Ju-soft HQP-1072SD Installation manual
HQP-1072 Series System
User Guide
HQP‐1072SystemUserGuide
2
Table of Contents
HQP-1072 Hardware User Guide ....................................................................3
1. HQP-1072 system Introduction ....................................................................4
1.1 Box Contents ..........................................................................4
1.2 Specification............................................................................6
1.3 Appearance.............................................................................8
2. Setting Up...................................................................................................10
2.1 Connect Power Cord.............................................................10
2.2 Connect Monitor/Keyboard/Mouse........................................10
2.3 Power On the System ...........................................................10
3. Installing the Server in a Rack....................................................................12
3.1 Installing the Server into the Rack ........................................12
4. System Maintenance..................................................................................14
4.1 Replacing Hard Disk .............................................................14
4.1.1. System Hard Disk Failed..............................................14
4.1.2. Data Drive Failed .........................................................26
4.2 Replacing Power Supply.......................................................34
4.3 Replacing System Fan..........................................................36
4.4 Routine Maintenance Work...................................................38
5. Spare Parts ................................................................................................39
5.1 System Backup SSD.............................................................39
5.2 Data Hard Disk......................................................................39
5.3 Power Supply........................................................................40
5.4 System Fan and Fan Housing...............................................40
HQP‐1072SystemUserGuide
3
HQP-1072 Hardware User Guide
Thank you for choosing our HQP-1072 series system!
The HQP-1072 is a full tested 1U server computer which installs
SDI/HD-SDI interface card and HQP-series applications for TV broadcasting.
Different modules are provided, depending on interface card and application
installed.
HQP-1072SD：SD (NTSC/PAL) TV Broadcast Playout
Operation System：Microsoft Windows 7 pro 64-bit
Software：HQP-Bplayer 2.0
Doungle：HQP-Bplayer SD
BMD Decklink Dual module：1 full SD channel
HQP-1072HS：HD/SD Simulcast TV Broadcast Playout
Operation System：Microsoft Windows 7 pro 64-bit
Software：HQP-Bplayer 2.0
Doungle：HQP-Bplayer HS
BMD Decklink Dual module：1 full HD/SD channel
This user guide will help you to setup your HQP-1072 series system
hardware step by step.
According to different application software installed, please check the
software user manual corresponding to each application, that will teach you
how to use our software.
HQP-1072 seriessystemis a dedicated computer for TV broadcasting,
and certain functions are disabled. Please do not execute any other software
which is not relevant. Some customers may install two or more applications on
the same system, please confirm with retailers of Ju-Soft CO., LTD whether
they can be simultaneously executed.
HQP‐1072SystemUserGuide
4
1. HQP-1072 system Introduction
1.1 Box Contents
Each HQP-1072 System has a complete burn-in test before delivery. Hard
drives are preinstalled in the server；please check if they are present and
undamaged once you open the package.
Open the box and ensure the listed items are present. If not, please
contact your retailer immediately.
1. HQP-1072 System 1U rack-mount server *1, with installation serial
number of Windows-7 on the chassis cover.
2. One 2.5” SSD 60GB (SLC) system hard drive is pre-installed in the
chassis.
3. Two 2.5” SATA 1GB data hard drives are pre-installed in the chassis.
4. CDs and Documents
HQP-1072 System packing list
Windows-7 installation disc
HQP-1072 System installation disc
HQP-1072 System restore disc
47CM
17CM
65CM
HQP‐1072SystemUserGuide
5
Motherboard driver disc
HQP-1072 System warranty document
User Guide
5. Accessories
US type power cord *1
EU type power cord *1
Layer1：CoverLayer
Layer2：HQP‐1072&PowerCord
PowerCord
HQP‐1072SystemUserGuide
6
1.2 Specification
Chassis 1U, 19" Rack-mount
Dimension
Height 1.7＂(43mm)
Width 17.2＂(437mm)
Depth 9.8＂(254mm)
Weight 4.5kg
Front Panel
Buttons Power On/Off button
System Reset button
LED Power LED
Hard drive activity LED
2 x Network activity LED
System Overheat LED
Motherboard
Super X9SPV-LN4F-3QE
CPU Intel® Core(TM) i7-3612QE CPU @ 2.10GHz 2.10GHz
Memory16GB DDR3 1333 ECC
Hard Drives
1 x 2.5” SSD (SLC) hard drive
2 x 2.5" SATA2 hard drives with RAID 1
Expansion Slots
1 x PCI-E 3.0 x16 slot
System Cooling
2 x 40X28MM 4-PIN PWM FAN, 8500 rpm
Power Supply
200W High-Efficiency Power Supply with PFC
AC Voltage 100-240V, 50-60Hz, 2.6Amp Max
HQP‐1072SystemUserGuide
7
Chipset
Intel® QM77 Chipset
Networking
4 x RJ45 LAN ports
1 x RJ45 Dedicated IPMI LAN port
Graphic Intel Integrated Graphics HD 4000
On-Board Input/Output
5 x RJ45 ports (include 1 Dedicated IPMI LAN port)
4 x USB 2.0 ports (4 x rear)
1 x VGA port
1 x COM ports (1 x rear)
Operating System
Windows 7 Professional 64bit
HQP‐1072SystemUserGuide
8
1.3 Appearance
HQP-1072 Series Front View：
1. Control Panel LEDs
The control panel located on the front of the chassis has five LEDs. These
LEDs provide you with critical information related to different parts of the
system.
Overheat/Fan Fail
Status Description
Continuously on and red An overheat condition has occurred.
(This maybe cause by cable congestion.)
Blinking red (1Hz) Fan failure, check for an inoperative fan.
Blinking red (0.25Hz) Power failure, check for an non-operational
power supply.
Solid blue
Local UID has been activated. Use this
function to locate the server in a rack mount
environment.
Blinking blue (300 m/s)
Remote UID is on. Use this function to
identify the server from a remote location.
NIC1
Indicates network activity on LAN1 when flashing.
NIC2
Indicates network activity on LAN2 when flashing.
21
44
3
HQP‐1072SystemUserGuide
9
2. Control Panel Buttons
There are two push-buttons located on the front of the chassis: a reset button
and a power on/off button.
3. HQP Series Number
4. Mounting ears
HQP-1072 Series Rear View：
1. Power Supply
2. COM ports RS232 9-pin
3. LAN port with IPMI
4. PS2 port
5. USB ports * 4
6. LAN ports * 4
7. VGA port D-SUB 15-pin
8. BMD DeckLink dual card
Reset Button
The reset button reboots the system.
HDD
Channel activity for all hard drives. This light indicates hard drive activity on the
system when flashing.
Power
Indicates power is being supplied to the system's power supply units.
This LED should normally be illuminated when the system is operating.
Power Button
This is the main power button, which is used to apply or turn off the
main system power.
1234 6
57
8
HQP‐1072SystemUserGuide
10
2. Setting Up
HQP-1072 System is a rack-mount server, installed on a 19" rack usually.
For the first time, it’s recommended to power on and test the server on the
desk, and then assemble it into the rack after successfully booting the server.
Follow the instructions to check weather it can be turned on and function
normally.
2.1 Connect Power Cord
First, please take the applicable cord (US or Euro type) and connect it to
the power supply connector.
2.2 Connect Monitor/Keyboard/Mouse
PS2 & USB interface are all supported by HQP-1072 Series System.
Please connect your monitor/keyboard/mouse to the HQP-1072 Series
System.
2.3 Power On the System
After the above mentioned peripheral devices are well connected, press
the power button to turn on the server.
When pressing the power button, you will see the LED light flashing and
hear the fan whirling. The fan spins at the highest speed on start-up, but the
server will check the internal temperature later on and automatically lower fan
speed when finding the unnecessity of high fan speed. Therefore, it is normal
that the server works with noise at the beginning.
Power
HQP‐1072SystemUserGuide
11
Booting process of HQP-1072 Series System may takes around 30
seconds. Default login password of the Windows 7 system is “HQP”.
The screenshot will be like this after you log on Windows 7 system:
Now, you can follow the software manual to start the software test of the
HQP-series software, see if the software can function normally.
HQP‐1072SystemUserGuide
12
3. Installing the Server in a Rack
After the server has been testified, please follow the instructions to mount
HQP-1072 system into a Rack to ensure the stability.
3.1 Installing the Server into the Rack
1. Confirm that chassis includes the four mounting screws required to mount
the chassis into a rack.
2. Align the thru holes of the chassis with the thru holes of the rack.
HQP‐1072SystemUserGuide
13
3. Insert the mounting screws into the thru holes in the front of the chassis
and through the thru holes in the rack and secure.
HQP‐1072SystemUserGuide
14
4. System Maintenance
HQP-1072 System is designed and tested under strict quality control for a
long time before delivering to ensure product quality. However, the damages of
components are irresistible since the computers are used continuously without
shutting down. As the test results indicated, the hard drive, power supply unit
and fans account for the most frequently damaged components. The steps to
maintain these three items are therefore specifically described as below.
4.1 Replacing Hard Disk
4.1.1. System Hard Disk Failed
HQP-1072 has one SSD 60GB (SLC) system hard disk and two SATA
1TB data hard disks mirrored as a RAID1 disk array.
If the system hard disk failed, the system will unable to startup. In this
case, please follow the instruction to replace the system hard drive and start
the system restoration.
1. Release these 5 screws to remove the cover of the chassis. (Rear 1,
Left 2, Right 2)
HQP‐1072SystemUserGuide
15
2. You will see there are 2 disk trays in the chassis, one for system disk
and one for data disks.
DATADiskTray
SystemDiskTray
HQP‐1072SystemUserGuide
16
3. Release the 4 screws on the bottom of the chassis to unlock the
system hard disk tray.
4. Release the 4 screws to unlock the abnormal system disk and replace
it with a backup.
5. Screw the system hard disk tray back to the chassis and put the cover
back. After replacing the abnormal system disk, we can start the
system restoration.
ReplacewiththebackupHDD
HQP‐1072SystemUserGuide
17
6. System restoration
Please prepare an external DVD-ROM drive and connect it to the
HQP-1072 system. Insert the win7 installation disc then restart the system.
Follow the step below to start the system restoration.
Windows will first start loading files needed for system restoration.
Please click Next to go to the next step.
HQP‐1072SystemUserGuide
18
Please click Repair your computer.
When you see this page, please take out the Window7 installation disc
and put the Restore CD disc 2/2 into the DVD-ROM drive. Select the option
Restore your computer using a system image that you created earlier and click
Next.
HQP‐1072SystemUserGuide
19
The system will start scanning for system image backup.
In this page, please select the option Select a system image and click
Next.
HQP‐1072SystemUserGuide
20
Please choose the system image in the DVD-ROM drive and click Next.
Select the date and time of system image and click Next.
This manual suits for next models
1
Table of contents
