Johnson Pump SPX Flow CombiLineBloc User manual

CLB/EN (1901) 6.6
CombiLineBloc
Orginal instructions
Read and understand this manual prior to operating or servicing this product
INSTRUCTION MANUAL
In-line circulation pump in block execution

EC-ECO/EN (1712) 1.3 1
EC Declaration of conformity
(Directive 2006/42/EC, appendix II-A)
Manufacturer
SPX Flow Technology Assen B.V.
Dr. A.F. Philipsweg 51
9403 AD Assen
The Netherlands
hereby declares that all pumps member of productfamilies CombiBloc, CombiBlocHorti,
CombiChem, CombiLine, CombiLineBloc and CombiNorm whether delivered without
drive (last position of serial number = B), or delivered as an assembly with drive (last
position of serial number = A), are in conformity with the provisions of Directive 2006/
42/EC (as altered most recently) and where applicable the following directives and
standards:
• EC directive 2014/35/EU, "Electric equipment for use within certain voltage limits"
• standards EN-ISO 12100 part 1 & 2, EN 809
The pumps to which this declaration refers may only be put into operation after they have
been installed in the way prescribed by the manufacturer, and, as the case may be, after
the complete system of which these pumps form part, has been made to fulfil the
requirements of Directive 2006/42/EC (as altered most recently).
EC Declaration of conformity
(Directive 2009/125/EC, Annex VI and Commission Regulation (EU) No 547/2012)
(Implementing Directive 2009/125/EC of the European Parliament and of the Council
with regard to ecodesign requirements for water pumps)
Manufacturer
SPX Flow Technology Assen B.V.
Dr. A.F. Philipsweg 51
9403 AD Assen
The Netherlands
Hereby declares that all listed pumps member of product families CombiBloc,
CombiBlocHorti, CombiChem, CombiLine, CombiLineBloc and CombiNorm are in
conformity with the provisions of Directive 2009/125/EC and Commission Regulation
(EU) No 547/2012 and the following standard:
• EN 16480

2EC-ECO/EN (1712) 1.3
Declaration of incorporation
(Directive 2006/42/EC, appendix II-B)
Manufacturer
SPX Flow Technology Assen B.V.
Dr. A.F. Philipsweg 51
9403 AD Assen
The Netherlands
hereby declares that the partly completed pump (Back-Pull-Out unit), member of
productfamilies CombiBloc, CombiBlocHorti, CombiChem, CombiLine, CombiLineBloc
and CombiNorm is in conformity with the following standards:
• EN-ISO 12100 parts 1 & 2, EN 809
and that this partly completed pump is meant to be incorporated into the specified pump
unit and may only be put into use after the complete machine of which the pump under
consideration forms part has been made and declared to comply with that directive.
Assen, December 1st 2017
B. Peek,
Managing Director

INT/EN (1512) 1.2 3
Instruction manual
All technical and technological information in this manual as well as possible drawings
made available by us remain our property and shall not be used (otherwise than for the
operation of this pump), copied, duplicated, made available to or brought to the notice of
third parties without our prior written consent.
SPXFLOW is a global multi-industry manufacturing leader. The company's highly-
specialized, engineered products and innovative technologies are helping to meet rising
global demand for electricity and processed foods and beverages, particularly in
emerging markets.
SPX Flow Technology Assen B.V.
P.O. B ox 9
9400 AA Assen
The Netherlands
Tel. [phone]
Fax. [phone]
Copyright © 2015 SPXFLOW Corporation

4INT/EN (1512) 1.2

CLB/EN (1901) 6.6 5
CombiLineBloc
Table of Contents
1 Introduction 9
1.1 Preface 9
1.2 Safety 9
1.3 Guarantee 10
1.4 Inspection of delivered items 10
1.5 Instructions for transport and storage 10
1.5.1 Weight 10
1.5.2 Use of pallets 10
1.5.3 Hoisting 11
1.5.4 Opening the packaging 11
1.5.5 Storage 11
1.6 Ordering parts 11
2 General 13
2.1 Pump description 13
2.2 Applications 13
2.3 Type code 14
2.4 Serial number 14
2.5 Bearing groups 14
2.6 Construction 15
2.6.1 Design 15
2.6.2 Pump casing/impeller 15
2.6.3 Mechanical seal 15
2.6.4 Bearing construction 15
2.7 Ecodesign Minimum Efficiency Requirements Water Pumps 16
2.7.1 Introduction 16
2.7.2 Implementing Directive 2009/125/EC 16
2.7.3 Energy Efficient Pump Selection 19
2.7.4 Scope of Implementing Directive 2009/125/EC 20
2.7.5 Product information 20
2.8 Application area 23
2.9 Re-use 23
2.10 Scrapping 23
3Installation 25
3.1 Safety 25
3.2 Preservation 25
3.3 Accessories 25
3.4 Environment 25
3.5 Piping 26

6CLB/EN (1901) 6.6
3.6 Installation 26
3.7 Connecting the electric motor 26
4 Commissioning 27
4.1 Inspection of the pump 27
4.2 Inspection of the motor 27
4.3 Preparing the pump unit for commissioning 27
4.4 Checking the sense of rotation 27
4.5 Pump in operation 28
4.6 Noise 28
5 Maintenance 29
5.1 Daily maintenance 29
5.2 Mechanical seal 29
5.3 Lubrication of the bearings 29
5.4 Environmental influences 29
5.5 Noise 29
5.6 Motor 29
5.7 Faults 30
6 Problem solving 31
7 Disassembly and assembly 33
7.1 Precautions 33
7.1.1 Switch off the electricity supply 33
7.1.2 Disconnecting the electricity supply 33
7.1.3 Support of the piping 33
7.1.4 Liquid draining 33
7.2 Removing the pump 33
7.2.1 Back-Pull-Out system 33
7.3 Disassembly 34
7.3.1 Disassembling the Back-Pull-Out unit 34
7.3.2 Assembling the Back-Pull-Out unit 34
7.4 Impeller 35
7.4.1 Disassembling the impeller 35
7.4.2 Mounting the impeller 36
7.5 Mechanical seal 37
7.5.1 Instructions for mounting a mechanical seal 37
7.5.2 Disassembling a mechanical seal M1 38
7.5.3 Assembling a mechanical seal M1 39
7.6 Replacing the stub shaft and the motor 40
7.6.1 Disassembling the stub shaft and the motor 40
7.6.2 Assembling the stub shaft and the motor 41
8Dimensions 43
8.1 Dimensions drawings 43
8.2 Pump dimensions 44
8.3 Overall length (G) 45
8.4 Weight 46
8.5 Flange dimensions 47
8.6 Base plate dimensions 47
9Parts 49
9.1 Ordering parts 49
9.1.1 Order form 49
9.1.2 Recommended spare parts 49

CLB/EN (1901) 6.6 7
CombiLineBloc
9.2 CLB parts 50
9.2.1 Sectional drawing 50
9.2.2 Parts list 51
9.3 Additional parts 200-160 52
9.4 Base plate 53
10 Technical data 55
10.1 Recommended locking liquids 55
10.2 Tightening moments 55
10.2.1 Tightening moments for bolts and nuts 55
10.2.2 Tightening moments for cap nut 55
10.3 Hydraulic performance 56
10.3.1 Performance overview 56
10.4 Noise data 59
10.4.1 Pump noise as a function of pump power 59
10.4.2 Noise level of entire pump unit 60
Index 61
Order form for spare parts 63

8CLB/EN (1901) 6.6

CLB/EN (1901) 6.6 Introduction 9
CombiLineBloc
1 Introduction
1.1 Preface
This manual is intended for technicians and maintenance staff and for those who are in
charge of ordering spare parts.
This manual contains important and useful information for the proper operation and
maintenance of this pump. It also contains important instructions to prevent potential
accidents and damage, and to ensure safe and fault-free operation of this pump.
! Read this manual carefully before commissioning the pump, familiarize
yourself with the operation of the pump and strictly obey the instructions!
The data published here comply with the most recent information at the time of going to
press. However they may be subject to later modifications.
SPXFLOW reserves the right to change the construction and design of the products at
any time without being obliged to change earlier deliveries accordingly.
1.2 Safety
This manual contains instructions for working safely with the pump. Operators and
maintenance staff must be familiar with these instructions.
Installation, operation and maintenance has to be done by qualified and well prepared
personnel.
Below is a list of the symbols used for those instructions and their meaning:
Personal danger for the user. Strict and prompt observance of the
corresponding instruction is imperative!
! Risk of damage or poor operation of the pump. Follow the corresponding
instruction to avoid this risk.
➢Useful instruction or tip for the user.
Items which require extra attention are shown in bold print.
This manual has been compiled by SPXFLOW with the utmost care. Nevertheless
SPXFLOW cannot guarantee the completeness of this information and therefore
assumes no liability for possible deficiencies in this manual. The buyer/user shall at all
times be responsible for testing the information and for taking any additional and/or
deviating safety measures. SPXFLOW reserves the right to change safety instructions.

10 Introduction CLB/EN (1901) 6.6
1.3 Guarantee
SPXFLOW shall not be bound to any guarantee other than the guarantee accepted by
SPXFLOW. In particular, SPXFLOW will not assume any liability for explicit and/or
implicit guarantees such as but not limited to the marketability and/or suitability of the
products supplied.
The guarantee will be cancelled immediately and legally if:
• Service and/or maintenance is not undertaken in strict accordance with the
instructions.
• The pump is not installed and operated in accordance with the instructions.
• Necessary repairs are not undertaken by our personnel or are undertaken without our
prior written permission.
• Modifications are made to the products supplied without our prior written permission.
• The spare parts used are not original SPXFLOW parts.
• Additives or lubricants used are other than those prescribed.
• The products supplied are not used in accordance with their nature and/or purpose.
• The products supplied have been used amateurishly, carelessly, improperly and/or
negligently.
• The products supplied become defective due to external circumstances beyond our
control.
All parts which are liable to wear are excluded from guarantee. Furthermore, all
deliveries are subject to our “General conditions of delivery and payment”, which will be
forwarded to you free of charge on request.
1.4 Inspection of delivered items
Check the consignment immediately on arrival for damage and conformity with the advice
note. In case of damage and/or missing parts, have a report drawn up by the carrier at
once.
1.5 Instructions for transport and storage
1.5.1 Weight
A pump or a pump unit is generally too heavy to be moved by hand. Therefore, use the
correct transport and lifting equipment. Weight of the pump or pump unit are shown on
the label on the cover of this manual.
1.5.2 Use of pallets
Usually a pump or pump unit is shipped on a pallet. Leave it on the pallet as long as
possible to avoid damages and to facilitate possible internal transport.
! When using a forklift always set the forks as far apart as possible and lift the
package with both forks to prevent it from toppling over! Avoid jolting the
pump when moving it!

CLB/EN (1901) 6.6 Introduction 11
CombiLineBloc
1.5.3 Hoisting
When lifting a complete pump unit always use a proper and sound lifting
device, approved to bear the total weight of the load!
Never go underneath a load that is being lifted!
! If the electric motor is provided with a lifting eye, this lifting eye is intended
only for the purpose of carrying out service activities to the electric motor!
The lifting eye is designed to bear the weight of the electric motor only!
It is NOT permitted to lift a complete pump unit at the lifting eye of an electric
motor!
1.5.4 Opening the packaging
The pump may be packed in a cardboard box with wooden bottom. The boxes are kept
shut by 2 plastic straps. These straps also serve to keep the bottom and the covering box
together.
Always make sure that the box stands on the floor!
Wear gloves: the straps are under tension and may be sharp!
1 Cut the plastic straps.
2 Remove the covering box.
3 Unscrew the pump from the bottom.
4 Rest the pump on the supporting brackets under the suction bend.
1.5.5 Storage
If the pump is not to be used immediately the stub shaft must be turned by hand twice
per week.
1.6 Ordering parts
This manual contains a survey of the spare parts recommended by SPXFLOW as well as
the instructions for ordering them. A fax-order form is included in this manual.
You should always state all data stamped on the type plate when ordering parts and in
any other correspondence regarding the pump.
➢This data is also printed on the label on the front of this manual.
If you have any questions or require further information with regard to specific subjects,
then do not hesitate to contact SPXFLOW.

12 Introduction CLB/EN (1901) 6.6

CLB/EN (1901) 6.6 General 13
CombiLineBloc
2 General
2.1 Pump description
The CombiLineBloc is a built-in circulation pump constructed with a lantern piece and a
standard IEC electric motor with flange. That means that the medium to be pumped will
not get into the electric motor. The pump is provided with a mechanical seal with bellows
mounted on the stub shaft which is mounted directly on the motor shaft. The pump has
been designed as a monobloc pump which means that pump, lantern piece and electric
motor have been assembled to form one compact unit. Suction and delivery flange are
in-line, so the pump can easily be built into straight pipes without a foundation being
required. The pump can also be mounted with the suction bend placed on a fundation by
means of the special support device. The pumps are available in 2 speeds. The flanges
are according to EN 1092-2 (DIN 2532) PN10 or EN 1092-2 (DIN 2531) PN6.
2.2 Applications
• In general, this pump can be used for thin, clean or slightly polluted liquids. These
liquids should not affect the pump materials.
• Further details about the application possibilities of your specific pump are mentioned
in the order confirmation and/or in the data sheet enclosed with the delivery.
• Do not use the pump for purposes other than those for which it is delivered without
prior consultation with your supplier.
Using a pump in a system or under system conditions (liquid, working
pressure, temperature, etc.) for which it has not been designed may hazard
the user!

14 General CLB/EN (1901) 6.6
2.3 Type code
Pumps are available in various designs. The main characteristics of the pump are shown
in the type code.
Example: CLB 65-200 G1
2.4 Serial number
Serial number of the pump or pump unit are shown on the name plate off the pump and
on the label on the cover of this manual.
2.5 Bearing groups
The pump range is divided in a number of bearing groups.
Pump family
CLB CombiLineBloc
Pump size
65 diameter discharge connection [mm]
200 nominal impeller diameter [mm]
Pump casing material
Gcast iron
Bbronze
Impeller material
1cast iron
2bronze
Example: 19-001160
19 year of manufacture
001160 unique number
Table 1: Bearing group division.
Bearing groups
122V3
40C-125 80A-250 200-160 150-250
40-160 100-200
40-200 100A-250
50-125 125-160
50-160 125C-200
50-200 125A-250
65-125 150-160
65-160 150-200
65-200 200-200
80-125
80-160
80-200
100-160
150-125

CLB/EN (1901) 6.6 General 15
CombiLineBloc
2.6 Construction
2.6.1 Design
The design is characterized by a compact construction. The pump is mounted to a
standard IEC flange motor by means of a lantern piece and a stub shaft. The pump cover
is clamped between the pump casing and the lantern piece.
The electric motors up to and including frame size 112M have B5 mounting arrangement
and the larger types have B3/B5 mounting arrangement. All vertically placed motors
have mounting arrangement V1.
2.6.2 Pump casing/impeller
• The pump casing is of the volute type. Suction and delivery flange are placed in-line
and have the same flange size.
• The specially shaped suction bend ensures low-noise functioning of the pump and
favorable NPSH values.
• The impeller is of the closed type and is mounted directly on the end of the stub shaft.
The impeller is fixed by means of a cap nut.
2.6.3 Mechanical seal
The pump is provided with a mechanical seal with mounting dimensions according to EN
12756 (L1K) (DIN 24960 (L1K)). This mechanical seal can be used up to a working
pressure of 10 bar and a temperature of 120 °C (peak values of 140 °C).
2.6.4 Bearing construction
The bearing is provided by the motor bearings. The selection of the motor-pump
combination is such that the bearings of the applied electric motors can absorb the axial
and radial forces without the bearing life being affected.
The electric motors must be provided with a fixed bearing.

16 General CLB/EN (1901) 6.6
2.7 Ecodesign Minimum Efficiency Requirements Water Pumps
• Directive 2005/32/EC of the European Parliament and of the Council;
• Commission regulation (EU) No 547/2012 Implementing Directive 2009/125/EC of
the European Parliament and of the Council with regard to ecodesign requirements for
water pumps.
2.7.1 Introduction
SPX Flow Technology Assen B.V. is an associate member of the HOLLAND PUMP
GROUP, an associate member of EUROPUMP, the organization of European pump
manufacturers.
Europump promotes the interest of the European pump industry with the European
institutions.
Europump welcomes the aim of the European Commission to reduce eco-impact of
products in the European Union. Europump is fully aware of the eco-impact of pumps in
Europe. For many years the ecopump initiative is one of the strategic columns in the work
of Europump. From the first of January 2013 the regulation is coming into force
concerning minimum required efficiencies of rotodynamic water pumps. The regulation
sets minimum efficiency requirements on water pumps set out under the Ecodesign
Directive for energy related products. This regulation mainly addresses manufacturers of
water pumps placing these products on the European market. But as a consequence
customers may also be affected by this regulation. This document gives necessary
information related to the coming into force of the water pump regulation EU 547/2012.
2.7.2 Implementing Directive 2009/125/EC
• Definitions:
“This Regulation establishes eco-design requirements for the placing on the market of
rotodynamic water pumps for pumping clean water, including where integrated in other
products.”
“Water pump” is the hydraulic part of a device that moves clean water by physical or
mechanical action and is of one of the following designs:
• End suction own bearing (ESOB);
• End suction close coupled (ESCC);
• End suction close coupled inline (ESCCi);
• Vertical multistage (MS-V);
• Submersible multistage (MSS);”
‘End suction water pump’ (ESOB) means a glanded single stage end suction
rotodynamic water pump designed for pressures up to 1600 kPa (16 bar), with a specific
speed ns between 6 and 80 rpm, a minimum rated flow of 6 m3/h, a maximum shaft
power of 150 kW, a maximum head of 90 m with nominal speed of 1450 rpm and a
maximum head of 140 m with nominal speed of 2900 rpm;
‘End suction close coupled water pump’ (ESCC) is an end suction water pump of which
the motor shaft is extended to become also the pump shaft;
‘End suction close coupled inline water pump’ (ESCCi) means a water pump of which
the water inlet of the pump is on the same axis as the water outlet of the pump;
‘Vertical multistage water pump’ (MS-V) means a glanded multistage (i > 1) rotodynamic
water pump in which the impellers are assembled on a vertical rotating shaft, which is
designed for pressures up to 2500 kPa (25 bar), with a nominal speed of 2900 rpm and
a maximum flow of 100 m3/h;

CLB/EN (1901) 6.6 General 17
CombiLineBloc
‘Submersible multistage water pump’ (MSS) means a multistage (i > 1) rotodynamic
water pump with a nominal outer diameter of 4” (10,16 cm) or 6” (15,24 cm) designed to
be operated in a borehole at nominal speed of 2900 rpm, at operating temperatures
within a range of 0°C and 90°C;
This Regulation shall not apply to:
1 water pumps designed specifically for pumping clean water at temperatures below -
10°C or above +120°C;
2 water pumps designed only for fire-fighting applications;
3 displacement water pumps;
4 self-priming water pumps.
• Enforcement:
In order to enforce this there will be a Minimum Efficiency Index (M.E.I.) criteria set for
the above list of pumps.
The MEI is a dimensionless figure that is derived from a complex calculation based on
the efficiencies at BEP (Best Efficiency Point), 75% BEP & 110% BEP, and the specific
speed. The range is used so that manufacturers do not take an easy option of providing
good efficiency at one point i.e. BEP.
The value ranges from 0 to 1,0 with the lower value being less efficient, this provides the
basis of eliminating the less efficient pumps starting with 0,10 in 2013 (the lowest 10%)
and 0,40 (the lowest 40%) in 2015.
The MEI value of 0,70 is classed benchmark for the most efficient pumps in the market at
the time of developing the directive.
The milestones for the MEI values are as follows;
1 1st January 2013 all pumps shall have a minimum MEI value of 0,10;
2 1st January 2015 all pumps shall have a minimum MEI value of 0,40.
The most important point of this is that unless the pumps comply then they
will not be allowed to have a CE marking.
• Part Load Performance
It is common practice that pumps spend much of their time working away from their rated
duty, and efficiency can fall off rapidly below the 50% duty point, any scheme should take
account of this real life performance. However, manufacturers need a pump efficiency
classification scheme that makes it impossible to design pumps with a steep fall off in
efficiency either side of the BEP point in order to claim a higher efficiency than would be
typical of real life operation.
• ‘House of Efficiency’
The decision scheme ‘House of Efficiency’ takes into account design and application
purposes as well as the pump minimum efficiency dependence on flow. The minimum
acceptable efficiency is therefore different for each pump type. The pass-or-fail scheme
is based on two criteria A and B.

18 General CLB/EN (1901) 6.6
Criterion A is the pass-or-fail minimum efficiency requirement at the best efficiency point
(BEP) of the pump:
Where
Criterion B is the pass-or-fail minimum efficiency requirement at part load (PL) and at
overload (OL) of the pump:
Therefore a method is devised what is called a “house of efficiency” scheme that also
requires pumps to pass efficiency thresholds at 75% and 110% of rated flow. The
advantage of this is that pumps will be penalised for poor efficiency away from rated
efficiency, hence it will take account of real life pump duties.
It should be stated that while the scheme may appear complicated at first sight, in
practice it has been easy for the manufacturers to apply the scheme to their pumps.
Figure 1: House of Efficiency
ηPump nsQBEP ,ηBOTTOM ≥
nsnNQBEP
HBEP0.75
-------------------
×=
ηBOTTOM PL OL,–xηBOTTOM ⋅≥
Head
η
BEP
HBEP
QBEP Flow
0QPL QOL
ηPL= 0.94 ηBEP
ηBEP
ηOL= 0.98 ηBEP
Pump Eff.
Curve
System
Curve
