Jumbl JUMWODKTCH User manual

Wooden Play Kitchen
JUMWODKTCH, JUMKTCHPNK1, JUMKTCHPNK2, JUMKTCHWHIT
User Guide
Thank you for purchasing the Jumbl Wooden Play Kitchen. This User Guide is intended to
provide you with guidelines to ensure that operation of this product is safe and does not
pose risk to the user. Any use that does not conform to the guidelines described in this
User Guide may void the limited warranty.
Please read all directions carefully before using the product and retain this guide for
reference. This product is intended for indoor use only. It is not intended for outside use.
This product is covered by a limited one-year warranty. Coverage is subject to limits and
exclusions. See warranty for details.
®

• Adult setup is required to assemble this product safely.
• Remove all packaging before using this product. Please keep all packaging materials out of
reach of children and pets.
• Set up indoors on an even surface.
• Always supervise children when using this product.
• Do not allow children to tip the product over. This can cause injury to children and damage to
the product.
• Do not drag the product to avoid damaging to your floor and the base of the product.
• Instruct children on proper use of this product. Do not use in a manner other than intended.
• Keep pets away from the product to avoid it tipping over and causing injury to pets/children and
product damage.
• Do not allow children to climb on this product. This can lead to injury and product damage.
• Never place computers, televisions, or other heavy objects on top of the product.
Please read all safety precautions and instructions
carefully before using this product.
Failure to properly follow the guidelines established here
could result in serious injury.
This product is not recommended for children
under 3 years old.
Safety Precautions
Choking hazard – small parts associated with this product
are a choking hazard for children under 3 years old.
WARNING
WARNING

Package Contents
1PC 1PC
1PC
1PC
1PC
1PC
1PC
1PC
1PC
1PC
1PC
1
7
6
2
3
5
8
4
9
10
11

Package Contents (continued)
2PCS 1PC
1PC
1PC
1PC
2PCS
1PC
1PC
1PC
2PCS
12
1PC
1PC
1PC
1PC
1PC
1PC
21
20
13
14
19
22
15
23
24
25
16
17
18
26
27

Package Contents
Hardware
(continued)
1PC1PC
29
28
34PCS
A
2PCS
B
8PCS
C
2PCS
D
22PCS
E
4PCS
F
16PCS
G
5PCS
H
5PCS
I
27PCS
J
4PCS
K
2PCS
L
42 mm 32 mm 9 mm 25 mm
30 mm
9 mm20 mm
18 mm 28 mm

Accessories
Package Contents (continued)
Recommended Tools
• Philips head screwdriver (not included) • Wrench (included)
1PC 1PC 1PC 1PC
1PC 1PC 1PC 1PC
1PC4PCS4PCS4PCS4PCS

Assembly Instructions
Step 1
• Fasten all handles to doors 7, 8, 9, 10, and 11 using two (2)
E screws on each door. Orient each door as shown.
Door 7 uses a different handle than the other doors.
8
9
7
11
10
E
x10 x4 x1

Step 2
• Fasten the chalkboard to door 8 using four (4) C screws.
• Fasten the ice dispenser to door 11 using four (4) C screws.
Chalkboard
Ice dispenser
C
x8
8
11

Step 3
• Fasten one (1) I latch to each of the five (5) doors using
two (2) G screws on each door. G
x5
I
x10
8
9
7
11
10

Step 4
• Fasten two (2) H latches to panel 2 and one (1) H latch to panel 29
as shown. Use G screws to fasten. G
x3
H
x6
29
2

D
x2
H
x2
Step 5
• Fasten one (1) H latch to each side of panel 3 using
two (2) D screws.
Use the provided wrench to hold the nut in place as you
tighten the screws.
3

Kx4
x4
Step 6
• Mount the four (4) dials onto panel 16 using four (4) K screws.
Make sure the inner piece of the dial fits into the lower holes on panel 16
and that the dial spins after tightening the screws.

Step 7
• Insert one (1) wooden dowel into panel 6 and attach it to panel 5.
• Then, insert four (4) additional dowels into the sides of panel 6. J
x5
6
5

Step 8
• Fasten panel 1 to panel 5 using two (2) A screws while
aligning the dowels from panel 6 into panel 1.
Make sure the back grooves of panels 1 and 5 are
aligned and that the hinges on panel 5 are facing up.
Ax2
1
5
6

Step 9
• Fasten panel 4 to panel 5 using two (2) A screws while aligning the
dowels from panel 6 into panel 4.
Make sure the back grooves on panels 4 and 5 are aligned. Ax2
5
4
6

Step 10
• Fasten panel 2 to panel 5 using two (2) A screws.
Make sure latches on panel 2 are facing panel 1
and the back grooves on panel 2 align with panel 5. Ax2
5
2
1

Step 11
• Fasten panel 3 to panel 5 using two (2) A screws.
Make sure the back grooves on panel 3 align with panel 5. Ax2
5
1
3

Step 12
• Insert backboards 12 and 13 into their respective slots.
12
12
13

Step 13
• Fasten two (2) shelf holders on opposite sides of panel 3 using two (2) B screws.
Be sure to use the inner screw holes on the shelf holders. Bx2
3

Step 14
• Fasten one shelf holder each on panel 2 and panel 4 using two (2) E screws each.
Be sure to use the inner screw holes on the shelf holders.
x4
E
4
2
