ACX2000 and ACX2100 Quick Start Description
This Quick Start contains information you need to install and configure the router quickly. For complete
installation instructions, see the ACX2000 and ACX2100 Universal Access Routers Hardware Guide at
https://www.juniper.net/documentation/.
WARNING: This Quick Start contains a summary of safety warnings in “Safety Warnings”
on page 25. For a complete list of warnings for this router, including translations, see the
ACX2000 and ACX2100 Universal Access Routers Hardware Guide at
https://www.juniper.net/documentation/.
The ACX Universal Metro Routers are Ethernet-optimized mobile backhaul routers that provide both
switching and carrier-class Ethernet routing. The ACX Series routers enable a wide range of business and
residential applications and services, including microwave cell site aggregation, MSO mobile backhaul
service cell site deployment, and service provider or operator cell site deployment. The ACX2000 routers
have high-density Ethernet interfaces and high-capacity switching throughput.
The routers are single-board routers with a built-in Routing Engine and one Packet Forwarding Engine.
The Packet Forwarding Engine has one “pseudo” Flexible PIC Concentrator (FPC 0). Because there is no
switching fabric, the single Packet Forwarding Engine takes care of packet forwarding.
The compact routers are one rack unit (U; that is, 1.75 in., or 4.45 cm) tall. Several routers can be stacked
in a single floor-to-ceiling rack for increased port density per unit of floor space.
The ACX2000 router contains sixteen T1/E1 ports and eight copper Gigabit Ethernet ports. The ACX2000
router also contains two ports for installing Gigabit Ethernet SFP and two ports for installing 10-Gigabit
Ethernet SFP+ transceivers.
The ACX2100 router contains sixteen T1/E1 ports, and four copper Gigabit Ethernet ports. The ACX2100
router also contains two ports for installing Gigabit Ethernet SFP transceivers and two ports for installing
10-Gigabit Ethernet SFP+ transceivers. The ports labeled COMBO PORTS provide an additional four
copper Gigabit Ethernet ports or four Gigabit Ethernet SFP ports. You can only use one set of combination
ports at a time.
Figure 1 on page 4 shows the front panel of the ACX2000 router. Figure 2 on page 4 and
Figure 3 on page 5 show the front panel of the AC-powered and DC-powered ACX2100 routers.
3
All manuals and user guides at all-guides.com

Figure 1: Front Panel of the ACX2000 Router
ACX2000
MGMT
SYS 0 1
CONSOLE/AUX
ALARM
1PPS 10MHz
IN OUT IN OUT
T1/E1
0/0/4
0/0/12
0/0/5
0/0/13
0/0/6
0/0/14
0/0/7
0/0/15
0/0/0
0/0/8
0/0/1
0/0/9
0/0/2
0/0/10
0/0/3
0/0/11
0/1/0
0/1/4
0/1/1
0/1/5
0/1/2
0/1/6
0/1/3 POE
0/1/7 POE
GE
0/2/0 0/2/1 0/3/0 0/3/1
g006412
EXT REF CLK IN
GE XE
1 2 3 4
13
5
9
1014
76
8
1112
8—1—Ten-Gigabit Ethernet SFP+ portsDC terminals
9—2—Gigabit Ethernet SFP portsManagement Ethernet port
10—3—1-PPS and 10-Mhz GPS input and outputConsole or auxiliary port
11—4—External reference clocking portAlarm input and output contacts
12—5—USB portsT1/E1 and RJ-45 Gigabit Ethernet network ports
13—6—System LEDPoE Gigabit Ethernet ports
14—7—Grounding terminalsESD point
Figure 2: Front Panel of the AC-Powered ACX2100 Router
g017846
ACX2100
MGMT CONSOLE/AUX
SYS 0 1 EXT REF CLK IN
ALARM
OUTIN IN OUT
0/0/8
0/0/0
0/0/9
0/0/1
0/0/10
0/0/2
0/0/11
0/0/3
0/0/12
0/0/4
0/0/13
0/0/5 0/0/6
0/0/14
0/0/7
0/0/15
1/0/0
1/0/2
1/0/1 1/1/11/1/0
1/0/3 1/1/2
GE
1/1/3
COMBO PORTS XE
1/3/0 1/3/1
T1/E1
1PPS 10MHz
GE
1/1/0 1/1/1 1/2/0
1/1/2 1/1/3 1/2/1
54
1215
1 2
14 13
3
10
8
9
7
11
6
9—1—Ten-Gigabit Ethernet SFP+ portsAC inlets
10—2—Gigabit Ethernet SFP portsManagement Ethernet port
11—3—Combination Gigabit Ethernet SFP portsConsole or auxiliary port
12—4—1-PPS and 10-Mhz GPS input and outputAlarm input and output contacts
13—5—External reference clocking portT1/E1 network ports
14—6—USB portsGigabit Ethernet network ports
15—7—System LEDCombination Gigabit Ethernet RJ-45 ports
8—ESD point
4
All manuals and user guides at all-guides.com

Figure 3: Front Panel of the DC-Powered ACX2100 Router
g017845
ACX2100
MGMT CONSOLE/AUX
SYS 0 1 EXT REF CLK IN
ALARM
OUTIN IN OUT
0/0/8
0/0/0
0/0/9
0/0/1
0/0/10
0/0/2
0/0/11
0/0/3
0/0/12
0/0/4
0/0/13
0/0/5 0/0/6
0/0/14
0/0/7
0/0/15
1/0/0
1/0/2
1/0/1 1/1/11/1/0
1/0/3 1/1/2
GE
1/1/3
COMBO PORTS XE
1/3/0 1/3/1
T1/E1
1PPS 10MHz
GE
1/1/0 1/1/1 1/2/0
1/1/2 1/1/3 1/2/1
12 10
8
9
54
13
1 2
1114
3 76
16 15
9—1—Ten-Gigabit Ethernet SFP+ portsDC terminals
10—2—Gigabit Ethernet SFP portsManagement Ethernet port
11—3—Combination Gigabit Ethernet SFP portsConsole or auxiliary port
12—4—1-PPS and 10-Mhz GPS input and outputAlarm input and output contacts
13—5—External reference clocking portT1/E1 network ports
14—6—USB portsGigabit Ethernet network ports
15—7—System LEDCombination Gigabit Ethernet RJ-45 ports
16—8—Grounding terminalsESD point
5
All manuals and user guides at all-guides.com

Step 1: Prepare the Site for Installation
Prepare your site for installation by observing the following guidelines:
•You can install the router in a four-post rack or cabinet or an open-frame rack.
•The rack rails must be spaced widely enough to accommodate the chassis's external dimensions: 1.7 in.
(4.4 cm) high, 9.4 in. (24 cm) deep, and 17.5 in. (44 cm) wide. The outer edges of the mounting brackets
extend the width to 19.2 in. (48.7 cm).
•One person must be available to lift the router while another secures the router to the rack.
•The rack must be strong enough to support the weight of the fully configured router, up to 7 lb (3.2 kg).
•For service personnel to remove and install hardware components, allow at least 2.16 in. (5.5 cm) in
front of the router.
•The rack or cabinet must have an adequate supply of cooling air.
•Ensure that the cabinet allows the chassis hot exhaust air to exit from the cabinet without recirculating
into the router.
•When deploying the router in environments where the router may operate between 131° F (55° C) and
149° F (65° C), allow a 1 rack unit (U) gap above and below the router.
•When installing the router in a cabinet, ensure that the bottom of the cabinet is closed and there is no
opening.
•You must install the router into a rack that is secured to the building structure.
•Mount the router at the bottom of the rack if it is the only unit in the rack.
•When mounting the router in a partially filled rack, load the rack from the bottom to the top, with the
heaviest component at the bottom of the rack.
•Install the router only in restricted areas, such as dedicated equipment rooms and equipment closets, in
accordance with Articles 110-16, 110-17, and 110-18 of the National Electrical Code, ANSI/NFPA 70.
6
All manuals and user guides at all-guides.com

Figure 4: ACX Series Rack Clearance and Chassis Dimensions
RearFront 17.5"
(44.5 cm)
9.4"
(24 cm)
g006404
Front-mounting flange
19.2"
(48.7 cm)
2.16" (5.5 cm)
clearance required
for the cables
.75" (2 cm)
clearance required
for free airflow
3" (7.6 cm)
3" (7.6 cm)
7
All manuals and user guides at all-guides.com

Step 2: Install the Router
IN THIS SECTION
Tools Required to Install the Router in a Rack | 8
Install the Mounting Brackets | 8
Install the ACX Series Router in the Rack | 9
Tools Required to Install the Router in a Rack
To install the router in a rack, you need the following tools:
•Phillips (+) screwdriver, number 2
•ESD grounding wrist strap
Install the Mounting Brackets
Two mounting brackets for front or rear mounting ship with the router (see Figure 5 on page 9 and
Figure 6 on page 9).
Attach both mounting brackets to either the front or rear of the chassis:
1. Align the bracket with the two sets of mounting holes.
2. Insert the four screws at the top and bottom of the bracket and tighten each partially.
3. Tighten the four screws completely.
4. Repeat the procedure for the other bracket.
8
All manuals and user guides at all-guides.com

Figure 5: Installing the Mounting Brackets to the Front of the ACX Series Router
g006405
Figure 6: Installing the Mounting Brackets to the Rear of the ACX Series Router
g006406
Install the ACX Series Router in the Rack
The router can be installed horizontally in a rack or cabinet.
NOTE: For additional installation options, contact JTAC.
One person must be available to lift the router while another secures the router to the rack. The chassis
weighs approximately 7 lb (3.2 kg). To install the chassis (see Figure 7 on page 10):
1. Ensure that the rack is in its permanent location and is secured to the building. Ensure that the installation
site allows adequate clearance for both airflow and maintenance.
2. Position the router in front of the rack or cabinet.
3. Have one person grasp both sides of the router, lift the router, and position it in the rack, aligning the
mounting bracket holes with the threaded holes in the rack rails. Make sure the chassis is level.
9
All manuals and user guides at all-guides.com

4. Have the second person install a mounting screw into each of the open mounting holes aligned with
the rack, starting from the bottom.
5. Visually inspect the alignment of the router. If the router is installed properly in the rack, all the mounting
screws on one side of the rack should be aligned with the mounting screws on the opposite side, and
the router should be level.
Figure 7: Installing the Front-Mounted Router in the Rack
g006407
Mounting rack
Mounting bracket
10
All manuals and user guides at all-guides.com

Step 3: Ground the ACX2000 and ACX2100 Router
IN THIS SECTION
Tools Required to Ground the ACX Router | 11
Connect the Grounding Cable | 11
You must ground the router before connecting power.
Tools Required to Ground the ACX Router
To ground the router, you need the following tools:
•Phillips (+) screwdriver, number 2
•ESD grounding wrist strap
•Two SAE 10-32 screws and paint piercing washers (not provided)
•Grounding lug, Panduit LCD06-10A or equivalent (not provided)
•Grounding cable, minimum 6 AWG (13.3 mm2) 90° C wire (not provided)
Connect the Grounding Cable
You ground the router by connecting a grounding cable to earth ground and then attaching it to the chassis
grounding points. To ground the router:
1. Verify that a licensed electrician has attached the cable lug, which is provided with the router, to the
grounding cable.
2. Attach an electrostatic discharge (ESD) grounding strap to your bare wrist, and connect the strap to
an approved site ESD grounding point. See the instructions for your site.
3. Ensure that all grounding surfaces are clean and brought to a bright finish before you make grounding
connections.
11
All manuals and user guides at all-guides.com

4. Connect the grounding cable to a proper earth ground.
5. Detach the ESD grounding strap from the site ESD grounding point.
6. Wrap and fasten one end of the ESD grounding strap around your bare wrist, and connect the other
end of the strap to the ESD point on the chassis.
7. Place the grounding cable lug over the grounding points on the front of the chassis (see
Figure 8 on page 13).
8. Secure the grounding cable lug with the washers and screws. The holes are sized for SAE 10-32 screws.
Apply 4.34 lb-in (0.49 Nm) of torque to each screw. Do not overtighten the screw. (Use a number 2
Phillips screwdriver.)
CAUTION: Ensure that each grounding cable lug seats flush against the surface of
the grounding points as you are tightening the screws. Ensure that each screw is
properly threaded into the grounding points. Applying installation torque to the screw
when improperly threaded may result in damage to the terminal.
CAUTION: The maximum torque rating of the grounding screws on the router is 4.34
lb-in (0.49 Nm). The grounding screws may be damaged if excessive torque is applied.
Use only a torque-controlled driver to tighten screws. Use an appropriately sized
driver, with a maximum torque capacity of 5 lb-in. or less. Ensure that the driver is
undamaged and properly calibrated and that you have been trained in its use. You
may wish to use a driver that is designed to prevent overtorque when the preset
torque level is achieved.
9. Dress the grounding cable, and verify that it does not touch or block access to router components, and
that it does not drape where people could trip on it.
12
All manuals and user guides at all-guides.com

Figure 8: Grounding Points on the Router
g006419
1
2
2—1—SAE 10-32 screw and washerGrounding lug
13
All manuals and user guides at all-guides.com

Step 4: Connect External Devices and Cables
IN THIS SECTION
Tools Required to Connect External Devices and Cables | 14
Connect the ACX Series Router to a Network for Out-of-Band Management | 14
Connect the ACX Series Router to a Management Console or Auxiliary Device | 15
Connect Network Interface Cables to the ACX Series Router | 15
Figure 9: Ethernet Cable Connector
Tools Required to Connect External Devices and Cables
To connect external devices and cables to the router, you need the following tools:
•Ethernet cable with an RJ-45 connector attached (provided)
•RJ-45 to DB-9 serial port adapter (provided)
•Management host, such as a PC, with an Ethernet port (not provided)
Connect the ACX Series Router to a Network for Out-of-Band Management
1. Turn off the power to the management device.
2. Plug one end of the Ethernet cable (Figure 9 on page 14 shows the connector) into the MGMT port
on the front of the chassis. Figure 1 on page 4,Figure 2 on page 4, and Figure 3 on page 5 show
the port.
3. Plug the other end of the cable into the network device.
14
All manuals and user guides at all-guides.com

Connect the ACX Series Router to a Management Console or Auxiliary
Device
1. Turn off the power to the console or auxiliary device.
2. Plug the RJ-45 end of the serial cable (Figure 9 on page 14 shows the connector) into the
CONSOLE/AUX port on the front panel. Figure 1 on page 4,Figure 2 on page 4, and
Figure 3 on page 5 show the port.
3. Plug the female DB-9 end into the device's serial port.
Connect Network Interface Cables to the ACX Series Router
1. Have ready a length of the type of cable used by the network ports. For cable specifications, see the
ACX2000 and ACX2100 Universal Access Routers Hardware Guide.
NOTE: Shielded cables are required for outside deployment.
2. Remove the rubber safety plug from the cable connector port.
WARNING: Do not look directly into a fiber-optic transceiver or into the ends of
fiber-optic cables. Fiber-optic transceivers and fiber-optic cables connected to a
transceiver emit laser light that can damage your eyes.
CAUTION: Do not leave a fiber-optic transceiver uncovered except when inserting
or removing a cable. The safety cap keeps the port clean and prevents accidental
exposure to laser light.
3. Insert the cable connector into the cable connector port on the faceplate.
4. Arrange the cable to prevent it from dislodging or developing stress points. Secure the cable so that it
is not supporting its own weight as it hangs to the floor. Place excess cable out of the way in a neatly
coiled loop.
15
All manuals and user guides at all-guides.com

CAUTION: Avoid bending a fiber-optic cable beyond its minimum bend radius. An
arc smaller than a few inches in diameter can damage the cable and cause problems
that are difficult to diagnose.
CAUTION: Do not let fiber-optic cables hang free from the connector. Do not allow
the fastened loops of a cable to dangle, which stresses the cable at the fastening point.
16
All manuals and user guides at all-guides.com

Step 5: Connect Power to the ACX Series Router
IN THIS SECTION
Connect AC Power to an AC-Powered ACX2100 Series Router | 17
Connect DC Power to a DC-Powered ACX2000 or ACX2100 Router | 18
Depending on your configuration, your router uses either AC or DC power supplies. Perform the appropriate
procedures for each power supply in your router.
WARNING: You must ground the router before connecting the power cables.
Connect AC Power to an AC-Powered ACX2100 Series Router
To connect power to the AC-powered router, you need the following tools:
•AC power cords
1. Locate the power cords, which should have a plug appropriate for your geographical location. See the
ACX2000 and ACX2100 Universal Access Routers Hardware Guide.
2. Wrap and fasten one end of the ESD grounding strap around your bare wrist, and connect the other
end of the strap to the ESD point on the chassis.
3. Insert the appliance coupler end of the power cord into the appliance inlet on the power supply.
4. Insert the power cord plug into an external AC power source receptacle.
NOTE: Each power supply must be connected to a dedicated AC power feed and a dedicated
customer site circuit breaker. We recommend that you use a dedicated customer site circuit
breaker rated for 2 A (100 VAC) or 1 A (240 VAC), or as required by local code.
17
All manuals and user guides at all-guides.com

5. Dress the power cord appropriately. Verify that the power cord does not block the air exhaust and
access to router components, or drape where people could trip on it.
6. Repeat Step 1through Step 5for the remaining power supplies.
7. Observe the system LED on the router. If an AC power supply is functioning normally, the system LED
lights green steadily.
If the system LED is not lit, the power supply is not functioning normally. Repeat the cabling procedures.
Connect DC Power to a DC-Powered ACX2000 or ACX2100 Router
To connect power to the DC-powered router, you need the following tools:
•Phillips (+) screwdriver, number 2
•ESD grounding wrist strap
•M3 screws and flat washers
•DC power source cables, minimum 14 AWG or as required by local code (not provided)
•Ring lugs, Molex 190700067 or equivalent (not provided)
The DC power supply has four terminals on the front panel, covered by a clear plastic cover.
Table 1: ACX Series DC Power System Input Voltage
SpecificationNominal Voltage
Operating range: +18 to +30 VDC+24
Operating range: –39 to –56 VDC–48
Operating range: –39 to –72 VDC–60
1. Attach an electrostatic discharge (ESD) grounding strap to your bare wrist, and connect the strap to
one of the ESD points on the chassis. For more information about ESD, see the ACX2000 and ACX2100
Universal Access Routers Hardware Guide.
2. Switch off the dedicated customer site circuit breakers. Ensure that the voltage across the DC power
source cable leads is 0 V and that there is no chance that the cable leads might become active during
installation.
18
All manuals and user guides at all-guides.com

3. Remove the clear plastic cover protecting the terminal on the faceplate.
4. Verify that the DC power cables are correctly labeled before making connections to the power supply.
In a typical power distribution scheme where the return is connected to chassis ground at the battery
plant, you can use a multimeter to verify the resistance of the –48V and return DC cables to chassis
ground:
For –48V and –60V:
a. The cable with very large resistance (indicating an open circuit) to chassis ground is the DC input
cable (–).
b. The cable with very low resistance (indicating a closed circuit) to chassis ground is the return cable
(+).
For +24V:
a. The cable with very low resistance (indicating a closed circuit) to chassis ground is the DC input
cable (–).
b. The cable with very large resistance (indicating an open circuit) to chassis ground is the return cable
(+).
5. Remove the screws and flat washers from the terminals.
6. Secure each power cable lug to the terminal with the flat washers and screw (see Figure 10 on page 20).
Apply between 8 lb-in. (0.9 Nm) and 9 lb-in. (1.02 Nm) of torque to each screw. Do not overtighten
the screw. (Use a number 2 Phillips screwdriver.)
a. Secure the positive DC source power cable lug to the return (+) terminal.
b. Secure the negative DC source power cable lug to the input (–) terminal.
CAUTION: Ensure that each power cable lug seats flush against the surface of the
terminal block as you are tightening the screws. Ensure that each screw is properly
threaded into the terminal. Applying installation torque to the screw when the screw
is improperly threaded may result in damage to the terminal.
19
All manuals and user guides at all-guides.com

CAUTION: The maximum torque rating of the terminal screws on the DC power
supply is 9 lb-in. (1.02 Nm). The terminal screws may be damaged if excessive torque
is applied. Use only a torque-controlled driver to tighten screws on the DC power
supply terminals. Use an appropriately sized driver, with a maximum torque capacity
of 9 lb-in. or less. Ensure that the driver is undamaged and properly calibrated and
that you have been trained in its use. You may wish to use a driver that is designed
to prevent overtorque when the preset torque level is achieved.
7. Replace the clear plastic cover over the terminals on the faceplate.
8. Attach an electrostatic discharge (ESD) grounding strap to your bare wrist, and connect the strap to
an approved site ESD grounding point. See the instructions for your site.
9. Connect each DC power cable to the appropriate external DC power source.
NOTE: For information about connecting to external DC power sources, see the instructions
for your site.
10. Switch on the external circuit breakers to provide voltage to the DC power source cable leads. Observe
the system LED on front of the router. If the DC power cable is correctly installed and functioning
normally, the system LED lights green steadily. If the system LED is not lit, the power supply is not
functioning normally. Repeat the installation and cabling procedures.
Figure 10: Connecting DC Power to the Router
g006409
20
All manuals and user guides at all-guides.com
