2
3
4
5
6
7
8
910
12
11
13 14 15 16
1
4
DAssembly
1. Fit the gear box onto the rear
axle from the Left Side.
2. Slide a wheel onto the rear axle.
and make the wheel match with the
bushing.
3. Slide another bushing, and make
it match with the wheel also.
4. Slide a Φ10 washer onto the rear axle.
5. Insert a split pin into the hole at the end of the
rear alxe, bend the ends of split pin back using a
long nose pliers.
6. Fit the wheel cover ring to the wheel cover.
7. Fit the wheel cover to the wheel.
9. Slide a Φ10 washer onto the rear axle.
10. Slide a iron tube onto the rear alxe.
11. Slide a wheel onto the rear axle.
12. Slide a bushing onto the rear axle. Also make it match with the wheel.
13. Slide a Φ11 washer onto the rear axle.
14. Insert a split pin into the hole at the end of the rear alxe, bend the ends of split
pin back using a long nose pliers.
15. Fit the wheel cover ring to the wheel cover.
16. Fit the wheel cover to the wheel.
1WD
