Joyside JS-OH-Z03 Series User manual

1
INSTRUCTION MANUAL
Joyside Standing Heater
Series JS-OH-Z03
IF YOU PURCHASED THE GREENHOUSE ONLINE AND HAVE ANY
QUESTION OR CONCERNS
PLEASE CONTACT US WITH EMAIL OR WHATS APP
[e-mail].
WhatsApp QR Code

Owner’s Manual
DANGER
WARNING
WARNING
WARNING
If you smell gas:
1. Shut off gas to the appliance.
3. If odor continues, keep away from
the appliance and immediately call
Do not store or use gasoline or other
vicinity of this or any other appliance.
An LP-cylinder not connected for use
shall not be stored in the vicinity of
this or any other appliance.
Improper installation, adjustment, alteration, service or maintenance can cause injury or
property damage. Read the owner’s manual thoroughly before installing or servicing this
result causing property damage, personal injury or loss of life.
For outdoor use only.
Save these instructions for future use. If
you are assembling this unit for someone
else, give this manual to him or her and
read and save for the future.
Model No.：PH02-S/CAPH-7SMOCHA/CAPH-7-S
/CAPH-7-SB/ CAPH-7-S HB
/v-CAPH-7-S/PH02-SS/CAPH-7-SS
3177588
Intertek
INSISTS ON THE HIGHEST STANDARD OF QUALITY IN MANUFACTURING.
IN CASE OF ANY ISSUES DO NOT RETURN TO STORE.
CALL 1-800-379-2185 OR E-MAIL US AT [email protected] WITH QUESTIONS OR WARRANTY ISSUES.
OUR OFFICE HOURS ARE MONDAY TO FRIDAY 8 AM – 4 PM (PST).
WE WILL BE BACK TO YOU AS QUICKLY AS POSSIBLE.
Model No：JS-OH-Z03A，JS-OH-Z03B
E-MAIL US AT [email protected]
WE WILL BE BACK TO YOU AS QUICKLY AS POSSIBLE.

Page 2
WARNING
Before you assemble or operate this unit, please carefully read this entire manual. Failure to do so
SAFETY INFORMATION
tThe installation of this unit must adhere to local codes or either the National Fuel Gas Code, ANSI
Z223. 1/NFPA54, OR CAN/CGA-B149.1, National Gas and Propane Installation Code.
tTHIS UNIT IS INTENDED FOR OUTDOOR USE ONLY! This product shall be used outdoors, in a
ventilated space and shall not be used in any enclosed area.
tThis unit is to be used with propane gas only! (sold separately)
tDo not attach a remote gas supply to this unit.
tOnly use propane gas for this unit.
tThis unit is not intended for natural gas.
tConverting this unit to natural gas is dangerous and not recommended. The conversion of this unit
will void the manufacturer warranty.
tDo not use any solid fuel or charcoal for this unit.
tIf the propane gas tank is leaking gas, you may hear, see, or smell a hiss. Do the following:
tApplying too much propane may result in gas pooling and will not burn. Allow fresh air into the unit
so that the remaining gas may escape.
t
tThe max. inlet supply pressure: max. Gas supply 11 in w.c. (2.74kPa)
tUse LP propane tanks with the following dimensions: diameter 12 in, height 18 in.
tYou must use a propane tank that has a collar to protect the gas valve.
t
tThe tank system must be set up for vapor withdrawal.
tDiscontinue use if any part of the propane tank is damaged. Rust and dents may be hazardous and
should be inspected by a gas supplier.
tDo not burn anything other than the provided materials for this patio heater.
tDo not operate unit until all parts are fully assembled.
tDo not paint or color any part of this heating unit.
tUnit may be hot while in use, do not attempt to move it while in use.
tNever leave this heating unit unattended while in use.
tThis unit is not intended for cooking.
t
tKeep a safe distance to avoid burning skin or clothing.
tDo not sit or rest hands or feet on this heating unit.
t
tKeep all electrical cords and fuel supply hose away from heated surfaces.
tCombustible material should not be within 24 inches of the top of the unit, or within 36 inches
around the entire unit.
t
vapors and liquids.
t
tDo not add water into the unit.
tDo not operate unit if any part has been under water. Call a service technician to replace any

Page 3
damaged parts should this occur.
• Do not disconnect any part while unit is in use.
• Do not store a spare propane tank on or near this unit.
• If the heating unit is indoors, detach the propane tank and leave outdoors.
•
• Always remove protective cover before operating (if applicable).
• Check for leaks after not using the unit for long periods of time.
• Children should never operate this unit. Children must be supervised while near this unit.
• Keep gas tank at least 5 feet away from unit when lit. (if external tank)
• The maximum gas supply pressure is 250psi.
•
inspected annually and cleaned regularly.
• Inspect all elements of this heating unit before each use. If there is damage, the burner must be
replaced.
• Be aware of the hazards of high temperatures and stay away from the unit to avoid any burns or
injury.
•
of the U.S. Department of Transportation or the National Standard of Canada CAN/CSA-B339, LP gas
tanks, spheres and tubes for Transportation of Dangerous Goods; and Commission.
•
gas tank connection.
•
• Children and adults should be alerted to the hazards of high surface temperatures and should
stay away to avoid burns or clothing ignition.
• Young children should be carefully supervised when they are in the area of the appliance.
•
near the appliance.
• Any guard or other protective device removed for servicing the appliance shall be replaced
prior to operating the appliance.
•
may be required as necessary. It is imperative that the control compartment, burners and
circulating airways of the appliance are kept clean.
NOTE: You must follow all steps to properly assemble this heating item. Make sure the gas
valve is turned “OFF” before assembling. Do NOT attempt to assemble without proper tools.
WARNING: Cancer and Reproductive Harm-www.P65Warnings.ca.gov

Page 4
BE CAREFUL: WHEN CERTAIN MATERIALS OR
ITEMS ARE STORED ABOVE, BESIDE OR UNDER
THIS HEATER WHILE IN USE, THEY WILL BE
SUBJECT TO RADIANT HEAT AND COULD BE
SERIOUSLY DAMAGED.
Combustible materials should not be within 24
inches of the top of the unit, or within 36 inches
around the entire unit.
SAFETY INFORMATION

Page 5
HARDWARE
Before beginning assembly of product, make sure all parts are present. Compare parts with
package contents list and hardware contents list. If any parts are missing or damaged, do not
attempt to assemble the product.
Estimated Assembly Time: 30 minutes
Tools Required for Assembly (not included): Phillips Screwdriver
AA
HH
GG
FFDD
CC
BB
KK
JJ
II MM
LL
EE
Item Description Qty
AA M6x10 Screw 8
BB M6 Nut 14
CC M8 Bolt 3
DD M6x22Bolt 6
EE Wrench 1
FF ReŇector Stud 3
GG Wing Nut 3
HH Washer 6
II Anchoring Arm 3
JJ Anchoring Nut 3
KK Cap Nut 9
LL Small screw 9
MM Webbing 1

Page 6
CONTENTS
Item Description Qty
A ReŇector Panel 3
Center ReŇector 1
C Head Assembly 1
D Post 1
E Tank Housing 1
FPost Support 1
GSupport Legs 1
H Regulator 1
IBase 1
JWheel Assembly 1

Page 7
ASSEMBLY INSTRUCTIONS
I
I
I
1. Align the holes in the wheel assembly (J) with the
holes in the base (I), attach the wheel assembly to
the base using 2 pcs M6x10 screws (AA) and 2 pcs
M6 nuts (BB).
2. Mount the 3 pcs anchoring arms (II) to the
holes on the base (I) using 6 pcs M6x10 screws
(AA) and 6 pcs M6 nuts (BB).
3. Attach the 3 pcs support legs (G) to the top of the
base (I) using 3 pcs M8 bolts (CC).
J
II
JJ
G
I
Optional: If you wish, the patio heater can be
fixed by hammering the 3 pcs anchoring nuts
(JJ) into ground through the anchoring arms
after assembly.

Page 8
ASSEMBLY INSTRUCTIONS
4. Attach the post support (F) to the top of the support
legs (G) using 6 pcs M6 x 22 bolts (DD) and 6 pcs M6
nuts (BB).
5. Place the tank housing (E) on top of the assembly.
F
G
E
6.
(FF) into the top holes of the head assembly (C).
C
FF

Page 9
KKB
AAA
7. -
semble the outer rim using one small screw (LL)
and one cap nut (KK). Repeat this step with the
three M6 screws (AA) and three cap nuts (KK).
Tighten all screws tightly.
!!!gggnnniiilllbbbmmmeeesss
WARNING
8.
ers (HH) and three wing nuts (GG).
9.Unscrew the four screws that are preas-
sembled on the head assembly (C). Place the
head assembly (C) into the top of the post (D) by
inserting the regulator (H) into the post (D).
Tightly fasten the previously removed screws
back into the head assembly (C) through the
slots at the top of the post (D).
C
CH
D
FF
HH
GG
