MX960 3D Universal Edge Router Quick Start

MX960 Quick Start Description
This Quick Start contains information you need to install and configure the router quickly.
For complete installation instructions, see the MX960 3D Universal Edge Router Hardware
Guide at http://www.juniper.net/techpubs/.
WARNING: This Quick Start contains a summary of safety warnings in “Safety
Warnings” on page 29. For a complete list of warnings for this router, including
translations, see the MX960 3D Universal Edge Router Hardware Guide at
http://www.juniper.net/techpubs/.
The MX960 3D Universal Edge Router with the standard cable manager is 16 rack units
(U) tall, or 21 U with the extended cable manager. Three routers with the standard cable
manager, or two routers with the extended cable manager, can be stacked in a single
floor-to-ceiling rack, for increased port density per unit of floor space.
The router provides 14 slots that can be populated with up to 12 Dense Port Concentrators
(DPCs) or Modular Port Concentrators (MPCs), six Flexible PIC Concentrators (FPCs),
and two Switch Control Boards (SCBs) in nonredundant fabric configurations.
Several types of DPCs are available. Each DPC includes either two or four Packet
Forwarding Engines. Each Packet Forwarding Engine enables a throughput of 10 Gbps.
Up to two PICs can be installed in each FPC. Fully populated, the MX960 router supports
up to 12 PICs.
Up to two Modular Interface Cards (MICs) can be installed in each MPC. Fully populated,
the MX960 router supports up to 24 MICs.
For a list of the supported DPCs, FPCs, MPCs, MICs, and PICs, see the MX Series Interface
Module Reference.
The router is shipped in a cardboard box strapped securely to a wooden pallet. Plastic
straps secure the top and bottom in place. The router chassis is bolted to this pallet.
Quick Start installation instructions and a cardboard accessory box are also included in
the shipping container.
3Copyright © 2015, Juniper Networks, Inc.
MX960 Quick Start Description

Step 1: Prepare the Site for MX960 Installation
•Rack-Mounting Requirements on page 4
•Tools Required to Unpack and Prepare the MX960 Router for Installation on page 5
Rack-Mounting Requirements
•You can install the router in a four-post rack or cabinet or an open-frame rack.
•The rack rails must be spaced widely enough to accommodate the router chassis's
external dimensions: 27.75 in. (70.49 cm) high, 23.0 in. (58.42 cm) deep, and
17.37 in. (44.11 cm) wide. The outer edges of the mounting brackets extend the width
to 19 in. (48.3 cm).
•The rack must be strong enough to support the weight of the fully configured router,
up to 350 lb (158.76 kg). If you stack three fully configured routers in one rack, it must
be capable of supporting about 1,050 lb (476.3 kg).
•For service personnel to remove and install hardware components, there must be
adequate space at the front and back of the router. Allow at least 30 in. (76.2 cm) in
front of the router and 24 in. (61 cm) behind the router.
•The rack or cabinet must have an adequate supply of cooling air.
•Ensure that the cabinet allows the chassis hot exhaust air to exit from the cabinet
without recirculating into the router.
•The router must be installed into a rack that is secured to the building structure.
•Mount the router at the bottom of the rack if it is the only unit in the rack.
•When mounting the router in a partially filled rack, load the rack from the bottom to
the top with the heaviest component at the bottom of the rack.
Copyright © 2015, Juniper Networks, Inc.4
MX960 3D Universal Edge Router Quick Start

Figure 1: MX960 Rack Clearance and Router Dimensions
Tools Required to Unpack and Prepare the MX960 Router for Installation
To unpack the router and prepare for installation, you need the following tools:
•A mechanical lift—recommended
•Phillips (+) screwdrivers, numbers 1 and 2
•2.5 mm flat-blade (–) screwdriver
•7/16-in. (11 mm) torque-controlled driver or socket wrench
•1/2-in. or 13-mm open-end or socket wrench to remove bracket bolts from the shipping
pallet
•Electrostatic discharge wrist strap
•Antistatic mat
Proceed to “Step 2: Install the Mounting Hardware” on page 6.
5Copyright © 2015, Juniper Networks, Inc.
Tools Required to Unpack and Prepare the MX960 Router for Installation

Step 2: Install the Mounting Hardware
•Install the Mounting Hardware in a Four-Post Rack or Cabinet on page 6
•Install the Mounting Hardware in an Open-Frame Rack on page 7
Install the Mounting Hardware in a Four-Post Rack or Cabinet
1. On the front rack rails, install cage nuts in the holes specified in the MX960 3D Universal
Edge Router Hardware Guide for the large shelf and the spacer bars.
2. On the front of each front rack rail, partially insert a mounting screw into the hole
containing the lowest cage nut.
3. Install the large shelf on the front rack rails. Rest the bottom slot of each ear on a
mounting screw.
4. Partially insert a mounting screw into the top hole in each ear of the large shelf.
5. Tighten all the screws completely.
6. On the rear rack rails, install cage nuts in the holes specified in the MX960 3D Universal
Edge Router Hardware Guide for the small shelf.
7. On the back of each rear rack rail, partially insert a mounting screw into the hole
containing the lowest cage nut.
8. Install the small shelf on the back rack rails. Rest the bottom slot of each ear on a
mounting screw. The small shelf installs on the back of the rear rails, extending toward
the center of the rack. The bottom of the small shelf should align with the bottom of
the large shelf.
9. Partially insert screws into the open holes in the ears of the small shelf.
10. Tighten all the screws completely.
Copyright © 2015, Juniper Networks, Inc.6
MX960 3D Universal Edge Router Quick Start

Figure 2: Mount Hardware for a Four-Post Rack or Cabinet
Install the Mounting Hardware in an Open-Frame Rack
1. On the rear of each rack rail, partially insert a mounting screw into the highest hole
specified in the MX960 3D Universal Edge Router Hardware Guide for the large shelf.
2. Install the large shelf on the rack. Hang the shelf over the mounting screws using the
keyhole slots located near the top of the large shelf flanges.
3. Partially insert screws into the open holes in the ears of the large shelf.
4. Tighten all the screws completely.
7Copyright © 2015, Juniper Networks, Inc.
Install the Mounting Hardware in an Open-Frame Rack

Figure 3: Mount Hardware for an Open-Frame Rack
Copyright © 2015, Juniper Networks, Inc.8
MX960 3D Universal Edge Router Quick Start

Step 3: Install the Router
•Remove Components on page 9
•Install the Router Using a Lift on page 10
•Reinstall Components on page 12
Remove Components
Figure 4: Components to Remove from the Front of the MX960 Router
g004091
Figure 5: Components to Remove from the Rear of the MX960 Router
9Copyright © 2015, Juniper Networks, Inc.
Step 3: Install the Router

Before installing the router, you must remove the following components:
•Power supplies
•Switch Control Boards (SCBs)
•Cable management system
•Routing Engines
•Air filter
•Fan trays
•Line cards:
•Dense Port Concentrators (DPCs)
•Flexible PIC Concentrators (FPCs)
•Physical Interface Cards (PICs)
•Modular Port Concentrators (MPCs)
•Modular Interface Cards (MICs)
To remove the components from the router:
1. Slide each component out of the chassis evenly so that it does not become stuck or
damaged.
2. Label each component as you remove it so you can reinstall it in the correct location.
3. Immediately store each removed component in an electrostatic bag.
4. Do not stack removed components. Lay each one on a flat surface.
NOTE: For complete instructions on removing router components, see the
MX960 3D Universal Edge Router Hardware Guide.
Install the Router Using a Lift
Before installing the router, you must remove all components (see “Remove Components”
on page 9). To install the router using a lift:
1. Ensure that the rack is in its permanent location and is secured to the building. Ensure
that the installation site allows adequate clearance for both airflow and maintenance.
For details, see the MX960 3D Universal Edge Router Hardware Guide.
2. Load the router onto the lift, making sure it rests securely on the lift platform (see
Figure 6 on page 11).
Copyright © 2015, Juniper Networks, Inc.10
MX960 3D Universal Edge Router Quick Start

Figure 6: Load the MX960 Router onto the Lift
3. Using the lift, position the router in front of the rack or cabinet, centering it in front of
the mounting shelves.
4. Lift the chassis approximately 0.75 in. above the surface of the mounting shelves, and
position it as close as possible to the shelves.
5. Carefully slide the router onto the mounting shelves so that the bottom of the chassis
and the mounting shelves overlap by approximately 2 inches.
6. Slide the router onto the mounting shelves until the mounting brackets or
front-mounting flanges contact the rack rails. The shelves ensure that the holes in
the mounting brackets and the front-mounting flanges of the chassis align with the
holes in the rack rails.
7. Move the lift away from the rack.
8. To install the router in an open-frame rack, install a mounting screw into each of the
open mounting holes aligned with the rack, starting from the bottom.
9. Visually inspect the alignment of the router. If the router is installed properly in the
rack, all the mounting screws on one side of the rack should be aligned with the
mounting screws on the opposite side and the router should be level.
11Copyright © 2015, Juniper Networks, Inc.
Install the Router Using a Lift

Reinstall Components
To reinstall the components in the router:
1. Slide each component into the chassis evenly so that it does not become stuck or
damaged.
2. Tighten the captive screws for each component.
NOTE: Make sure that all empty slots are covered with a blank panel before
operating the router.
Proceed to “Step 4: Connect the Grounding Cable” on page 13.
Copyright © 2015, Juniper Networks, Inc.12
MX960 3D Universal Edge Router Quick Start

Step 4: Connect the Grounding Cable
1. Attach an electrostatic discharge (ESD) grounding strap to your bare wrist, and connect
the strap to an approved site ESD grounding point. See the instructions for your site.
2. Connect the grounding cable to a proper earth ground.
3. Verify that a licensed electrician has attached the cable lug provided with the router
to the grounding cable.
4. Make sure that grounding surfaces are clean and brought to a bright finish before
grounding connections are made.
5. Attach an electrostatic discharge (ESD) grounding strap to your bare wrist, and connect
the strap to one of the ESD points on the chassis. For more information about ESD,
see the MX960 3D Universal Edge Router Hardware Guide.
6. Place the grounding cable lug over the grounding points. The left pair is sized for M6
bolts, and the right pair is sized for UNC 1/4-20 bolts.
7. Secure the grounding cable lug to the grounding points, first with the washers, then
with the screws.
8. Verify that the grounding cabling is correct, that the grounding cable does not touch
or block access to router components, and that it does not drape where people could
trip on it.
Proceed to “Step 5: Connect External Devices and Line Card Cables” on page 14.
13Copyright © 2015, Juniper Networks, Inc.
Step 4: Connect the Grounding Cable

Step 5: Connect External Devices and Line Card Cables
Figure 7: Connect External Devices and DPC Cables
•Connect to a Network for Out-of-Band Management on page 14
•Connect a Management Console on page 14
•Connect the Line Card Cables on page 15
Connect to a Network for Out-of-Band Management
1. Turn off the power to the management device.
2. Plug one end of the RJ-45 Ethernet cable into the ETHERNET port on the Routing
Engine.
3. Plug the other end of the cable into the network device.
Connect a Management Console
1. Turn off the power to the management device.
2. Plug one end of the RJ-45 Ethernet cable into the CONSOLE or AUX port on the Routing
Engine.
3. Plug the female DB-9 end into the device's serial port.
Copyright © 2015, Juniper Networks, Inc.14
MX960 3D Universal Edge Router Quick Start

Connect the Line Card Cables
1. Have ready a length of the type of cable used by the DPCs, MPCs, MICs, or PICs. For
cable specifications, see the MX Series Interface Module Reference.
2. If the cable connector port is covered by a rubber safety plug, remove the plug.
WARNING: Do not look directly into a fiber-optic transceiver or into the
ends of fiber-optic cables. Fiber-optic transceivers and fiber-optic cable
connected to a transceiver emit laser light that can damage your eyes.
CAUTION: Do not leave a fiber-optic transceiver uncovered except when
inserting or removing cable. The safety cap keeps the port clean and
prevents accidental exposure to laser light.
3. Insert the cable connector into the cable connector port on the faceplate.
4. Arrange the cable in the cable management system to prevent it from dislodging or
developing stress points. Secure the cable so that it is not supporting its own weight
as it hangs to the floor. Place excess cable out of the way in a neatly coiled loop in
the cable management system. Placing fasteners on the loop helps to maintain its
shape.
CAUTION: Avoid bending fiber-optic cable beyond its minimum bend
radius. An arc smaller than a few inches in diameter can damage the cable
and cause problems that are difficult to diagnose.
CAUTION: Do not let fiber-optic cable hang free from the connector. Do
not allow fastened loops of cable to dangle, which stresses the cable at
the fastening point.
Proceed to “Step 6: Connect Power Cables” on page 16.
15Copyright © 2015, Juniper Networks, Inc.
Connect the Line Card Cables

Step 6: Connect Power Cables
Depending on your configuration, your router uses either AC or DC power supplies. Perform
the appropriate procedures for each power supply in your router.
•Connect Power to an AC Router with Normal-Capacity Power Supplies on page 16
•Connect Power to an AC Router with High-Capacity Power Supplies on page 16
•Connect Power to a DC Router with Normal-Capacity Power Supplies on page 20
•Connect Power to a DC Router with High-Capacity Power Supplies on page 21
Connect Power to an AC Router with Normal-Capacity Power Supplies
1. Locate the power cords shipped with the router, which should have a plug appropriate
for your geographical location (see the MX960 3D Universal Edge Router Hardware
Guide).
2. Attach an electrostatic discharge (ESD) grounding strap to your bare wrist, and connect
the strap to one of the ESD points on the chassis. For more information about ESD,
see the For more information about ESD, see the MX960 3D Universal Edge Router
Hardware Guide..
3. Move the power switch on the power supply faceplate to the standby position.
4. Insert the appliance coupler end of the power cord into the appliance inlet on the
power supply.
5. Insert the power cord plug into an external AC power source receptacle.
NOTE: Each power supply must be connected to a dedicated AC power
feed and a dedicated customer site circuit breaker. We recommend that
you use a 15 A (250 VAC) minimum, or as permitted by local code.
6. Dress the power cord appropriately. Verify that the power cord does not block the air
exhaust and access to router components, or drape where people could trip on it.
7. Repeat Step 1through Step 6for the remaining power supplies.
Connect Power to an AC Router with High-Capacity Power Supplies
NOTE: A minimum of two AC nominal 220 VAC 20 amp power cords are
required for this procedure.
To install an MX960 high-capacity AC power supply, use the following procedure (see
Figure 8 on page 17).
1. Verify that the power switch on the power supply is in the off (O) position.
2. Ensure that the release lever below the empty power supply slot is locked in the
counterclockwise position (see Figure 8 on page 17).
Copyright © 2015, Juniper Networks, Inc.16
MX960 3D Universal Edge Router Quick Start

Figure 8: MX960 with High-Capacity AC Power Supplies Installed
g006061
AC-1 OK
AC-2 OK
DC OK
PS FAIL
AC-1 OK
AC-2 OK
DC OK
PS FAIL
AC-1 OK
AC-2 OK
DC OK
PS FAIL
AC-1 OK
AC-2 OK
DC OK
PS FAIL
Protective earthing ESD point
Power supply
ejectors
AC Power
supplies
Air exhaust
Input mode switch
If necessary, pull the spring-loaded locking pin in the release lever away from the
chassis and turn the release lever counterclockwise until it stops. Let go of the locking
pin in the release lever. Ensure that the pin is seated inside the corresponding hole in
the chassis.
3. On the power supply, rotate the metal cover away from the input mode switch to
expose the switch.
4. Move the input mode switch to position 0 for one feed or position 1 for two feeds (see
Figure 9 on page 18).
17Copyright © 2015, Juniper Networks, Inc.
Connect Power to an AC Router with High-Capacity Power Supplies

Figure 9: MX960 AC Power Input Mode Switch
g006057
0
1
1
0
CAUTION: Do not use a pencil, because fragments can break off and cause
damage to the power supply.
5. Using both hands, slide the power supply straight into the chassis until the power
supply is fully seated in the chassis slot. The power supply faceplate will protrude
beyond the chassis.
The small tab on the metal housing that is controlled by the release lever must be
inside of the corresponding slot at the bottom of the power supply (see
Figure 9 on page 18). This tab is used to pull the power supply down in the chassis
slot, prior to removing the power supply.
6. While firmly pushing the handle on the power supply faceplate with one hand, use
your other hand to pull the spring-loaded locking pin in the release lever away from
the chassis and turn the release lever clockwise until it stops.
7. Let go of the locking pin in the release lever. Ensure that the pin is seated inside the
corresponding hole in the chassis.
8. Locate a power cord with the type of plug appropriate for your geographical location
(see AC Power Cord Specifications for the MX960 Router).
9. Plug the power cord into the corresponding appliance inlet located in the chassis
directly above the power supply. This is the recommend receptacle when using the
power supply in one-feed mode. If using the power supply in two-feed mode, plug the
second power cord into the receptacle on the power supply.
NOTE: Each power supply must be connected to a dedicated AC power
feed and a dedicated customer site circuit breaker.
Copyright © 2015, Juniper Networks, Inc.18
MX960 3D Universal Edge Router Quick Start

10. Dress the power cords appropriately. Verify that the power cord does not block the
air exhaust and access to router components, and that they do not drape where people
could trip on them.
11. Move the AC input switch above the power supply to the on (—) position. This is the
only switch you have to turn on if you are using the power supply in one feed mode. If
using the power supply in two-feed mode, move the power switch on the power supply
to the on position. Remember to turn on both switches when operating the power
supply in two-feed mode.
12. If the power supply is correctly installed and functioning normally, the AC1 OK,AC2 OK
(two-feed mode only) DC OK LEDs light steadily, and the PS FAIL LED is not lit. See
Table 1 on page 19.
Table 1: MX960 High-Capacity AC Power Supply LEDs
LEDs
DIP Switch
Position
Connected
Inputs PS FAILDC OKAC-2 OKAC-1 OK
OffGreenOffGreen0 (1 input)PDM connected,
power supply
disconnected
OffGreenGreenOff0 (1 input)PDM
disconnected,
power supply
connected
OffGreenGreenGreen0 (1 input)PDM connected,
PS connected
RedOffOffGreen1 (2 inputs)PDM connected,
PS disconnected
RedOffGreenOff1 (2 inputs)PDM
disconnected, PS
connected
OffGreenGreenGreen1 (2 inputs)PDM connected,
PS connected
Note: The corresponding appliance inlet located in the chassis directly above the power supply is the recommend receptacle when
using the power supply in one feed mode. If using the power supply in two-feed mode, plug the second power cord into the
receptacle on the power supply
Note: PDM in the above table stands for Power Distribution Module.
13. Repeat steps 1-12 for installing power supplies in slots 1, 2, and 3, where required.
19Copyright © 2015, Juniper Networks, Inc.
Connect Power to an AC Router with High-Capacity Power Supplies

Connect Power to a DC Router with Normal-Capacity Power Supplies
1. Ensure that the voltage across the DC power source cable leads is 0 V and that there
is no chance that the cable leads might become active during installation.
2. Secure the power cable lugs to the terminal studs, first with the split washer, then
with the nut. Apply between 23 lb-in. (2.6 Nm) and 25 lb-in. (2.8 Nm) of torque to
each nut. Do not overtighten the nut. (Use a 7/16-in. [11 mm] torque-controlled driver
or socket wrench.)
a. Attach the positive (+) DC source power cable lug to the RTN (return) terminal.
b. Attach the negative (–) DC source power cable lug to the –48V (input) terminal.
Table 2: MX960 DC Power System Input Voltage
SpecificationItem
Operating range: –40 to –72 VDCDC input voltage
Figure 10: Connect Ground and Power Cables
CAUTION: Ensure that each power cable lug seats flush against the surface
of the terminal block as you are tightening the nuts. Ensure that each nut
is properly threaded onto the terminal stud. The nut should be able to spin
freely with your fingers when it is first placed onto the terminal stud.
Applying installation torque to the nut when improperly threaded may
result in damage to the terminal stud.
Copyright © 2015, Juniper Networks, Inc.20
MX960 3D Universal Edge Router Quick Start
