Joney JYF-3002 User manual

1
Contents
1Introduction of the fingerprint lock....................................3
1.1 Feactures....................................................................................3
1.1.1 Brief Introduction...................................................................4
1.1.2 Introduction of functions........................................................4
1.2 Diamensions...............................................................................4
1.3 Technical data.............................................................................5
2Operation..............................................................................6
2.1 Ways to put the finger.................................................................6
2.2 Setting Card + password............................................................6
2.3 Setting fingerprint + password + card...........................................6
2.4 Alarming Function..........................................................................16
2.4.1 Low voltage alarm...............................................................16
2.5 Backup power................................................................................16
2.6 Installing / replacing batteries........................................................16
2.6.1 Installing batteries...............................................................16
2.6.2 Replacing batteries.............................................................16
2.7 Remarks........................................................................................17
3Installation Procedures .....................................................17
3.1 Opening pores on the door.......................................................17
3.2 Opening pores on lock holder case..........................................18
3.3 Installation procedures .............................................................19
4Maintenance and upkeep ..................................................22
4.1 Daily maintenance and upkeep ................................................22
4.2 Notice for use ...........................................................................23
5After-sale Service...............................................................26
5.1 Remarks about after-sale service.............................................26
5.2 Packing List ..............................................................................26

2
5.3 Accessories ..............................................................................27
A/2(2013 年7月)

1
Important Tips
1. Fingerprint lock is a kind of hi-technical product, and its normal
operation and life span are directly influenced by the installation.
Therefore, we kindly suggested you to call in a professional to install it.
Please open pores, supporting pits, buckle and buckle pores
according to the indication of opening pore in the door plank. Pores
should be opened accurately and the lock should be installed
according to the indication strictly. If the lock cannot be opened
(smoothly) after installation, please contact with the local distributors
or our after-sales department to solve the problem.
2. If your house is sprucing up, it is suggested to uninstall the lock after
you exanimate the locks and to reinstall them after the sprucing up.
The aims are: 1. To avoid the lock appearance being damaged by
corrosives, and the wet paint on the door will influence the gearing of
the lock. 2. Ethyl alcohol, paint and other chemicals will be used when
we sprucing up the house, which will be volatized to accelerate to
damage the lock appearance and shorten its life span.
3. Before installation, please switch on all of the connecting wire and
load the batteries, and then press the initialized button to initialize the
lock and restore factory defaults.
4. When installing the lock, please do take the mechanical keys with you
so as to unlock it if the door is close before you finish the installation.

2
Registration Form of Users
For convenience, we make this form for administrator to record
information of user registration. You can also make you form according to your
specific requirements.
No.
Department
Name
Fingerprint
No.
Date of
registration
signature
Remarks

3
1 Introduction of the fingerprint lock
1.1 Feactures

4
1.1.1 Brief Introduction
Features : Delicate appearance design, Reasonable structure, Secure
fingerprint lock.
Applications: Government, Police station, Army, Bank, Law Court, Hospital,
Office building, Residential area, etc.
1.1.2 Introduction of functions
Adopting the international advance biotechnology to ensure its high quality;
4 peaces AA batteries; handles can prevent the wreaking havoc;
Unlocking methods: 1. Fingerprint + Password + mechanical key; 2. Card +
password + mechanical key.
1.2 Diamensions

5
1.3 Technical data
No.
Items
Technical parameters
1
Sensor resolution
Bright background, 500dpi
2
Sensor damage resistance
ability
1000 times of impact with 4H pencil
3
Starting time
<1 second
4
Way of contrast
1：N
5
False rejection rate
≤1%
6
Error rate
≤0.0001%
7
Finger point
360°
8
Fingerprint registration module
Create one fingerprint module at one
time
9
Fingerprint update mode
Auto update
10
Fingerprint information
The fingerprint information will not
lose when the battery is off or
changed
11
Fingerprint capacity
100 Pieces
12
Lights interfere
Avoid explosion under high light
13
Fingerprint collector
Hard glass, nanometer surface
treatment
14
Static Power Consumption
< 30 u A
15
Dynamic Power Consumption
The working current is under 200 mA
16
Control system
Dicaryon dual circuit and individual
control
17
The fingerprint battery life
Open door for 5000 times
18
The combination battery life
Open door for 6000 times
19
Working voltage
DC 6 V
20
Power supply mode
Battery powered
21
Combination capacity
100 Groups
22
backup power
DC 9 V
23
Low voltage alarm
4.9 V
24
Antistatic ability
Contact discharge 8KV，air discharge
15KV
25
Working temperature
-10℃to 55℃
26
Working humidity
10% to 90%
27
Storage temperature
-20℃to 7 0℃
28
Combination design
Random combination
29
Combination length
6-digit numbers
30
Door open method
Left open, right open
(Remark: We emphasize the technology updating, we keep the right to
notice you if parameters are changed)

6
2 Operation
2.1 Ways to put the finger
Remarks: please notice to put your finger in the right position
Please put your finger on the fingerprint acquisition windows with moderate
force and keep flat because the central of the fingerprint contents most of the
information. Compare the right and wrong way of putting finger as below:
手指须放置在指纹采集窗中心
保持手指平放在指纹采集窗
轻轻地把手指按在指纹采集窗
保持平稳（不要向前或向后滑）
Lock-out function
Pull the handle upwards inside or outside the door can make it lock out and
realize the function of anti-theft bolt. Rotate the small knob in the back of the
lock 45 degrees, the door will be deadlock, and it cannot be opened outside in
any ways.
2.2 Setting in the mode of Card + password
Mifare card password lock has the following two methods to unlock:

7
1. Stand-alone (independent): Mifare card or password alone to open the
door.
2. Combined: Mifare card and password are used together to open the
door.
Note:
1. The system locks Initialized from the factory, the first management
password is 12345678, unlock method is stand-alone model.
1.1 Change Stand-alone model to the combined model:
Enter 8-bit management password，press key button and then press “6
“button, buzzer 6 sounds, blue light flashing, then press key button to
confirm, the buzzer "beep "long, you have change the model successfully. If
you want to exit, press the“*“button;
1.2 Change combined model to the Stand-alone model:
Put in 8-bit management passwords, then press “5 “button , buzzer 5
sounds, blue light flashing, then press the key button to confirm, the buzzer
"beep "long, you have change it successfully. If you want to exit, press the *
button;
2. In combination mode, if swipe the card first(or enter a password before
pressing the key button) there would be sounds of "di di", blue lights
flashing.Then put in the password and press the key button (or swipe the
card) in 10 seconds, blue light on and the door unlocked.
Mifare Card Operation Manual:
⑴Management Card
Function: setting and clear the effective unlocking card; unlock the
door.
⑵Unlocking card
Function: unlocking the door and set the stay-open state.
⑶Mechanical key
Function: emergency unlocking the door, setting and managing the
management card.

8
Note: Before put in the password, please brush touch the button panel
until the backlit blue lights on. Then you can put in password.
1. Setting and clearing the management card
1.1 Pressing the initial button on the breadborad for 5 times can empty
all the cards and password.
1. 2 Pressing the initial button on the breadborad for 5 times and read
the first card, a short “beep” and a long “beep” indicate this card is set
as the management card.
2. Adding unlocking cards
2.1 Enter the setting card state:
Read the management card, the buzzer sound a "beep", the motor
rotating, blue lights flashing, then you can open the door. The light will
be off after you unlock. If you do not open the lock and read the
management card, there will be a sound of “beep”, blue light flashing
slowly, this is enter into the setting unlock card state, the card it reading
is the unlock card. Within 5 seconds if the lock hasn’t detected the valid
IC card, then you will hear two short beeps "beep, beep", the unlock
card key card was setting well.
2.2 Process of setting unlocking card:
Entry the Setting key state, take the IC cards close to the inductive
area of lock, if setting the card success, you will sound a short "beep"
and then a long "beep". Repeat this operation, you can set other
unlocking cards. If this card already exists, then the buzzer will sound 2
short beeps of "Didi". 200 unlocking cards are available at most.
3. Clearing the unlocking card
3.1 Clearing single one unlocking card
Read the management card 3 times, there will blue light flashing, put
the card key you want to clear nearing to the inductive area and read it
once, a short' beep' and a long' beep', means that the card has been
clearws successfully. Repeat this operation to delete the other door
cards. If the card does not exist, then the buzzer sounds 6 short beeps.
