FPC Handling Instructions for T-series Platforms 1
FPC Handling Instructions for T-series Platforms
Part No. 530-010119-01
Revision 1
25 August 2003
This document explains how to avoid damaging the Flexible PIC Concentrators (FPCs) that
install into Juniper Networks T320 Internet routers and T640 Internet routing nodes. Many
components on the FPC are fragile and can be irreparably damaged if the FPC is not handled
carefully.
Contents FPC Description ....................................................................................................................1
Store an FPC .........................................................................................................................4
Hold an FPC ..........................................................................................................................5
Install an FPC ........................................................................................................................9
Contact Juniper Networks....................................................................................................10
Revision History ..................................................................................................................11
FPC Description
FPCs house the Physical Interface Cards (PICs) that connect the router to network media. The
main function of an FPC is to connect the PICs installed in it to the other router components.
Up to eight FPCs install vertically in the front of the T320 router or T640 routing node
(see Figure 1). The FPCs are numbered FPC0 through FPC7, left to right. Each FPC on a T320
router can house up to two PICs, and each FPC on a T640 routing node can house up to four
FPCs. An FPC can be installed into any FPC slot on the routing platform, regardless of which
PICs it contains.
FPCs are hot-removable and hot-insertable. When you bring an FPC online in an operating
routing platform, the Routing Engine downloads the FPC software, the FPC runs its
diagnostics, and the PICs in the FPC are enabled. No interruption occurs to the routing
functions. For more information about FPC functionality, see the T320 Internet Router
Hardware Guide and T640 Internet Routing Node Hardware Guide (accessible at
https://www.juniper.net/techpubs/hardware/index.html).

FPC Description
FPC Handling Instructions for T-series Platforms
2
Figure 1: FPC Installed in T640 Routing Node Chassis
This document discusses how to hold FPCs in both the vertical and horizontal positions.
Regardless of orientation, the same terms are used for each of the four edges of the FPC (see
Figure 2):
Faceplate—The edge of the FPC that has slots into which the PICs insert
Connector edge—The edge opposite the faceplate, with the connectors that attach to the
midplane
Top edge—The edge at the top of the FPC when it is in the vertical position
Bottom edge—The edge at the bottom of the FPC when it is in the vertical position
g003146
The instructions in this document apply to both T320 FPCs
and T640 FPCs. The figures show T640 FPCs.

FPC Handling Instructions for T-series Platforms 3
FPC Description
Figure 2: FPC Edges
Many components on the FPC are fragile and can be irreparably damaged if the FPC is not
handled carefully. The following sections describe the procedures for properly handling an
FPC:
Store an FPC on page 4
Hold an FPC on page 5
Install an FPC on page 9
g003147
Top edge
Bottom edge
Faceplate
Connector edge
Failure to handle FPCs as specified in this document can
cause irreparable damage.

Store an FPC
FPC Handling Instructions for T-series Platforms
4
Store an FPC
Store an FPC as follows:
In the routing platform
In the container in which a spare FPC is shipped
Horizontally and component-side up on a flat, stable surface
When you store the FPC on a horizontal surface or in the shipping container, always place it
inside an antistatic bag. Because the FPC is heavy and antistatic bags are fragile, inserting the
FPC into the bag is easier with two people. One person holds the FPC in the horizontal
position with the faceplate facing his or her body. The other person slides the opening of the
bag over the FPC connector edge.
If you must insert the FPC into a bag by yourself, first lay the FPC horizontally on a flat, stable
surface, component side up. Orient it with the faceplate facing you. Carefully insert the FPC
connector edge into the opening of the bag and pull the bag toward you to cover the FPC.
Never stack an FPC under or on top of any other component (see Figure 3). Never lay an FPC
component side down.
Figure 3: Do Not Stack FPCs
g003139

FPC Handling Instructions for T-series Platforms 5
Hold an FPC
Hold an FPC
You hold an FPC vertically when installing it into the chassis or an equipment rack. When
carrying an FPC, you can hold it either vertically or horizontally.
To hold an FPC vertically, follow this procedure (see Figure 4):
1. Orient the FPC so that the faceplate is facing you.
2. Place one hand around the FPC faceplate, about a quarter of the way down from the top
edge. To avoid deforming the electromagnetic interference (EMI) shielding strip, do not
press hard on it.
3. Place the other hand at the bottom edge of the FPC, against the heat sink that is about
midway between the faceplate and connector edge.
Figure 4: Hold an FPC Vertically
An FPC configured with four Physical Interface Cards
(PICs) can weigh as much as 32 lb (14.5 kg). Be prepared
to accept the full weight of the FPC as you lift it.
g003148
EMI shielding strip

Hold an FPC
FPC Handling Instructions for T-series Platforms
6
If the FPC is in a horizontal position before you grasp it, place your left hand around the
faceplate and your right hand along the bottom edge.
If the FPC is in a vertical position before you grasp it (if it is installed in a router or routing
node, for example), you can place either hand around the faceplate and the other hand under
the bottom edge.
You can rest the faceplate of the FPC against your body as you carry it.
To hold an FPC horizontally, follow this procedure (see Figure 5):
1. Orient the FPC so that the faceplate is facing you.
2. Grasp the top edge with your left hand and the bottom edge with your right hand,
against the heat sinks that are about midway between the faceplate and connector edge.
You can rest the faceplate of the FPC against your body as you carry it.
Figure 5: Hold an FPC Horizontally
As you carry the FPC, take care not to bump it against anything. The components are fragile.
g003141

FPC Handling Instructions for T-series Platforms 7
Hold an FPC
Never hold or grasp the FPC in any places except those indicated in this document. In
particular, never grasp the connector edge, especially at the power connector located in the
corner where the connector and bottom edges meet (see Figure 6).
Figure 6: Do Not Grasp the Connector Edge
g003142
Hand position can damage fragile prongs
on power connector in corner

Hold an FPC
FPC Handling Instructions for T-series Platforms
8
Never carry the FPC by the faceplate with only one hand (see Figure 7).
Figure 7: Do Not Carry an FPC with Only One Hand
Do not rest any edge of an FPC directly against a hard surface (see Figure 8). If you must rest
the FPC temporarily on an edge while changing its orientation between vertical and
horizontal, use your hand as a cushion between the edge and the surface.
Figure 8: Do Not Rest the FPC on an Edge
g003143
g003144

FPC Handling Instructions for T-series Platforms 9
Install an FPC
Install an FPC
The FPC power connector is located in the corner where the bottom and connector edges
meet. If a power connector prong becomes bent, it no longer aligns with the female
connector on the midplane, and the FPC no longer functions. To avoid damaging the power
connector when installing an FPC, follow this procedure (see Figure 9):
1. Attach an ESD grounding strap to your bare wrist and connect the strap to one of the
ESD points on the chassis.
2. If any PIC in the FPC use fiber-optic cable, verify that there is a rubber safety cap over
each transceiver on the PIC faceplate. Install a cap if necessary.
3. Orient the FPC vertically (see “Hold an FPC” on page 5) with the component side facing
to the right.
4. Tilt the top of the FPC toward you slightly.
5. Carefully align the connector edge of the FPC with the appropriate empty slot in the
chassis.
6. Gently rest the bottom edge of the FPC on the bottom edge of the slot opening, making
contact a short distance forward of the power connector.
7. Tilt the top of the FPC toward the chassis until the FPC is completely vertical.
8. Slowly slide the FPC into the slot until you feel resistance.
9. Align the ejector handles on the FPC faceplate in a position close to horizontal.
10. Simultaneously turn both ejector handles clockwise until you cannot turn them farther.
For instructions about connecting cable to the PICs on the FPC, see the T320 Internet Router
Hardware Guide or T640 Internet Routing Node Hardware Guide.
Take care not to bend or otherwise damage the power
connector prongs (see Figure 9).

Contact Juniper Networks
FPC Handling Instructions for T-series Platforms
10
Figure 9: Install an FPC
Contact Juniper Networks
For technical support, contact the Juniper Networks Technical Assistance Center (JTAC) at
[e-mail]. If you are reporting a software problem, please issue the following
command from the CLI before contacting support:
user@host> request support information | save filename
For documentation issues, contact Juniper Networks at [e-mail].
When instructed by a JTAC representative to provide a core file for analysis, gzip the file,
rename the file to include your company name, copy it to ftp.juniper.net:pub/incoming, and
then send the filename, along with software version information (the output of the show
version command) and the configuration, to [e-mail].
Do not bend or damage prongs
on power connector
g003145

FPC Handling Instructions for T-series Platforms 11
Revision History
Revision History
18 August 2003—First edition.
