Stealthbox®
INSTALLATION GUIDE
SB-F-RTRKCTR/12W3v2-D2, JL AUDIO, Inc 2002 Sheet SKU#011159 Revision 11/18/2003Page 1
for the
SB-F-RTRKCTR/12W3v2
Rear Console Only
(Fits 2002-Up Ford SuperCrew
Harley Davidson, King Ranch;
2001-2002 Lincoln Navigator and
2002 Blackwood )
This Stealthbox is a product
which requires professional
installation skills and tools.
Please read this installation guide
thoroughly before beginning the
project. It will guide you step by
step through the installation. Several
of the steps in this process may
require two people to accomplish.
It is absolutely vital that the
enclosure be properly mounted to
the vehicle according to these
instructions. Failure to mount the
enclosure properly presents two
problems: 1) The sub-bass
performance will suffer due to the
movement of the enclosure caused
by the force exerted by the
woofer(s) and 2) A loose enclosure
presents a serious safety hazard in
the event of a collision or sudden
deceleration.
Please enjoy your JL Audio
Stealthbox responsibly.
STEP 1: Remove front exposed pocket,
internal instert and rubber flooring.
STEP 2: With an 8mm socket and long
extenstion, remove the four bolts. Located
where the front pocket was removed from in
STEP 1.
STEP 3: Remove the pair of bolts from side
rear of the OEM console.
You will have to lower the two rear seats and
lift up drop flooring to expose the bolts.
After the pair of bolts are removed, remove
OEM console out of truck.
STEP 4: With the OEM console removed
you , unbolt the rear bracket.
STEP 5: The Stealthbox is shipped with two
brackets attacahed to it. Remove the rear
angle bracket from the Stealthbox.
Mount this black angle bracket to where the
OEM bracket was removed.
Use the three bolts that was removed in
STEP4.
STEP 6: The top picture shows how the front
bracket is installed when shipped.
Remove all mounting hardware and flip the
front bracket. Remount the flipped bracket
with the same hardware.
The bottom picture shows the bracket
properly mounted for install.
START
HERE
Continued on Page 2 ➔
www.jlaudio.com
➔
➔

➔➔
➔➔➔
➔
STEP 7: Position the Stealthbox into location.
Hand tighten front of Stealthbo;, using the
supplied pair of1” sapcers, pair of lock washers,
pair of fender washers and the pair of
#8x40mm bolts.
STEP 8: (no picture) Line up rear of
Stealthbox to the rear angle bracket that was
mounted in STEP 5. Mount the Stealthbox
using the bolts that held the rear angle bracket
onto the enclosure, that was removed in
STEP 5.
With all bolts lined up, securly thighten all
mounting bolts.
STEP 13: With internal console and structure
support removed from outside shell.
Cut the four
tabs that are shown.
Cont.
From
Page 1
Continued on Page 3 ➔
➔
STEP 9: With factory console outside truck,
remove the four 8mm bolts from bottom of
console.
STEP 10: Remove hinghed lid by removing
the seven T-15 torx head bolts.
(6 are shown in the picture, 7th is under strap,
not seen)
STEP 14: With Steathbox mounted, place the
OEM console shell over Stealthbox.
Push in the supplied pair of tree locks to each
side of the OEM console.
STEP 15: Using a 1/8” drill bit, drill into
upper sides of the Stealthbox. Using the OEM
screw holes as guides. Use the four screws
that was removed in STEP12 to mount
outside shell to the Stealthbox.
STEP 11: With lid removed, this will allow
access to a pair of T-15 Torx bolts. Remove
these T-15 Torx head bolts.
Pull out inner console from outside shell.This
will expose the structure support.
STEP 12: Remove the four screws from
sides of the structure support. Remove the
structure support from outside shell.
SB-F-RTEKCTR/12W3v2-D2, JL AUDIO, Inc 2002 Sheet SKU#011159 Revision 11/18/2003Page 2
www.jlaudio.com
➔➔
STEP 13 B (if nessesary): In some
consoles there might be additional two
tabs.They are located on the rear of outside
shell, remove these is so equipt.
➔
➔
➔
➔
➔
➔
➔
➔
➔
➔
➔
➔
➔
➔
➔
➔
➔
➔
➔
➔
➔

➔
Continued on Page 4 ➔
➔➔
➔➔
STEP 17: A) Line up small angle bracket to front
middle of OEM inner(cut) console and mark hole.
STEP 17: B) Using an 1/8” drill bit, drill
marked hole.
Cont.
From
Page 2
➔
➔
STEP 17: C) Mount the small angle bracket using
the suppied black rivet and small washer.
STEP 18: Place inner (cut) OEM console inside
outter OEM console / top of Stealthbox.
Drill six holes using 1/8” drill bit. Using the OEM
inner console’s lid mounting holes as guides.
STEP 19: Using the six(out of seven) T-15 Torx
bolts that was removed in STEP 10, mount lid.
STEP 20: With lid mounted, drill “7th” hole
using a 1/8” drill bit.
Don’t forget to bolt down lid strap with the
7th t-15 Torx screw.
SB-F-RTEKCTR/12W3v2-D2, JL AUDIO, Inc 2002 Sheet SKU#011159 Revision 11/18/2003Page 3
www.jlaudio.com
➔
➔
STEP 16: Use masking tape to mark cutting
template.
IMPORTANT!!!! Please read STEP 16 A and
Bbefore cutting.
Us ing a suitable saw to cut OEM inner
console.
IMPORTANT!!!!
A) Cut 1 1/2” under lip.Where there is no
ledge/reinforcement
IMPORTANT!!!!
B) Where there is a ledge/reinforcement cut
1 5/16” under the ledge/reinforcement.

Specifications:
Enclosure Type: Acoustic Suspension (Sealed)
Driver Type: One JL AUDIO 12W3v2-D2 Subwoofer
Nominal Impedance: 4Ω
Cont. Power Handling: 300 Watts
JL Audio recommends using a high quality amplifier such as the JL Audio 250/1. The diagram below shows the recommended
crossover, infrasonic filter and equalizer settings for the 250/1 when being used to power the JL Audio Stealthbox®.
Included Hardware:
1) Black Pop Rivet
1) #4 Steel Flat Washer
1) Small Angle Bracket
1) #8x1/2” Pan Head Screw
2) 1/4” Flat Washers
2) 1/4” Lock Washers
2) #6 x 40mm Bolts
2) Round Steel Spacers
2) Tree Push-In Rivets
10369 N. Commerce Pkwy, Miramar, Florida 33025-392 Phone: [phone] Fax: [phone]
The JL Audio 250/1 is a very versitile audio component. Please consult the owner’s manual for detailed information
about installing and tuning this amplifier.
➔➔➔
STEP 21: Mount lid strap using the
“7th” T-15 Torx bolt.
STEP 22: With OEM outer console, OEM
inner cut console and hinged lid mounted.
Look in the lid latch catch, located on the
front of OEM inner console.You will see the
small angle bracket that was mounted in
STEP 11. Drill 1/8” hole through the lid latch
catch using the hole from the small angle
bracket as a guide. Mount the small angel
bracket with supplied #8x1/2” black pan head
screw to the Stealthbox.
STEP 23: Repalce front pocket that was removed
in STEP 1 and close the lid.
Cont.
From
Page 3
➔
SB-F-RTRKCTR/12W3v2-D2, JL AUDIO, Inc 2002 Sheet SKU#011159 Revision 11/18/2003Page 4
www.jlaudio.com
Mid/High Frequency Driver Information:
CONGRATULATIONS!
INSTALL COMPLETE.
XR570-CSi
XR570-CXi
Front Location Driver Size:
5"x7” (1271mm x 177.8mm)
Applicable JL Audio Products:
TR570-CXi, XR570-CXi or CSi
Rear Location Driver Size:
5"x7” (1271mm x 177.8mm)
Applicable JL Audio Products:
TR570-CXi, XR570-CXi or CSi
