JJM Boiler Works CBM-227 Installation and operating instructions

14 Coleman Ave. Westeld, MA 01085
413-527-1893
690 Island Way Unit 206, Clearwater, FL 33767
413-427-3373 jjmboilerworks.net
Revised - April, 2019
CBM-227
Installation Operation
& Maintenance
Model: CBM-227
Acidic Condensate pH Treatment System

How much reside condensate will my equipment develop?
Hot water heaters / Boilers / Furnaces / Economizers
Multiple Boiler Common Flue drains: 33.3% of total BTU input of connected equipment.
Example: (3) Boilers @ 100,000 BTU Input would need a pH treatment kit rated @ 100,000
BTU for the stack drain and a ow rate of .725 to .798 depending on eciency.
Consider the following when choosing a neutralizer for less maintenance during operation
of your heating equipment.
1. Your location in relation to weather (Very Cold, Cold, Moderately Cold)
2. System Design (Process, Radiate, Snow Melt, Heating, etc.)
3. Yearly Operating Hours
4. pH level out of heating equipment (3.2 to 4.0 is normal)
5. If pH out of the heating equipment is below 3.2 pH contact the factory for sizing.
6. Abnormally low pH out of the equipment condensate drain can be caused by the following:
A. Improper Combustion
B. Contaminated Combustion Air
C. High Sulfur Content in Gas Supply
D. pH below 2.0 is considered hazardous waste by EPA. Contact JJM Technical
Service at 413-427-3373 or 413-527-1893
JJM® highly recommends operating your heating equipment for 24-48
hours prior to connecting a neutralizer so as to ush out dirt, grease, and
oils from connected piping and the heater. is is also the best time to check
the heater condensate pH level for sizing your neutralizer.

!WARNING
JJM® neutralizers are sized by BTU input to establish a ow rating.
Job site conditions will determine neutralizer design. See GPH chart below.
Equipment Efciency GPH Condensate
90% .725 / Per 100,000 BTU Input
91% .733 / Per 100,000 BTU Input
92% .741 / Per 100,000 BTU Input
93% .750 / Per 100,000 BTU Input
94% .758 / Per 100,000 BTU Input
95% .766 / Per 100,000 BTU Input
96% .774 / Per 100,000 BTU Input
97% .782 / Per 100,000 BTU Input
98% .790 / Per 100,000 BTU Input
99% .798 / Per 100,000 BTU Input
ALL JJM NEUTRALIZING PRODUCTS
1

2
Inspect frequently
Installer — Instruct the building owner to frequently inspect the CBM neutrazlier and all condensate connections. e owner must
notify a qualied technician if any problems are noticed.
Replacement parts
Contact JJM® Boiler Works, your local wholesaler or manufacturer’s representative for replacement parts and rell kit.

!DANGER Install all electrical wiring in accordance with the National
Electrical Code and local requirements.
Indicates a condition or hazard which will cause severe
personal injury, death or major property damage.
WARNING
Indicates a condition or hazard which may cause severe
personal injury, death or major property damage.
CAUTION
Indicates a condition or hazard which will or can cause
minor personal injury or property damage.
NOTICE
Indicates special attention is needed, but not directly related
to potential injury or property damage.
NOTICE
is unit when installed must be electrically grounded in
accordance with the requirements of the authority having
jurisdiction or , in the absence of such requirements, with
the current edition of the National Electrical Code, ANSI/
NFPA 70 and/or the Canadian Electrical Code, Part 1, CSA
C22.1, Electrical Code.
CAUTION
Label all wires prior to disconnection when servicing con-
trols. Wiring errors can cause improper and dangerous
operation. Verify proper operation aer servicing.
CBM-227 Acidic Condensate pH Treatment Kits –– Installation/Operation & Maintenance
Overview

!

!

!

!

!

Read before proceeding
Failure to comply with these guidelines could result
in severe personal injury, death or substantial
property damage.
Neutralizer and lines must be wet
• Beforeoperatingtheboiler,furnaceorhotwaterheater,ll
theCBM-227andtrapswithtapwater.NEVERoperatewith
tubesorP-trapsdry.
Application restrictions
• Condensing boilers, furnaces, hot water heaters and ue pipe
condensate drains.
• DO NOT exhaust ue gases through CBM tubes, they are not
rated for boiler or furnace ue gases. Operating tubes as ex-
haust vents can cause injury or death from carbon monoxide.
• Gas traps must be installed between the boiler, ue drains,
and furnace condensate outlet and the inlet of all JM tubes.
• JM tubes must be installed below system P-traps, boiler,
furnace, and breaching condensate drains.
• e use of Ferris and Copper piping on the neutralizer inlet or
out is not permitted. e use of CPVC, PVC, PP Tubing, and
Stainless Steel piping is the only material that shall be used.
Combined piping options
Flue pipe condensate drains
• Boiler/furnace condensate drain and ue condensate drain
can be commonly piped to a neutralizer tube. Also, the ue
pipe must be terminated so rain water cannot enter the ue
pipe.
Replace tubes regularly
• Tubes should be replaced when pH level moves below5.0.
e pH should be checked regularly (at least twice during the
rst year of operation) to determine the required recharging
schedule.
• At minimum a recharge should take place at least once a year.
• Use only JJM® pH Power Pellets®, DO NOT USE LIMESTONE
CHIPS.
What is pH?
e pH measurement of a uid is an indicator of the acidity or
alkalinity. Neutral uids have pH of 7.0. Acid uids have pH below
7. And alkaline uids have pH above 7 (up to 14). e pH can be
easily measured using digital pocket pH probe.
Condensate pH from condensing boilers and furnaces is typically
around 3.2 - 4.0. e condensate pH needs to be increased (made
more neutral) to prevent possible damage to cast iron soil pipe,
ABS pipe, septic tanks, plants, wastewater treatment plants and
other materials handling waste water.
CBM condensate pH treatment tubes
increase pH (reduce acidity).
CBM re side condensate neutralizing tubes are designed to raise
the pH level of the condensate discharged by high-eciency
boilers, warm air furnaces and hot water heaters.
Each increase of 1.0 in pH is a 10-times decrease in acidity. e
pH of condensate is increased by approximately 1.0 to 3.0 aer
passing through neutralizing tubes.
Applying CBM neutralizing tubes
Condensate can be collected from ue ways and boiler/furnace
condensate trap outlets. See WARNING section at le for guide-
lines on application.
Match neutralizing tubes to boiler/furnace ratings. Consider us-
ing the next larter size neutralizing tube for boiler systems with
domestic hot water heating.
Locate the neutralizing tube below the condensate connection
and slightly above the oor drain or inlet to a condensate pump
reservoir (if used).
Follow the guidelines in this manual, the boiler/furnace manual
and all applicable local codes when installing, using and main-
taining CBM condensate neutralizing tubes.
Installation sequence
1. Before installing boiler or furnace, determine if a mounting pad will
be needed to elevate the boiler or furnace so that the condensate
connection will be above bottom of the CBM OUTLET. See Figure2
or Figure3. Provide a mounting pad for the CBM tube if needed to
obtain the proper elevation relative to a condensate pump reservoir
(when used — see Figure3).
2. Connect PVC piping from appliance or breaching drains to P-traps
and then from P-trap outlets to either one of the two CBM tube inlets.
3. Connect the CBM tube outlet to house drain or condensate pump.
4. Use Teon tape on all threaded plastic ttings.
5. NOTE — Always consult the local authority regarding any require-
ments concerning ue gas condensate handling codes.
CBM-227 Acidic Condensate pH Treatment Kits –– Installation/Operation & Maintenance
Overview
3

Figure 1 CBM-227 condensate neutralizing tubes – features and dimensions
CBM-227 Acidic Condensate pH Treatment Kits –– Installation/Operation & Maintenance
A Condensing boiler, hot water heater or furnace
B Condensate neutralizing tube (or multiple tubes piped in parallel)
C Boiler/furnace condensate trap connection
D Boiler/furnace vent
E Vent condensate trap, when used — Install a trap as shown. Con-
nect the tubing to a separate CBM tube if appliances are common
vented. For individually-vented appliances, the vent condensate
drain can be connected to the appliance condensate drain line.
F Drain or sump
G Condensate pump
H Bottom of boiler/furnace condensate outlet — MUST be ABOVE
condensate pump inlet connection
J Bottom of CBM tube condensate outlet
L Mounting pad or structural platform, when required to elevate
boiler condensate drain as needed
M Mounting clamps
Figure 2 CBM-227 tube with oor drain, typical Figure 3 CBM-227 with condensate pump, typical
N Mounting clamps must be secured to the mounting surface
P Plastic tubing or PVC pipe — When using PVC pipe, remove the
CBM inlet and outlet hose barb ttings and replace with threaded
PVC ttings. Include unions in the piping to allow removal of the
CBM tube for inspection and service. — Secure pipe or tubing in
place. — Protect with a shield if necessary if routed through trac
areas.
R Use hose clamps at all connections when using plastic tubing.
S Condensate drain termination at oor drain (or condensate pump
reservoir inlet) — secure in place with clamps. — Follow instruc-
tions for condensate pump.
T Elevate the CBM tube on a structural base if necessary for the
outlet to be raised.
U Route condensate discharge line from to appropriate drain loca-
tion.
Installation
4
CBM-227 SERIES
FLOOR
SIDE VIEW
46”
STANDARD EQUIPMENT:
(2) 1” Acid Proof “Slip in Pipe” Poly Couplings, (4) Stainless Steel Clamps, Clear PVC
Tube, MgO Pellets, (2) 1” Split Ring Pipe Clamps with 3/8” threaded rod bases.
PART NO. MBH GPH MATERIAL #PELLETS
5003 1,500 MAX. 11.0 CLEAR PVC 8.5
INLET PORT
1” Sch40
OUTLET PORT
1” Sch40
4.5”
2.25”
CBM-227 SERIES
FLOOR
SIDE VIEW
46”
STANDARD EQUIPMENT:
(2) 1” Acid Proof “Slip in Pipe” Poly Couplings, (4) Stainless Steel Clamps, Clear PVC
Tube, MgO Pellets, (2) 1” Split Ring Pipe Clamps with 3/8” threaded rod bases.
PART NO. MBH GPH MATERIAL #PELLETS
5003 1,500 MAX. 11.0 CLEAR PVC 8.5
INLET PORT
1” Sch40
OUTLET PORT
1” Sch40
4.5”
2.25”

CBM-227 Acidic Condensate pH Treatment Kits –– Installation/Operation & Maintenance
C
F
E
Y-tting By-pass
Figure 6
6B
DA
Key
A
Rev. 03/2015
By-pass Drain
B
C
D
E
F
Boiler/Hot Water Heater/Furnace Condensate Drain
By-pass Piping
PH Treatment Tube
House Drain
Boiler, Hot Water Heater, Furnace
Note: Contact Factory for PH Treatment Tube and Tank Sizing and Piping Sizing
F
Y-tting By-pass with Wall Mounted Heating Unit
Figure 7
E
B
A
C
D
Do Not Mount
The pH Treatment Tube
in Vertical Position
Key
A
Rev. 03/2015
By-pass Drain
B
C
D
E
F
Boiler/Hot Water Heater/Furnace Condensate Drain
By-pass Piping
PH Treatment Tube
House Drain
Boiler, Hot Water Heater, Furnace
Note: Contact Factory for PH Treatment Tube and Tank Sizing and Piping Sizing
Figure 4 Y-tting by-pass with oor-mounted boiler
(see legend at left)
Figure 5 Y-tting by-pass with wall-mounted boiler
(see legend at left)
Installation (continued)
Piping Options - Overow by-pass piping
See Figure 4 and Figure 5 for installation with a y-tting for an overow by-pass line.
Locate the overow discharge so ow can be easily seen. Instruct the owner to notify the service technician immediately if
ow through the overow line is frequent or steady.
Make sure the installation complies with all local code requirements.
Piping for multiple boilers/furnaces/vent (see gures 6, 7, 8, 9, and 10)
A Boilers / Hot Water Heaters / Furnace Condensate Drains
B By-pass Drain
C By-pass Piping
D pH Treatment Tube
E House Drain
F Boiler / Hot Water Heater / Furnace Condensate Drain
Note: Contact Factory for pH Treatment Tube and Tank Sizing
and Pipe Sizing.
A Boilers / Hot Water Heaters / Furnace Condensate Drains
B By-pass Drain
C By-pass Piping
D pH Treatment Tube
E House Drain
F Boiler / Hot Water Heater / Furnace Condensate Drain
Note: Contact Factory for pH Treatment Tube and Tank Sizing
and Pipe Sizing.
F
Y-tting By-pass with Wall Mounted Heating Unit
Figure 7
E
B
A
C
D
Do Not Mount
The pH Treatment Tube
in Vertical Position
Key
A
Rev. 03/2015
By-pass Drain
B
C
D
E
F
Boiler/Hot Water Heater/Furnace Condensate Drain
By-pass Piping
PH Treatment Tube
House Drain
Boiler, Hot Water Heater, Furnace
Note: Contact Factory for PH Treatment Tube and Tank Sizing and Piping Sizing
5

CBM-227 Acidic Condensate pH Treatment Kits –– Installation/Operation & Maintenance
Installation (continued)
Piping for Single Heating Unit with Condensate Pump
GCondensate Drain
Figure 3
Key
A
Rev. 03/2015
Flue Drain
B
C
D
E
F
Boilers/Hot Water Heaters/Furnaces Condensate Drains
Common Flue Vent
PH Treatment Tube or Tank
House Drain
Boilers, Hot Water Heaters, Furnaces
Note: Contact Factory for PH Treatment Tube and Tank Sizing and Piping Sizing
C
F
A D
B
E
D
G
Figure 6 Piping for Single Heating Unit with
Condensate Pump
A Boilers / Hot Water Heaters / Furnace Condensate Drains
B Flue Drain
C Common Flue Vent
D pH Treatment Tube
E House Drain
F Boilers / Hot Water Heaters / Furnaces
G Condensate Drain
Note: Contact Factory for pH Treatment Tube and Tank Sizing and Pipe Sizing.
Ratings & Dimensions (in inches)
A
C
10/2014
B
Flue Drain
B
Piping for Multiple Boilers/Individual pH Treatment Kits
Common Piping
C
D
E
F
Boilers/Hot Water Heater Condensate Common Drain
Common Flue Vent
Neutralizer Tube or Tank
House Drain
Boilers, Hot Water Heaters, Furnaces
Note: Contact Factory for Neutralizer Sizing and Piping Sizing
F F F F
D
D
D
D
A
E
D
Figure 7 Piping for Single Heating Unit with Common
pH Treatment Tube or Tank
A Boilers / Hot Water Heaters / Furnace Condensate Drains
B Flue Drain
C Common Flue Vent
D pH Treatment Tube
E House Drain
F Boilers / Hot Water Heaters / Furnaces
Note: Contact Factory for pH Treatment Tube and Tank Sizing and
Pipe Sizing.
Key
A
C
Rev. 03/2015
F F F F
Flue Drain
A
B
Piping for Multiple Heating Units
C
D
E
F
Boilers/Hot Water Heaters/Furnaces Condensate Drains
Common Flue Vent
PH Treatment Tube or Tank
House Drain
Boilers, Hot Water Heaters, Furnaces
Note: Contact Factory for PH Treatment Tube and Tank Sizing and Piping Sizing
D
E
D
Figure 1
B
Figure 8 Piping for Single Heating Unit with Common
pH Treatment Tube or Tank
A Boilers / Hot Water Heaters / Furnace Condensate Drains
B Flue Drain
C Common Flue Vent
D pH Treatment Tube
E House Drain
F Boilers / Hot Water Heaters / Furnaces
Note: Contact Factory for pH Treatment Tube and Tank Sizing and
Pipe Sizing.
6

C
F
B
A
E
Piping for Single Heating Unit with Common pH Treatment Tube or Tank
D
6
Figure 4
Key
A
Rev. 03/2015
Flue Drain
B
C
D
E
F
Boilers/Hot Water Heaters/Furnaces Condensate Drains
Single Flue Vent
PH Treatment Tube or Tank
House Drain
Boilers, Hot Water Heaters, Furnaces
Note: Contact Factory for PH Treatment Tube and Tank Sizing and Piping Sizing
Figure 9 Piping for Single Heating Unit with Common
pH Treatment Tube or Tank
A Boilers / Hot Water Heaters / Furnace Condensate Drains
B Flue Drain
C Common Flue Vent
D pH Treatment Tube
E House Drain
F Boilers / Hot Water Heaters / Furnaces
Note: Contact Factory for pH Treatment Tube Sizing and Pipe Sizing.
CBM-227 Acidic Condensate pH Treatment Kits –– Installation/Operation & Maintenance
Installation (continued)
Inspect frequently
Installer — Instruct the building owner
to frequently inspect the neutralizer and
all condensate connections. e owner
must notify a qualied technician if any
problems are noticed.
Maintenance
Recharge as required
When pH tube or tank outlet falls below
5PH. Local codes may have different
requirement, check with local authority.
Replacement parts
Contact your local wholesaler or manu-
facturer’s representative for replacement
parts.
Dealer listing at www.jjmboilerworks.com
OUTDOOR INSTALLATIONS — provide and install electric heat tape and insulation on the condensate drain lines and
around the tube to prevent possibility of neutralizer tube damage or line blockage due to freezing. Failure to comply
with the following guidelines could result in severe personal injury, death or substantial property damage.
C
F F F F
B
A
D
E
Piping Multiple Heating Units/Single pH Treatment Kit /Common Piping
Figure 5
Key
A
Rev. 03/2015
Flue Drain
B
C
D
E
F
Boilers/Hot Water Heaters/Furnaces Condensate Common Drain
Common Flue Vent
PH Treatment Tank
House Drain
Boilers, Hot Water Heaters, Furnaces
Note: Contact Factory for PH Treatment Tank Sizing and Piping Sizing
Figure 10 Piping Multiple Heating Units/Single pH
Treatment Kit/Common Piping
A Boilers / Hot Water Heaters / Furnace Condensate Drains
B Flue Drain
C Common Flue Vent
D pH Treatment Tube
E House Drain
F Boilers / Hot Water Heaters / Furnaces
Note: Contact Factory for pH Treatment Tube Sizing and Pipe Sizing.
7

Revised - April, 2019
14 Coleman Ave. Westeld, MA 01085
413-527-1893
690 Island Way Unit 206, Clearwater, FL 33767
413-427-3373 jjmboilerworks.net
8
MaintenanceProcedures
Acidicwastewaterneutralizerslikeallfilteringdevicesneedbothmaintenanceandreplacing.
WhenthepHfallsbelow5.0attheoutletportofanyneutralizertheactiveingredientmustbereplaced.Media
replacementschedulewilldependonseveralfactorsincludingOperatingHours,Efficiency,SystemDesign,and
NeutralizerPipingScheme.TheactiveingredientinthecaseofJJM™productsisMagnesiumHydroxidePellets.
ThetradenameisphPowerPellets®.
BeforechangingthepelletswhenthepHlevelfallsbelow5.0youcangetthemostoutofyourneutralizerbyfirst
agitatingthepellets.Inthecaseofaninlinetubeproductstrylightlytappingtheoutersidesofthetubewitha
rubbermalletseveraltimesandthencheckthephlevelonceagainattheoutletport.Youmayfindthatyourph
levelhasrisenbackintothe5.0to9.5pHrange.
ModelsCBM-226andCBM-227canbeturned180degreesbyloosingthepolycouplingstainlesssteelclampsand
twistingthetubesoastohavethe“THISSIDEUPLABEL”atthebottomfloorlevel.
Whenyourneutralizerisatankproductwithloosepelletsyoucansimplyuseawoodeddoweltostirthepellets
andagainusefreshtapwatertoflushoutthetank.
Ifyourneutralizerpelletsareincasedinaporouspelletbagtherearethreemethodstoagitatingthepellets:
1.Removethepelletbagorbagsfromthetankandusingyourhandsmovethepelletsaroundinsidethebags.
2.Usingafive-gallonbucketfilledwithfreshtapwater,usesteponewiththebagunderwater.
3.Usingafreshwaterhoseslowlypourfreshwateroverbothsidesofthepelletbagandalsousemethodone.
IfthepHlevelishasnotrisenbackintothesaferangeof5.0to9.5pHthepelletsmustbereplaced.

IfyouhaveourModelV-250orV-250Combiverticalcanisterstrythefollowingmethod:
1.Twistofftheoutercanistertogetaccesstotheinnerpelletcartridgeandoverafive-gallonpailshakethe
Cartridgeseveraltimestoagitatethepellets.
2.Againusingafive-gallonpailfilledwithfreshtapwaterletthecartridgesoakforfiveminutesunderwaterand
thendrainandhandshakethecartridgetoagitatethepellets.Alsocleanoutanysedimentwhichmaybeheld
withintheoutercanister.
DURINGALLOFTHEABOVEPROCEEDURESTHEFOLLOWINGSAFETYITEMSMUSTBEUSED:
1.WEARSAFETYGLASSES
2.WEARRUBBERORLATEXPROTECTIVEGLOVES
3.SHUTOFFALLELECTRICALPOWERTOTHEHEATINGUNITORUNITSBEFORESERVICINGYOURNEUTRALIZERS.
ThepelletsareNon-Hazardousandcanbedisposedofinyournormalrefuge.MSDSsheetscanbefoundonlineat
www.jjmboilerworks.net
AnyquestionscanbedirectedtoJJMBoilerWorks,Inc.@413-527-1893oratwww.jjmboilerworks.net
Maintenance Procedures
