JVC KD-G326 User manual

ENGLISH
INDONESIA
CD RECEIVER KD-G326/KD-G325
ALAT PENERIMA CD KD-G326/KD-G325
For canceling the display demonstration, see page 5.
Untuk membatalkan tampilan demonstrasi, lihat halaman 5.
For installation and connections, refer to the separate manual.
Untuk instalasi dan penyambungan, lihat buku pedoman terpisah.
INSTRUCTIONS
BUKU PETUNJUK
GET0342-004A
[UN]
KD-G326
KD-G325
Cover_KD-G326_5_004A_f.indd 2Cover_KD-G326_5_004A_f.indd 2 10/14/05 4:12:34 PM10/14/05 4:12:34 PM

ENGLISH
2
Thank you for purchasing a JVC product.
Please read all instructions carefully before operation, to ensure your complete understanding and to
obtain the best possible performance from the unit.
IMPORTANT FOR LASER PRODUCTS
1. CLA 1 LA ER PRODUCT
2. CAUTION: Do not open the top cover. There are no user serviceable parts inside the unit; leave
all servicing to qualified service personnel.
3. CAUTION: Visible and invisible laser radiation when open and interlock failed or defeated.
Avoid direct exposure to beam.
4. REPRODUCTION OF LABEL: CAUTION LABEL, PLACED OUT IDE THE UNIT.
How to detach/attach the control
panel
Detaching...
Attaching...
Warn ng:
If you need to operate the unit while driving,
be sure to look ahead carefully or you may be
involved in a traffic accident.
Caut on on volume sett ng:
Discs produce very little noise compared
with other sources. Lower the volume
before playing a disc to avoid damaging
the speakers by the sudden increase of the
output level.
How to reset your un t
• Your preset adjustments will also be erased.
• If a disc is loaded, it will eject. Be careful not to
drop the disc.
How to forc bly eject a d sc
• If this does not work, reset your unit.
• Be careful not to drop the disc when it ejects.
EN02-05_KD-G326_5[U_UH]f.indd 2EN02-05_KD-G326_5[U_UH]f.indd 2 10/4/05 6:03:09 PM10/4/05 6:03:09 PM

ENGLISH
3
How to read th s manual
• Button operations are mainly explained with
the illustrations in the tabel below.
• is used to indicate an indicator is
displayed for the correspnding operation.
• ome related tips and notes are explained in
“More about this unit” (see pages 14 and 15).
Press briefly.
Press repeatedly.
Press either
one.
Press and hold until your
desired response begins.
Press and hold both
buttons at the same time.
How to use the M MODE button
If you press M MODE, the unit goes into
functions mode, then the number buttons
and ¢/4 buttons work as different
function buttons.
Ex.: When number button 2 works as
MO (monaural) button.
To use these buttons for their original
functions again after pressing M MODE, wait
for 5 seconds without pressing any of these
buttons until the functions mode is cleared or
press M MODE again.
CONTENTS
Control panel — KD-G326 and KD-G325 ........ 4
Gett ng started ................................. 5
Basic operations .................................................... 5
Rad o operat ons .............................. 6
D sc operat ons ................................. 7
Playing a disc in the unit ...................................... 7
Sound adjustments ........................... 9
General sett ngs — PSM ................... 10
Remote controller — RM-RK60 .............. 12
Ma ntenance .................................... 13
More about th s un t ......................... 14
Troubleshoot ng ............................... 16
Spec f cat ons ................................... 17
For safety...
• Do not raise the volume level too much, as
this will block outside sounds, making driving
dangerous.
• top the car before performing any
complicated operations.
Temperature ns de the car...
If you have parked the car for a long time in hot
or cold weather, wait until the temperature in
the car becomes normal before operating the
unit.
Time countdown indicator
EN02-05_KD-G326_5[U_UH]f.indd 3EN02-05_KD-G326_5[U_UH]f.indd 3 10/4/05 6:03:12 PM10/4/05 6:03:12 PM

ENGLISH
4
Control panel — KD-G326 and KD-G325
1 (standby/on/attenuator) button
2 SOURCE button
3 BAND button
4 Remote sensor
• You can control this unit with an
optionally purchased remote controller. For
details, see page 12.
• DO NOT expose the remote sensor to
strong light direct sunlight or artificial
lighting).
5 Loading slot
6 Display indo
7 0 (eject) button
8 EQ (equalizer) button
9 ¢/4 buttons
p Control dial
q SEL (select) button
w DISP (display) button
e MO (monaural) button
r SSM (Strong-station Sequential Memory)
button
t Number buttons
y RPT (repeat) button
u RND (random) button
i M MODE button
o (control panel release) button
Display window
; Disc information indicators—TAG (ID3
Tag), (folder), (track/file)
a Disc type indicators—WMA, MP3
s DISC indicator
d Playback mode / item indicators—
RND (random), (disc), (folder),
RPT (repeat)
f LOUD (loudness) indicator
g EQ (equalizer) indicator
h Sound mode (C-EQ: custom equalizer)
indicators—JAZZ, CLASSIC, HIP HOP,
POPS, ROCK, USER
j Tr (track) indicator
k Source display / Volume level indicator /
Time countdo n indicator
l Main display
/ Tuner reception indicators— ST (stereo),
MO (monaural)
Parts identification
Display window
EN02-05_KD-G326_5[U_UH]f.indd 4EN02-05_KD-G326_5[U_UH]f.indd 4 10/14/05 8:50:40 AM10/14/05 8:50:40 AM

ENGLISH
5
Basic settings
• See also “General settings — PSM” on pages
10 and 11.
1
2
1 Canceling the display
demonstrations
Select “DEMO,” then “DEMO OFF.”
2 Setting the clock
Select “ LO K H” (hour), then adjust
the hour.
Select “ LO K M” (minute), then
adjust the minute.
3 Finish the procedure.
To check the current clock
time while the power is
turned off
To check the other
information while
listening to the radio
Clock Ô Frequency
Getting started
Basic operations
~ Turn on the power.
Ÿ
* You cannot select “DISC” as the
playback source if there is no disc in the
unit.
! For FM/AM tuner
⁄ Adjust the volume.
@ Adjust the sound as you want. (See
page .)
To drop the volume in a
moment (ATT)
To restore the sound, press
it again.
To turn off the power
Volume level appears.
Volume level indicator
EN02-05_KD-G326_5[U_UH]f.indd 5EN02-05_KD-G326_5[U_UH]f.indd 5 10/18/05 4:05:44 PM10/18/05 4:05:44 PM

ENGLISH
6
Radio operations
~
Ÿ
! Start searching for a station.
When a station is received,
searching stops.
To stop searching, press the
same button again.
To tune in to a station manually
In step ! above...
1
2 Select the desired station frequencies.
When an FM stereo broadcast is hard to
receive
Reception improves, but stereo effect will be
lost.
To restore the stereo effect, repeat the same
procedure. “MONO OFF appears and the MO
indicator goes off.
Storing stations in memory
You can preset six stations for each band.
FM station automatic presetting —
SSM (Strong-station Sequential
Memory)
1 Select the FM band (FM1 – FM3) you
ant to store into.
2
3
“SSM flashes, then disappears when
automatic presetting is over.
Local FM stations with the strongest signals are
searched and stored automatically in the FM
band.
Manual presetting
Ex.: Storing FM station of 92.5 MHz into preset
number 4 of the FM1 band.
1
2
Lights up when monaural mode is activated.
Lights up when receiving an FM stereo
broadcast with sufficient signal strength.
Selected band appears.
EN06-11_KD-G326_5[U_UH]f.indd 6EN06-11_KD-G326_5[U_UH]f.indd 6 10/14/05 8:51:06 AM10/14/05 8:51:06 AM

ENGLISH
7
3
Listening to a preset station
1
2 Select the preset station (1 – 6) you
want.
Disc operations
Playing a disc in the unit
All tracks will be played repeatedly until you
change the source or eject the disc.
To stop play and eject the
disc
To fast-forward or reverse
the track
To go to the next or
previous tracks
To go to the next or previous folders (only for
MP3 or WM discs)
To locate a particular track (for CD) or folder
(for MP3 or WM discs) directly
To select a number from 01 – 06:
To select a number from 0 – 12:
• To use direct folder access on MP3/WMA
discs, it is required that folders are assigned
with 2-digit numbers at the beginning of their
folder names—01, 02, 03, and so on.
To select a particular track in
a folder (for MP3 or WMA
disc):
Prohibiting disc ejection
You can lock a disc in the loading slot.
To cancel the prohibition, repeat the same
procedure.
Preset number flashes for a while.
EN06-11_KD-G326_5[U_UH]f.indd 7EN06-11_KD-G326_5[U_UH]f.indd 7 10/18/05 4:06:23 PM10/18/05 4:06:23 PM

ENGLISH
8
Selecting the playback modes
You can use only one of the following playback
modes at a time.
1
2 Select your desired playback mode.
7 Repeat play
Mode lays repeatedly
TRK RPT : The current track.
FLDR RPT*3 : All tracks of the current
folder.
RPT OFF : Cancels.
7 Random play
Mode lays at random
FLDR RND*3 : All tracks of the current
folder, then tracks of the next
folder and so on.
DISC RND : All tracks of the current disc.
RND OFF : Cancels.
*3 Only while playing an MP3 or a WMA
disc.
Changing the display information
While playing an audio CD or a CD Text
While playing an M 3 or a WMA disc
• When “TAG DISP” is set to “TAG ON”
(see page 11)
• When “TAG DISP” is set to “TAG OFF”
: Clock ith the current track number
: Elapsed playing time ith the current
track number
*1 If the current disc is an audio CD,
“ O AME” appears.
*2 If an MP3/WMA file does not have ID3 tags,
folder name and file name appear. In this
case, the TAG indicator will not light up.
EN06-11_KD-G326_5[U_UH]f.indd 8EN06-11_KD-G326_5[U_UH]f.indd 8 10/4/05 6:03:43 PM10/4/05 6:03:43 PM

ENGLISH
9
Sound adjustments
You can select a preset sound mode suitable to
the music genre (C-EQ: custom equalizer).
BAS
(bass)
TRE
(treble)
LOUD
(loudness)
USER
(Flat sound) 00 00 FF
ROCK
(Rock or disco music) +03 +01 N
CLASSIC
(Classical music) +01 –02 FF
POPS
(Light music) +04 +01 FF
HIP HOP
(Funk or rap music) +02 00 N
JAZZ
(Jazz music) +02 +03 FF
Adjusting the sound
You can adjust the sound characteristics to your
preference.
*1 Displayed only when “L/O MODE” is set to
“WOOFER” (see page 11).
Indication, [Range]
BAS*2 (bass), [–06 to +06]
Adjust the bass.
TRE*2 (treble), [–06 to +06]
Adjust the treble.
FAD*3 (fader), [R06 to F06]
Adjust the front and rear speaker balance.
BAL*4 (balance), [L06 to R06]
Adjust the left and right speaker balance.
LOUD*2 (loudness), [L UD N or L UD FF]
Boost low and high frequencies to produce a
well-balanced sound at low volume level.
SUB. W
*5 (subwoofer), [00 to 08]
Adjust the subwoofer output level when a
subwoofer is connected.
VOL (volume), [00 to 30 or 50*6]
Adjust the volume.
*2 When you ad ust the bass, treble, or loudness,
the ad ustment you have made is stored for
the currently selected sound mode (C-EQ)
including “USER.”
*3 If you are using a two-speaker system, set the
fader level to “00.”
*4 This ad ustment cannot affect the subwoofer
output.
*5 This takes effect only when a subwoofer is
connected.
*6 Depending on the amplifier gain control
setting. (See page 11 for details.)
Preset va ues
Indication (For)
Ex.: When “ROCK” is selected
EN06-11_KD-G326_5[U_UH]f.indd 9EN06-11_KD-G326_5[U_UH]f.indd 9 10/14/05 8:53:12 AM10/14/05 8:53:12 AM

ENGLISH
10
Indications Selectable settings, [reference page]
DEMO
Display
demonstration
DEMO ON : [Initial]; Display demonstration will be activated
automatically if no operation is done for about 20 seconds,
[5].
DEMO OFF : Cancels.
CLOCK H
Hour adjustment
1 – 12, [5]
[Initial: 1 (1:00)]
CLOCK M
Minute adjustment
00 – 59, [5]
[Initial: 00 (1:00)]
DIMMER
Dimmer
ON : Dims the display illumination of this unit.
OFF : [Initial]; Cancels.
SCROLL*1
Scroll
ONCE : [Initial]; Scrolls the disc information once.
AUTO : Repeats scrolling (5-second intervals in between).
OFF : Cancels.
• Pressing DISP for more than one second can scroll the display regardless
of the setting.
*1 Some characters or symbols will not be shown correctly (or will be blanked) on the display.
General settings — PSM
You can change PSM (Preferred Setting Mode)
items listed in the table that follows.
1
2 Select a PSM item.
3 Adjust the PSM item selected.
4 Repeat steps 2 and 3 to adjust other
PSM items if necessary.
5 Finish the procedure.
EN06-11_KD-G326_5[U_UH]f.indd 10EN06-11_KD-G326_5[U_UH]f.indd 10 10/4/05 6:03:45 PM10/4/05 6:03:45 PM

ENGLISH
11
Indications Selectable settings, [reference page]
WOOFER*2
Subwoofer cutoff
frequency
LOW : Frequencies lower than 55 Hz are sent to the subwoofer.
MID : [Initial]; Frequencies lower than 85 Hz are sent to the
subwoofer.
HIGH : Frequencies lower than 115 Hz are sent to the subwoofer.
L/O MODE
Line output mode
hen connecting an amplifier or a subwoofer, set this correctly.
REAR : [Initial]; Select if the REAR LINE OUT terminals are used
for connecting the speakers through an external amplifier.
WOOFER : Select if the REAR LINE OUT terminals are used for
connecting a subwoofer.
TAG DISP
Tag display
TAG ON : [Initial]; Shows the ID3 tag while playing MP3/ MA tracks,
[8].
TAG OFF : Cancels.
AMP GAIN
Amplifier gain
control
You can change the maximum volume level of this unit.
LOW PWR : VOL 00 – VOL 30 (Select this if the maximum power of the
speaker is less than 50 to avoid damaging the speaker.)
HIGH PWR : [Initial]; VOL 00 – VOL 50
*2 Displayed only when “L/O MODE” is set to “WOOFER.”
EN06-11_KD-G326_5[U_UH]f.indd 11EN06-11_KD-G326_5[U_UH]f.indd 11 10/18/05 11:10:05 AM10/18/05 11:10:05 AM

ENGLISH
12
Remote controller — RM-RK60
This unit can be remotely controlled as
instructed here (with an optionally purchased
remote controller). We recommend that you
use remote controller RM-RK60 with your unit.
Installing the lithium coin battery
(CR2025)
Aim the remote controller directly at the
remote sensor on the unit. Make sure there is
no obstacle in between.
Warning:
• o not install any battery other than
CR2025 or its equivalent; otherwise, it may
explode.
• Store the battery in a place where children
cannot reach to avoid risk of accident.
• To prevent the battery from over-heating,
cracking, or starting a fire:
– o not recharge, short, disassemble,
heat the battery, or dispose of it in a fire.
– o not leave the battery with other
metallic materials.
– o not poke the battery with tweezers or
similar tools.
– Wrap the battery with tape and insulate
when throwing away or saving it.
Main elements and features
1 (standby/on attenuator) button
• Turns the power on if pressed briefly or
attenuates the sound when the power is
turned on.
• Turns the power off if pressed and held.
2 SRC (source) button
• Selects the source.
3 R (reverse) / F (forward) buttons
• Searches for stations if pressed briefly.
• Fast-forwards or reverses the track if
pressed and held.
• Changes the tracks of the disc if pressed
briefly.
4 SOUN button
• Selects the sound mode (C-EQ: custom
equalizer).
5 U (up) / (down) buttons
• Changes the FM/AM bands with U only.
• Changes the preset stations with only.
• Changes the folder of the MP3/WMA
discs.
6 VOLUME – /+ buttons
• Adjusts the volume level.
Caution:
EN12-17_KD-G326_5[U_UH]f.indd 12EN12-17_KD-G326_5[U_UH]f.indd 12 10/14/05 8:54:21 AM10/14/05 8:54:21 AM

ENGLISH
13
Maintenance
Ho to clean the connectors
Frequent detachment will deteriorate the
connectors. To minimize this possibility,
periodically wipe the connectors with a cotton
swab or cloth moistened with alcohol, being
careful not to damage the connectors.
Moisture condensation
Moisture may condense on the lens inside the
C player in the following cases:
• After starting the heater in the car.
• If it becomes very humid inside the car.
Should this occur, the C player may
malfunction. In this case, eject the disc and
leave the unit turned on for a few hours until
the moisture evaporates.
Ho to handle discs
When removing a disc from
its case, press down the center
holder of the case and lift the disc
out, holding it by the edges.
• Always hold the disc by the
edges. o not touch its recording surface.
When storing a disc into its case, gently insert
the disc around the center holder (with the
printed surface facing up).
• Make sure to store discs into the cases after
use.
Center holder
Connector
To keep discs clean
A dirty disc may not play correctly.
If a disc does become dirty, wipe it
with a soft cloth in a straight line
from center to edge.
• o not use any solvent (for example,
conventional record cleaner, spray, thinner,
benzine, etc.) to clean discs.
To play ne discs
New discs may have some rough
spots around the inner and outer
edges. If such a disc is used, this
unit may reject the disc.
To remove these rough spots, rub the edges
with a pencil or ball-point pen, etc.
Warped disc
Sticker Sticker residue
Disc Stick-on label
Do not use the following discs:
EN12-17_KD-G326_5[U_UH]f.indd 13EN12-17_KD-G326_5[U_UH]f.indd 13 10/14/05 8:54:23 AM10/14/05 8:54:23 AM

ENGLISH
14
More about this unit
Basic operations
Turning on the power
• By pressing SOURCE on the unit, you can
also turn on the power. If the source is ready,
playbac also starts.
Turning off the power
• If you turn off the power while listening to a
disc, disc play will start from where playbac
has been stopped previously, next time you
turn on the power.
Tuner operations
Storing stations in memory
• During SSM search...
– All previously stored stations are erased
and stations are stored newly.
–
Received stations are preset in No. 1 (lowest
frequency) to No. 6 (highest frequency).
– When SSM is over, the station stored in
No. 1 will be automatically tuned in.
• When storing a station manually, the
previously preset station is erased when a new
station is stored in the same preset number.
Disc operations
Caution for DualDisc playback
• The Non-DVD side of a “DualDisc” does
not comply with the “Compact Disc Digital
Audio” standard. Therefore, the use of Non-
DVD side of a DualDisc on this product may
not be recommended.
General
• This unit has been designed to reproduce
CDs/CD Texts, and CD-Rs (Recordable)/
CD-RWs (Rewritable) in audio CD (CD-DA),
MP3 and WMA formats.
• When a disc has been loaded, selecting
“DISC” for the playbac source starts disc
play.
Inserting a disc
• When a disc is inserted upside down, the disc
automatically ejects.
• Do not insert 8 cm discs (single CD) and
unusual shape discs (heart, flower, etc.) into
the loading slot.
Playing a disc
• While fast-forwarding or reversing on an MP3
or WMA disc, you can only hear intermittent
sounds.
Playing a CD- or CD- W
• Use only “finalized” CD-Rs or CD-RWs.
• This unit can play bac only files of the same
type which are first detected if a disc includes
both audio CD (CD-DA) files and MP3/
WMA files.
• This unit can play bac multi-session discs;
however, unclosed sessions will be s ipped
while playing.
• Some CD-Rs or CD-RWs may not play
bac on this unit because of their disc
characteristics, or for the following reasons:
– Discs are dirty or scratched.
– Moisture condensation occurs on the lens
inside the unit.
– The pic up lens inside the unit is dirty.
– CD-R/CD-RW on which the files are
written with “Pac et Write” method.
– There are improper recording conditions
(missing data, etc.) or media conditions
(stained, scratched, warped, etc.).
• CD-RWs may require a longer readout time
since the reflectance of CD-RWs is lower than
that of regular CDs.
EN12-17_KD-G326_5[U_UH]f.indd 14EN12-17_KD-G326_5[U_UH]f.indd 14 10/26/05 12:50:19 PM10/26/05 12:50:19 PM

ENGLISH
15
• Do not use the following CD-Rs or CD-RWs:
– Discs with stickers, labels, or protective seal
stuck to the surface.
– Discs on which labels can be directl
printed b an ink jet printer.
Using these discs under high temperatures or
high humidities ma cause malfunctions or
damage to the unit.
Playing an MP3/WMA disc
• This unit can pla back MP3/WMA files
with the extension code <.mp3> or <.wma>
(regardless of the letter case—upper/lower).
• This unit can show the names of albums,
artists (performer), and ID3 Tag (Version
1.0, 1.1, 2.2, 2.3, or 2.4) for MP3 files and for
WMA files.
• This unit can displa onl one-b te
characters. No other characters can be
correctl displa ed.
• This unit can pla back MP3/WMA files
meeting the conditions below:
– Bit rate: 8 kbps — 320 kbps
– Sampling frequenc :
48 kHz, 44.1 kHz, 32 kHz (for MPEG-1)
24 kHz, 22.05 kHz, 16 kHz (for MPEG-2)
– Disc format: ISO 9660 Level 1/ Level 2,
Romeo, Joliet, Windows long file name
• The maximum number of characters for file/
folder names var among the disc format used
(includes 4 extension characters—<.mp3> or
<.wma>).
– ISO 9660 Level 1: up to 12 characters
– ISO 9660 Level 2: up to 31 characters
– Romeo: up to 128 characters
– Joliet: up to 64 characters
– Windows long file name: up to 128
characters
• This unit can pla back files recorded in VBR
(variable bit rate).
Files recorded in VBR have a discrepanc
in elapsed time displa , and do not show
the actual elapsed time. Especiall , after
performing the search function, this
difference becomes noticeable.
• This unit can recognize a total of 512 files, of
200 folders, and of 8 hierarchies.
• This unit cannot pla back the following files:
– MP3 files encoded with MP3i and
MP3 PRO format.
– MP3 files encoded in an unappropriate
format.
– MP3 files encoded with La er 1/2.
– WMA files encoded with lossless,
professional, and voice format.
– WMA files which are not based upon
Windows Media® Audio.
– WMA files cop -protected with DRM.
– Files which have the data such as WAVE,
ATRAC3, etc.
• The search function works but search speed is
not constant.
Changing the source
• If ou change the source, pla back also stops
(without ejecting the disc).
Next time ou select “DISC” for the pla back
source, disc pla starts from where it has been
stopped previousl .
Ejecting a disc
• If the ejected disc is not removed within
15 seconds, the disc is automaticall inserted
again into the loading slot to protect it from
dust. (Disc will not pla this time.)
General settings—PSM
• If ou change the “AMP GAIN” setting from
“HIGH PWR” to “LOW PWR” while the
volume level is set higher than “VOL 30,” the
unit automaticall changes the volume level to
“VOL 30.”
EN12-17_KD-G326_5[U_UH]f.indd 15EN12-17_KD-G326_5[U_UH]f.indd 15 10/20/05 9:23:00 AM10/20/05 9:23:00 AM

ENGLISH
16
Symptoms Remedies/Causes
General
• Sound cannot be heard from the
speakers.
• Adjust the volume to the optimum level.
• Check the cords and connections.
• This unit does not work at all. Reset the unit (see page ).
FM/AM
• SSM automatic presetting does not
work.
Store stations manually.
• Static noise while listening to the
radio.
Connect the antenna firmly.
Disc playback
• Disc cannot be played back. Insert the disc correctly.
• CD-R/CD-RW cannot be played
back.
• Tracks on the CD-R/CD-RW cannot
be skipped.
• Insert a finalized CD-R/CD-RW.
•
Finalize the CD-R/CD-RW with the component
which you used for recording.
• Disc can be neither played back nor
ejected.
• Unlock the disc (see page 7).
• Eject the disc forcibly (see page ).
• Disc sound is sometimes interrupted. • Stop playback while driving on rough roads.
• Change the disc.
• Check the cords and connections.
• “NO DISC” appears on the display. Insert a playable disc into the loading slot.
MP3/WMA playback
• Disc cannot be played back. • Use a disc with MP3/WMA tracks recorded in
the format compliant with ISO 9660 Level 1,
Level , Romeo, or Joliet.
• Add the extension code <.mp3> or <.wma> to
the file names.
• Noise is generated. Skip to another track or change the disc. (Do not
add the extension code <.mp3> or <.wma> to
non-MP3 or WMA tracks.)
• A longer readout time is required
(“CHECK” keeps flashing on the
display).
Do not use too many hierarchies and folders.
• Tracks do not play back in the order
you have intended them to play.
Playback order is determined when the files are
recorded.
• Elapsed playing time is not correct. This sometimes occurs during play. This is caused
by how the tracks are recorded on the disc.
• “NO FILES” appears on the display. Insert a disc that contains MP3/WMA tracks.
• Correct characters are not displayed
(e.g. album name).
This unit can only display alphabets (upper case),
numbers, and a limited number of symbols.
Troubleshooting
What appears to be trouble is not always serious. Check the following points before calling a service
center.
EN12-17_KD-G326_5[U_UH]f.indd 16EN12-17_KD-G326_5[U_UH]f.indd 16 10/24/05 11:28:23 AM10/24/05 11:28:23 AM

ENGLISH
17
Specifications
AUDIO AMPLIFIER SECTION
Maximum Power Output:
Front: 50 W per channel
Rear: 50 W per channel
Continuous Power Output (RMS):
Front: 1 W per channel into 4 Ω, 40 Hz
to 20 000 Hz at no more than 0.8%
total harmonic distortion.
Rear: 1 W per channel into 4 Ω, 40 Hz
to 20 000 Hz at no more than 0.8%
total harmonic distortion.
Load Impedance: 4 Ω (4 Ω to 8 Ω allowance)
Tone Control Range:
Bass: ±10 dB at 100 Hz
Treble: ±10 dB at 10 kHz
Frequency Response: 40 Hz to 20 000 Hz
Signal-to-Noise Ratio: 70 dB
Line-Out Level/Impedance:
2.5 V/20 kΩ load (full scale)
Output Impedance: 1 kΩ
TUNER SECTION
Frequency Range:
FM: 87.5 MHz to 108.0 MHz
AM: 531 kHz to 1 602 kHz
[FM Tuner]
Usable Sensitivity: 11.3 dBf (1.0 μV/75 Ω)
50 dB Quieting Sensitivity:
16.3 dBf (1.8 μV/75 Ω)
Alternate Channel Selectivity (400 kHz): 65 dB
Frequency Response: 40 Hz to 15 000 Hz
Stereo Separation: 30 dB
Capture Ratio: 1.5 dB
[AM Tuner]
Sensitivity: 20 μV
Selectivity: 35 dB
CD PLAYER SECTION
Type: Compact disc player
Signal Detection System: Non-contact optical
pickup (semiconductor laser)
Number of Channels: 2 channels (stereo)
Frequency Response: 5 Hz to 20 000 Hz
Dynamic Range: 6 dB
Signal-to-Noise Ratio: 8 dB
Wow and Flutter: Less than measurable limit
MP3 Decoding Format:
MPEG1/2 Audio Layer 3
Max. Bit Rate: 320 kbps
WMA (Windows Media® Audio) Decoding
Format:
Max. Bit Rate: 1 2 kbps
GENERAL
Power Requirement:
Operating Voltage:
DC 14.4 V (11 V to 16 V allowance)
Grounding System: Negative ground
Allowable Operating Temperature:
0°C to +40°C
Dimensions (W × H × D):
Installation Size (approx.):
182 mm × 52 mm × 150 mm
Panel Size (approx.):
188 mm × 58 mm × 11 mm
Mass (approx.):
1.2 kg (excluding accessories)
Design and specifications are subject to change
without notice.
• Microsoft and Windows Media are either
registered trademarks or trademarks of
Microsoft Corporation in the United States
and/or other countries.
EN12-17_KD-G326_5[U_UH]f.indd 17EN12-17_KD-G326_5[U_UH]f.indd 17 10/26/05 12:49:42 PM10/26/05 12:49:42 PM

2
INDONESIA
Terima kasih telah membeli produk JVC.
Harap membaca seluruh petunjuk dengan teliti sebelum mengoperasikan, untuk memastikan anda
memahami secara keseluruhan dan mendapatkan performansi terbaik dari unit ini.
PENTING UNTUK PRODUK-PRODUK LASER
1. PR DUK LASER KELAS 1
2. PERHATIAN: Jangan membuka penutup atas. Tidak ada bagian yang dapat diperbaiki oleh
pengguna di dalam unit tersebut; biarkanlah semua bagian yang diperbaiki untuk memenuhi
syarat perbaikan teknis.
3. PERHATIAN: Radiasi laser yang terlihat dan tidak terlihat ketika membuka dan salah sambung
atau gagal. Hindari sorotan pencahayaan yang langsung.
4. REPR DUKSI DARI LABEL: LABEL PERHATIAN, TEMPATKAN DI LUAR UNIT
TERSEBUT.
Cara melepas/memasang panel kontrol
Melepas...
Memasang...
Peringatan
Jika anda perlu mengoperasikan unit tersebut
sementara mengemudi, pastikan untuk
melihat ke atas dengan hati-hati atau anda
mungkin terlibat suatu kecelakaan lalu lintas.
Perhatian pada pengaturan volume
Disk-disk menghasilkan sangat kecil noise
(derau) dibandingkan dengan sumber yang
lain. Kecilkan volume sebelum disk untuk
menghindari kerusakan speaker-speaker
dengan penambahan mendadak dari level
keluaran.
Bagaimana mereset unit anda
• Penyetelan-penyetelan pengaturan awal anda
akan terhapus juga.
• Jika sebuah disk sudah dimuat, akan
dikeluarkan. Hati-hati untuk tidak
menjatuhkan disk tersebut.
Bagaimana secara paksa
mengeluarkan sebuah disk
• Jika ini tidak bekerja, coba mengeset kembali
(reset) alat penerima anda.
• Hati-hati untuk tidak menjatuhkan disk
tersebut ketika dikeluarkan.
IN02-05_KD-G326_5[UN]1.indd 2IN02-05_KD-G326_5[UN]1.indd 2 10/19/05 5:04:46 PM10/19/05 5:04:46 PM

3
INDONESIA
Bagaimana membaca manual ini
• perasi tombol secara umum dijelaskan
dengan ilustrasi dalam tabel di bawah ini.
• digunakan untuk menunjukkan
indikator yang ditampilkan untuk
pengoperasian yang bersangkutan.
• Beberapa saran dan catatan yang berkaitan
dijelaskan dalam “Lebih lagi tentang alat
penerima ini” (lihat halaman 14 dan 15).
Tekan dengan singkat.
Tekan secara berulang.
Tekan salah
satu.
Tekan dan tahan sampai
respon yang anda
harapkan dimulai.
Tekan dan tahan kedua
tombol pada waktu
bersamaan.
Bagaimana menggunakan tombol
M MODE
Jika anda menekan M M DE, alat penerima
masuk ke dalam mode fungsi-fungsi, kemudian
tombol-tombol nomor dan tombol-tombol
¢/4 bekerja sebagai tombol-tombol
yang berbeda fungsi.
Contoh: Ketika tombol nomor 2 bekerja
sebagai tombol M (mono).
Untuk menggunakan tombol-tombol ini
untuk fungsi aslinya setelah menekan
M MODE, tunggu 5 detik tanpa menekan
tombol apa pun sampai mode fungsi kosong
atau tekan lagi M M DE.
DAFTAR ISI
Panel kontrol — KD-G326 dan KD-G325 ........ 4
Memulai .......................................... 5
Pengoperasian-pengoperasian dasar .................... 5
Pengoperasian–pengoperasian
radio ............................................. 6
Pengoperasian-pengoperasian disk ... 7
Memainkan disk di dalam unit .............................. 7
Penyetelan suara-suara .................... 9
Pengaturan-pengaturan umum
— PSM ......................................... 10
Remote Kontrol — RM-RK60 ................. 12
Perawatan ....................................... 13
Lebih lagi tentang alat penerima ini .... 14
Pemecahan Masalah ......................... 16
Spesifikasi-spesifikasi ....................... 17
Untuk keselamatan...
• Jangan menaikkan level volume terlalu tinggi
karena akan menghalangi suara dari luar, dan
membahayakan perjalanan anda.
• Hentikan mobil sebelum melakukan
pengoperasian yang rumit.
Suhu dalam mobil...
Jika anda telah memarkir mobil terlalu lama
dalam cuaca yang panas atau dingin, tunggu
hingga suhu dalam mobil menjadi normal
kembali sebelum mengoperasikan unit ini.
Indikator hitung mundur waktu
IN02-05_KD-G326_5[UN]1.indd 3IN02-05_KD-G326_5[UN]1.indd 3 10/19/05 5:04:53 PM10/19/05 5:04:53 PM

4
INDONESIA
Panel kontrol — KD-G326 dan KD-G325
1 Tombol (standby/hidup/pelemah)
2 Tombol S URCE
3 Tombol BAND
4 Sensor remote kontrol
• nda dapat mengendalikan unit ini
dengan remote kontrol opsional yang
bisa nda beli. Untuk rinciannya, lihat
halaman 12.
• J NG N membiarkan sensor remote
kontrol pada cahaya kuat (sinar matahari
langsung atau pencahayaan buatan).
5 Celah pemuatan
6 Jendela tampilan
7 Tombol 0 (keluar)
8 Tombol EQ (equalizer)
9 Tombol-tombol ¢/4
p Tombol kontrol
q Tombol SEL (pilih)
w Tombol DISP (tampilan)
e Tombol M (mono)
r Tombol SSM (Memori Urutan Stasiun-
Kuat)
t Tombol-tombol nomor
y Tombol RPT (ulang)
u Tombol RND (acak)
i Tombol M M DE
o Tombol (pelepas panel kontrol)
Jendela tampilan
; Indikator-indikator informasi disk—
TAG (Ujung ID3), (folder), (trek/file)
a Indikator-indikator tipe disk—WMA, MP3
s Indikator DISC
d Indikator mode putar ulang / indikator
item—RND (acak), (disk), (folder),
RPT (ulang)
f Indikator L UD (kekerasan)
g Indikator EQ (equalizer)
h Indikator-indikator mode suara (C-EQ:
kostum equalizer)—JAZZ, CLASSIC,
HIP H P, P PS, R CK, USER
j Indikator Tr (trek)
k Tampilan sumber / Indikator level volume /
Indikator hitung mundur waktu
l Tampilan utama
/ Indikator-indikator penerima tuner—
ST (stereo), M (mono)
Pengenalan bagian-bagian
Jendela tampilan
IN02-05_KD-G326_5[UN]1.indd 4IN02-05_KD-G326_5[UN]1.indd 4 10/19/05 5:04:56 PM10/19/05 5:04:56 PM
