1.0.0 Introduction
1.1.0 Forward
The Jogler JLT-6000 series transmitter represents the latest in magnetostrictive level transmitter
technology. Suitable for most liquid level applications, the JLT transmitter provides a very accurate and
reliable output for remote level control with zero maintenance. With greater ease of communication and
programmability, the JLT series contains the latest state-of-the-art electronics and sensor technology.
The JLT series is available in three different configurations; the ILT, LGT and MGT-6000 series. All
transmitters are factory calibrated to the specifications required with each order and installation.
The ILT-6000 series transmitter is designed for direct insertion into a storage tank, process
vessel or bypass chamber. The ILT can be top or bottom mounted and comes with a patented
thermo-well enclosure. As a result, the 316 SS waveguide probe of the transmitter is not exposed
directly to the process conditions since it is isolated within the thermowell. Only the thermowell
enclosure and level float are exposed to external process conditions. Remote mounted transmitter head
locations are available.
The LGT-6000 series transmitter is designed for installation directly into a liquid level sight
glass. The patented LGT design provides 100% confirmation between the liquid level in the gage and
the float position of the transmitter relative to the fluid level established in the sight glass. Top, bottom
or remote mounted transmitter head locations are available. The waveguide probe and float are
directly exposed to external process conditions in this configuration. The waveguide probe is not
exposed to internal process conditions.
The MGT-6000 series transmitter is designed exclusively for magnetic level indicators. The
waveguide probe is installed externally on the outside of the magnetic level gage chamber and is not
exposed to process conditions. Based on the level gage specifications, top, bottom or remote mounted
transmitter head locations are available.
1.2.0 Theory Of Operation
Magnetostrictive level transmitters operate in conjunction with a magnetic field that originates from a
liquid level float designed for the process media. A two wire waveguide probe of variable length is
connected to the transmitter sensor and electronic assembly. The two wire waveguide is housed within
a sealed ¼ inch (OD) sensor probe and receives a short current pulse at timed intervals. Disruption of
the waveguide is caused by torsion generated by the float’s lateral magnetic field at any elevation. This
torsion or deflection of the waveguide is detected by the transmitter sensor, which produces a very
accurate signal proportionate to the level elevation.

6646 Complex Drive | Baton Rouge, LA 70809 | Phone: [phone] | Toll Free: 1-800-223-8469 | [e-mail] | www.jogler.com
Page 4
JLT-6000 .IOMM.REV 001 (06.2007) WWW.JOGLER.COM PAGE 4
__________________________________________________________________________________
Installation and Operating Manual JLT-6000
__________________________________________________________________________________
2.0.0 Preparation
2.1.0 Introduction
Jogler JLT series level transmitters are built and designed to exact customer specifications as defined
in each model number. Wiring terminations are required and need to follow proper procedures.
2.2.0 Unpacking Freight
Upon receipt, all packages containing Jogler products are to be opened carefully and inspected for
freight damages. If damage to the product has occurred due to freight, a claim needs to be made at the
point of product receipt and initial inspection within 24 hours. Jogler does not insure freight or make
freight claims on behalf of the owner. Do not discard the shipping container until all components are
accounted and inspected for.
2.3.0 Storage
If the transmitter requires storage for prolonged periods, care must be given to ensure product
protection from physical and ambient conditions. Seal the entire device completely from condensation
and store it with the shipping materials provided. Do not leave any auxiliary conduit connection open.
Recommended storage temperatures are -10 to +130° F.
2.4.0 Electronic Static Discharge
Jogler level transmitters are manufactured from the highest quality electronic components of which can
be damaged by static electricity. Care must be taken to eliminate static discharges surrounding the
transmitter upon installation. All equipment proximal to the transmitter must be grounded to a secure
source. Grounding terminals are provided both inside and outside of the instrument enclosure.
2.5.0 Equipment and Recommended Tools
To attach the JLT series transmitter to an existing piping or vessel connection, the operator will need
the following tools:
•Nut drivers for MGT attachment to piping clamps
•Phillips and flat head screwdrivers
•Wrenches for ILT and LGT installation
•Digital volt meter to verify and troubleshoot voltage

6646 Complex Drive | Baton Rouge, LA 70809 | Phone: [phone] | Toll Free: 1-800-223-8469 | [e-mail] | www.jogler.com
Page 5
JLT-6000 .IOMM.REV 001 (06.2007) WWW.JOGLER.COM PAGE 5
__________________________________________________________________________________
Installation and Operating Manual JLT-6000
__________________________________________________________________________________
2.6.0 Temperature Ratings
The maximum ambient temperature rating of the JLT series electronics is -40 to + 160° F. The ambient
temperature range of the LED readout is -10 to +160° F. Ambient temperatures above and below that
rating may cause the LED readout to malfunction. The transmitter head may require protection from
prolonged direct sunlight exposure. Low temperature cryogenic or high temperature insulation blankets
should be installed during extreme process operating temperatures.
The maximum process temperature rating of the JLT series transmitter is -40°F to +235° F and applies
to the waveguide probe.
2.7.0 Pressure Ratings
The maximum process pressure rating of the JLT series transmitter waveguide probe is 300 PSIG.
This rating applies to LGT-6000 series which is a direct insertion model for level gage applications only.
The waveguide probe in the ILT-6000 series transmitter is protected by and contained within the
thermowell and is therefore not subject to process pressure. The MGT-6000 is an externally mounted
transmitter and is not subject to process pressure.
2.8.0 Voltage
The JLT transmitter is designed to operate at 24 Volts DC, nominal. Please ensure that the power
supply to the transmitter is the same 24 VDC voltage required. Although the voltage range of the JLT
transmitter is +12 to +30 VDC, it is highly recommended that the service voltage is established at a
stable and continuous 24 VDC. Higher voltages will damage the transmitter. Do not connect to AC
current since this will damage the transmitter and violate the transmitter warranty.

6646 Complex Drive | Baton Rouge, LA 70809 | Phone: [phone] | Toll Free: 1-800-223-8469 | [e-mail] | www.jogler.com
Page 6
JLT-6000 .IOMM.REV 001 (06.2007) WWW.JOGLER.COM PAGE 6
__________________________________________________________________________________
Installation and Operating Manual JLT-6000
__________________________________________________________________________________
3.0.0. Mounting
3.1.0 Introduction
Determine if the installation requires a top, bottom or remote mounted location. Consideration should
be given to electrical conduit connections before the transmitter is installed. It is important to verify
chemical compatibility with all wetted components.
3.2.0 MGT – Magnetic Level Indicators
•The second bend in the waveguide should be placed at the same elevation of the centerline of
the upper or lower process connection, depending upon the preferred transmitter head location.
•The transmitter head contains a special pipe clamp groove for chamber attachment first.
•Insolating Lbrackets are supplied for the waveguide. These maintain an even distance of the
waveguide away from the magnetic level gage chamber.
•Corresponding pipe clamps are provided for each Lbracket position, which should be spaced
evenly apart throughout the waveguide.
•Secure the L brackets by tightening each pipe clamp accordingly after the transmitter head is
secured.
3.3.0 ILT – Direct Tank Insertion (Waveguide with Thermowell)
•The assembly includes a welded flanged thermo-well and float that is separate from the
transmitter head and waveguide.
•Verify if the flanged thermo-well and float assembly matches the connection flange of the tank
or vessel and is of the specified material. Please note, since the ILT transmitter head, sensor
and waveguide probe are isolated from the process environment, the material of the
thermowell assembly can be different.
•Attach the flanged thermo-well and float assembly to the vessel connection flange without the
ILT transmitter head and waveguide.
•Slip the transmitter waveguide into the thermo-well after the thermo-well flange is attached to
the vessel connection flange.
•Secure the transmitter head, sensor and waveguide by tightening the sensor thread.
3.4.0 LGT – Level Gage Insertion (Waveguide without Thermowell)
•The assembly includes the transmitter head, threaded sensor, float and waveguide.
•Verify if the material of the waveguide and float are compatible with the process service.
•Connection size and type is 0.75 inch MNPT threaded or 0.75 inch sanitary, minimum.
•Secure the transmitter head, sensor and waveguide by tightening the sensor connection.

6646 Complex Drive | Baton Rouge, LA 70809 | Phone: [phone] | Toll Free: 1-800-223-8469 | [e-mail] | www.jogler.com
Page 7
JLT-6000 .IOMM.REV 001 (06.2007) WWW.JOGLER.COM PAGE 7
__________________________________________________________________________________
Installation and Operating Manual JLT-6000
__________________________________________________________________________________
4.0.0 Wiring
Connection to the JLT-6000 transmitter requires an electrical conduit connection of ¾ inch NPT. The
enclosure contains two conduit connection ports (Photograph No. 1). Wiring between the power supply
and the JLT-6000 transmitter should be made with 18 – 22 AWG shielded twisted pair instrument cable.
4.1.0 Connections
Once the electrical conduit is properly connected, the terminal block needs to be accessible for wiring
connections. The terminal block is located on the termination board which is attached to the enclosure
beneath the sealed transmitter puck. (Photograph No. 2) The transmitter puck plugs into the termination
board. The puck will require removal (unplugging) from the termination board in order to gain access to
the terminal block. Simply pull the transmitter puck out vertically and carefully. There are three guide
pins located on the bottom of the transmitter puck housing. These pins realign the puck perfectly into
the termination board upon reinstallation. (Photograph Nos. 3 and 4)
Wiring to the terminal block is as follows:
Terminal Block: POS (+) Positive 24 VDC Red Wire
Terminal Block: NEG (-) Negative Black Wire
Ground Screw: 8-32 NC Inside Enclosure Back Green Wire
Photograph No. 1 Photograph No. 2 Photograph No. 3 Photograph No. 4
Enclosure – Front Termination Board Transmitter Puck – Front Transmitter Puck – Rear
Warning: Electrical connections may induce an explosion hazard. Do not connect or
disconnect equipment unless power has been turned off and the installation area has been
rendered non-hazardous. Determine the correct polarity before connecting.
The JLT-6000 is designed for Class 1, Division 1, Groups B, C and D hazardous locations. Explosion
proof installations could have flammable vapors and liquids present. If disconnecting, instrument covers
must remain tight until power is turned off. Make sure that power is off in any junction box if exposed to
hazardous atmospheres. Power to the instrument can only be turned on after the installation is
complete, instrument covers are tight and secure, the area is non-hazardous and the installation has
been checked by the appropriate electrical engineers.

6646 Complex Drive | Baton Rouge, LA 70809 | Phone: [phone] | Toll Free: 1-800-223-8469 | [e-mail] | www.jogler.com
Page 8
JLT-6000 .IOMM.REV 001 (06.2007) WWW.JOGLER.COM PAGE 8
__________________________________________________________________________________
Installation and Operating Manual JLT-6000
__________________________________________________________________________________
5.0.0 Transmitter Configuration
5.1.0 Introduction
The JLT-6000 transmitter is factory configured to probe length, float density and positioning. The
internal parameters that are important to the basic configuration of the transmitter are protected by a
factory password and cannot be changed by the end user. The operator is provided with a user
password that will be necessary to change some of the basic transmitter settings that are fundamental
to transmitter performance.
5.2.0 Operation
Each JLT-6000 can be programmed by the three push buttons (keypad) located on the transmitter
head. They are the Up and Down arrow keys and the Select key which are used to navigate the
displays and to calibrate the transmitter. The Up and Down arrow keys move forward and backward in
the menu structure when in the scroll mode and increase and decrease the value displayed when in the
set mode. The Select key selects the set mode when on a menu screen where it is available. The
Select key also accepts a value and moves to the next step when in the set mode.
The scroll or set mode is indicated by the lack or presence of the set mode symbol in the upper right
hand corner of the screen. Screen scrolling is in ascending order of screen number when the down
arrow is depressed and descending order when the up arrow is depressed.
The JLT-6000 has an LCD display that shows two lines of eight characters each. All transmitter menu
screens are shown on the LCD display. The display defaults to the scrolling measurement screen that
shows the level height (inches or metric), percentage and milliamp outputs. The scrolling default display
can be changed to any of the individual three output values at the operator’s choice.
5.3.0 Screen Menus
5.3.1 Screen 1: Default Display
Category: Display
Description: Displays one of the following: Level in units, Level in percent, Loop
Output in milliamps, Error Messages. The Default Display is denoted
by the “*” symbol.
Notes: In the event of a transmitter error, the corresponding error message
will be displayed in place of the output. Any of the output types may be
displayed or they can be selected to scroll. This selection is made from
Screen No. 5.
5.3.2 Screen 2: Level
Category: Display
Description: Displays the absolute measurement in level units (inches or cm)
Notes: In the event of a transmitter alarm condition, ALARM will be displayed
in place of the level value.

6646 Complex Drive | Baton Rouge, LA 70809 | Phone: [phone] | Toll Free: 1-800-223-8469 | [e-mail] | www.jogler.com
Page 9
JLT-6000 .IOMM.REV 001 (06.2007) WWW.JOGLER.COM PAGE 9
__________________________________________________________________________________
Installation and Operating Manual JLT-6000
__________________________________________________________________________________
5.3.0 Screen Menus (Continued)
5.3.3 Screen 3: Level %
Category: Display
Description: Displays the value of the primary variable in percent of span. The
range is 0.00% to 100.00%
Notes: In the event of a transmitter alarm condition, ALARM will be displayed
in place of the level value.
5.3.4 Screen 4: Loop
Category: Display
Description: Displays the value of the 4-20 mA current loop in milliamps.
Notes: In the event of a transmitter alarm condition, ALARM will be displayed
in place of the level value
5.3.5 Screen 5: Dft Display
Category: User Setting
Input: Scroll, Level, Level%, Loop (scroll selectable)
Description: Selects the default screen display as either: Scroll, Level, Level % or
Loop
Notes: None
5.3.6 Screen 6: Quick Cal
Category: User Setting
Input: Select 4 mA and 20 mA points based on float position.
Description: Allows the setting of the 0% and 100% points based on the current
float position. The 0% and 100% points may be configured at either
end of the probe (i.e. provides for direct OR reverse action). If the 4.00
mA button is pressed, then the current float position is set as the 4 mA
elevation. If the 20 mA button is pressed, the current float position is
set as the 20 mA elevation. The 0 measured value of the PV is then
equated to the 0% level point by setting the value of the offset.
Notes: This function takes into account the mounting type and also checks for
reverse action settings when computing the offset value.
5.3.7 Screen 7: Units
Category: User Setting
Input: Inches, Centimeters (scroll selectable)
Description: Selects the level units in cm or inches.

6646 Complex Drive | Baton Rouge, LA 70809 | Phone: [phone] | Toll Free: 1-800-223-8469 | [e-mail] | www.jogler.com
Page 10
JLT-6000 .IOMM.REV 001 (06.2007) WWW.JOGLER.COM PAGE 10
__________________________________________________________________________________
Installation and Operating Manual JLT-6000
__________________________________________________________________________________
5.3.0 Screen Menus (Continued)
5.3.8 Screen 8: Probe Ln
Category: User Setting
Input: Length of sensor probe in inches or cm.
Description: Defines the length of the sensor probe. This is the valid range of
detection of a magnetic field along the length of the sensor probe. The
length is defined as increasing from the center point of the sensor
element.
Notes: If a signal is detected beyond the set probe length, it will be ignored.
5.3.9 Screen 9: 4 Ma Set
Category: User Setting
Input: Position of the 4 milliamp (0%) point in inches or cm.
5.3.10 Screen 10: 20 Ma Set
Category: User Setting
Input: Position of the 20 milliamp (100%) point in inches or cm.
5.3.11 Screen 11: Offset
Category: User Setting
Input: PV measurement offset in inches or cm.
Description: A positive or negative adjustment to the PV zero reference mark.
5.3.12 Screen 12: Damping
Category: User Setting
Input: Value of the damping time constant in seconds.
Description: Sets value of the damping time constant. Input range is 0-15 seconds
in 0.10 second intervals up to 1.0 second followed by 1.0 second
intervals.
5.3.13 Screen 13: Fault
Category: User Setting
Input: Low, High, Latch (scroll selectable)
Description: Determines the value of the current loop output during a fault
condition. Loop current can be set to 3.60 mA, 22.0 mA or latched to
the value of the current loop just before fault condition occurred.
Notes: If HART communication is detected, the Low value of the current loop
will be set to 3.70 mA instead of 3.60 mA to ensure reliability of
communication.
5.3.14 Screen 14: Poll Adr
Category: User Setting
Input: Integer number in the range 0 – 15.
Description: Sets poll address of the transmitter for use in HART multi-drop mode.
