Julabo CF30 User manual

26.06.18
English
Operating
manual
Cryo-Compact Circulators
The Economy-Series
CF30 CF40
1.951.4866-V7 06/18
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

2
Congratulations!
You have made an excellent choice.
JULABO thanks you for the trust you have placed in us.
This operating manual has been designed to help you gain an understanding of the operation
and possible applications of our Cryo-Compact Circulators. For optimal utilization of all
functions, we recommend that you thoroughly study this manual prior to beginning operation.
The JULABO Quality Management System
Temperature control devices for research and industry are developed,
produced, and distributed according to the requirements of ISO 9001
and ISO 14001. Certificate Registration No. 01 100044846
Unpacking and inspecting
Unpack the Cryo-Compact Circulator and accessories and inspect them for possible transport
damage. Damage should be reported to the responsible carrier, railway, or postal authority,
and a damage report should be requested. These instructions must be followed fully for us to
guarantee our full support of your claim for protecting against loss from concealed damage.
The form required for filing such a claim will be provided by the carrier.
Printed in Germany Changes without prior notification reserved
Important: keep original operating manual for future use
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

Cryo-Compact Circulator
3
TABLE OF CONTENTS
Operating manual..................................................................................................... 4
1. Intended use....................................................................................................... 4
1.1. Description ..................................................................................................... 4
2. Operator responsibility – Safety instructions ...................................................... 4
2.1. Disposal ......................................................................................................... 6
2.2. EC Conformity................................................................................................ 7
2.3. Warranty conditions........................................................................................ 9
2.4. Technical specifications ............................................................................... 10
3. Safety notes for the user .................................................................................. 14
3.1. Explanation of safety notes.......................................................................... 14
3.2. Explanation of other notes............................................................................ 14
3.3. Safety instructions........................................................................................ 14
Operating instructions............................................................................................. 17
4. Operating controls and functional elements ..................................................... 17
5. Preparations..................................................................................................... 19
5.1. Installation.................................................................................................... 19
5.2. Temperature application to external, closed systems................................... 20
5.3. Tubing.......................................................................................................... 21
5.4. Bath fluids .................................................................................................... 22
6. Operating procedures....................................................................................... 23
6.1. Power connection......................................................................................... 23
6.2. Filling............................................................................................................ 23
6.3. Switching on / Start - Stop............................................................................ 25
6.4. LControl of the cooling machine ................................................................ 25
6.5. Setting the temperatures.............................................................................. 26
6.6. AUTOSTART ON / OFF............................................................................... 26
6.7. Remote control: activate – deactivate .......................................................... 27
7. Safety installations............................................................................................ 28
7.1. Excess temperature protection.................................................................... 28
7.2. Low level protection...................................................................................... 28
8. Troubleshooting guide / Error messages.......................................................... 29
9. Electrical connections....................................................................................... 31
10. Remote control................................................................................................. 32
10.1.Setup for remote control............................................................................... 32
10.2.Communication with a PC or a superordinated data system........................ 32
10.3.List of commands......................................................................................... 33
10.4.Status messages.......................................................................................... 34
10.5.Error messages............................................................................................ 34
11. JULABO Service – Online remote diagnosis.................................................... 36
12. Draining............................................................................................................ 37
13. Cleaning / repairing the unit.............................................................................. 37
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

Operating manual
4
Operating manual
1. Intended use
JULABO Cryo-Compact Circulators have been designed for temperature application to
specific fluids in a bath tank. The units feature pump connections for temperature control of
external systems (loop circuit).
JULABO circulators are not suitable for direct temperature control of foods,
semi-luxury foods and tobacco, or pharmaceutical and medical products. Direct
temperature control means unprotected contact of the object with the bath
medium (bath fluid).
1.1. Description
PID1
RS232
;The Cryo-Compact Circulators are operated via the splash-proof keypad.
The implemented microprocessor technology allows to set and to store the
setpoint that can be indicated on the LED temperature display.
;The PID temperature control adapts the heat supplied to the thermal
requirements of the bath.
;Safety installations conforming to IEC 61010-2-010
The excess temperature protection is a safety installation independent from
the control circuit.
The safety value is set using a tool (screwdriver).
If the low level protection device is triggered, a complete shutdown of the
heater and circulating pump is effected.
;The serial interface RS232 allows modern process technology without
additional interface.
2. Operator responsibility – Safety instructions
The products of JULABO ensure safe operation when installed, operated, and maintained
according to common safety regulations. This section explains the potential dangers that may
arise when operating the circulator and also specifies the most important safety precautions to
preclude these dangers as far as possible.
The operator is responsible for the qualification of the personnel operating the units.
¾The personnel operating the units should be regularly instructed about the dangers
involved with their job activities as well as measures to avert these dangers.
¾Make sure all persons tasked with operating, installing, and maintaining the unit have read
and understand the safety information and operating instructions.
¾When using hazardous materials or materials that could become hazardous, the circulator
may be operated only by persons who are absolutely familiar with these materials and the
circulator. These persons must be fully aware of possible risks.
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

Cryo-Compact Circulator
5
If you have any questions concerning the operation of your unit or the information in this
manual, please contact us!
Contact:
Safety instructions for the operator:
¾Avoid strikes to the housing, vibrations, damage to the operating-element panel (keypad,
display), and contamination.
¾Make sure the product is checked for proper condition regularly (depending on the
conditions of use). Regularly check (at least every 2 years) the proper condition of the
mandatory, warning, prohibition and safety labels.
¾Make sure that the mains power supply has low impedance to avoid any negative effects
on the instruments being operated on the same mains.
¾This unit is designed for operation in a controlled electromagnetic environment. This
means that transmitting devices (e.g., cellular phones) should not be used in the
immediate vicinity.
¾Magnetic radiation may affect other devices with components sensitive to magnetic fields
(e.g., monitors). We recommend maintaining a minimum distance of 1 m.
¾Permissible ambient temperature: max. 40 °C, min. 5 °C.
¾Permissible relative humidity: 50% (40 °C).
¾Do not store the unit in an aggressive atmosphere. Protect the unit from contamination.
¾Do not expose the unit to sunlight.
Appropriate operation
Only qualified personnel is authorized to configure, install, maintain, or repair the circulator.
Persons who operate the circulator must be trained in the particular tasks by qualified
personnel. The summarized user guidance (short manual) and the specification table with
information on individual parameters are sufficient for this.
Use
The bath can be filled with flammable materials. Fire hazard!
There might be chemical dangers depending on the bath medium used.
Observe all warnings for the used materials (bath fluids) and the respective instructions (safety
data sheets).
Insufficient ventilation may result in the formation of explosive mixtures. Only use the unit in
well ventilated areas.
Only use recommended materials (bath fluids). Only use non-acid and non corroding
materials.
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

Operator responsibility – Safety instructions
6
When using hazardous materials or materials that could become hazardous, the operator
must affix the enclosed safety labels (1 + 2) to the front of the unit so they are highly visible:
1
Warning label W00: Colors: yellow, black
Danger area. Attention! Observe instructions.
(operating manual, safety data sheet)
2
or
Mandatory label M018: Colors: blue, white
Carefully read the user information prior to beginning operation.
Scope: EU
2
Semi S1-0701 Table A1-2 #9
Carefully read the user information prior to beginning operation.
Scope: USA, NAFTA
Particular care and attention is necessary because of the wide operating range.
There are thermal dangers: Burn, scald, hot steam, hot parts and surfaces that can be
touched.
Warning label W26:Colors: yellow, black
Hot surface warning.
(The label is put on by JULABO)
Warning label W017: Colors: yellow, black
Low temperature warning.
(The label is put on by JULABO)
Observe the instructions in the manuals for instruments of a different make that you connect to
the circulator, particularly the corresponding safety instructions. Also observe the pin
assignment of plugs and technical specifications of the products.
2.1. Disposal
The product may be used with oil as bath fluid. These oils fully or partially consist of mineral oil
or synthetic oil. For disposal, follow the instructions in the material safety data sheets.
This unit contains refrigerants, which at this time are not considered harmful to the ozone
layer. However, over the long operating period of the unit, disposal rules may change.
Therefore, only qualified personnel should handle the disposal.
Valid in EU countries
See the current official journal of the European Union – WEEE directive.
Directive of the European Parliament and of the Council on waste electrical
and electronic equipment (WEEE).
This directive requires electrical and electronic equipment marked with a
crossed-out trash can to be disposed of separately in an environmentally
friendly manner.
Contact an authorized waste management company in your country.
Disposal with household waste (unsorted waste) or similar collections of
municipal waste is not permitted!
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

Cryo-Compact Circulator
7
2.2. EC Conformity
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

Operator responsibility – Safety instructions
8
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

Cryo-Compact Circulator
9
2.3. Warranty conditions
JULABO GmbH warrants its products against defects in material or in workmanship, when
used under appropriate conditions and in accordance with appropriate operating instructions
for a period of ONE YEAR.
Extension of the warranty period – free of charge
With the ‘1PLUS warranty’ the user receives a free of charge extension to the warranty of up
to 24 months, limited to a maximum of 10 000 working hours.
To apply for this extended warranty the user must register the unit on the JULABO web
site , indicating the serial no. The extended warranty will apply from the date of JULABO
GmbH’s original invoice.
JULABO GmbH reserves the right to decide the validity of any warranty claim. In case of
faults arising either due to faulty materials or workmanship, parts will be repaired or replaced
free of charge, or a new replacement unit will be supplied.
Any other compensation claims are excluded from this guarantee.
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

Operator responsibility – Safety instructions
10
2.4. Technical specifications
CF30
Working temperature range °C -30 ... +150
Temperature stability °C ±0.03
Temperature selection digital
via keypad indication on LED-DISPLAY
remote control via personal computer indication on monitor
Temperature indication: LED-DISPLAY
Resolution °C 0.1
Temperature control PID 1
Working temperature sensor Pt 100
Safety temperature sensor Pt 100
Heater wattage (at 230 V) kW 2,0
Heater wattage (at 115 V) kW 1,0
Cooling capacity
Medium ethanol °C kW 20 0 -20 0.32 0.25 0.15
Cooling compressor 1-stage
Refrigerant R134a
Cooling machine Air-cooled
Electrical connections:
Computer interface RS232
Pump capacity:
Flow rate max. at 0 bar l/min 15
Pressure max. at 0 liter bar 0,35
Bath opening (WxL) cm 16x3
Bath depth cm 14
Filling volume liters 2.0 ... 3.0
Overall dimensions (WxDxH) cm 24x46x40
Weight kg 35
Ambient temperature °C 5 ... 40
Protection class according to IEC 60 529 IP 21
Mains power connection 230 V/50 Hz V/ Hz 207-253 / 50
Current draw (at 230 V) A 10
Mains power connection 230 V/60 Hz V/ Hz 207-253 / 60
Current draw (at 230 V) A 11
Mains power connection 115 V/60 Hz V/ Hz 103-127 / 60
Current draw (at 115 V) A 13
All measurements have been carried out at: rated voltage and frequency
ambient temperature: 20 °C Technical changes without prior notification reserved.
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

Cryo-Compact Circulator
11
CF40
Working temperature range °C -40 ... +150
Temperature stability °C ±0.03
Temperature selection digital
via keypad indication on LED-DISPLAY
remote control via personal computer indication on monitor
Temperature indication: LED-DISPLAY
Resolution °C 0.1
Temperature control PID 1
Working temperature sensor Pt 100
Safety temperature sensor Pt 100
Heater wattage (at 230 V) kW 2,0
Heater wattage (at 115 V) kW 1,0
Cooling capacity
Medium ethanol °C kW 20 0 -20 -30 0.47 0.4 0.28 0.12
Cooling compressor 1-stage
Refrigerant R404A, R452A*
Cooling machine Air-cooled
Electrical connections:
Computer interface RS232
Pump capacity:
Flow rate max. at 0 bar l/min 15
Pressure max. at 0 liter bar 0,35
Bath opening (WxL) cm 19x3
Bath depth cm 19
Filling volume liters 4.0 ... 5.5
Overall dimensions (WxDxH) cm 28x46x46
Weight kg 41
Ambient temperature °C 5 ... 40
Protection class according to IEC 60 529 IP 21
Mains power connection 230 V/50 Hz V/ Hz 207-253 / 50
Current draw (at 230 V) A 13
Mains power connection 230 V/60 Hz V/ Hz 207-253 / 60
Current draw (at 230 V) A 12
Mains power connection 115 V/60 Hz V/ Hz 103-127 / 60
Current draw (at 115 V) A 16
* at 230 V / 50 Hz
All measurements have been carried out at: rated voltage and frequency
ambient temperature: 20 °C Technical changes without prior notification reserved.
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

Operator responsibility – Safety instructions
12
Warning functions and safety installations
Excess temperature protection adjustable from 0 °C ... 220 °C
Low liquid level protection float switch
Classification according to DIN 12876-1 class III
Alarm message optical + audible (permanent)
Warning message optical + audible (in intervals)
Overload protection for compressor and pump motor
Supervision of working sensor plausibility control
Reciprocal sensor monitoring between
working and safety sensors difference >35 K
Environmental conditions according to IEC 61 010-1:
Use indoors only.
Altitude up to 2000 m - normal zero.
Ambient temperature: see Technical specifications
Humidity:
Max. relative humidity 80% for temperatures up to +31 °C,
linear decrease down to 50% relative humidity at a temperature of +40 °C
Protection class according to IEC 60 529 IP21
The unit corresponds to Class I
Overvoltage category II
Pollution degree 2
Caution:
The unit is not suitable for use in explosive atmosphere
EMC requirements according to EN 61326-1
The device is an ISM device of group 1 per CISPR 11 (uses HF for internal purposes) and is
classified in class A (industrial and commercial sector).
Note!
Devices of class A are intended for the use in an industrial electromagnetic
environment.
When operating in other electromagnetic environments, their
electromagnetic compatibility may be impacted.
This device is not intended for the use in living areas and cannot
guarantee adequate protection of the radio reception in such
environments.
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

Cryo-Compact Circulator
13
Information about the used refrigerants
The Regulation (EU) No. 517/2014 on fluorinated greenhouse gases applies to all systems
which contain fluorinated refrigerants and replaces (EC) 842/2006.
The aim of the Regulation is to protect the environment by reducing emissions of fluorinated
greenhouse gases.
Among other things it regulates the emission limits, use and recovery of these substances. It
also contains requirements for operators of systems which require / contain these substances
to function.
Under Regulation 517/2014, the operator of a system of this nature has the following duties:
xThe operator must ensure that the equipment is checked at regular intervals for leaks.
xThese intervals depend on the CO2equivalent of the system. This is calculated from the
refrigerant fill volume and type of refrigerant. The CO2equivalent of your system is
shown on the model plate.
xThe operator undertakes to have maintenance, repair, service, recovery and recycling
work carried out by certified personnel who have been authorized by JULABO.
xAll such work must be documented. The operator must keep records and archive them
for at least five years. The records must be submitted to the relevant authority on
request.
Refer to the text of the Regulation for further information.
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

Safety notes for the user
14
3. Safety notes for the user
3.1. Explanation of safety notes
In addition to the safety warnings listed above, warnings are posted throughout
the manual. These warnings are designated by an exclamation mark inside an
equilateral triangle. “Warning of a dangerous situation (Attention! Please follow
the documentation).”
The danger is classified using a signal word.
Read and follow these important instructions.
Warning:
Describes a possibly highly dangerous situation. If these instructions are not
followed, serious injury and danger to life could result.
Caution:
Describes a possibly dangerous situation. If this is not avoided, slight or minor
injuries could result. A warning of possible property damage may also be
contained in the text.
Notice:
Describes a possibly harmful situation. If this is not avoided, the product or
anything in its surroundings can be damaged.
3.2. Explanation of other notes
Note!
Draws attention to something special.
Important!
Indicates usage tips and other useful information.
3.3. Safety instructions
Follow the safety instructions to avoid personal injury and property damage. Also,
the valid safety instructions for workplaces must be followed.
xOnly connect the unit to a power socket with an earthing contact (PE –
protective earth)!
xThe power supply plug serves as a safe disconnecting device from the line
and must always be easily accessible.
xPlace the unit on an even surface on a base made of nonflammable
material.
xDo not stay in the area below the unit.
xMake sure you read and understand all instructions and safety precautions
listed in this manual before installing or operating your unit.
xSet the excess temperature safety installation below the flash point of the
bath fluid.
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

Cryo-Compact Circulator
15
xNever operate the unit without bath fluid in the bath.
xPay attention to the thermal expansion of bath oil during heating to avoid
overflowing of the fluid.
xPrevent water from entering the hot bath oil.
xDo not drain the bath fluid while it is hot!
Check the temperature of the bath fluid prior to draining (e.g., by switching
the unit on for a short moment).
xUse suitable connecting tubing.
xAvoid sharp bends in the tubing, and maintain a sufficient distance from
surrounding walls.
xMake sure that the tubing is securely attached.
xRegularly check the tubing for material defects (e.g., for cracks).
xNever operate damaged or leaking units.
xAlways turn off the unit and disconnect the mains cable from the power
source before performing any service or maintenance procedures, or
before moving the unit.
xAlways turn off the unit and disconnect the mains cable from the power
source before cleaning the unit.
xAlways empty the bath before moving the unit.
xTransport the unit with care.
xSudden jolts or drops may cause damage in the interior of the unit.
xObserve all warning labels.
xNever remove warning labels.
xNever operate units with damaged mains power cables.
xRepairs are to be carried out only by qualified service personnel.
xSome parts of the bath tank and the pump connections may become
extremely hot during continuous operation. Therefore, exercise particular
caution when touching these parts.
xSome parts of the bath tank and the pump connections may become
extremely cold during continuous operation. Therefore, exercise particular
caution when touching these parts.
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

Safety notes for the user
16
Caution:
The circulator may be used, for example, to control the temperature of fluids in
a reactor.
We do not know what substances are contained in these vessels.
Many substances are:
xinflammable, easily ignited, or explosive
xhazardous to health
xenvironmentally hazardous
i.e.: dangerous
The user alone is responsible for the handling of these substances!
The following questions should help to recognize possible dangers and to
reduce the risks to a minimum.
xAre all tubes and electrical cables connected and layed?
Note:
sharp edges, hot surfaces in operation, moving machine parts, etc.
xDo dangerous vapors or gases develop during heating?
Must the work be done in a fume hood?
xWhat to do when a dangerous substance was spilled on or in the unit?
Before starting to work, obtain information concerning the substance and
determine the method of decontamination.

Notice:
Check the safety installations at least twice a year!
xExcess temperature protection according to IEC 61010-2-010
With a screwdriver, turn back the adjustable excess temperature protection
until the shutdown point (actual temperature).
xLow level protection according to IEC 61010-2-010
To check the function of the float, it can be manually lowered with a
screwdriver, for example.
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

Cryo-Compact Circulator
17
Operating instructions
4. Operating controls and functional elements
Front view CF40 / CF30 Rear view CF40/ CF30
7
6b
SERIAL
T16A
T16A
8
9
10
11
SERIAL
T16A
T16A
7
6b
9
10
11
8
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

Operating controls and functional elements
18
1
Mains power switch, illuminated
2 °C
140
100
180
220
0
60
20
Adjustable excess temperature protection according to
IEC 61010-2-010
3.0 Indication
3.1
LED temperature display
3.2 Control indicator –Heating
3.3 Control indicator – Cooling
3.4 Control indicator – Alarm
4.0 Keypad splash-water protected
Edit keys (set point increase or decrease)
Enter key Store set point value / parameter
Escape key 1. Cancel entries
2. Switch over LED temperature display
5 Drain port
6a
6b
Handle: front
Handle: rear
7
SERIAL Interface RS232: remote control via personal computer
8
Pump connector M16x1: - Feed
9 Pump connector M16x1: – Return
10
Mains fuses: T16A
T20A (CF40 115 V / 60 Hz)
11 Mains power cable with plug
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

Cryo-Compact Circulator
19
5. Preparations
5.1. Installation
xPlace the unit on an even surface on a base made of
nonflammable material.
xCooling machine, pump motor and electronics produce
intrinsic heat that is dissipated via the venting openings.!
Never cover these openings!
xBe sure that the flow of ventilation can exit under the
instrument.
xKeep at least 20 cm of open space on the side and rear of
the unit.
xThe place of installation should be large enough and provide
sufficient air ventilation to ensure the room does not warm
up excessively because of the heat the instrument rejects to
the environment. (Max. permissible ambient temperature:
35 °C).
For a fault (leakage) in the refrigeration system, the standard
EN 378 prescribes a certain room space to be available for
each kg of refrigerant.
The refrigerant quantity is specified on the type plate.
> For 0.52 kg of refrigerant R404A, 1 m3 of space is
required.
> For 0.25 kg of refrigerant R134a, 1 m3 of space is
required.
> For 0.423 kg of refrigerant R452A, 1 m3 of space is
required.
xModel CF40 with 0.16 kg filling quantity of refrigerant
R404A = 0.33 m3volume
Model CF40 with 0.17 kg filling quantity of refrigerant
R452A = 0.40 m3volume
Model CF30 with 0.15 kg filling quantity of refrigerant R134a
= 0.6 m3volume
xDo not install the unit in the immediate vicinity of heat sources and do not
expose it to sunlight.
xBefore operating the unit after transport, wait about one hour after
installation. This will allow any oil that has accumulated laterally during
transport to flow back down, thus ensuring that the compressor can
develop its maximum capacity.
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

Preparations
20
5.2. Temperature application to external, closed systems
The Cryo-Compact Circulator is used for temperature application to external,
closed systems (loop circuit)
Caution: Securely attach all tubing to prevent slipping.
Notice: Flood hazard!
If the liquid levels in the Cryo-Compact Circulator bath and the external system
are at different heights, overflowing must be prevented after the power has
been turned off.
xUnscrew the M16x1 collar nuts on the
pump connectors with a 19 mm (3/4“)
wrench and remove the sealing disks.
Using the collar nuts, screw on the tubing
connection fittings (for tubing 8 mm or 12
mm in diameter) delivered with the unit and
tighten firmly. (Pressure pump: 8, Return:
9)
xPush on the tubings, and secure with tube
clamps.
xAttach the tubing to the connectors of the
external closed system, e.g., an instrument
with a pressure-resistant temperature
jacket or a temperature coil, and fasten
with tube clamps to prevent slipping.
Tubing see page 21
Return flow safety device
For this reason, shut-off valves can be integrated in the loop circuit.
Order No. Description
8 970 456 Shut-off valve (suitable up to +90 °C)
8 970 457 Shut-off valve (suitable up to +200 °C)
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]
