KD-SV3204

Installation/Connection Manual

GET0348-002A

[UI]

0106DTSMDTJEIN

This unit is designed to operate on 12 V DC, NEGATIVE ground electrical systems. If your vehicle does not have this system, a voltage inverter is required, which can be purchased at JVC car audio dealers.

WARNINGS

• DO NOT install any unit in locations here;

– it may obstruct the steering heel and gearshift lever operations.

– it may obstruct the operation of safety devices such as air bags.

– it may obstruct visibility.

• DO NOT operate the unit hile driving.

• If you need to operate the unit hile driving, be sure to look ahead carefully.

• The driver must not atch the monitor hile driving.

If the parking brake is not engaged, “PARKING” flashes on the display, and no playback picture ill be sho n on the monitor.

– This arning appears only hen the parking brake ire is connected to the parking brake system built in the car.

PRECAUTIONS on po er supply and speaker connections:

• DO NOT connect the speaker leads of the po er cord to the car battery; other ise, the unit ill be seriously damaged.

• EFORE connecting the speaker leads of the power cord to the speakers, check the speaker wiring in your car.

To prevent short circuits, we recommend that you disconnect the battery’s negative terminal and make all electrical connections before installing the unit.

• Be sure to ground this unit to the car’s chassis again after installation.

Notes:

• Replace the fuse with one of the specified rating. If the fuse blows frequently, consult your JVC car audio dealer.

• It is recommended to connect to the speakers with maximum power of more than 50 W (both at the rear and at the front, with an impedance of 4 Ω to 8 Ω). If the maximum power is less than 50 W, change

“AMP GAIN” setting to prevent the speakers from being damaged (see page 16 of the INSTRUCTIONS).

• To prevent short-circuit, cover the terminals of the UNUSED leads with insulating tape.

• The heat sink becomes very hot after use. e careful not to touch it when removing this unit.

Heat sink

Rubber cushion

Crimp connector

Washer (ø5)

Lock nut (M5)

Mounting bolt (M5 × 20 mm)

Parts list for installation and connection

The following parts are provided for this unit. If any item is missing, consult your JVC car audio dealer immediately.

Handles

Remote controller

attery

A / B

Hard case/Control panel

Sleeve

Trim plate

Power cord

Instal1-2_SV3204_002A_f.indd 1Instal1-2_SV3204_002A_f.indd 1 2/7/06 11:35:53 AM2/7/06 11:35:53 AM

Do the required electrical connections.

*1 When you stand the unit,

be careful not to damage the

fuse on the rear.

end the appropriate tabs to hold the

sleeve firmly in place.

INSTALLATION (IN-DASH MOUNTING)

The following illustration shows a typical installation. If you have any questions or require information regarding installation kits, consult your JVC car audio dealers or a company supplying kits.

• If you are not sure how to install this unit correctly, have it installed by a qualified technician.

Removing the unit

efore removing the unit, release the rear section.

Insert the two handles, then pull them as

illustrated so that the unit can be removed.

When installing the unit ithout using the sleeve

In a Toyota car for example, first remove the car radio and install the unit in its place.

When using the optional stay

Note : When installing the unit on the mounting bracket, make sure to use the 8 mm-long screws. If longer screws are

used, they could damage the unit.

*2 Not supplied for this unit.

Screw (option)

Stay (option)

Fire wall

Dashboard

Install the unit at an angle of less than 30˚.

TROUBLESHOOTING

• The fuse blo s.

* Are the red and black leads connected correctly?

• Po er cannot be turned on.

* Is the yellow lead connected?

• No sound from the speakers.

* Is the speaker output lead short-circuited?

• Sound is distorted.

* Is the speaker output lead grounded?

* Are the “–” terminals of L and R speakers grounded in common?

• Noise interfere ith sounds.

* Is the rear ground terminal connected to the car’s chassis using shorter and thicker cords?

• This unit becomes hot.

* Is the speaker output lead grounded?

* Are the “–” terminals of L and R speakers grounded in common?

• This unit does not ork at all.

* Have you reset your unit?

racket*2

Flat type screws (M5 × 8 mm)*2

Pocket

Flat type screws (M5 × 8 mm)*2

racket*2

Instal1-2_SV3204_002A_f.indd 2Instal1-2_SV3204_002A_f.indd 2 2/7/06 11:35:58 AM2/7/06 11:35:58 AM

Connecting the parking brake wire

When installing the monitor in a location where it can be seen by the driver

Connect the parking brake wire to the parking brake system built in the car.

When installing the monitor in a location where it cannot be seen by

the driver

Connect the parking brake wire to metallic body or chassis of the car.

Connecting the crimp connector

Parking brake wire (light green)

To metallic body or chassis of the car

Parking brake switch (inside the car)

Parking brake

Parking brake wire (light green)

To external components (see diagram )

Light green

VIDEO OUT (see diagram )

To parking brake, metallic body or chassis of the car

Before connecting: Check the wiring in the ehicle carefully. Incorrect connection may cause serious damage to this unit.

The leads of the power cord and those of the connector from the car body may be different in color.

1 Connect the colored leads of the power cord in the order specified in the illustration below.

2 Connect the antenna cord.

3 Finally connect the wiring harness to the unit.

15 A fuse

Black

Blue with white stripe

Red

Yellow *2

To metallic body or chassis of the car

Ignition switch

Fuse block

To an accessory terminal in the fuse block

To the remote lead of other equipment (200 mA max.)

To a li e terminal in the fuse block connecting to the car battery

(bypassing the ignition switch) (constant 12 V)

*1 Not supplied for this unit.

Line out (see diagram )

Rear ground

terminal

*2 Before checking the operation of this unit prior to

installation, this lead must be connected, otherwise

power cannot be turned on.

Left speaker (front) Right speaker (front) Left speaker (rear) Right speaker (rear)

PurplePurple with black stripeGreenGreen with black stripeGrayGray with black stripeWhiteWhite with black stripe

Wire connecting the battery and the parking brake switch.

Attach the parking brake wire to this point.

Blue

To the automatic antenna if any (250 mA max.)

Typical connections

ELECTRICAL CONNECTIONS

LINE IN (see diagram )

Antenna terminal

Brown

To cellular phone system

Contact the metallic part of the crimp to the wires inside.

Pinch the crimp firmly.

Instal3-4_SV3204_002A_f.indd 4Instal3-4_SV3204_002A_f.indd 4 2/7/06 11:35:14 AM2/7/06 11:35:14 AM

AV1-IN

AV2-INPUT

Other external component

CAUTION

Before connecting the external components, make sure that the unit is turned off.

Connecting the external components

JVC CD changer

External component

3.5 mm stereo mini plug

*8 AUX Input Adapter KS-U58 (not supplied for this

unit)

• Set “EXT IN” for the external input setting (See page 6 of the INSTRUCTIONS.)

• Set “CHANGER” for the external input setting (See page 6 of the INSTRUCTIONS.)

*5 iPod is a trademark of Apple

Computer, Inc., registered in the

U.S. and other countries.

CD changer Apple iPod® or JVC D. player

CD changer

jack

External component

Connecting the external amplifier

You can connect an amplifier to upgrade your car stereo system.

• Connect the remote lead (blue with white stripe) to the remote lead of the other equipment so that it can be controlled through this unit.

• Disconnect the speakers from this unit connect them to the amplifier. Leave the speaker leads of this unit unused.

Rear speakers

JVC Amplifier

Remote lead Y-connector (not supplied for this unit)

Remote lead (Blue with white stripe) To the remote lead of other equipment or automatic antenna if any

Front speakers

*3 Firmly attach the ground wire to the metallic body or to

the chassis of the car—to the place uncoated with paint (if

coated with paint, remo e the paint before attaching the

wire). Failure to do so may cause damage to the unit.

Connecting the monitor

KV-MR9010

9-INCH WIDESCREEN MONITOR

(not supplied)

Apple iPod

(separately purchased)

JVC D. player

(separately purchased)

CD changer jack

Signal cord (not supplied for this unit)

You can connect these components as illustrated below. The iPod*5 or D. player can be connected using an interface adapter (not supplied)—KS-PD100 (for iPod) or KS-PD500 (for D. player).

Video cord (not supplied)

Rear side

VIDEO OUT

External component

*7 Line Input Adapter KS-U57 (not supplied for

this unit)

*6 Connecting cord supplied for

your CD changer

Before connecting the monitor, make sure the unit is turned off.
