INSTRUCTION MANUAL
K600
REMOTE
CONTROL

K600 REMOTE CONTROL - INSTRUCTION MANUAL
DESCRIPTION
The K600 allows you to control by distance¹ the main functions of the
"player" and change music, folder, volume, pause, play and power.
OPERATION
Transmitter unit: Whenever an o key is pressed, an RF (radio frequency)
signal, will be transmitted to the receiving unit.
Receptor unit: The "led action" will light up indicating the presence of the
received signal, and will transmit in IR (infra red) the code corresponding
to the key pressed.
The receiver can operate with two transmitters, to do this, per form steps
1 and 2 of the item “CODING THE CONTROL” for the new transmitter.
IMPORTANTE
The control panel will not work if the coding procedure is not carried out.
To avoid interference, install the receiver in a location where the antennais
close to the panel and at least 50 cm away from the car alarm receiver.
¹For a longer range, install the equipment in a location where the antenna is free and
the most exposed as possible, the distance achieved is 600 meters in open area.

K600 REMOTE CONTROL - INSTRUCTION MANUAL
BASIC COMMANDS
TRANSMITTER UNIT
1. Volume control (+);
2. Volume control ( _ );
3. Rewind the music;
4. Advance the music;
5. LED indicator;
6. Go up the folder;
7. Go down the folder;
8. Play / pause / ATT;
9. Power / function (switches to aux, CD, USB, radio, etc.).
1
4
2
8
9
3
5
6
7

K600 REMOTE CONTROL - INSTRUCTION MANUAL
BASIC COMMANDS
OF THE RECEIVER UNIT
1 - RF receiver antenna;
2 - Led action, reception indicator;
3 - 12v power supply (black white stripe) and GND (black).
4 - Infra-red emitter (point to the front of the player);
5 - Memory mode key.
1
4
2
5
3

K600 REMOTE CONTROL - INSTRUCTION MANUAL
ENCODING THE CONTROL
LEARN MODE:
The receiver has more than 220 models of audio and video devices stored
in its memory see the attached table or on the website: jfaeletronicos.com
Control:
1. Press the "M" key on the receiving unit (Indication 1), the action LED
will be constantly lit;
2. Press the keys on the transmitting unit (Indication 2) corresponding to
the “player” model, as shown in the table, example: If you want to
program the SONY cd, perform step 1 and then press the keys
in sequence on the control. Check that the led will ash 1 time and then 4
times, indicating that model 14 (Sony) has been programmed.
3. After completing this process, press the “M” key on the receiving unit
(Indication 1) or wait 10 seconds to exit the memory mode.
1
LED action
2

K600 REMOTE CONTROL - INSTRUCTION MANUAL
1

K600 REMOTE CONTROL - INSTRUCTION MANUAL

K600 REMOTE CONTROL - INSTRUCTION MANUAL

K600 REMOTE CONTROL - INSTRUCTION MANUAL

K600 REMOTE CONTROL - INSTRUCTION MANUAL

K600 REMOTE CONTROL - INSTRUCTION MANUAL

MEMORY MODE ENCODING TABLE 2
NOTE: Keys that must be pressed simultaneously:
K600 REMOTE CONTROL - INSTRUCTION MANUAL
HB9750
HBDVD
HBD9200
HBD9500, HBD9550AVN, HBD9600AW
JVC
KENWOOD KDC MP2045V
LG
NAPOLI 9000
NAPOLI 9905
NAPOLI 8480
NAPOLI 1950, 9981
NAPOLI 4203, 4335, 5333
NAPOLI 9912, 9913
NAPOLI 9975, 9485, 9486, 9985
NAPOLI 9480
NAPOLI 5333, 5133
NAPOLI 8787
SONY
SONY+
PANASONIC
PHILCO CD230
PHILCO DVD500
PHILIPS
PIONEER
PIONEER DVH-7380AV
POSITRON SP3110
POSITRON SP4120AV
ROADSTAR RS-4136
WEBOX 1300 - MODE (UP)
12
08
11
12
02
19
35
20
21
22
23
24
25
26
27
28
33
14
15
32
16
17
18
01
48
40
37
24
45
MODEL CODE NUMBER

RECOMMENDED RECEIVER INSTALLATION
The installation of the equipment in the sound system is done through a
polarized power cable. Make sure the white-striped wire from the receiver
unit is connected to the battery's direct positive (+12V) and the black wire
to the negative (GND).
The receiving unit should preferably be xed away from metal parts and
the car's bodywork (which degrades the transmission) keeping, whenever
possible, the antenna unobstructed to allow the greatest possible range of
the equipment.
Position the infrared emitter, from the receiver unit aimed at the player's
panel, so that there are no obstacles between them. It is recommended to
install the receiver unit in the trunk and the IR emitter in the center of the
rear window, pointing towards the front of the player. Make sure the
wires are not crushed in the installation process.
Infrared emitter
Polarized cable
feed
Unit
receiver
Infrared emitterPlayer
K600 REMOTE CONTROL - INSTRUCTION MANUAL

RECOMMENDATIONS AND NOTES
1- Install the receptor unit at least 1 meter of the Alarms central or
electronic injection module. It is recommended to install receptor in the
trunk and the infrared emitting in the rear seat pointing to the front of the
"CD player".
2- For greater range should keep the antenna stretched and in a location
that is visual and away from the car bodywork.
3- supply the receiving unit with 12V.
4- The receptor can operate with two transmitters; for this, performing
steps 1 and 2 to the new transmitter. This feature is recommended for
customers using the Slim control on the steering wheel and a K1200 to
control by distance from the player.
K600 REMOTE CONTROL - INSTRUCTION MANUAL
TECHNICAL SPECIFICATIONS
UNITY
RECEIVER
Operating voltage: 9 to 16 V
Stand-by consumption: 13 mA
Reverse polarity protection: YES
UNITY
TRANSMITTER
Battery model: A 23 – 12 V
Operating Frequency: 433.92 MHz
Reverse polarity protection: NO
Radiated power (3 meters): 0.808 mW
Modulation: ASK
“This equipment operates on a secondary basis,have not
the right of protection against armful interference, even
of the same type of station, and notmay cause
interference to systems operating in primary basis. “
01260-14-04318
APPROVED PRODUCT
