KD-AV7008
Installation/Connection Manual
LVT1174-002A
[A]
This unit is designed to operate only on 12 V DC, NEGATIVE ground electrical systems. If your
vehicle does not have this system, a voltage inverter is required, which can be purchased at JVC
car audio dealers.
WARNINGS
•DO NOT install any unit in locations where;
–it may obstruct the steering wheel and gearshift lever operations, as this may result in a traffic
accident.
–it may obstruct the operation of safety devices such as air bags, as this may result in a fatal
accident.
–it may obstruct visibility.
•DO NOT operate any unit while manipulating the steering wheel, as this may result in a traffic
accident.
•The driver must not watch the monitor while driving.
If the driver watches the monitor while driving, it may lead to carelessness and cause an accident.
•If you need to operate the main unit while driving, be sure to look ahead carefully or you may be
involved in a traffic accident.
•If the parking brake is not engaged, “DRIVER MUST NOT WATCH THE MONITOR WHILE
DRIVING.” appears on the monitor, and no playback picture will be shown.
–This warning appears only when the parking brake wire is connected to the parking brake
system built in the car.
Notes on mounting the hideaway unit
• Mount on a firm surface, under the front seat or in the trunk.
•Since heat is generated inside the unit, do not mount near inflammable objects. In addition, mount
in an area that will not prevent the unit from dissipating heat.
•Do not mount the unit in the places which are subject to heat such as near a radiator, in a glove
compartment or in insulated area such as under a car mat that will prevent the unit from dissipating
heat.
Notes on electrical connections
•Replace the fuse with one of the specified rating. If the fuse blows frequently, consult your JVC
car audio dealer.
•Maximum input of the speakers should be more than 50 W at the rear, 50 W at the front, and
35 W at the center, with an impedance of 4 Ωto 8 Ω.
•Be sure to ground each unit to the car’s chassis.
•The main unit and the hideaway unit become very hot after use. Be careful not to get burned
when removing them.
•To prevent short-circuit, cover the terminals of the UNUSED leads with insulating tape.
•Take preventative measures to avoid unexpected disconnection of the cords and
damage to the cords.This trouble may happen while moving or reclining the seat.
1004MNMMDWJEIN
EN
Parts list
aMain unit
rWasher—ø5 sRubber cushion
qLock nut—M5
bHideaway unit
tRemote controller uBattery
CR2025
RM-RK220
vCenter speaker/rear
camera cord
wExtension antenna cord
CSleeve-mounting plates
Type A Type B
dFixing screws—
M5 x 6 mm
e, fPower cords
eFor main unit: fFor hideaway unit:
gAV bus cable—2.5 m
hCrimp connectors iHandles jSoft case kTr im plate
lSleeve mBrackets nFixing screws—
M4 x 8 mm
oBlind cover
pMounting bolt—
M5 x 20 mm
When installing the unit without using the sleeve
In a Toyota for example, first remove the car radio and install the unit in its place.
Note : When installing the unit on the mounting bracket, make sure to use screws of proper
length refering to the table above. If longer screws are used, they could damage the unit.
Flat type screws*2
Bracket*2
*2Not included with this unit.
Pocket
123 45
678 9
l
rq
p
When using the optional stay
Screw (option)
Stay (option)
Fire wall
Dashboard
Install the unit at an angle of less than 30˚, taking it into account
that the monitor would eject when in use (see below).
30˚
Required space for the monitor ejection
60˚
105˚
51.8
143.3
15
12.2
mm
177
© 2004 Victor Company of Japan, Limited
Use the following screws
For No.1 – 5 M5 x 8 mm*2
For No.6 – 9 M4 x 3 mm*2
InstallKD-AV7008_1[A]5.p65 04.10.5, 3:49 PM1

2
B
C
E
A F~
F
A
REMOTE
SENSOR RESET 3214
AV OUTPUT
RLVIDEO
POWER AV BUS AUDIO
TV ANTENNA
TV TUNER UNIT KV-C1008
MULTIMEDIA DVD/CD RECEIVER WITH REMOVABLE MONITOR HIDEAWAY UNIT KD-AV7008
AV INPUT 1
L
RAUDIO
FM / AM ANTENNA
POWER
BACKCAMERA
REMOTE
CENTER
SPEAKER
CENTER
SUB
WOOFER
L
R
REAR
L
R
FRONT
VIDEO
AV INPUT 2
L
RAUDIO VIDEO TO CHANGER AV BUS TO MAIN UNIT
PRE OUT
AUDIOVIDEO L R
AV OUTPUT
LR
LR
TO CHANGER
VIDEO
B
F
D
A
C
A
CA
CB E
D
L
C
B
R
SYSTEM CONNECTIONS
•For A , B , C , D, E, F, more information are given on the following pages.
Camcorder, rear view camera, etc.
VCR (KV-V8 or KZ-V10)
Playback source
CD changer
CD changer (CH-X1500, etc.)
2nd monitor
Center speaker
(CS-CN100, etc.)
See “ C Electrical connections.”
See “ EConnecting the external amplifiers.”
TV tuner unit
(KV-C1008)
Antenna cord from the car
Hideaway unit
Main unit
AV bus cable (supplied)*1
See “ FConnecting the back camera lead.”
See “ DConnecting the cradle.”
:These products are optionally available
from JVC.
Use the extension antenna cord (supplied)
if necessary.
*1Extension AV bus cable (KV-U1013: not supplied) can be used when the supplied AV bus cable is
not long enough.
Black
Black with white stripe
Purple with white stripe
2
1
53 mm
184 mm
!
Ÿ
~
⁄
@
l
s
p
k
c
A
d
B
B
INSTALLATION
The following illustration shows a typical installation. However, you should make adjustments corresponding to your specific car. If you have any questions or require information regarding installation
kits, consult your JVC car audio dealer or a company supplying kits.
ÅInstalling the main unit (in-dash mounting)
Do the required
electrical connections.
Attach the sleeve-mounting plates—either type,
corresponding to the depth of the mounting area
(A: see the next step).
Use Type B when Ais 165 mm while use Type A
when Ais less than 165 mm.
Bend the appropriate tabs to hold
the sleeve firmly in place.
2
1
i
Removing the main unit
Before removing the main unit, release the rear section.
Insert the two handles, then pull them as
illustrated so that the unit can be removed.
InstallKD-AV7008_1[A]5.p65 04.10.5, 3:49 PM2

3
(PARKING BRAKE)
1
2
3
5
6
4
7
2
1
(ILLUMINATION)
3
4
2
1
2
1
6A
Fuse block
To a live terminal in the fuse block connecting to the car battery (bypassing the
ignition switch) (constant 12 V)
To an accessory terminal in the fuse block
To metallic body or chassis of the car
Ignition switch
*1Not supplied with this unit.
*2Before checking the operation of this unit prior to installation, this lead must be connected, otherwise power cannot be turned on.
Orange with white stripe
Red
Yellow*2
Black
Yellow*2
Blue with white stripe
Fuse block
To a live terminal in the fuse block connecting to the car battery
(bypassing the ignition switch) (constant 12 V)
To metallic body or chassis of the car
Black
Gray with black stripe
White
White with black stripe Green with black stripeGray Green Purple with black stripe Purple
To the remote lead of other equipment—200 mA max.
Left speaker (rear)Right speaker (front)
Left speaker (front) Right speaker (rear)
Ignition switch
Light green
To automatic antenna if any—250 mA max.
Blue
Main unit
Hideaway unit *1
*1
*1
*1
To parking brake of the car
15 A fuse
PRECAUTIONS on power supply and
speaker connections:
•DO NOT connect the speaker leads of the
power cord to the car battery; otherwise, the
units will be seriously damaged.
•BEFORE connecting the speaker leads of the power
cord to the speakers, check the speaker wiring in
your car.
L
R+
-
+
-
+
-
+
-
L
R+
-
+
-
+
-
+
-
L
R+
-
+
-
+
-
+
-
Where-to-connect depends on your dimmer usage.
For details, see page 46 of the Instructions.
PARKING
BRAKE
h
Connecting the parking brake wire
Connect the parking brake wire to the parking brake system built in the car.
To metallic body or chassis
of the car
Parking brake switch (inside the car)
Parking brake wire (light green)
Parking brake
Contact the metallic part of the crimp
to the wires inside.
Attach the parking brake wire (light green) to this point.
Wire connecting the battery and the parking brake switch.
Pinch the crimp firmly.
How to connect the crimp connector
m
n
Tapping screws (not supplied)
Floor
ıInstalling the hideaway unit (under the front seat)
•Be sure to use the tapping screws (not supplied) of appropriate length so that they will not
damage any parts of the car.
1 Connect the colored leads of the power cord in the order specified in the illustration below.
2 Connect the wiring harness to the units.
3 Connect the main unit and the hideaway unit using AV bus cable (supplied).
ÇElectrical connections
Before connecting...
•Make sure that the antenna cord from the car is connected to the hideaway unit (see page 2). If the
antenna cord is not long enough, use the extension antenna cord (supplied).
•Check the wiring in the car carefully. Incorrect connection may cause serious damage to the units.
The leads of the power cord and those of the connector from the car body may be different in color.
Brown
To cellular phone system
InstallKD-AV7008_2[A]5.p65 04.10.5, 3:49 PM3

4
Headphones (not supplied)*4
D Connecting the cradle
By using the cradle (KV-CR100), you can remove the monitor from the main unit and insert it into the cradle so that the persons
sitting on the rear seat can view the playback picture even while the driver are driving your car.
•The driver must not put on the headphones while driving. It is dangerous to shut off the outside sounds while driving.
•Additional monitor (KV-MAV7001) can also be purchased to used so that you do not need to remove the monitor from the main
unit.
KV-CR100
Main unit Removable monitor or additional
monitor KV-MAV7001*3
AV bus cable supplied for KV-CR100
After removing the monitor from the main unit, insert the blind
cover into the main unit to prevent internal dust accumulation.
Hold
Stereo mini plug (∅3.5 mm)
o
*3When not in use, store the monitor in the supplied soft case for its
protection.
*4To listen to source sound while in Dual Mode operations.
See page 33 of the INSTRUCTIONS (separate volume).
MULTIMEDIA DVD/CD RECEIVER WITH REMOVABLE MONITOR HIDEAWAY UNIT KD-AV7008
AV INPUT 1
L
RAUDIO
FM / AM ANTENNA
POWER
BACKCAMERA
REMOTE
CENTER
SPEAKER
CENTER
SUB
WOOFER
L
R
REAR
L
R
FRONT
VIDEO
AV INPUT 2
L
RAUDIO VIDEO TO CHANGER AV BUS TO MAIN UNIT
PRE OUT
AUDIO
VIDEO L R
AV OUTPUT
LRL
L
INPUT
INPUT
INPUT
R
L
INPUT
R
L
R
L
R
R
JVC Amplifier
Rear speakers
Front speakers
JVC Amplifier
Subwoofer
Center speaker
EConnecting the external amplifiers
You can connect amplifiers to upgrade surround system in the car compartment.
•Connect the PRE OUT terminals of the hideaway unit to the amplifier’s line-in terminals.
•Disconnect the speakers from the hideaway unit, connect them to the amplifier. Leave the speaker leads of the unit
unused.
*5Firmly attach the ground wire to the metallic body or to the chassis of the car—to the place uncoated with paint (if coated with
paint, remove the paint before attaching the wire). Failure to do so may cause damage to the unit.
*5
*5*5
*5
FConnecting the back camera lead
Locate the back lamp lead in the trunk.
Back lamp lead
JVC Amplifier
JVC Amplifier
If you connect the remote lead (blue with white stripe) to the remote lead of the other equipment, they can be turned on and off
automatically with this unit.
Remote lead
Y-connector (not supplied with this unit)
Remote lead (Blue with white stripe)
Hideaway unit To the remote lead of other equipment
JVC Amplifier
Back lamps
BACK
CAMERA
To back lamp To car battery
Back lamp lead
TROUBLESHOOTING
•The fuse blows.
*Are the red and black leads connected correctly?
•Power cannot be turned on.
*Is the yellow lead connected?
•No sound from the speakers.
*Is the speaker output lead short-circuited?
•Sound is distorted.
*Is the speaker output lead grounded?
*Are the “–” terminals of L and R speakers grounded in common?
•Noise interfere with sounds.
*Is the rear ground terminal connected to the car’s chassis using
shorter and thicker cords?
•Unit becomes hot.
*Is the speaker output lead grounded?
*Are the “–” terminals of L and R speakers grounded in common?
InstallKD-AV7008_2[A]5.p65 04.10.5, 3:49 PM4
