Juniper EX3200 Series User manual

Quick Start Guide
EX3200 and EX4200
IN THIS GUIDE
Step 1: Begin | 1
Step 2: Up and Running | 7
Step 3: Keep Going | 8
Step 1: Begin
IN THIS SECTION
Install a Power Supply (If It Is Not Installed) | 2
Install a Fan Tray (If It Is Not Installed) | 3
Mount the Switch | 4
Connect Power to the EX3200 and EX4200 | 4
To install and perform initial configuration of a Juniper Networks®EX3200 or EX4200 Ethernet Switch, you need:
•Two mounting brackets and eight mounting screws (provided)
•Electrostatic discharge (ESD) grounding strap (not provided)
•For AC power supply installation—An AC power supply (if not installed), an AC power cord with a plug appropriate for
your geographical location, and a power cord retainer (if not installed)
•For DC power supply installation—A DC power supply (if not installed) and DC power source cables (12–14 AWG—not
provided) with ring lugs (Molex 0190700067 or equivalent—not provided) attached
•Fan Tray (if not installed)
•Ethernet cable with an RJ-45 connector attached (provided)

•Management host, such as a PC, with an Ethernet port (not provided)
•Screws to secure the chassis to the rack or cabinet (not provided)
•Phillips (+) screwdriver, number 2 (not provided)
Power supplies and fan trays for EX4200-24F-S, and EX4200-48T-S switches are not shipped by default; you must order
them separately. Register product serial numbers on the Juniper Networks website and update the installation base data
if there is any addition or change to the installation base or if the installation base is moved. Juniper Networks will not be
held accountable for not meeting the hardware replacement service-level agreement for products that do not have
registered serial numbers or accurate installation base data.
Register your product(s) at https://tools.juniper.net/svcreg/SRegSerialNum.jsp.
Update your install base at https://www.juniper.net/customers/csc/management/updateinstallbase.jsp.
The fan tray and the power supply modules in the EX3200 or EX4200 switches are hot-removable and hot-insertable
field-replaceable units (FRU): You can remove and replace them without powering off the switch or disrupting switch
functions.
NOTE: EX4200 switches support power supplies and a fan tray with AIR OUT airflow direction.
Install a Power Supply (If It Is Not Installed)
1. Remove the power supply from the bag. Take care not to touch power supply components, pins, leads, or solder
connections.
2. Push down on the locking lever on the left front of the power supply until it is in its lowest position (see the figure
under Connect Power to the EX3200 and EX4200 for the location of the locking lever). You might need to loosen the
locking lever screw to move the lever.
3. Using both hands, place the power supply in the power supply slot on the rear panel of the switch and slide it in until
it is fully seated.
2

4. Push the locking lever up to its highest position (this action might pull the power supply in). Tighten the locking lever
screw.
Install a Fan Tray (If It Is Not Installed)
CAUTION: When you are installing a fan tray, ensure that the fans face downward.
1. Remove the fan tray from its bag. Using both hands, align the tray with the fan tray guides on the fan tray slot on the
rear panel of the chassis and slide it in until it is fully seated.
2. Tighten the screws on the fan tray by using the screwdriver.
3

Mount the Switch
You can mount the switch on two posts of a 19-in. rack or cabinet by using the mounting brackets provided with the
switch.
1. Ensure that the rack is properly secured to the building in its permanent location.
NOTE: If you are mounting multiple units on a rack, mount the heaviest unit at the bottom and mount the
others from bottom to top in decreasing order of the weight of the units.
2. Align the mounting brackets along the front or rear of the side panels of the chassis depending on whether you are
front-mounting or rear-mounting the switch, and attach the mounting brackets to the chassis by using the mounting
screws. Tighten the screws.
NOTE: The switch weighs 18 lb (8.2 kg). Installing the switch requires one person to lift the switch and a
second person to secure it to the rack.
3. Have one person grasp both sides of the switch, lift the switch, and position it in the rack, aligning the mounting bracket
holes with the threaded holes in the rack rail. Align the bottom hole in each mounting bracket with a hole in each rack
rail, making sure that the chassis is level.
4. Have a second person secure the switch to the rack or cabinet by using appropriate screws.
Connect Power to the EX3200 and EX4200
IN THIS SECTION
Connecting EX3200 and EX4200 to AC power | 5
Connecting EX3200 and EX4200 to DC power | 6
NOTE: If you are interconnecting multiple switches as a Virtual Chassis, power on only one switch—the one
you will use as the master.
4

Connecting EX3200 and EX4200 to AC power
To connect power to an AC-powered switch:
1. Squeeze the two sides of the power cord retainer clip and insert the L-shaped ends of the wire clip into the holes in
the bracket on each side of the AC appliance inlet.
2. Insert the coupler end of the power cord into the AC appliance inlet.
3. Push the power cord into the slot in the adjustment nut of the power cord retainer clip. Turn the nut until it is snug
against the base of the coupler and the slot in the nut is turned 90° from the top of the switch.
4. If the AC power source outlet has a power switch, set it to the OFF (0) position.
5. Insert the power cord plug into the power source outlet.
6. If the AC power source outlet has a power switch, set it to the ON (|) position.
7. Repeat these steps for each AC power supply.
5

Connecting EX3200 and EX4200 to DC power
To connect power to a DC-powered switch:
Each DC power supply has four terminals labeled A+, B+, A–, and B–. The power supply is shipped with jumpers from the
A+ input to the B+ input tied together and jumpers from the A– input to the B– input tied together.
CAUTION: Ensure that you install the power supply module first and then install the DC input wire,
before closing input breaker ON.
WARNING: Ensure that the input circuit breaker is open so that the voltage across the DC power
source cable leads is 0 V and that the cable leads will not become active while you are connecting DC
power. Remove the screw that secures the terminal block cover and remove the cover.
1. Connect the power supply to the power sources. Secure power source cables to the power supply by screwing the
ring lug attached to the cable to the appropriate terminal (use the screw from the terminal).
•To connect a power supply to a power source: Leave the jumpers in place and secure the positive power source
cable to the A+ terminal and the negative power source cable to the A– terminal.
•To connect one power supply to two power sources: Remove the jumpers and secure the positive power source
cable of the first power source to the A+ terminal and the negative power source cable to the A– terminal. Then
secure the positive power source cable of the second power source to the B+ terminal and the negative power source
cable to the B– terminal.
2. Replace the terminal block cover and secure it by using the screw.
3. Close the input circuit breaker. Verify that the LEDs on the power supply are lit green and are on steadily.
4. Repeat these steps for each DC power supply.
6

Step 2: Up and Running
NOTE: Before you begin the configuration, enable a DHCP client on the management PC that you connect to
the switch so that the switch can obtain an IP address dynamically.
NOTE: Read the following steps before you begin the configuration. Complete the initial configuration within
10 minutes by using EZSetup. The LCD panel displays a countdown timer when the switch is in initial setup
mode. The switch exits EZSetup after 10 minutes and reverts to the factory configuration, and the PC loses
connectivity to the switch.
1. Transition the switch into EZSetup mode by using the Menu and Enter buttons located to the right of the LCD panel:
•Press Menu until you see MAINTENANCE MENU. Then press Enter.
•Press Menu until you see ENTER EZSetup. Then press Enter.
If EZSetup does not appear as an option in the menu, select Factory Default to return the switch to the factory default
configuration. EZSetup is displayed in the menu only when the switch is set to the factory default configuration.
•Press Enter to confirm setup and continue with EZSetup.
Connect the Ethernet cable from the Ethernet port on the PC to port 0 (ge-0/0/0) on the front panel of the switch.The
ge-0/0/0 interface is now configured as a DHCP server with the default IP address, 192.168.1.1. The switch can assign
an IP address to the management PC in the IP address range 192.168.1.2 through 192.168.1.253.
2. From the PC, open a Web browser, type http://192.168.1.1 in the address field, and press the Enter key.
3. On the J-Web login page, enter root as the username, leave the Password field blank, and click Login.
4. On the Introduction page, click Next.
5. On the Basic Settings page, enter the hostname, enter and reenter a password, specify the time zone, and synchronize
the switch date and time settings with the management PC or set them manually. Then, click Next.
6. Use the Management Options page to select the management scenario:
•In-band Management—Use VLAN ‘default’ for management
Select this option to configure all data interfaces as members of the default VLAN. Click Next. Specify the management
IP address and the default gateway.
•In-band Management—Create new VLAN for management
Select this option to create a management VLAN. Click Next. Specify the VLAN name, VLAN ID, member interfaces,
and management IP address and default gateway for the new VLAN.
7

•Out-of-band Management—Configure management port
Select this option to configure only the management interface. Click Next. Specify the IP address and default gateway
for the management interface.
7. Click Next.
8. On the Manage Access page, you can select options to enable Telnet, SSH, and SNMP. For SNMP, you can configure
the read community, location, and contact.
9. Click Next. The Summary page displays the settings you have selected.
10. Click Finish. The configuration is committed as the active switch configuration. You can now log in by using the CLI or
the J-Web interface to continue configuring the switch.
NOTE: After the configuration is committed, the connectivity between the PC and the switch might be lost. To
reconnect, release and renew the IP address by executing the appropriate commands on the PC or by removing
and reinserting the Ethernet cable.
Step 3: Keep Going
IN THIS SECTION
Safety Warnings Summary | 8
Power Cable Warning (Japanese) | 9
Contacting Juniper Networks | 9
See the complete EX3200 and EX 4200 documentation at https://www.juniper.net/documentation/product/en_US/ex3200
and https://www.juniper.net/documentation/product/en_US/ex4200.
Safety Warnings Summary
This is a summary of safety warnings. For a complete list of warnings, including translations, see the complete EX3200
and EX4200 documentation at https://www.juniper.net/documentation/product/en_US/ex3200 and
https://www.juniper.net/documentation/product/en_US/ex4200.
8

WARNING: Failure to observe these safety warnings can result in personal injury or death.
•Permit only trained and qualified personnel to install or replace switch components.
•Perform only the procedures described in this quick start and the EX Series documentation. Other services must be
performed only by authorized service personnel.
•Before installing the switch, read the planning instructions in the EX Series documentation to make sure that the site
meets power, environmental, and clearance requirements for the switch.
•Before connecting the switch to a power source, read the installation instructions in the EX Series documentation.
•Installing the switch requires one person to lift the switch and a second person to install mounting screws. To prevent
injury, keep your back straight and lift with your legs, not your back.
•If the rack has stabilizing devices, install them in the rack before mounting or servicing the switch in the rack.
•Before installing or after removing an electrical component, always place it component-side up on an antistatic mat
placed on a flat, stable surface or in an antistatic bag.
•Do not work on the switch or connect or disconnect cables during electrical storms.
•Before working on equipment that is connected to power lines, remove jewelry, including rings, necklaces, and watches.
Metal objects heat up when connected to power and ground and can cause serious burns or become welded to the
terminals.
Power Cable Warning (Japanese)
The attached power cable is only for this product. Do not use this cable for another product.
g040300
Contacting Juniper Networks
For technical support, see:
http://www.juniper.net/support/requesting-support.html
9

Juniper Networks, the Juniper Networks logo, Juniper, and Junos are registered trademarks of Juniper Networks, Inc. in the
United States and other countries. All other trademarks, service marks, registered marks, or registered service marks are the
property of their respective owners. Juniper Networks assumes no responsibility for any inaccuracies in this document. Juniper
Networks reserves the right to change, modify, transfer, or otherwise revise this publication without notice. Copyright © 2020
Juniper Networks, Inc. All rights reserved. Rev. 01, June 2020.
