Features and specifications
The following information is asummary of the features and specifications of the
server. Depending on the server model, some features might not be available, or
some specifications might not apply.
Table 1. Features and specifications
Microprocessor:
vIntel
®
Pentium
®
4or Celeron
Processor
v1MB Level-2 or 256 KB level-2
cache
v800 MHz front-side bus (FSB) or 533
MHz front-side bus
Note: Use the Configuration/Setup
Utility program to determine the type
and speed of the microprocessor.
Memory:
vMinimum: 256 MB
vMaximum: 8GB
vTypes: PC2-4200, double-data-rate 2
(DDR2) with ECC
vConnectors: four dual inline memory
module (DIMM) connectors, two-way
interleaved
Drives: (depending on your model)
vDiskette: (optional) 1.44 MB (two
mode)
vHard disk drive: SATA
vOne of the following IDE drives:
–CD-ROM
–CD-RW (optional)
–DVD-ROM (optional)
–DVD/CD-RW combo (optional)
Expansion bays: (depending on your
model)
vTwo 5.25-in. bays (one CD or DVD
drive installed)
vOne 3.5-in. removable-media drive
bays (optional)
vTwo 3.5-in. hard disk drive bays (one
hard disk drive installed)
Expansion slots:
vOne PCI Express x1
vOne PCI Express x8
vTwo PCI 32-bit/33 MHz
Video controller:ATI ES1000 video
controller with 16 MB SDRAM video
memory on the system board
Fans: Two speed-controlled fans
Power supply: One 310 watt (90-240 V
ac)
Important: Make sure that the ac power
supply input voltage is set to the right level
(between 110 Vac and 220 Vac) for your
geographic location before powering on
the system.
Size:
vHeight: 438 mm (17.24 in.)
vDepth: 497 mm (19.57 in.)
vWidth: 205 mm (8.07 in.)
vWeight: 14 kg (31 lb) to 17 kg (37.48 lb)
depending upon configuration
Integrated functions:
vBroadcom 5721 10/100/1000 Ethernet
controller on the system board with
RJ-45 Ethernet port
vTwo serial ports
vOne parallel port
vTwo-port Serial ATA controller
vFour Universal Serial Bus (USB) v2.0
ports (two on front and two on rear)
vKeyboard port
vMouse port
vATA-100 single-channel IDE controller
vATI ES1000 video
–Compatible with SVGA and VGA
–16 MB video memory
Diagnostic LEDs:
vFans
vMemory
vMicroprocessor
Acoustical noise emissions:
vSound power, idling: 5.0 bel
vSound power, operating: 5.5 bel
Environment:
vAir temperature:
–Server on: 10° to 35°C (50° to 95°F)
Altitude: 0to 914 m(2998.0 ft)
–Server off: 0° to 60°C (-32° to 140°F)
Altitude: 0to 2133 m(7000.0 ft)
v
Humidity (operating and storage): 8% to
80%
Heat output:
Approximate heat output in British thermal
units (Btu) per hour
vMinimum configuration: 379 Btu (111 watts)
per hour
vMaximum configuration: 853 Btu (250 watts)
per hour
Electrical input:
vSine-wave input (50 or 60 Hz) required
vInput voltage and frequency ranges
manually selected
vInput voltage low range:
–Minimum: 100 Vac
–Maximum: 127 Vac
v
Input voltage high range:
–Minimum: 200 Vac
–Maximum: 240 Vac
vInput kilovolt-amperes (kVA) approximately:
–Minimum: 0.15 kVA (all models)
–Maximum: 0.59 kVA
Notes:
1. Power consumption and heat output vary
depending on the number and type of
optional features installed and the
power-management optional features in
use.
2. These levels were measured in controlled
acoustical environments according to the
procedures specified by the American
National Standards Institute (ANSI) S12.10
and ISO 7779 and are reported in
accordance with ISO 9296. Actual
sound-pressure levels in agiven location
might exceed the average values stated
because of room reflections and other
nearby noise sources. The declared
sound-power levels indicate an upper limit,
below which alarge number of computers
will operate.
