Juxta VJ77 User manual

User’s
Manual Model VJ77
PC-based Parameters Setting Tool
(with Model L4506HA Dedicated Adapter)
IM 77J01J77-01E
IM 77J01J77-01E
9th Edition

User Registration Request
Thank you for purchasing YOKOGAWA products.
Please register to the following Partner Portal Member Site.
You can use various services such as confirmation of purchased product information,
download of related materials, and newsletter.
https://partner.yokogawa.com/global/

i
IM 77J01J77-01E
IM 77J01J77-01E 9th Edition: Jan. 2021 (YK)
All Rights Reserved Copyright © 1999, Yokogawa Electric Corporation
Introduction
This instruction manual describes the functions and operation of the Model VJ77 PC-
based Parameters Setting Tool (R3.01 or later).
 ConguationofThisManual
This manual consists of 11 chapters.
Chapter 1 VJ77 PC-based Parameters Setting Tool
Gives an overview of VJ77 and describes its functions and the operating environment.
Chapter 2 Setup
Describes how to setup the hardware and software required to use VJ77.
Chapter 3 Basic Operation
Describes the basic operation and main windows of VJ77.
Chapter 4 Setting Parameters
Describes how to set parameters of JUXTA or YS80 instruments.
Chapter 5 Setting a Program
Describes how to set a program for JUXTA computing units.
Chapter 6 Uploading and Downloading
Describes how to upload parameter or program data inside JUXTA instruments from VJ77
and how to download the data to JUXTA or YS80 instruments.
Chapter 7 Saving Data
Describes how to save parameter or program data on a disk.
Chapter 8 Printing Data
Describes how to print parameter or program data.
Chapter 9 Monitoring Input/Output Values
Describes how to monitor the I/O values of JUXTA or YS80 instruments and how to view the
result of self-diagnosis.
Chapter 10 Input and output adjustment
Describes how to adjust JUXTA or YS80 instruments’ input/output, how to correct the wiring
resistance, and others.
Chapter 11 Trouble shooting
Describes how to solve problems when any trouble has occurred while using VJ77.

ii
IM 77J01J77-01E
Intended Readers
This manual is intended for people familiar with the functions of JUXTA signal conditioners
or YS80 series rack insturuments and capable of working with Windows, such as
instrumentation and control engineers and personnel in charge of maintaining instruments
and control equipment.
Related Documents
Instruction manuals for individual JUXTA signal conditioners
These manuals provide information about the procedure of installation and wiring of signal
conditioners and parameter lists.
Instruction manuals for individual YS80 series rack instruments
These manuals provide information about the procedure of installation and wiring of signal
conditioners and parameter lists.
Trademark
All the brands or names of Yokogawa Electric’s products used in this manual are either
trademarks or registered trademarks of Yokogawa Electric Corporation.
Windows is a registered trademark of Microsoft Corporation, USA.
Authorised Representative in the EEA
Yokogawa Europe BV. (Address: Euroweg 2 , 3825 HD Amersfoort, The Netherlands) is the
Authorised Representative of Yokogawa Electric Corporation for this Product in the EEA.
You can download the latest manuals from the following website:
To view the User’s Manuals, use Adobe Acrobat Reader of Adobe Systems Incorporated.
http://www.yokogawa.com/ns/juxta/vj77/download/
• Manuals
Model VJ77 PC-based Parameters Setting Tool (IM 77J01J77-01E)
Model VJ77 PC-based Parameter Setting Tool
Downloading the Software and Manual (IM 77J01J77-11Z1)
• GeneralSpecications
Model VJ77 PC-based Parameters Setting Tool (GS 77J01J77-01E)

iii
IM 77J01J77-01E
Visual Inspection and Cross-check of Accessories
On receiving the product, visually inspect it for any damage.
 CheckingModelandSu󰀩xCodes
Makesurethatthemodelandsu󰀩xcodesofthedeliveredproductareasspeciedinyour
order.
Model Su󰀩xcode Description
VJ77 PC-based parameters setting tool
-E10 For use with PC/AT compatible personal computers (English
version)
Checking the Standard Accessories
Make sure that the delivered package contains all of the following items.
Dedicated adapter (Model: L4506HA) 1 unit
MicroUSB(USB2.0) cable (Part no.: A1590WL) 1 cable
JUXTA communication cable with 3-pin connectors (Part no.: F9182ED) 1 cable
JUXTA communication cable with 5-pin connectors (Part no.: F9182EE) 1 cable
Modular jack conversion adapter (Part no.: E9786WH) 1 unit
Model VJ77 PC-based Parameters Setting Tool
Downloading the Software and Manual
1 copy
JUXTA communication
cable (3-pin connectors)
MicroUSB (USB2.0)
cable
Dedicated adapter
(Model: L4506HA)
JUXTA communication
cable (5-pin connectors)
Modular-jack
conversion adapter

iv
IM 77J01J77-01E
Documentation Conventions
Documentation Conventions
The following conventions are used throughout this manual:
The names of named dialog boxes, windows,
and views are written in title cap and refer to
the exact titles.
Parameter Setting Menu dialog box
Gantt view
The names of unnamed windows, dialog
boxes, and views are written in all lowercase
letters.
document window
print preview
Commands (including buttons) in a dialog
box or window and menu commands are
written in boldface.
Click OK.
Click Options.
From the File menu, choose Exit.
Characters to be typed by the user via
keyboard are written in monotype font.
Type JUXTA in the Model box.
Item Usage
IMPORTANT
Indicates that operating the hardware or software in a particular manner may damage it or
result in a system failure.
NOTE
Draws attention to information that is essential for understanding the operation and/or
features of the product.
TIP
Gives additional information to complement the present topic.
See Also
Gives reference locations for further information on the topic.
Illustrations in This Document
(1) Illustrationsandgurespresentingthisproductoritsfunctionsinthismanualmaynot
beexactlythesameastheactualproductorfunctionssoastosimplifyunderstanding.
(2) Figuresandillustrationsrepresentingthedisplaysmaydi󰀨erfromtheactualdisplaysin
regardtothepositionand/ordisplaycharacters(uppercaseorlowercase,forexample),
butnottoanextentthatimpairsacorrectunderstandingofthefunctionsandtheproper
setting operation.

v
IM 77J01J77-01E
Notice
Regarding This User’s Manual
(1) This manual should be passed on to the end user. Keep this manual in a safe place.
(2) Read this manual carefully to gain a thorough understanding of how to operate this
product before you start using it.
(3) This manual is intended to describe the functions of this product. Yokogawa Electric
Corporation (hereinafter simply referred to as Yokogawa) does not guarantee that
these functions are suited to the particular purpose of the user.
(4) Under absolutely no circumstances may the contents of this manual, in part or in
whole, be transcribed or copied without permission.
(5) The contents of this manual are subject to change without prior notice.
(6) Everye󰀨orthasbeenmadetoensureaccuracyinthepreparationofthismanual.
Should any errors or omissions come to your attention however, please contact your
nearestYokogawarepresentativeoroursaleso󰀩ce.
Regarding Protection, Safety, and Prohibition Against Unauthorized
Modication
(1) In order to protect the product and the system controlled by it against damage and
ensure its safe use, make sure that all of the instructions and precautions relating
to safety contained in this document are strictly adhered to. Yokogawa does not
guarantee safety if the product is not handled according to these instructions.
(2) The following safety symbols are used in this manual.
Symbols used on the product and in this manual
CAUTION
Thissymbolontheproductindicatesthattheoperatormustrefertoanexplanation
in the user’s manual to avoid the risk of injury or death of personnel or damage to the
instrument.Themanualdescribeshowtheoperatorshouldexercisespecialcareto
avoid electrical shock or other dangers that may result in injury or the loss of life.
Protective ground terminal:
This symbol indicates that the terminal must be connected to ground prior to operating
the equipment.
Function ground terminal:
This symbol indicates that the terminal must be connected to ground prior to operating
the equipment.

vi
IM 77J01J77-01E
 ExemptionfromResponsibility
(1) Yokogawadoesnotmakeanywarrantiesregardingtheproductexceptthose
mentioned in the WARRANTY that is provided separately.
(2) Yokogawa assumes no liability to any party for any loss or damage, direct or indirect,
caused by the use or any unpredictable defect of the product.
(3) Be sure to use the spare parts approved by Yokogawa when replacing parts or
consumables.
(4) Modicationoftheproductisstrictlyprohibited.
(5) Thissoftwaremaybeusedwithonespeciedcomputeronly.Youmustpurchase
another copy of the software for use on each additional computer.
(6) Copying the software for purposes other than backup is strictly prohibited.
(7) Reverse engineering such as the disassembly or recompilation of software is strictly
prohibited.
(8) NoportionofthesoftwaresuppliedbyYokogawamaybetransferred,exchanged,
leased, or sublet for use by any third party without the prior permission of Yokogawa.

vii
IM 77J01J77-01E
LICENSE AGREEMENT FOR PACKAGE SOFTWARE PRODUCT
ATTENTION! -
Please read this LICENSE AGREEMENT (hereinafter referred to as the “Agreement”) carefully before installing this package software product of Yokogawa Electric
Corporation (hereinafter referred to as “Yokogawa”) on the computer.
Installing this package software product indicates your acceptance of the terms and conditions of this Agreement. If you are not the end user, transferring this package
software product indicates your acceptance of the terms and conditions of this Agreement. If you don’t accept the terms and conditions of this Agreement, please kindly
return this package software product, without installing it, to the seller or Yokogawa immediately.
1. Grant of License
(1) The terms and conditions of this Agreement shall apply to the following package software of Yokogawa (herein after referred to as “Package Software Product”.
Product: VJ77, Parameters Setting Tool and materials related thereto that Yokogawa designates Number of license: One (1)
(2) ThePackageSoftwareProducthereinshallinclude;withoutlimitation,asoftwareprogram,font,database,dataputintoll-in-the-form,instructionmanual,
functionalspecications,materialsrelatedtheretoimage,photograph,animation,videoimage,sound,music,textallofwhichareincorporatedintosoftware
component(program)andapplet.(“applet”meanssoftwarecomponent(program)incorporatedintotextoricon.)
2. Terms and Conditions of License
(1) Yokogawagrantsyou,forthepurposeofyourownuse,non-exclusiveandnon-transferablelicenseofthePackageSoftwareProductondesignatedcomputer
agreed by both parties in consideration of the license fee agreed separately by the both parties.
(2) You are, unless otherwise agreed in writing by Yokogawa, not entitled to sell, lend, distribute, transfer or sublicense, or if any, pledge the Package Software Product.
You shall not use Package Software Product on other computer than the designated one through Wide area network, either, including but not limited to intranet,
internet, local area network and wide area network.
(3) ThePackageSoftwareProductshallnotbecopiedinwholeorinpartexceptkeepingonecopyforback-uppurposeunlessotherwiseagreedinwritingbyYokogawa
inadvance.YoushallstoreandmanagethecopyorduplicateofthePackageSoftwareProductinstrictcondenceandwithutmostcare.
(4) Youshallnotandshallnothaveanythirdparty,includingtheenduser,alter,decompile,disassemble,decrypt,extractorotherwisereverse-engineerthePackage
Software Product or create any derivative works thereof. Unless otherwise separately agreed by Yokogawa, Yokogawa has no obligation to provide you with the
source code for the Package Software Product.
(5) The Package Software Product including all proprietary technology, algorithm, and know-how such as a factor, invariant or process contained therein shall be the
proprietary property or trade secret of Yokogawa or a third party which grants Yokogawa the rights.
(6) Theproprietarypropertyand/ortradesecretasdenedintheprecedingArticle2.(5)shallnotbepublishedordisclosedtoanythirdpartiesexceptforyourlimited
employeesorequivalentstheretowhoneedtohaveaccessthereto.Youarealsorequiredtoimposenolessstringentcondentialityobligationthanhereintheon
them.
(7) Yokogawa may use or add copy protection in or to the Package Software Product. In no event shall you remove or attempt to remove such copy protection.
(8) The Package Software Product and the all copy and duplicates thereof shall be returned to Yokogawa or the party designated by Yokogawa immediately after the
expirationorterminationofthisAgreement.Alternatively,ifYokogawarequiresinwritingtoyouthatallthePackageSoftwareProductisdestroyedordisposed,all
the information therein shall be deleted completely.
(9) Youshallnotremoveanycopyrightnotice,trademarknotice,logoorotherproprietarynoticesoridenticationshowninthePackageSoftwareProduct.
3. LimitationforSpecicUses
(1) Unlessotherwiseagreedbybothpartiesinwriting,thePackageSoftwareProductshallnotbeintendedtobespecicallydesigned,manufacturedordistributedfor
the purpose of operation of any aviation, vessel, support of those operations from the ground, or for any design, construction, maintenance, operation and/or use of
nuclear products and/or facilities.
(2) Even if you use the Package Software Product for the purpose of preceding Article 3.(1), Yokogawa disclaims any responsibilities, warranties, liabilities, claims
or damages whatsoever similar thereto arising out of the use or operations of the Package Software Product for such purpose and you shall indemnify and hold
harmlessYokogawaincludingwithoutlimitationitso󰀩cers,employees,salesrepresentatives,andtheiro󰀩cersandemployees,fromanyclaim,suit,demand,
damage, and similar thereto (including reasonable attorneys’ fees).
4. Warranty
(1) DuringthewarrantyperioddenedinthisArticle4.(4)below(hereinaftercalled“WarrantyPeriod”),YokogawawarrantsthatthePackageSoftwareProductshall
properlyfunctioninaccordancewiththeInstructionManualorFunctionalSpecicationsofYokogawa,onthehardwareundertheenvironmentalorotherconditions
designated by the vendor of such hardware or by Yokogawa. However, in no event shall Yokogawa warrant the following under any operating environment and
circumstance.
The Package Software Product;
a) will never be interrupted
b) will never be free from defect
c) will be completely corrected
d) willbefreefromanycrossinterferencesuchascrossconictwithothersoftwareprogram
e) will satisfy your or your customer’s any particular and/or prospective purpose
f) will be accurate, correct, reliable or most up-dated
g) will be free of vulnerability (including but not limited to vulnerability to intrusion or attack cause by computer virus or unauthorized access or the like).
(2) DuringtheWarrantyPeriod,ifthePackageSoftwareProductfailstooperateinaccordancewiththestepsoftheinstructionmanualorfunctionalspecications
attributable to Yokogawa, or if defect(s) such as damage of a media of the Package Software Product attributable to Yokogawa is found, Yokogawa agrees to either
repair or replace, free of charge, any Package Software Product which shall be returned to Yokogawa’s nearest authorized service facility immediately at your
expense;whereinconsiderationofthelicensefeeofthePackageSoftwareProductisoutsideofJapan,re-importtaxandotherchargesshallbealsobornebyyou.
Further, in the case that repair or replacement of the Package Software Product requires additional works such as loading of the same at the site by Yokogawa or
anypersondesignatedbyYokogawaisneeded,suchcostandexpensefortheworksshallbebornebyyouandyoushallinitializeorshutdownthesystemand
other related system, products or equipment, if deemed necessary at Yokogawa’s sole judgment.
(3) Notwithstanding the preceding Article 4.(2), Yokogawa’s warranty shall not apply if the defect of the Package Software Product is caused by any of the followings;
a) where hardware on which the Package Software Product operates becomes out of warranty of the vendor and proper maintenance contract for the hardware is
not in place;
b) where, if Yokogawa designates hardware on which the Package Software Product operates, you changed such hardware to other hardware without
Yokogawa’s consent;
c) where any third party other than entrusted by Yokogawa conducted renovation, or improvement of the Package Software Product;
d) where hardware on which the Package Software Product operates was moved by you or any third party without Yokogawa’s consent;
e) where you or a party you designate (including your customer) misused, renovated, up-graded, or used the Package Software Product for any other purpose
than set forth in the Instruction Manuals etc.;
f) wherethePackageSoftwareProductwasusedoroperatedunderthedi󰀨erentoperatingenvironmentand/orotherconditionsthanthetermsdesignatedby
Yokogawa or provider of hardware;
g) whereyouoryourcustomerdoesnotexecutethepropertroubleornon-conformityavoidingmeasures(includingrepairorreplacement)Yokogawaproposed;
or other cause of defect not attributable to Yokogawa;
(4) The Warranty Period shall be the twelve (12) month period from the date when Yokogawa complete the delivery at the place designated by you (including your
customer)oryouoryourcustomerusepartorwholeofthePackageSoftwareProductfortheoperation,whichevercomesrst,unlessotherwiseagreedinwriting
by Yokogawa.

viii
IM 77J01J77-01E
(5) Underseparatemaintenancecontract,YokogawamayconductmaintenanceserviceforthePackageSoftwareProduct,attheexpenseofyouevenafterthe
Warrantyperiod.ThemaintenanceserviceforthePackageSoftwareProductshallbeclassiedintothoseofstandardsoftware,customizedsoftware.
a) Standard Software
 StandardSoftwarehereinmeansthestandardpackagesoftwarecoveredbyYokogawa’sCatalogueand/orGeneralSpecications.Themaintenanceservice
forStandardSoftwaremaybeavailableforthelatesttwoversionsunlessotherwisecoveredbyYokogawa’sCatalogueand/orGeneralSpecications.
However, the maintenance service for the Package Software Product which is the earlier version among the latest two versions may be available only for
ve(5)yearsafterthelastup-dated.ThemaintenanceservicefortheversionofthePackageSoftwareProductdeclaredbyYokogawatodiscontinueorder
acceptancemaybeavailableforve(5)yearsaftersuchdeclaration.
b) Customized Software
 CustomizedSoftwarehereinmeansthesoftwarecustomizedbyYokogawapursuanttotheQuotationorFunctionalSpecicationsagreedbybothparties.
The maintenance service for the Customized Software shall not be available to you including your customer after the Warranty Period unless otherwise
separatelyagreedbybothparties.However,suchmaintenanceservicemaybeconductedatyourexpenseasremodelingcontractagreedbythebothparties.
(6) Notwithstanding the preceding Article 4.(1), 4.(2), 4.(3), 4.(4) and 4.(5), on the third party’s software, warranty, including warranty period, of such third party provider
shall apply.
5. Revision-Up Package Software
When you receive the Revision-Up of the Package Software Product which is substituted for or is added to the Package Software Product (“Revision-Up”), you can install
such Revision-Up in the computer(s) on which you use the Package Software Product. Furthermore, the Revision-Up shall be considered as the Package Software
Product and you shall agree to comply with the terms and conditions of this Agreement in order to use the Revision-Up.
6. If You are not the End User
If you are not the end user of the Package Software Product, you shall present the terms and conditions of this Agreement to your end user and cause your end user to
observe such terms and conditions. If Yokogawa incurs damage due to your end user’s breach of such terms and conditions as set forth herein, you shall indemnify and
hold Yokogawa harmless as set forth herein above. In this case, it is the end user that is granted the license of the Package Software Product by Yokogawa and if you are
not the end user, you shall transfer the possession of media and related materials of the Package Software Product to your end user.
7. Intellectual Property Infringement
(1) If and when any third party should demand injunction, initiate a law suit, or demand damages against you under patent right, utility model right, design patent right,
trademark right, copyright and/or any other right relating to any of the Package Software Product including but not limited to its related materials, you shall notify
Yokogawaofthate󰀨ectinwritingwithoutdelay.
(2) In case of preceding Article 7.(1), you shall assign to Yokogawa all of the rights to defend you, to negotiate and to settle with the claiming party. Furthermore, you
shall provide Yokogawa with necessary information or any other assistance for Yokogawa’s defense and negotiation. If and when such a claim should be attributable
toYokogawa,YokogawashalldefendyouandnegotiatewiththeclaimingpartyatYokogawa’scostandexpenseandberesponsibleforthenalsettlementor
judgment granted to the claiming party in the preceding Article 7.(1).
Provided, however, that Yokogawa shall have no liability for any claim of infringement in the preceding Article 7.(1) if based on;
a) use of other than the latest version of Package Software Product made available to you, if the infringement would have been avoided by use of such version;
b) addition to Package Software Product of any other software or program not advised or recommended by Yokogawa, if the infringement would have been
avoided without such addition;
c) the combination or use of Package Software Product with software or program not furnished by Yokogawa if such infringement would have been avoided by
use of Package Software Product with Yokogawa software or program alone; or any other cause not within the control of Yokogawa.
(3) Whenanyassertionoftheinfringementofthirdparty'srightdenedinArticle7.(1)ismadeorwhen,atYokogawa’sjudgment,thereispossibilityofsuchassertion,
Yokogawawill,atitsdiscretionandnotobligation,takeanyofthefollowingcountermeasuresatYokogawa’scostandexpense.
a) To acquire the necessary right from a third party which has lawful ownership of the right so that you will be able to continue to use the Package Software
Product;
b) To replace the Package Software Product with the one, which avoids the infringement;
c) To remodel the Package Software Product so that the Package Software Products can avoid the infringement of such third party's right; or
d) If and when Yokogawa fails to take either of the countermeasures set forth in a. through c. above, Yokogawa shall indemnify you only by paying back the price
amount of the Package Software Product, which Yokogawa has already received.
8. Limitation of Liability
If and when you should incur any damage relating to the Package Software Product Yokogawa provided to you under any damage due to the reason attributable to
Yokogawa”, Yokogawa shall take actions in accordance with this Agreement. However, in no event shall Yokogawa be responsible for any indirect damage, consequential
damage,punitivedamageand/orspecialdamage,includingwithoutlimitation,lossofoperationalprot,lossofinterruptionofyourbusiness,andlossofbusiness
informationandthatYokogawa’sliabilitytoyourdamageshallnotexceedthepriceamountofthePackageSoftwareProductYokogawareceived.Itisspecically
agreed by both parties that Yokogawa shall be released and discharged from part or any and all of the liability and responsibility under this Agreement if you (including
thecaseyouhaveanythirdpartycauseto)modify,remodel,combinewithothersoftwareorproducts,orcauseanydeviationfromthebasicspecicationsorfunctional
specications,withoutYokogawa’spriorwrittenconsent.
9. Term
(1) ThisAgreementshallbecomee󰀨ectivefromthedatewhenyoureceivethePackageSoftwareProductandcontinuesine󰀨ectuntiltheearlierofearlyterminationas
provided in Article 12, Yokogawa gives thirty (30) days prior written notice to you, or your license term terminates.
(2) Articles 2.(4), 2.(6), 2.(8), 7, 8,11 and 12 shall survive even after the termination.
10. Injunction for Use
During the term of this Agreement, Yokogawa may, at its own discretion, demand an injunction against you and your customer in case Yokogawa deems the Package
SoftwareProductisusedimproperlyorundersevererenvironmentsthanthoseYokogawarstgrantedoranyotherconditionwhichYokogawamaynotpermit.
11. CondentialityObligation
(1) You agree that the structure, organization and code of the Package Software Product are the valuable trade secrets of Yokogawa or third party which grants
Yokogawa the rights and the Package Software Product contains other proprietary information and know-how of Yokogawa and its third party, which may be
disclosed for the purpose of license granted hereunder. You shall not divulge any of such trade secrets, information and know-how to any third party without
Yokogawa’s consent and shall not use for any purpose other than license use.
(2) YoushallmaintainthePackageSoftwareProduct,itsmedia,anyprintingmaterialandanycopythereofinstrictcondenceandwithutmostcaretocomplywiththe
said secrecy obligation and protect the right of Yokogawa and third party which grants Yokogawa the rights.
12. Termination by Cause
Yokogawa may terminate this Agreement without any notice or demand to you immediately terminate. if you breach any of the terms and conditions of this Agreement.
13. Governing Law and Arbitration
(1) This Agreement shall be governed by and construed in accordance with the laws of Japan.
(2) Alldisputes,controversiesordi󰀨erenceswhichmayarisebetweenthepartieshereto,outoforinrelationtoorinconnectionwiththisAgreementshallbenally
settled by arbitration in Tokyo, Japan in accordance with the Commercial Arbitration Rules of the Japan Commercial Arbitration Association. The arbitration is
conductedinEnglishlanguage.Theawardrenderedbythearbitrator(s)shallbenalandbindinguponthepartieshereto.
14. Miscellaneous
(1) This Agreement supersedes all prior oral and written understandings, representations and discussions between the parties concerning the subject matter hereof to
theextentsuchunderstandings,representationsanddiscussionsshouldbediscrepantorinconsistentwiththisAgreement.
(2) IfanypartofthisAgreementisfoundvoidorunenforceable,itshallnota󰀨ectthevalidityofthebalanceoftheAgreement,whichshallremainvalidandenforceable
according to its terms and conditions. The parties hereby agree to attempt to substitute for such invalid or unenforceable provision a valid or enforceable provision
thatachievestothegreatestextentpossibletheeconomic,legalandcommercialobjectivesoftheinvalidorunenforceableprovision.
(3) FailurebyeitherpartytoinsistonperformanceofthisAgreementortoexercisearightdoesnotpreventsuchpartyfromdoingsoatalatertime,eitherinrelationto
that default or any subsequent default.

ix
IM 77J01J77-01E
IM 77J01J77-01E 9th Edition
Model VJ77
PC-based Parameters Setting Tool
CONTENTS
Introduction ................................................................................................................. i
Visual Inspection and Cross-check of Accessories ............................................. iii
Documentation Conventions................................................................................... iv
Notice........................................................................................................................... v
LICENSE AGREEMENT FOR PACKAGE SOFTWARE PRODUCT ...................... vii
1. VJ77 PC-based Parameters Setting Tool...................................................1-1
1.1 An Overview of VJ77 and Its Functions ............................................................. 1-1
1.1.1 What is VJ77?........................................................................................ 1-1
1.1.2 Functions................................................................................................ 1-1
1.2 Conceptual View of VJ77 ..................................................................................... 1-2
1.3 OperatingEnvironmentandWiringSpecications .......................................... 1-3
1.3.1 System Requirements ........................................................................... 1-3
1.3.2 Dedicated Adapter ................................................................................. 1-3
1.4 ExternalViewofDedicatedAdapter ................................................................... 1-4
1.5 Precautions When Communicating with Device............................................... 1-5
2. Setup..............................................................................................................2-1
2.1 Downloading the Software and Driver ..................................................................2-1
2.2 Installing the USB Driver .........................................................................................2-1
2.3 Installing VJ77 ....................................................................................................... 2-7
2.4 Uninstalling VJ77 .................................................................................................. 2-7
2.5 Connecting Instrument to Personal Computer ................................................. 2-8
2.5.1 Items Required for Connection.............................................................. 2-8
2.5.2 How to Connect ..................................................................................... 2-8
2.6 Setting the Communication Port....................................................................... 2-10
3. Basic Operation............................................................................................3-1
3.1 Starting VJ77 ......................................................................................................... 3-1
3.2 Quitting VJ77 ........................................................................................................ 3-1
3.3 Window Elements and Functions ....................................................................... 3-2
3.4 Basic Operation .................................................................................................... 3-3
3.4.1 Operation Using a Mouse ...................................................................... 3-3
3.4.2 Operation Using Keyboard .................................................................... 3-4
3.5 Main Windows and Their Functions ................................................................... 3-5
3.5.1 DISPLAY Menu Window ........................................................................ 3-5
3.5.2 SET Menu Window ................................................................................ 3-5
3.5.3 ADJUST Menu Window......................................................................... 3-6
3.5.4 Program Setting Window....................................................................... 3-6

IM 77J01J77-01E
x
4. Setting Parameters.......................................................................................4-1
4.1 Displaying the Parameter Setting Window ........................................................ 4-1
4.2 Setting Parameters ............................................................................................... 4-2
4.2.1 Entering a Setting Value and Writing It to Device .................................. 4-2
4.2.2 Notes on Setting JUXTA Parameters .................................................... 4-3
4.2.3 SelectinganItemfromaListBoxandWritingIttoDevice .................... 4-4
5. Setting a Program (JUXTA only) .................................................................5-1
5.1 Opening Program Setting Window ..................................................................... 5-2
5.2 Setting a Program ................................................................................................. 5-3
5.2.1 Creating a New Program ....................................................................... 5-3
5.2.3 Converting Free (User) Program Automatically..................................... 5-7
6. Uploading and Downloading Data from/to Device ...................................6-1
6.1 Uploading Data to Your PC .................................................................................. 6-1
6.1.1 Uploading Parameter Data from Device................................................ 6-1
6.1.2 Opening a Parameter File ..................................................................... 6-2
6.1.3 Uploading Program Data from JUXTA Instrument ................................ 6-2
6.1.4 Opening a Program File......................................................................... 6-2
6.2 Downloading Data to JUXTA Instrument............................................................ 6-3
6.2.1 Downloading Parameter Data to Device ............................................... 6-3
6.2.2 Downloading a Program to Device ........................................................ 6-4
7. Saving Data ...................................................................................................7-1
7.1 Saving Parameter Data to Disk............................................................................ 7-1
7.2 Saving Program Data to Disk .............................................................................. 7-1
7.3 Saving Comma-separated Value File to Disk..................................................... 7-1
8. Printing Data .................................................................................................8-1
8.1 Printing Data.......................................................................................................... 8-1
8.2 Previewing the Print Image.................................................................................. 8-2
9. Monitoring I/O Values...................................................................................9-1
9.1 OpeningtheMonitorDialogBox......................................................................... 9-1
10. Input and output adjustment.....................................................................10-1
10.1 Opening the Adjusting Window ........................................................................ 10-1
10.2 Performing Fine Adjustment of Input ............................................................... 10-2
10.2.1 Adjusting the Zero Point of Input.......................................................... 10-2
10.2.2 Adjusting the Input Span...................................................................... 10-2
10.3 Correcting the Output......................................................................................... 10-3
10.4 Setting Wire Resistance Compensation .......................................................... 10-4
10.5 Using the Forced Output Function ................................................................... 10-5
11. Troubleshooting ......................................................................................... 11-1
Revision Information .................................................................................................. i

1-1
IM 77J01J77-01E
1. VJ77 PC-based Parameters Setting
Tool
This chapter gives an overview of the VJ77 tool and describes its operating
environment.
1.1 An Overview of VJ77 and Its Functions
1.1.1 What is VJ77?
The VJ77 Parameter Setting Tool is a PC software package for setting various parameters
and computing unit programs of the microcomputer-based JUXTA, and various parameters
of YS80 series rack instruments with the BRAIN communication function (hereafter, the
YS80).
1.1.2 Functions
Parameter setting
Setsparametersthatcongurethefunctionsofmicroprocessor-basedJUXTAorYS80
instruments.
Program setting
Sets programs of microprocessor-based JUXTA computing units.
ProgramscanbeeditedfromaPCevenwheno󰀪ine.*
*AstateinwhichthePC(VJ77)andtheJUXTAinstrumentarenotconnected
Download to/upload from the JUXTA instrument
Uploads parameters or program from a microprocessor-based JUXTA instrument to a
personal computer, and downloads the parameters and program once loaded or a program
you created, to a JUXTA instrument. It also enables you to read and write parameters to and
fromtheYS80.YoucanalsowritetoaYS80evenitisofadi󰀨erentstyle.
Data saving to disk
Saves parameters or program in a JUXTA instrument to the hard disk of a personal
computer, etc. Also, you can save loaded YS80 parameters to the PC’s hard disk.
Data printing
Prints parameters or program uploaded from a JUXTA instrument. Also, you can print
loaded YS80 parameters to a printer connected to the PC.
Input/output value monitor
Views the I/O values and the result of self-diagnosis of a microprocessor-controlled JUXTA
or YS80 instrument.
Input and output adjustment
Adjusts inputs and outputs of a microprocessor-controlled JUXTA or YS80 instrument.

1-2
IM 77J01J77-01E
1.2 Conceptual View of VJ77
ALM1
ALM2
Hard disk
Upload from/download to JUXTA or YS80
JUXTA or YS80 Personal computer
Read from/Save to a disk
(Pier-to-pier communication)
Reference to
parameters Set parameters/
Set programs
(only for JUXTA) Adjust
Instrumens
Figure 1.2.1 Conceptual View of VJ77 PC-based Parameters Setting Tool

1-3
IM 77J01J77-01E
1.3 Operating Environment and Wiring
Specications
1.3.1 System Requirements
OS: Windows 8.1 Pro Update (32-bit/64-bit version)
Windows 10 Pro (64-bit version)
Windows 8.1/10 supports a Japanese edition and English version.
CPU: Pentium 4 series processor
For Windows 8.1 Pro Update: Equivalent to 3.0 GHz or higher
recommended
For Windows 10 Pro: 1 GHz or higher processor or SoC
Main memory: Windows 8.1 Pro Update: At least 2 GB recommended
Windows 10 Pro: At least 2 GB recommended
Hard disk space: Package program: 10MB or more
.Net Framework 4.0 :620MBor more
Display: 1024×768pixelsorbetter,256colorsormorerecommended
Communication port: At least 1 port (USB port)
Printer: Required for printing, support for letter or A4 size
1.3.2 Dedicated Adapter
Power supply: Supplied from the USB bus power.
Insulation resistance: Minimum of 100 M/500 V DC between USB communication port
and the JUXTA connection sides.
Dielectric strength: 500 V AC/minute between USB communication port and the JUXTA
connection sides.
Ambient temperature: 0 to 50°C
Ambient humidity: 5 to 90%RH (no condensation)
Transport and storage conditions: -40 to 70°C, 5 to 95%RH (no condensation)
Waterproof & dustproof construction: Not applicable

1-4
IM 77J01J77-01E
1.4 ExternalViewofDedicatedAdapter
Unit: mm
Modular-jack
conversion
Communication cable
985±35
1150±25
3-pin connector
5-pin connector
1095±20
(78.4)
78.4
70.2
18.5
14.5
30
(70.2)
MicroUSB cable
Figure 1.4.1 Dedicated Adapter
EMC Standards
Moel L4506HA
EMC directive:
EN 61326-1 compliance, Class A Table 2
EN 55011 Class A Group 1
EMC Regulatory Arrangement in Australia and New Zealand (RCM): EN 55011 Class A,
Group 1
KC marking: Electromagnetic wave interference prevention standard, electromagnetic wave
protection standard compliance.

1-5
IM 77J01J77-01E
1.5 Precautions When Communicating with
Device
NOTE
Do not remove the communication cable while communicating with a JUXTA or YS80
instrument.
Communication may be in progress in the following windows.
• Communicationexecutionwindow
• Parameter setting window
• Parameter view window
• Program setting window
• ParameterSettingdialogbox
• ProgramEditordialogbox
• ConstantSettingdialogbox
• CheckDownloadingtoDevicedialogbox
• CommandCheckErrorlistdialogbox
• SLOTNo.Settingdialogbox

Blank Page
