Journey so lite Portable Lift User manual

PRODUCT MANUAL
Portable Lift
so lie
Instruction for Use
Mini Portable Lift
Before using this product, the user is directed to read the instructions carefully and pay special
attention to the designated ※ sections to ensure correct operation.
Instruction for Use
Mini Portable Lift
Before using this product, the user is directed to read the instructions carefully and pay special
attention to the designated ※ sections to ensure correct operation.

2
Portable Lift
so lie
CONTENTS
1
Contents
I. Introduction and Notes .............................................................................................................. 4
II. Product Description .................................................................................................................... 6
III. Technical Specifications .............................................................................................................. 7
IV. Instructions for Use .................................................................................................................... 8
4.1. Instructions ..................................................................................................................... 8
4.2. Charger LED Indicator ................................................................................................... 15

3
Portable Lift
so lie
I. INTRODUCTION AND NOTES
2
1. Introduction and Notes
This is an electric lift with casters. It can be raised and lowered from 9.1 in to 35.8 in. The
maximum loading weight is 110.2 lbs and the height of the object/goods to be weighed should be
less than 19.7 in. Use this lift only on level ground.
※ NOTES:
1. Take the lift to a level place. Connect the remote control cable and the battery cable as shown
before attempting to operate the unit.
2. Lock the lift in place with the caster brake before beginning the lifting operation

4
Portable Lift
so lie
I. INTRODUCTION AND NOTES
3
3. Place the object/goods to be weighed on the center of the lift, and buckle it with the safety
belt before operation.
4. When the lift is in operation, the anti-tipping rod at the bottom will extend out, so the user
must be careful to avoid tripping on it when walking around the lift.

5
Portable Lift
so lie
II. PRODUCT DESCRIPTION
4
2. Product Description

6
Portable Lift
so lie
III. TECHNICAL SPECIFICATIONS
5
3. Technical Specifications
SPECIFICATION
Product Weight
28.7 lbs with battery
26.5 lbs without battery
Max Capacity 110.2 lbs
Platform Dimensions (LxW) 29.8 x 19.3 in
Raised Dimensions to Max Height (LxWxH) 29.8 x 19.3 x 35.9 in
Folded Dimension (LxWxH) 32.8 x 19.3 x 8.9 in
Motor DC motor 24V, 8000N
Battery Li-ion Battery 24V, 3.5AH
Charger 29.4V, 1.5A
Wheel Size 2” for main wheels
1” for extending rods
Wheel Material Rubber
Frame Material Aluminum Alloy
Platform Material ABS (with safety belt)
Remote Control Wired with two-button

7
Portable Lift
so lie
IV. INSTRUCTIONS FOR USE
6
4. Instructions for Use
4.1. Instructions
The following instruction is for lifting an electric wheelchair, as an example. But this lift works
equally well for lifting a variety of mobility aids such as foldable scooters and power chairs, as well
as for luggage, groceries, etc.
1.1.1. Procedure for lifting a wheelchair into a trunk
STEP 1
Step on the brakes on four
casters, to ensure that the
wheels cannot turn.
STEP 2
Unbuckle the safety belt, letting
the straps dangle off the edges so
they won’t be caught beneath
the chair. Place the wheelchair on
the lift as shown.
STEP 3
Place the wheelchair on the lift
as shown.

8
Portable Lift
so lie
IV. INSTRUCTIONS FOR USE
7
STEP 4
Maneuver the chair as necessary
to get it at the center of the
tabletop, with its wheels aligned
with the edge of the tabletop.
Then buckle the safety belt
around it.
STEP 5
Remove the remote control from
the side bag, and keep pressing
the Up button until the tabletop
is raised to reach the bottom
level of the trunk.
STEP 6
If you need to reposition the lift
at this point for better access to
the trunk, step on the four caster
wheels to release the brakes so
that you can move the lift to a
more advantageous position
nearer the trunk.
STEP 7
If you released the brakes in Step
6, reapply them now by stepping
down on the caster wheels. As
shown in the picture, readjust
the lift height to level where the
wheelchair will be able to slide
over into the trunk.

9
Portable Lift
so lie
IV. INSTRUCTIONS FOR USE
8
STEP 8
At this point, place the remote
control into the side bag to
prevent it from being damaged as
the wheelchair is shifted from lift
to trunk
STEP 9
Unbuckle the safety belt and,
grasping the chair with both
hands, gently push it into the
trunk, making sure it settles in
securely.
STEP 10
Retrieve the remote control from
the side bag. Keep pressing the
Down button until the lift is fully
lowered and folded down.

10
Portable Lift
so lie
IV. INSTRUCTIONS FOR USE
9
STEP 11
Place the remote control back in the
side bag, and buckle the safety belt.
STEP 12
Place the lift into the trunk alongside
the wheelchair if there’s room, or into
the back seat or wherever you wish to
secure it for transport.

11
Portable Lift
so lie
IV. INSTRUCTIONS FOR USE
10
1.1.2. Procedure for removing the wheelchair from the trunk
STEP 1
Push the lift near the vehicle trunk,
and remove the remote control from
the side bag.
STEP 2
Keep pressing the Up button until the
tabletop is about 2 in higher than the
bottom surface of the trunk.

12
Portable Lift
so lie
IV. INSTRUCTIONS FOR USE
11
STEP 3
Step on the brakes on all four casters,
to ensure that the wheels cannot turn.
STEP 4
As shown, grasp both sides of the
wheelchair and ease it from the trunk
onto the lift.
STEP 5
As shown, slide the wheelchair along
the tabletop until it’s centered and its
wheels are aligned with the edge of the
tabletop. Then buckle the safety belt.

13
Portable Lift
so lie
IV. INSTRUCTIONS FOR USE
12
STEP 6
Release the brakes on all the lift
casters.
STEP 7
Move the lift away from the vehicle,
being careful that it does not collide
with the vehicle during the lowering
process. To lower, keep pressing the
Down button on the remote control,
until the lift is fully lowered and fully
folded down.
STEP 8
Unbuckle the safety belt.

14
Portable Lift
so lie
IV. INSTRUCTIONS FOR USE
13
STEP 9
In order to get the wheels of the chair
on the ground, first grasp the top of
the wheelchair firmly, raising it slowly
and easing the wheel-end (bottom) of
the chair over the edge of the lift to
the ground.
STEP 10
Buckle the safety belt
STEP 11
Collect and place the remote control
and charger into the side bag, and
buckle the safety belt. Place the lift
the trunk or at some other desired
location.

15
Portable Lift
so lie
IV. INSTRUCTIONS FOR USE
14
※
NOTES:
1. When placing the wheelchair on the lift, make sure that it is situated securely in place.
2. When using the lift, be sure to brake all four casters in order to keep the lift securely in place
during the lifting and lowering process. It is also helpful to keep one hand on the wheelchair
during lifting or lowering.
3. Once the wheelchair has been removed and the operation is complete, be sure to place the
remote control into the side bag to avoid its being broken or damaged.
4.2. Charger LED Indicator
1. As shown, connect one end of the charger to the battery and the other end to the outlet. The
red light on the charger indicates that it is charging, and the green light indicates that it is
fully charged.
※ NOTES:
1. If the battery has not been charged for a long time, make sure to fully charge it before attempting to use the
lift. Charge the battery at least once a month, and each time when you charge it, keep charging until the light
turns green.
2. The battery must be charged with a matching charger to avoid battery damage.
3. The charging environment must be dry, ventilated and free of flammable and explosive materials to prevent
fire.
4. The avoid battery damage, do not use this battery in other equipment.
5. The battery should be immediately recharged after use.

If you have any questions, call us at our toll free number:
1-800-958-8324
