Jupiter Avionics JCP3-070 User manual

JCP3-070
Control Panel with RX Volume Controls
Installation and Operating Manual
Rev A
Jupiter Avionics Corporation
1959 Kirschner Road
Kelowna BC
Canada V1Y 4N7
Tel: [phone]
Toll-Free: 1 855 478 2232
www.jupiteravionics.com

JCP3-070 Control Panel with RX Volume Controls
Installation and Operating Manual
Rev A Page ii
Copyright 2019 Jupiter Avionics Corp.
All rights reserved
Jupiter Avionics Corporation (JAC) permits a single copy of this manual to be printed or downloaded for the express
use of an installing agency. Any such electronic or printed copy of this manual must contain the complete text of this
copyright notice. Any unauthorized commercial distribution of this manual is strictly prohibited. Except as described
above, no part of this manual may be reproduced, copied, transmitted, disseminated, downloaded, or stored in any
storage medium for any purpose without the express prior written consent of JAC.
RECORD OF REVISIONS
Revision
Rev Date
Description
ECR
A
Oct 2019
Initial release, Serial number 1001 and higher.
6241
Prepared:
MPB
Checked:
Approved:
IMPORTANT:
Information in this document is subject to change without notice.
To confirm the current revision status of this manual, visit the JAC website:
www.jupiteravionics.com
JAC
SRM
11-06-19 JAC
KDV
11-06-19

JCP3-070 Control Panel with RX Volume Controls
Installation and Operating Manual
Rev A Page iii
Table of Contents
SECTION 1 - DESCRIPTION........................................................................................................................................... 1
1.1 System Overview.............................................................................................................................................. 1
1.2 Features Overview............................................................................................................................................ 1
1.3 Inputs and Outputs ........................................................................................................................................... 2
1.3.1 Inputs ........................................................................................................................................................ 2
1.3.2 Outputs ..................................................................................................................................................... 2
1.3.3 Bi-directional Signals ................................................................................................................................ 2
1.4 Specifications.................................................................................................................................................... 2
1.4.1 Electrical Specifications ............................................................................................................................ 2
1.4.2 Mechanical Specifications ........................................................................................................................ 3
SECTION 2 – INSTALLATION ........................................................................................................................................ 4
2.1 Introduction ....................................................................................................................................................... 4
2.2 Continued Airworthiness................................................................................................................................... 4
2.3 Unpacking and Inspecting Equipment .............................................................................................................. 4
2.3.1 Warranty ....................................................................................................................................................... 4
2.4 Installation Procedures ..................................................................................................................................... 4
2.4.1 Installation Limitations .................................................................................................................................. 4
2.4.2 Cabling and Wiring ....................................................................................................................................... 4
2.4.3 Mechanical Installation ................................................................................................................................. 5
2.4.4Legend Replacement.................................................................................................................................... 5
2.4.5Post Installation Checks ............................................................................................................................... 5
2.5 Legend Text Selection using ProCS™ ............................................................................................................. 6
2.6 Adjustments and Configuration using ProCS™ ............................................................................................... 7
2.6.1 ProCS™ Setup ......................................................................................................................................... 7
2.6.2 Configuring the JRAC-xxx Remote Audio Controller via the JCP3-070 ................................................... 7
2.7 Installation Kit ................................................................................................................................................... 7
2.7.1 Recommended Crimp tools ...................................................................................................................... 7
2.8 Installation Drawings......................................................................................................................................... 7
SECTION 3 – OPERATION ............................................................................................................................................. 8
3.1 Introduction ....................................................................................................................................................... 8
3.2 Front Panel Controls......................................................................................................................................... 8
(1) Individual Receive Volume Controls ........................ .................................................................................... 9
(2) Transceiver Switches ................................................................................................................................... 9
(3) Receiver Switches ........................................................................................................................................ 9
(5)EMER/NORM Mode Switch.......................................................................................................................... 9
(6)Multi-function (Transmit/ICS) Switch .......................................................................................................... 10
(7)Music/Configuration Connector Cover (♫/io).............................................................................................. 10
(8)Transmit Annunciator - TX.......................................................................................................................... 10
(9)Transmit Selector........................................................................................................................................ 11
(10)VOX Threshold Control............................................................................................................................... 11
(11)CALL Annunciator....................................................................................................................................... 11
(12)ICS Volume Control .................................................................................................................................... 11
3.3 Normal Operation Mode ................................................................................................................................. 12
3.3.1 Panel Lighting ......................................................................................................................................... 12
3.3.2 Receiving ................................................................................................................................................ 12
(4) Master Receive Volume Control .................................................................................................................. 9

JCP3-070 Control Panel with RX Volume Controls
Installation and Operating Manual
Rev A Page iv
3.3.3 Transmitting (Transmit Operation).......................................................................................................... 12
3.3.4 VOX Operation ....................................................................................................................................... 12
3.3.5 ICS Operation.......................................................................................................................................... 12
3.3.6 Multi-Function (XMIT / ICS) Switch Operation ....................................................................................... 12
3.3.7 Music Operation ..................................................................................................................................... 13
3.4 Emergency Operation Mode........................................................................................................................... 13
Appendix A - Installation Drawings ........................................................................................................................... A1
A1 Introduction .....................................................................................................................................................A1
A2 Installation Drawings.......................................................................................................................................A1
Appendix B - Certification Documents...................................................................................................................... B1
B1 Airworthiness Approval ...................................................................................................................................B2
B2 Instructions for Continued Airworthiness ........................................................................................................B2

Rev A Page 1
JCP3-070 Control Panel with RX Volume Controls
SECTION 1 - DESCRIPTION
1.1 System Overview
The JCP3-070 Control Panel with RX Volume Controls is part of an aircraft audio system consisting of one control
panel and one remote audio controller.
Figure 1-1 Aircraft Audio System
The JCP3-070 has the switches and level controls that allow the user to operate the remote audio controller. Control
commands are sent to the remote audio controller via a serial data bus from the control panel. The control commands
manage the user selectable functions of the audio system. The control panel provides a locking toggle switch with a
discrete output that places the remote audio controller in emergency operating mode.
The JCP3-070 front panel music / configuration connector provides a discrete path to the JRAC music / configuration
connections. Configuration settings can be sent to the JRAC using a configuration cable and a PC running the product
configuration application ProCSTM. To facilitate future customizations and certification, neither software nor complex
electronic devices are used in the JCP3-070 design.
1.2 Features Overview
The JCP3-070 features a 15 pin D-Min connector, which interfaces to the remote audio controller. The JCP3-070
input power is derived from the remote audio controller.
The JCP3-070 has 1 rotary 6-position transmit selector switch and 6 transmit select annunciators.
The JCP3-070 has a transmit active annunciator
The JCP3-070 has 6 toggle transceiver monitor switches
The JCP3-070 has a call annunciator
The JCP3-070 has 2 center-off toggle receiver monitor switches.
The JCP3-070 has 1 of each rotary 16-position VOX threshold control,. ICS volume control and RX volume control
The JCP3-070 has 1 locking toggle Emergency / Normal mode select switch.
The JCP3-070 has 1 spring load center off toggle switch, nominally for ICS and TX PTT control.
A 3.5mm Music / Configuration connector is provided on the faceplate of the JCP3-070 for downloading configuration
data to the remote audio controller Remote Audio Controller. The connector can also be used as a music input and is
compatible with most music players.

R
1
R
i
n
1
1
1
1
1
1
R
ev
A
1
.3
R
efer to the J
n
put and out
p
1
.3.1
1
.3.2
1
.3.3
1
.4
1
.4.1
Power In
p
1
.4.1.1
Volume
C
Inputs
a
CP3-070 co
n
p
ut signals.
Inputs
Name
CALL AN
N
CONTRO
L
MUSIC L
E
+5/+28 V
D
MODE S
E
POWER I
N
RESET I
N
TX ANNU
CONFIG
D
CONTRO
L
CONFIG
D
A
UDIO C
O
Outputs
Name
CONFIG
D
A
UDIO C
O
CONFIG
D
CONTRO
L
CONTRO
L
MODE S
E
NORM M
O
Ground
s
Name
POWER
G
CHASSIS
MUSIC/C
O
Specifi
c
Electrica
p
ut
Primary n
o
Input curr
e
Audio Pe
r
C
ontrols
Master R
e
Receive
A
nd Outpu
t
n
nector maps
N
UNCIATOR
L
DATA TO
J
E
FT/ MUSIC
R
D
C LIGHTS I
N
E
LECT / CON
N
PUT
N
PUT
N
CIATOR
D
ATA TO RE
L
LER
D
ATA FROM
R
O
NTROLLE
R
D
ATA FROM
R
O
NTROLLE
R
D
ATA TO RE
L
LER
L
DATA FRO
E
LECT / CON
O
DE SELEC
T
G
ROUND
GROUND
O
NFIG COM
M
c
ations
l Specifica
t
o
minal voltag
e
e
nt
r
formance
e
ceive Audio
C
udio Control
s
t
s
for the matin
CP3
R
IGHT
N
PUT
FIG AUDIO
MOTE AUDI
O
R
EMOTE
R
EMOTE
MOTE AUDI
O
M JCP3
FIG AUDIO
T
M
ON
t
ions
e
(from remo
t
C
ontrol varia
t
s
variation
JCP3-
g connector
d
Qty Ty
p
1
A
c
t
1 Da
t
2
A
u
d
2
A
n
a
1 Mu
1 Po
w
1
A
c
t
1
A
c
t
O
1 Da
t
1 Da
t
Qty Ty
p
1 Da
t
O
1 Da
t
1 Da
t
1 Mu
1
A
c
t
Qty Ty
p
1 Gr
o
1 Gr
o
2 Gr
o
t
e audio cont
r
ion
070 Contr
o
I
d
esignators
a
p
e
t
ive low discr
e
t
a signal
d
io signal
a
log control
s
lti format sig
n
w
er Supply
t
ive low discr
e
t
ive low discr
e
t
a signal
t
a signal
p
e
t
a signal
t
a signal
t
a signal
lti format sig
n
t
ive low discr
e
p
e
o
und
o
und
o
und
r
oller)
o
l Panel wi
t
I
nstallation
a
nd pin assig
n
e
te
s
ignal
n
al
e
te
e
te
n
al
e
te
13.5 Vdc
≤0.2 A at
32 3 dB
32 3 dB
t
h RX Volu
m
and Opera
n
ments for th
e
13.5 Vdc
m
e Control
s
ting Manu
a
Page
2
e
s
al
2

JCP3-070 Control Panel with RX Volume Controls
Installation and Operating Manual
Rev A Page 3
Rated Output Power
Music rated output level 400 mVrms ±10%
Output Load
Music load 1000 Ω±10%
1.4.1.4 Discrete Signals
Active low control input, active signal level ≤+3 Vdc
Active low control input, inactive signal level ≥+9 Vdc
Active low control input signals, when active, source 0.1 to 10 mA
Active low control output, active output ≤+2 Vdc
Active low control output signals, when active, sink ≤100 mA
Active low control input signals have an internal pull-up resistor
1.4.1.5 Lights Input
LIGHTS INPUT current 10 mA max.
1.4.2 Mechanical Specifications
2.625 in [66.7 mm] max
1.65 in [41.9 mm] max
1.22 in [31.0 mm] max
5.75 in [146.1 mm] max
4.95 in [125.7 mm] max
1.12 lb [0.53 kg] max
5052-H32 brushed aluminum with
conversion coating
J1 (System) One 15-pin D-Sub male, V5 locking
J2 (Music /configuration) One 4 pole 3.5mm stereo jack
J3
J4 (Rear stud fastener)
Maintenance only access
One 4-40,0.5 in. max
4 Dzus fasteners
≤2.5 mΩ
INST-JCPX
Height
Behind panel depth
In front of panel depth
Faceplate width
Behind panel width
Weight
Enclosure material
Connectors (4):
Mounting
Bonding
Installation kit partnumber
Rated Input Level
Music rated input 400 mVrms ±10%

Rev A Page 4
JCP3-070 Control Panel with RX Volume Controls
SECTION 2 – INSTALLATION
2.1 Introduction
This section contains unpacking and inspection procedures, installation information, and post-installation checks.
2.2 Continued Airworthiness
Maintenance of the JCP3-070 is on condition only. Scheduled inspection and/or periodic maintenance of this unit is
not required.
2.3 Unpacking and Inspecting Equipment
Unpack the equipment carefully. Check for shipping damage and report any problems to the relevant carrier. Confirm
that the Authorized Release Certificate or Certificate of Conformance is included. Complete the on-line warranty card
from the Jupiter Avionics Corporation (JAC) website – www.jupiteravionics.com/warrantyregistration.
2.3.1 Warranty
All products manufactured by JAC are warranted to be free of defects in workmanship or performance for 2 years
from the date of installation by an approved JAC dealer or agency. This warranty covers the cost of all materials and
labour to repair or replace the unit, but does not include the cost of transporting the defective unit to and from JAC or
its designated warranty repair centre, or of removing and replacing the defective unit in the aircraft. This warranty
does not cover failures due to abuse, misuse, accident, or unauthorized alteration or repairs.
THIS WARRANTY IS VOID IF THE PRODUCT IS NOT INSTALLED BY AN AUTHORIZED JAC DEALER. If the on-
line warranty card is not completed, the product will be warranted from the date of manufacture.
Contact JAC for return authorization, and for any questions regarding this warranty and how it applies to your unit(s).
JAC is the final arbiter concerning warranty issues.
2.4 Installation Procedures
WARNING: Loud noise can cause hearing damage. Set the headset volume to minimum before
conducting tests, and slowly increase the volume to a comfortable listening level.
CAUTION: The power input circuitry of the unit may be damaged if the installation does not conform to the
wiring instructions in this manual.
2.4.1 Installation Limitations
The JCP3-070 may be installed only by following the applicable airworthiness requirements.
2.4.2 Cabling and Wiring
All wire shall be selected in accordance with the original aircraft manufacturer’s maintenance instructions, or AC43.13-
1B Change 1, Paragraphs 11-76 through 11-78. Unshielded wire types shall qualify to MIL-W-22759 as specified in
AC43.13-1B Change 1, Paragraphs 11-85, 11-86, and listed in Table 11-11. For shielded wire applications, use Tefzel
MIL-C-27500 shielded wire with tag ring or equivalent (for shield terminations) to make the most compact and easily
terminated interconnect. Follow the Connector Map in Appendix A of this manual.

JCP3-070 Control Panel with RX Volume Controls
Installation and Operating Manual
Rev A Page 5
Allow 3” from the end of the shielded wiring to the shield termination to allow the connector hood to be easily installed.
Refer to the Interconnect drawing in Appendix A of this manual for shield termination details. Note that this unit has a
‘clamshell’ hood that is installed after the wiring is complete.
Maintain wire segregation and route wiring in accordance with the original aircraft manufacturer’s maintenance
instructions.
Refer to the Interconnect drawing for additional specifications. Check that the ground connection is clean and well
secured, and that it shares no path with any electrically noisy aircraft accessories such as blowers, turn-and-bank
instruments, or similar loads.
2.4.3 Mechanical Installation
The JCP3-070 can be mounted in any attitude and location with adequate space for the front panel and sufficient
clearance for the connector and wiring harness. It requires no direct cooling.
2.4.4 Legend Replacement
The JCP3-070 illuminated legends are field replaceable. For further information, refer to the ‘Legend Replacement’
document in Appendix A of this manual.
2.4.5 Post Installation Checks
2.4.5.1 Voltage/Resistance checks.
Do not attach this unit until the following conditions are met:
a) Check P1 between pins 1and 9 for +13 Vdc power.
b) Check P1 pin 14 for +5 Vdc lights voltage or P1 pin 15 for +28 Vdc lights voltage.
c) Check P1 pin 10 (Chassis ground) for continuity to ground (less than 0.5 Ω).
d) Confirm P1 pin 13 (RESET INPUT) is connected to the Remote Audio Controller P3 pin 13 (RESET
OUTPUT)
e) Check all pins for shorts to ground or adjacent pins.
2.4.5.2 Power on Checks.
Power up the aircraft’s systems and confirm normal operation of all functions of the JCP3-070. Refer to
Section 3 (Operation) for specific operational details.
a) Begin with only the pilot’s headset attached. Confirm correct ICS and radio operation for both receive and
transmit. Check yoke or cyclic switch action. Check the radio selection and inputs. Do not proceed until the
radios are functioning correctly.
b) If there is a music source in the system, turn it on and check for proper mute operation.
c) Unusual buzzes, hums or other background audio are symptomatic of multiple grounds, or noisy external
systems such as blowers or pumps sharing wiring with the audio system. If a transmitter fails to key or
correctly modulate it is often the result of not connecting all required grounds to the radio or external audio
system.
d) Check the ICS operation and Emergency operation.
e) Plug in the co-pilot’s headset. Check for correct ICS operation. Check yoke or cyclic switch functions.
f) Plug in any remaining headsets, and check for correct ICS operation. Note that an incorrect cordset (drop cord)
or improper jack wiring may cause a wide range of problems, from loss of audio to a tone heard in the headset.
g) Check that all configurations settings are correct.
When all performance checks are satisfied, complete the necessary regulatory documentation before releasing the
aircraft for service. Refer to Appendix B.

JCP3-070 Control Panel with RX Volume Controls
Installation and Operating Manual
Rev A Page 6
2.5 Legend Text Selection using ProCS™
The configuration program ProCS™can be used to customize the text for eachlegend either at the time of ordering
the unit, oriftext changes arerequired after installation. The JCP3-070 need not be connected toa computer to
select the legend text.
For information on ordering customized legends, refer to How to Order aCustom Unit or the Configuration Chart on
the JAC website and in Appendix A of this manual.
2.5.1 Virtual Front Panel
The Virtual Front Panel window is used to specify the text for each legend.
In the example shown here, the option ‘New…’ has been selected. A pop-up
‘New Label’ window will appear, allowing the user to create a customized
legend – in this case, JAC. The new legend name will now be shown in the
appropriate position on the faceplate representation in the software
program, and will be used in the connector maps and interconnect.
Note: If the name of a front panel switch is changed using this software, the change will be incorporated in
the connector maps and interconnect, to give truly customized installation diagrams.
2.5.2 Connector Maps
This section contains connector maps and interconnects that are automatically generated to show changes to switch
labels that affect the installation of the remote audio controller.
Among the options is ‘- - - -‘ which signifies that
the legend will be left blank, and ‘New…’ which
allows the user to enter a completely new
legend of up to five characters. If a ‘new’
legend has been added, the option ‘Edit …’ is
added to the menu to enable changes to the
newly created label.
Clicking on a customizable legend will open a drop-down
menu listing the options for that label. The currently
selected option will be highlighted. To escape from the
menu, click on the desired option, or right-click in the
window. A 'Print…’ box will appear. Click outside the box to
escape, or select it to print the 'Virtual Front Panel window
showing the current label selections.

JCP3-070 Control Panel with RX Volume Controls
Installation and Operating Manual
Rev A Page 7
2.6 Adjustments and Configuration using ProCS™
2.6.1 Configuring the JRAC-xxx Remote Audio Controller via the JCP3-070
The JCP3-070 has no internal adjustments;however, configuration data for the remote audio controller Remote Audio
Controller can be sent via the JCP3-070 front panel connector (♫/io), using the configuration program ProCS™. For
full information on configuring the remote audio controller, refer to the remote audio controller manual on the JAC
website.
The front panel Music/Configuration port
(♫/io) is protected by a urethane rubber
cover, which can be lifted upwards or
rotated round (as shown) to provide access
to the port
♫/io port
Port cover
For full information on the configuration process, refer to the ProCS™ manual on the Jupiter Avionics website.
2.6.2 ProCS™ Setup
The JCP3-070 menu items 'ProCS Setup' provide Setup drawings showing different cabling arrangements for
connecting the JCP3-070 to a computer and other equipment.
ProCS Setup - JA99,ProCS Setup - CAB-USB-0006 and ProCS Setup - Virtual Panel show the connections used
for testing the JCP3-070. These setup drawings would not be used in normal operation.
ProCS Setup - JRAC-001 shows the cabling for using the JCP3-070 for configuring the JRAC Remote Audio
Controller using ProCS™ (see section 2.6.1 above).
2.7 Installation Kit
The kit required to install this unit is not included with the unit.
The installation kit (Part # INST-JCPx) consists of the following:
Quantity Description JAC Part #
1 0.375" Inside Diameter TAG ring CON-5500-0375
1 D-Sub 15-pin connector, hood and 15 crimp pins CON-3420-0015
1 3/4" I/D Heat Shrink Tubing WIR-HTSK-0750
2.7.1 Recommended Crimp tools
Connector Type
Hand crimp tool
Positioner
Insertion/extraction tool
Positronic
9507
9502-3
M81969/1-04
Positronic
AFM8 (Daniels)
M22520/2.08 KB-1
2.8 Installation Drawings
The drawings and documents required for Installation can be found in Appendix A of this manual.

Rev A Page 8
JCP3-070 Control Panel with RX Volume Controls
SECTION 3 – OPERATION
3.1 Introduction
This section contains the operating instructions for the JCP3-070.
The JCP3-070 acts as a Control Panel for a remote audio controller such as the Jupiter Avionics JRAC-001.
The JCP3-070 commands the remote audiocontroller, and this manual iswritten to describe the results of any
operation of the JCP3-070 controls.
3.2 Front Panel Controls
Note: The legends and annunciators are removable and may be replaced with custom ordered parts. For the
purpose of this manual the controls will be referred to by the default names as shown below.
1. Individual Receive Volume Controls 7. Music/configuration port cover and legend (♫/io)
2. Transceiver switches and associated legends 8. Transmit annunciator (deadfront)
3.Receiver switches and associated legends 9. Transmit selector
4.Master Receive volume control 10. VOX threshold control
5. EMER/NORM switch 11. CALL annunciator (deadfront)
6. Pilot’s Transmit/ICS (Multi-function) switch 12. ICS volume control
2
3
4
11
7
6
5
8
9
12
10
1

JCP3-070 Control Panel with RX Volume Controls
Installation and Operating Manual
Rev A Page 9
(1) Individual Volume Controls
These are eight non-illuminated rotary controls,
each of which is associated with the COM or
NAV switch below it.
Rotating a control clockwise (cw) will increase
the volume of the associated radio, and rotating
it counterclockwise (ccw) will reduce it.
(2) Transceiver Switches
These are six white two-position toggle switches.
When a switch is set to the ‘up’ position, audio from
the associated transceiver is routed to the phones.
The legends (above the switches) are
interchangeable to allow customization.
(Default – COM1, COM2, COM3, COM4, COM5
and COM6)
(3) Receiver Switches
These are two blue two-position centre-off
toggle switches. When a switch is set to the ‘up’
or ‘down’ position audio from the selected
receiver is routed to the phones.
The legends (two above and two below the
switches) are interchangeable to allow
customization. (Default – NAV1, NAV2, NAV3,
N4&5.)
(4) Master Receive Volume Control
This is a rotary knob that adjusts the phones volume of
the receive audio from minimum - fully counterclockwise
(ccw) to maximum - fully clockwise (cw). Individual radio
volume controls should be set to a nominal level, and
then adjusted for changing flight conditions using this
control.
(5) EMER/NORM Mode Switch
This is a red two-position locking toggle switch. When set to the ‘up’
position, the unit is Emergency mode, and when set to the ‘down’
position, the unit is in Normal mode. The legends are
interchangeable to allow customization. (Default – EMER, NORM.)
The switch is lockable to prevent accidental changing of the mode.
The switch must be lifted to release the lock.
For full information on Emergency and Normal Mode operation, see
sections 3.3 and 3.4 below.

JCP3-070 Control Panel with RX Volume Controls
Installation and Operating Manual
Rev A Page 10
(6) Multi-function (Transmit/ICS) Switch
This is a green two-position centre-off momentary toggle switch.
When in the default XMIT/ICS configuration, this switch acts as the
pilot’s ‘Press-to-talk’ (PTT) button. The unit will transmit on the
selected transceiver when the switch is held in the ‘up’ position, and
when held in the ‘down’ position, it will transmit on the intercom.
See section 3.3.6 below for Multi-function Switch operation.
Note: At installation, this switch may be configured to operate in default (XMIT/ICS) or alternative mode.
Check with your installing agency for confirmation of the operation of this switch. The legends are
interchangeable to allow customization.
(7) Music/Configuration Connector Cover (♫/io)
This is a music input that is compatible with most music players.
It accepts a 3 pole 3.5mm stereo plug with a slim diameter
connector housing.
(This connector may also used during installation to change
configuration settings for the remote audio controller.)
The port (♫/io) is protected by a urethane rubber cover, which can be
lifted upwards or rotated round (as shown) to provide access to the
port.
♫/io port
Port cover
CAUTION: If an unapproved connector or cable is used, damage to the unit or to any attached device may
occur. If in doubt, contact JAC for a list of approved cables, music sources and devices.
(8) Transmit Annunciator - TX
This is a deadfront annunciator that will illuminate
when the remote audio controller is transmitting.
The default legend is ‘TX’, but it is interchangeable
to allow customization.

JCP3-070 Control Panel with RX Volume Controls
Installation and Operating Manual
Rev A Page 11
(9) Transmit Selector
This is a rotary six-position control that is used to
select transmission via one of the six transceivers.
Each of the transmit selector positions is linked by a
white line to the corresponding transmit select
annunciator, transceiver switch and legend.
The appropriate annunciator will light green to show
which transceiver is selected for transmit - ‘COM4’ in
this example.
(10)VOX Threshold Control
This is a rotary knob that is used to select the VOX threshold of
the unit. See below.
When rotated fully cw, the threshold will be at maximum and
VOX ICS operation is disabled and ICS PTT input is required for
ICS operation.
When rotated fully ccw, the threshold will be at minimum (almost
live).
To adjust the unit for VOX (Voice activated) use, the VOX control should be set fully ccw and then slowly rotated cw to
the point where no intercom audio can be heard. The VOX control should be adjusted for proper operation according
to the ambient noise.
(11 CALL Annunciator
This is a customizable deadfront annunciator activated by
an external switch.
When enabled, it will illuminate when a call is received from
another user’s audio controller, or by a remote ‘call’ button
within the aircraft.
Note: Check with your installing agency for confirmation of the operation of this annunciator. The legends
are interchangeable to allow customization.
(12) ICS Volume Control
This is a rotary control used to adjust the volume of all
ICS audio to suit the ambient conditions. Rotating the
control fully cw gives rated level, and fully ccw reduces
the output to minimum level.

JCP3-070 Control Panel with RX Volume Controls
Installation and Operating Manual
Rev A Page 12
3.3 Normal Operation Mode
Note: Numbers in parentheses refer to the front panel controls shown in section 3.2.
The Audio System is in Normal mode when the front panel EMER / NORM switch (5) is in the NORM position and
suitable electrical power is supplied to the audio system (Control Panel with RX Volume Controls, and Remote Audio
Controller).
All operation described is for an Audio System consisting of a JCP3 Control Panel with RX Volume Controls and a
JRAC Remote Audio Controller.
3.3.1 Panel Lighting
The Control Panel with RX Volume Controls legends and annunciators will be illuminated and dim (when appropriate)
through the aircraft lighting buss.
3.3.2 Receiving
When the Audio System receives an incoming transmission on a transceiver or receiver that has been selected, either
by the white transceiver receive switches (1) or the transmit selector (8), the incoming audio will be directed to the
user’s phones.
The audio level of any incoming transmission will depend upon the level selected by the front panel RX volume control
(3). It will be muted if the unit is transmitting and muting of receive audio during transmit is enabled.
3.3.3 Transmitting (Transmit Operation)
To select a transceiver, rotate the Transmit Select Switch until it aligns with the line leading to the Transceiver Select
switch legend - see (1) - default legends COM 1 through COM 6. The corresponding Transmit Select annunciator will
illuminate.
When the user’s TX PTT is activated, the Audio System will transmit on the selected transceiver, and the deadfront
Transmit Annunciator (7) will illuminate ‘TX’. All MIC and sidetone audio will be routed to the user’s phones, and any
music will be muted for the duration of the transmission.
3.3.4 VOX Operation
A user’s MIC audio is routed to the ICS when the MIC audio level exceeds the VOX threshold.
A user’s MIC audio is disconnected from the ICS when the MIC audio level falls below the VOX threshold for 0.5 to 2
seconds. The VOX level is controlled by the VOX knob (9).
3.3.5 ICS Operation
ICS audio routed to the PHONES is the sum of all the MIC audio from users with ICS KEY active or with MIC audio
level exceeding the VOX Threshold level.
The ICS audio routed to the PHONES also includes the audio input on the ICS TIE from other audio controllers.
The sum of all the MIC audio from users with ICS KEY active or with MIC audio level exceeding the VOX Threshold
level is output on the ICS TIE line.
The ICS audio is muted during transmit (if selected via ProCS).
The ICS audio level at the phones is controlled by the ICS volume control (11).

JCP3-070 Control Panel with RX Volume Controls
Installation and Operating Manual
Rev A Page 13
3.3.6 Multi-Function (XMIT / ICS) Switch Operation
Note: At installation, this switch may be configured to operate in default or alternative mode. Check with
your installing agency for confirmation of the operation of this switch.
Default Operation
When in the default XMIT/ICS configuration, this switch acts as the pilot’s ‘Press-to-talk (PTT) button. The Audio
System will transmit on the selected transceiver when the switch is set to the ‘up’ position, and when set to the ‘down’
position, it will transmit on the intercom.
Alternative Operation
This switch may be configured to provide a ground signal to operate other equipment.
3.3.7 Music Operation
Music to the phones will be muted by incoming audio (ICS, Receive, Direct or Alert Audio) or if the Audio System is
transmitting. When the incoming audio has ended, the music will gradually return to the previous level.
3.4 Emergency Operation Mode
Emergency mode can be selected by the EMER / NORM switch on the Control Panel with RX Volume Controls.
Refer to the controlled device operating manual for information on operation during emergency mode.

Rev A Page A1
JCP3-070 Control Panel with RX Volume Controls
Installation and Operating Manual
Appendix A - Installation Drawings
A1 Introduction
The drawings necessary for installation and troubleshooting of the JCP3-070 Control Panel with RX Volume Controls
are in this Appendix, as listed below.
Note: A fully customized set of Connector Maps and Interconnects can be created using the ProCS™
software. Refer to the ProCS™ manual for further information.
A2 Installation Drawings
DOCUMENT Rev
JCP3-070 Connector Map A
JCP3-070 Interconnect A
JCP3-070 Mechanical Installation A
Reference Documents
TOL-CUST-EXTR Legend Replacement A
JCP3-070 Configuration Chart (DOC-CONF-P3X70) (A)

JUPITER AVIONICS TEMPLATE AUTOCAD PORTRAIT SIZEA REV B.DWT
TITLE
APPROVED
PREPARED
CHECKED
L00N3
NCAGE CODE PART NO. SHEET
DOC NO.
CONFIDENTIAL & PROPRIETARY
TO JUPITER AVIONICS CORP.
Control Panel with RX Volume Controls
P1 Main Connector
JCP3-070 1/2
JCP3-070 Connector Map Rev A.dwg
TAT
POWER INPUT CONTROL DATA TO JCP3 CONTROL DATA FROM JCP3 NORM MODE SELECT MUSIC LEFT/CONFIG DATA TO REMOTE AUDIO CONTROLLER
POWER GROUND CHASSIS GROUND CALL ANNUNCIATOR TX ANNUNCIATOR
P1
15 PIN FEMALE DMIN
MATING CONNECTOR
1 2 3 4 5
9 10 11 12
6 7 8
14 1513
MUSIC / CONFIG COMMON MUSIC RIGHT/CONFIG DATA FROM REMOTE AUDIO CONTROLLER MODE SELECT/CONFIG AUDIO
RESET INPUT +5 VDC LIGHTS INPUT +28 VDC LIGHTS INPUT
VIEW IS FROM REAR OF MATING CONNECTOR
MAIN CONNECTOR
JAC
AH
10-31-19
JAC
KDV
10-31-19

JUPITER AVIONICS TEMPLATE AUTOCAD PORTRAIT SIZEA REV B.DWT
TITLE
APPROVED
PREPARED
CHECKED
L00N3
NCAGE CODE PART NO. SHEET
DOC NO.
CONFIDENTIAL & PROPRIETARY
TO JUPITER AVIONICS CORP.
Control Panel with RX Volume Controls
P2 and P3 Connector Map
JCP3-070 2/2
JCP3-070 Connector Map Rev A.dwg
TAT
P2
4 POLE MALE 3.5MM STEREO
TIP: TX DATA
1ST RING: RX DATA
2ND RING: GROUND
3RD RING: CONFIG AUDIO
PLUG FORMATS
JA99 CONFIGURATION CABLE
IPHONE 3GS OR 4 TIP: LEFT MUSIC 1ST RING: RIGHT MUSIC
2ND RING: GROUND
MP3 STEREO PLAYER,
MATING PLUG NAMES JCP3 SIGNAL NAMES
CONFIG DATA TO AUDIO CONTROLLER
CONFIG DATA FROM AUDIO CONTROLLER
MUSIC / CONFIG COMMON
MODE SELECT / CONFIG AUDIO
FRONT PANEL MUSIC LEFT
FRONT PANEL MUSIC RIGHT
MUSIC / CONFIG COMMON
FRONT PANEL MUSIC / AUDIO CONTROLLER CONFIGURATION CONNECTOR
3 POLE MALE 3.5MM STEREO
P3
4 POLE MALE 3.5MM STEREO
TIP: TX DATA
1ST RING: RX DATA
2ND RING: GROUND
3RD RING: MODE SELECT
JA99 CONFIGURATION CABLE
MATING PLUG NAMES JCP3 SIGNAL NAMES
CONFIG DATA TO JCP3
CONFIG DATA FROM JCP3
GROUND
MODE SELECT
JCP3 CONFIGURATION CONNECTOR
ACCEPTS THE FOLLOWING
PLUG FORMATS
ACCEPTS THE FOLLOWING
(ACCESSIBLE DURING MAINTENANCE)
JAC
AH
10-31-19
JAC
KDV
10-31-19
