JOSEF DAVIDSSONS JD 320 Manual

JD 320/Viking 30
Installaon and maintenance manual
A

Technical data 4
What comes with the stove 5
JD 320/Viking 30 wood stove
dimensions and installaon 6 – 7
About the JD 320/Viking 30 8
Operaon of your
JD 320/Viking 30 9
Installaon and connecon 10
Connecng outdoor air
to the wood stove 11
Replaceable parts 12
How to replace vermiculite and
back plate 13
Maintenance, cleaning the stove 14
How to light the stove 14
Problem-solving 15
Warranty 16

3
Congratulaons on your new JD 320/Viking 30! All of us at Josef Davidssons Er. hope that,
like many others around the country, you will have many happy hours in the kitchen.
The JD 320/Viking 30 is a ne wood stove which works equally well for cooking and for cold
winter evenings.
This manual provides instrucons in how to install your wood stove and maintenance advice
and ps on the best way to run it. Do not hesitate to contact us if you have more quesons
about ring and your JD 320/Viking 30.
Best wishes,
Markus Mikael
It will soon be me for the rst re.

4
TECHNICAL DATA
Eciency (%) 78
Output (kW) 3–8
Heang capacity (approx. m²) up to 80
Weight (kg) 150
Size (H x W x D mm) 850–900 x 300 x 600
Firebox size (H x W x D mm) 300 x 190 x 390
Firewood length (mm) 300–350
Flue dimensions (Ø, mm) 125
Clearance to ammable material See page 7
Approval cercate number 0386/04
CE standard EN12815
IMPORTANT POINTS BEFORE YOU
GET STARTED:
Fing by a professional
The manual contains instrucons on how the JD 320/
Viking 30 should be ed and installed. To guarantee the
funcon and safety of the stove, we recommend instal-
laon by a professional. Contact one of our dealers, who
can help with the installaon or recommend a suitable
er.
Building applicaon
To install a replace and t a chimney, a building appli-
caon has to be submied to the municipal planning
commiee. Contact your planning commiee if you are
unsure how to apply.
Supporng base
Check that the wooden joists in your home are sucient-
ly strong to take a wood stove and chimney. The wood
stove and chimney can normally be placed on ordinary
wooden joists in a house if the total weight does not
exceed 400 kg.
Hearth
Embers falling from the stove constute a re risk. If you
have a ammable oor in front of your wood stove, it
must be protected with a hearth area covering at least
300 mm to the front of the re door and 100 mm to
either side. The hearth may be made of real stone, con-
crete, sheet metal or glass, for example.
The safety clearances given in this manual apply to the
Swedish market. If the wood stove is installed in another
country, the local regulaons must be observed.
WARNING! THE WOOD STOVE CAN GET VERY HOT
When you light the stove, some surfaces can get very hot and could cause burns on contact. Beware
also of the intense heat which radiates through the glass door. If ammable material is placed closer
than the specied safety clearance, it could catch re quickly. Smouldering can cause sudden ignion
of gas with a risk of personal injury and material damage.
NOTE:
The installaon must be inspected by a qualied
chimneysweep before the wood stove is used.

5
WHAT COMES WITH THE WOOD STOVE?
Check that all parts are included in the package.
12 3
TIP:
The pallet is classed as untreated wood. Corrugated cardboard goes into card and plasc tape into
the combusble bin at the recycling centre.
5
4
6 7 8 9
Produkt:
Oden 6300
DOP: Nr 2
Josef Davidsson´s Eftr. AB
Box 42
330 21 REFTELE
Sweden
Typ/Type/Type:
Raumheizer/Radiator/
Kamin
Brenstoff/Fuel/Bränsle:
Scheitholz/Log wood/
Vedbränsle
Nennwärmeleistung/
Nominal heating capacity/No-
minell värmekapacitet: 6 kW
Mindestabstände/
Least distances/
Minimiavstånd brännbart
Seitenwand/
Side wall/
Sida:300mm Konvektion
300mmTäljsten
500mmStrålning
Rückwand/
Back wall/
Bakåt: 100mm
CO-Emission/
CO emissions/
Utsläpp av CO: 0,09%
Wirkungsgrad/
Efficiency/
Verkningsgrad: 82%
Abgastemperatur/
Flue gas temperature/
Rökgastemperatur: 229 0C
Staub/
Dust/
Partikel: 37 mg/m3
Serielle/
Serial/
Serienr:
Jahr/Year/Tillv.år:
Zeitbrandfeuerstätte/
Time fire heat/
Sekundär värmekälla
Ausschließlich empfohlene Brennstoffe
verwenden/Exclusively recommended fuels
use/Endast för vedeldning
Mehrfachbelegung des Schorsteins ist
Zulässig/Multiple allocation of the chimney
is allowed/Tillåten för skorsten med flera
eldstäder
Standard/
Standard/
Standard:
Lesen und Befolgen Sie die
Bedienungsanleitung/Reading and obeying
the operating instructions/Läs och följ
eldningsinstruktioner i manualen
13 1015
EN 13240
§15s
DIN+
BimschV. 1+2
1. Installaon instrucons
Guide to installing and maintaining your wood stove.
2 .Fire cement
Sealant for connecon to chimney.
3. Stove black
Black polish for maintenance and care of the stove.
4. Ash pan
Collects ash le over from burning.
5. Lining sleeve (for rear connecon)
For ng instrucons, see page 10.
6. Connecng pipe (for rear connecon)
For ng instrucons, see page 10.
7. Oval sleeve (for top connecon)
For ng instrucons, see page 10.
8. CE mark
Guarantees that the product sases all essenal
health and safety requirements under the Construcon
Products Direcve. Placed on the boom of the heat
deector.
9. Poker
Praccal poker included.
A. With Viking 30.
B. With JD 320.
A B

6
JD 320/VIKING 30 WOOD STOVE
DIMENSIONS AND INSTALLATION
The pictures show the major dimensions required for
correct installaon and opmum funcon.
All dimensions are given in millimetres.
NOTE:
Remember that the hearth plate (oor protecon) must reach at least 300 mm to the front and at least
100 mm to the sides of the re door.
150 mm
Brännbar vägg
300 mm
125 mm
300 mm
170 mm
620 mm
315 mm
Brännbar vägg
50 mm
125 mm
100 mm
Luftspalt 5–10 mm
Brännbar vägg
50 mm
125 mm
Luftspalt 5–10 mm
100 mm
*Connecon for outdoor air. Connecng sleeve for outdoor air, Ø 60 mm.
Front viewSide view, rear conneconSide view, top connecon
Ext. Ø 60 (outdoor air connecon) Ext. Ø 60 (outdoor air connecon)
VIKING 30/JD 320
850–900 mm (900–920 mm with extension set)

7
Installaon clearances
Observe the safety clearances for installaon.
Lowest possible ceiling height for proper safety
clearance is 2000 mm.
In front of the wood stove there must be a clearance of
at least 1,000 mm to ammable material.
The clearances relate to installaon with an insulated
outlet pipe.
Uninsulated outlet pipes must have a clearance of at
least 500 mm to ammable material.
The stove has been tested and approved with 50 mm of
lightweight concrete or similar material as a rewall.
In a diagonal posion, remember that the dimensions
are always taken from the centre of the outlet pipe.
Between the stove and any wall cabinet there must be
a safety clearance of at least 1,000 mm and 150 mm to
the sides.
Always contact your chimneysweep if you are unsure of
how to posion and install your stove.
150 mm
Flammable wall
300 mm
125 mm
300 mm
170 mm
620 mm
315 mm
Flammable wall
50 mm
125 mm
100 mm
Air gap 5–10 mm
Flammable wall
50 mm
125 mm
Air gap 5–10 mm
100 mm
Flammable wall
Front view
Minimum clearance to amma-
ble material above the stove:
1,000 mm
Min. 50 mm
lightweight
concrete
Min. 50 mm
lightweight
concrete
Air gap
5–10 mm
Air gap
5–10 mm
100 mm
IMPORTANT:
Between the stove and any insulang material (light-
weight concrete etc.) there must be an air gap of 5–10
mm.

8
ABOUT THE JD 320/VIKING 30
Manufacturer’s warranty
This product has been manufactured in accordance with
the type approval document for the product, which
includes the installaon and maintenance instrucons as a
related document.
General
The JD 320/Viking 30 is made of heavy cast iron and the
rebox is lined with vermiculite. Between the vermiculite
lining and the thick cast iron sides there is an air gap, with
oval holes in the top, providing for good circulaon of air
to prevent overheang of the sides. With its heat-retaining
materials, the stove gives o good aer-heat for several
hours aer it stops burning.
The re door is provided with a window of ceramic-hard-
ened glass to view the re. Thanks to the ght covers and
the special supply of air to the re, the stove maintains a
maximum heat output and low wood consumpon. The
wood burns when the supply of secondary air
ows through the holes in the vermiculite sides and
through primary air supplied when the re door is ajar in
the lighng-up phase. The JD 320/Viking 30 is ed with a
throle valve and a removable hotplate.
Adjustable stove height
The total height of the stove is adjustable between 850
and 900 mm (900–920 mm with an extension set). Li
the front of the stove so it rests on the rear screw feet to
make it easier to adjust the front feet, and vice versa. The
screw feet can be ne-adjusted from inside with a sloed
screwdriver. The four screw feet have an M12 thread and
take a 12 mm spanner.
When the wood stove has been adjusted to the right
height and is standing in the right place, the plinth can be
screwed on. The long sides are slightly curved, enabling
them to t ghtly around the stove and hold the plate
securely in place.
850–900 mm (900–920 mm with extension set)
Plinth

9
If you have connected outdoor air, you can reg-
ulate the supply of air here with the aid of the
supply air knob. When outdoor air is connected,
the valve on the lower door should be closed.
OPERATION OF YOUR
JDE 320/VIKING 30
Convecon air
Apart from radiang heat, the JDE 320/Viking 30 is also
designed for convecon. That means that the cool am-
bient air is sucked in to the sides of the stove, heated up
and pushed through the oval holes in the top to ow out
into the room. This makes the sides of the stove cooler
and heats a larger area around the stove.
Combuson air
The primary air is supplied when the re door is le ajar as
wood is fed in and during the lighng-up phase. The sec-
ondary air is supplied through the rotary valve on the lower
door and through a fresh air intake under the stove. The
secondary air is then heated up in the stove and passes into
the re through the holes in the vermiculite in the rebox.
Heated ambient air
Ambient air
Ambient air
Secondary air
valves
64 Ø mm
Secondary air and
connecon to
outdoor air
Airpipe

10
INSTALLATION AND CONNECTION
The wood stove meets the requirements for connec-
on to chimneys designed for a smoke temperature of
350°C.
The connecng sleeve measures 125 mm on the out-
side, and can used for both rear and top connecon. For
top connecon, the connecng sleeve adds 50 mm, so
the starng height is 50 mm above the grate.
When an uninsulated 125 mm outlet pipe is used, the
pipe passes out of the back of the stove. For top connec-
on with an insulated outlet pipe, remember that this
scks out behind the stove.
The opmum chimney draught is between –10 and
–15 Pa. The draught is mainly aected by the length and
area of the chimney, and also by how pressure-ght it
is. The minimum recommended chimney length is 3.5 m
and a suitable cross-seconal area is 120–180 cm² (125
mm in diameter).
A ue with sharp bends and horizontal secons will re-
duce the draught in the chimney. The maximum horizon-
tal ue length is 500 mm, provided that the vercal ue
length is at least 5 m.
It should be possible to sweep the whole length of the
ue, and the soot hatches should be easy to get at.
Check that the chimney is ght and that there are no
leaks around soot hatches and ue joints. The wood
stove may be connected to a chimney with other stoves.
Important:
With a top connecon, the rst pipe must have a soot
hatch to allow for sweeping.
12
3 4
Carefully cut a hole where you want to
connect your stove to the chimney stack.
Plug with oakum between the ue and
the lining sleeve.
All chimney accessories can be obtained from your nearest dealer.
Close with a ue ring to cover the
installaon.
Cement in the lining sleeve.
CONNECTING THE WOOD STOVE TO AN EXISTING CHIMNEY
NOTE:
Steps 3 and 4 apply to top connecon to an exisng chimney. To connect straight back to an exisng chim-
ney, do not use oakum but use the re cement supplied instead.
