JK-Products R PRO IR EVIVE Laydown JK 199 User manual

1030889-00C / us-en / 02.2024
Model-No.: JK 1 /99 RV 0-46
Operating instructions
R PRO IREVIVE Laydown

Contact information
2/66
Contact information
Customer Service JK Products & Services
411 West Washington Avenue
Suite B
Jonesboro, Arkansas 72401
800-445-0624
870-935-9046
http://jkproducts.us/service
Manufacturer JK-Products GmbH
Rottbitzer Str. 69
53604 Bad Honnef
GERMANY
Tel.: [phone] / 818-140
Fax: [phone] / 818-166
WARNING!
Read these operating instructions.
Failure to observe these instructions:
may result in serious injury and death,
can result in damage to the device and the envi-
ronment.
– For the safety of yourself and others, read and
observe all instructions contained herein before
operating the device.
– Please makethe instructions and additional in-
formation available to anyone who operates or
services the device.
Copyright
The copyright remains with JK-Holding GmbH.
The contents may not be duplicated (in whole or part),distributed or
utilized for competitionpurposeswithout authorization ordisclosed to
other parties.
The right to make technical changes in regard to the figures and infor-
mation contained in this instruction manual is reserved!

Table of Contents
02/2024 1030889-00C Operating instructions – 3/66
1 Table of Contents
2What certain words and signs mean (Glossary).................. 6
2.1 Definitions.................................................................................6
2.2 Warning signs...........................................................................7
2.3 Symbols on thedevice.............................................................8
3What this device is............................................................. 9
3.1 Guidelines..................................................................................9
3.2 Export........................................................................................9
3.3 Scope of delivery ......................................................................9
3.3.1 Options......................................................................................9
3.4 Device description..................................................................10
3.5 Options....................................................................................10
3.6 Function description...............................................................10
3.7 Transport.................................................................................11
3.8 Installation location................................................................11
3.8.1 Ventilation...............................................................................11
3.8.2 Setup location.........................................................................12
3.8.3 Commissioning.......................................................................14
3.9 Signs and stickers on the device...........................................15
3.10 Technical data ........................................................................17
3.10.1 Power rating, electrical specifications and noise level ........17
3.10.2 Dimensions.............................................................................18
3.10.3 Lamp configuration................................................................18
3.10.4 Accent lighting........................................................................18
3.10.5 Spare parts..............................................................................19
4Why you use it ................................................................. 20
4.1 Intended use ...........................................................................20
4.2 Skin condition.........................................................................20
5Who cannot use it............................................................ 21
5.1 Prohibited usage.....................................................................21
5.1.1 REVIVE system .......................................................................21
5.1.2 Vibra Shape (vibration plate) .................................................21
6What you must do to avoid serious harm ......................... 22
6.1 General....................................................................................22
6.2 REVIVE system .......................................................................23
6.3 Sensor .....................................................................................23

Table of Contents
4/66
7What you must do to avoid other harm............................. 24
7.1 General....................................................................................24
7.2 REVIVE system .......................................................................24
7.3 Sensor .....................................................................................24
7.4 Vibra Shape - vibration plate..................................................24
7.5 Foreseeable misuse...............................................................25
7.6 Obligations of the studio operator.........................................25
7.7 Staff training...........................................................................25
8Risks of using this device ................................................ 26
9Benefits of using this device............................................ 27
10 How to decide to use this device...................................... 28
11 What to do before the application .................................... 29
12 How to use this device..................................................... 30
12.1 How to set this device up.......................................................30
12.2 How to make sure the device works .....................................30
12.3 How to use it to treat your condition.....................................30
12.4 How to choose correct application regimen.........................30
12.4.1 Application times....................................................................30
12.5 How to operate the device.....................................................31
12.5.1 Control Center.........................................................................31
12.5.2 User settings overview...........................................................31
12.6 Functions.................................................................................32
12.6.1 Navigation...............................................................................33
12.6.2 Info / Maintenance / Button lock...........................................34
12.6.3 Timer settings / External Timer setting.................................35
12.7 Operating display of the sensor.............................................35
12.8 Selection of the application...................................................35
12.9 Sun Select setting with the outer interface...........................35
12.10 Measurement (automatic mode)...........................................35
12.11 Connections............................................................................36
12.12 How to use..............................................................................36
12.12.1 How to start ............................................................................36
12.12.2 Application tips.......................................................................37
12.12.3 How to stop.............................................................................37
12.13 What to do after the application............................................38
12.13.1 Cleaning and disinfection.......................................................38
12.14 Safety instructions for cleaning/
disinfection and maintenance ...............................................39
12.15 How to clean/disinfect...........................................................41
12.15.1 Cleaning and disinfection of surfaces...................................42
12.15.2 Cleaning/disinfectionplan.....................................................43
12.16 How to maintain......................................................................44
12.16.1 Technical modifications.........................................................44
12.16.2 Maintenance schedule for wear parts...................................44

Table of Contents
02/2024 1030889-00C Operating instructions – 5/66
12.16.3 Cleaning and maintenancework preparation.......................46
12.16.4 Instructions for replacing the lamps .....................................46
12.16.5 Cleaning and disinfection of the sensor................................47
12.16.6 Disassembly for maintenance and cleaning work................47
12.16.7 Removing the canopy panel...................................................48
12.16.8 Removing the acrylic panel....................................................49
12.16.9 Changing the AROMA card ....................................................51
12.16.10 Cleaning the ventilation slot...................................................51
12.16.11 Cleaning or replacing
lamps and filter panels in the canopy....................................51
12.16.12 Cleaning or replacing
the lamps and filter panels in the shoulder tanner...............51
12.16.13 Cleaning or replacing Ambient Light.....................................51
12.16.14 Cleaning or replacing the canopy accent lighting.................51
12.16.15 Cleaning or replacing the frontpanel accent lighting...........52
12.16.16 Cleaning the filters..................................................................52
12.16.17 Cleaning the filter mats..........................................................52
12.16.18 Cleaning the filter mats in shoulder tanner...........................52
12.16.19 Air conditioning:
Empty the condensation tank and clean the filter................52
12.16.20 AQUA / AROMA SYSTEM maintenance................................52
12.17 How to store the device.........................................................53
12.17.1 Decommissioning...................................................................53
12.17.2 Storage....................................................................................53
12.17.3 Disposal...................................................................................53
13 What to do when things go wrong.................................... 54
13.1 Troubleshooting......................................................................55
14 Where you can find out more........................................... 56
15 How we studied this device.............................................. 57
16 Appendix ......................................................................... 58
17 JK-Products, Inc. – Limited Warranty .............................. 59
17.1 Limited Acrylic Warranty........................................................60
17.2 Warranty Claims .....................................................................61
17.2.1 Policy & Procedures................................................................61
17.2.2 Labor Warranty Claim/Credit Procedures.............................62
17.2.3 Quality inspection and acceptance form..............................62
17.3 Limited Lifetime Warranty......................................................63
18 Index................................................................................ 64

What certainwords and signs mean (Glossary)
6/66
2 What certain words and signs mean (Glossary)
2.1 Definitions
Studio operator
People who provide devices to users on a commercialbasis. The stu-
dio operator is trained to operate and maintain the deviceand is re-
sponsible for the orderly operation of the device as well as compli-
ance with the maintenance intervals.
User
A person who uses the device at a commerciallocation.
Staff
People who are responsible for the operation, cleaning/disinfection as
well as general maintenance work andwho instruct theusers in the
operation of the devices.
JK Factory Certified Technician
Level 1
Authorized toperform general maintenancesuch as replacing lamps,
aqua mist, and fragrance containers as well as overall cleaning of the
unit.
Level 2
Authorized toperform maintenance and repairssuch as replacement
of ballast,framed acrylic, electronic circuit boards, and otherelectrical
components.
Level 3
Authorized and trained to utilize JK Productsproprietary diagnostic
software to adjust operating parameters and perform detailed diag-
nostics.
Level 4
This individualis uniquely qualified to assess the condition of a unit
and make a determination if the device meets the requirements for
continued use ten (10) years from thedate ofmanufacture.
NOTE:
Each technician level is authorized to perform the
tasks of technician levels smaller in number to
theirs. E.g. a level 3 technician is authorized to per-
form the tasks assigned to a level 1 and 2 techni-
cian.

What certainwords and signs mean (Glossary)
02/2024 1030889-00C Operating instructions – 7/66
2.2 Warning signs
Danger notices, nonobservance will lead to death or serious injury:
DANGER!
Type and source of danger, e.g. 'DANGER – High
voltage!'
Description of the consequences, e.g. 'You canbe
killed or injured by an electric shock!'
Countermeasures:
– Disconnect device from power supply before
opening.
– Do not reach into the inside with thedevice
switched on.
Warning notices, nonobservance can lead to death or serious injury.
WARNING!
Type and source of danger, e.g. 'WARNING – hot
surface!'
Description of the consequences, e.g. 'You canburn
your hand (skin, face)!'
Countermeasures:
– Do not touch hot parts and nearby surfaces.
– Wait until hot parts and surfaces have cooled
down.
NOTICE
ESD-sensitive components!
The word 'NOTICE' without warning sign points out
that danger for devices, materials and the environ-
ment can be expected here.
Countermeasures:
– Avoid doing this.
Important information:
NOTE:
This symboldoes not identify safety notices, but
states information for a better understanding of the
processes.

What certainwords and signs mean (Glossary)
8/66
2.3 Symbols on the device
The following symbols aredisplayed on the deviceor on the packag-
ing:
Manufacturer, company address
Read the operating instructions!
Where there are great differences in temperaturebetween the
transport route and the installation site the device may not be put
into operation immediately afterbeing set up.
Wait at least 2 hours before connecting the device to the power sup-
ply.
Maximum transport weight
Do not stack!
This side up.
Keep dry.
Temperature limitations.
The temperature limits arenoted nextto the upper andlower hori-
zontal line.
Recyclable material.
Polystyrene
Cardboard
Mixed paper
Steel
Wood
Permitted air pressure during transport and storage.

What this device is
02/2024 1030889-00C Operating instructions – 9/66
3 What this device is
3.1 Guidelines
This product is in conformity with UL STD 482 and fulfils the require-
ments for the exempt group according to IEC 62471.
3.2 Export
This deviceis exclusively intended for use inthe USAand may not be
exported to other countries and operated there! Themanufactureras-
sumes no liability whatsoever in the event of non-compliance. High lia-
bility risksmay occur for the exporter and/or thestudio operator in the
event of noncompliance.
3.3 Scope of delivery
REVIVE device
AROMA card
Protective goggles
Allen-key
Technical documentation
3.3.1 Options
Not applicable for this device.

What this device is
10/66
3.4 Device description
1. INTERIOR DISPLAY
2. Red Light & Near InfraredLEDs, canopy
3. Handle, canopy
4. Red Light & Near InfraredLEDs, base
5. Body cooling with AROMA
3.5 Options
Not applicable for this device.
3.6 Function description
See page 31 for information on control and operation of the device
and its features.

What this device is
02/2024 1030889-00C Operating instructions – 11/66
3.7 Transport
3.8 Installation location
This product is suitable for fitness studios or similar installation loca-
tions.
You may find detailed information on installation and setting up in the
Installation Instructions (see folder Technical Documentation).
3.8.1 Ventilation
NOTICE
Danger of failure!
Danger of overheating by obstruction of the air routing.
–Observe the ventilation information to avoid serious system
malfunctions.

What this device is
12/66
3.8.2 Setup location
WARNING!
Sudden movements and malfunctions!
Crushing hazard.
– The deviceis not suitable for operation in mo-
bile facilities (ships, buses, trains).
Risk of falling! Risk of being injured by falling ob-
jects!
Ceilings and joists may break if the load per square
foot is too high!
– Ensure that ceiling and joists are sufficient for
the weight of your device (see Installation In-
structions inthe folder Technical Documenta-
tion).
CAUTION!
Danger of overheating by obstruction of the air
routing!
Any liability is excluded in case of damage or injury
proven to be theresult of the use of non-genuine
spare parts.
– Do not change, obstruct or block the air inflow
and outflow area to the device or make any un-
authorized changes to thedevice. The manu-
facturer shall bear no liability for damage or in-
juries resulting from such actions.
–Observe the ventilation information to avoid se-
rious system malfunctions.
–Before putting a device into operation, the
transport pallet mustbe removed from under
the device.Danger of overheating by obstruc-
tion of the airrouting.
– Maintain the minimum distances from the
walls! Dimensions are given on page 18.
– Only use OEM spare parts of the same type!
The use of otherparts will void the manufactur-
er's warranty!

What this device is
02/2024 1030889-00C Operating instructions – 13/66
NOTICE
Salty air! Contaminated air!
Device damagedue to corrosion of thehousing and electrical com-
ponents.
– Do not install the device near swimming pools.
– Do not operate the device in locations with aggressiveenviron-
mental conditions (e.g. air containing chlorine).
Damage to the device possible!
Where there are great differences in temperaturebetween the
transport route and the installation site the device may not be put
into operation immediately afterbeing set up.
– Wait at least 2 hours before connecting the device to the power
supply.
Damage to the device possible!
The deviceis not to be used outdoors.
Environmental conditions
Optimum ambient temperature:
between 59°F (15 °C) and ~90°F (32°C)
Storage temperature: between 5 °F (-15 °C) and 140 °F (+60 °C)
Air pressure: between 794 hPa and 1060 hPa
Relative humidity: between 30 % and 70 %
Please contact the customer servicedepartmentbefore putting the
device into operation - see page2.
You can obtain data regarding the airsupply and ventilation from the
customer service department (see page 2).

What this device is
14/66
3.8.3 Commissioning
DANGER!
Damaged mains power cable!
Danger to persons through electric shock or burns.
–Only the manufacturer or specialist companies
are permitted to replace the mains power cable.
Initial commissioning will be undertaken by themanufacturer's own
service personnel or by a (Level 3) JK Factory Certified Technician.
The device will be handed over ready for use.
As the studio operator youare responsible for abiding by the electrical
regulations applicable at theinstallation site.
The unit incorporates special preventive measures with regard to the
electromagnetic compatibility and must be installed and commis-
sioned according to the EMC instructions obtained chapter 16 Appen-
dix.
If the devicehas not been operated or serviced for a period of one
year or longer, it mustfirst be inspected by a (Level 3) JK Factory Cer-
tified Technicianbefore being put back into operation.Failureto do so
may result in personal injury or property damage.
NOTE:
If a fire is suspected, immediately disconnect the
power supply,as long asthis is safely possible.
Continue to observe all regulations required by law,
public authorities and employer’s liability insurance
associations, which remain unaffected by the afore-
mentioneddirections.

What this device is
02/2024 1030889-00C Operating instructions – 15/66
3.9 Signs and stickers on the device
Signs which warn of danger areas or give important information on
components are attached to the device. Ensure that the instruction
signs are always clearly recognizable and easily legible. Any missing
instructionsigns or stickersmust be replaced.
1: Standards (1031046-..)
2: Sticker (1014367-..)

What this device is
16/66
3: Name plate (example)
4: Sticker 'Follow Operating Instructions' (1014232-..)
5: Sticker 'ESD label for sensitive components' (1029427-..)

What thisdev
ice is
02/2024 1030889-00C Operating instructions – 17/66
3.10 Technical data
3.10.1 Power rating, electrical specifications
and noise level
JK 199 / RV 0-46
Power consumption rating: 1400 W
Rated frequency: 60 Hz
Rated voltage: 230 V 1 phase
Rated overcurrent protection device 15 amp 2 pole*
Power supply: SJOOW 14-3 AWG1)
Ingress protection classification: IP20
Protection against electricshock: Class I
Noise level inside the device: 70 dB(A)
Noise level 1m away from device: < 71.6 dB(A)
Load on the base plate: max. 330 lbs / 150 kg
Weight: approx. 330 lbs / 150 kg
Max. humidity: 70%
Ambient temperature: 59-89,6°F (15-32 °C)
Max. operating altitude (above sea level): 6,500 ft (2,000 m)
* Due to high inrush current caused by the electrical components used, such as ballasts, power suppl
ies, etc.,
the units must be protected by slow-blow fuses.
When using circuit breakers, makesure that they have tripping characteristicD or similar.
1) Wire size is dependent on local electricalcode. Please check with your local electrician orinspector to en-
sure proper size is used.
NOTE:
Adaptation of theunit is required for operating alti-
tudes greater than 6,500 ft / 2,000 m abovesea
levelin order to guarantee trouble-free operation.

What this device is
18/66
3.10.2 Dimensions
B = 925 mm
H = 1093 mm
H1 = 1322 mm
B2 = 1118 mm
L = 2160 mm
BK = 2400 mm
TK = 1500 mm
3.10.3 Lamp configuration
Not applicable for this device.
3.10.4 Accent lighting
Not applicable for this device.

What this device is
02/2024 1030889-00C Operating instructions – 19/66
3.10.5 Spare parts
Number Description Order-no.
1 1 Scent card 1514150-..
2 1 Canopy panel 1514013-..
3 1 Base panel 1514018-..
4 1 Gas pressure spring 1513924-..
1SW4 Allen key 84500-..
1 Protective goggles 1027147-..
For more spare parts, contact Customer Service (see page 2).

Why you use it
20/66
4 Why you use it
4.1 Intended use
REVIVE PRO IR Laydown
This deviceis used for the application of near infraredand red-light
technology for one person at a time.
The devicemay not be used by people with reduced physical, sensory
or mental capabilities or who have insufficient experience and/or
knowledge without supervision. A person responsible for their safety
must ensure, either by supervision or instruction, that thedevice is
used correctly and safely. If there is any doubt, use of the device by
such categories of persons is forbidden! This device is only to be op-
erated with the specified Red Light & Near Infrared LEDs or their equiv-
alent. The usage times given in these operating instructions are valid
only for the specified Red Light & Near Infrared LEDs.
Any otheruse shall be considered improper. The manufacturer cannot
be held liable for damage or injuries resulting from this.The operator
bears the sole risk for this.
Proper use also includes compliancewith the manufacturer's instruc-
tions and its operating and maintenance conditions. The devicemay
only be operated, maintained and repaired bypersons familiar with
these tasks and who havebeen informed of the dangers involved.
4.2 Skin condition
Not applicable for this device.
