J-TOURER Instruction Manual
J-TOURER Instruction Manual
9 10
Warnings
1. Unfolding the J-TOURER
2. Adjusting the hood
3. Ventilation panel
4. Attaching the bumper bar
5. Removing the bumper bar
6. Operating 5-point safety harness
7. Adjusting the 5-point safety harness
8. Operating the parking brake
9. Adjusting the backrest
10. Adjusting the legrest
11. Folding the J-TOURER
11
13
13
13
13
14
14
14
14
15
15
15
CONTENTS
Care & maintenance
Warranty
Patent list
17
19
20

J-TOURER Instruction Manual
J-TOURER Instruction Manual
11 12
Warnings
IMPORTANT: read these instructions carefully before use and keep for
future reference.
Important Safety Information.
This vehicle is intended for children from birth to a maximum weight of 22kg.
Any weight added to the stroller will aect the stability.
The stroller is suitable for one child only to the maximum weight stated
above.
This stroller complies with BS EN 1888-2:2018
WARNING:never leave the child unattended.
WARNING:always apply the brake when stationary/leaving
the stroller and when inserting or removing your child from the
stroller.
WARNING:this product is not suitable for running or skating.
WARNING:ensure that all the locking devices are engaged
before use.
WARNING:to avoid injury ensure that your child is kept away
when unfolding and folding this product.
WARNING:do not let your child play with this product.
WARNING:always use the restraint system in combination
with the seat unit.
WARNING:the maximum weight for the standard shopping
basket is 3kg.
WARNING:never lift/carry this product while occupied.
WARNING:do not use the stroller on steps, stairs or
escalators; as it may be dangerous to your child.
WARNING:always descend/mount kerbs on the back wheels,
do not tip the stroller forward.
WARNING:any load attached to the handle and/or the back of
the backrest and/or the sides of the chassis will aect the stability
of the product.
WARNING:never use a parasol attached to the stroller in
windy conditions.
WARNING: always use the seat in the most reclined position
for new born babies from approximately 6 months.
WARNING: only replacement parts supplied or recommended
by the manufacture/distributor should be used.

J-TOURER Instruction Manual
J-TOURER Instruction Manual
13 14
1. Unfolding the J-TOURER
Unclip the travel lock located on the side of the chassis (fig. 2).
Pull the front wheels outwards until they click into place (fig. 3).
Lift the handle, keep lifting the stroller until it starts to unfold
(fig. 4 & 5) and the stroller clicks and locks into place.
WARNING:ensure the locking mechanism is engaged before use.
2. Adjusting the hood
Pull the hood outwards into the desired position. Push back to open
the hood (fig. 6).
3. Ventilation panel
The J-TOURER features a ventilation mesh hood panel for added
ventilation. Simply unzip the zip on the hood and pull the hood
outwards (fig. 7). To close, pull that section backwards and zip up.
4. Attaching the bumper bar
Push the bumper bar into the housings at each side of the seat until it
clicks into place (fig. 8).
CAUTION: ensure the bumper bar is attached correctly before use.
5. Removing the bumper bar
Press the buttons located on each side of the bumper bar to release (fig. 9).
6. Operating 5-point safety harness
To fasten the harness bring together the left and right sections of the
shoulder straps and push into the main buckle housing on the crotch
strap until they click into place (fig. 10 & 11).
WARNING:to avoid injury always use the 5-point safety harness.
To open the harness, press the button on the buckle housing (fig. 12).
7. Adjusting the 5-point safety harness
The waist strap and shoulder straps are adjustable to grow with your
child. Simply slide the harness through the adjusters to the desired
position (fig. 13 & 14).
WARNING:to avoid injury always use the 5-point safety harness.
8. Operating the parking brake
Press down on the pedal to engage the parking brake (fig. 15).
To release the brake lift the brake pedal upwards (fig. 16).

J-TOURER Instruction Manual
J-TOURER Instruction Manual
15 16
WARNING:never leave your stroller without fully
engaging the parking brake.
9. Adjusting backrest
To recline the backrest, squeeze and pull down the clip on the back
of the seat unit (fig. 17 & 18) until it is in the desired position (fig. 19).
To adjust the seat back into a seated position simply squeeze the
release button on the back of the seat and push upwards into the
desired position (fig. 20).
10. Adjusting the leg rest
Press the buttons on the sides of the leg rest and push downwards into
the desired position (fig. 21).
To raise, simply flit the leg rest into the desired position (fig. 22).
11. Folding the J-TOURER
The J-TOURER can be folded with the bumper bar still attached,
however for a more compact fold, remove the bumper bar from
the stroller before folding (fig. 23).
Slide the button on the top of the handle and press the the button on
the front of the handle to release the locking mechanisms (fig. 24).
Fold the top section of the stroller forwards (fig. 25) and then
downwards (fig. 26) until the back section is aligned with the rear legs
of the pushchair (fig. 27).
Secure the travel lock on the side of the chassis (fig. 28). Bring the
front wheels in (fig. 29).

J-TOURER Instruction Manual
J-TOURER Instruction Manual
17 18
Care & Maintenance
• Regularly check screws, rivets, bolts and fastenings to ensure they
are locked tight and secure.
• Replace any parts in an inferior condition.
• Always apply the brake when stationary/leaving the stroller and
when inserting or removing your child from the stroller.
• When using this product during the winter, by the sea or o-road it is
important to clean using clean fresh water and dry thoroughly. Salt
water and salt and grit from the roads will corrode metal parts unless
removed.
• Check on a regular basis that all chassis locking devices are working
correctly.
• If any part of the product is damaged, contact our Customer Services
Team immediately.
• Do not expose to excessive sunlight for extended periods of time,
even normal exposure to sunlight may cause change to the colour of
the fabrics.
• Light oil or silicone spray can be used to lubricate moving parts.
• Ensure zips are either fully open or closed to prevent damage.
• Always use the rain cover in inclement weather.
• Never leave the raincover over the stroller with your child in it when
indoors.
• Do not place items on top of the hood/canopy, it could damage the
fabrics and aect the stability of the product.
• Any load attached to the handle and/or the back of the backrest and/
or the sides of the chassis will aect the stability of the product.
• Tyres could potentially leave marks on some surfaces such as vinyl
flooring and carpet.
• Fabrics should be cleaned in accordance to the care labels.
• Do not place fabrics in a washing machine, hand wash or sponge
clean only using a mild detergent and warm water (30º C) in
accordance to the care labels.
• Never leave the stroller with the child near swimming pools, stairs
and fire.

J-TOURER Instruction Manual
J-TOURER Instruction Manual
19 20
Warranty
JUNIORJONES Ltd provide the guarantee that all products purchased
from us are free from manufacturing faults and material defects in both
the workmanship and the materials.
With regard to our stroller products, your guarantee is valid for three
years from the date of purchase. With regard to our carrycots, soft
goods and other accessories, your guarantee is valid for twelve months
rom the date of purchase.
Please retain your proof of purchase as we may, at our discretion,
require proof of purchase to validate any claim under this guarantee.
As an owner of a JUNIORJONES product, it is your responsibility to
ensure your product is kept in good condition and is regularly
maintained. You must also adhere to all instructions for care and use,
as these will keep your product in the best condition and will prevent
injury or damage to your product or child.
Your statutory rights are not aected.
Patent list
Chinese Design Application No. 201930490706.4
