
lifting.
Remove the workpiece from the
blade prior to turning the scroll saw
ON.
Feed the workpiece towards the
sawblade in the direction of the
sawline, and cut as required by
turning to follow the line drawn.
Do not perform any operation
freehand.
Attention:
Always observe the safety
instructions and adhere to the current
regulations.
Ensure that the transparent sawguard
is lowered to the workpiece before
you start sawing.
Do not reach under the scroll saw
table when the motor is running.

The condition of the sawblade should
be checked before each machining
process.
Work only with a sharp and flawless
sawblade.
Bevel cutting:
The table can be tilted between 0°
and 45° for bevel cutting.
Loosen the locking knob (H).
Fig 5
Tilt the table to the left until the
desired angle on the scale (G) has
been reached.
Retighten the locking knob.
Fig 6
Attention:
Angle cutting requires more care.
Be careful.
7. Setup and adjustments
General note:
Setup and adjustment work may
only be carried out after the
machine is protected against
accidental starting by pulling the
mains plug.
7.1 Changing the sawblade
The machine accepts pin blades and
plain end blades.
Check sawblade for flaws (cracks,
broken teeth, bending) before
installation. Do not use faulty
sawblades.
The sawblade teeth must point in
cutting direction (down)
The sawblades may only be
changed when the mains plug is
pulled!
Open the transparent sawguard.
Remove the table insert (M)
Release blade tension.
Fig 7
The quick release blade tension knob
(A) allows a quick and easy blade
change.
Fig 8
Loosen the upperand lower blade
holder screws (L and I).
Fig 9
Replace the sawblade.
The teeth of the blade must point in
the cutting direction (down).
The sawblade tension can be
adjusted by turning the tension knob.
Fig 10
Turn clockwise to increase tension
(Fig 10).
Reposition the table insert and the
transparent sawguard.
8. Maintenance and inspection
General notes:
Maintenance, cleaning and repair
work may only be carried out after
the machine is protected against
accidental starting by pulling the
mains plug.
Repair and maintenance work on the
electrical system may only be carried
out by a qualified electrician.
Clean the machine regularly.
Inspect the proper function of the dust
extraction daily.
All protective and safety devices must
be re-attached immediately after
completed cleaning, repair and
maintenance work.
Defective safety devices must be
replaced immediately.
Cleaning:
Regularly clean the machine housing
with a soft cloth preferably after each
use.
If the dirt does not come off use a soft
cloth moistened with soapy water.
Never use solvents such as petrol,
alcohol, ammoniac water, etc. These
solvents may damage the plastic
parts.
Saw blades:
Only use sharp saw blades.
Lubrication:
Lubricate the arm bearings after
every 50 hours of use.

Fig 11
Remove the 4 bearing covers (B).
Apply a generous amount of light oil
(SAE 20).
Replace the bearing covers.
Motor brushes:
The collector brushes are due to wear
and may need replacement.
- Disconnect the machine form the
power source, pull mains plug.
-remove the brush covers.
-Replace the collector brushes
(Jet Article Number: JSS16-083
….2 pieces needed).
-reattach the brush covers.
9. Trouble shooting
Motor doesn’t start
*No electricity-
check mains and fuse.
*Defective switch, motor or cord-
consult an electrician.
*Motor brushes worn-
Replace brushes.
Machine vibrates excessively
*Stand on uneven surface-
adjust base for even support.
Cut is not square
*Bevel stop setting is bad.
Cutting surfaces is bad
*Wrong sawblade used
*resin collection on sawblade
*sawblade is dull
*sawblade damaged-
replace sawblade immediately
*workpiece inhomogeneous
*Feed pressure too high-
Do not force the workpiece.
10. Available accessories
Stock number 10000809
Set of 5 sawblades
