JVC KD-LX10 User manual

ENGLISH
LVT0393-001A
[J]
ESPAÑOL
FRANÇAIS
CD RECEIVER KD-LX10
RECEPTOR CON CD KD-LX10
RECEPTEUR CD KD-LX10
For customer Use:
Enter below the Model No. and
Serial No. which are located on
the top or bottom of the cabinet.
Retainthisinformationforfuture
reference.
Model No.
Serial No.
INSTRUCTIONS
MANUAL DE INSTRUCCIONES
MANUEL D’INSTRUCTIONS
For installation and connections, refer to the separate manual.
Para la instalación y las conexiones, refiérase al manual separado.
Pour l’installation et les raccordements, se référer au manuel séparé.
ATT
S
S
M
KD-LX10
SOURCE
BBE
MODE BAND
DISP
INTLOCALMONOSCM
10789 11 12
RPT RND
OFFSEL
EN00.KD-LX10[J]/f 99.12.25, 4:06 PM3

2
ENGLISH
INFORMATION (For U.S.A.)
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particularinstallation.Ifthisequipmentdoescauseharmfulinterferencetoradioortelevision
reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
– Connect theequipment into anoutlet on acircuit different from thatto which thereceiver
is connected.
– Consult the dealer or an experienced radio/TV technician for help.
IMPORTANT FOR LASER PRODUCTS
Precautions:
1. CLASS 1 LASER PRODUCT
2. DANGER: Invisible laser radiation when open and interlock failed or defeated.Avoid direct
exposure to beam.
3. CAUTION: Do not open the top cover.There are no user-serviceable parts inside. Leave
all servicing to qualified service personnel.
4. CAUTION: This CD player uses invisible laser radiation, however, is equipped with safety
switches to prevent radiation emission when unloading CDs. It is dangerous to defeat the
safety switches.
5. CAUTION: Use of controls, adjustments or performance of procedures other than those
specified herein may result in hazardous radiation exposure.
How to reset your unit
Press the reset button on the front panel using a ball-point
pen or a similar tool.
This will reset the built-in microcomputer.
NOTE:
Your preset adjustments — such as preset channels or sound
adjustments — will also be erased.
BEFORE USE
* For safety....
• Do not raise the volume level too much, as this
will block outside sounds, making driving
dangerous.
• Stop the car before performing any complicated
operations.
* Temperature inside the car....
If you have parked the car for a long time in hot
or cold weather, wait until the temperature in the
car becomes normal before operating the unit.
EN02-05.LX10[J]/f 99.12.25, 4:06 PM2

3
ENGLISH
Thank you for purchasing a JVC product. Please read all instructions carefully before operation, to
ensure your complete understanding and to obtain the best possible performance from the unit.
CONTENTS
BASIC OPERATIONS .................................................... 5
RADIO OPERATIONS ...................................................6
Listening to the radio ..................................................................... 6
Searching a station automatically: Auto search ........................... 6
Searching a station manually:Manual search ............................. 7
Storing stations in memory ............................................................8
FM station automatic preset: SSM...............................................8
Manual preset.............................................................................. 9
Tuning into a preset station ......................................................... 10
CD OPERATIONS....................................................... 11
Playing a CD ................................................................................. 11
Playing a CD Text ......................................................................... 12
Locating a track or a particular portion on a CD ..................... 13
Selecting CD playback modes......................................................14
Prohibiting CD ejection ............................................................... 15
SOUND ADJUSTMENTS .............................................16
Adjusting the sound......................................................................16
Turning on/off the BBEII function ............................................... 17
Using the Sound Control Memory ..............................................18
Selecting and storing the sound modes..................................... 18
Recalling the sound modes........................................................19
Storing your own sound adjustments .........................................20
OTHER MAIN FUNCTIONS .........................................21
Setting the clock ............................................................................21
Controlling the volume automatically (Audio Cruise) ..............22
Changing the general settings (PSM) ......................................... 24
Assigning names to the sources ...................................................28
REMOTE OPERATIONS...............................................30
Installing the battery ....................................................................30
Using the remote controller ......................................................... 31
CD CHANGER OPERATIONS ......................................32
Playing CDs ................................................................................... 32
Selecting CD playback modes......................................................34
To be continued on the next page
EN02-05.LX10[J]/f 99.12.25, 4:06 PM3

4
ENGLISH
EXTERNAL COMPONENT OPERATIONS ..................... 36
Playing an external component ...................................................36
MAINTENANCE......................................................... 37
Handling CDs................................................................................37
TROUBLESHOOTING ................................................. 38
SPECIFICATIONS ....................................................... 39
To activate the display demonstration
While holding DISP, press ¢until “DEMO”appears on the
lower part of the display.
Various functions and display illumination modes equipped for
this unit will be demonstrated repeatedly in sequence.
During the display demonstration, “DEMO” flashes on the lower
part of the display.
To turn off the display demonstration, press ¢again for a
few seconds while holding DISP.
• Thedisplaydemonstrationwillturnoffautomatically after1hour.
How to use the number buttons:
After pressing MODE, the number buttons work as different function buttons (while
“MODE” remains on the display).
To use these buttons as number buttons after pressing MODE, wait for 5 seconds
without pressing any number button so that“MODE” disappears from the display.
• Pressing MODE again also erases “MODE” from the display.
EN02-05.LX10[J]/f 99.12.25, 4:06 PM4

5
ENGLISH
BASIC OPERATIONS
Note:
When you use this unit for the
firsttime,setthe built-in clock
correctly, see page 21.
1
Turn on the power.
The display illuminates and the control panel comes out.
2
Select the source.
Each time you press the button, the source changes as follows:
=Tuner (FM or AM) =CD* =CD changer or External component**
=(back to the beginning)
To operate the tuner, see pages 6 – 10.
To operate the CD player, see pages 11 – 15.
To operate the CD changer, see pages 32 – 35.
To operate the external component, see page 36.
Notes:
*If a CD is not in the loading slot, you cannot select CD as the source to play.
** Without connecting the equipment and setting “EXT INPUT” correctly (see page 25), you
cannot select it as the source to play.
3
Adjust the volume.
4
Adjust the sound as you want (see pages 16 – 20).
To drop the volume in a moment
Press SOURCE (ATT) for more than 1 second while listening to any source. “ATT” starts
flashing on the display, and the volume level will drop in a moment.
To resume the previous volume level, press the button for more than 1 second again.
To turn off the power
Press and hold OFF/ 0until “SEEYOU” appears on the display.
12
3
Volume level meter
Equalization pattern (see page 16)
EN02-05.LX10[J]/f 99.12.25, 4:06 PM5

6
ENGLISH
RADIO OPERATIONS
Listening to the radio
You can use either automatic searching or manual searching to tune into a particular station.
Searching a station automatically: Auto search
1
Select the band.
1Press SOURCE (ATT) to select the tuner as the source.
2Press BAND to select the band (FM1, FM2, FM3 or AM).
Each time you press the button, the band changes as
follows:
Note:
This receiver has three FM bands (FM1, FM2, FM3).You can use any one of them to listen
to an FM broadcast.
2
Start searching a station.
When a station is received, searching stops.
To stop searching before a station is received, press the same button you have pressed
for searching.
To tune in FM stations only with strong signals
This function works only while searching FM stations, including SSM preset (see page 8).
1Press MODE.
“MODE” appears on the lower part of the display, and the number buttons can work as
different function buttons.
2Press LOCAL, while “MODE”is still on the display, so that the LOCAL indicator lights up on
the display.
Each time you press the button, the LOCAL indicator lights up and goes off alternately.
12
2
1- 1 1- 2
LOCAL MODE
FM1 FM2 FM3 AM
To search stations of
lower frequencies
To search stations of
higher frequencies
Selected band appears.
EN06-10.LX10[J]/f 99.12.25, 4:07 PM6

7
ENGLISH
Searching a station manually: Manual search
1
Select the band.
1Press SOURCE (ATT) to select the tuner as the source.
2Press BAND to select the band (FM1, FM2, FM3 or AM).
Note:
This receiver has three FM bands (FM1, FM2, FM3). You can use any one of them to listen
to an FM broadcast.
2
Press and hold ¢or 4until “M” (Manual)
starts flashing on the display.
3
Tune into a station you want while
“M” is flashing.
• If you release your finger from the button, the
manual mode will automatically turn off after
5 seconds.
When an FM stereo broadcast is hard to receive:
1Press MODE while listening to an FM stereo broadcast (the ST indicator lights up while
receiving an FM stereo broadcast).
“MODE” appears on the lower part of the display, and the number buttons can work as
different function buttons.
2Press MONO (monaural), while “MODE” is still on the display, so that the MO indicator
lights up on the display.
The sound you hear becomes monaural but reception will be improved (the ST indicator
goes off).
Each time you press the button, the MO indicator lights up and goes off alternately.
12
To tune into stations
of lower frequencies
To tune into stations
of higher frequencies
2
1- 1 1- 2
MODE
MONO
EN06-10.LX10[J]/f 99.12.25, 4:07 PM7

8
ENGLISH
1
Select the FM band number (FM1, FM2 or
FM3) you want to store FM stations into.
1Press SOURCE (ATT) to select the tuner as the
source.
2Press BAND to select the band (FM1, FM2, or FM3).
2
Press and hold both buttons for more than
2 seconds.
Local FM stations with the strongest signals are searched and stored automatically in the
band number you have selected (FM1, FM2 or FM3).These stations are preset in the number
buttons — No. 1 (lowest frequency) to No. 6 (highest frequency).
When automatic preset is over, the station stored in number button 1 will be automatically
tuned in.
Storing stations in memory
You can use one of the following two methods to store broadcasting stations in memory.
• Automatic preset of FM stations:SSM (Strong-station Sequential Memory)
• Manual preset of both FM and AM stations
FM station automatic preset: SSM
You can preset 6 local FM stations in each FM band (FM1, FM2 and FM3).
12
“SSM” appears, then disappears when automatic preset is over.
1- 1 2 1- 2
FM1 FM2 FM3 AM
EN06-10.LX10[J]/f 99.12.25, 4:07 PM8

9
ENGLISH
Manual preset
You can preset up to 6 stations in each band (FM1, FM2, FM3 and AM) manually.
EXAMPLE: Storing an FM station of 88.3 MHz into the preset number 1 of the FM1 band
1
Select the band.
1Press SOURCE (ATT) to select the tuner as the source.
2Press BAND to select the FM1 band.
2
Tune into a station of 88.3 MHz.
See page 6 to tune into a station.
3
Press and hold the number button (in this example, 1)
for more than 2 seconds.
4
Repeat the above procedure to store other stations into other
preset numbers.
Notes:
• A previously preset station is erased when a new station is stored in the same preset number.
• Preset stations are erased when the power supply to the memory circuit is interrupted (for example,
during battery replacement). If this occurs, preset the stations again.
12
23 1-
1 1- 2
FM band number and “MEMO”
appear alternately for a while.
EN06-10.LX10[J]/f 99.12.25, 4:07 PM9

10
ENGLISH
Tuning into a preset station
You can easily tune into a preset station.
Remember that you must store stations first. If you have not stored them yet, see pages 8
and 9.
1
Select the band.
1Press SOURCE (ATT) to select the tuner as the source.
2Press BAND to select the band (FM1, FM2, FM3 or AM).
2
Select the number (1 – 6) for the preset station you want.
When using this unit in an area other than North or South America:
You need to change the AM/FM channel intervals. See “To change the AM/FM channel
intervals” on page 27.
12
1- 1 1- 2
2 2
EN06-10.LX10[J]/f 99.12.25, 4:07 PM10

11
ENGLISH
CD OPERATIONS
Playing a CD
Current track Elapsed
playing time
Total playing time of
the inserted disc
Total track number
of the inserted disc
1
Open the loading slot.
The display panel moves down, and the loading slot appears.
2
Insert a disc into the loading slot.
The unit draws a CD, the display panel moves up, and CD play starts
automatically.
Notes:
• When a CD is in the loading slot, selecting “CD” as the source by pressing SOURCE (ATT) starts
CD play.
• When a CD is inserted upside down, “CD EJECT”appears on the display and the CD automatically
ejects.
• When you play a CD Text, the disc title and performer appear on the display. Then the current track
and elapsed playing time appear on the display. See also “Playing a CD Text” (page 12) and “To
select the scroll mode” (page 27).
If a CD Text includes much text information, some may not appear on the display.
• If you change the source, the CD play also stops (without ejecting the CD).
To stop play and eject the CD
Press OFF/0briefly.
CDplaystops,thedisplay panel moves down,thentheCD automaticallyejectsfromtheloading
slot.
To move up the display panel, press ¢or 4.
CAUTION: NEVER insert your finger between the display panel
and the unit, as it may get caught in the unit.
Note:
If the ejected disc is not removed for about 15 seconds, the disc is automatically inserted again into the
loading slot to protect it from dust. (CD play will not start this time.)
1
¢
4
EN11-15.LX10[J]/f 99.12.25, 4:08 PM11

12
ENGLISH
Select text display mode while playing a CD Text.
Each time you press the button, the display changes as follows:
Notes:
• The display shows up to 10 characters at one time and scrolls if there are more than 10 characters.
See also “To select the scroll mode” on page 27.
Some characters or symbols will not be shown (and be blanked) on the display.
(Ex. “ABCå!d#”]“ABCA D ”)
• When you press DISP while playing a conventional CD, “NO NAME” appears for the disc title/
performer and the track title.
Disc Title / Performer Track Title
Current track no.
and Elapsed playing time
Playing a CD Text
Ina CDText,someinformationaboutthedisc(itsdisc title,performerand tracktitle)is recorded.
You can show these disc information on the display.
DISP
EN11-15.LX10[J]/f 99.12.25, 4:08 PM12

13
ENGLISH
To fast-forward or reverse the track
Press and hold ¢, while playing a CD, to fast-forward the track.
Press and hold 4, while playing a CD, to reverse the track.
To go to the next tracks or the previous tracks
Press ¢briefly, while playing a CD, to go ahead to the beginning of
thenext track.Eachtime you pressthebuttonconsecutively,the beginning
of the next tracks is located and played back.
Press 4briefly, while playing a CD, to go back to the beginning of
the current track. Each time you press the button consecutively, the
beginning of the previous tracks is located and played back.
To go to a particular track directly
Press the number button corresponding to the track number to start its
playback.
• To select a track number from 1 – 6:
Press 1 (7) – 6 (12) briefly.
• To select a track number from 7 – 12:
Press and hold 1 (7) – 6 (12) for more than 1 second.
Locating a track or a particular portion on a CD
Number buttons
1(7) to 3 (9) Number buttons
4 (10) to 6 (12)
¢
4
EN11-15.LX10[J]/f 99.12.25, 4:08 PM13

14
ENGLISH
Selecting CD playback modes
To play back tracks at random (Random Play)
You can play back all tracks on the CD at random.
1Press MODE while playing a CD.
“MODE”appears on the lower part of the display, and the number buttons
can work as different function buttons.
2Press RND (Random), while “MODE” is still on the display, so that the
RND indicator lights up on the display.
Each time you press the button, CD random play mode turns on and off
alternately.
When the random mode is turned on, the RND indicator lights up on the
display and a track randomly selected starts playing.
To play back tracks repeatedly (Repeat Play)
You can play back the current track repeatedly.
1Press MODE while playing a CD.
“MODE”appears on the lower part of the display, and the number buttons
can work as different function buttons.
2Press RPT (Repeat), while“MODE”is still on the display, so that the RPT
indicator lights up on the display.
Each time you press the button, CD repeat play mode turns on and off
alternately.
When the repeat mode is turned on, the RPT indicator lights up on the
display. Track number of the currently playing track
RND
RPTMODE INT
EN11-15.LX10[J]/f 99.12.25, 4:08 PM14

15
ENGLISH
To play back only intros (Intro Scan)
You can play back the first 15 seconds of each track sequentially.
1Press MODE while playing a CD.
“MODE” appears on the lower part of the display, and the number buttons
can work as different function buttons.
2Press INT (Intro), while“MODE” is still on the display.
Each time you press the button, CD intro scan mode turns on and off
alternately.
When the intro scan mode is turned on, “INT” appears on the display for
5 seconds and the track number flashes.
Prohibiting CD ejection
You can prohibit CD ejection and can lock a CD in the loading slot.
WhilepressingSOURCE(ATT),press and hold OFF/0formorethan2seconds.“NOEJECT”
flashes on the display for about 5 seconds, and the CD is locked and cannot be ejected.
Note:
If you press OFF/0while CD ejection is prohibited,the control panel moves down, but the CD cannot
be ejected. (“NO EJECT” appears on the display.)
To move up the display panel, press ¢or 4.
To cancel the prohibition and unlock the CD, press and hold OFF/0for more than 2
seconds again, while pressing SOURCE (ATT).“EJECT OK” flashes on the display for about
5 seconds, and the CD is unlocked.
Track number of the currently playing track
OFF/0
SOURCE (ATT)
EN11-15.LX10[J]/f 99.12.25, 4:08 PM15

16
ENGLISH
SOUND ADJUSTMENTS
Adjusting the sound
You can adjust the sound characteristics to your preference.
1
Select the item you want to adjust.
Eachtimeyou press the button,the adjustableitems change asfollows:
Indication To do: Range
BASS Adjust the bass. –06 (min.) — +06 (max.)
TREBLE Adjust the treble. –06 (min.) — +06 (max.)
FADER* Adjust the front and rear speaker R06(Rear only)— F06 (Frontonly)
balance.
BAL(ance) Adjust the left and right speaker L06 (Left only) — R06 (Right only)
balance.
VOLUME Adjust the volume. 00 (min.) — 50 (max.)
Note:
*If you are using a two-speaker system, set the fader level to “00.”
2
Adjust the level.
Note:
Normally + / – button works as the volume control. So you do not
have to select “VOLUME” to adjust the volume level.
12
TREBLEBASS FADER
BAL(ance)VOLUME
Equalization pattern changes as you adjust the bass or treble.
EN16-20.LX10[J]/f 99.12.25, 4:09 PM16

ENGLISH
17
Turning on/off the BBEII function
The BBEII* function restores the brilliance and clarity of the original live sound in recording,
broadcasts, etc.
Whena speakerreproducessound, it introducesfrequency-dependent phase shifting,causing
high-frequency sounds to take longer to reach the ear than low frequency sounds.The BBEII
function adjusts the phase relationship between the low, mid and high frequencies by adding
a progressively longer delay time to the low and mid frequencies, so that all frequencies
reach the listener’s ears at the proper time.
In addition, the BBEII function boosts low and high frequencies, which loudspeakers tend to
be less efficient in reproducing, through dynamic, program-driven augmentation. When
combined with the phase compensation feature, the resulting sound has a clearer, more
finely detailed “live” presence.
Each time you press BBE, the BBEII function changes as follows.
As the number gets higher, the BBEII function becomes stronger.
When shipped from the factory, the BBEII function is set to “BBE 2.”
To cancel the BBEII function, select “BBE OFF.”
*Under license from BBE Sound, Inc.
Ris a trademark of BBE Sound, Inc.
BBE
BBE 1 BBE 2 BBE 3 BBE OFF
EN16-20.LX10[J]/f 99.12.25, 4:09 PM17

18
ENGLISH
Using the Sound Control Memory
You can select and store a preset sound adjustment suitable for each playback source.
(Advanced SCM)
Selecting and storing the sound modes
Once you select a sound mode, it is stored in memory, and will be recalled every time you
select the same source. A sound mode can be stored for each of the following sources —
FM1, FM2, FM3, AM, CD and external components.
• If you do not want to store the sound mode separately for each playback source, but want to
use the same sound mode for all the sources, see“To cancel Advanced SCM” on page 26.
1
Light “MODE” on the lower part of the display.
The number buttons can work as different function buttons.
2
Select the sound mode you want.
Each time you press the button, the sound mode changes as follows:
• If the“Link” indicator is lit on the display (with“SCM LINK”set to “LINK
ON” — see page 26), the selected sound mode can be stored in
memory for the current source, and the effect applies to the current
source.
• If the “Link”indicator is NOT lit on the display (with “SCM LINK” set to
“LINK OFF”), the selected sound mode effect applies to any source.
Indication For: Preset values
Bass Treble BBEII
SCM OFF (Flat sound) 00 00 BBE 2
SCM BEAT Rock or disco music +02 00 BBE 2
SCM SOFT Quiet background music +01 –03 Off
SCM POP Light music +04 +01 Off
Within
5 seconds
12
“Link” indicator
SCM BEAT SCM SOFT
SCM POPSCM OFF
EN16-20.LX10[J]/f 99.12.25, 4:09 PM18

ENGLISH
19
Recalling the sound modes
Select the source while the “Link” indicator is
lit on the display.
The“Link”indicatorstarts flashing, andthe sound modestored
in memory for the selected source is recalled (and appears
on the display for a while).
Notes:
• You can adjust each sound mode to your preference, and store it in memory.
If you want to adjust and store your original sound mode, see “Storing your own sound adjustments”
on page 20.
• To adjust the bass and treble reinforcement levels or to turn on/off the BBEII function temporarily,
see pages 16 and 17. (Your adjustments will be canceled if another source is selected.)
• By setting “CLOCK DISP” to “CLOCK OFF” (see page 26), you can always show the current
sound mode setting when the unit is turnd on.
SOURCE (ATT)
EN16-20.LX10[J]/f 99.12.25, 4:09 PM19

20
ENGLISH
Storing your own sound adjustments
You can adjust the sound modes (SCM BEAT, SCM SOFT, SCM POP:see page 18) to your
preference and store your own adjustments in memory.
1
Light “MODE” on the lower part of the display.
The number buttons can work as different function buttons.
REMEMBER you must finish the following steps while “MODE”
is still on the display. Otherwise, the setting will be canceled.
2
Select the sound mode you want.
For details, see page 18.
3
To adjust the bass or treble level
1Select “BASS” or “TREBLE.”
2Adjust the bass or treble level.
To turn on or off the BBEII function
See page 17.
4
Press and hold SCM until the sound mode you have
selected flashes on the display.
Youradjustment madefortheselectedsound mode isstoredin memory.
5
Repeat the same procedure to adjust other sound modes.
To reset to the factory settings
Repeat the same procedure and reassign the preset values listed in the table on page 18.
12,4 33- 2 3- 1
12
EN16-20.LX10[J]/f 99.12.25, 4:09 PM20
