JMA-5312-6/6HS
JMA-5322-7/9/6HS
JMA-5332-12
SIMPLIFIED MANUAL
1INTRODUCTION ..................................................................................................S-1
1.1 READ ME..................................................................................................S-1
2BASIC OPERATION.............................................................................................S-2
2.1 OWER ON AND START THE SYSTEM .................................................S-2P
2.2 END THE OPERATION AND POWER OFF .............................................S-3
2.3 ADJUST MONITOR BRILLIANCE [BRILL]..............................................S-3
2.4 HANGE OBSERVATION RANGE [RANGE + / - ]..................................S-4C
2.5 ADJUST GAIN [GAIN / PL] ......................................................................S-4
2.6 SUPPRESS SEA CLUTTER [AUTO-SEA] ...............................................S-4
2.7 UPPRESS RAIN / SNOW CLUTTER [AUTO-RAIN] ..............................S-6S
2.8 USING ELECTRONIC BEARING LINE (EBL1 / EBL2)............................S-7
2.9 USING VARIABLE RANGE MARKER (VRM1 / VRM2) ...........................S-9
2.10 SWITCH TRANSMITTER PULSE LENGTH [GAIN / PL] .......................S-10
2.11 SWITCH AZIMUTH DISPLAY MODE [AZI MODE] .................................S-10
2.12 SWITCH TRUE / RELATIVE MOTION DISPLAY MODE [TM / RM] ....... S-11
2.13 DISPLAY RADAR TRAILS [TRAILS] .....................................................S-12
3TARGET TRACKING OPERATION ...................................................................S-13
3.1 CQUIRING TARGET [ACQ] .................................................................S-13A
3.2 ISPLAY TRACKED TARGET DATA [TGT DATA] ................................S-13D
3.3 CANCELING TRACKED TARGETS [TGT CNCL] .................................S-14
4AIS OPERATION................................................................................................S-15
4.1 SETTING AIS DISPLAY FUNCTION (AIS FUNCTION)..........................S-15
4.2 ACTIVATE AIS TARGETS (ACT AIS) .....................................................S-15
4.3 ISPLAY ACTIVATED AIS TARGET DATA[TGT DATA] ........................S-16D
4.4 DEACTIVATE AIS TARGETS (DEACT AIS) ...........................................S-17
5TARGET TRACKING / AIS COMMON OPERATION .........................................S-18
5.1 ETTING VECTORS (VECTOR).............................................................S-18S
5.2 SETTING COLLISION DECISION CRITERIA (CPA / TCPA LIMIT) .......S-19
6OTHER CONTENTS ..........................................................................................S-20
6.1 ESET ALARM BUZZER [ALARM ACK] ..............................................S-20R
6.2 OPERATION ON NUMERIC VALUE INPUT MENU ...............................S-20
