Jura IMPRESSA J9.3 One Touch TFT User manual

IMPRESSA J9.3 One Touch TFT –
Quick Reference Guide
KThese short instructions do not replace the ‘IMPRESSA J9.3 One Touch TFT Instructions for Use’.
Makesureyou read andobservethesafety informationandwarningsfirstin order to avoidhazards.
E

2
IMPORTANT SAFEGUARDS
IMPORTANT SAFEGUARDS
SAVE THESE INSTRUCTIONS.
Pass them on to any subsequent user.
When using electrical appliances, basic safety precautions shall
always be followed, to reduce the risk of fire, electric shock, and/or
injury to persons, including the following:
ZRead all instructions.
ZDo not touch hot surfaces. Use handles or knobs.
ZToprotectagainstfire,electricshockandinjurytopersons,do
not immerse power cord, plugs, or body of machine in water
or other liquid.
ZClose supervision is necessary when any appliance is used by
or near children.
ZUnplug from outlet when not in use and before cleaning.
Allowtocoolbeforeputtingonortaking offparts,andbefore
cleaning the appliance.
ZDonot operateanyappliancewith a damagedcordor plug or
aftertheappliancemalfunctions,orhasbeendamagedinany
manner. Return appliance to the nearest authorized service
facility for examination, repair or adjustment.
ZTheuseofanaccessoryattachmentnotrecommendedbythe
appliance manufacturer may result in fire, electric shock, or
injury to persons.
ZDo not use outdoors.
ZDo not let the cord hang over the edge of a table or counter,
or touch hot surfaces.
ZDo not place on or near a hot gas or electric burner, or in a
heated oven.
ZAlways attach plug to appliance first, then plug cord into the
wall outlet. To disconnect, turn any control to ‘OFF’ then
remove plug from wall outlet.
ZDo not use appliance for other than intended use.
ZUse extreme caution when dispensing hot steam, hot water
or hot coffee.
ZFor household use only.
Follow the basic safety
precautions

3
IMPORTANT SAFEGUARDS
The appliance is designed and intended for household use only. It
shallonly beusedforcoffeepreparationandtoheatmilkandwater,
according to these instructions. Use for any other purpose will be
deemed improper. JURA Elektroapparate AG cannot accept any
responsibility for the consequences of improper use.
People, including children, who
Zdonothavethephysical,sensoryormentalcapabilitiestouse
the appliance safely or
Zare inexperienced or lack knowledge in how to use the appli-
ance safely
must be supervised by a responsible person when using it, or must
be instructed in how to use it correctly.
ZThe power cord is provided to reduce the risk resulting from
becoming entangled in or tripping over a long cord.
ZThe cord shall be arranged so that it will not drape over the
countertop or table topwhereit can bepulled on by children
or tripped over.
ZThis appliance has a 3-pin grounded plug. As a safety feature,
this plug will fit in a polarized outlet only one way.
ZIfthe plug does notfitfully in theoutlet,reversethe plug.Ifit
still does not fit, contact a qualified electrician.
ZDo not modify the plug in any way or attempt to defeat this
safety feature.
Do NOT use extension cords.
If the user chooses to use an extension cord,
Zthe marked electrical rating of the extension cord shall be at
least as great as the electrical rating of the appliance, and
Zif the appliance is of the grounded type, the extension cord
shall be a grounding type 3-wire cord, and
Zthelongercordshall be arrangedsothatitwillnotdrapeover
thecountertoportabletopwhereitcanbepulledonbychild-
ren or tripped over.
To reduce the risk of fire or electric shock, DO NOT remove any ser-
vice covers. DO NOT modify the appliance in any way that is not
described in these instructions. NO user serviceable parts included.
Repair MUST be done by authorized personnel only.
Intended use
Special power cord set
instructions
J WARNING

4
IMPORTANT SAFEGUARDS
In the event of signs of damage, for example if there is a smell of
burning, unplug the machine immediately from outlet and contact
JURA customer service.
This appliance is for household use. Any servicing other than clea-
ning and user maintenance shall be performed by an authorized
service representative:
ZDo not immerse base in water or try to disassemble.
ZDo not put the appliance or any individual parts in the dish-
washer.
ZCheck voltage to be sure that the voltage indicated on the
name plate complies with your voltage.
ZNever use warm or hot water to fill the water container. Use
cold water only.
ZKeep your hands and the cord away from hot parts of the
appliance during operation.
There is a risk of scalds or burns on the spouts and the cappuccino
frother / nozzle.
ZKeep children away.
ZDo not touch any hot parts. Use the handles or knobs provi-
ded.
ZEnsure that the cappuccino frother / nozzle is correctly fitted
and clean. If incorrectly fitted or if they become blocked, the
cappuccino frother or its parts might come off.
ZNever clean with scouring powders or hard implements.
ZEnsure that the ventilation slots are not covered.
ZNever pull out the drip tray during the brewing process. Only
pull the drip tray when the display instructs you or when the
appliance is ready for use.
JCAUTION
NOTICE

5
IMPORTANT SAFEGUARDS
ZNever fill instant coffee, chocolate mix etc. into the bean con-
tainerorgroundcoffeefunnel(fillerfunnelforgroundcoffee).
It will damage the functioning of the brewing chamber.
ZNever fill sugar coated coffee beans into the bean container.
In case of doubt, call your dealer.
ZNeverfillanything other than coffeebeans intothebeancon-
tainer(nochocolate,norice,nonuts,nospices,nothingother
than roasted coffee beans).
ZNever fill frozen beans into the bean container. If you store
beans in the freezer, let them thaw 3 to 4 hours before filling
them into the bean container.
ZNever fill anything but fresh, cold and clean water into the
water tank, except when decalcifying.
ZNeverusemineralorcarbonatedwater.Youcanusetapwater,
bottled water, spring water and reverse osmosis water.
ZNeverdoanythingwiththemachinewhichisnotdescribedin
these instructions. In case of doubt, call your dealer.
NEVER DO
(or you will void your
warranty protection):

6
IMPRESSA J9.3 One Touch TFT – Quick Reference Guide
IMPRESSA J9.3 One Touch TFT – Quick Reference Guide
You can initiate the rinse operation manually at any time.
Precondition: ‘Please select product:’ is displayed.
TPlace a receptacle under the coffee spout.
OTPress the P button.
‘Maintenance status (1/6)’
TPress the ‘Rinse the coffee system’ button.
‘Machine is rinsing.’, water flows out of the coffee spout.
The rinse stops automatically and ‘Please select product:’
appears on the display.
Aftereachmilkpreparation,theIMPRESSApromptsyoutorinsethe
milk system.
Precondition: ‘Rinse the milk system’ is displayed.
TPlace a receptacle under the cappuccino frother.
cTPress the Rotary Switch.
‘Milksystemis being rinsed.’,waterflowsout of the cappuc-
cino frother.
The rinse stops automatically and ‘Please select product:’
appears on the display.
To ensure that the cappuccino frother always works properly, you
should clean it daily when you have been preparing milk. Your
IMPRESSA will not prompt you to clean the cappuccino frother.
Non-recommended cleaning agents will not optimally remove milk
residues.This maycausethecappuccinofrothertobecomeblocked
and fly off the machine. Discharge of hot steam.
TUse only original JURA Cappuccino Cleaner.
Rinsing the machine
Rinsing the cappuccino
frother
Cleaning the cappuccino
frother
J WARNING

7
IMPRESSA J9.3 One Touch TFT – Quick Reference Guide
Harmful and irritating cleaning agent. Harmful if swallowed. Irritat-
ing to eyes and skin.
TKeep children AWAY.
TAvoid contact with skin and eyes.
TAfter contact with skin, wash immediately with plenty of
water. In case of skin irritation, seek medical advice.
TAftereyecontact,immediatelyflusheyeswithplentyofwater
and seek medical advice.
TIf swallowed, rinse mouth immediately and drink large quan-
tities of water. Do not induce vomiting. Seek medical advice
immediately and show label.
EJURACappuccinoCleanerisavailablefromspecializeddealers.
Precondition: ‘Please select product:’ is displayed.
OTPress the P button.
‘Maintenance status (1/6)’
TPress the ‘Clean the milk system’ button.
‘Cleaning agent for milk system’
TPour8.5oz(250ml)offreshwaterintoareceptacleandadd
one capful (max. 0.5 oz (15 ml)) of Cappuccino Cleaner.
TImmerse the milk pipe in the receptacle.
TTurn the setting wheel of the cappuccino frother to the Milk
Foam üor Milk zposition.
TPlace another receptacle under the cappuccino frother.
TPress the ‘Next’ button.
‘Milk system is being cleaned.’, water flows out of the cap-
puccino frother.
‘Water for cleaning milk system’
TRinsethereceptaclethoroughly,fillitwith8.5oz(250ml)of
fresh water and immerse the milk pipe in the water.
TEmpty the other receptacle and place it under the cappuc-
cino frother again.
cTPress the Maintenance button.
TPress the ‘Next’ button.
‘Milk system is being cleaned.’, the cappuccino frother and
the pipe are rinsed with fresh water.
‘Please select product:’ appears on the display.
J WARNING

8
IMPRESSA J9.3 One Touch TFT – Quick Reference Guide
TCarefully pull the cappuccino frother down and off.
TDismantle the cappuccino frother into its individual parts.
TRinse all parts of the cappuccino frother thoroughly under
running water.
TReassemble the cappuccino frother.
EEnsure that all individual parts are correctly and firmly con-
nected to ensure correct operation of the cappuccino frother.
TFirmly attach it to the connector.
Your IMPRESSA no longer has to be descaled if you are using the
CLEARYLBluefiltercartridge.Ifthewaterhardnessis10°dHormore,
we recommend using the filter cartridge.
EIf you do not know the hardness of your water, you must find
this out first (see Chapter 1 ‘Preparing and using for the first
time – Determining the water hardness’).
EPerform the ‘inserting the filter’ operation without any inter-
ruptions.ThiswillensurethatyourIMPRESSAalwaysproduces
its best.
Precondition: ‘Please select product:’ is displayed.
OTPress the P button.
‘Maintenance status (1/6)’
gTTurn the Rotary Switch until the program item
‘Maintenance settings (3/6)’ is displayed.
TPress the ‘Filter’ button.
‘Filter’
TPress the ‘Active’ button.
TPress the ‘Save’ button.
‘Saved’ appears briefly on the display.
‘Insert filter’
TRemove the filter cartridge extension from the Welcome
Pack.
TFit the filter extension on top of a CLEARYL Blue filter car-
tridge.
TRemove and empty the water tank.
Dismantling and rinsing
the cappuccino frother
Inserting and activating
the filter

9
IMPRESSA J9.3 One Touch TFT – Quick Reference Guide
TOpen the filter holder and insert the filter cartridge into the
water tank, exerting slight pressure.
TClose the filter holder. It will click into place audibly.
EAfter two months, the filter will cease to work. You can check
the elapsed time by referring to the date plate on the filter
holder in the water tank.
TFill the water tank with fresh, cold water and reinsert the
tank.
TPlace a receptacle (at least 17 oz or 500 ml) under the cap-
puccino frother.
TPress the ‘Next’ button.
‘Filter is being rinsed.’, water flows out of the cappuccino
frother.
EYou can interrupt rinsing of the filter at any time by pressing
any button. Press the Rotary Switch kto continue rinsing of
the filter.
EThe water may be slightly discolored. This is not harmful to
health and does not affect the taste.
Rinsing of the filter stops automatically after approximately
17oz(500ml).Themachineheatsup.‘Pleaseselectproduct:’
appears on the display. The filter is now activated.
EAfter 2000 oz (60 liters) of water have flowed through, the fil-
ter will cease to work. Your IMPRESSA will automatically
prompt you to change the filter.
EAfter two months, the filter will cease to work. You can check
the elapsed time by referring to the date plate on the filter
holder in the water tank.
EIftheCLEARYLBluefiltercartridgeisnotactivatedinprogram-
ming mode, you will not be prompted to change the filter.
Precondition: ‘Change filter’ is displayed.
OTPress the P button.
‘Maintenance status (1/6)’
TPress the ‘Change the filter’ button.
‘Change the filter’
Changing the filter

10
IMPRESSA J9.3 One Touch TFT – Quick Reference Guide
EIf you do not want to start changing the filter just yet, press
the ‘’button. The prompt ‘Change filter’ remains active.
TPress the ‘Next’ button.
‘Change filter’
TRemove and empty the water tank.
TOpen the filter holder and remove the old CLEARYL Blue fil-
ter cartridge and filter extension.
TFit the filter extension on top of a new filter cartridge.
TInsert the filter cartridge into the water tank, exerting slight
pressure.
TClose the filter holder. It will click into place audibly.
TFill the water tank with fresh, cold water and reinsert the
tank.
TPlace a receptacle (at least 17 oz or 500 ml) under the cap-
puccino frother.
TTurn the setting wheel of the cappuccino frother to the
Steam position n.
TPress the ‘Next’ button.
‘Filter is being rinsed.’, water flows out of the cappuccino
frother.
EYou can interrupt rinsing of the filter at any time by pressing
any button. Press the Rotary Switch kto continue rinsing of
the filter.
EThe water may be slightly discolored. This is not harmful to
health and does not affect the taste.
Rinsing of the filter stops automatically after approximately
17oz(500ml).Themachineheatsup.‘Pleaseselectproduct:’
appears on the display.

11
IMPRESSA J9.3 One Touch TFT – Quick Reference Guide
After 200 preparations or 80 switch-on rinses, the IMPRESSA will
prompt you to clean it.
Non-recommended (e.g. liquid) cleaning agents may contain sub-
stances that could damage the machine or leave residues.
TUse only original JURA cleaning tablets. These are specially
formulated for your machine.
Harmful and irritating cleaning agent. Harmful if swallowed. Irritat-
ing to eyes and skin.
TKeep children AWAY.
TAvoid contact with skin and eyes.
TAvoid generation of dust. Do not inhale dust.
TAfter contact with skin, wash immediately with plenty of
water. In case of skin irritation, seek medical advice.
TAftereyecontact,immediatelyflusheyeswithplentyofwater
and seek medical advice.
TIf swallowed, rinse mouth immediately and drink large quan-
tities of water. Do not induce vomiting. Seek medical advice
immediately and show label.
EThe cleaning program lasts approximately 20 minutes.
EDonotinterruptthecleaningprogram.Thequalityofcleaning
will be impaired if you do so.
EJURA cleaning tablets are available from specialized dealers.
Precondition: ‘Clean machine’ is displayed.
OTPress the P button.
‘Maintenance status (1/6)’
TPress the ‘Clean’ button.
‘Clean’
EIf you do not want to start cleaning just yet, press the ‘’but-
ton. The prompt ‘Clean machine’ remains active.
TPress the ‘Next’ button.
‘Empty coffee grounds container’
TEmpty the drip tray and coffee grounds container and put
them back into the machine.
‘Please press the Rotary Switch.’
Cleaning the machine
J WARNING
J WARNING

12
IMPRESSA J9.3 One Touch TFT – Quick Reference Guide
TPlace one receptacle under the coffee spout and another
under the cappuccino frother.
kTPress the Rotary Switch.
‘Machine is being cleaned.’, water flows out of the coffee
spout.
The operation is interrupted, ‘Add cleaning tablet’.
TOpen the cover of the filler funnel for ground coffee.
TInsert a JURA cleaning tablet into the filler funnel.
TClose the cover of the filler funnel.
‘Please press the Rotary Switch.’
kTPress the Rotary Switch.
‘Machine is being cleaned.’, water flows repeatedly out of
the coffee spout and the cappuccino frother.
The operation is interrupted, ‘Empty coffee grounds con-
tainer’.
TEmpty the drip tray and coffee grounds container and put
them back into the machine.
Cleaning is now complete. The IMPRESSA is once more
ready for use.
The IMPRESSA builds up deposits of limescale over time and auto-
matically prompts you to descale it when necessary. The degree of
calcification depends on the hardness of your water.
Non-recommended descaling agents (e.g. vinegar) may contain
substances that could damage the machine or leave residues.
TUse only original JURA descaling tablets. These are specially
formulated for your machine.
Descaling the machine
J WARNING

13
IMPRESSA J9.3 One Touch TFT – Quick Reference Guide
Harmfuland irritatingdescaling agent.Harmfulifswallowed.Irritat-
ing to eyes and skin.
TKeep children AWAY.
TAvoid contact with skin and eyes.
TAvoid generation of dust. Do not inhale dust.
TAfter contact with skin, wash immediately with plenty of
water. In case of skin irritation, seek medical advice.
TAftereyecontact,immediatelyflusheyeswithplentyofwater.
Remove contact lenses. Seek medical advice.
TIf swallowed, rinse mouth immediately and drink large quan-
tities of water. Do not induce vomiting. Seek medical advice
immediately and show label.
If the descaling operation is interrupted, there may be damage to
the machine.
TAllow the descaling program to run to the end.
EThe descaling program lasts approximately 45 minutes.
EJURA descaling tablets are available from specialized dealers.
EIf you use a CLEARYL Blue filter cartridge and this is activated,
you will not be prompted to descale.
EIf the descaling agent comes into contact with sensitive sur-
faces(e.g.marble), damagecannotberuledout.Cleanupany
splashes immediately.
Precondition: ‘Decalcify machine’ is displayed.
OTPress the P button.
‘Maintenance status (1/6)’
TPress the ‘Descale’ button.
‘Descale’
EIfyoudonotwanttostartdescalingjustyet,pressthe‘’but-
ton. The prompt ‘Decalcify machine’ remains active.
TPress the ‘Next’ button.
‘Empty drip tray’
TEmpty the drip tray and coffee grounds container and put
them back into the machine.
‘Pour descaling agent into water tank.’
J WARNINGJ WARNING
NOTICE

14
IMPRESSA J9.3 One Touch TFT – Quick Reference Guide
TRemove and empty the water tank.
TCompletely dissolve the contents of one blister (three JURA
descaling tablets) in a receptacle holding 17 oz (500 ml) of
water. This may take several minutes.
TPourthesolutionintotheemptywatertankandinsertitinto
the machine.
‘Please press the Rotary Switch.’
TRemove the cappuccino frother.
TPlace a receptacle (at least 17 oz or 500 ml) under the con-
nector of the cappuccino frother.
kTPress the Rotary Switch.
‘Machine is being descaled.’, water flows repeatedly out of
the connector of the cappuccino frother.
The operation stops automatically, ‘Empty drip tray’.
TEmpty the receptacle under the connector of the cappuc-
cino frother.
TEmpty the drip tray and coffee grounds container and put
them back into the machine.
‘Fill water tank’
TRemove the water tank and rinse it thoroughly.
TFill the water tank with fresh, cold water and reinsert the
tank.
‘Please press the Rotary Switch.’
TRefit the cappuccino frother.
TPlaceareceptacleunderthecappuccinofrotherandanother
under the coffee spout.
kTPress the Rotary Switch.
‘Machine is being descaled.’, water flows out of the cappuc-
cino frother and the coffee spout.
‘Machineisheating.’,‘Machineisrinsing.’,waterflowsoutof
the coffee spout.
The operation stops automatically, ‘Empty drip tray’.
TEmpty the drip tray and coffee grounds container and put
them back into the machine.
Descaling is now complete. The IMPRESSA is once more
ready for use.
EIf the descaling operation stops unexpectedly, rinse the water
tank thoroughly.
J9.3_Kurz/UL_en/201107
