Jet JSS-16A User manual





JSS‐16A SCROLLSAW

Original:
GB
OperatingInstructions

Translations:
D
Gebrauchsanleitung

F
Moded´emploi






















JPW(Tool)AG
Tämperlistrasse5
CH‐8117Fällanden
Switzerland
Phone +41448064748
Fax +41448064758

www.jettools.com


M‐10000808MA2017‐03



CE‐ConformityDeclaration
CE‐Konformitätserklärung
DéclarationdeconformitéCE

Product/Produkt/Produit:
ScrollSaw
Dekupiersäge
Scieàchantourner
JSS‐16A
10000808MA
Brand/Marke/Marque:
JET
Manufacturer/Hersteller/Fabricant:
JPW(Tool)AG,Tämperlistrasse5,CH‐8117Fällanden,Switzerland
Weherebydeclarethatthisproductcomplieswiththeregulations
Wirerklärenhiermit,dassdiesesProduktderfolgendenRichtlinieentspricht
Parlaprésente,nousdéclaronsqueceproduitcorrespondauxdirectivessuivantes

2006/42/EC
MachineryDirective/Maschinenrichtlinie/DirectiveMachines

2014/30/EU
electromagneticcompatibility/elektromagnetischeVerträglichkeit/compatibilitéélectromagnétique

designedinconsiderationofthestandards
undentspechendfolgenderzusätzlicherNormenentwickeltwurde
etétédéveloppédanslerespectdesnormescomplémentairessuivantes

ENISO12100:2010
EN61029‐1:2009+A11:2011
EN55014‐1:2006+A1+A2:2011
EN55014‐2:2015


ResponsiblefortheDocumentation/Dokumentations‐Verantwortung/RésponsabilitédeDocumentation:
HansjörgMeier
HeadProduct‐Mgmt/LeiterProdukt‐Mgmt./Resp.deGestionsProduits
JPW(Tool)AG






2017‐03‐15AlainSchmid,GeneralManager
JPW(Tool)AG,Tämperlistrasse5,CH‐8117Fällanden,
Schweiz/Suisse/Switzerland


GB‐ENGLISH
OperatingInstructions

DearCustomer,
ManythanksfortheconfidenceyouhaveshowninuswiththepurchaseofyournewJET‐machine.Thismanualhasbeenprepared
fortheownerandoperatorsofaJETJSS‐16Ascrollsawtopromotesafetyduringinstallation,operationandmaintenance
procedures.Pleasereadandunderstandtheinformationcontainedintheseoperatinginstructionsandtheaccompanyingdocuments.
Toobtainmaximumlifeandefficiencyfromyourmachine,andtousethemachinesafely,readthismanualthoroughlyandfollow
instructionscarefully.

…TableofContents
1.Declarationofconformity
2.Warranty
3.Safety
Authorizeduse
Generalsafetynotes
Remaininghazards
4.Machinespecifications
Technicaldata
Noiseemission
Contentsofdelivery
Machinedescription
5.Transportandstartup
Transportandinstallation
Assembly
Dustconnection
Mainsconnection
Startingoperation
6.Machineoperation
7.Setupandadjustments
Changingthesawblade
Sawbladeswithpin
Sawbladeswithoutpin
8.Bladeselection
9.Maintenanceandinspection
10.Troubleshooting
11.Environmentalprotection
12.Availableaccessories

1.Declarationofconformity
Onourownresponsibilityweherebydeclarethatthisproduct
complieswiththeregulationslistedonpage2.
Designedinconsiderationofthestandards.

2.Warranty
TheJPW(Tool)AGguaranteesthatthesuppliedproductisfree
frommaterialdefectsandmanufacturingfaults.
Thiswarrantydoesnotcoveranydefectswhicharecaused,
eitherdirectlyorindirectly,byincorrectuse,carelessness,
accidentaldamage,repair,inadequatemaintenanceor
cleaningandnormalwearandtear.
Anywarrantydetails(i.e.warrantyperiod)canbefoundinthe
GeneralTermsandConditions(GTC)thatare
integralpartofthecontract.TheseGTCcanbeviewedatthe
websiteofyourdealerorsenttoyouuponrequest.
JPW(Tool)AGreservestherighttomakechangestothe
productandaccessoriesatanytime.

3.Safety
3.1Authorizeduse
Thismachineisdesignedforsawingwood,woodderived
materialsaswellassimilartobemachinedhardplasticsonly.
Machiningofothermaterialsisnotpermittedandmaybe
carriedoutinspecificcasesonlyafterconsultingwiththe
manufacturer.
Theworkpiecemustallowtosafelybeloaded,supportedand
guided.
Theproperusealsoincludescompliancewiththeoperating
andmaintenanceinstructionsgiveninthismanual.
Themachinemustbeoperatedonlybypersonsfamiliarwith
itsoperation,maintenanceandrepairandwhoarefamiliar
withitshazards.
Therequiredminimumagemustbeobserved
Themachinemustonlybeusedinatechnicallyperfect
condition
Whenworkingonthemachine,allsafetymechanismsand
coversmustbemounted.
Inadditiontothesafetyrequirementscontainedinthis
operatinginstructionsandyourcountry’sapplicable
regulations,youshouldobservethegenerallyrecognized
technicalrulesconcerningtheoperationofwoodworking
machines.
Anyotheruseexceedsauthorization.
Intheeventofunauthorizeduseofthemachine,the
manufacturerrenouncesallliabilityandtheresponsibilityis
transferredexclusivelytotheoperator.

3.2Generalsafetynotes
Woodworkingmachinescanbedangerousifnotusedproperly.
Thereforetheappropriategeneraltechnicalrulesaswellas
thefollowingnotesmustbeobserved.
Readandunderstandtheentireinstructionmanualbefore
attemptingassemblyoroperation.


Keepthisoperatinginstructionclosebythemachine,
protectedfromdirtandhumidity,andpassitovertothenew
ownerifyoupartwiththetool.
Nochangestothemachinemaybemade.
Dailyinspectthefunctionandexistenceofthesafety
appliancesbeforeyoustartthemachine.
Donotattemptoperationinthiscase,protectthemachineby
unpluggingthemainscord.
Removealllooseclothingandconfinelonghair.
Beforeoperatingthemachine,removetie,rings,watches,
otherjewellery,androllupsleevesabovetheelbows.
Wearsafetyshoes;neverwearleisureshoesorsandals.
Alwaysweartheapprovedworkingoutfit:
‐safetygoggles
‐earprotection
‐dustprotection

Duringmachineoperationthetransparentsawguardmust
alwaysbeloweredtotheworkpiece.
Insurethattheworkpiecedoesnotrollwhencuttinground
pieces.
Usesuitabletableextensionsandsupportingaidsfordifficult
tohandleworkpieces.
Nevercutpiecesthataretoosmall.
Duringcuttingoperationtheworkpiecemustfirmlybepressed
againstthetablesurface
Donotperformanyoperationfreehand.
Removecutandjammedworkpiecesonlywhenmotoris
turnedoffandthemachineisatacompletestandstill.
Donotreachunderthescrollsawtablewhenthemotoris
running.

Installthemachinesothatthereissufficientspaceforsafe
operationandworkpiecehandling.
Keepworkareawelllighted.
Themachineisdesignedtooperateinclosedroomsandmust
beplacedstableonfirmandlevelledground.
Makesurethatthepowercorddoesnotimpedeworkand
causepeopletotrip.
Keeptheflooraroundthemachinecleanandfreeofscrap
material,oilandgrease.
Stayalert!
Giveyourworkundividedattention.Usecommonsense.
Keepanergonomicbodyposition.
Maintainabalancedstanceatalltimes.
Donotoperatethemachinewhenyouaretired.
Donotoperatethemachineundertheinfluenceofdrugs,
alcoholoranymedication.Beawarethatmedicationcan
changeyourbehaviour.
Keepchildrenandvisitorsasafedistancefromtheworkarea.
Neverreachintothemachinewhileitisoperatingorrunning
down.
Neverleavearunningmachineunattended.Beforeyouleave
theworkplaceswitchoffthemachine.
Donotoperatetheelectrictoolnearinflammableliquidsor
gases.Normalbrushfiremightignite.
Observethefirefightingandfirealertoptions,forexamplethe
fireextinguisheroperationandplace.
Donotusethemachineinadumpenvironmentanddonot
exposeittorain.
Wooddustisexplosiveandcanalsorepresentarisktohealth.
Dustformsometropicalwoodsinparticular,andfrom
hardwoodslikebeachandoak,isclassifiedasacarcinogenic
substance.
Alwaysuseasuitabledustextractiondevice
Beforemachining,removeanynailsandotherforeignbodies
fromtheworkpiece.
Specificationsregardingthemaximumorminimumsizeofthe
workpiecemustbeobserved.
Donotforcethepowertool.Itwilldoabetterandsaferjob
andgiveyoumuchbetterserviceifitisusedattheratefor
whichitwasdesigned.
Neveroperatewiththeguardsnotinplace–seriousriskof
injury!
Connectionandrepairworkontheelectricalinstallationmay
becarriedoutbyaqualifiedelectricianonlyAlwaysunwind
anyextensioncordsfully.
Damagedextensioncordsreplaceimmediately.
Removedefectivesawbladesimmediately.
DonotusethepowertooliftheON/OFFswitchdoesnotturn
thepowertoolONandOFF.
Makeallmachineadjustmentsormaintenancewiththe
machineunpluggedfromthepowersource.

3.3Remaininghazards
Whenusingthemachineaccordingtoregulationssome
remaininghazardsmaystillexist
Themovingsawbladeintheworkareacancauseinjury.

Brokensawbladescancauseinjuries.
ThrownworkpiecescanleadtoinjuryWoodchipsandsawdust
canbehealthhazards.Besuretowearpersonalprotection
gearsuchassafetygogglesear‐anddustprotection.
Useasuitabledustexhaustsystem.
Theuseofincorrectmainssupplyoradamagedpowercord
canleadtoinjuriescausedbyelectricity.

4.Machinespecifications
4.1Technicaldata
Sawbladelength,pintype 127mm
Bladestroke 15mm
Bladespeed 550~1600SPM
Maxcuttingheightat90° 50mm
Tablesize 415x254mm
Tabletilt 0°/45°left
Throat 406mm
Dustportdiameter 35mm
Overall(LxWxH) 620x340x330mm
Weight 11.5kg
Mains 1~230V,PE,50Hz
Motorpower P1=90WS2‐30min
Referencecurrent 0,8A
Extensioncord H05VV‐F3G1mm²
Installationfuseprotection 10A
Protectionclass I

4.2Noiseemission
(Inspectiontolerance4dB)
Acousticpowerlevel(accordingtoENISO3746):
Idling LwA79,2dB(A)
Acousticpressurelevel(accordingtoENISO11202):
Idling LpA72,1dB(A)
Thespecifiedvaluesareemissionlevelsandarenotnecessarily
tobeseenassafeoperatinglevels.Thisinformationis
intendedtoallowtheusertomakeabetterestimationofthe
hazardsandrisksinvolved.

4.3Contentofdelivery
1Scrollsaw
1Transparentbladeguard
1Airblower
1Allenkey3mm
1Allenkey2.5mm
2Bladeadapters
Setof5sawblades(pintype)
Operatingmanual
Sparepartslist

4.4Machinedescription

Fig1
A….Bladetensionknob
B….Bearingcovers
C….Table
D….Sawdustblower
E…..Bladeandkeystoragearea
F….Mountingholes
G….Bevelscale
H….Bevellockknob
I…..Lowerbladeholder
J….Transparentsawguard
K….Bladeguardlockknob

Fig2
L…..Upperbladeholder
M….Tableinsert
N….Dustconnectionport
O….ON/OFFbutton
P….Variablespeedcontrolknob
Q….Table90°adjustingscrew


5.Transportandstartup
5.1Transportandinstallation
Themachineisdesignedtooperateinclosedroomsandmust
beplacedstableonfirmandlevelledsurface.Themachinecan
bebolteddownifrequired.
Forpackingreasonsthemachineisnotcompletelyassembled.

5.2Assembly
Ifyounoticeanytransportdamagewhileunpacking,notify
yoursupplierimmediately.Donotoperatethemachine!
Disposeofthepackinginanenvironmentallyfriendlymanner.
Cleanallrustprotectedsurfaceswithamildsolvent.
Mountingthesawdustblower:
Mountthesawdustblower(D,Fig3)andpointittowardsthe
cuttingarea.

Fig3
Thesawdustblowerkeepstheworkareaclean.
Mountingthetransparentbladeguard:
Mountthetransparentsawguardguard(J)totheverticalguide
rod.

Fig4
Note:
Duringmachineoperationthesawguardmustalwaysbe
loweredtotheworkpiece

5.3Dustconnection
Themachinehasa35mmdustport(N,Fig2)whereitcanbe
connectedtoadustextractor.

5.4Mainsconnection
Mainsconnectionandanyextensioncordsusedmustcomply
withapplicableregulations.
Themainsvoltagemustcomplywiththeinformationonthe
machinelicenceplate.
Themainsconnectionmusthavea10Asurge‐prooffuse.
OnlyusepowercordsmarkedH05VV‐F
Connectionsandrepairstotheelectricalequipmentmayonly
becarriedoutbyqualifiedelectricians.
5.5Startingoperation
YoucanstartthemachinewiththeON/OFFbutton.
Themachinehasvariablespeed550‐1600SPMforcutting
variousmaterials.
Withthevariablespeedcontrolknob(P)thecuttingspeedcan
bechosen.

6.Machineoperation
Correctworkingposition:
Infrontofthemachinestandinginthedirectionofcutting.
Workpiecehandling:
Insurethattheworkpiecedoesnotrollwhencuttinground
pieces.
Usesuitabletableextensionsandsupportingaidsfordifficult
tohandleworkpieces.
Nevercutpiecesthataretoosmall.
Presstheworkpiecedownagainstthetabletoavoid
ancontrollablelifting.
Removetheworkpiecefromthebladepriortoturningthe
scrollsawON.
Feedtheworkpiecetowardsthesawbladeinthedirectionof
thesawline,andcutasrequiredbyturningtofollowtheline
drawn.
Donotperformanyoperationfreehand.

Attention:
Alwaysobservethesafetyinstructionsandadheretothe
currentregulations.
Ensurethatthetransparentsawguardisloweredtothe
workpiecebeforeyoustartsawing.

Donotreachunderthescrollsawtablewhenthemotoris
running.
Theconditionofthesawbladeshouldbecheckedbeforeeach
machiningprocess.
Workonlywithasharpandflawlesssawblade.


Bevelcutting:
Thetablecanbetiltedbetween0°and45°forbevelcutting.
Loosenthelockingknob(H).

Fig5
Tiltthetabletotheleftuntilthedesiredangleonthescale(G)
hasbeenreached.
Retightenthelockingknob.

Fig6
Attention:
Anglecuttingrequiresmorecare.
Becareful.

7.Setupandadjustments
Generalnote:
Setupandadjustmentworkmayonlybecarriedoutafterthe
machineisprotectedagainstaccidentalstartingbypulling
themainsplug.
7.1Changingthesawblade
Themachineacceptspinbladesandplainendblades.
Checksawbladeforflaws(cracks,brokenteeth,bending)
beforeinstallation.Donotusefaultysawblades.
Thesawbladeteethmustpointincuttingdirection(down)
Thesawbladesmayonlybechangedwhenthemainsplugis
pulled!
Openthetransparentsawguard.
Removethetableinsert(M)
Releasebladetension.

Fig7
Thequickreleasebladetensionknob(A)allowsaquickand
easybladechange.
Replacethesawblade.
Theteethoftheblademustpointinthecuttingdirection
(down).
Thesawbladetensioncanbeadjustedbyturningthetension
knob.

Fig8
Turnclockwisetoincreasetension(Fig8).
Repositionthetableinsertandthetransparentsawguard.

7.2Sawbladeswithpin
Themachineacceptspinblades.
Theupperandlowerbladeholdersareequippedwithslotsand
pinrecesses(Fig9).

Fig9
Youcanpositionthebladeforcuttingfromthefrontorfrom
theside.


7.3Sawbladeswithoutpin
Themachinealsoacceptsplainendblades.
Twoadapterswithsetscrewsaresuppliedwiththemachine
(Fig10).

Fig10
Adjustonesetscrewoneachadaptoruntilitcovers
approximatelyhalfthehole(Fig11).


Fig11
Insertthesawbladeandtightentheopposingsetscrew.
Installthesecondadaptor.

Note:
Theadaptershave4threadholes.Youcanpositiontheset
screwsforcuttingfromthefrontorfromtheside.


8.0Bladeselection
Thefollowinginformationisgeneralinnature.
Awidearrayofbladesareavailableforthisscrollsaw.
Factorstoconsiderwhenselectingablade:
‐Typeofmaterialtobecut(hardwood,softwood).
‐Thicknessofworkpiece(thickerpieceswillrequirelarger
blades).
‐Featuresofworkpiece(straightcuts,sweepingcurvesortight
fretwork).
Thesefactorsareimportant(Fig12,Fig13).

Fig12
Width(W):
Generally,widerbladesareusedformakingstraightcutsand
longcurves.Narrowbladesaresuitedforcutswithtight
corners,suchasfretwork.Whencuttingstraightlineswitha
narrowblade,theblademayhaveatendencytodrift.
Pitch:
Pitchismeasuredin“teethperinch”(TPI)andcanbeconstant
orvariable.
Afinepitch(moreteethperinch)willcutslowlybutmore
smoothly,andminimizevibration.
Trytouseabladethatwillhaveaminimumof3teethengaged
intheworkpieceatanygiventime.
Set:
“Set”referstothemannerinwhichthebladeteetharebentor
positioned.
Bendingtheteethcreatesakerf(K)thatiswiderthantheback
oftheblade(T).
Twocommonsetsarethestraightoralternatingset(S)and
therakerset(R).
Material:
Bladesaremanufacturedbystamping,milling,orgrinding.
Stampedbladesarepunchedoutonapressfromsheetsteel.
Milledbladesaremadecuttingtheteeththrougha“milling”
process,thenheat‐hardeningthesteel.
Groundbladeshavehigh‐carbonsteelteethwhichtendtohold
theirsharpnesslonger,andprovidesmoothcuts.
Specialstylesarealsoavailable,suchastwistandspiralblades,
whichcutfromallsides.
Mostbladesofferedare130mm(5inches)long.
Optimally,ablade(andtheoperator’stechnique)shouldleave
smooth,cleancutsthatdonotrequiresanding.
Theusermayfindafewcarefully‐selectedstyleswillserve
mostofhisorherneeds.Theselectioncanbeexpandedasthe
usergainsexperience.

Toothform:
Toothform(Fig30)hasaneffectoncuttingrate.
‐Regular(A)Standardbladeformwithevenlyspacedteeth
andzero‐degreerakeangle.Offerscleancutsatslowerfeed
rates.
‐Skiptooth(B)Morespacebetweenteeth,forgoodchip
removalandfastcuts.
‐Doubletooth(C)Askiptoothwithlargergapsbetween
toothsets;goodchipremoval,fastcutting.
‐Reversetooth(D)Preventsundersidetear‐out,leavesclean
edge.
‐Spiral(E)Cutsonallsideswithoutturningworkpiece;good
fornarrowfretwork.
‐Crowntooth(F)Cutsonbothupanddownstrokes;goodfor
clean,splinter‐freeedges.
Acrowntoothblademayoftenbeturnedoverforafreshset
ofcuttingteeth.


Fig13


9.Maintenanceandinspection
Generalnotes:
Maintenance,cleaningandrepairworkmayonlybecarried
outafterthemachineisprotectedagainstaccidentalstarting
bypullingthemainsplug.
Repairandmaintenanceworkontheelectricalsystemmay
onlybecarriedoutbyaqualifiedelectrician.
Cleanthemachineregularly.
Inspecttheproperfunctionofthedustextractiondaily.
Allprotectiveandsafetydevicesmustbere‐attached
immediatelyaftercompletedcleaning,repairandmaintenance
work.
Defectivesafetydevicesmustbereplacedimmediately.

Cleaning:
Regularlycleanthemachinehousingwithasoftcloth
preferablyaftereachuse.
Ifthedirtdoesnotcomeoffuseasoftclothmoistenedwith
soapywater.
Neverusesolventssuchaspetrol,alcohol,ammoniacwater,
etc.Thesesolventsmaydamagetheplasticparts.

Sawblades:
Onlyusesharpsawblades.

Lubrication:
Lubricatethearmbearingsafterevery50hoursofuse.

Fig14

Removethe4bearingcovers(B,Fig14).
Applyagenerousamountoflightoil(SAE20).
Replacethebearingcovers.


Motorbrushes:
Thecollectorbrushesareduetowearandmayneed
replacement.
‐Disconnectthemachineformthepowersource,pullmains
plug.
‐removethebrushcovers.
‐Replacethecollectorbrushes(JetArticleNumber:JSS16A‐079
….2piecesneeded).
‐reattachthebrushcovers.




10.Troubleshooting
Motordoesn’tstart
*Noelectricity‐
checkmainsandfuse.
*Defectiveswitch,motororcord‐
consultanelectrician.
*Motorbrushesworn‐
replacebrushes.
Machinevibratesexcessively
*Standonunevensurface‐
adjustbaseforevensupport.
Cutisnotsquare
*Bevelstopsettingisbad.

Cuttingsurfacesisbad
*Wrongsawbladeused
*resincollectiononsawblade
*sawbladeisdull
*sawbladedamaged‐
replacesawbladeimmediately
*workpieceinhomogeneous
*Feedpressuretoohigh‐
donotforcetheworkpiece.


11.Environmentalprotection
Protecttheenvironment.
Yourappliancecontainsvaluablematerialswhichcanbe
recoveredorrecycled.Pleaseleaveitataspecialized
institution.


12.Availableaccessories
Stocknumber10000809
Setof5sawblades(pintype)


































