JMPosner SQ1 User manual

CASCADE FOUNTAIN
USER GUIDE
This manual covers the use of the following commercial fountain models:
SQ1 -SQ2 - SQ3 - SQ4 & SQ4 TALL

2
IMPORTANT SAFEGUARDS
When using our Cascade Chocolate Fountain, safety precautions should always be
followed including the following:
1. READALLINSTRUCTIONSBEFOREUSINGTHISFOUNTAIN.
2. Whenthefountainbasinisremoved,thetopofthefountainbasecanbeextremely
hot.AVOIDANYCONTACTWITHTHETOPOFTHEFOUNTAINBASEIFITISEXPOSEDasthe
heatingelementislocateddirectlybeneath.
3. Avoidallothersurfacesthathavebecomehotduringuse.
4. Toprotectagainstelectricalshockanddamagetothefountain,donotputthe
fountainbaseinwaterorotherliquids.Neverallowliquidtoenterthefountainbase
throughthebottomgrate,ventholes,orotheropenings.
5. Whenbasinisremoved,takeextracaretokeeptheliquidorotherobjectsfrom
enteringintotheexposedopeningatthetopofthefountainbase.
6. Avoidcontactwithmovingparts,suchastheaugerinthecylinderorthespindleinthe
centreofthebasin.
7. Closesupervisionisnecessarywhenthefountainisusednearchildren.
8. Donotoperatethefountainifyouobservedamagetotheelectricalcordorplugorif
thebaseofthefountainhasbeendroppedordamagedinanymanner.Thefountain
mustbereturnedtoJMPosneroradesignatedrepairfacilityforexaminationand
repairasspeciedinthe“Warranty”sectionofthismanual.
9. Alwaysunplugthefountainfromtheelectricaloutletwhenitisnotinuse,especially
beforeputtingonortakingoffparts,andbeforecleaning.
10.Donotallowtheelectricalcordtocomeintocontactwithhotsurfaces.Anextension
cordmaybeusedifnecessary.Careshouldbetakentopositiontheelectricalcord
sothatitdoesnotcreateahazardbyhangingoveratableorcounteredgeinsucha
waywhereitmightbetrippedonorpulledbythosearoundthefountain.
11.Neverplaceanyobject,especiallyyourngers,insidethecentralcylinderwhilethe
fountainisinuse.Doingsomaycausesevereinjurytopersonsordamagetothe
fountainitself.
12.Theuseofaccessoryattachments,otherthanthosemadeavailablespecicallyfor
usewiththisfountain,isnotrecommendedbythemanufacturer,andmaycause
injury,andwillvoidyourwarranty.
13.Extremecautionmustbeusedwhenmovingafountainorfountaincomponents
containinghotliquid.Alwaysmovethefountainbyliftingthedrum.Ifyouliftthebasin
itmightcomeofffromthedrum.
14.UseofthefountainoutdoorsisnotrecommendedunlessusedwithaWindGuard.
15.Donotusethisfountainforotherthanitsintendeduse.
16.TheFountainmustbeonalevelsurfacetooperateproperly.
17.Observeandfollowcustomarysanitationguidelineswhenusingthismachine.



3
WARNING
PleaserefertoimportantinformationregardingbearingservicingofthisCascade
ChocolateFountaincontainedinyourusermanualandwarranty.
InessencethisrequiresthattheCascadeChocolateFountainhasit’sbearingsserviced
every800hoursoreachyear,whichevercomesrst.Failuretodothismayresultinthe
invalidationofyourwarranty.
GENERAL INFORMATION
Themainproblemofinsufcientservicingis:
• Theseals(locatedinthebowl)mayfailwhichwillallowchocolatetoleakintothe
motorcompartmentandcausethemotorandothercomponentstofail.
• Toreducetheriskofproblemsandtotestwhetherthemachinerequiresaservice.
Pleasetakenoteofthefollowingpoints:
• Neverwashtheremovablebowlinthedishwasher.Thesteamandhotwatercan
causeprematurefailureofthesealsandrustingofthebearings.Alwayswashinthe
sinkanddonotfullysubmerge.
• Everytimeyoucleanthefountainandremovethebowltryturningthespindleby
hand.Thisshouldmovefreely,ifitdoesnotthenmachineneedstobeserviced.
• Oncethebowlhasbeenremovedchecktheunderside,andalsointhemotor
compartmentforanysignsofleakingchocolate(thiscanresemblethickblack
grease).Ifthereisanyevidenceofthisstopusingthemachineimmediatelyandbook
aservice.
• Fortheavoidanceofdoubt,anymachinethatisreturnedtouswherethebearings
haveseizedwillbedeemedtobeoutofwarranty.
SQ4 - SPECIFICATION
• Totalheight:    935mm
• Heightoftopsection:   534mm
• Widthofdrum:    367mm
• Heightofdrum:    401mm
• Widthofbasin:    500mm
• Weight:     29.5kg
• Electrical: 110/230V|60/50Hz|500W
SQ2 - SPECIFICATION
• Totalheight:    992mm
• Heightoftopsection:   633mm
• Widthofdrum:    295mm
• Heightofdrum:    359mm
• Widthofbasin:    408mm
• Weight:     18.5kg
• Electrical:  110/230V|60/50Hz|450W
SQ1 - SPECIFICATION
• Totalheight:    723mm
• Heightoftopsection:   452mm
• Widthofdrum:    255mm
• Heightofdrum:    271mm
• Widthofbasin:    300mm
• Weight:     9.5kg
• Electrical:  110/230V|60/50Hz|250W
SQ3 - SPECIFICATION
• Totalheight:   1131mm
• Heightoftopsection:   735mm
• Widthofdrum:    367mm
• Heightofdrum:    396mm
• Widthofbasin:    495mm
• Weight:     28kg
• Electrical:  110/230V|60/50Hz|500W
SQ4 TALL - SPECIFICATION
• Totalheight:   1400mm
• Heightoftopsection:   534mm
• Widthofdrum:    367mm
• Heightofdrum:    401mm
• Widthofbasin:    500mm
• Weight:     37.5kg
• Electrical:  110/230V|60/50Hz|500W

4
FOUNTAIN ASSEMBLY INSTRUCTIONS
FOUNTAIN COMPONENTS
• DecorativeBall–Fitsonthetophat(SQ1/SQ2/SQ3only).
• TopHat–Fitsontopofthecentrecolumnandholdsthemetalscrewinthemiddle.
• Cups–Fixedtothecentrecolumn,allowthechocolatetoowdownsmoothly.
• Brackets–Toxthecupstothecentrecolumn.
• CentreColumn–Slotsintothecentralhousingofthebasin.
• Auger–Sitsonthesquaremetalshaftinthemiddleofthebasininsidethecentre
column.
• Basin–Whichsitsontopofthedrumandholdsthecentrecolumnandscrew.Donot
placeitinthedishwasher.ThebasinisNON - REMOVABLEontheSQ1andSQ4TALL
models.
• Drum–Thisisthebottomofthefountain.Ithousesalloftheelectricalcomponents,
includingthemotorunit.Onlytobeopenedbyaqualiedperson.
a.)Theventholesallowhotairproducedbythemotorandheatingelementsto
escape,coolingtheelectricalcomponents.Ventholesshouldnotbecoveredduring
use.
• MembraneSwitch–Thecontrolsystemswitchesthechocolateheateronandoffto
maintainthetemperatureatapre-setlevel,andswitchesthemotoronandoffas
required.ThereisatwodigitLEDdisplaytoindicatethetemperatureindegreesCelsius
(notfeaturedonSQ1cascade),andalsotwoindividualLEDindicatorswhichlight
whentheheaterandmotorrespectivelyareON.Themembraneswitchpanelhasa
pairofpush-buttonswitchesforUPandDOWNcontrolofthetemperature,andathird
push-buttoncommandstheON/OFFstateofthemotor.
• Fuse–Themachinehas3fuses.1stfuseisinthepowercord.2ndfuseisinthepower
socketonthedrumandthe3rdfuseisonthePCBboardinsidethedrum.Onlya
qualiedelectricianshouldreplacethefuseinthePCBboard.
• AdjustableFeet–Screwintothebottomofthebase.Thesemaybetightenedor
loosenedtoraiseorloweraparticularsideofthefountainforleveling.

5
STEP 1
Removefountaincomponentsfromtheirboxes
andplacefountaindrumonasturdy,level
surface.Makesurethedrumislevelsothatthe
chocolatewillowproperly.
STEP 2
Tocheckthefountainislevelplaceaspiritlevel
onthebasinrimatvariouslocations(Fig.1).If
levelingisneeded,raiseorloweraparticular
sideofthefountainbyadjustingthefeet.
STEP 3
Placeaugerontopofthesquarecentreshaftin
themiddleofbasin(Fig.2).
STEP 4
Placethecentrecolumnontothecentre
housinginthemiddleofthefountainbase(Fig.
3).Ensurethattheslotonthecolumnbaselines
upwiththelocatingpinontheinsideofthe
housing.Pleasenotethattheaugerwillnotll
thewholelengthofthecolumn,thisisnormal
anddoesnotaffectoperationofthefountain.
STEP 5
PlacetheCupsonthecentrecolumn,
matchingthenumbersonthecupswiththe
correctnumberedbracketonthecolumn(Fig.
4).Forexample,cupA1mustattachtobracket
A1;thereare8cupsintotal,A1-A4andB1-B5.
STEP 6
Placethetophatontopofthecentrecolumn.
STEP 7
Placethedecorativeballintothetophat.
FOUNTAIN ASSEMBLY SQ1 CASCADE
Centre & Locating Pins
Slot in column
Fig. 1
Fig. 2
Fig. 3
Fig. 4

6
STEP 1
Removefountaincomponentsfromtheirboxes
andplacefountaindrumonasturdy,level
surface.Makesurethedrumislevelsothatthe
chocolatewillowproperly.
STEP 2
Placethebasinontopofthedrumatan
angleandpushdownandturnclockwise45
degreestolockthebasinwithdrum.Tocheck
thefountainislevelplaceaspiritlevelonthe
basinrimatvariouslocations(Fig.1).Ifleveling
isneeded,raiseorloweraparticularsideofthe
fountainbyadjustingthefeet.
STEP 3
Placeaugerontopofthesquarecentreshaftin
themiddleofbasin(Fig.2).
STEP 4
Placethecentrecolumnontothecentre
housinginthemiddleofthefountainbase(Fig.
3).Ensurethattheslotonthecolumnbaselines
upwiththelocatingpinontheinsideofthe
housing.Pleasenotethattheaugerwillnotll
thewholelengthofthecolumn,thisisnormal
anddoesnotaffectoperationofthefountain.
STEP 5
PlacetheCupsonthecentrecolumn,
matchingthenumbersonthecupswiththe
correctnumberedbracketonthecolumn(Fig.
4).Forexample,cupA1mustattachtobracket
A1;thereare10cupsintotal,A1-A5andB1-B5.
STEP 6
Placethetophatontopofthecentrecolumn.
STEP 7
Placethedecorativeballintothetophat.
FOUNTAIN ASSEMBLY SQ2 CASCADE
Centre & Locating Pins
Slot in column
Fig. 1
Fig. 2
Fig. 3
Fig. 4

7
STEP 1
Removefountaincomponentsfromtheirboxes
andplacefountaindrumonasturdy,level
surface.Makesurethedrumislevelsothatthe
chocolatewillowproperly.
STEP 2
Placethebasinontopofthedrumatan
angleandpushdownandturnclockwise45
degreestolockthebasinwithdrum.Tocheck
thefountainislevelplaceaspiritlevelonthe
basinrimatvariouslocations(Fig.1).Ifleveling
isneeded,raiseorloweraparticularsideofthe
fountainbyadjustingthefeet.
STEP 3
Placeaugerontopofthesquarecentreshaftin
themiddleofbasin(Fig.2).
STEP 4
Placethecentrecolumnontothecentre
housinginthemiddleofthefountainbase(Fig.
3).Ensurethattheslotonthecolumnbaselines
upwiththelocatingpinontheinsideofthe
housing.
STEP 5
PlacetheCupsonthecentrecolumn,
matchingthenumbersonthecupswiththe
correctnumberedbracketonthecolumn(Fig.
4).Forexample,cupA1mustattachtobracket
A1;thereare15cupsintotal,A1-A5,B1-B5and
C1-C5.
STEP 6
Placethetophatontopofthecentrecolumn
makingsurethattheaugerpinsitsinthemiddle
ofthetophatring.
STEP 7
Placethedecorativeballintothetophat.
FOUNTAIN ASSEMBLY SQ3 CASCADE
Centre & Locating Pins
Slot in column
Fig. 1
Fig. 2
Fig. 3
Fig. 4

8
STEP 1
Removefountaincomponentsfromtheirboxes
andplacefountaindrumonasturdy,level
surface.Makesurethedrumislevelsothat
thechocolatewillowproperlybyplacinga
spiritlevelonthebasinrimatvariouslocations
(Fig.1).Iflevelingisneeded,raiseorlowera
particularsideofthefountainbyadjustingthe
feet.
STEP 2
Placebothaugersontopofthesquarecentre
shaftinthemiddleofeachcolumn.(Fig.2)
STEP 3
Placeeachcolumnontothecolumnhousing
(Fig.3).
STEP 4
PlacetheCupsonthecolumns,matching
thenumbersonthecupswiththecorrect
numberedbracketonthecolumn(Fig.4).For
example,cupA1mustattachtobracketA1.
STEP 5
Placeeachtophatontopofthecolumns
makingsurethattheaugerpinsitsinthemiddle
ofthetophatring.
FOUNTAIN ASSEMBLY SQ4 & SQ4 TALL CASCADE
Fig. 1
Fig. 2
Fig. 3
Fig. 4
Centre & Locating Pins
Slot in column

9
FOUNTAIN OPERATING INSTRUCTIONS
STEP 1
Preheatthefountainbyturningonswitchonthepowersocketsettheheatlevelto70
degreesbypressingthe( + )key(SQ1operatesatastandardtemp.).Allowfountainto
preheatforatleast10minutes.
STEP 2
JMPosnerFonduechocolatecaneitherbepre-meltedormelteddirectlyinthefountain.
Topre-melt,followtheinstructionsonthemicrowaveablebag.Tomeltinthefountain,
add1kgofchocolateatatime,stirringoccasionallyuntilcompletelymelted.
Toaddchocolatetothefountainduringuse,eitherpre-meltthechocolateorpour1cup
ofchipsatatimedirectlyintothebasin.Allowchipstomeltbeforeaddingmore.
Important Note:Donotoverllthefountain;seefountaincapacitiesbelow.
STEP 3
Oncethechocolateiscompletelymelted,lowertheheatbypressingthe( - )keytothe
operatingtemperatureandturnthemotorswitchto“ON”.
SQ3 7kg 13kg
SQ4&SQ4TALL 4kgpersection 6.3kgpersection
SQ2 4kg 7kg
SQ1 1.5kg 3kg
FountainCapacities
Model Min. Amt (kgs) Max. Amt (kgs)
White Pre-set 70°C70°C60°C
Milk Pre-set 70°C70°C60°C
SQ1 SQ2 SQ3 SQ4 & SQ4 TALL
Dark Pre-set 70°C70°C60°C
TemperatureSettings
Chocolate type

10
IMPORTANT INFORMATION ABOUT THE
CONTROL PANEL
Thecontrolsystemswitchesthechocolateheateronandoffsoastomaintainthe
temperatureatapre-setlevel,andswitchesthemotoronandoffasrequired.
ThereisatwodigitLEDdisplaytoindicatethetemperatureindegreesCentigrade,and
alsotwoindividualLEDindicatorswhichlightwhentheheaterandmotorrespectivelyare
on.Amembraneswitchpanelhasapairofpush-buttonswitchesforUP( + )andDOWN
( - )tocontrolthetemperature,andathirdpush-buttoncommandstheON/OFFstateof
themotor.
1) SETTING THE TEMPERATURE
Wheneitherofthe( + ) or( - )push-buttonsispressedthesystementersthetemperature
settingmodeandthedisplayshowstheexistingunchangedsetpointtemperature.The
twodisplaydecimalpointsashonalternatelytoconrmthatthetemperaturesetting
modeisenabled.Furtherpressesofthe( + ) or( - )push-buttonscausethetemperature
tobeincreasedordecreasedrespectivelyby1°Catatime,butifeitherpush-buttonis
heldforlongerthantwosecondsthetemperatureisraisedorloweredcontinuouslyata
rateof3°Cpersecondforaslongasthepushbuttonisheld.Ifthetemperaturereaches
99°C,furtheruseofthe( + )push-buttoncannotalterthetemperaturefurthernorifthe
temperaturereaches0°Cthe( - )push-buttonwillnotehaveanyeffect(notethatsetting
atemperaturebelowtheambienttemperatureisirrelevantasthesystemonlyhasa
heater).
Ifneitherpush-buttonisoperatedforlongerthanthreeseconds,thesystemautomatically
comesoutofthetemperaturesettingmodeandtheashinglightturnsoff.Atthesame
timethenalsettemperaturevalue(TSET)isstored,thistemperaturesettingwillbeused
whenthefountainisnextswitchedon.
2) TEMPERATURE CONTROL
Whenthefountainisswitchedon,theheaterisalwaysintheONstateinitially,andthe
HeaterLEDisilluminated.Thetemperaturewilluctuatearoundyoursettemperature,
thusthehysteresisbandis2°C.Ifthetemperaturesensorfails,orisun-pluggedfromthe
controlboard,theheaterandthemotorarebothswitchedOFF,andthedisplayshows
‘SF’(SensorFault).
3) MOTOR CONTROL
Whenthefountainisswitchedon,themotorisalwaysintheOFFstateinitially,andthe
MotorLEDisoff.ThemotorsubsequentlyrunsONwhenthe( ON )push-buttonispressed,
andtheMotorLEDisilluminated.Subsequentoperationofthe( ON / OFF )push-button
togglesthemotorandindicatorbetweentheONandOFFstates.
However,ifwhenthemotorissettobe( ON )themotorwillonlystartwhentheactual
temperaturegetstowithin10°Cofthetemperaturesetusingthecontrolpanel(eg.
Fountainsetat80°Cmotorwillonlyfunctionwhenactualtemperaturereaches70°C).In
thisevent,thedisplayshows‘LT’(Lowtemperature)fortwosecondsbeforeitrevertsto
thenormaltemperatureindication.Thisistominimizepossibleoverheatingofthemotor,
asthereisariskoftheAugerbeinglockedduetosolidchocolate.
Themotoralsohasabuilt-inthermalswitchwhichopensifitstemperatureexceedsa
safelimit.Thisswitchconnectsbacktothecontrollertooverridenormalmotoroperation.
WheneverthethermalswitchisopenthemotordriveissettoOFF,andthedisplayshows
‘OL’(Over-Load)untilthemotorhascooledsufcientlytoresetthethermalswitch.The
motorcanthenbere-startedmanuallybyusingthe( ON / OFF )push-button.
