DESCRIPTION
The 13 SEER Series condensing unit is the outdoor part of a
versatile system of air conditioning. It is designed to be custom-
matched with one of UPG’s complete line of evaporator sec-
tions, with each serving a specific function. Matching Air Han-
dlers are available for upflow, downflow, or horizontal
applications to provide a complete system. Electric Heaters are
available, if required. Add-on coils are available for use with
upflow, downflow, or horizontal furnaces and air handlers.
WARRANTY
1-year limited parts warranty.
5-year limited compressor warranty.
FEATURES
•QUALITY CONDENSER COILS - The coil is constructed of
aluminum microchannel tubing and enhanced aluminum fins
for increased efficiency and corrosion protection.
•PROTECTED COMPRESSOR - The compressor is inter-
nally protected against high pressure, temperature, and
externally by a factory installed high pressure switch. This is
accomplished by the simultaneous operation of high pres-
sure relief valve and a temperature sensor which protects the
compressor if undesirable operating conditions occur. A liq-
uid line filter-drier further protects the compressor.
•DURABLE FINISH - The cabinet is made of pre-painted
steel. The pre-treated galvanized steel provides a better
paint to steel bond, which resists corrosion and rust creep.
Special primer formulas and matted-textured finish insure
less fading when exposed to sunlight.
•LOWER INSTALLED COST - Installation time and costs are
reduced by easy power and control wiring connections.
Available in sweat connect models only. The unit contains
enough refrigerant for matching indoor coils and 15 feet of
interconnecting piping. The small base dimension means
less space is required on the ground or roof.
•TOP DISCHARGE - The warm air from the top mounted fan
is blown up away from the structure and any landscaping.
This allows compact location on multi-unit applications.
•LOW OPERATING SOUND LEVEL - The upward air flow
carries the normal operating noise away from the living area.
The rigid top panel effectively isolates any motor sound. Iso-
lator mounted compressor and the rippled fins of the con-
denser coil muffle the normal fan motor and compressor
operating sounds.
•LOW MAINTENANCE - Long life permanently lubricated
motor-bearings need no annual servicing.
•EASY SERVICE ACCESS - Fully exposed refrigerant con-
nections, and a single panel covering the electrical controls
make for easy servicing of the unit.
•SECURED SERVICE VALVES - Secured re-usable service
valves are provided on both the liquid and vapor sweat con-
nections for ease of evacuating and charging.
•U.L. and C.U.L. listed - approved for outdoor application.
•Agency Listed -U.L. and C.U.L. listed - approved for out-
door application. The unit is certified in accordance with the
Unitary Small Equipment certification program, which is
based on ARI Standard 210/240.

415571-UTG-C-0309
2Johnson Controls Unitary Products
All dimensions are in inches. They are subject to change with-
out notice. Certified dimensions will be provided upon request.
Physical and Electrical Data
MODEL TCGD30
S43S1 TCGD36 S43S1 TCGD42 S43S1 TCGD48 S43S1 TCGD60 S43S1 TCGD30 S44S1 TCGD36 S44S1 TCGD42 S44S1 TCGD48 S44S1 TCGD60 S44S1
Unit Supply Voltage 208-230V, 3 60Hz 460V, 3 60Hz
Normal Voltage Range 1187 to 252 432 to 532
Minimum Circuit Ampacity 11.4 12.3 16.3 15.5 23.9 9.4 7.1 8.0 7.9 13.5
Max. Overcurrent Device Amps 215 20 25 25 40 15 15 15 15 20
Min. Overcurrent Device Amps 315 15 20 20 25 15 15 15 15 15
Compressor Type Recip Recip Recip Recip Scroll Recip Recip Recip Recip Scroll
Compressor Amps Rated Load 8.1 8.6 11.8 11.2 17.9 6.6 4.5 5.2 5.1 9.6
Locked Rotor 63 68 88 88 120 30 34 44 44 70
Crankcase Heater No No No No No No No No No No
Fan Motor Amps Rated Load 1.2 1.5 1.5 1.5 1.5 1.2 1.5 1.5 1.5 1.5
Fan Diameter Inches 17.5 22 22 22 22 17.5 22 22 22 22
Fan Motor Rated HP 1/4 1/4 1/4 1/4 1/4 1/4 1/4 1/4 1/4 1/4 Nominal RPM 1100 850 850 850 850 1100 850 850 850 850
Nominal CFM 2050 3200 2950 2950 3600 2050 3200 2950 2950 3600
Coil Face Area Sq. Ft. 9.6 13.07 14.16 14.16 18.68 9.6 13.07 14.16 14.16 18.68 Rows Deep 1 1 1 1 1 1 1 1 1 1
Fin / Inches 23 23 23 23 23 23 23 23 23 23
Liquid Line Set OD (Field Installed) 3/8 3/8 3/8 3/8 3/8 3/8 3/8 3/8 3/8 3/8
Vapor Line Set OD (Field Installed) 3/4 3/4 7/8 7/8 7/8 3/4 3/4 7/8 7/8 7/8
Unit Charge (Lbs. - Oz.) 43 - 14 4 - 9 4 - 5 4 - 9 5 - 6 3 - 14 4 - 9 4 - 5 4 - 9 5 - 6
Charge Per Foot, Oz. 0.62 0.62 0.67 0.67 0.67 0.62 0.62 0.67 0.67 0.67
Operating Weight Lbs. 131 145 173 173 195 131 145 173 173 195
1. Rated in accordance with ARI Standard 110, utilization range “A”.
2. Dual element fuses or HACR circuit breaker. Maximum allowable overcurrent protection.
3. Dual element fuses or HACR circuit breaker. Minimum recommended overcurrent protection.
4. The Unit Charge is correct for the outdoor unit, matched indoor coil and 15 feet of refrigerant tubing. For tubing lengths other than 15 feet, add or
subtract the amount of refrigerant, using the difference in length multiplied by the per foot value. If line exceeds 25 feet, you may refer to publications
software 036-68001-001 for proper line sizing.
B
A
C
Unit
Model
Dimensions
(Inches) Refrigerant Connection Service Valve Size
A1
1. Including Fan Guard.
B C Liquid Vapor
30 28 23-1/2 23-1/2
3/8”
3/4”
36 28 29 29
42 30 29 29 7/8”48 30 29 29
60 32 33-5/8 33-5/8

415571-UTG-C-0309
Johnson Controls Unitary Products 3
PROCEDURES:
1. Unit factory charge listed on the unit nameplate includes refrigerant for the condenser, the smallest evaporator and 15 feet of interconnecting
line tubing.
2. Verify the TXV and additional charge required for specific evaporator coil in the system using the above table.
3. Additional charge for the amount of interconnecting line tubing greater than 15 feet at the rate specified in Physical and Electrical Data Table.
4. For orifice or TXV matches requiring additional charge, the refrigerant needs to be weighed in for specific coil match and lineset length.
5. Permanently mark the unit nameplate with the total system charge. Total System Charge = Base Charge (as shipped) + adder for evaporator +
adder for line set.
System Charge for Various Matched Systems
Outdoor Unit TCGD30S4(3,4)S1 TCGD36S4(3,4)S1 TCGD42S4(3,4)S1 TCGD48S4(3,4)S1 TCGD60S4(3,4)S1
Required Orifice or TXV 1,2 0.061/4F1 0.065/4G1 0.075/4G1 0.073/4H1 0.087/4J1
Factory Charge, lbs-oz 3 - 14 4 - 9 4 - 5 4 - 9 5 - 6
Indoor Coil3,4 Additional Charge, oz
AHP30 0––––
AHP36 20–––
AHP42 –00––
AHP/SHP60 –––00
AHX30 0––––
AHX36 20–––
AHX42 –82––
AHX48 –––0–
AHX60 ––––4
F4FP024 –––––
F4FP036 –––––
F4FP040 0––––
F5FP048 –824–
F5FP060 –––00
F6FP030 0––––
F6FP036 0––––
F6FP042 –82––
F6FP048 – – TXV + 2 0 –
F6FP060 ––––4
FC/MC/PC32 0––––
FC/MC/PC35 0––––
FC/MC/PC37 20–––
FC/MC/PC43 200––
FC/MC/PC48 –824–
FC/MC/PC60 –––00
FC/MC62 ––––4
HC36 0––––
HC42 200––
HC60 ––––0
UC48 –824–
UC60 –––00
FOOTNOTES:
1. For applications requiring a TXV use 1TVM series kit.
2. Approved orifice shipped with outdoor unit.
3. Systems matched with furnace or air handlers not equipped with blower-off delays may require blower Time Delay Kit 2FD06700224.
4. PC coils cannot be used in downflow or horizontal applications. FC coils cannot be used in horizontal applications.

415571-UTG-C-0309
4Johnson Controls Unitary Products
— = Not applicable.
COOLING CAPACITY - With Air Handler Coils
UNIT
MODEL
AIR HANDLER COIL
MODEL1
COOLING
MODEL W RATED
CFM NET MBH SEER EER
TOTAL SENS.
13 SEER AC WITH MA
TCGD30S4(3,4)S1 MA12B 17 FC/MC35B 1000 29.0 21.0 13.00 11.00
MA12B 17 FC/MC43B 1000 29.0 21.0 13.00 11.00
TCGD36S4(3,4)S1 MA12B 17 FC/MC43B 1200 35.0 24.8 13.00 11.00
MA14D 24 FC/MC48D 1200 35.0 24.8 13.00 11.00
TCGD42S4(3,4)S1 MA16C 21 FC/MC43C 1400 42.0 29.2 13.00 11.00 MA14D 24 FC/MC48D 1400 42.0 29.2 13.00 11.00
MA16C 21 FC/MC48C 1400 42.0 29.2 13.00 11.00
TCGD48S4(3,4)S1
MA16C 21 FC/MC48C 1600 48.0 34.4 13.00 11.00
MA20D 24 FC/MC48D 1600 48.0 34.4 13.00 11.00
MA16C 21 FC60C 1600 48.0 34.4 13.00 11.00
MA20D 24 FC/MC60D 1600 48.0 34.4 13.00 11.00
TCGD60S4(3,4)S1 MA20D 24 FC/MC60D 1800 57.0 38.5 13.00 11.00
MA20D 24 FC/MC62D 1800 57.0 38.5 13.00 11.00
13 SEER AC WITH AHP / SHP / AHX / F*FP
TCGD30S4(3,4)S1
AHP30 17 – 1015 29.0 21.0 13.00 11.00
AHP36 21 – 1040 29.0 21.0 13.00 11.00
AHX30 17 - 1025 29.4 22.2 14.00 11.75
AHX36 21 - 1005 30.0 22.3 14.50 12.00
F4FP040 18 – 1050 29.0 21.0 13.00 11.00
F6FP030 17 - 1035 29.2 21.6 13.50 11.40
F6FP036 21 - 980 29.4 21.4 14.00 12.00
TCGD36S4(3,4)S1
AHP36 21 – 1235 35.0 24.8 13.00 11.00
AHP42 21 – 1255 35.0 24.8 13.00 11.00
AHX36 21 - 1225 35.2 25.0 13.50 11.50
AHX42 21 - 1190 35.4 25.2 14.00 11.80
F5FP048 24 – 1235 35.0 24.8 13.00 11.00
F6FP042 21 - 1290 35.8 25.8 13.50 11.50
TCGD42S4(3,4)S1
AHP42 21 – 1485 41.0 29.2 13.00 11.00
AHX42 21 - 1395 42.0 29.9 14.50 12.00
F5FP048 24 – 1455 41.0 29.2 13.00 11.00
F6FP042 21 - 1455 42.0 30.1 14.00 11.75
F6FP048 24 - 1380 41.5 29.4 13.50 11.70
TCGD48S4(3,4)S1
AHP/SHP48 24 – 1675 48.0 34.4 13.00 11.00
AHP/SHP60 24 – 1600 48.0 35.0 13.50 11.00
AHX48 24 - 1660 48.0 35.4 13.50 11.50
F5FP048 24 – 1600 48.0 34.4 13.00 11.00
F5FP060 24 – 1600 48.0 34.4 13.00 11.00
F6FP048 24 - 1625 47.0 34.8 13.00 11.30
TCGD60S4(3,4)S1
AHP/SHP60 24 – 1850 57.0 38.5 13.00 11.00
AHX60 24 - 1905 58.5 40.0 13.50 11.50
F5FP060 24 – 1900 57.0 38.5 13.00 11.00
F6FP060 24 - 1710 57.5 39.0 13.50 11.50
Rated in accordance with DOE test procedures (Federal Register 12-27-79 and 3-18-88) and ARI Standards 210.
Cooling MBH based on 8°F entering air temperature, 50% RH, and rated air flow.
EER (Energy Efficiency Ratio) is the total cooling output in BTU’s at 95°F outdoor ambient divided by the total electric power in watt-hours at those conditions.
SEER (Seasonal Energy Efficiency Ratio) is the total cooling output in BTU’s during a normal annual usage period for cooling divided by the total electric power
input in watt-hours during the same period.
1. MC coils available with a factory installed horizontal drain pan. See price pages for specific model number.

415571-UTG-C-0309
Johnson Controls Unitary Products 5
COOLING CAPACITY - Upflow, Downflow & Horizontal Furnaces and Coils
UNIT MODEL FURNACE** COIL
MODEL
COOLING
CFM RANGE
(Min.-max.) WRATED CFM NET MBH SEER1EER
TOTAL SENS.
TCGD30S4(3,4)S1
800 - 1200 14 FC/MC/PC32 1000 29.0 21.0 13.00 11.00
800 - 1200 17,21 FC/MC/PC35 1000 29.0 21.0 13.00 11.00
800 - 1200 14 FC/MC/PC37 1000 29.0 21.0 13.00 11.00
800 - 1200 17,21 FC/MC/PC43 1000 29.0 21.0 13.00 11.00
800 - 1200 17 HC36 1000 29.0 21.0 13.00 11.00
800 - 1200 21 HC42 1000 29.0 21.0 13.00 11.00
TCGD36S4(3,4)S1
1000 - 1400 14 FC/MC/PC37 1200 35.0 24.8 13.00 11.00
1000 - 1400 17,21 FC/MC/PC43 1200 35.0 24.8 13.00 11.00
1000 - 1400 21,24 FC/MC/PC48 1200 35.0 24.8 13.00 11.00
1000 - 1400 21 HC42 1200 35.0 24.8 13.00 11.00
1000 - 1400 21,24 UC48 1200 35.0 24.8 13.00 11.00
TCGD42S4(3,4)S1
1200 - 1600 17,21 FC/MC/PC43 1400 42.0 29.2 13.00 11.00
1200 - 1600 21,24 FC/MC/PC48 1400 42.0 29.2 13.00 11.00
1200 - 1600 21 HC42 1400 42.0 29.2 13.00 11.00
1200 - 1600 21,24 UC48 1400 42.0 29.2 13.00 11.00
TCGD48S4(3,4)S1
1400 - 1800 21,24 FC/MC/PC48 1600 48.0 34.4 13.00 11.00
1400 - 1800 21,24 FC/MC/PC60 1600 48.0 34.4 13.00 11.00
1400 - 1800 24 HC60 1600 48.0 34.4 13.00 11.00
1400 - 1800 21,24 UC48 1600 48.0 34.4 13.00 11.00
1400 - 1800 21,24 UC60 1600 48.0 34.4 13.00 11.00
TCGD60S4(3,4)S1
1600 - 2000 21,24 FC/MC/PC60 1800 57.0 38.5 13.00 11.00
1600 - 2000 24 FC/MC62 1800 57.0 38.5 13.00 11.00
1600 - 2000 24 HC60 1800 57.0 38.5 13.00 11.00
1600 - 2000 21,24 UC60 1800 57.0 38.5 13.00 11.00
1. Requires a 2FD06700224 Blower Time Delay unless a standard furnace is equipped with one.
** Refer to Quick Selection Chart for specific furnace match-up.

415571-UTG-C-0309
6Johnson Controls Unitary Products
COOLING CAPACITY - With High Efficiency Motor Furnaces
UNIT
MODEL FURNACE MODEL COIL MODEL1WCOOLING
RATED
CFM Net MBH SEER EER
TOTAL SENS.
13 SEER HP WITH VARIABLE SPEED FURNACES2
TCGD30S4(3,4)S1
T*(8,L)X*A12 FC/MC/PC32A 14 970 29.2 21.4 13.20 11.00
T*(8,L)X*B12 FC/MC/PC35B 17 1120 30.0 22.8 14.00 11.50
T*(8,L)X*C16 FC/MC/PC35C 21 1105 30.0 22.8 14.00 12.00
T*(8,L)X*C20 FC/MC/PC35C 21 850 28.8 20.6 14.00 12.00
T*9X*B12 FC/MC/PC35B 17 1085 29.8 22.8 14.00 12.00
T*9X*C16 FC/MC/PC35C 21 1075 29.8 22.4 14.00 12.00
T*(8,L)X*A12 FC/MC/PC37A 14 1105 30.0 22.9 13.80 11.50
T*(8,L)X*B12 FC/MC/PC43B 17 1125 30.0 22.9 14.00 12.00
T*(8,L)X*C16 FC/MC/PC43C 21 710 28.2 19.3 14.00 12.00
T*(8,L)X*C20 FC/MC/PC43C 21 870 29.6 21.2 14.00 12.00
T*9X*B12 FC/MC/PC43B 17 1095 30.0 22.9 13.80 11.50
T*9X*C16 FC/MC/PC43C 21 1055 30.0 22.9 14.00 12.00
T*9X*C20 FC/MC/PC43C 21 720 28.2 19.3 14.00 12.00
TCGD36S4(3,4)S1
T*(8,L)X*A12 FC/MC/PC37A 14 1290 35.2 25.4 13.30 11.25
T*(8,L)X*B12 FC/MC/PC43B 17 1300 35.2 25.4 13.30 11.25
T*(8,L)X*C16 FC/MC/PC43C 21 1175 35.2 24.8 14.00 11.50
T*(8,L)X*C20 FC/MC/PC43C 21 1250 35.6 25.6 13.80 11.70
T*9X*B12 FC/MC/PC43B 17 1270 35.2 25.4 13.25 11.25
T*9X*C16 FC/MC/PC43C 21 1260 35.4 25.4 13.45 11.40
T*9X*C20 FC/MC/PC43C 21 1185 35.0 24.6 13.55 11.40
T*(8,L)X*C16 FC/MC/PC48C 21 1185 35.6 25.2 14.00 11.50
T*(8,L)X*C20 FC/MC/PC48C 21 1270 35.8 25.8 14.00 11.50
T*9X*C16 FC/MC/PC48C 21 1280 35.8 25.8 13.70 11.50
T*9X*C20 FC/MC/PC48C 21 1205 35.4 25.0 13.70 11.50
T*9X*D20 FC/MC/PC48D 24 1240 35.4 25.0 13.70 11.50
T*(8,L)X*C16 UC48C 21 1185 34.2 24.8 13.50 11.50
T*(8,L)X*C20 UC48C 21 1300 34.8 25.4 13.50 11.50
T*9X*C16 UC48C 21 1280 34.6 24.8 13.15 11.20
T*9X*C20 UC48C 21 1205 34.0 24.6 13.25 11.20
T*9X*D20 UC48D 24 1240 34.0 24.6 13.30 11.25
TCGD42S4(3,4)S1
T*(8,L)X*B12 FC/MC/PC43B 17 1300 42.0 29.0 13.50 11.50
T*(8,L)X*C16 FC/MC/PC43C 21 1475 42.0 29.9 13.50 11.50
T*(8,L)X*C20 FC/MC/PC43C 21 1415 42.0 29.5 13.50 11.50
T*9X*B12 FC/MC/PC43B 17 1270 42.0 29.0 13.50 11.50
T*9X*C16 FC/MC/PC43C 21 1410 42.0 29.6 13.30 11.00
T*9X*C20 FC/MC/PC43C 21 1400 42.0 29.6 13.50 11.00
T*(8,L)X*C16 FC/MC/PC48C 21 1360 42.0 29.5 13.80 11.50
T*(8,L)X*C20 FC/MC/PC48C 21 1475 42.0 30.1 14.00 11.50
T*9X*C16 FC/MC/PC48C 21 1425 42.0 29.3 13.50 11.50
T*9X*C20 FC/MC/PC48C 21 1420 42.0 29.3 13.50 11.50
T*9X*D20 FC/MC/PC48D 24 1435 42.0 29.7 13.50 11.50
T*(8,L)X*C16 UC48C 21 1400 42.0 29.4 13.50 11.00
T*(8,L)X*C20 UC48C 21 1515 42.0 30.0 13.50 11.00
T*9X*C16 UC48C 21 1425 41.5 29.2 13.30 11.00
T*9X*C20 UC48C 21 1420 42.0 29.4 13.20 11.00
T*9X*D20 UC48D 24 1435 42.0 29.4 13.40 11.00
For Notes See Page 7.

415571-UTG-C-0309
Johnson Controls Unitary Products 7
TCGD48S4(3,4)S1
T*(8,L)X*C16 FC/MC/PC48C 21 1600 48.0 34.4 13.30 11.00
T*(8,L)X*C20 FC/MC/PC48C 21 1660 48.0 34.4 13.20 11.00
T*9X*C16 FC/MC/PC48C 21 1565 48.0 34.8 13.10 11.00
T*9X*C20 FC/MC/PC48C 21 1615 48.0 34.4 13.20 11.00
T*9X*D20 FC/MC/PC48D 24 1635 48.0 34.8 13.20 11.00
T*(8,L)X*C16 FC/PC60C 21 1605 48.0 34.6 13.30 11.00
T*(8,L)X*C20 FC/MC/PC60D 21 1595 48.0 34.8 13.30 11.00
T*9X*C16 FC/PC60C 21 1575 48.0 34.6 13.30 11.00
T*9X*C20 FC/PC60C 21 1625 47.0 34.6 13.40 11.00
T*9X*D20 FC/MC/PC60D 24 1490 47.5 33.8 13.20 11.00
T*9X*C16 FC/PC60C 21 1575 47.0 33.8 13.10 11.00
T*9X*C20 FC/PC60C 21 1625 47.0 33.8 13.10 11.00
TCGD60S4(3,4)S1
T*(8,L)X*C16 FC/PC60C 21 1605 56.5 37.8 13.50 11.00
T*(8,L)X*C20 FC/MC/PC60D 21 1690 57.0 37.8 13.50 11.00
T*9X*C16 FC/PC60C 21 1575 56.0 37.8 13.30 11.00
T*9X*C20 FC/PC60C 21 1560 56.0 37.8 13.30 11.00
T*9X*D20 FC/MC/PC60D 24 1630 56.5 37.8 13.30 11.00
T*9X*C20 FC/MC/PC60D 21 1645 56.5 37.8 13.30 11.00
T*(8,L)X*C20 FC/MC62D 21 1665 57.0 37.8 13.50 11.00
T*(8,L)X*C16 UC60C 21 1640 56.0 37.2 13.00 11.00
T*(8,L)X*C20 UC60D 21 1735 56.5 38.5 13.00 11.00
T*9X*C16 FC/PC60C 21 1575 56.0 37.2 13.00 11.00
T*9X*C20 FC/PC60C 21 1560 56.0 37.2 13.00 11.00
T*9X*D20 UC60D 24 1630 56.0 37.2 13.00 11.00
T*(8,L)X*C20 UC60D 21 1735 56.5 38.5 13.00 11.00
T*9X*C20 UC60D 21 1645 56.0 37.2 13.00 11.00
1. MC coils available with a factory installed horizontal drain pan. See price pages for specific model number.
2. Variable speed furnaces have B.O.D (Blower on Delay) standard.
COOLING CAPACITY - With High Efficiency Motor Furnaces (Continued)
UNIT
MODEL FURNACE MODEL COIL MODEL1WCOOLING
RATED
CFM Net MBH SEER EER
TOTAL SENS.
13 SEER HP WITH VARIABLE SPEED FURNACES2

415571-UTG-C-0309
8Johnson Controls Unitary Products
ACCESSORIES
Refer to Price Manual for specific model numbers.
OFF CYCLE TIMER DELAY - Provides a 5-minute off cycle to
prevent rapid recycling of the compressor.
ROOM THERMOSTATS - A wide selection of compatible ther-
mosets are available to provide optimum performance and fea-
tures for any installation.
1H/1C, manual changeover electronic non-programmable ther-
mostat.
1H/1C, auto/manual changeover, electronic programmable,
deluxe 7-day, thermostat.
1H/1C, auto/manual changeover, electronic programmable.
* For the most current accessory information, refer to the price
book or consult factory.
SOUND POWER RATINGS*
* Rated in accordance with ARI 270-95 Standards.
TYPICAL INSTALLATION
TYPICAL FIELD WIRING
UNIT
MODEL (dBA)
230V 460V
30 76 76
36 76 76
42 77 76
48 77 77
60 78 78
THERMOSTAT
SEAL OPENING(S) WITH
PERMAGUM OR EQUIVALENT
TO INDOOR COIL
TO FURNACE OR
AIR HANDLER
TERMINAL BLOCK
NEC CLASS 2 WIRING
NEC CLASS 1 WIRING
ALL OUTDOOR WIRING
MUST BE WEATHERPROOF. CONTROL
ACCESS
PANEL
WEATHERPROOF
DISCONNECT
SWITCH
MINIMUM 18” SERVICE
ACCESS CLEARANCE
ON ONE SIDE
60” OVERHEAD
CLEARANCE
6” CLEARANCE
AROUND PERIMETER
NOTE:
ALL FIELD WIRING TO BE IN ACCORDANCE WITH ELECTRIC CODE (NEC) AND/OR LOCAL CODES
POWER WIRING
CONTACTOR
TERMINALS
COIL
GND.
LUG
CYRGW
YRGW
POWER WIRING
CONTROL WIRING
FACTORY WIRING
24 VOLT CONTROL WIRING
MINIMUM 18 GA. WIRE
(NEC CLASS 2) FURNACE OR AIR HANDLER TERMINAL BLOCK
ROOM THERMOSTAT
CONDENSING UNIT
ALL OUTDOOR WIRING MUST BE WEATHERPROOF. USE COPPER CONDUCTORS ONLY.
TERMINAL W IS ONLY
REQUIRED ON SYSTEMS
WITH HEAT.
*
*

415571-UTG-C-0309
Johnson Controls Unitary Products 9
Multipliers for determining the performance with other indoor sections.
NOTE: For dry bulb temperatures different than those listed (between 73-87 F), sensible capacity increases by 1060 BTUH per 1000 CFM per degree above the listed
temperature and decreases by 1060 BTUH per 1000 CFM per degree below the listed temperature.
COOLING PERFORMANCE DATA
AIR CONDITIONER MODEL NO. TGCGD30S4(3,4)S1
INDOOR COIL MODEL NO. FC/MC/PC35
CONDENSING
ENTERING AIR
TEMPERATURE
IDCFM 800 1000 1200
ID DB (°F) 80 80 75 80 80 80 80 75 80 80 80 80 75 80 80
ID WB (°F) 57 62 62 67 72 57 62 62 67 72 57 62 62 67 72
65 T.C. 28.4 31.4 30.8 33.1 34.4 29.8 31.8 31.4 33.4 34.5 31.2 32.3 32.1 33.7 34.7 S.C. 28.8 25.8 21.7 21.2 16.0 30.4 28.2 23.6 22.6 17.1 31.9 30.7 25.4 24.0 18.1
KW 1.7 1.7 1.7 1.7 1.7 1.7 1.7 1.7 1.7 1.7 1.7 1.7 1.7 1.7 1.7
75 T.C. 26.4 28.8 28.2 30.9 32.6 27.9 29.7 28.9 31.4 32.8 29.5 30.5 29.6 31.8 32.9 S.C. 26.9 24.7 20.5 20.3 15.4 28.5 27.1 22.6 22.0 16.4 30.2 29.5 24.6 23.7 17.5
KW 1.8 1.8 1.8 1.9 1.9 1.8 1.8 1.8 1.9 1.9 1.9 1.9 1.9 1.9 1.9
85 T.C. 24.4 26.3 25.6 28.8 30.9 26.0 27.5 26.4 29.3 31.0 27.7 28.7 27.1 29.8 31.2 S.C. 24.9 23.6 19.4 19.4 14.7 26.6 26.0 21.6 21.4 15.8 28.4 28.4 23.9 23.4 16.8
KW 2.0 2.0 2.0 2.0 2.1 2.0 2.0 2.0 2.0 2.1 2.0 2.0 2.0 2.1 2.1
95 T.C. 22.4 23.8 23.0 26.7 29.1 24.2 25.3 23.8 29.0 29.3 26.0 26.9 24.7 27.9 29.4 S.C. 22.9 22.5 18.2 18.5 14.1 24.8 24.9 20.7 21.2 15.1 26.7 27.3 23.1 23.1 16.2
KW 2.1 2.1 2.1 2.2 2.3 2.2 2.2 2.2 2.2 2.3 2.2 2.2 2.2 2.2 2.3
105 T.C. 20.5 21.8 20.4 23.7 26.3 22.0 23.1 21.3 24.3 26.4 23.6 24.5 22.1 24.8 26.4 S.C. 21.0 20.7 17.1 17.4 13.2 22.6 22.7 19.1 19.7 14.3 24.3 24.7 21.0 22.0 15.4
KW 2.3 2.3 2.3 2.4 2.4 2.4 2.4 2.3 2.4 2.5 2.4 2.4 2.3 2.4 2.5
115 T.C. 18.6 19.8 17.9 20.9 23.5 19.9 21.0 18.8 21.4 23.5 21.2 22.2 19.6 21.8 23.6 S.C. 19.1 18.9 15.9 16.4 12.3 20.5 20.5 17.5 18.6 13.5 22.0 22.2 19.1 20.9 14.7
KW 2.5 2.5 2.4 2.5 2.6 2.5 2.5 2.5 2.5 2.6 2.6 2.6 2.5 2.6 2.6
125 T.C. 16.8 17.9 15.4 18.1 20.7 17.8 18.9 16.2 18.5 20.7 18.9 19.9 17.1 18.8 20.7 S.C. 17.3 17.2 14.8 15.3 11.4 18.4 18.4 16.0 17.6 12.6 19.6 19.6 17.1 19.8 13.9
KW 2.7 2.7 2.6 2.7 2.8 2.7 2.7 2.6 2.7 2.8 2.7 2.7 2.7 2.7 2.8
NOTE: ALL CAPACITIES INCLUDE INDOOR FAN HEAT AT 1250 BTUH/1000 CFM.
Air Handlers Coils T.C. S.C. KW
– FC/MC/PC35 1.00 1.00 1.00
– FC/MC/PC37 1.00 1.00 1.00
– FC/MC/PC43 1.00 1.00 1.00
– HC36 1.00 1.00 1.00
– HC42 1.00 1.00 1.00
AHP30 – 1.00 1.00 1.00
AHP36 – 1.00 1.00 1.00
AHX30 – 1.01 1.06 0.95
AHX36 – 1.03 1.06 0.95
MA12B FC/MC35B 1.00 1.00 1.00
MA12B FC/MC43B 1.00 1.00 1.00
F4FP040 – 1.00 1.00 1.00
F6FP030 – 1.01 1.03 0.97
F6FP036 – 1.01 1.02 0.93
Furnaces Coils T.C. S.C. KW
T*(8,L)X*A12 FC/MC/PC32A 1.01 1.02 1.01
T*(8,L)X*B12 FC/MC/PC35B 1.03 1.09 0.99
T*(8,L)X*C16 FC/MC/PC35C 1.03 1.09 0.95
T*(8,L)X*C20 FC/MC/PC35C 0.99 0.98 0.91
T*9X*B12 FC/MC/PC35B 1.03 1.09 0.94
T*9X*C16 FC/MC/PC35C 1.03 1.07 0.94
T*(8,L)X*A12 FC/MC/PC37A 1.03 1.09 0.99
T*(8,L)X*B12 FC/MC/PC43B 1.03 1.09 0.95
T*(8,L)X*C16 FC/MC/PC43C 0.97 0.92 0.89
T*(8,L)X*C20 FC/MC/PC43C 1.02 1.01 0.94
T*9X*B12 FC/MC/PC43B 1.03 1.09 0.99
T*9X*C16 FC/MC/PC43C 1.03 1.09 0.95
T*9X*C20 FC/MC/PC43C 0.97 0.92 0.89

415571-UTG-C-0309
10 Johnson Controls Unitary Products
Multipliers for determining the performance with other indoor sections.
NOTE: For dry bulb temperatures different than those listed (between 73-87 F), sensible capacity increases by 1060 BTUH per 1000 CFM per degree above the listed
temperature and decreases by 1060 BTUH per 1000 CFM per degree below the listed temperature.
COOLING PERFORMANCE DATA
AIR CONDITIONER MODEL NO. TCGD36S4(3,4)S1
INDOOR COIL MODEL NO. FC/MC/PC43
CONDENSING
ENTERING AIR
TEMPERATURE
IDCFM 1000 1200 1400
ID DB (°F) 80 80 75 80 80 80 80 75 80 80 80 80 75 80 80
ID WB (°F) 57 62 62 67 72 57 62 62 67 72 57 62 62 67 72
65 T.C. 34.7 36.1 35.2 37.4 37.3 33.8 35.5 34.8 37.0 37.5 32.9 34.9 34.4 36.6 37.6 S.C. 34.3 33.0 27.6 25.5 18.4 33.3 31.0 26.2 24.6 18.0 32.3 29.1 24.7 23.6 17.7
KW 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 1.9 2.0 1.9 2.0 2.0
75 T.C. 33.6 34.7 33.6 35.9 36.6 32.6 33.9 33.2 35.5 36.6 31.5 33.2 32.7 35.1 36.6 S.C. 33.3 32.5 27.5 25.6 18.6 32.1 30.6 25.8 24.5 18.0 31.0 28.7 24.2 23.3 17.5
KW 2.2 2.2 2.2 2.2 2.2 2.2 2.2 2.2 2.2 2.2 2.1 2.2 2.2 2.2 2.2
85 T.C. 32.4 33.2 32.0 34.4 35.8 31.3 32.3 31.5 34.1 35.7 30.2 31.5 31.0 33.7 35.5 S.C. 32.2 32.0 27.3 25.8 18.8 30.9 30.2 25.5 24.3 18.0 29.6 28.3 23.7 22.9 17.3
KW 2.4 2.4 2.4 2.4 2.4 2.4 2.4 2.4 2.4 2.4 2.3 2.4 2.4 2.4 2.4
95 T.C. 31.3 31.7 30.4 33.0 35.0 30.1 30.7 29.9 35.0 34.8 28.9 29.8 29.4 32.2 34.5 S.C. 31.1 31.5 27.2 26.0 19.0 29.7 29.7 25.2 24.9 18.0 28.3 27.9 23.2 22.5 17.1
KW 2.6 2.6 2.6 2.6 2.7 2.6 2.6 2.6 2.6 2.7 2.5 2.6 2.6 2.6 2.6
105 T.C. 27.9 28.8 27.2 29.8 32.5 27.0 27.8 26.6 29.4 32.2 26.0 26.9 25.9 29.0 31.9 S.C. 28.7 28.9 25.0 25.0 18.4 27.3 27.2 23.2 23.2 17.3 25.8 25.6 21.5 21.4 16.2
KW 2.8 2.8 2.8 2.8 2.9 2.8 2.8 2.8 2.8 2.9 2.7 2.8 2.7 2.8 2.9
115 T.C. 24.6 26.0 24.2 26.8 30.1 23.9 25.1 23.4 26.3 29.8 23.3 24.1 22.6 25.9 29.5 S.C. 26.3 26.3 22.8 24.1 17.8 24.9 24.8 21.3 22.2 16.6 23.5 23.3 19.8 20.3 15.4
KW 3.0 3.0 3.0 3.0 3.1 3.0 3.0 2.9 3.0 3.1 2.9 2.9 2.9 3.0 3.1
125 T.C. 21.3 23.2 21.1 23.7 27.6 20.9 22.3 20.2 23.2 27.3 20.5 21.3 19.3 22.7 27.0 S.C. 23.9 23.8 20.6 23.2 17.2 22.5 22.4 19.4 21.2 15.9 21.1 21.0 18.2 19.2 14.6
KW 3.2 3.2 3.2 3.2 3.4 3.2 3.2 3.1 3.2 3.3 3.1 3.1 3.1 3.2 3.3
NOTE: ALL CAPACITIES INCLUDE INDOOR FAN HEAT AT 1250 BTUH/1000 CFM.
Air Handlers Coils T.C. S.C. KW
– FC/MC/PC43 1.00 1.00 1.00
– FC/MC/PC48 1.00 1.00 1.00
– HC42 1.00 1.00 1.00
– UC48 1.00 1.00 1.00
AHP36 – 1.00 1.00 1.00
AHP42 – 1.00 1.00 1.00
AHX36 – 1.01 1.01 0.96
AHX42 – 1.01 1.02 0.94
MA12B FC/MC43B 1.00 1.00 1.00
MA14D FC/MC48D 1.00 1.00 1.00
F5FP048 – 1.00 1.00 1.00
F6FP042 – 1.02 1.04 0.98
Furnaces Coils T.C. S.C. KW
T*(8,L)X*A12 FC/MC/PC37A 1.01 1.02 0.98
T*(8,L)X*B12 FC/MC/PC43B 1.01 1.02 0.98
T*(8,L)X*C16 FC/MC/PC43C 1.01 1.00 0.96
T*(8,L)X*C20 FC/MC/PC43C 1.02 1.03 0.96
T*9X*B12 FC/MC/PC43B 1.01 1.02 0.98
T*9X*C16 FC/MC/PC43C 1.01 1.02 0.98
T*9X*C20 FC/MC/PC43C 1.00 0.99 0.96
T*(8,L)X*C16 FC/MC/PC48C 1.02 1.02 0.97
T*(8,L)X*C20 FC/MC/PC48C 1.02 1.04 0.98
T*9X*C16 FC/MC/PC48C 1.02 1.04 0.98
T*9X*C20 FC/MC/PC48C 1.01 1.01 0.97
T*9X*D20 FC/MC/PC48D 1.01 1.01 0.97
T*(8,L)X*C16 UC48C 0.98 1.00 0.93
T*(8,L)X*C20 UC48C 0.99 1.02 0.95
T*9X*C16 UC48C 0.99 1.00 0.97
T*9X*C20 UC48C 0.97 0.99 0.95
T*9X*D20 UC48D 0.97 0.99 0.95

415571-UTG-C-0309
Johnson Controls Unitary Products 11
Multipliers for determining the performance with other indoor sections.
NOTE: For dry bulb temperatures different than those listed (between 73-87 F), sensible capacity increases by 1060 BTUH per 1000 CFM per degree above the listed
temperature and decreases by 1060 BTUH per 1000 CFM per degree below the listed temperature.
COOLING PERFORMANCE DATA
AIR CONDITIONER MODEL NO. TCGD42S4(3,4)S1
INDOOR COIL MODEL NO. FC/MC/PC43
CONDENSING
ENTERING AIR
TEMPERATURE
IDCFM 1200 1400 1600
ID DB (°F) 80 80 75 80 80 80 80 75 80 80 80 80 75 80 80
ID WB (°F) 57 62 62 67 72 57 62 62 67 72 57 62 62 67 72
65 T.C. 44.4 45.5 43.6 47.0 48.5 45.9 46.5 45.0 48.5 49.8 47.5 47.5 46.5 50.1 51.1 S.C. 41.5 35.6 29.7 28.7 21.5 42.9 37.5 31.4 30.2 22.9 44.4 39.4 33.2 31.7 24.3
KW 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.6 2.5 2.5 2.5 2.5 2.6
75 T.C. 42.3 42.9 41.2 45.1 46.6 44.2 44.3 42.7 46.6 47.9 46.0 45.7 44.2 48.1 49.1 S.C. 39.4 35.2 29.2 28.5 21.3 41.1 37.4 31.1 30.1 22.4 42.9 39.7 33.0 31.8 23.6
KW 2.7 2.7 2.7 2.8 2.8 2.7 2.7 2.7 2.8 2.8 2.8 2.8 2.8 2.8 2.9
85 T.C. 40.2 40.3 38.9 43.3 44.6 42.4 42.1 40.4 44.7 45.9 44.6 43.9 41.9 46.0 47.2 S.C. 37.2 34.7 28.7 28.2 21.2 39.3 37.3 30.8 30.0 22.0 41.5 40.0 32.9 31.8 22.9
KW 3.0 3.0 3.0 3.0 3.1 3.0 3.0 3.0 3.1 3.1 3.0 3.0 3.0 3.1 3.1
95 T.C. 38.2 37.7 36.5 41.5 42.7 40.7 39.9 38.0 42.0 44.0 43.2 42.1 39.6 43.9 45.3 S.C. 35.0 34.3 28.1 28.0 21.0 37.5 37.3 30.5 29.4 21.6 40.0 40.3 32.8 31.9 22.2
KW 3.2 3.2 3.2 3.3 3.4 3.3 3.3 3.3 3.3 3.4 3.3 3.3 3.3 3.4 3.4
105 T.C. 35.3 34.7 32.8 37.4 38.7 37.5 36.7 34.2 38.6 39.8 39.8 38.8 35.6 39.8 40.9 S.C. 32.3 32.1 26.5 26.4 19.6 34.5 34.5 28.8 28.4 20.4 36.7 37.0 31.1 30.5 21.2
KW 3.5 3.5 3.5 3.6 3.7 3.5 3.5 3.5 3.6 3.7 3.6 3.6 3.5 3.6 3.7
115 T.C. 32.4 31.7 29.2 33.4 34.8 34.5 33.6 30.5 34.6 35.7 36.5 35.5 31.8 35.7 36.7 S.C. 29.7 30.0 25.0 24.9 18.2 31.6 31.9 27.2 27.0 19.3 33.5 33.8 29.4 29.1 20.3
KW 3.7 3.7 3.7 3.8 4.0 3.8 3.8 3.7 3.8 4.0 3.8 3.8 3.7 3.9 4.0
125 T.C. 29.6 28.8 25.6 29.4 30.9 31.4 30.5 26.8 30.5 31.7 33.2 32.2 28.0 31.7 32.5 S.C. 27.1 27.9 23.5 23.4 16.8 28.7 29.3 25.6 25.6 18.1 30.2 30.6 27.6 27.8 19.4
KW 4.0 4.0 3.9 4.0 4.2 4.0 4.0 4.0 4.1 4.3 4.1 4.1 4.0 4.1 4.3
NOTE: ALL CAPACITIES INCLUDE INDOOR FAN HEAT AT 1250 BTUH/1000 CFM.
Air Handlers Coils T.C. S.C. KW
– FC/MC/PC48 1.00 1.00 1.00
– HC42 1.00 1.00 1.00
– UC48 1.00 1.00 1.00
AHP42 – 0.97 1.00 0.97
AHX42 – 1.00 1.02 0.92
MA16C FC/MC43C 1.00 1.00 1.00
MA14D FC/MC48D 1.00 1.00 1.00
MA16C FC/MC48C 1.00 1.00 1.00
F5FP048 – 1.00 1.00 1.00
F6FP042 – 1.00 1.03 0.94
F6FP048 – 0.99 1.01 0.93
Furnaces Coils T.C. S.C. KW
T*(8,L)X*B12 FC/MC/PC43B 1.00 0.99 0.96
T*(8,L)X*C16 FC/MC/PC43C 1.00 1.02 0.96
T*(8,L)X*C20 FC/MC/PC43C 1.00 1.01 0.96
T*9X*B12 FC/MC/PC43B 1.00 0.99 0.96
T*9X*C16 FC/MC/PC43C 1.00 1.02 1.00
T*9X*C20 FC/MC/PC43C 1.00 1.02 1.00
T*(8,L)X*C16 FC/MC/PC48C 1.00 1.01 0.96
T*(8,L)X*C20 FC/MC/PC48C 1.00 1.03 0.96
T*9X*C16 FC/MC/PC48C 1.00 1.00 0.96
T*9X*C20 FC/MC/PC48C 1.00 1.00 0.96
T*9X*D20 FC/MC/PC48D 1.00 1.02 0.96
T*(8,L)X*C16 UC48C 1.00 1.01 1.00
T*(8,L)X*C20 UC48C 1.00 1.03 1.00
T*9X*C16 UC48C 0.99 1.00 0.99
T*9X*C20 UC48C 1.00 1.01 1.00
T*9X*D20 UC48D 1.00 1.01 1.00

415571-UTG-C-0309
12 Johnson Controls Unitary Products
Multipliers for determining the performance with other indoor sections.
NOTE: For dry bulb temperatures different than those listed (between 73-87 F), sensible capacity increases by 1060 BTUH per 1000 CFM per degree above the listed
temperature and decreases by 1060 BTUH per 1000 CFM per degree below the listed temperature.
COOLING PERFORMANCE DATA
AIR CONDITIONER MODEL NO. TCGD48S4(3,4)S1
INDOOR COIL MODEL NO. FC/MC/PC48
CONDENSING
ENTERING AIR
TEMPERATURE
IDCFM 1400 1600 1800
ID DB (°F) 80 80 75 80 80 80 80 75 80 80 80 80 75 80 80
ID WB (°F) 57 62 62 67 72 57 62 62 67 72 57 62 62 67 72
65 T.C. 49.7 51.4 50.6 55.8 54.6 52.0 53.1 51.9 56.4 55.4 54.4 54.7 53.2 56.9 56.3 S.C. 47.2 43.1 35.9 36.0 26.1 49.2 45.9 38.2 37.4 27.6 51.2 48.7 40.4 38.8 29.0
KW 2.7 2.8 2.8 2.8 2.8 2.7 2.8 2.8 2.8 2.8 2.7 2.8 2.8 2.8 2.9
75 T.C. 47.5 48.6 47.7 52.9 52.4 49.8 50.3 48.9 53.6 53.1 52.0 52.1 50.2 54.3 53.8 S.C. 44.9 42.0 35.0 34.9 25.4 47.0 44.8 37.1 36.5 26.8 49.0 47.6 39.3 38.2 28.1
KW 3.0 3.0 3.0 3.1 3.1 3.0 3.0 3.0 3.1 3.2 3.0 3.0 3.0 3.1 3.2
85 T.C. 45.4 45.8 44.8 49.9 50.2 47.5 47.6 46.0 50.8 50.8 49.7 49.4 47.1 51.7 51.4 S.C. 42.7 41.0 34.0 33.8 24.8 44.7 43.7 36.1 35.7 26.0 46.8 46.5 38.2 37.6 27.2
KW 3.2 3.3 3.3 3.4 3.4 3.3 3.3 3.3 3.4 3.5 3.3 3.3 3.3 3.4 3.5
95 T.C. 43.2 42.9 42.0 47.0 47.9 45.3 44.9 43.1 48.0 48.4 47.4 46.8 44.1 49.1 48.9 S.C. 40.4 39.9 33.0 32.7 24.1 42.4 42.6 35.1 34.6 25.2 44.5 45.4 37.1 37.0 26.3
KW 3.5 3.5 3.5 3.6 3.7 3.6 3.6 3.5 3.7 3.8 3.6 3.6 3.6 3.7 3.8
105 T.C. 39.8 39.4 37.3 42.4 43.6 41.6 41.1 38.4 43.4 44.0 43.5 42.9 39.5 44.4 44.5 S.C. 37.1 37.0 30.9 30.9 22.9 38.9 39.3 32.9 33.0 23.9 40.8 41.5 34.9 35.1 25.0
KW 3.8 3.8 3.8 3.9 4.0 3.9 3.9 3.8 3.9 4.1 3.9 3.9 3.8 4.0 4.1
115 T.C. 36.5 35.9 32.7 38.0 39.3 38.1 37.5 33.9 38.9 39.8 39.7 39.1 35.1 39.8 40.2 S.C. 33.9 34.2 28.9 29.2 21.6 35.5 36.0 30.9 31.3 22.7 37.2 37.7 32.8 33.3 23.8
KW 4.1 4.1 4.0 4.2 4.3 4.1 4.1 4.1 4.2 4.4 4.2 4.2 4.1 4.2 4.4
125 T.C. 33.1 32.4 28.1 33.5 35.1 34.5 33.8 29.4 34.4 35.5 35.9 35.3 30.6 35.2 36.0 S.C. 30.7 31.4 26.9 27.5 20.4 32.1 32.7 28.8 29.6 21.5 33.5 34.0 30.7 31.6 22.5
KW 4.4 4.4 4.3 4.4 4.6 4.4 4.4 4.3 4.5 4.7 4.5 4.5 4.4 4.5 4.7
NOTE: ALL CAPACITIES INCLUDE INDOOR FAN HEAT AT 1250 BTUH/1000 CFM.
Air Handlers Coils T.C. S.C. KW
– FC/MC/PC60 1.00 1.00 1.00
– HC60 1.00 1.00 1.00
– UC48 1.00 1.00 1.00
– UC60 1.00 1.00 1.00
AHP/SHP48 – 1.00 1.00 1.00
AHP/SHP60 – 1.00 1.01 1.00
AHX48 – 1.00 1.03 0.96
MA16C FC/MC48C 1.00 1.00 1.00
MA20D FC/MC48D 1.00 1.00 1.00
MA16C FC60C 1.00 1.00 1.00
MA20D FC/MC60D 1.00 1.00 1.00
F5FP048 – 1.00 1.00 1.00
F5FP060 – 1.00 1.00 1.00
F6FP048 – 0.98 1.01 0.95
Furnaces Coils T.C. S.C. KW
T*(8,L)X*C16 FC/MC/PC48C 1.00 1.00 1.00
T*(8,L)X*C20 FC/MC/PC48C 1.00 1.00 1.00
T*9X*C16 FC/MC/PC48C 1.00 1.01 1.00
T*9X*C20 FC/MC/PC48C 1.00 1.00 1.00
T*9X*D20 FC/MC/PC48D 1.00 1.01 1.00
T*(8,L)X*C16 FC/PC60C 1.00 1.01 1.00
T*(8,L)X*C20 FC/MC/PC60D 1.00 1.01 1.00
T*9X*C16 FC/PC60C 1.00 1.01 1.00
T*9X*C20 FC/PC60C 0.98 1.01 0.98
T*9X*D20 FC/MC/PC60D 0.99 0.98 0.99
T*9X*C16 FC/PC60C 0.98 0.98 0.98
T*9X*C20 FC/PC60C 0.98 0.98 0.98

415571-UTG-C-0309
Johnson Controls Unitary Products 13
Multipliers for determining the performance with other indoor sections.
NOTE: For dry bulb temperatures different than those listed (between 73-87 F), sensible capacity increases by 1060 BTUH per 1000 CFM per degree above the listed
temperature and decreases by 1060 BTUH per 1000 CFM per degree below the listed temperature.
COOLING PERFORMANCE DATA
AIR CONDITIONER MODEL NO. TCGD60S4(3,4)S1
INDOOR COIL MODEL NO. FC/MC/PC60
CONDENSING
ENTERING AIR
TEMPERATURE
IDCFM 1400 1600 1800
ID DB (°F) 80 80 75 80 80 80 80 75 80 80 80 80 75 80 80
ID WB (°F) 57 62 62 67 72 57 62 62 67 72 57 62 62 67 72
65 T.C. 55.8 63.8 62.1 65.2 71.9 60.3 65.7 62.8 66.7 69.8 64.8 67.5 63.5 68.2 67.8 S.C. 54.7 51.6 41.4 41.1 34.1 58.4 54.2 43.9 42.6 31.9 62.1 56.8 46.5 44.2 29.6
KW 3.0 3.0 3.0 3.1 3.1 3.0 3.0 3.0 3.1 3.1 3.0 3.1 3.0 3.1 3.1
75 T.C. 56.9 61.1 58.9 62.7 69.7 59.2 63.0 59.9 64.3 67.9 61.4 64.9 61.0 65.9 66.0 S.C. 53.9 50.4 40.5 40.0 33.5 55.8 53.1 43.1 41.8 31.5 57.7 55.7 45.6 43.6 29.5
KW 3.4 3.5 3.5 3.5 3.6 3.4 3.5 3.5 3.5 3.5 3.5 3.5 3.5 3.5 3.5
85 T.C. 58.0 58.4 55.7 60.3 67.6 58.0 60.4 57.1 61.9 65.9 58.1 62.4 58.5 63.6 64.1 S.C. 53.2 49.3 39.7 39.0 32.9 53.3 52.0 42.2 41.0 31.2 53.4 54.7 44.8 42.9 29.4
KW 3.9 3.9 3.9 3.9 4.0 3.9 3.9 3.9 3.9 4.0 3.9 3.9 3.9 3.9 4.0
95 T.C. 59.1 55.7 52.5 56.9 65.5 56.9 57.8 54.3 57.0 63.9 54.7 59.8 56.0 61.2 62.2 S.C. 52.4 48.1 38.8 37.9 32.3 50.7 50.9 41.4 38.8 30.8 49.0 53.6 43.9 42.3 29.4
KW 4.3 4.3 4.3 4.4 4.5 4.3 4.3 4.3 4.4 4.4 4.3 4.3 4.3 4.4 4.4
105 T.C. 56.4 52.2 48.8 54.0 60.1 54.0 54.3 50.5 55.7 59.7 51.6 56.3 52.2 57.4 59.4 S.C. 49.7 45.9 37.5 36.5 29.7 47.9 48.3 40.0 38.7 29.4 46.2 50.6 42.5 40.9 29.0
KW 4.9 4.9 4.9 4.9 5.0 4.9 4.9 4.9 5.0 5.0 4.9 4.9 4.9 5.0 5.0
115 T.C. 53.8 48.8 45.2 50.2 54.8 51.2 50.9 46.8 51.9 55.7 48.7 53.0 48.5 53.6 56.6 S.C. 47.1 43.8 36.2 35.0 27.3 45.3 45.7 38.6 37.3 27.9 43.5 47.7 41.1 39.6 28.6
KW 5.5 5.4 5.4 5.5 5.6 5.5 5.5 5.4 5.5 5.6 5.4 5.5 5.4 5.5 5.6
125 T.C. 51.2 45.4 41.6 46.5 49.4 48.5 47.5 43.2 48.2 51.6 45.7 49.7 44.8 49.8 53.8 S.C. 44.5 41.7 34.9 33.6 24.9 42.6 43.2 37.3 35.9 26.5 40.7 44.7 39.7 38.3 28.2
KW 6.1 6.0 5.9 6.1 6.2 6.0 6.0 6.0 6.1 6.2 6.0 6.0 6.0 6.1 6.2
NOTE: ALL CAPACITIES INCLUDE INDOOR FAN HEAT AT 1250 BTUH/1000 CFM.
Air Handlers Coils T.C. S.C. KW
– FC/MC62 1.00 1.00 1.00
– HC60 1.00 1.00 1.00
– UC60 1.00 1.00 1.00
AHP/SHP60 – 1.00 1.00 1.00
AHX60 – 1.00 1.00 0.98
MA20D FC/MC60D 1.00 1.00 1.00
MA20D FC/MC62D 1.00 1.00 1.00
F5FP060 – 1.00 1.00 1.00
F6FP060 – 1.00 1.00 0.96
Furnaces Coils T.C. S.C. KW
T*(8,L)X*C16 FC/PC60C 0.99 0.98 0.99
T*(8,L)X*C20 FC/MC/PC60D 1.00 0.98 1.00
T*9X*C16 FC/PC60C 0.98 0.98 0.98
T*9X*C20 FC/PC60C 0.98 0.98 0.98
T*9X*D20 FC/MC/PC60D 0.99 0.98 0.99
T*9X*C20 FC/MC/PC60D 0.99 0.98 0.99
T*(8,L)X*C20 FC/MC62D 1.00 0.98 1.00
T*(8,L)X*C16 UC60C 0.98 0.97 0.98
T*(8,L)X*C20 UC60D 0.99 1.00 0.99
T*9X*C16 FC/PC60C 0.98 0.97 0.98
T*9X*C20 FC/PC60C 0.98 0.97 0.98
T*9X*D20 UC60D 0.98 0.97 0.98
T*(8,L)X*C20 UC60D 0.99 1.00 0.99
T*9X*C20 UC60D 0.98 0.97 0.98

Subject to change without notice. Printed in U.S.A. 415571-UTG-C-0309
Copyright © 2009 by Johnson Controls, Inc. All rights reserved. Supersedes 415571-UTG-B-0708
Johnson Controls Unitary Products
5005 York Drive
Norman, OK 73069
