JVC GY-HM100U - Camcorder - 1080p User manual

4HANKYOUFORPURCHASINGTHIS*6#PRODUCT"EFOREOPERATINGTHIS
DEVICEPLEASEREADTHEINSTRUCTIONSCAREFULLYTOENSURETHE
BESTPOSSIBLEPERFORMANCE
For Customer Use:
%NTERBELOWTHE3ERIAL.OWHICHISLOCATEDONTHEBODY
2ETAINTHISINFORMATIONFORFUTUREREFERENCE
-ODEL.O'9(-5
3ERIAL.O
HD MEMORY CARD CAMERA RECORDER
GY-HM100U INSTRUCTIONS
イラストは GY-HM100 に付属のマイクを取り付けた例です。
The illustration shows the GY-HM100U
with the provided microphone attached.
LYT2089-001D
M9H7_EN_001D.book Page 1 Thursday, August 26, 2010 11:51 AM

2
Getting Started
Safety Precautions
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead symbol, within an
equilateral triangle, isintended to alert the user to the
presence of uninsulated "dangerous voltage" within the
product'senclosure that may be of sufficient magnitude
to constitute arisk of electric shock to persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructionsin
the literature accompanying the appliance.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead symbol, within an
equilateral triangle, isintended to alert the user to the
presence of uninsulated "dangerous voltage" within the
product'senclosure that may be of sufficient magnitude
to constitute arisk of electric shock to persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructionsin
the literature accompanying the appliance.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead symbol, within an
equilateral triangle, isintended to alert the user to the
presence of uninsulated "dangerous voltage" within the
product'senclosure that may be of sufficient magnitude
to constitute arisk of electric shock to persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructionsin
the literature accompanying the appliance.
WARNING: TO PREVENT FIRE OR SHOCK
HAZARD, DO NOT EXPOSE THISUNIT TO
RAIN OR MOISTURE.
NOTES:
• The ratingplate and safety caution are on the
bottom and/or the back of the main unit.
• The serial number plate is on the battery pack
mount.
• The ratinginformation and safety caution of the
AC adapter are on its upper and lower sides.
Caution on Replaceable lithium battery
The battery used in thisdevice may present afire
or chemical burn hazard if mistreated.
Do not recharge, disassemble, heat above 100°C
or incinerate.
Replace battery with Panasonic, Sanyo, Sony or
Maxell CR2025.
Danger of explosion or Risk of fire if the battery is
incorrectly replaced.
• Dispose of used battery promptly.
• Keep away from children.
• Do not disassemble and do not dispose of in fire.
For USA-California Only
Thisproduct containsaCR Coin Cell Lithium
Battery which containsPerchlorate Material
– special handling may apply.
See www.dtsc.ca.gov/hazardouswaste/perchlorate
When the equipment isinstalled in acabinet or on
ashelf, make sure that it has sufficient space on all
sidesto allow for ventilation (10 cm (3-15/16") or
more on both sides, on top and at the rear).
Do not block the ventilation holes.
(If the ventilation holesare blocked by a
newspaper, or cloth etc. the heat may not be able
to get out.)
No naked flame sources, such as lighted candles,
should be placed on the apparatus.
When discarding batteries, environmental
problemsmust be considered and the local rulesor
lawsgoverning the disposal of these batteriesmust
be followed strictly.
The apparatus shall not be exposed to dripping or
splashing.
Do not use thisequipment in abathroom or places
with water.
Also do not place any containersfilled with water
or liquids(such as cosmeticsor medicines, flower
vases, potted plants, cupsetc.) on top of thisunit.
(If water or liquid isallowed to enter this
equipment, fire or electric shock may be caused.)
Do not point the lensdirectly into the sun. This
can cause eye injuries, as well as lead to the
malfunctioning of internal circuitry. There isalso a
risk of fire or electric shock.
CAUTION!
CAUTION!
Connecting cables(Audio/Video, etc.) to the
cameraand leaving it on top of the TV isnot
recommended, as tripping on the cableswill cause
the camerato fall, resulting in damage.
The following notesconcern possible physical
damage to the cameraand to the user.
Carrying or holding the cameraby the LCD monitor
can result in dropping the unit, or in amalfunction.
Do not use atripod on unsteady or unlevel surfaces. It
could tip over, causing serious damage to the camera.
CAUTION:
The mainsplug shall remain readily operable.
WARNING:
The battery pack, the camerawith battery installed,
and the remote control with battery installed should
not be exposed to excessive heat such as direct
sunshine, fire or the like.
M9H7_EN_001D.book Page 2 Thursday, August 26, 2010 11:51 AM

3
IMPORTANT SAFETY INSTRUCTIONS
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use thisapparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in
accordance with the manufacturer’sinstructions.
8. Do not install near any heat sourcessuch
as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce heat.
9. Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the
point where they exit from the apparatus.
10. Only use attachments/accessoriesspecified by the
manufacturer.
11. Use only with the cart,
stand, tripod, bracket,
or table specified by
the manufacturer, or
sold with the apparatus.
When acart isused,
use caution when
moving the cart/
apparatus combination
to avoid injury from tip-over.
12. Unplug thisapparatus during lightning stormsor
when unused for long periodsof time.
13. Refer all servicing to qualified service personnel.
Servicing isrequired when the apparatus has
been damaged in any way, such as power-supply
cord or plug isdamaged, liquid has been spilled
or objectshave fallen into the apparatus, the
apparatus has been exposed to rain or moisture,
doesnot operate normally, or has been dropped.
If thissymbol isshown, it isonly valid in
the European Union.
ThisClass B digital apparatus complieswith
Canadian ICES-003.
Cet appareil numérique de laclasse B est
conforme à lanorme NMB-003 duCanada.
Declaration of Conformity
Model Number : GY-HM100U
Trade Name : JVC
Responsible party : JVC AMERICAS CORP.
Address : 1700 Valley Road Wayne, N. J. 07470
Telephone Number : 973-317-5000
Thisdevice complieswith Part 15 of FCC
Rules. Operation issubject to the following
two conditions: (1) Thisdevice may not cause
harmful interference, and (2) thisdevice must
accept any interference received, including
interference that may cause undesired operation.
Changesor modificationsnot approved by
JVC could void the user’sauthority to operate
the equipment. Thisequipment has been
tested and found to comply with the limitsfor
aClass B digital device, pursuant to Part 15 of
the FCC Rules. These limitsare designed to
provide reasonable protection against harmful
interference in aresidential installation. This
equipment generates, uses, and can radiate
radio frequency energy and, if not installed
and used in accordance with the instructions,
may cause harmful interference to radio
communications. However, there isno guarantee
that interference will not occur in aparticular
installation. If thisequipment doescause harmful
interference to radio or television reception,
which can be determined by turning the
equipment off and on, the user isencouraged
to try to correct the interference by one or more
of the following measures: Reorient or relocate
the receiving antenna. Increase the separation
between the equipment and receiver.
Connect the equipment into an outlet on a
circuit different from that to which the receiver is
connected.
Consult the dealer or an experienced radio/
TV technician for help.
When usingthe AC adapter in areas other than
the USA
The provided AC adapter featuresautomatic voltage
selection in the AC range from 110 V to 240 V.
USING HOUSEHOLD AC PLUG ADAPTER
In case of connecting the unit’spower cord to
an AC wall outlet other than American National
Standard C73 seriestype use an AC plug adapter,
called a“SiemensPlug”, as shown.
For thisAC plug adapter, consult your nearest
JVC dealer. PlugAdapter
AC adapter
M9H7_EN_001D.book Page 3 Thursday, August 26, 2010 11:51 AM

4
Getting Started
This camcorder enables recording of HD format images as
videos or still pictures on an SD card, and also playback of
these videos or still pictures.
䡵SupportsvariousHD video recording formats
(1080i, 1080p, and 720p)
Shooting can be performed in different HD recording
modes, thus supporting a wide variety of content
production.
䡵QuickTime(MOV)/MP4 format for video files
Enables direct recording in the QuickTime file format used
by Apple Inc.’s Final Cut Pro. The recorded clips can be
edited directly using Final Cut Pro. In addition, the support
for MP4 file format enables the video files to be used
widely in different environments.
䡵SD card recording
This camcorder comes with two SD card slots, and
enables continuous recording to two SD cards by
switching automatically between the slots. In addition,
recorded files can also be moved or copied between the
two SD cards. However, video files can only be copied.
䡵Supportsboth video recording and still picture
recording modes
You can select a mode from video recording and still
picture recording. During playback of a file, you can select
a video or still picture from the thumbnail display on the
index screen or date search screen.
䡵Supports60 Hz/50 Hz HD signals
䡵FocusAssist function
Enables easy and accurate focusing during shooting.
䡵User buttonsadded
Enables you to switch camera settings instantly to suit the
shooting conditions.
䡵Time code reader/generator
The built-in time code reader/generator can be used to
record and play back the time code and user’s bit.
䡵Built-in viewfinder and color LCD display
Displays the status screens, menu screens for settings,
and alarm indications, in addition to the camera image
and playback image.
䡵Built-in monitor speaker for audio checking
䡵Recording check function for convenient
recording review
䡵Camera designed with 3-CCD system for high-
quality picture
䡵Zebra pattern video level indication
䡵Full Auto shooting mode
Eliminates the need for troublesome switch operations by
automatically providing a wide range of compatibility with
shooting conditions that change as you move between
indoors and outdoors or between bright and dark
locations.
䡵Image Stabilizer feature
Reduces blurring of images due to camera shake.
䡵ND filtersprovided
䡵Program AE function
Enables selection of shooting conditions according to the
scenes of your preference.
䡵White balance adjustment feature
Enables white balance to be adjusted automatically or
manually.
䡵Built-in color bars(multi-format color bars)
䡵Slow shutter
Makes it possible to brightly shoot video of dark subjects
with little motion by accumulating the images.
䡵Three audio input terminals
This camcorder comes with two XLR terminals and one
mini-jack terminal, which can be used as audio input
terminals for the built-in or external microphone.
䡵Three video output terminals
This camcorder comes with an HDMI terminal, a
component terminal, and an A/V OUT (video/audio
output) terminal, which support a wide variety of TV
monitor types.
䡵Connection to PCsvia USB port
Video or still picture files stored on an SD card can be
retrieved to a PC.
䡵Saving and loading of setting files
The current menu and camcorder settings can be saved
to an SD card. (Up to four files) In addition, settings files
stored on the SD card can also be loaded onto the
camcorder according to the shooting scene to reproduce
the most suitable settings.
Main Features
M9H7_EN_001D.book Page 4 Thursday, August 26, 2010 11:51 AM

5
Getting Started
Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Main Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Attaching the Audio Unit . . . . . . . . . . . . . . . . . . . . . . . .7
SD Cards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Precautions for Proper Use . . . . . . . . . . . . . . . . . . . . . . . . 8
Names of Parts and Functions . . . . . . . . . . . . . . . . . . . . 10
Names of Remote Control Parts and Functions . . . . . . .14
Indications on the LCD Screen and in the Viewfinder . . . 15
Displaying the Status Screen . . . . . . . . . . . . . . . . . . . .15
Items Displayed During Video and
Still Picture Shooting . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Items Displayed During Video Shooting Only . . . . . . . 16
Items Displayed During Still Picture Shooting Only . . . 17
Items Displayed During Video Playback . . . . . . . . . . . 17
Items Displayed During Still Picture Playback . . . . . . . 17
Preparations
Settings and Adjustments Before Use . . . . . . . . . . . . . . . 18
Adjusting the Grip Belt . . . . . . . . . . . . . . . . . . . . . . . . . 18
Setting up the Remote Control . . . . . . . . . . . . . . . . . . 18
Attaching an External Microphone . . . . . . . . . . . . . . . .18
Attaching the Tripod . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Removing the Hood . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Charging the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Checking the Remaining Battery Power . . . . . . . . . . .20
Turning On the Power . . . . . . . . . . . . . . . . . . . . . . . . . 20
Lens Cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Setting the Date . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Setting the Language . . . . . . . . . . . . . . . . . . . . . . . . . .21
Assigning Functions to the USER Buttons . . . . . . . . . 21
Viewing the Viewfinder/LCD Screen . . . . . . . . . . . . . . 22
Inserting an SD Card . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Formatting the SD Card . . . . . . . . . . . . . . . . . . . . . . . . 24
Resetting the File Number . . . . . . . . . . . . . . . . . . . . . . 24
Shooting
Selecting a Shooting Mode . . . . . . . . . . . . . . . . . . . . . . .25
Selecting the Video/Still Picture Shooting Mode . . . . . 25
Selecting the Full Auto/Manual Shooting Mode . . . . . . 25
Selecting a Focusing Mode . . . . . . . . . . . . . . . . . . . . . 26
Using the Camcorder in the Video Shooting Mode . . . . . 26
Setting the Video Format . . . . . . . . . . . . . . . . . . . . . . . 26
Displaying the Remaining Space on the SD Card . . . . 27
Shooting Videos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Capturing Still Pictures in the Video
Shooting Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Recording Multiple Clips as a Continuous File . . . . . .28
Using the Camcorder in the Still Picture
Shooting Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
Setting the Picture Quality, Recording Size,
and Sensitivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
Capturing Still Pictures . . . . . . . . . . . . . . . . . . . . . . . . .29
Zoom Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
Adjusting the Focus Manually . . . . . . . . . . . . . . . . . . . . .31
Using the Focus Assist Function . . . . . . . . . . . . . . . . .31
Shooting Different Scenes and Conditions
(Program AE) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
Enabling Lolux Mode with the USER Button . . . . . . . .32
Using the Built-in ND Filter . . . . . . . . . . . . . . . . . . . . . . .32
Adjusting the Exposure Manually . . . . . . . . . . . . . . . . . .33
Using the Tele Macro Feature . . . . . . . . . . . . . . . . . . . . .33
Displaying the Zebra Pattern . . . . . . . . . . . . . . . . . . . . . .34
Displaying the Zebra Pattern . . . . . . . . . . . . . . . . . . . .34
Specifying the Luminance Level Range for
Displaying Zebra Pattern . . . . . . . . . . . . . . . . . . . . . . .34
Adjusting the White Balance . . . . . . . . . . . . . . . . . . . . . .35
Adjusting Automatic White Balance . . . . . . . . . . . . . . .35
Using the Full Auto White Balance (FAW) Function . . .36
Adjusting White Paint . . . . . . . . . . . . . . . . . . . . . . . . . .36
Adjusting Manual Gain . . . . . . . . . . . . . . . . . . . . . . . . . .37
Adjusting the Shutter Speed . . . . . . . . . . . . . . . . . . . . . .37
Adjusting the Aperture . . . . . . . . . . . . . . . . . . . . . . . . . . .37
Setting the Photometry Area . . . . . . . . . . . . . . . . . . . . . .38
Displaying the Color Bar . . . . . . . . . . . . . . . . . . . . . . . . .39
Adjusting the Camera Image . . . . . . . . . . . . . . . . . . . . . .39
Audio Recording . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40
Setting the Reference Audio Recording Level . . . . . . .40
Using the Built-in Microphone . . . . . . . . . . . . . . . . . . .40
Using an External Microphone Connected to the
MIC Terminal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40
Using an External Microphone Connected to the
INPUT1/INPUT2 Terminal . . . . . . . . . . . . . . . . . . . . . .40
Reducing Wind Noise . . . . . . . . . . . . . . . . . . . . . . . . .40
Monitoring Audio Sound Using a Headphone . . . . . . . . .41
Time Code Recording Setting . . . . . . . . . . . . . . . . . . . . .41
Displaying the Time Code/User’s Bit . . . . . . . . . . . . . .41
Recording the Time Code . . . . . . . . . . . . . . . . . . . . . .41
Presetting the Time Code/User’s Bit . . . . . . . . . . . . . .42
Playback
Selecting the Video/Still Picture Playback Mode . . . . . . .43
Playing Videos on the SD Card . . . . . . . . . . . . . . . . . . . .43
Playing Back Videos from the Playback
Index Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43
Selecting a File on the Date Search Screen . . . . . . . .45
Viewing Video File Information . . . . . . . . . . . . . . . . . . .46
Capturing a Still Picture in the Still Mode . . . . . . . . . . .46
Enlarging a Still Image . . . . . . . . . . . . . . . . . . . . . . . . .47
Adjusting the Volume of the Built-In Speaker
or Headphone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47
Contents
M9H7_EN_001D.book Page 5 Thursday, August 26, 2010 11:51 AM

6
Getting Started
Playing Still Pictures on the SD Card . . . . . . . . . . . . . . . 48
Viewing Still Pictures in a Slideshow . . . . . . . . . . . . . . 48
Returning to the Still Picture Index Screen . . . . . . . . . 48
Selecting a File on the Date Search Screen . . . . . . . . 48
Viewing Still Picture File Information . . . . . . . . . . . . . . 49
Enlarging a Still Picture . . . . . . . . . . . . . . . . . . . . . . . .49
Viewing Videos on a Monitor . . . . . . . . . . . . . . . . . . . . . .49
Editing Files
Enabling/Disabling File Protection . . . . . . . . . . . . . . . . . . 50
Specifying Files Individually . . . . . . . . . . . . . . . . . . . . . 50
Specifying Selected Files . . . . . . . . . . . . . . . . . . . . . . . 50
Appending To or Deleting From All Files . . . . . . . . . . .51
Deleting Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Deleting Files Individually . . . . . . . . . . . . . . . . . . . . . . 51
Deleting Selected Files . . . . . . . . . . . . . . . . . . . . . . . . 51
Deleting All Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Copying/Moving Files . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Copying Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Moving Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Other Features
Connecting to a Computer . . . . . . . . . . . . . . . . . . . . . . . 54
Saving/Loading Settings . . . . . . . . . . . . . . . . . . . . . . . . . 54
Saving Settings to an SD Card . . . . . . . . . . . . . . . . . . 54
Loading Settings from an SD Card . . . . . . . . . . . . . . . 55
Operation Sound and Tally Settings . . . . . . . . . . . . . . . . 56
Displaying the Hour Meter . . . . . . . . . . . . . . . . . . . . . . . . 56
Restoring the Default Settings . . . . . . . . . . . . . . . . . . . . 56
Menu Screens
Setting Menu Screens . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
List of Valid Menu Items for Each Operation Mode . . . . . 58
Menu Screens of the Video Shooting Mode . . . . . . . . . .59
Menu Screens of the Still Picture Shooting Mode . . . . . .67
Menu Screens of Video/Still Picture Playback Modes . . . 69
Others
Tr o u bleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Warning Displays . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
Estimated Recordable Time/Number . . . . . . . . . . . . . . . 73
Estimated Video Recording Time . . . . . . . . . . . . . . . . 73
Estimated Number of Still Picture Shots . . . . . . . . . . . 73
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Dimensional Outline Drawing . . . . . . . . . . . . . . . . . . . . 75
Contents(continued)
How to use this manual
䡵Symbolsused
Caution :Describes precautions concerning the
operation of this product.
Memo :Describes reference information, such as
functions and usage restrictions of this
product.
A:Indicates the reference page numbers and
reference items.
䡵Content of thismanual
●All rights reserved by JVC. Unauthorized duplication or
reprinting of this manual, in whole or in part, is strictly
prohibited.
●All other product names used in this manual are
trademarks or registered trademarks of their respective
companies. Marks such as ™, 姞and 姝have been
omitted in this manual.
●Illustrated designs, specifications and other contents of
this manual are subject to changes for improvement
without prior notice.
Remember that this camcorder is intended for
private consumer use only.
Any commercial use without proper permission
isprohibited. (Even if yourecord an event such
as ashow, performance or exhibition for personal
enjoyment, it isstrongly recommended that you
obtain permission beforehand.)
Trademarks
•HDMI isatrademark of HDMI
Licensing, LLC.
•Other product and company namesincluded in
thisinstruction manual are trademarksand/or
registered trademarksof their respective holders.
•
We recommend using the Category 2 HDMI cable
(High Speed cable) for viewing in higher image quality.
•QuickTime and Final Cut Pro are trademarksof
Apple Inc.
M9H7_EN_001D.book Page 6 Thursday, August 26, 2010 11:51 AM

7
This camcorder comes bundled with the following
accessories.
Attaching the Audio Unit
The audio unit (with handle) is not attached to the camcorder
unit when purchased.
Attach the audio unit according to the following procedure.
1 . Attach the audio unit by sliding it all the way into
the shoe on the top of the camcorder.
2 . Turn the screw on the audio unit clockwise to fasten
it fully and securely to the camcorder.
TIf the audio unit is not fully and securely tightened, it will be
loose and may drop off from the camcorder during use.
3 . Connect the audio unit cable to the AUDIO IN
terminal of the camcorder.
Memo :
●The clamp on the audio unit is for fixing the microphone
cable and cannot be used to fix the audio unit cable.
(APage 18)
This camcorder saves the recorded images and audio sound
on the SD card (sold separately) in the card slot.
Memo :
●If the SD card contains files recorded by devices other than
this camcorder or files that are saved from a PC, the
recordable time may be shorter or data may not be
properly recorded. In addition, the remaining space on the
card may not increase even when files are deleted using a
PC.
Make use of the following SD cards.
Video : SDHC card that supports Class 6 or higher
(4 GB to 32 GB)
Still Picture : SD card (256 MB to 2 GB), SDHC card (4 GB
to 32 GB)
●Panasonic, TOSHIBA, or SanDisk
Using cards other than those specified above may prevent
data from being recorded correctly or result in loss of
data.
Accessories
The CD-ROM provided with this camcorder comes with
[JVC ProHD Clip Manager] and other application software
as well as the user guides.
TFor detail, refer to the user guides for each application
software.
AC Adapter
AP-V21M
Battery
BN-VF823U
Remote
Control Unit
CD-ROM Audio Unit
Component Cable AV Cord USB Cable
Battery Charger
AA-VF8KR
Microphone
Power Cord
⳯2
SD Cards
Audio Unit
Screw
Shoe Cable
AUDIO IN Terminal
Open the cover
Clamp
M9H7_EN_001D.book Page 7 Thursday, August 26, 2010 11:51 AM

8
Getting Started
䡵Allowable ambient temperature and humidity
Be sure to use this device within the allowable temperature range
of 0°C to 40°C and a relative humidity of 35 % to 80 %. Using this
device at a temperature or humidity outside the allowable ranges
could result not only in malfunction but the impact on the CCD
elements could be serious as small white spots may be generated.
䡵Strong electromagnetic wavesor magnetism
Noise may appear in the picture or audio and/or the colors may
be incorrect if the camera is used near a radio or television
transmitting antenna, in places where strong magnetic fields are
generated by transformers, motors, etc., or near devices emitting
radio waves, such as transceivers or cellular phones.
䡵Use of wireless microphone near the camera
When a wireless microphone or wireless microphone tuner is used
near the camera during recording, the tuner could pick up noise.
䡵Avoid using or placing thisdevice in the
following places.
●Places subject to extreme heat or cold
●Places with excessive dirt or dust
●Places with high humidity or moisture
●Places subject to smoke or vapor such as near a cooking stove
●Places subject to strong vibrations or unstable surfaces
●In a parked car under direct sunlight or near a heater for long
hours
●Places subject to radiation or X-rays, or where corrosive gases
occur
䡵 Protect thisdevice from being splashed with water.
(Especially when shooting in the rain)
䡵Protect thisdevice from getting wet when
shooting on a beach. In addition, salt and sand
may adhere to the camera body. Be sure to clean
the camera after use.
䡵Protect thisdevice against penetration of dust
when using it in a place subject to sandy dust.
䡵Do not expose thisdevice and the remote
control to excessive heat, such asdirect
sunlight or fire. The built-in battery may explode
if it getsheated up.
䡵Optical performance of lens
Due to the optical performance of the lens, color divergence
phenomena (magnification chromatic aberration) may occur. This
is not a camera malfunction.
䡵 Noise may appear in the image when switching
between the playback picture and the EE picture.
䡵If placed on itsside, heat release efficiency will
deteriorate.
䡵Precautionsfor transportation
●When carrying the camcorder, be sure to hold the carrying
handle. Holding the lens or viewfinder may result in damage.
●Do not drop or hit this device against a hard object.
䡵Do not insert objectsother than the memory
card into the card slot.
䡵Do not leave the card slot cover open for a long
period of time. Dirt entering the interior of the
slot may cause it to malfunction.
䡵Do not turn off the [POWER] switch or remove
the power cord during recording or playback.
䡵The camera may not show stable picturesfor a
few secondsimmediately after the power is
turned on, but thisisnot a malfunction.
䡵Do not turn off the [POWER] switch when the
camera rebootsdue to the following operations.
●Rebooting when the video/still picture mode is switched while
the [SYSTEM SELECT] menu is set to [720-**]
●Rebooting when the [SYSTEM SELECT] menu is set
●Rebooting after a setting file stored on the SD card is loaded
●Rebooting when the [SYSTEM SELECT] menu is changed
with the default value settings
䡵Use the supplied AC adapter asthe power
supply. Do not use the supplied AC adapter on
other devices.
䡵When the connectorsthat come with connector
coversare not in use, put on the coversto
prevent damage to the connectors.
䡵When thisdevice isnot in use, be sure to set the
[POWER] switch to AOFFBin order to reduce
power consumption.
䡵Wipe the external cabinet of the device with a
soft cloth. Do not wipe the body with benzene or
thinner. Doing so may cause the surface to melt
or turn cloudy. When it isextremely dirty, soak
the cloth in a solution of neutral detergent, wipe
the body with it, and then use a clean cloth to
remove the detergent.
LCD Screen and Viewfinder
䡵The LCD and viewfinder screensare
manufactured using high-precision technology.
Black spotsmay appear on the LCD and
viewfinder screens, or red, blue, and/or white
spotsmay not turn off. However, thisisnot a
malfunction and these spotsare not recorded
on the SD card.
䡵If you use thisdevice continuously for a long
period of time, the charactersdisplayed in the
viewfinder may temporarily remain on the
screen. Thisisnot recorded on the SD card.
They will not appear after you turn the power off
and then on again.
䡵If you use thisdevice in a cold place, the images
may appear to lag on the screen, but thisisnot a
malfunction. Thisisnot recorded on the SD
card.
䡵Do not press against the surface with force or
subject it to strong impact. Doing so may
damage or break the screens.
Handling of SD Cards
䡵The access lamp blinkswhen data on the SD
card isbeing accessed (recording, playback,
formatting, etc.). Do not remove the SD card,
turn off the power, or remove the battery/AC
adapter during access.
Precautionsfor Proper Use
M9H7_EN_001D.book Page 8 Thursday, August 26, 2010 11:51 AM

9
䡵If the SD card isremoved while data isbeing
accessed, the request for recovery screen may
appear repeatedly even if execution isselected.
When thishappens, format the SD card. All data
will be deleted.
䡵Do not use or store thisdevice in a place that is
subject to static electricity or electrical noise.
䡵Inserting the SD card incorrectly may result in
damage of thisdevice or the SD card.
䡵We are not liable for any accidental loss of data
stored on the SD card. (Please back up any
important data.)
䡵Make use of the SD card within the prescribed
conditionsof use.
Do not use the SD card in places that are subject to direct
sunlight, high humidity or corrosion, places near thermal
equipment, or in a car under the sun with the doors and windows
closed.
䡵Do not bend or drop the SD card, or subject it to
strong impact or vibration.
䡵Do not splash the SD card with water.
䡵Do not place the SD card near locationsthat are
exposed to strong magnetic fieldsor radio
waves.
䡵Do not touch the metal parts.
䡵If you want to wipe out all information by
completely erasing the data, we recommend
either using commercially available software
that isspecially designed for that purpose, or by
physically destroying the SD card with a
hammer, etc. When formatting or erasing data
using the camera, only the file administration
information ischanged. The data isnot
completely erased from the SD card.
Rechargeable Battery
䡵Be sure to use only JVC batteries.
We do not guarantee the safety and performance
of thisdevice if a battery other than a JVC
product isused.
䡵The battery isnot charged when purchased.
䡵When using the battery in a low temperature
environment (10°C or below), the operating time
may be shortened, or it may not function
properly. When using the device outdoorsin the
winter weather, warm the battery, such asby
placing it in the pocket, before attaching it.
䡵Do not expose the battery to excessive heat,
such asdirect sunlight or fire.
䡵If the battery isnot to be used for a long time,
Ause up the charge completely and detach it from the
camera to prevent deterioration. (Wait for the battery
to run out by itself such as through continuous
shooting or playback.)
Bcharge the battery once every half a year, and store it
again after using up the charge.
䡵Attach the battery cap after removing the
battery, and store it in a dry place between 15°C
to 25°C.
䡵ATTENTION:
The product you have purchased is powered by
a rechargeable battery that is recyclable.
Please call 1-800-8-BATTERY for information on
how to recycle this battery.
Characteristic CCD Phenomena
Smear and blooming
When shooting an extremely bright light source, vertical
streaking (called "smear") may occur or expansion of light
(called "blooming") may appear around it. This is a
characteristic of the CCD and not a malfunction.
Moire or aliasing
Stripes, lines or other fine patterns may appear jagged
when they are shot.
White dots
High temperatures can cause CCD sensor pixels to
produce white dots in the image. This condition is
conspicuous especially when gain is applied.
This is a characteristic of the charged-coupled device
(CCD). As far as possible, use this device under conditions
where the temperature of this device does not increase.
Characteristic LensPhenomena
When shooting an extremely bright light source, ghosting
may occur. This is a characteristic of the lens and not a
malfunction.
Copyright
Any recordings made on this camcorder that are played back
for profit or public preview may infringe on the rights of the
owner of the recordings.
Do not use the recordings for purpose other than personal
enjoyment without prior consent from the owner.
Battery
Battery Cap
Smear
Vertical pale streaking appearing at
high luminous object
High luminous object
(Electric light, sunlight, etc.)
Blooming
Blurring in highlight
Monitor Screen
M9H7_EN_001D.book Page 9 Thursday, August 26, 2010 11:51 AM

10
Getting Started
Front
ATally lamp (APage 56)
BTally lamp (APage 56)
CRemote control sensor (APage 18)
D[AWB] Auto White Balance button (APage 35)
For adjusting the white balance.
ELens/Lens cover (APage 20)
To p
FShoe
For mounting separately sold accessories.
GEyepiece focus lever
Lever for adjusting the visibility. It is found on the under
side.
HEyepiece
IViewfinder (APage 22)
J[SNAPSHOT] Snapshot button (APage 29)
Button for starting the recording of still images.
KZoom lever (APage 30)
For zooming to the Tele (T) or Wide (W) end.
LMicrophone holder (APage 18)
For mounting an external microphone.
MKnob
Knobfor locking the microphone in place.
NExternal microphone (APage 18)
Namesof Partsand
Functions
AWB
SNAP
SHOT
TW
SR
Qdcb
TU V WXY
Za
Front Top
M9H7_EN_001D.book Page 10 Thursday, August 26, 2010 11:51 AM

11
ABuilt-in microphone (APage 40)
BLens cover switch (APage 20)
CManual ring (APage 30)
D[ND FILTER] switch (APage 32)
Reduces the amount of incident light to 1/10.
E[GAIN] switch (APage 37)
For selecting one of the three sensitivity levels.
F[WHT.BAL.] White balance selection switch (APage 35)
For selecting one of the three types of white balance.
G[A/B] Card slot A/B selection button (APage 23)
HCard slot A access lamp (APage 23)
ICard slot A (APage 23)
Slot for SD cards.
Open the door to insert the SD card.
JCard slot B (APage 23)
Slot for SD cards.
Open the door to insert the SD card.
KCard slot B access lamp (APage 23)
L[FULL AUTO] Full Auto mode selection button
(APage 25)
For setting the shooting mode to the Full Auto or Manual
mode.
M[AF/MF] Focusing mode selection button (APage 26)
For setting the focusing mode to the Auto or Manual
mode.
N[FOCUS/ZOOM] ring switch
For setting the function of the manual ring to focus
(APage 31) or zoom adjustment (APage 30).
O[USER2] User 2 button (APage 21)
A specific feature in the menu setting can be assigned to
this button according to the user’s preference.
P[USER1] User 1 button (APage 21)
A specific feature in the menu setting can be assigned to
this button according to the user’s preference.
Q[CH-1/CH-2 AUDIO LEVEL] CH-1/CH-2 recording level
adjustment knob(APage 40)
For adjusting the audio input level for the CH-1 or CH-2
audio.
R[CH-1/CH-2 AUDIO SELECT] CH-1/CH-2 audio selection
switch (APage 40)
For setting the method of adjusting the audio recording
level for the CH-1 or CH-2 audio to the Auto or Manual
mode.
S[INPUT1/INPUT2 AUDIO INPUT] INPUT1/INPUT2 audio
input signal selection switch (APage 40)
For selecting the input signal for the INPUT1 or INPUT2
terminal.
T[CH-2 INPUT] CH-2 audio input terminal selection switch
(APage 40)
For selecting whether to input audio signals to CH-2
audio from the INPUT1 or INPUT2 terminal.
Memo :
●INPUT1 terminal, INPUT2 terminal: R, Son Page 13
CH-2 INPUT CH-1
3
4
5
2
1
2
3
0
CH-2
AUDIO INPUT
AUTO MANUAL
AUTO MANUAL
USER1
GAIN
L-
M-
H-
B-
A-
PRST-
WHT.BAL A / B
AB
FOCUS
ZOOM
ON
ND
FILTER
OFF
USER2
AF/MF FULL AUTO
AUDIO
SELECT
INPUT1
INPUT2
- LINE -
- MIC -
MIC+48V
INPUT1
INPUT2
S
R
Q
d
c
b
TUVW XY Za
e
f
g
hij
LCD Side
M9H7_EN_001D.book Page 11 Thursday, August 26, 2010 11:51 AM

12
Getting Started
ALCD cover
B[COMPONENT OUT] Component output terminal
(APage 49)
C[A/V OUT] Audio/Video output terminal (APage 49)
D[Q.REVIEW] Quick Review button (APage 27)
For checking the video image immediately before
shooting starts.
E[MENU] Menu button (APage 57)
Displays the menu screen. Press this button again to exit
the menu screen.
FBuilt-in speaker (APage 47)
G[CAM/MEDIA] Camera shooting/media playback
selection button (APage 25)
For setting this camcorder to the Camera Shooting or
Media Playback mode.
H[USER3] User 3button (APage 21)
A specific feature in the menu setting can be assigned to
this button according to the user’s preference.
I[DISPLAY] Display button
For switching the displays on the LCD screen and
viewfinder. (APage 15)
When in the playback mode, pressing this button displays
the file information.
(APage 46)
J[REC] Video recording button (APage 27)
Button for starting or stopping video recording.
KLCD screen (APage 22)
L[INDEX] Index button
Displays the remaining space on the SD card
(APage 27) and the remaining battery power
(APage 20).
When in the playback mode, pressing this button
switches between the playback index and date search
screens. (APage 45)
MSet Lever
When in the shooting mode, this lever is used for
Program AE selection and as the zooming lever.
(APage 32)
When in the playback mode, this lever is used for
playback file selection and playback control. (APage 43)
When the menu screen is displayed, this lever is used for
menu setting. (APage 57)
Bottom
NTripod mounting holes (APage 18)
●To prevent the camcorder from falling, attach securely
using the rotation prevention hole.
●Use screws with screw length 5 mm and below.
Namesof Partsand
Functions(continued)
CH-2 INPUT CH-1
3
4
5
2
1
2
3
0
CH-2
AUDIOINPUT
AUTOMANUAL
AUTO MAN UAL
USER1
GAIN
L-
M-
H-
B-
A-
PRST-
WHT.BAL A / B
AB
FOCUS
ZOOM
ON
ND
FILTER
OFF
USER2
AF/MF FULL AUTO
AUDIO
SELECT
INPUT1
INPUT2
- LINE -
- MIC -
MIC+48V
INPUT1 INPUT2
Q.REVIEW
MENU
CAM / MEDIA
DISPLAY
COMPONENT
OUT
A / V OUT
USER3
INDEX
T
W
REC
P
R
O
G
R
A
M
A
E
SRQ
d
cb
T
UVWXY
Z
a
LCD Side (LCD Cover)
When the LCD cover is opened
Bottom
M9H7_EN_001D.book Page 12 Thursday, August 26, 2010 11:51 AM

13
Rear
A[IRIS] Aperture button (APage 37)
Press this button to set the aperture manually.
B[SHUTTER] Shutter Speed button (APage 37)
Press this button to set the shutter speed manually.
C[AE±] Exposure button (APage 33)
Press this button to set the exposure manually.
D[ADJ./VOL.] Adjustment/Volume knob
ADJ. : For adjusting the aperture (APage 37), shutter
speed (APage 37), and exposure (APage 33).
VOL. : Also for adjusting the volume of a headphone and
the built-in speaker. (APage 41)
EBattery mount (APage 19)
F[HDMI] terminal (APage 49)
G[USB (2) ] terminal (APage 54)
H[DC] input terminal (APage 19)
IBattery lock release button (APage 19)
J[REC] Video recording button (APage 27)
For starting or stopping video recording.
KStill picture indicating lamp (APage 25)
Lights up during still picture shooting or still picture
playback mode.
LVideo indicating lamp (APage 25)
Lights up during video shooting or video playback mode.
M[ACCESS] Charging/Access indicating lamp
Lights up or blinks during recording or playback.
Blinks when the battery is charging. (Light goes out when
charging is complete.)
Grip Belt Side
N[POWER/MODE] Power/Operating mode switch
POWER : Turns the power On/Off. (APage 20)
MODE : Switches between the video mode and still
picture mode. (APage 25)
OGrip belt mount (APage 18)
P[HEADPHONE ( )] Headphone jack (APage 41)
Q[MIC] Microphone input terminal (APage 40)
For connecting a mini-jack microphone.
●The MIC terminal provides a 4 V power supply to the
microphone.
R[INPUT1] Audio input 1 terminal (APage 40)
For connecting an XLR microphone.
S[INPUT2] Audio input 2 terminal (APage 40)
For connecting an XLR microphone.
MIC
DC
OPEN
REC
PUSH
IRIS
SHUTTER
AE
±
ADJ./ VOL.
CLOSE
ACCESS
S
R
Q
d
c
b
TUVWXY
Z
a
efg
hi
e
Rear Grip Belt Side
M9H7_EN_001D.book Page 13 Thursday, August 26, 2010 11:51 AM

14
Getting Started
A[STA RT / STOP] button
Button for starting or stopping video recording.
B[ZOOM] button
Press (T) to zoom in.
Press (W) to zoom out.
Playback zoom can be used when a video is paused or
during playback of still images.
C[S.SHOT] SNAPSHOT button
Button for starting the recording of still images.
D[–] button
Moves to the previous date when the playback index
screen is displayed.
E[N] Reverse button
Returns to the beginning of the file during playback.
F[PLAYLIST] button
This function is not available on this camcorder.
G[DISP] DISPLAY button
For switching the displays on the LCD screen and
viewfinder.
H[INDEX] button
Displays the remaining space on the SD card and the
remaining battery power.
When in the playback mode, pressing this button
switches between the playback index and date search
screens.
I[O] Forward button
Advances to the next file during playback.
J[+] button
Moves to the next date when the playback index screen is
displayed.
K[INFO] button
When in the playback mode, pressing this button displays
the file information.
L[ ] Left button
Moves the cursor to the left on the menu screen or
playback index screen.
It is also used to perform reverse search during playback.
M[ ] Down button
Moves the cursor downward on the menu screen or
playback index screen.
N[ ] Right button
Moves the cursor to the right on the menu screen or
playback index screen.
It is also used to perform forward search during playback.
O[ ] Up button
Moves the cursor upward on the menu screen or
playback index screen.
P[SET] button
For confirming a selected item on the menu screen or
playback index screen.
It is also used to start or stop playback when in the
playback mode.
Memo :
●To use the remote control, set [REMOTE] in the [CAMERA
SETTINGS] menu to [ON]. (APage 66)
Namesof Remote Control
Partsand Functions
SET
SET
S
R
Q
d
c
b
T
U
V
W
X
Y
Z
a
e
f
The Left, Right, Up, and Down buttons can be used to shift
the zoom position when a still image is enlarged using the
ZOOM button.
M9H7_EN_001D.book Page 14 Thursday, August 26, 2010 11:51 AM

15
The status screen can be displayed on the LCD screen or
viewfinder.
Status screen is a screen display for identifying the current
settings.
Displaying the StatusScreen
䡵When in the video shooting or still picture
shooting mode
Pressing the DISPLAY button each time toggles the display
as follows:
“Main information for camera shooting”B“Full display”B
“Simple display”
The diagrams above are displays in the video shooting
mode.
䡵When in the video playback or still picture
playback mode
During video playback, pressing the DISPLAY button each
time toggles the display as follows:
[DISPLAY DATE ONLY]B[DISPLAY ALL]B[OFF]
Memo :
●When in the still mode or when the index screen is
displayed, pressing the DISPLAY button displays the file
information.
●To display this screen on the monitor that is connected to
the video output terminal of this camcorder, set [DISPLAY
ON TV] in the [CONNECTION SETTINGS] menu to [ON].
Indicationson the LCD
Screen and in the Viewfinder
DISPLAY
00:00:00:00
18dB
F5.6
1/4000
±0
[
1h56m
]
[
1h56m
]
A
B
CH1
CH2
4:50 PM
00:00:00:00
10x
18dB
F5.6
1/4000
±0
3200K
SPORT
ND
[
1h56m
]
[
1h56m
]
NOV.1.2009
A
B
CH1
CH2
Main in
f
ormation
f
or camera shooting
Full display
Simple display
DISPLAY
DISPLAY
Appears when the remaining
time falls below 2 minutes
Q.REVIEW MENU
CAM / MEDIA
DISPLAY
COMPONENT
OUT
A / V OUT
USERS
DISPLAY button
Select the details to display using the settings in the [ON-
SCREEN DISPLAY] menu.
ASetting Menu ScreensB: (APage 57)
OFF : No display.
DISPLAY ALL : Displays all icons and the date and time.
DISPLAY DATE
ONLY : Displays only the date and time.
DISPLAY DATE
5 SEC : Displays only the date and time for 5
seconds in the following cases:
●When playback starts
●When a file is changed during playback
●When the menu screen is closed
DISPLAY
4:50 PM
NOV.1.2009
NOV.1.2009
4:50 PM
00:00:00:00
005/600
+1
A
DISPLAY DATE ONLY
DISPLAY ALL
OFF
DISPLAY
DISPLAY
M9H7_EN_001D.book Page 15 Thursday, August 26, 2010 11:51 AM

16
Getting Started
ItemsDisplayed During Video and Still
Picture Shooting
AShooting Mode
A:FullAutoShooting
M:ManualShooting
BFocusing Mode
AF : Auto Focus
MF : Manual Focus
CExposure
L:Fixed
DAperture
EShutter Speed
FND Filter
Displayed when the ND filter switch is set to AONB.
GWhite Balance Color Temperature
HProgram AE
PORT : Portrait
SPORT :Sports
SNOW :Snow
SPOT.L :Spotlight
TWIL. : Night
IImage Stabilizer [OFF]
Displayed when [OIS] in the [CAMERA SETTINGS] menu
is set to [OFF].
JLCD Screen Backlight
Displayed when [MONITOR BACKLIGHT] in the
[DISPLAY SETTINGS] menu is set to [ON].
KMicrophone Input Level
LDate/Time
MBattery
Blinks in red when the battery runs out.
NFocus Assist
Displayed when [FOCUSASSIST] in the [CAMERA
PROCESS] menu is set to [ON].
OSpeaker/Headphone Volume (displayed during volume
adjustment)
PZoom
QCard Slot
: The selected card slot is indicated by the card icon
as shown on the left.
RAutomatic Slot Switch
Displayed when [SLOT AUTO SWITCHING] in the
[CAMERA SETTINGS] menu is set to [ON].
STele Macro
Displayed when [TELE MACRO] in the [CAMERA
PROCESS] menu is set to [ON].
ItemsDisplayed During Video Shooting
Only
AVideo Mode
BSensitivity
CWind Noise
Displayed when the [WIND CUT] menu is set to [ON].
DSimultaneous Still Picture Recording
EContinuous Clip Recording
Displayed when the [CLIP CONTINUOUSREC] menu is
set to [ON].
FMode Indicator
RREC : Recording
RW : Record Standby mode (Record Pause mode)
GTime Code or User’s Bit
TC : Time Code
UB : User’s Bit
The framing mode display for the time code is as follows:
HRemaining Time on the SD Card
IVideo Picture Quality
SP:Standard
HQ : High
JFrame Rate
KVertical Resolution
LHorizontal Resolution
Indicationson the LCD
Screen and in the
Viewfinder (continued)
NOV.1.2009
4:50
10x
F5.6
1/4000
±0
3200K
SPORT
ND
PM
A
B
CH1
CH2
S
R
Q
d
c
b
T
U
V
W
X
Y
Za
e
f
g
hi
The color of the icons in I, J, Kand Lchanges
according to the settings in the [FILE FORMAT] menu.
When set to [QuickTime file format] : Displays in blue.
When set to [MP4 file format] : Displays in orange.
00:00:00:00
18dB
[
1h56m
]
[
1h56m
]
S
R
Q
b
T
U
V
W
X
Y
Z
a
00:00:00:00Colon (:) for non-drop frames
Dot (.) for drop frames
M9H7_EN_001D.book Page 16 Thursday, August 26, 2010 11:51 AM

17
ItemsDisplayed During Still Picture
Shooting Only
AStill Picture Mode
BFocus Icon
Blinks in yellow: Focusing in progress
Lights in green: Focusing completed
CSelf-Timer
: 10-second self-timer
: 2-second self-timer
DStill Picture Recording
EShutter Mode
: Continuous Shooting
: Bracket Shooting
FRemaining Number of Shots on the SD Card
GStill Picture Quality
FINE : High
STD : Standard
HStill Picture Size
ItemsDisplayed During Video Playback
AVideo Mode
BDate/Time
CBattery
Blinks in red when the battery runs out.
DSpeaker/Headphone Volume (displayed during volume
adjustment)
ETime Code or User’s Bit
TC : Time Code
UB : User’s Bit
The framing mode display for the time code is as follows:
FCurrent File Number/Total Number of Files
GMode
I:Playback
W:Still
N:ForwardSearch
O: Reverse Search
WI :ForwardSlow
HW : Reverse Slow
The value on the left indicates the speed step.
HCard Slot
IAutomatic Slot Switch
Displayed when [SLOT AUTO SWITCHING] in the
[CAMERA SETTINGS] menu is set to [ON].
JVideo Picture Quality
SP:Standard
HQ : High
KFrame Rate
LVertical Resolution
MHorizontal Resolution
ItemsDisplayed During Still Picture
Playback
AStill Picture Mode
BDate/Time
CBattery
Blinks in red when the battery runs out.
DSlideshow (Blinks during playback)
ECurrent File’s Folder Number and File Number
FCard Slot
GAutomatic Slot Switch
Displayed when [SLOT AUTO SWITCHING] in the
[CAMERA SETTINGS] menu is set to [ON].
[
9999
]
[
9999
]
1
10
10
S
R
Q
T
U
V
W
X
NOV.1.2009
4:50 PM
00:00:00:00
A
005/600
+1
S
R
Q
cb
T
U
V
WXYZa
The color of the icons in J, K, Land Mchanges
according to the settings in the [FILE FORMAT] menu.
When set to [QuickTime file format] : Displays in blue.
When set to [MP4 file format] : Displays in orange.
00:00:00:00 Colon (:) for non-drop frames
Dot (.) for drop frames
101-0098
NOV.1.2009
4:50 PM
S
R
Q
T
U
VW
M9H7_EN_001D.book Page 17 Thursday, August 26, 2010 11:51 AM

18
Preparations
Adjusting the Grip Belt
Open the pad and adjust the position of the grip belt accordingly.
Caution :
●If the grip is loose, the camcorder may fall off resulting in
injuries or malfunction.
●Parents should take extra care when your child is using the
camcorder.
Setting up the Remote Control
The remote control comes supplied with batteries when you
purchase this product.
To start using, pull out the insulation sheet.
Memo :
●To use the remote control, set [REMOTE] in the [CAMERA
SETTINGS] menu to [ON].
●Point the front end of the remote control toward the sensor.
Use the remote control within a distance of 5 meters from
the camcorder. The camcorder may not respond to the
remote control operations at some angles.
䡵Replacing batteries
1 . Press the lock tab, and pull out the battery holder.
2 . Replace the button battery (CR2025).
Attaching an External Microphone
You can attach a microphone to the microphone holder.
The supplied microphone is a phantom microphone.
1 . Turn the knob on the microphone holder
anticlockwise to loosen it and open the microphone
holder.
2 . Place the microphone in the microphone holder.
3 . Turn the knob on the microphone holder clockwise
to secure the microphone.
4 . Connect the microphone to the INPUT1/INPUT2
audio input terminal, or the MIC terminal according to
the type of microphone cable terminal you are using.
INPUT1/INPUT2 Terminal: XLR Terminal
MIC Terminal : Mini-jack Terminal (stereo)
5 . Attach the microphone cable to the clamp.
6 . Specify the audio input settingscorrectly.
(APage 40)
Memo :
●When the audio unit cable is connected to the AUDIO IN
terminal of the camcorder, the MIC terminal is disabled.
Attaching the Tripod
To prevent the camcorder from falling off, which may result in
injuries or damages, read the instruction manual of the tripod
to be used and make sure that it is securely attached.
(APage 12)
Caution :
●Use the tripod on a stable surface.
Settingsand Adjustments
Before Use
AWB
Remote Control Sensor
Insulation Sheet
Lock Tab
Button Battery
A
UDIO IN
OPEN
2. Microphone
Microphone Holder
5. Clamp
4. INPUT1/
INPUT2 Terminals
1.3. Knob
AUDIO IN
Terminal
4. MIC Terminal
M9H7_EN_001D.book Page 18 Thursday, August 26, 2010 11:51 AM

19
Removing the Hood
Remove the hood when attaching a filter (with external
diameter 50 mm and below), teleconverter or wide converter
to the front of the lens.
䡵Turn the hood in an anti-clockwise direction to
remove it.
Charging the Battery
There are two ways to charge the battery.
䡵Charging with the supplied battery charger.
䡵Charging with thiscamcorder.
1 . Connect the battery charger to a power outlet using
the provided power cord.
2 . Attach the supplied battery to the battery charger
by pressing and sliding it in the direction of the
arrow.
●When battery charging starts, the indicating lamp
blinks.
●When charging is complete, the indicating lamp lights
up.
3 . Remove the battery by sliding it in the opposite
direction after charging iscomplete.
1. Turn off the power of the camcorder.
2 . Attach the supplied battery.
With the battery mark (D) on the left, insert it into the
camcorder, and slide it to the left.
3 . Connect the AC adapter that isprovided with the
camcorder.
Connect the DC cable to the DC terminal, and the AC
adapter to a power outlet using the provided power cord.
●When battery charging starts, the access indicating
lamp blinks.
●When charging is complete, the access indicating lamp
goes out.
Charging time and continuous recording time (approximate)
●The above are the approximate charging times when
used under an ambient temperature range of 10°C to
35°C.
●A longer charging time may be required if the battery has
been left unused for a long time.
●Recording time may differ depending on the age of the
battery, charging condition, and operating environment.
●Recording time is shortened in cold environments.
●Recording time is shortened when the zoom lens and
LCD screen are frequently used.
䡵Removing the battery
1 . Turn off the power of the camcorder.
2 . Press the battery lock release button and slide the
battery to the right.
Charging the Battery with the Supplied
Charger
Hood
To Power Outlet
Power Cord
Battery
Charger
Indicating Lamp
Battery
Charging the Battery with thisCamcorder
Battery Charging Time Continuous
Recording Time
BN-VF815U Approx. 2 hrs 40
mins
Approx. 1 hr 25
mins
BN-VF823U
(Provided)
Approx. 3hrs 40
mins
Approx. 2 hrs 10
mins
MIC
AU DIOIN
OPEN
Access Indicating Lamp
Battery Lock
Release Button
Battery
DC Terminal
AC Adapter
To Power Outlet
Power Cord
M9H7_EN_001D.book Page 19 Thursday, August 26, 2010 11:51 AM

20
Preparations
Checking the Remaining Battery Power
Preparation: Attach the battery.
1 . Press INDEX.
●The remaining battery power and recordable time are
displayed for about 3seconds.
To display the information for about 15 seconds, press
INDEX for 2 seconds or longer.
Memo :
●The recordable time display should only be used as a
guide.
It is displayed in units of 10 minutes.
●The recordable time shown on the LCD screen may differ
from that shown on the viewfinder.
䡵When the power ison
1 . Video shooting mode: Press INDEX three times.
Still picture shooting mode: Press INDEX once.
2 . Press INDEX to clear the display.
Memo :
●When video shooting is in progress, the information does
not appear.
●When the AC adapter is in use, the information does not
appear.
Turning On the Power
Preparation: Attach a charged battery or connect the AC
adapter.
1 . Set the POWER/MODE switch to ON.
●The camcorder turns on in the video shooting mode.
䡵Turning off the power
1 . Set the POWER/MODE switch to OFF.
䡵Auto Power Off feature
When [AUTO POWER OFF] in the [CAMERA SETTINGS]
menu is set to [ON], the power turns off automatically when it
is not operated for 5 minutes or longer.
LensCover
Before shooting, open the lens cover.
When this camcorder is not in use, close the lens cover to
protect the lens.
䡵Use the lens cover switch to open or close the lens cover.
Memo :
●Do not press against the lens cover with force. Doing so
may damage the lens or the cover.
Settingsand Adjustments
Before Use (continued)
INDEX
BATTERY CONDITION
MAX TIME
min
DC
REC
PUSH
IRIS
SHUTTER
INDEX
T
W
REC
AE ±
ADJ./ VOL.
P
R
O
G
R
A
M
A
E
INDEX
INDEX
MIC
POWER/MODE Switch
USER1
GAIN
L-
M-
H-
B-
A-
PRST-
WHT.BAL A / B
AB
FOCUS
ZOOM
ON
ND
FILTER
OFF
USER2
AF/MF FULL AUTO
Lens Cover Switch
M9H7_EN_001D.book Page 20 Thursday, August 26, 2010 11:51 AM
