JVC KD-R307 User manual

1– EN
ENGLISH
[European Union only]
IMPORTANT FOR LASER PRODUCTS
1. CLASS 1 LASER PRODUCT
2. CAUTION: Do not open the top cover. There are no user serviceable parts inside the unit; leave all servicing to qualified
service personnel.
3. CAUTION: Visible and/or invisible class 1M laser radiation when open. Do not view directly with optical instruments.
4. REPRODUCTION OF LABEL: CAUTION LABEL, PLACED OUTSIDE THE UNIT.
KD-R307/KD-R37
CD RECEIVER: INSTRUCTIONS/INSTALLATION
0409DTSMDTJEIN
EN
© 2009 Victor Company of Japan, Limited
Warning
If you need to operate the unit while driving, be sure to
look around carefully or you may be involved in a traffic
accident.
Caution on volume setting
Discs produce very little noise compared with other sources.
Lower the volume before playing a disc to avoid damaging
the speakers by the sudden increase of the output level.
For safety...
• Do not raise the volume level too much, as this will block
outside sounds, making driving dangerous.
• Stop the car before performing any complicated
operations.
Temperature inside the car...
If you have parked the car for a long time in hot or cold
weather, wait until the temperature in the car becomes
normal before operating the unit.
Detaching the control panel
Attaching the control panel
How to reset your unit
Reset the unit after installation is complete.
• Your preset adjustments will also be erased.
How to forcibly eject a disc
• Be careful not to drop the disc when it ejects.
• If this does not work, reset your unit.
PREPARATIONS
Enter Menu operation. Select an item.
Basic settings
Thank you for purchasing a JVC product.
Please read all instructions carefully before operation, to ensure your complete understanding and to obtain the best
possible performance from the unit.
Installation/connection are explained at the last section of this manual (reverse page, indicated with
symbol).
Basic operations
Select the source.
• Turn on the power.
• Attenuate the sound (if the
power is on).
• Turn off the power [Hold].
• Control the volume or selection [Turn].
• Confirm the selection [Press].
• FM: Enter SSM preset mode [Hold].
• CD: Enter playback mode [Hold].
Detach the panel.
Check the current clock time/other information.
See also “CLOCK DISP“ of “Menu operations.”
Control panel
Display window Disc indicator Playback mode / item indicator
• ST: Lights up when receiving an FM
stereo broadcast with sufficient
signal strength.
• MO: Lights up in monaural mode.
• Source display
• Track number
• Folder number
• Time countdown indicator
Main display (time,
playback information)
EQ (equalizer) indicator
Sound mode indicator
LOUD (loudness) indicator
Disc information indicators
Tr (track) indicator
To play new discs
Remove any rough areas from the inner and
outer edges of the disc.
Do not use the following discs:
• Single CD (8 cm disc)
• Warped disc
• Disc with sticker and sticker residue
• Disc with stick-on label
• Unusual shape disc
• C-thru Disc (semi-transparent disc)
• Disc with transparent or semi-transparent parts on its
recording area
MAINTENANCE
How to clean the connectors
Wipe the connectors
with a cotton swab or
cloth moistened with
alcohol.
Moisture condensation
Moisture may condense on the lens inside the unit. Eject
the disc and leave the unit turned on for a few hours until
the moisture has evaporated.
To keep discs clean
Wipe in a straight line from center of disc to
edge. Do not use liquid cleaners, thinners, or
benzene.
– The pickup lens inside the unit is dirty.
– The files on the CD-R/CD-RW are written using the
“Packet Write” method.
– There are improper recording conditions (missing data,
etc.) or media conditions (stained, scratched, warped,
etc.).
• CD-RWs may require a longer readout time since the
reflectance of CD-RWs is lower than that of regular CDs.
Playing an MP3/WMA disc
• This unit can play back MP3/WMA files with the
extension code <.mp3> or <.wma> (regardless of the
letter case—upper/lower).
• This unit can show the names of albums, artists
(performer), and tag (Version 1.0, 1.1, 2.2, 2.3, or 2.4) for
MP3 files and for WMA files
• This unit can play back MP3/WMA files meeting the
conditions below:
– Bit rate: 8 kbps — 320 kbps
– Sampling frequency:
48 kHz, 44.1 kHz, 32 kHz (for MPEG-1)
24 kHz, 22.05 kHz, 16 kHz (for MPEG-2)
– Disc format: ISO 9660 Level 1/ Level 2, Romeo, Joliet,
Windows long file name
• The maximum number of characters for file/folder names
vary depending on the disc format used (includes 4
extension characters—<.mp3> or <.wma>).
– ISO 9660 Level 1: up to 12 characters; ISO 9660 Level
2: up to 31 characters; Romeo: up to 128 characters;
Joliet: up to 64 characters; Windows long file name: up
to 128 characters
• This unit can recognize a total of 512 files, 255 folders,
and 8 hierarchical levels.
• This unit can play back files recorded in VBR (variable bit
rate).
Files recorded in VBR have a discrepancy in the elapsed
time display, and do not show the actual elapsed time.
In particular, this difference becomes noticeable after
performing the search function.
• This unit cannot play back the following files:
– MP3 files: encoded in MP3i and MP3 PRO format; an
inappropriate format; layer 1/2.
– WMA files: encoded in lossless, professional, and voice
format; not based upon Windows Media® Audio; copy-
protected with DRM.
– Files which have data such as AIFF, ATRAC3, etc.
• The search function works but search speed is not
constant.
Basic operations
• By pressing SRC on the unit, you can also turn on the
power. If the source is ready, playback also starts.
• If you turn off the power while listening to a track,
playback will start from where it had been stopped
previously next time you turn on the power.
• If no operation is done for about 30 seconds after
pressing MENU button, the operation will be canceled.
Tuner operations
• During SSM search...
– All previously stored stations are erased and the
stations are stored anew.
– When SSM is over, the station stored in the lowest
preset number will be automatically tuned in.
• Network-Tracking Reception requires two types of Radio
Data System signals—PI (Programme Identification)
and AF (Alternative Frequency) to work correctly.
• If a Traffic Announcement is received by TA Standby
Reception, the volume level automatically changes to the
preset level (TA VOL) if the current level is lower than the
preset level.
• When Alternative Frequency Reception is activated
(with AF selected), Network-Tracking Reception is also
activated automatically. On the other hand, Network-
Tracking Reception cannot be deactivated without
deactivating Alternative Frequency Reception.
Disc operations
Caution for DualDisc playback
• The Non-DVD side of a “DualDisc” does not comply with
the “Compact Disc Digital Audio” standard. Therefore,
the use of Non-DVD side of a DualDisc on this product
may not be recommended.
General
• This unit has been designed to reproduce CDs/CD Texts,
and CD-Rs (Recordable)/CD-RWs (Rewritable) in audio CD
(CD-DA) and MP3/WMA formats.
Playing a CD-R or CD-RW
• Use only “finalized” CD-Rs or CD-RWs.
• This unit can play back multi-session discs; however,
unclosed sessions will be skipped while playing.
• Some CD-Rs or CD-RWs may not be played back on this
unit:
– Discs are dirty or scratched.
– Moisture condensation has occurred on the lens inside
the unit.
MORE ABOUT THIS UNIT
1Cancel the display demonstrations
Select “DEMO,” then “DEMO OFF.”
2Set the clock
Select “CLOCK” =“CLOCK SET.”
Adjust the hour, then press control dial once
to proceed to adjust the minute.
Select “24H/12H,” then “24 HOUR” or
“12 HOUR.”
• To return to the previous menu, press BACK.
Connectors
*1You cannot select “CD” as the playback source
if no disc is in the unit.
*2You cannot select these sources if they were
disabled in the Menu (see “Menu operations”).
Radio Data
System indicators
GET0569-001B
[EE]
OPERATIONS
Return to the
previous menu.
EN_KD-R307_R37[EE]ff.indd 1EN_KD-R307_R37[EE]ff.indd 1 4/13/09 3:03:30 PM4/13/09 3:03:30 PM

2 – EN
INSTRUCTIONS
3.5 mm stereo mini
plug (not supplied)
Portable audio player, etc.
Turn on the connected
component and start
playing the source.
External component operations
You can connect an external component to the AUX (auxiliary)
input jack on the control panel.
• Make sure “AUX ON” is selected in the “SRC SELECT” =
“AUX IN” setting, see “Menu operations.”
Disc operations
Turn on the power.
Insert disc.
All tracks will be played repeatedly until you change the source or eject the disc.
Eject disc.
• “NO DISC” appears.
Press SRC to listen to another
playback source.
• 4/ ¢
[Press] Go to the previous or next track.
[Hold] Reverses or fast-forwards the track.
• 5/ ∞: Go to the previous or next folder (for MP3/WMA discs).
Selecting the playback modes
Changing the display information
While playing an audio
CD or CD Text
While playing an MP3 or
a WMA disc
A=B=Disc title/
performer*1=Track
title*1=(back to the
beginning)
A=B=Album name/
performer (folder name*2)
=Track title (file name*2)
=(back to the beginning)
A: The elapsed playing time with the current track
number
B: Clock with the current track number
*1If the current disc is an audio CD, “NO NAME” appears.
*2If an MP3/WMA file does not have tags or “TAG
DISPLAY” is set to “TAG OFF,” folder name and
file name appear.
REPEAT
TRACK RPT : Repeats current track
FOLDER RPT : MP3/WMA: Repeats current
folder
RANDOM
FOLDER RND : MP3/WMA: Randomly plays all
tracks of current folder, then
tracks of next folders
ALL RND : Randomly plays all tracks
• To cancel repeat play or random play, select “RPT OFF”
or “RND OFF.”
• To return to the previous menu, press BACK.
Prohibiting disc ejection
To cancel the prohibition, repeat the same procedure.
Selecting a track/folder
• For MP3/WMA disc, select the desired folder, then the
desired track by performing the control dial.
• To return to the previous menu, press BACK.
Sound adjustments
* You can change “USER” settings and store as your own sound mode (see below).
Storing your own sound mode
Preset values
SETTINGS
Select “EQ”
Indication (For)
BASS
TREBLE
LOUD
USER (Flat sound) 00 00 OFF
ROCK (Rock or disco music) +03 +01 ON
CLASSIC (Classical music) +01 –02 OFF
POPS (Light music) +04 +01 OFF
HIP HOP (Funk or rap music) +02 00 ON
JAZZ (Jazz music) +02 +03 OFF
\See reverse page
When an FM stereo broadcast is hard to receive
Reception improves, but the stereo effect will be lost. (MO indicator lights up.)
To restore the stereo effect, repeat the same procedure to select “MONO OFF.” The MO indicator goes off.
FM station automatic presetting—SSM (Strong-station Sequential Memory)
You can preset up to 18 stations for FM.
To preset other 6 stations, repeat from step 1again.
Manual presetting (FM/AM)
You can preset up to 18 stations for FM and 6 stations for AM.
Example: Storing the FM station of 92.50 MHz into preset number “04”.
Selecting preset station
The following features are available only for FM Radio Data System stations.
Radio operations
Select “FM,” “AM,” or “FM-LO.”
Search for a station—Auto Search.
Manual Search: Hold either one of the buttons until “M” flashes on the display, then press it repeatedly.
Note:
FM:
87.5 MHz – 108.0 MHz
FM-LO:
65.00 MHz – 74.00 MHz
Select “TUNER” =“MONO” =
“MONO ON”
(See also “Menu operations”.)
Select preset number “04.”
Select “USER” for “EQ”
This mode will be canceled if no operation is done for about
30 seconds.
1Select a tone.
BASS ÔTREBLE
2Adjust the Level.
–06 to +06
REPEAT
∆
RANDOM
Searching for your favourite FM Radio Data
System programme
You can tune in to a station broadcasting your favourite
programme by searching for a PTY code.
Standby receptions
TA Standby Reception
TA Standby Reception allows the unit to switch
temporarily to Traffic Announcement (TA) from any
source other than AM and FM-LO.
To activate/deactivate TA Standby Reception
• If the TP indicator flashes, TA Standby
Reception is not yet activated.
To activate the reception, tune in to another
station providing Radio Data System signals required
for TA Standby Reception.
PTY Standby Reception
PTY Standby Reception allows the unit to switch
temporarily to your favourite PTY programme from any
source other than AM and FM-LO.
To activate and select your favourite PTY code
for PTY Standby Reception, see “Menu operations:
PTY-STANDBY.”
• If the PTY indicator flashes, PTY Standby Reception is
not yet activated.
To activate the reception, tune in to another
station providing these signals.
Tracing the same programme—Network-
Tracking Reception
When driving in an area where FM reception is not
sufficient enough, this unit automatically tunes in to
another FM Radio Data System station of the same
network, possibly broadcasting the same programme
with stronger signals.
Programme A broadcasting on different frequency
areas (01 – 05)
To change the Network-Tracking Reception
setting, see “Menu operation: AF-REG.”
Automatic station selection—Programme
Search
Usually when you select a preset number, the station
preset in that number is tuned in.
If the signals from the FM Radio Data System preset
station are not sufficient for good reception, this unit,
using the AF data, tunes in to another frequency possibly
broadcasting the same programme as the original preset
station is broadcasting.
See “Menu operations: P-SEARCH.”
PTY codes
NEWS, AFFAIRS, INFO, SPORT, EDUCATE, DRAMA, CULTURE,
SCIENCE, VARIED, POP M (music), ROCK M (music), EASY
M (music), LIGHT M (music), CLASSICS, OTHER M (music),
WEATHER, FINANCE, CHILDREN, SOCIAL, RELIGION, PHONE IN,
TRAVEL, LEISURE, JAZZ, COUNTRY, NATION M (music), OLDIES,
FOLK M (music), DOCUMENT
The last selected PTY code
appears.
Select one of your
favourite programme
types or a PTY code.
If there is a station broadcasting a programme
of the same PTY code as you have selected, that
station is tuned in.
or
FM
SSM 01–06 ÔSSM 07-12
FM-LO
SSM 01–06 Refer to table
on right
While “USER”
is shown on the
display...
or
EN_KD-R307_R37[EE]_f.indd 2EN_KD-R307_R37[EE]_f.indd 2 18/9/08 2:48:23 PM18/9/08 2:48:23 PM

3 – EN
INSTRUCTIONS
Audio amplifier section
Maximum Power Output:
Front/Rear: 50 W per channel
Continuous Power Output (RMS):
Front/Rear: 19 W per channel into 4 Ω,
40 Hz to 20 000 Hz at no more
than 0.8% total harmonic
distortion.
Load Impedance: 4 Ω (4 Ω to 8 Ω allowance)
Tone Control Range: Bass: ±12 dB at 100 Hz
Treble: ±12 dB at 10 kHz
Frequency Response: 40 Hz to 20 000 Hz
Line-Out Level/Impedance: 2.5 V/20 kΩ load (full scale)
Signal-to-Noise Ratio: 70 dB
Other Terminal: AUX (auxiliary) input jack
Tuner section
Frequency Range:
FM: 87.5 MHz to 108.0 MHz
FM-LO: 65.00 MHz to 74.00 MHz
AM: MW:522 kHz to 1 620 kHz
LW: 144 kHz to 279 kHz
[FM Tuner]
Usable Sensitivity: 11.3 dBf (1.0 μV/75 Ω)
50 dB Quieting Sensitivity: 16.3 dBf (1.8 μV/75 Ω)
Alternate Channel Selectivity (400 kHz): 65 dB
Frequency Response: 40 Hz to 15 000 Hz
Stereo Separation: 30 dB
[MW Tuner]
Sensitivity/Selectivity: 20 μV/35 dB
[LW Tuner]
Sensitivity: 50 μV
SPECIFICATIONS
CD player section
Type: Compact disc player
Signal Detection System: Non-contact optical pickup
(semiconductor laser)
Number of channels: 2 channels (stereo)
Frequency Response: 5 Hz to 20 000 Hz
Dynamic Range: 93 dB
Signal-to-Noise Ratio: 98 dB
Wow and Flutter: Less than measurable limit
MP3 Decoding Format: (MPEG1/2 Audio Layer 3)
Max. Bit Rate: 320 kbps
WMA (Windows Media® Audio) Decoding Format:
Max. Bit Rate: 192 kbps
General
Power Requirement: Operating Voltage: DC 14.4 V
(11 V to 16 V allowance)
Grounding System: Negative ground
Allowable Operating Temperature: 0°C to +40°C
Dimensions (W × H × D):
Installation Size (approx.):
182 mm × 52 mm × 160 mm
Panel Size (approx.):
188 mm × 58 mm × 13 mm
Mass (approx.):
1.3 kg(excluding accessories)
Design and specifications are subject to change without
notice.
• Microsoft and Windows Media are either registered
trademarks or trademarks of Microsoft Corporation in the
United States and/or other countries.
TROUBLESHOOTING
Symptoms Remedies/Causes
General
• Sound cannot be heard from the speakers. • Adjust the volume to the optimum level.
• Check the cords and connections.
• This unit does not work at all. Reset the unit.
• “AUX IN” cannot be selected. Check the “SRC SELECT” =“AUX IN” setting (see “Menu
operation”).
• Display appears dim. Check the USER Color settings. (For KD-R37)
FM/AM
• SSM automatic presetting does not work. Store stations manually.
• Static noise while listening to the radio. Connect the aerial firmly.
• “AM” cannot be selected. Check the “SRC SELECT” =“AM” setting (see “Menu
operation”).
Disc playback
• Disc cannot be played back. Insert the disc correctly.
• CD-R/CD-RW cannot be played back.
• Tracks on the CD-R/CD-RW cannot be
skipped.
• Insert a finalized CD-R/CD-RW.
• Finalize the CD-R/CD-RW with the component which you used for
recording.
• Disc can be neither played back nor
ejected.
• Unlock the disc.
• Eject the disc forcibly.
• Disc sound is sometimes interrupted. • Stop playback while driving on rough roads.
• Change the disc.
• Check the cords and connections.
• “NO DISC” appears on the display. Insert a playable disc into the loading slot.
• “PLEASE” and “EJECT” appear alternately
on the display.
Press 0, then insert a disc correctly.
MP3/WMA playback
• Disc cannot be played back. • Use a disc with MP3/WMA tracks recorded in a format compliant
with ISO 9660 Level 1, Level 2, Romeo, or Joliet.
• Add the extension code <.mp3> or <.wma> to the file names.
• Noise is generated. Skip to another track or change the disc. (Do not add the extension
code <.mp3> or <.wma> to non-MP3 or WMA tracks.)
• A longer readout time is required
(“READING” keeps flashing on the display).
Do not use too many hierarchical levels and folders.
• Tracks are not played back in the order you
have intended.
Playback order is determined when the files are recorded.
• The elapsed playing time is not correct. This sometimes occurs during playback. This is caused by how the
tracks are recorded on the disc.
• The correct characters are not displayed
(e.g. album name).
This unit can only display Roman letters (upper case), Cyrillic
alphabets (upper case), numbers, and a limited number of symbols.
Creating your own color—USER Color (For KD-R37)
You can create your own colors—“DAY COLOR” or “NIGHT COLOR.”
DAY COLOR:Used when “DIMMER” is set to “DIMMER OFF.”
NIGHT COLOR:Used when “DIMMER” is set to “DIMMER ON.”
Select “COLOR” =“USER.”
While “USER” is shown on the display...
Exit from the setting.
Menu operations
Menu items Selectable settings
DEMO
DEMO • DEMO ON: The display demonstration will be activated automatically if no operation is done
for about 20 seconds.
• DEMO OFF: Cancels.
CLOCK
CLOCK
DISP*1
• CLOCK ON: The clock time is shown on the display at all times when the power is turned off.
• CLOCK OFF: Cancels; pressing DISP will show the clock time for about 5 seconds when the
power is turned off.
CLOCK SET : Adjust the hour, then the minute. [Initial: 0:00]
24H/12H • 24 HOUR
• 12 HOUR
CLOCK ADJ*2• AUTO: The built-in clock is automatically adjusted using the CT (clock time) data in the Radio
Data System signal.
• OFF: Cancels
EQ
EQ : Select a preset sound mode suitable to the music genre.
USER, ROCK, CLASSIC, POPS, HIP HOP, JAZZ
DISPLAY
DIMMER • DIMMER ON: Dims the display and button illumination.
• DIMMER OFF: Cancels.
SCROLL*3• SCROLL ONCE: Scrolls the displayed information once.
• SCROLL AUTO: Repeats scrolling (at 5-second intervals).
• SCROLL OFF: Cancels.
Pressing DISP for more than one second can scroll the display regardless of the setting.
TAG DISPLAY • TAG ON: Shows the Tag information while playing MP3/WMA tracks.
• TAG OFF: Cancels.
TUNER
AF-REG*4• AF ON: When the currently received signals become weak, the unit switches to another station
(the programme may differ from the one currently received). (The AF indicator lights up.)
• AF-REG ON: When the currently received signals become weak, the unit switches to another
station broadcasting the same programme. (The AF and REG indicators light up.)
• OFF: Cancels.
PTY-
STANDBY*4
PTY OFF, PTY codes: Activates PTY Standby Reception with one of the PTY codes. (Refer to “Radio
operations” on page 2 for PTY codes.)
TA VOLUME*4VOLUME 00 – VOLUME 50 (or VOLUME 00 – VOLUME 30)*5 [Initial: VOLUME 15]
P-SEARCH*4• SEARCH ON: Activates Programme Search.
• SEARCH OFF: Cancels.
MONO*6• MONO ON: Activate monaural mode to improve FM reception, but stereo effect will be lost.
• MONO OFF: Restore the stereo effect.
IF BAND • AUTO: Increases the tuner selectivity to reduce interference noises between adjacent stations.
(Stereo effect may be lost.)
• WIDE: Subject to interference noises from adjacent stations, but sound quality will not be
degraded and the stereo effect will remain.
COLOR
(For KD-R37)
COLOR 01
– COLOR 29,
USER
: Select one of the preset or user color for display and button (except T/P/ /0)
illumination. (See also “Creating your own color—USER color.”)
MENU COLOR
(For KD-R37)
MENU COLOR • OFF: Cancels.
• ON: Changes the display and button (except T/P//0) illumination during menu, list
search and playback mode operations.
AUDIO
FADER*7R06 – F06: Adjust the front and rear speaker output balance. [Initial: 00]
BALANCE L06 – R06: Adjust the left and right speaker output balance. [Initial: 00]
LOUD • LOUD OFF: Cancels.
• LOUD ON: Boost low and high frequencies to produce a well-balanced sound at a low volume
level.
AUX ADJUST AUX ADJ 00 – AUX ADJ 05: Adjust the auxiliary input level to avoid the sudden increase of the
output level when changing the source to external component connected to the AUX input jack
on the control panel.
BEEP • BEEP ON: Activates the keypress tone.
• BEEP OFF: Deactivates the keypress tone.
TEL MUTING • MUTING OFF: Cancels.
• MUTING 1/MUTING 2: Select either one which mutes the sounds while using a cellular phone.
AMP GAIN*8• HIGH POWER: VOLUME 00 – VOLUME 50
• LOW POWER: VOLUME 00 – VOLUME 30 (Select if the maximum power of each speaker is less
than 50 W to prevent damaging the speaker.)
SRC SELECT
AM*9• AM OFF: Disable “AM” in source selection.
• AM ON: Enable “AM” in source selection.
AUX IN*10 • AUX OFF: Disable “AUX IN” in source selection.
• AUX ON: Enable “AUX IN” in source selection.
*1If the power supply is not interrupted by turning off the ignition key of your car, it is recommended to select “CLOCK
OFF” to save the car’s battery.
*2Takes effect only when CT (clock time) data is received.
*3Some characters or symbols will not be shown correctly (or will be blanked) on the display.
*4Only for FM Radio Data System stations.
*5Depends on the amplifier gain control.
*6Displayed only when the source is “FM.”
*7If you are using a two-speaker system, set the fader level to “00.”
*8The volume level automatically changes to “VOLUME 30” if you change to “LOW POWER” with the volume level is set
higher than “VOLUME 30.”
*9Displayed only when any source other than “AM” is selected.
*10 Displayed only when any source other than “AUX IN” is selected.
Repeat step 2 if necessary.
• To return to the previous menu, press
BACK.
Initial: Underlined
Available characters on the display
Available characters Display indications
1
2
3Adjust the level (00 to 31) of the selected primary color.
4Repeat steps 1to 3to adjust other primary colors.
EN_KD-R307_R37[EE]_f.indd 3EN_KD-R307_R37[EE]_f.indd 3 18/9/08 2:48:28 PM18/9/08 2:48:28 PM

4 – EN
INSTALLATION / CONNECTION
In dash-mounting
Do the required electrical
connections.
Bend the appropriate tabs
to hold the sleeve firmly in
place.
When you stand the unit, be careful not
to damage the fuse on the rear.
Removing the unit
Before removing the unit, release the rear section.
When using the optional stay
Install the unit at an angle of less
than 30˚.
Screw (option)
Stay (option)
Fire wall
Dashboard
When installing the unit without using the sleeve
Flat type screws
(M5 × 8 mm)*
Pocket
Flat type screws (M5 × 8 mm)*
Bracket*
Bracket*
* Not supplied for this unit.
In a Toyota car for example, first remove the car radio and install the unit in its place.
TROUBLESHOOTING
• The fuse blows.
* Are the red and black leads connected correctly?
• Power cannot be turned on.
* Is the yellow lead connected?
• No sound from the speakers.
* Is the speaker output lead short-circuited?
• Sound is distorted.
* Is the speaker output lead grounded?
* Are the “–” terminals of L and R speakers grounded in
common?
• Noise interfere with sounds.
* Is the rear ground terminal connected to the car’s
chassis using shorter and thicker cords?
• This unit becomes hot.
* Is the speaker output lead grounded?
* Are the “–” terminals of L and R speakers grounded in
common?
• This unit does not work at all.
* Have you reset your unit?
ELECTRICAL CONNECTIONS
Purple
Front speaker
(left)
To the remote lead of other equipment or
power aerial if any (200 mA max.)
Blue with white
stripe
Red To an accessory terminal in
the fuse block
To a live terminal in the
fuse block connecting to the
car battery (bypassing the
ignition switch) (constant
12 V)
Yellow *2
To the metallic body or
chassis of the car
Black Ignition switch
15 A fuse
Fuse block
Rear speaker
(left)
Rear speaker
(right)
Front speaker
(right)
White with black stripe
Rear ground terminal
Aerial
terminal
Gray with black stripe
Green
Gray
Green with black stripe
Purple with black stripe
White
Connections without using the ISO connector
Use the front speaker lead if your speaker
system is two-speaker system.
To cellular phone system
Brown
Rear line out
Before connecting: Check the wiring in the vehicle carefully. Incorrect connection may cause serious damage to this
unit. The leads of the power cord and those of the connector from the car body may be different in color.
*1Not supplied for this unit.
*2Before checking the operation of this unit prior to installation, this lead must be connected, otherwise the power cannot
be turned on.
*3Firmly attach the ground wire to the metallic body or to the chassis of the car—to the place uncoated with paint (if
coated with paint, remove the paint before attaching the wire). Failure to do so may cause damage to the unit.
*4Cut the rear speaker leads of the car’s ISO connector and connect them to the amplifier.
Rear
speakers
Remote lead
Remote lead (blue with white stripe)
To the remote lead of
other equipment or
power aerial if any
Y-connector *1
JVC Amplifier
Connecting the external amplifier
Front speakers
Rear speakers
Signal cord *1
EF
B
D
H
G
A
C
N
J
I
K
M
L
P
O
• Connect the ISO connectors as illustrated.
From the car body
ISO connector of the supplied power cord
View from the lead side
You may need to modify the wiring of the supplied power cord as illustrated.
• Contact your authorized car dealer before installing this unit.
Original wiring Modified wiring 1
Use modified wiring 2if the unit does not turn on.
ISO
connector
Y: Yellow R: Red
Modified wiring 2
If your car is equipped with the ISO connector
For some VW/Audi or Opel (Vauxhall) automobile
PRECAUTIONS on power supply and speaker connections
PREPARATION
This unit is designed to operate on 12 V DC, NEGATIVE ground electrical
systems. If your vehicle does not have this system, a voltage inverter is required,
which can be purchased at JVC IN-CAR ENTERTAINMENT dealers.
WARNINGS
To prevent short circuits, we recommend that you disconnect the battery’s negative terminal and make all electrical
connections before installing the unit.
• Be sure to ground this unit to the car’s chassis again after installation.
Notes:
• Replace the fuse with one of the specified rating. If the fuse blows frequently, consult your
JVC IN-CAR ENTERTAINMENT dealer.
• It is recommended to connect to the speakers with maximum power of more than 50 W
(both at the rear and at the front, with an impedance of 4Ω to 8 Ω). If the maximum power
is less than 50 W, change “AMP GAIN” setting to prevent the speakers from being
damaged (see “Menu operation”).
• To prevent short-circuit, cover the terminals of the UNUSED leads with insulating tape.
• The heat sink becomes very hot after use. Be careful not to touch it when removing this unit.
Parts list for installation and connection
INSTALLATION
The following illustration shows a typical installation. If you have any questions or require information regarding installation
kits, consult your JVC IN-CAR ENTERTAINMENT dealer or a company supplying kits.
• If you are not sure how to install this unit correctly, have it installed by a qualified technician.
Heat sink
ÎTrim plate ................................................................ 1
‰Power cord............................................................... 1
ÏHandles.................................................................... 2
ÅControl panel ........................................................... 1
ıHard case ................................................................. 1
ÇSleeve ...................................................................... 1
* Not supplied for this unit.
Rubber cushion*
Mounting bolt (M4 × 5 mm;
M5 × 12.5 mm)*
Mounting bolt (M4 × 5 mm;
M5 × 12.5 mm)*
*Not supplied for this unit.
Lock nut (M5)*
Washer (ø5)*
EN_KD-R307_R37[EE]ff.indd 4EN_KD-R307_R37[EE]ff.indd 4 4/13/09 3:03:42 PM4/13/09 3:03:42 PM
