INSTALLATION GUIDE
for the
SB-N-FRNTCC/10W1v2
SB-N-FRNTCC/10W1v2
2005 - Up
2005 - Up
Nissan Frontier CrewCab Trucks
Nissan Frontier CrewCab Trucks
Thank you for choosing a JL Audio Stealthbox®for your automotive sound system. With proper
installation, your new vehicle-specific enclosed subwoofer system will deliver years of listening pleasure.
We strongly recommend that you have your new Stealthbox®installed by your authorized JL Audio
dealer. The installation professionals employed by your dealer have the necessary tools and experience
to disassemble and reassemble your vehicle properly. Also, keep in mind that your warranty coverage
extends to 1 year if your system is installed or approved by your authorized JL Audio dealer. If you
prefer to perform your own installation, please read this installation guide completely
before beginning the process.
If you choose to perform the installation yourself, it is absolutely vital that
the Stealthbox®be properly mounted to the vehicle according to these
instructions. Failure to mount the enclosure properly presents two problems:
1) The sub-bass performance will suffer due to the movement of the enclosure
caused by the force exerted by the woofer(s).
2) A loose enclosure presents a serious safety hazard in the event of a collision
or sudden deceleration.
STEP 1
Remove both storage bins from under the rear seat.
If the truck is not equipped with the factory woofer, go to
STEP 4.
Continued on Next Page
STEP 2
Using a 10mm socket, remove the three mounting bolts that
secure the factory woofer enclosure to the truck’s floor.
STEP 3
Using a 10mm socket, remove the two mounting bolts that
secure this mounting bracket to the truck’s floor.
Tuck the factory speaker wire under the carpet and out of
the mounting area of the Stealthbox®.
SB-N-FRNTCC/10W1v2_INSTR_SKU#011229
SB-N-FRNTCC/10W1v2_INSTR_SKU#011229
INSTALLATION
DIFFICULTY:
2
5
OUT
OF
ESTIMATED TIME:
1 HOUR

Continued on Next Page
SB-N-FRNTCC/10W1v2_INSTR_SKU#011229
SB-N-FRNTCC/10W1v2_INSTR_SKU#011229
STEP 7
Place the Stealthbox® into the mounting location.
Use a supplied 3/8-inch bolt to secure the long end of the
Z-bracket to the top of the Stealthbox®. Only hand tighten at
this time.
STEP 6
Trucks that are equipped with the factory woofer.
Use the supplied 6mm bolt to secure the short end of the
supplied Z-bracket to the floor, as in the picture. Only hand
tighten at this time.
Trucks that are not equipped with the factory woofer.
Feel for a mounting point that is located under the carpet
and on the floor area that slopes up. Once found, cut the car-
pet around this mounting point. Use the supplied 6mm bolt
to secure the short end of the supplied Z-bracket to the floor.
Only hand tighten at this time.
STEP 5
Place the middle of the wax square into place, shown in the
picture.
STEP 4
Remove the sill plate.
Page 2 • JL Audio, Inc 2006
STEP 10
Note: Before drilling, make sure that you are not going
to be drilling into any gas lines, brake lines, transmission
lines, electrical wiring, transfer case (4x4 vehicles)
or anything else that might cause a reduction in your
weekly pay. Always wear eye protection when drilling!
With a 1/2-inch drill bit and drill, place the drill bit through
wax square and the carpeting at the impression made in
the wax square. Drill through the metal floor. Remove the
wax square.
STEP 12
Place the Stealthbox® into the mounting area.
Run speaker wire to the Stealthbox® and wire to the terminal.
Double check the woofer for proper operation.
Back out the socket cup set screw to expose 2-inches
Place the Stealthbox®into position by guiding the socket
cup set screw through the drilled hole.
STEP 11
Place the sill plate back into place.
STEP 8
Lower the seat down onto the Stealthbox®. Line up the top
corner of the Stealthbox®to the bottom corner of the seat.
Flip the seat up and push down onto the top of the
Stealthbox®.
Unbolt the Z-bracket and remove the Stealthbox®carefully,
leaving the wax square in place. The socket cup set screw
will leave an impression in the wax.
Using an utility knife, cut an “X” through the wax square at
the impression of the socket cup set screw and through the
carpet.
6-inches
5-inches

SB-N-FRNTCC/10W1v2_INSTR_SKU#011229
SB-N-FRNTCC/10W1v2_INSTR_SKU#011229
STEALTHBOX WALL THREADED INSERT
VEHICLE SHEET METAL
FENDER WASHER SOCKET CUP SET SCREW
LOCK WASHER
FLAT WASHER
HEX NUT
CONGRATULATIONS
You have completed the installation for this model!
Please refer to the Power Recommendation section for an
amplifier recommendation and basic set-up help.
STEP 15
Secure the passenger’s side storage bin.
STEP 14
From under the vehicle, place a supplied fender washer,
flat washer, lock washer and then hex nut onto the socket
cup set screw and secure.
Note: For added protection it is recommended that
you apply a bead of silicone between the vehicle and
the fender washer. After the bolt assembly is tightly
secured, it is also recommended that vehicle under-
coating material is applied to the exposed assembly
STEP 13
Place a supplied 3/8-inch lock washer and flat washer onto
the 3/8-inch bolt.
Place the supplied 6mm flat washer onto the 6mm bolt.
Using a socket, fully secure the Z-bracket to the truck’s
mounting point and on top of the Stealthbox®.
Page 3 • JL Audio, Inc 2006
All specifications are subject to change without notice. “JL Audio®” and the JL Audio logo, “Stealthbox” and the Stealthbox logo are registered
trademarks of JL Audio, Inc.“Ahead of the Curve” and its respective logo is a trademark of JL Audio, Inc.
JLA-SKU#011229-05-12-200
JLA-SKU#011229-05-12-200
7
7• Printed in USA • ©2005 JL Audio, Inc. • U.S. PATENTS: #5,734,734 #5,949,898 #6,118,884 #6,229,902
#6,243,479 #6,294,959 #6,501,844 #6,496,590 #6,441,685 #5,687,247 #6,219,431 #6,625,292 #D472,891 #D480,709 Other U.S. & Foreign
patents pending. For more detailed information please visit us online at www.jlaudio.com.
[phone]
www.jlaudio.com
10369 NORTH COMMERCE PARKWAY • MIRAMAR, FLORIDA • 33025 • USA
INCLUDED HARDWARE
(2)
(2)
Black Rubber Tapered Squares
Black Rubber Tapered Squares
(1)
(1)
3/8-inch -16 x 1 1/2-inch Bolt
3/8-inch -16 x 1 1/2-inch Bolt
(2)
(2)
3/8-inch Split Lock Washer
3/8-inch Split Lock Washer
(1)
(1)
3/8-inch x 1 1/4-inch Fender Washer
3/8-inch x 1 1/4-inch Fender Washer
(2)
(2)
3/8-inch Flat Washer
3/8-inch Flat Washer
(1)
(1)
Z-Bracket
Z-Bracket
(1)
(1)
6mm x16mm Bolt
6mm x16mm Bolt
(1)
(1)
3-inch x 3-inch Wax Square
3-inch x 3-inch Wax Square
(1) 3/8-inch -16 Hex Nut
(1) 3/8-inch -16 Hex Nut
(1)
(1)
3/8-inch -16 x 2 1/4-inch Socket Cup Set Screw
3/8-inch -16 x 2 1/4-inch Socket Cup Set Screw
(1)
(1)
6mm Flat Washer
6mm Flat Washer
SPECIFICATIONS
Enclosure Type:
Acoustic Suspension (sealed)
Acoustic Suspension (sealed)
Driver Type:
10W1v2-4
10W1v2-4
Nominal Impedance:
4 ohms mono
4 ohms mono
Continuous Power Handling:
150 Watts
150 Wat ts
POWER RECOMMENDATION
JL Audio recommends using a high quality amplifier such as the JL Audio A2150.
The diagram below shows the recommended crossover, infrasonic filter and equalizer settings for the A2150 when
being used to power your Stealthbox®.
The JL Audio A2150 is a very versatile audio component. Please consult the owner’s manual for even more
detailed information about installing and tuning this amplifier.
MID/HIGH FREQUENCY DRIVER FITMENT
A variety of JL Audio coaxial and component systems will fit in the factory speaker locations of you vehicle.
Front Speaker Size / Location:
6.5-inch / Front Doors
6.5-inch / Front Doors
Fits JL Audio Models:
TR650-CXi, TR650-CSi, VR650-CXi, VR650-CSi, XR650-CXi, XR650-CSi,
TR650-CXi, TR650-CSi, VR650-CXi, VR650-CSi, XR650-CXi, XR650-CSi,
C5-650x, C5-650 & ZR650-CSi
C5-650x, C5-650 & ZR650-CSi
Rear Speaker Size / Location:
6.5-inch / Rear Doors
6.5-inch / Rear Doors
Fits JL Audio Models:
TR650-CXi, TR650-CSi, VR650-CXi, VR650-CSi, XR650-CXi, XR650-CSi,
TR650-CXi, TR650-CSi, VR650-CXi, VR650-CSi, XR650-CXi, XR650-CSi,
C5-650x, C5-650 & ZR650-CSi
C5-650x, C5-650 & ZR650-CSi
