JVC KW-V250BTM User manual

KW-V250BT (Region 3 – DVD Region Code 3 Area)
KW-V250BT (Region 4 – DVD Region Code 4 Area)
KW-V250BTM (Region 2 – DVD Region Code 2 Area)
MONITOR WITH DVD RECEIVER
INSTRUCTION MANUAL
This instruction manual is used to describe models listed above. Model availability and features (functions)
may differ depending on the country and sales area. B5A-2615-10 (M/M2/X)
ENGLISH
01_KWV_2019ST_MM2X_COVER.indd 101_KWV_2019ST_MM2X_COVER.indd 1 30/4/2021 4:29:20 PM30/4/2021 4:29:20 PM

ENGLISHi
Important NoticeImportant Notice
To ensure proper use, please read through this
manual before using this product. It is especially
important that you read and observe WARNINGS
and CAUTIONS in this manual.
Please keep the manual in a safe and accessible
place for future reference.
WARNINGS
To prevent accidents and damages
• DO NOT install any unit or wire any cable in a
location where;
–it may obstruct the steering wheel and gearshift
lever operations.
–it may obstruct the operation of safety devices such
as air bags.
–it may obstruct visibility.
• DO NOT raise the volume level too much, as this will
make driving dangerous by blocking outside sounds,
and may cause hearing loss.
• DO NOT operate the unit while driving. If you need
to operate the unit while driving, be sure to look
around carefully.
• Stop the car before performing any complicated
operations.
• The driver must not watch the monitor while driving.
CAUTIONS
To care for the unit
• If you have parked the car for a long time in hot or
cold weather, wait until the temperature in the car
becomes normal before operating the unit.
To care for the monitor
• The monitor built into this unit has been produced
with high precision, but it may have some ineffective
dots. This is inevitable and is not considered
defective.
• Do not expose the monitor to direct sunlight.
• Do not operate the touch panel using a ball-point
pen or similar tool with a sharp tip.
Touch the keys on the touch panel with your finger
directly (if you are wearing a glove, take it off).
• When the temperature is very cold or very hot...
–Chemical changes occur inside, causing
malfunction.
–Pictures may not appear clearly or may move
slowly. Pictures may not be synchronized with
the sound or picture quality may decline in such
environments.
On the volume setting
• Digital devices produce very little noise compared
with other sources. Lower the volume before playing
these digital sources to avoid damaging the speakers
by sudden increase of the output level.
The marking of products using lasers
The label is attached to the chassis/case and says
that the component uses laser beams that have been
classified as Class 1. It means that the unit is utilizing
laser beams that are of a weaker class. There is no
danger of hazardous radiation outside the unit.
00_KWV_2019ST_MM2X_EN.indb i00_KWV_2019ST_MM2X_EN.indb i 1/6/2018 12:07:01 PM1/6/2018 12:07:01 PM

ENGLISH ii
Important NoticeImportant Notice
For KW-V250BTM Region 2:
For Turkey
Bu ürün 28300 sayılı Resmi Gazete’de yayımlanan Atik
Elektrikli ve Elektronik Eşyalarin Kontrolü Yönetmeliğe
uygun olarak üretilmiştir.
Eski Elektrik ve Elektronik Ekipmanların İmha
Edilmesi Hakkında Bilgi (ayrı atık toplama
sistemlerini kullanan ülkeleri için uygulanabilir)
Sembollü (üzerinde çarpı işareti olan çöp
kutusu) ürünler ev atıkları olarak atılamaz.
Eski elektrik ve elektronik ekipmanlar,
bu ürünleri ve ürün atıklarını
geri dönüştürebilecek bir tesiste
değerlendirilmelidir. Yaşadığınız bölgeye
en yakın geri dönüşüm tesisinin yerini
öğrenmek için yerel makamlara müracaat
edin. Uygun geri dönüşüm ve atık
imha yöntemi sağlığımız ve çevremiz
üzerindeki zararlı etkileri önlerken
kaynakların korunmasına da yardımcı
olacaktır.
For KW-V250BTM Region 2:
Declaration of Conformity with regard to the RE
Directive 2014/53/EU
Declaration of Conformity with regard to the RoHS
Directive 2011/65/EU
Manufacturer:
JVC KENWOOD Corporation
3-12, Moriya-cho, Kanagawa-ku, Yokohama-shi,
Kanagawa, 221-0022, Japan
EU Representative:
JVCKENWOOD Europe B.V.
Amsterdamseweg 37, 1422 AC UITHOORN,
THE NETHERLANDS
English
Hereby, JVCKENWOOD declares that the radio
equipment “KW-V250BTM” is in compliance with
Directive 2014/53/EU.
The full text of the EU declaration of conformity is
available at the following internet address:
http://www.jvc.net/cs/car/eudoc/
RE 2014/53/EU Direktifi uyarınca Uygunluk Beyanı
RoHS Yönergesi 2011/65/EU’ya göre Uygunluk
Bildirimi
Üretici:
JVC KENWOOD Corporation
3-12, Moriya-cho, Kanagawa-ku, Yokohama-shi,
Kanagawa, 221-0022, Japan
AB Temsilcisi:
JVCKENWOOD Europe B.V.
Amsterdamseweg 37, 1422 AC UITHOORN,
THE NETHERLANDS
Turkish
Burada, JVCKENWOOD “KW-V250BTM” radyo
ekipmanının 2014/53/AB Direktifine uygun olduğunu
bildirir.
AB uyumluluk deklarasyonunun tam metni aşağıdaki
internet adresinde mevcuttur.
http://www.jvc.net/cs/car/eudoc/
00_KWV_2019ST_MM2X_EN.indb ii00_KWV_2019ST_MM2X_EN.indb ii 1/6/2018 12:07:01 PM1/6/2018 12:07:01 PM

About this manual
The displays and panels shown in this manual are
examples used to provide clear explanations of the
operations. For this reason, they may be different
from the actual displays or panels.
Illustrations of KW-V250BT are mainly used for
explanation.
The region code of a particular model will only
be stated if only one of the regions supports the
particular feature with the same model name.
This manual mainly explains operations using the
buttons on the monitor panel and keys on the
touch panel. For operations using the remote
controller, see page 36.
< > indicates the various screens/menus/
operations/settings that appear on the touch
panel.
[ ] indicates the keys on the touch panel.
Indication language: English indications are used
for the purpose of explanation. You can select the
indication language from the <Settings> menu.
(Page 27)
ContentsContents
Component Names and Operations...............3
Basic Operations.................................................3
How to reset your unit ..........................................................3
Turning on the power ...........................................................3
Turning off the power............................................................3
Turning off the AV source....................................................3
Turning off the screen and button illumination ...4
Adjusting the volume............................................................4
Getting Started ...................................................4
Initial settings..............................................................................4
Clock settings..............................................................................5
Various Screens and Operations .....................5
Home screen ...............................................................................5
Source control screen............................................................6
List/setting screen....................................................................8
Disc........................................................................8
Video...................................................................10
USB......................................................................12
Android...............................................................13
iPod/iPhone.......................................................14
Tuner...................................................................15
Spotify ................................................................18
Other External Components ..........................20
AV-IN..............................................................................................20
Rear view camera...................................................................20
Using an external navigation unit...............................21
Bluetooth® .........................................................21
Information................................................................................21
Preparation ................................................................................21
Connection................................................................................21
Bluetooth mobile phone ..................................................23
Bluetooth audio player.......................................................25
Bluetooth settings.................................................................26
Settings ..............................................................27
Audio settings..........................................................................27
Display settings.......................................................................30
Input settings...........................................................................32
System settings.......................................................................33
Key settings ...............................................................................36
Remote Controller............................................36
Preparation ................................................................................37
Basic operations......................................................................37
Searching for an item directly........................................38
JVC Remote APP........................................................... 38
Installation and Connection...........................38
Before installation..................................................................38
Installing the unit...................................................................40
Connecting external components .............................40
Wiring connection ................................................................41
References .........................................................42
Maintenance.............................................................................42
More information...................................................................42
Troubleshooting...............................................45
Specifications....................................................48
Trademarks and licenses...................................................50
2ENGLISH
00_KWV_2019ST_MM2X_EN.indb 200_KWV_2019ST_MM2X_EN.indb 2 1/6/2018 12:07:01 PM1/6/2018 12:07:01 PM

Component Names and OperationsComponent Names and Operations
1Reset button
2Loading slot
3Screen (touch panel)
4Built-in microphone*
• You can also connect an external microphone to
the unit (page 40). For details, contact the store
where you purchase this unit.
• See also <MIC SETUP> on page 26.
5Monitor panel
6Illumination bar
The brightness of the illumination changes
according to the music level. (Page 31)
7Volume +/–buttons
8FNC-button
• FNC (Press, blink once): Pops up the short-cut
menu. (Page 7)
• (Hold, blink twice): Enters favorite setting.
Default: Displays <Sound Effect> screen.
(Page28)
Basic OperationsBasic Operations
How to reset your unit
If the unit fails to operate properly, press the reset
button.
Turning on the power
Turning off the power
Turning off the AV source
1 Display the source/option selection
screen.
On the Home screen, touch as follows:
9-button
• (Press): Turns on the power.
• (Press): Displays the Home screen while the
power is on.
• (Hold): Activates the voice dialing.
pUSB input terminal
* Only for KW-V250BT Region 3.
3ENGLISH
03_KWV_2019ST_MM2X_Body01.indd 303_KWV_2019ST_MM2X_Body01.indd 3 18/6/2018 11:35:31 AM18/6/2018 11:35:31 AM

Initial settings
When you power on the unit for the first time or reset
the unit, the <Initial Settings> screen appears.
Perform the initial settings.
Once completed, the Home screen appears.
<Demonstration>
• ON (Initial): Activates the display demonstration.
• OFF: Deactivates the display demonstration.
Getting StartedGetting Started
<Language>
Select the text language used for on-screen
information.
• English (Initial)/Español/Français/Deutsch/
Italiano/Nederlands/Ελληνικά/Português/Türkçe/
Čeština/Polski/Magyar/Руccĸий/ / /
/ / / /Bahasa
Malaysia/Bahasa Indonesia/
–For external monitors, only English/Spanish/
French/German/Italian/Dutch/Russian/Portuguese
are available. If another language has been
selected, the text language for external monitors
will be set to English.
• GUI Language (Local (the language selected above)
(Initial)/English): Selects the language used for
displaying operation keys and menu items.
<Rear Camera> (Page 32)
Make the settings to display the picture from the
connected rear view camera.
<User Customize> (Page 30)
Change the display design.
<Viewing Angle> (Page 32)
Select the viewing angle in relation to the monitor to
make the image on the screen easier to see.
• Under 0° (Initial)/5°/10°/15°/20°
2 Turn off the AV source.
On the source/option selection screen, touch as
follows:
Turning off the screen and button
illumination
1 Display the pop-up short-cut menu.
2 On the pop-up short-cut menu, touch as
follows:
(Hold)
To turn on the screen and button illumination:
Press FNC on the monitor panel or touch the screen.
Adjusting the volume
You can adjust the volume (00 to
35) by pressing +to increase and
pressing –to decrease.
• Holding +increases the volume
continuously to level 15.
Basic OperationsBasic Operations
4ENGLISH
03_KWV_2019ST_MM2X_Body01.indd 403_KWV_2019ST_MM2X_Body01.indd 4 28/6/2018 3:04:41 PM28/6/2018 3:04:41 PM

Getting StartedGetting Started
Clock settings
1 Display the Home screen.
2 Display the <Clock> screen.
On the Home screen, touch as follows:
Then, on the <Settings> screen, touch as follows:
[System] <Clock> : [Enter]
• You can also display the <Clock> screen by
touching the clock area on the Home screen.
3 Set the clock time.
<Synchronize>
• Radio Data System (Initial): Synchronizes the
clock time with FM Radio Data System.
• Off: Sets the clock manually. Touch [J]/[K]to
adjust the hour, then minute.
–Touching [Reset] will set the minute to “00”.
Various Screens andVarious Screens and
OperationsOperations
You can display or change to other screens at any time
to show information, change the AV source, change
the settings, etc.
Home screen
• You can customize the Home screen. (Page 32)
• To display the Home screen from other screens, press
-.
Touching the operation keys performs the following
actions:
1Selects or changes the playback source.
2Displays all playback sources and options.
3Displays the <Settings> screen.
4Displays the <Clock> screen.
5Displays the current playing source control screen.
6Displays the phone control screen.
5
ENGLISH
03_KWV_2019ST_MM2X_Body01.indd 503_KWV_2019ST_MM2X_Body01.indd 5 28/6/2018 3:04:59 PM28/6/2018 3:04:59 PM

Available playback sources and options
Touch 2to display the source/option selection screen.
E.g. Source/option selection screen for KW-V250BT
Region 3
Touching the operation keys performs the following
actions:
[Tuner] Switches to the radio broadcast.
[Disc] Plays a disc.
[USB] Plays files on a USB device.
[iPod] Plays an iPod/iPhone.
[Android™] Plays an Android device.
[AV-IN] Switches to an external component
connected to the AV-IN input
terminal.
[BT Audio] Plays a Bluetooth audio player.
[Spotify] Switches to the Spotify application.
[NAV]* Displays the navigation screen.
[AV Off] Turns off the AV source.
Various Screens and OperationsVarious Screens and Operations
E.g. Common audio playback source screen:
1Playback source or media type
2Picture/artwork (shown if the file contains the
information)
3Track/file/song/video information
• Touching [H]scrolls the text if not all of the text
is shown.
4Clock display
5Current playback item information
(folder no./file no./track no./total track no./playback
file type)
6Displays/hides other available operation keys*
7Operation keys*
8IN indicator (lights up while a disc is inserted)
9Playing time/playback status
pPlayback mode indicator (Repeat/Random)
qFile type indicator
* See “Common operation keys on source control screen” on page
7.
[Home] Displays the Home screen.
[Setup] Displays the <Settings> screen.
[ Power Off] Turns off the power.
[Camera] Switches to the camera connected
to the rear view camera input.
[Now Playing] Displays the source currently
played back.
* Only for KW-V250BT Region 3/KW-V250BTM Region 2:
Selectable only when <Input> is set to [RGB] in <Navigation>
screen (page 33).
To return to the Home screen
Touch [HOME] on the source/option selection screen.
Source control screen
You can perform the playback operation from the
source control screen during playback.
• The operation keys and information displayed vary
depending on the selected source/disc type/file type
being played.
• If the operation keys are not displayed on the screen,
touch the screen to show them.
6ENGLISH
03_KWV_2019ST_MM2X_Body01.indd 603_KWV_2019ST_MM2X_Body01.indd 6 18/6/2018 11:35:39 AM18/6/2018 11:35:39 AM

Various Screens and OperationsVarious Screens and Operations
* About playback mode:
–Available playback modes differ depending on the source, disc
type, connected device, etc.
–You cannot activate repeat playback mode and random
playback mode at the same time.
–To cancel the playback mode, touch repeatedly until the
indicator disappears.
Using gesture control
You can also control playback by moving your finger
on the touch panel as follows (for some sources, the
gesture control is not available).
• Sliding the finger up/down:
Selects a folder.
• Sliding the finger left/right:
Selects an item (chapter/track/audio file/video file).
• Moving your finger clockwise/counterclockwise:
Increases/decreases the volume.
Common operation keys on source control screen
• The appearance of the operation keys may differ,
however the similar operation keys have the same
operations.
• Available operation keys differ depending on the
selected source or connected device.
Touching the operation keys performs the following
actions:
6
[I] Displays other available operation keys
besides those shown on 7.
• To hide the window, touch [H].
[ ][ ] Selects a folder.
[ ] Selects repeat playback mode.*
[o]Stops playback.
[MODE] Displays the setting screen of the current
playback source.
7
[ ] Displays the <Equalizer> screen.
(Page27)
[ ] Displays the folder list/track list/audio
menu/video menu.
[S]/[T]• (Touch) Selects an item (chapter/
folder/track/audio file/video file).
• (Hold) Reverses/forwards search.
• (Hold) Plays in slow-motion while
paused for video playback.
[IW]Starts/pauses playback.
[ ] Selects random playback mode.*
Using the pop-up short-cut menu
While displaying the source control screen, you can
jump to another screen by touching the operation
keys on the pop-up short-cut menu.
1 Display the pop-up short-cut menu.
2 Select an item to jump to by touching as
follows.
[M] Ejects the disc from loading slot.
[ - ] • (Touch) Switches the screen.
• (Hold) Turns off the screen.
[ ]* Displays the <Settings> screen.
(Page 27)
[ ]* Displays the <User Customize>
screen and you can change the
background design. (Page 30)
[ ]* Displays the <Screen
Adjustment> screen. (Page 32)
[ ]* Displays the picture from the
connected rear view camera.
* You can customize these pop-up short-cut menu. For details, see
<Key Customize> on page 36.
To close the pop-up menu
Press FNC on the monitor panel.
7
ENGLISH
03_KWV_2019ST_MM2X_Body01.indd 703_KWV_2019ST_MM2X_Body01.indd 7 28/6/2018 3:05:30 PM28/6/2018 3:05:30 PM

Various Screens and OperationsVarious Screens and Operations
Using touch screen operation during
playback
Touching the areas performs the following actions:
1Displays the video control menu while playing a
video.
2While playing a video: Displays the source control
screen.
While playing an audio file: Displays the playback
operation keys.
3Goes to the previous chapter/track.*
4Goes to the next chapter/track.*
* Not available for video from an external component (AV-IN).
List/setting screen
Below are the common operation keys which appear
on the list/setting screen.
• The appearance of the operation keys may differ,
however the similar operation keys have the same
operations.
• Available operation keys differ depending on the
setting screens. Not all these operation keys are
shown on every screen.
Touching the operation keys performs the following
actions:
1Enters alphabet search* to list the items in
alphabetical order. When a keypad appears, touch
the first letter you want to search for.
• For “USB” source, you can switch between the
folder list and file list by touching [ ] or [ ].
Then, touch [OK] to start searching.
2Returns to the root folder.
3Returns to the upper layer.
4Closes the current screen.
5Exits from the current screen or returns to the
previous screen.
6Changes the page to display more items.
* Alphabet search is not available:
–For Android source
–When the playlist is selected
DiscDisc
• If a disc does not have a disc menu, all tracks on it will
be played repeatedly until you change the source or
eject the disc.
• For playable disc types, file types and other
information, see pages42 and 43.
• If “ ” appears on the screen, the unit cannot accept
the operation you have tried to do.
–In some cases, without showing “ ”, operations
will not be accepted.
• When playing back a multi-channel encoded disc,
the multi-channel signals are downmixed.
Inserting a disc
Label side up
The source changes to “DISC” and playback starts.
• The IN indicator lights up while a disc is inserted.
8ENGLISH
03_KWV_2019ST_MM2X_Body01.indd 803_KWV_2019ST_MM2X_Body01.indd 8 28/6/2018 3:05:56 PM28/6/2018 3:05:56 PM

DiscDisc
Selecting a folder/track on the list
1 Display the folder/track list.
On the source control screen, touch as follows:
2 Select the folder (1), then the item (2) in
the selected folder.
Select an item in each layer until you reach and
select the desired file.
Settings for disc playback
• Available items shown on the <DISC Mode> screen
differ depending on the type of disc/file being
played back.
1 Display the <DISC Mode> screen.
On the source control screen, touch as follows:
Ejecting a disc
Display the pop-up short-cut menu, then
eject the disc.
• When removing a disc, pull it out horizontally.
• You can eject a disc while playing another AV source.
• If the ejected disc is not removed within 15 seconds,
the disc is automatically inserted again into the
loading slot to protect it from dust.
Playback operations
Audio playback information and key
operation
• For playback information, see “Source control screen”
on page6.
• For key operations on the touch panel, see “Common
operation keys on source control screen” on
page7.
2 Make the settings.
<Menu Language>*1
Select the initial disc menu language. (Initial:
English)
<Subtitle Language>*1
Select the initial subtitle language or turn subtitles
off (Off). (Initial: English)
<Audio Language>*1
Select the initial audio language. (Initial: English)
<Dynamic Range Control>
You can change the dynamic range while playing
Dolby Audio encoded discs.
• Wide: Reproduces powerful sound at a low
volume level with its full dynamic range.
• Normal: Reduces the dynamic range a little.
• Dialog (Initial): Reproduces movie dialog more
clearly.
9
ENGLISH
00_KWV_2019ST_MM2X_EN.indb 900_KWV_2019ST_MM2X_EN.indb 9 1/6/2018 12:07:03 PM1/6/2018 12:07:03 PM

DiscDisc
<Down Mix>
When playing back a multi-channel disc, this
setting affects the signals reproduced through the
front and/or rear speakers.
• Dolby Surround: Reproduces multi-channel
surround sound by connecting an amplifier
compatible with Dolby Surround.
• Stereo (Initial): Reproduces stereo playback
sound.
<Screen Ratio>
Select the monitor type to watch a wide screen
picture on the external monitor.
16:9 (Initial) 4:3 LB 4:3 PS
<File Type>*2
Select the playback file type when a disc contains
different types of files.
• Audio: Plays back audio files.
• Still image: Plays back still picture files.
• Video: Plays back video files.
• Audio&Video (Initial): Plays back audio files and
video files.
*1 For list of language codes, see page43.
*2 For playable file types, see page42.
If the disc contains no files of the selected type, the existing
files are played in the following priority: audio, video, then still
picture. You can change these settings only while playback is
stopped.
VideoVideo
Playback operations
Video playback information on the source
control screen
E.g. Video playback source control screen
1Media type
2Playback status
3Current playback item information
(title no./chapter no./folder no./file no./track no.)
4Playing time
5IN indicator (lights up while a disc is inserted)
6Playback mode indicator (Repeat/Random)
7File type indicator
Video menu control operations
You can display the video menu control during video
playback.
• Available operation keys differ depending on the
selected disc type and file type.
Video playback except VCD
E.g. Video menu control screen
Touching the operation keys performs the following
actions:
1
[ ]*1 Displays the picture size selection
screen.
1Touch [ Zoom] to change the
magnification level of the picture
(Zoom1, Zoom2, Zoom3, Full:
Initial).
2Touch [J] [K] [H] [I]to move the
zooming frame.
10 ENGLISH
03_KWV_2019ST_MM2X_Body01.indd 1003_KWV_2019ST_MM2X_Body01.indd 10 8/6/2018 12:06:51 PM8/6/2018 12:06:51 PM

VideoVideo
[ ] Displays the aspect ratio selection
screen.
Touch [ Aspect] to select the aspect
ratio.
<Full>*2: For 16:9 original pictures
4:3 signal 16:9 signal
<Just>: For viewing 4:3 pictures
naturally on the wide screen
4:3 signal 16:9 signal
<Normal>*2: For 4:3 original pictures
4:3 signal 16:9 signal
<Auto>: For “DISC” source and
“USB” source only: The aspect ratio is
automatically selected to match the
incoming signals.
[ ] Displays the picture adjustment screen.
1Touch [DIM ON] or [DIM OFF] to
turn on or off the dimmer.
2Touch [+]/[–] to adjust the other
items.
• <Bright>: Adjusts the brightness
(−15 to +15).
• <Contrast>: Adjusts the contrast
(−10 to +10).
• <Black>: Adjusts the blackness
(−10 to +10).
• <Color>: Adjusts the color
(−10 to +10).
• <Tint>: Adjusts the tint (−10 to +10).
• <Sharpness>: Adjusts the sharpness
(−2 to +2).
[ ] Selects the audio type.
[ ] Selects the subtitle type.
[ ] Selects the view angle.
*1 When [ ] is set to <Just> or <Auto>, the picture is
zoomed with the aspect ratio of the <Full> setting.
This feature may not be used for some video sources.
*2 While DivX is played back with <Screen Ratio> set to [16:9]
(Page10 for discs/Page13 for USB), the aspect ratio may
not be set correctly.
2
[ MENU] Displays the disc menu (DVD).
[T MENU] Displays the disc menu (DVD).
[ ] Switches to the direct disc menu mode.
Touch the target item to select.
[ ] Displays the menu/scene selection
screen.
• [J] [K] [H] [I]: Selects an item.
• [Enter]: Confirms the selection.
• [Return]: Returns to the previous
screen.
Video playback for VCD
E.g. Video menu control screen
11
ENGLISH
00_KWV_2019ST_MM2X_EN.indb 1100_KWV_2019ST_MM2X_EN.indb 11 1/6/2018 12:07:03 PM1/6/2018 12:07:03 PM

VideoVideo USBUSB
You can connect a USB mass storage class device such
as a USB memory, digital audio player, etc. to the unit.
• For playable file types and other information, see
pages42 and44.
• You cannot connect a PC or portable HDD to the
USB input terminal.
• You cannot connect a USB device via a USB hub.
Connecting a USB device
On the monitor panel
USB device
(commercially available)
The source changes to “USB” and playback starts.
• All tracks in the USB device will be played repeatedly
until you change the source or disconnect the USB
device.
Touching the operation keys performs the following
actions:
1
[ ]
Refer to “Video playback except VCD” on
page10.
[ ]
[ ]
2
[ MENU] Displays the disc menu.
[ ] Selects the audio channel
(ST: stereo, L: left, R: right).
[ ]*Displays or hides the direct selection
keys.
1Touch [DIR/CLR] to select a track
directly on a VCD.
2Touch the numbers ([0], [1] to [9]) to
select the desired track.
3Touch [Enter] to confirm.
To delete the last entry, touch [DIR/
CLR].
[Return] Displays the previous screen or menu.
* You need to stop playback to deactivate the PBC function when
playing a VCD with PBC activated.
Playback operations
Playback information and key operation
• For playback information, see “Source control screen”
on page6.
• For key operations on the touch panel, see “Common
operation keys on source control screen” on
page7.
Selecting the file type to play
You can specify the file type to play.
E.g. USB source control screen
Select the file type as follows:
[Audio] Plays back audio files.
[Video] Plays back video files.
[Photo] Plays back still picture files.
If the USB device contains no files of the selected type,
the existing files are played in the following priority:
audio, video, then still picture. You can change these
settings only while playback is stopped.
12 ENGLISH
03_KWV_2019ST_MM2X_Body01.indd 1203_KWV_2019ST_MM2X_Body01.indd 12 28/6/2018 3:06:16 PM28/6/2018 3:06:16 PM

USBUSB
Selecting a folder/track on the list
1 Display the folder/track list.
On the source control screen, touch as follows:
2 Select the folder (1), then the item (2) in
the selected folder.
E.g. USB list screen
Select an item in each layer until you reach and
select the desired file.
Selecting a folder/track using alphabet
search
(Applicable only for audio file type)
You can search for a folder or an audio file by entering
the first letter you want to search for.
1 Select the list (folder or track) to search.
On the USB list screen, touch as follows:
• [ ]: Folder list
• [ ]: Track list
2 Enter the alphabet to search.
Touch the first letter you want to search for, then
touch [OK].
Settings for USB playback
1 Display the <USB Mode> screen.
On the source control screen, touch as follows:
2 Make the settings.
<Screen Ratio>
Select the monitor type to watch a wide screen
picture on the external monitor.
16:9 (Initial) 4:3 LB 4:3 PS
<Drive Select>
• Next: Switch between internal memory and the
memory source of the connected device (such as
a mobile phone).
AndroidAndroid
Connecting an Android device
This unit supports Android OS 4.1 and above.
Android
(commercially available)
USB cable
(commercially available)
On the monitor panel
When connecting an Android device, “AUDIO MODE” is
shown. You can control Android device using a media
player application installed in the Android device.
13
ENGLISH
00_KWV_2019ST_MM2X_EN.indb 1300_KWV_2019ST_MM2X_EN.indb 13 1/6/2018 12:07:03 PM1/6/2018 12:07:03 PM

iPod/iPhoneiPod/iPhone
Connecting an iPod/iPhone
• For playable iPod/iPhone types and other
information, see page 44.
• You cannot watch video.
Wired connection
iPod/iPhone
Lightning model
(commercially available)
iPod/iPhone 30-pin
connector model
(commercially available)
On the
monitor panel
USB Audio cable
for iPod/iPhone:
KS-U62 (optional
accessory)
30-pin to USB cable
(accessory of iPod/
iPhone)
The source changes to “iPod” and playback starts.
Bluetooth connection
Pair the iPod/iPhone with this unit via Bluetooth.
(Page21)
Selecting the playback device via the
connection method
See <Smartphone Setup> on page 33 for more
information.
Playback operations
Playback information and key operation
• For playback information, see “Source control screen”
on page6.
• For key operations on the touch panel, see “Common
operation keys on source control screen” on
page7.
Additional keys operations: Touching the operation
keys performs the following actions.
[ ] Switches the device on the
<Smartphone Setup> screen.
(Page33)
Selecting an audio file from the menu
1 Display the audio menu.
On the source control screen, touch as follows:
Playback operations
Playback information and key operation
AUDIO MODE
Android
IWST
E.g. Android source control screen
Touching the operation keys performs the following
actions:
[S]/[T]Selects an audio file.
[IW]Starts/pauses playback.
AndroidAndroid
14 ENGLISH
03_KWV_2019ST_MM2X_Body01.indd 1403_KWV_2019ST_MM2X_Body01.indd 14 28/6/2018 3:06:38 PM28/6/2018 3:06:38 PM

iPod/iPhoneiPod/iPhone
2 Select a category (1), then select a
desired item (2).
Select an item in each layer until you reach and
select the desired file.
• Available categories differ depending on the type
of iPod/iPhone.
Settings for iPod/iPhone playback
1 Display the <iPod Mode> screen.
On the source control screen, touch as follows:
2 Make the settings.
<Artwork>
• ON (Initial): Shows the artworks of the playing
files.
• OFF: Hides the artworks of the playing files.
Listening to the radio
The unit switches to FM alarm scene automatically
when receiving an alarm signal from FM broadcast.
Playback information on the source control
screen
1Selects the band (AM/FM1/FM2/FM3)
2Text information
• Touching [H]scrolls the text if not all of the text
is shown.
• Touching [Radio Text] switches the information
between Radio Text, Radio Text Plus and PTY
code.
3Current station frequency
4Displays the preset stations window (Page17)
• To hide the window, touch [I].
5[P1] – [P5]
• (Touch) Selects a preset station.
• (Hold) Presets the current station.
TunerTuner
6Displays/hides other available operation keys*
7NEWS indicator
8AF indicator
9TI indicator
pOperation keys*
qST/MONO indicator
The ST indicator lights up when receiving an FM
stereo broadcast with sufficient signal strength.
wSeek mode indicator
eLO.S indicator
rRDS indicator
tEON indicator
The EON indicator lights up when a Radio Data
System station is sending EON signals.
* See the following “Operation keys on source control screen”.
Operation keys on source control screen
• The appearance of the operation keys may differ,
however the similar operation keys have the same
operations.
• See also “Common operation keys on source control
screen” on page7.
15
ENGLISH
00_KWV_2019ST_MM2X_EN.indb 1500_KWV_2019ST_MM2X_EN.indb 15 1/6/2018 12:07:04 PM1/6/2018 12:07:04 PM

Touching the operation keys performs the following
actions:
6
[SSM ]*1 (Hold) Presets stations automatically.
[MONO]*1 Activates monaural mode for better FM
reception (stereo effect will be lost).
• The MONO indicator lights up while
monaural mode is activated.
• To deactivate, touch [MONO] again.
[TI]*1 (For FM RDS features)
Activates TI standby reception mode.
• When TI is activated, the unit is ready
to switch to traffic information if
available. The TI indicator lights up in
white.
• If the TI indicator lights up in orange,
tune into another station providing
Radio Data System signals.
• The volume adjustment for Traffic
Information is automatically
memorized. The next time the unit
switches to Traffic Information, the
volume is set to the memorized level.
• To deactivate, touch [TI] again.
[MODE]*1 Change the settings for the selected
tuner reception on <Tuner Mode>
screen. (Page 17)
TunerTuner
Presetting stations in the memory
You can preset five stations for each band.
Automatic presetting — SSM (Strong-
station Sequential Memory) (for FM only)
On the source control screen, touch as follows:
(Hold)
The local stations with the strong signals are found and
stored automatically.
Manual presetting
1 Tune in to a station you want to preset.
2 Select a preset number to store into.
(Hold)
E.g. Tuner source control screen
The station selected in step 1 is stored into the
preset number [P1] to [P5] you have selected.
p
[PTY]*1*2 (For FM RDS features)
Enters PTY search mode.
1Touch [PTY].
2Touch and hold a PTY code to search
for.
If there is a station broadcasting a
program of the same PTY code as you
have selected, that station is tuned in.
[SEEK] Changes the seek mode for [S]/[T].
• AUTO1 (Initial): Auto search
• AUTO2: Tunes in preset stations one
after another
• MANU: Manual search
[S]/[T]Searches for a station.
• The search method differs depending
on the selected seek mode (see
above).
*1 Appears only when FM is selected as the source.
*2 Only English/Spanish/French/German/Dutch/ Portuguese are
available for the text language here. If another language has
been selected in <Language> (Page 33), the text language
is set to English.
16 ENGLISH
03_KWV_2019ST_MM2X_Body01.indd 1603_KWV_2019ST_MM2X_Body01.indd 16 28/6/2018 3:07:15 PM28/6/2018 3:07:15 PM

TunerTuner
Selecting a preset station
1 Select the band, then display the preset
station window.
On the source control screen, touch as follows:
2 Select a preset station.
E.g. Preset station window
To hide the window: Touch [ I].
Settings for other FM Radio Data System
features
1 Display the <Tuner Mode> screen.
On the source control screen, touch as follows:
2 Make the settings.
<AF Regional>
When driving in an area where FM reception is not
sufficient enough, this unit automatically tunes in
to another FM Radio Data System station of the
same network, possibly broadcasting the same
program with stronger signals— Network-Tracking
Reception.
Select the Network-Tracking Reception mode.
• AF: Switches to another station. The program
may differ from the one currently received. The
AF indicator lights up.
• AF Reg: Switches to another station broadcasting
the same program. The AF indicator lights up.
• OFF (Initial): Deactivates the function.
The RDS indicator lights up when the Network-
Tracking Reception is activated and an FM Radio
Data System station is found.
<NEWS>*
• 00min to 90min: Activates News Standby
Reception by selecting the period of time to
disable the interruption. The NEWS indicator
lights up.
• OFF (Initial): Deactivates the function.
<Local>
• ON: Tunes in only to FM stations with sufficient
signal strength. The LO.S indicator lights up.
• OFF (Initial): Deactivates the function.
<Auto TP Seek>
• ON (Initial): Automatically searches for a station
with better reception for traffic information if the
current reception of current station is poor.
• OFF: Deactivates the function.
* The volume adjustment for Traffic Information is automatically
memorized. The next time the unit switches to Traffic
Information, the volume is set to the previous level.
17ENGLISH
03_KWV_2019ST_MM2X_Body01.indd 1703_KWV_2019ST_MM2X_Body01.indd 17 22/6/2018 9:30:12 AM22/6/2018 9:30:12 AM

SpotifySpotify
With Spotify, your music is everywhere. Working out,
partying or relaxing, the right music is always at your
fingertips. There are millions of songs on Spotify—from
old favorites to the latest hits. Just choose the music
you love, or let Spotify surprise you.
You can stream Spotify from iPhone/iPod touch or
Android devices.
• Because Spotify is a third-party service, the
specifications are subject to change without
prior notice. Accordingly, compatibility may be
impaired or some or all of the services may become
unavailable.
• Some functions of Spotify cannot be operated from
this unit.
• For issues using the application, contact Spotify at
<www.spotify.com>.
Preparation
Installing the application
Your smartphone must have built in Bluetooth and the
following profiles must be supported:
• SPP (Serial Port Profile)
• A2DP (Advanced Audio Distribution Profile)
Establish an Internet connection using LTE, 3G, EDGE,
or WiFi.
Ensure you are logged in to your smartphone
application. If you do not have an Spotify account, you
can create one for free from your smartphone or at
<www.spotify.com>.
Install the latest version of the Spotify application on
your smartphone.
• For Android devices: Search for “Spotify” in Google
Play to find and install the most recent version.
• For iPhone/iPod touch: Search for “Spotify” in the
Apple iTunes App Store to find and install the most
recent version.
Connecting the device
For Android devices
Pair the Android device with this unit via Bluetooth.
(Page 21)
For iPhone/iPod touch
• Via USB input terminal: Connect iPhone/iPod touch
with the cable. (Page14)
–For Lightning models: Use KS-U62 (optional
accessory).
–For 30-pin connector models: Use 30-pin to USB
cable (accessory of iPod/iPhone).
• Via Bluetooth: Pair the iPhone/iPod touch with this
unit. (Page21)
Selecting the device
For selecting the playback device via the connection
method to use, see <Smartphone Setup> on page
33.
Playback operations
Playback information and key operation
You can also operate Spotify with a remote controller,
RM-RK258*1.
You can only control play, pause and skip with the
remote controller.
1Displays/hides other available operation keys*2
2Picture data
3Track information
• Touching [H]scrolls the text if not all of the text
is shown.
• Touching [ ]/[ ] changes the displayed
information between artist ( ) and album ( ).
4Operation keys*2
5Playing time/playback status
6Progress bar
*1 For KW-V250BT Region 4: Purchase optionally remote
controller, RM-RK258.
*2 See “Operation keys on source control screen” on page 19.
18 ENGLISH
03_KWV_2019ST_MM2X_Body01.indd 1803_KWV_2019ST_MM2X_Body01.indd 18 28/6/2018 3:07:40 PM28/6/2018 3:07:40 PM
