Jinmuyu Electronics JMY6801H IC User manual

ISO14443A, ISO14443B, ISO15693 CONTACTLESS, ISO7816 IC CARD READER
JMY6801H IC Card Reader
User’s manual
(Revision 3.50)
Jinmuyu Electronics Co. LTD
2012/3/2
Please read this manual carefully before using. If any problem, please mail to: Jinm[email protected]

Mifare & ISO14443A& ISO14443B & ISO15693 & ISO7816 Module http://www.jinmuyu.com
Copyright © 2003-2014 Jinmuyu Electronics Co., LTD. All rights reserved. 1/6
Contents
1Product introduction................................................................................................................................2
2Characteristics.........................................................................................................................................2
3Physical parameter and pin outs..............................................................................................................3
3.1 Photo........................................................................................................................................3
3.2 Dimension ...............................................................................................................................4
3.3 Pin configurations and Pin outs...............................................................................................4
3.4 Model available.......................................................................................................................4
3.5 Model rule ...............................................................................................................................5
3.5.1 Model format...................................................................................................................5
3.5.2 Card operating type .........................................................................................................5
3.5.3 Communication port........................................................................................................5

Mifare & ISO14443A& ISO14443B & ISO15693 & ISO7816 Module http://www.jinmuyu.com
Copyright © 2003-2014 Jinmuyu Electronics Co., LTD. All rights reserved. 2/6
1Product introduction
JMY6801H is a RFID read/write module with UART, IIC, RS232C or USB port. JMY6801H
has various functions and supports multi ISO/IEC standard of contactless card. The RF protocol is
complex. The designer combined some frequent used command of RF card and then user could
operate the cards with full function by sending simple command to the module. The modules build in
SAM slot. It could operate contact smart card according to ISO7816.
The module has a length of 506 bytes command buffer could send APDU over 256 bytes to
T=CL smart cards and SAM cards. The modules support FSDI=8 of ISO14443-4. The module and
antenna is integrated. The impedance between RF circuit and antenna was tuned by impedance
analyzer, and then the module has excellent performance and stability. There is ferrite plate between
main PCB and antenna, so such design applies to some metallic-around systems.
2Characteristics
PCD model: NXP CL RC632
Working frequency: 13.56MHz
Supported standard: ISO14443A, ISO14443B, ISO15693, ISO7816
Card supported: Mifare 1K/4K, FM11RF08, Ultra Light, DesFire, Mifare ProX,
SR176, SRI512, SRI1K, SRI2K, SRI4K, SRIX4K, T=CL CPU cards(both ISO14443A &
ISO14443B), TI Tag It, I. Code SLI, ST LRI and other tags according to ISO15693, and
ISO7816 SAM cards (both T=0 & T=1)
Anti collision ability: Full function anti collision; be able to process multi-cards; be able
to set operate single card only
Auto detecting card: Supported, default OFF. The default state can be set.
SAM slot: 2 slot
SAM baud rate: 9600bps/38400bps/19200bps(default)/115200bps/57600bps.
ISO7816 PPS set: Supported
EEPROM: 512 Bytes
Power supply: DC 5V (±0 .5V)
Interface: IIC/UART/RS232C/USB HID (select when place order)
Communication rate: IIC: 400Kbps
UART/RS232C/USB: 19.2Kbps/115.2Kbps
USB: USB 2.0 HID
Max. command length: JCP04 254 Bytes; JCP05 510 Bytes.
Interface level: UART/IIC: 3.3V (TTL level; 5V tolerance)
Power consumption: 150mA
Operating distance: 80mm (depending on card and antenna design)
Dimension: 70mm*50mm*16.5mm
Weight: About 120g
ISP: Supported

Mifare & ISO14443A& ISO14443B & ISO15693 & ISO7816 Module http://www.jinmuyu.com
Copyright © 2003-2014 Jinmuyu Electronics Co., LTD. All rights reserved. 3/6
Operating temperature: -25 to +85°C
Storage temperature: -40 to +125°C
RoHS: Compliant
3Physical parameter and pin outs
3.1 Photo

Mifare & ISO14443A& ISO14443B & ISO15693 & ISO7816 Module http://www.jinmuyu.com
Copyright © 2003-2014 Jinmuyu Electronics Co., LTD. All rights reserved. 4/6
3.2 Dimension
3.3 Pin configurations and Pin outs
Pin number
Function
Type
Description
1
ICC
Output
Card in/out indication 0: Card IN; 1: Card OUT
2
TXD/SDA
Input/output
RS232C TXD / UART TXD / IIC SDA/ USB D+
3
RXD/SCL
Input
RS232C RXD / UART RXD / IIC SCL/ USB D-
4
VCC
Power
VCC
5
GND
Power
GND
3.4 Model available
JMY6801HI IIC interface
JMY6801HT UART interface, TTL level
JMY6801HS RS232C (UART interface, RS232 level)
JMY6801HU USB to UART Bridge

Mifare & ISO14443A& ISO14443B & ISO15693 & ISO7816 Module http://www.jinmuyu.com
Copyright © 2003-2014 Jinmuyu Electronics Co., LTD. All rights reserved. 5/6
3.5 Model rule
3.5.1 Model format
1
2
3
4
JMY
6801
X
X
1: company code; 2: product series code; 3: card operating type; 4: communication port type
3.5.2 Card operating type
M: PCD is RC500, support Mifare Class
A: PCD is RC500, support ISO14443A and Mifare Class
C: PCD is RC531, support ISO14443A, ISO14443B and Mifare Class
G: PCD is RC400, support ISO15693
H: PCD is RC632, support ISO15693, ISO14443A, ISO14443B and Mifare Class
D: PCD is RC500, support ISO14443A and Mifare Class with 511 bytes communication buffer
E: PCD is RC531, support ISO14443AB and Mifare Class with 511 bytes communication buffer
F: PCD is RC632, support ISO15693, ISO14443A, ISO14443B and Mifare Class with 511 bytes
communication buffer
3.5.3 Communication port
I: IIC
T: UART
S: RS232C
U: USB
