JCY-1800/1850

Record of Revisions
VDR/S-VDR Real Time Monitor / Installation Manual
i
Record of Revision
Rev Description Date Approved by Checked by
1.0 First Edition 07-Feb-1st M.Takayama R.Uchijima
1.2 Added example of connection 07-Jul-23rd M.Takayama R.Uchijima

Before Using
VDR/S-VDR Real Time Monitor / Installation Manual
ii
< Before Using >
Icons
This manual and product employ various icons to enable users to use the product safety and
correctly, and to prevent any harm to users or others, and to prevent damage to the property.
The icons and the meanings are indicated below.
Example of icons
The △symbole indicates a caution (including danger or warning).
Inside of the symbol indicates the actual details (this icon indicates the
caution regarding electric shock).
The symbol indicates prohibition.
The actual contents (this icon indicates “disassembly prhibited”) are
provided inside or alongside of the symbol
The ●symbol indicates an action or insutruction. The actual contenst (this
icon indicates removal of the power plug from socket) are provided inside of
the symbol
Electric
shock
Disassembly
prohibited
Remove
Plug
WARNING Incorrect use of the equipment by ignoring this icon may cause death
or a seruous injury.
CAUTION
Incorrect use of the equipment by ignoring this icon may cause an
injury or physical damage.

Notes on Using
VDR/S-VDR Real Time Monitor / Installation Manual
iii
< Notes on Using >
Do not disassemble or remodel this equipment.
Such action may cause fire, electric shock, or an equipment fault.
Do not use any AC/DC adaptor other than attachment.
Such action may cause fire, electric shock, or an equipment fault.
Do not use any power supply voltage other than the specified voltages.
Such action may cause fire, electric shock, or an equipment fault.
Do not use any battery other than specification.
Such action may cause burst of a battery by liquid leak, fire, or injury.
Do not put containers into which it went, such as water, or a small metal thing on
this equipment top or near.
When water enters or a metal thing falls into the equipment, it becomes the cause
of a fire, an electric shock, and failure.
Do not damage a power cord or process it.
If put a heavy thing, heat, it pulls or it bends by force, a power cord will be
damaged and it may become the cause of fire and electric shock.
When a fault occurs, turn off the power supply of this equipment, remove the plug,
and contact the Sales Department of Japan Radio Company, nearest branch
company, branch office, sales office, or our agent.
Continuous use may cause fire or electric shock.
Do not check or repair the inside of the equipment by yourself.
Checking or repair by anyone other than the specialist maintenance staff may
cause fire or electric shock.
Request checking or repair of the inside of the equipment to the sales Department
of Japan Radio Company, nearest branch company, branch office, sales office, or
our agent.

Before Using
VDR/S-VDR Real Time Monitor / Installation Manual
iv
CAUTION
Do not install the equipment in the location affected by water, humidity, dust, or
soot. It may become the cause of fire, electric shock, or a fault.
Do not put in from a vent foreign substance, such as metal or a thing which is
easy to burn.
It may become the cause of fire, electric shock, or a fault.
Do not put on a place with many vibration and shocks.
It may fall and may become the cause of an injury and failure.
Do not wet this equipment or do not put in water.
It may become the cause of electric shock, or a fault.
Do not plug up the vent of this equipment.
It may be filled with heat and fire and failure may occur.
When the equipment is not used for a long time, pull out a power supply plug
from a wall socket for safety.
It may become the cause of fire or electric shock.
Pull out a plug from a wall socket for safety at the time of care.
It may become the cause of fire or electric shock.
Be careful of a computer virus.
If a computer is infected with a virus, it may suffer the damage of an unusual
display, a program, and data being destroyed, and may become the cause of
failure.
Please confirm whether it is infected with the computer virus, using a virus
checker program periodically.

Contents
VDR/S-VDR Real Time Monitor / Installation Manual
v
<Contents>
< Before Using > ...................................................................................................................... ii
< Notes on Using >.................................................................................................................. iii
Chapter1 Installation Procedure...............................................................................................1
Chapter2 System Composition.................................................................................................3
2.1 Basic Composition ......................................................................................................................... 3
2.2 In case of connecting with user LAN ............................................................................................. 4
2.3 In case of connecting with Radar IF (NWP-46) ............................................................................. 5
Chapter3 Wiring Diagrams .......................................................................................................7
Chapter 4 Wiring ....................................................................................................................11
4.1 In case of JCY-1800 VDR ........................................................................................................... 11
4.2 In case of JCY-1850 S-VDR........................................................................................................ 12
4.3 Wiring to VDR IF（Router）........................................................................................................ 13
Chapter5 Setup VDR/S-VDR by Maintenance software ........................................................15
Chapter6 PC (Server/Client) Setup ........................................................................................19
6.1 PC Specification .......................................................................................................................... 19
6.2 Setup Items of PC........................................................................................................................ 19
6.2.1 Set the IP address .............................................................................................................................. 19
6.2.2 Stop automatic synchronization with an Internet time server .............................................................. 23
6.2.3 Stop the Remote Assistance............................................................................................................... 24
6.2.4 Stop the Automatic Updates ............................................................................................................... 26
6.2.5 Stop the Error Reporting ..................................................................................................................... 28
6.2.6 Invalidate the Windows Firewall.......................................................................................................... 31
6.2.7 Set the Power Options ........................................................................................................................ 35
6.3 Install the VDR/S-VDR Real Time Monitor software ................................................................... 37
6.4 Uninstall the VDR/S-VDR Real Time Monitor software............................................................... 41
6.5 Initial setup for the VDR/S-VDR Real Time Monitor.................................................................... 42
6..5.1 Setup.................................................................................................................................................. 43
Chapter7 Final Check.............................................................................................................57
Chapter8 Trouble Shooting ....................................................................................................59

Contents
VDR/S-VDR Real Time Monitor / Installation Manual
vi
Chapter9 Appendix.................................................................................................................61
9.1 How to eject CF card from VDR/S-VDR ...................................................................................... 61
9.2 Example of connection ................................................................................................................ 63
9.2.1 Example1 In case of only one VDR/S-VDR Real Time Monitor........................................................ 65
9.2.2 Example2 In case of connecting with Client PC ............................................................................... 70
9.2.3 Example3 In case of connecting with Client PC and Radar IF ......................................................... 78
9.2.4 Example4 In case of connecting with Client PC ............................................................................... 88
9.2.5 Example5 In case of connecting with Client PC and VDR IF............................................................ 98
9.2.6 Example6 In case of connecting with Client PC ............................................................................. 110
9.2.7 Example7 In case of connecting with Client PC and Radar IF ....................................................... 123
9.3 Hyper Terminal Setup................................................................................................................ 142
9.3.1 Starting.............................................................................................................................................. 142
9.3.2 End144
9.4 Installation Flow for Server PC .................................................................................................. 145
9.5 Installation Follow for Client PC................................................................................................. 146

Chapter1 Installation Procedure
VDR/S-VDR Real Time Monitor / Installation Manual
1
Chapter1 Installation Procedure
General Procedure
(1) Mounting the necessary unit
(2) Wiring the cable connected unit in according with installation drawings
(3) Checking wiring condition
(4) Setup of VDR/SVDR by Maintenance software
(5) Setup of PC in which the VDR/S-VDR Real Time Monitor is installed
(6) Final check
When Radar IF is connected to VDR/S-VDR, VDR IF (Router)
should be connected for separation between Radar IF and user
LAN.
The Firewall of the VDR IF unit is invalidated beforehand at factory
shipment.
If the operation check is completion, the firewall should be
validated.
Attention
Note
This installation manual is described for version 1.2 of VDR/S-VDR
Real Time Monitor software.
Since the VDR IF (Router) model is changed from AR410 to
AR415S, do not mistake it.
Attention
To set up the VDR/S-VDR for VDR/S-VDR Real Time Monitor, use
the latest Maintenance software (Ver. 1.2.0A).
If your Maintenance software is old version, download the latest
version from Marin Service Home Page.
Attention

Chapter1 Installation Procedure
VDR/S-VDR Real Time Monitor / Installation Manual
2
Blank Page
