JVC DR-M100S User manual

STANDBY/ON
RAM/RW
PR
+
PR
-
PUSH-OPEN
LPT1024-001B EN
DVD VIDEO RECORDER
INSTRUCTIONS
DR-M100S
M100SEK_00.book Page 1 Tuesday, March 22, 2005 5:31 PM

Filename [M100SEK_02Safety.fm]
Masterpage:Left0
2EN
Page 2Tuesday, 22 March 2005 17:31
SAFETY FIRST
The rating plate and the safety caution are on the rear of the unit.
WARNING: DANGEROUS VOLTAGE INSIDE
WARNING: TO PREVENT FIRE OR SHOCK HAZARD,
DO NOT EXPOSE THIS UNIT TO RAIN OR
MOISTURE.
CLASS 1 LASER PRODUCT
REPRODUCTION OF LABELS
WARNING LABEL INSIDE OF THE UNIT
●Manufactured under licence from Dolby Laboratories. ADolbyBand double-D symbol are trademarks of Dolby Laboratories.
●ADTSBand ADTS DIGITAL OUTBare trademarks of Digital Theater Systems, Inc.
●VIDEO Plus+ and PlusCode are registered trademarks of Gemstar Development Corporation. The VIDEO Plus+ system is manufactured
under license from Gemstar Development Corporation.
●This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents and other intellectual
property rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection technology must be
authorized by Macrovision Corporation, and is intended for home and other limited viewing users only unless otherwise authorized by
Macrovision Corporation. Reverse engineering or disassembly is prohibited.
Safety Precautions
CAUTION:
A UNIT IS A CLASS 1 LASER PRODUCT. HOWEVER THIS
UNIT USES A VISIBLE LASER BEAM WHICH COULD CAUSE
HAZARDOUS RADIATION EXPOSURE IF DIRECTED. BE
SURE TO OPERATE THE UNIT CORRECTLY AS
INSTRUCTED.
WHEN THIS UNIT IS PLUGGED INTO THE WALL OUTLET,
DO NOT PLACE YOUR EYES CLOSE TO THE OPENING OF
THE DISC TRAY AND OTHER OPENINGS TO LOOK INTO
THE INSIDE OF THIS UNIT.
USE OF CONTROLS OR ADJUSTMENTS OR
PERFORMANCE OF PROCEDURES OTHER THAN THOSE
SPECIFIED HEREIN MAY RESULT IN HAZARDOUS
RADIATION EXPOSURE.
DO NOT OPEN COVERS AND DO NOT REPAIR YOURSELF.
REFER SERVICING TO QUALIFIED PERSONNEL.
OR
IMPORTANT:
8Please read the various precautions on page 2 -4 before
installing or operating the unit.
8It should be noted that it may be unlawful to re-record pre-
recorded tapes, DVDs, or discs without the consent of the
owner of copyright in the sound or video recording,
broadcast or cable programme and in any literary, dramatic,
musical, or artistic work embodied therein.
CAUTION:
8When you are not using the unit for a long period of time, it is
recommended that you disconnect the power cord from the
mains outlet.
8Dangerous voltage inside. Refer internal servicing to
qualified service personnel. To prevent electric shock or fire
hazard, remove the power cord from the mains outlet prior to
connecting or disconnecting any signal lead or aerial.
M100SEK_00.book Page 2 Tuesday, March 22, 2005 5:31 PM

Masterpage:Right+
EN 3
Filename [M100SEK_02Safety.fm]
Page 3Tuesday, 22 March 2005 17:31
SAFETY FIRST
When the equipment is installed in a cabinet or a shelf, make sure
that it has sufficient space on all sides to allow for ventilation
(10 cm or more on both sides, on top and at the rear).
When discarding batteries, environmental problems must be
considered and the local rules or laws governing the disposal of
these batteries must be followed strictly.
Failure to heed the following precautions may result in
damage to the unit, remote control or disc.
1. DO NOT place the unit ^
^in an environment prone to extreme temperatures or
humidity.
^in direct sunlight.
^in a dusty environment.
^in an environment where strong magnetic fields are
generated.
^on a surface that is unstable or subject to vibration.
2. DO NOT block the unit’s ventilation openings or holes.
(If the ventilation openings or holes are blocked by a
newspaper or cloth, etc., the heat may not be able to get out.)
3. DO NOT place heavy objects on the unit or remote control.
4. DO NOT place anything which might spill on top of the unit
or remote control.
(If water or liquid is allowed to enter this equipment, fire or
electric shock may be caused.)
5. DO NOT expose the apparatus to dripping or splashing.
6. DO NOT use this equipment in a bathroom or places with
water. Also DO NOT place any containers filled with water or
liquids (such as cosmetics or medicines, flower vases, potted
plants, cups, etc.) on top of this unit.
7. DO NOT place any naked flame sources, such as lighted
candles, on the apparatus.
8. AVOID violent shocks to the unit during transport.
MOISTURE CONDENSATION
Moisture in the air will condense on the unit when you move it from
a cold place to a warm place, or under extremely humid
conditions^just as water droplets form on the surface of a glass
filled with cold liquid. In conditions where condensation may occur,
disconnect the unit’s power plug from the wall and keep it
disconnected for a few hours to let the moisture dry, then turn on
the unit.
DISCLAIMER OF LIABILITY
JVC shall not be liable for any loss relating to the unit’s failure to
properly record, store or playback any content (video, audio or
otherwise) for any reason whatsoever. Any applicable warranties
shall only cover replacement or repair of the effected unit, and
shall not apply to recovery or replacement of lost content.
HOW TO USE THIS INSTRUCTION MANUAL
●All major sections and subsections are listed in the Table Of
Contents on page 5. Use this when searching for information on
a specific procedure or feature.
●The Index on pages 11 -14 illustrates the controls and
connections on the front and rear panel, the front display panel
and the remote control.
●The list of terms on page 79 lists frequently-used terms, and the
number of the page on which they are used or explained in the
manual.
●The Amark signals a reference to another page for instructions
or related information.
●Operation buttons necessary for the various procedures are
clearly indicated through the use of illustrations at the beginning
of each major section.
The STANDBY/ON Abutton does not completely shut off
mains power from the unit, but switches operating current on and
off. ABBshows electrical power standby and ACBshows ON.
ATTENTION:
8Using a mobile phone in the vicinity of the unit may cause
picture vibration on the TV screen or change the screen to a
blue back display.
8Some TVs or other appliances generate strong magnetic
fields. Do not place such appliances on top of the unit as it
may cause picture disturbance.
8If there is a power outage when using the unit, the recorded
data may be erased.
8Recorded programmes and data cannot be restored once
the disc is damaged.
IMPORTANT
Connection to the mains supply in the United Kingdom.
DO NOT cut off the mains plug from this equipment.
If the plug fitted is not suitable for the power points in your home
or the cable is too short to reach a power point, then obtain a
proper safety approved extension lead/adapter or consult your
dealer.
In the unlikely event of the plug fuse failing be sure to
replace the fuse only with an identical approved type, as
originally fitted, and to replace the fuse cover. If the fuse
fails again consult your nearest JVC dealer.
If nonetheless the mains plug is cut off remove the fuse and
dispose of the plug immediately, to avoid a possible shock
hazard by inadvertent connection to the mains supply.
If this product is not supplied fitted with a mains plug then follow
the instructions given below:
DO NOT make any connection to the Larger Terminal coded E
or Green.
The wires in the mains lead are coloured in accordance with the
following code:
If these colours do not correspond with the terminal
identifications of your plug, connect as follows:
Blue wire to terminal coded N (Neutral) or coloured Black.
Brown wire to terminal coded L (Live) or coloured Red.
If in doubt — consult a competent electrician.
Blue to N (Neutral) or Black
Brown to L (Live) or Red
M100SEK_00.book Page 3 Tuesday, March 22, 2005 5:31 PM

Filename [M100SEK_02Safety.fm]
Masterpage:Left+
4EN
Page 4Tuesday, 22 March 2005 17:31
SAFETY FIRST
This equipment has been designed and manufactured to meet international safety standards but, like any electrical equipment,
care must be taken if you are to obtain the best results and safety is to be assured.
DO read the operating instructions before you attempt to use the equipment.
DO ensure that all electrical connections (including the mains plug, extension leads and interconnections between pieces of equipment)
are properly made and in accordance with the manufacturer’s instructions. Switch off and withdraw the mains plug when making or
changing connections.
DO consult your dealer if you are ever in doubt about the installation, operation or safety of your equipment.
DO be careful with glass panels or doors on equipment.
DON’T continue to operate the equipment if you are in any doubt about it working normally, or if it is damaged in any way^switch off,
withdraw the mains plug and consult your dealer.
DON’T remove any fixed cover as this may expose dangerous voltages.
DON’T leave equipment switched on when it is unattended unless it is specifically stated that it is designed for unattended operation or has
a standby mode. Switch off using the switch on the equipment and make sure that your family knows how to do this. Special
arrangements may need to be made for infirm or handicapped people.
DON’T use equipment such as personal stereos or radios so that you are distracted from the requirements of road safety. It is illegal to
watch television whilst driving.
DON’T listen to headphones at high volume, as such use can permanently damage your hearing.
DON’T obstruct the ventilation of the equipment, for example with curtains or soft furnishings. Overheating will cause damage and shorten
the life of the equipment.
DON’T use makeshift stands and NEVER fix legs with wood screws^to ensure complete safety always fit the manufacturer’s approved
stand or legs with the fixings provided according to the instructions.
DON’T allow electrical equipment to be exposed to rain or moisture.
ABOVE ALL...
Some Do’s And Don’ts On The Safe Use Of Equipment
^NEVER let anyone especially children push anything into holes, slots or any other opening in the case^this could result in a fatal
electrical shock;
^NEVER guess or take chances with electrical equipment of any kind^it is better to be safe than sorry!
M100SEK_00.book Page 4 Tuesday, March 22, 2005 5:31 PM

Masterpage:Right0
EN 5
Filename [M100SEK_03TOC.fm]
Page 5 March 22, 2005 5:31 pm
CONTENTS
SAFETY FIRST 2
Safety Precautions .........................................................................2
Some Do’s And Don’ts On The Safe Use Of Equipment ...............4
DISC INFORMATION 6
About Discs ....................................................................................6
INDEX 11
INSTALLING YOUR NEW UNIT 17
Basic Connection .........................................................................17
INITIAL SETTINGS 18
Auto Set Up..................................................................................18
Preset Download..........................................................................19
Language .....................................................................................21
Monitor Set...................................................................................22
BASIC OPERATIONS ON DVD DECK 23
Basic Playback.............................................................................23
Playback Features .......................................................................24
Live Memory Playback .................................................................28
Using The On-screen Bar ............................................................31
Basic Recording ...........................................................................35
Recording Features......................................................................36
TIMER RECORDING 38
VIDEO Plus+ Timer Programming ...............................................38
Manual Timer Programming.........................................................39
On-Disc Timer Programming .......................................................40
Check, Cancel And Change Programmes ...................................42
Automatic Satellite Programme Recording ..................................43
NAVIGATION 44
Library Database Navigation........................................................44
Basic Operation Of Original Information ......................................45
Edit Original Information...............................................................47
Basic Operation Of Play List Information .....................................48
Edit Play List Information .............................................................49
Edit Library Information ................................................................52
Playback With MP3/JPEG Navigation..........................................53
EDITING 54
DV Dubbing ................................................................................. 54
Digital Audio Dubbing .................................................................. 55
Edit From A Camcorder ............................................................... 56
Edit To Or From Another Recorder ............................................. 57
Output/Input Set .......................................................................... 58
SYSTEM CONNECTIONS 60
Connecting To A Satellite Receiver............................................. 60
Connecting To A Dolby Digital Decoder Or An
Amplifier With Built-in DTS........................................................ 60
SUBSIDIARY SETTINGS 61
Mode Set ..................................................................................... 61
Remote Control Functions........................................................... 63
Scan Mode Set ............................................................................ 64
Tray Lock..................................................................................... 64
Child Lock.................................................................................... 64
VIDEO Plus+ System Setup ........................................................ 65
Tuner Set..................................................................................... 66
Clock Set ..................................................................................... 69
Format A Disc.............................................................................. 70
Finalise A Disc............................................................................. 71
TROUBLESHOOTING 72
APPENDIX 75
SPECIFICATIONS 78
LIST OF TERMS 79
M100SEK_00.book Page 5 Tuesday, March 22, 2005 5:31 PM

Filename [M100SEK_04DiscInfo.fm]
Masterpage:Left0
6EN DISC INFORMATION
Recordable/Playable Discs
You can use discs with the following logos for recording and
playback.
●The above table is based on the information as of February 2005.
●Recording and playback may not be performed depending on the
characteristics and condition of the disc used, leading to
unsatisfactory results. Using discs manufactured by JVC is
recommended since they have been tested to be compatible with
this unit.
DVD-RAM Discs
It is only possible to use discs which conform with DVD-RAM
standard Version 2.0, 2.1 or 2.2.
●If you use a disc formatted under a different standard version,
format it on this unit before use.
●It may not be possible to record, play back, edit or dub a
DVD-RAM disc even if it conforms to the standard if it was
recorded or edited on the devices from other manufacturers or on
a PC, or if it has far too many titles, or if there is very little
available capacity remaining on the disc.
●DVD-RAM discs recorded on this unit cannot be played back on
an incompatible DVD player.
●It is possible to record copy-once programmes of digital
broadcasts only onto 4.7/9.4 GB DVD-RAM discs. (2.8 GB
DVD-RAM discs are not compatible)
●This unit does not support discs contained in cartridges. Use the
disc after removing it from the cartridge. For details on discs in
TYPE2 and TYPE4 (disc removable) cartridge, refer to its
instruction manual.
●While recording, it is possible not only to start playback of a
programme currently being recorded, but also to watch another
programme previously recorded.
DVD-R/RW Discs
It is only possible to use DVD-R discs which conform with DVD-R
standard Version 2.0 or 2.1.
It is only possible to use discs which conform with DVD-RW
standard Version 1.1 or 1.2. Available in VR mode and Video
mode.
When a DVD-R/RW disc (Video mode) is finalised (Apg. 71), it
can be played back on a standard DVD player as a DVD VIDEO
disc.
When a DVD-RW disc (VR mode) is finalised (Apg. 71), it can be
played back on DVD player compatible with the VR mode of
DVD-RW discs.
Before finalising^
it is possible to record on unrecorded areas of the disc, edit the
disc title and programme titles, and delete programmes.
●It is impossible to record or edit DVD-R/RW discs recorded on
other devices even if they have not been finalised.
●It is impossible to overwrite recorded areas of DVD-R discs.
●Available recording capacity does not increase even if a recorded
programme is deleted from a DVD-R disc.
After finalising^
After a DVD-R/RW disc (Video mode) has been finalised, it is
possible to play back the recorded programmes (video and/or
audio) on a standard DVD video player as a DVD VIDEO disc.
●Edited titles are displayed
as the ADVD menuBin
video mode.
●It is impossible to record,
edit or delete the data
either in video mode or in
VR mode.
●Either in video mode or in
VR mode, although the
disc can be played back
on DVD players from other
manufacturers, sometimes it may not be possible to play back
depending on the disc and recording conditions.
●It is impossible to record on CD-R/RW or DVD-R discs used for
authoring.
●When recording copy-once programmes of digital broadcasts,
record in VR mode using CPRM compatible DVD-RW discs.
NOTE:
The following may result if you play back a DVD-R disc recorded
on another unit.
●The disc does not play.
●A mosaic pattern (block noise) appears on the screen.
●Video or audio may be dropped out.
●The unit stops during playback.
About Discs
DVD-RAM
12 cm: 4.7 GB/9.4 GB
8cm:1.4GB/2.8GB
Ver. 2.0/2x speed
Ver. 2.1/1x -3x speed
Ver. 2.2/5x speed
DVD-RW
12 cm: 4.7 GB
8cm:1.4GB
Ver. 1.1/1x -2x speed
(Video mode/VR mode)
Ver. 1.2/4x/6x speed
(Video mode/VR mode)
DVD-R
12 cm: 4.7 GB
8cm:1.4GB
Ver. 2.0/1x -4x/8x speed
(Video mode)
Ver. 2.1/16x speed
(Video mode)
CONTENTS MENU
81 Sister Princess ED2 14/11 0:55 PR12<HDD MN26
82 GALAXY ANGLE A#04 OP 06/10 9:30 PR12<HDD
83 GALAXY ANGLE A#04 ED 06/10 9:30 PR12<HDD
84 FISHING WORLD OP 22/12 20:00 PR3
85 FISHING WORLD ED 22/12 20:00 PR3
86 RALLY CAR OP 10/04 0:30 PR3
87 RALLY CAR ED 10/04 0:30 PR3
88 Chobits #04 OP 02/05 PR10
89 Chobits #04 ED 02/05 PR10
90 Chobits #25 ED 26/09 PR10 MN32 LPCM
16.11.2002
07.10.2002
07.10.2002
22.12.2002
22.12.2002
04.10.2002
04.10.2002
02.05.2002
02.05.2002
26.09.2002
PREV
NEXT
M100SEK_00.book Page 6 Tuesday, March 22, 2005 5:31 PM

Masterpage:Right+
EN 7
Filename [M100SEK_04DiscInfo.fm]
DISC INFORMATION
Discs For Playback Only
You can use discs with the following logos for playback only.
●Playback may not be performed depending on the characteristics
and condition of the disc used.
●DTS Audio CDs can also be played back. (An optional DTS
decoder is required)
●MP3 and JPEG discs can be played back on this unit only when
they have been recorded in the ISO9660 or Joliet format and
finalised.
●JPEG files that can be played back on this unit must conform to
JFIF/Baseline process, and the maximum resolution of a JPEG
file is 2,812 pixels in width and 2,112 pixels in height.
●CD-R/RW discs recorded in music CD format need to be finalised
to play back on this unit.
●Operation and audio quality of this unit are not guaranteed for
discs that do not conform to the Compact Disc specification
(CD-DA).
Before you play back a CD, check for the CD logo and read the
notes on the package to confirm that it conforms to the Compact
Disc specification.
●Depending on the intentions of the author of the software,
recording conditions of DVD discs and Video CD/SVCD discs
may be restricted. Since this unit plays back discs according to
the intentions of the author of the software as indicated on the
disc, some functions may not operate as commanded.
●When switching from the first layer to the second layer of double-
layered DVD VIDEO discs, the image and sound may be
momentarily distorted. This is not a malfunction.
●DVD-AUDIO discs compatible with DVD video players can be
played.
●Super Audio CDs (SACD) compatible with conventional CD
players can be played.
●It is possible to play back finalised +R/+RW (Video mode only)
discs. ADVDBlights on the front display panel when a +R/+RW
disc is loaded.
However, the use of +R double layer disc on this unit may not be
recommended.
Unplayable Discs
The unit may not be able to play back or it may take some time to
read a disc depending on the recording status or condition of the
disc, or if the disc is scratched, dirty or warped.
In addition, do not attempt to play back discs in unusual shapes
(heart-shaped, octagonal, or other forms). If such discs are
accidentally played back, it may cause noise that can lead to
speaker damage.
●CD-ROM discs (including PHOTO-CD and CD-G)
●Discs recorded in Packet Write (UDF) format
●1.3 GB double density CDs (DDCD)
●High density CDs (HDCD)
The following discs also cannot be played back.
●Discs of a region number other than A2B
●DVD-RAM (2.6 GB/5.2 GB)
●DVD-RAM (TYPE1)
Caution for DualDisc playback
The Non-DVD side of a ADualDiscBdoes not comply with the
ACompact Disc Digital AudioBstandard. Therefore, the use of Non-
DVD side of a DualDisc on this product may not be recommended.
Region Number
The world is divided into 6 regions for DVD VIDEO discs.
DVD VIDEO discs are assigned a region number to indicate which
region they may be played back in. A disc cannot be played back
on this unit unless the region number of the disc matches that of
the unit. The region number for this unit is A2B. Only discs whose
region number includes A2Bor AALLBcan be played back such as
shown below.
Examples of DVD VIDEO labels which can be played back
using this unit.
Marks of discs in this instruction manual
DVD VIDEO Video CD/Super Video CD
Audio CD
CD-DA files
CD-R
CD-DA/JPEG/
MP3 files
CD-RW
CD-DA/JPEG/
MP3 files
CD-ROM
JPEG/MP3 files
(example of region code
indications)
Allows operation with a
DVD-RAM disc.
Allows operation with a
Video CD/Super Video
CD (SVCD) disc.
Allows operation with a
DVD-R disc.
Allows operation with
an Audio CD disc.
Allows operation with a
DVD-RW disc.
Allows operation with a
disc including MP3
files.
Allows operation with a
DVD VIDEO disc.
Allows operation with a
disc including JPEG
files.
M100SEK_00.book Page 7 Tuesday, March 22, 2005 5:31 PM

Filename [M100SEK_04DiscInfo.fm]
Masterpage:Left+
8EN DISC INFORMATION
Recording Medium And Format
DVD-RAM
●Recording and erasing can be performed as many times as
possible on a disc.
●Editing can be performed after recording, such as deleting
unwanted parts.
●While recording, it is possible not only to start playback of a
programme currently being recorded, but also to watch another
programme previously recorded.
DVD-RW (VR mode)
●Recording and erasing can be performed as many times as
possible on a disc.
●Editing can be performed after recording, such as deleting
unwanted parts.
DVD-RW (Video mode)
●Can be played back on other DVD players after finalising.
●New recording can be performed by erasing all the data on a disc
once played back.
DVD-R
●Can be played back on other DVD players after finalising.
●Suitable when keeping a recorded disc for a long time.
File Structure Of Discs
DVD VIDEO
Typically, DVD VIDEO discs are made up of larger units called
AtitlesB. Each title has a number (title number) that can be used to
select desired titles. Titles are further divided into units called
AchaptersB. Each chapter has a number (chapter number) that can
also be used to select desired chapters. Note that some discs are
not divided into titles and chapters.
When you record a programme on a DVD-RAM/RW (VR mode)
disc
A single recording session results in a single title. In addition,
chapter marks are automatically inserted when recording is
paused. It is also possible to insert chapter marks at desired
locations during playback. (Apg. 26)
When you record a programme on a DVD-R/RW (Video mode)
disc
A single recording session results in a single title. In addition,
chapter marks are automatically inserted when recording is
paused. It is possible to insert chapter marks at desired locations
during playback. Once the disc has been finalised, these chapter
marks are deleted and new chapter marks are assigned
automatically approximately every 5 minutes.
●In Video mode, even before finalising, it is impossible to perform
editing operations other than changing the disc name and/or title
names and deleting programmes and/or titles.
●After finalising, it is impossible to perform editing operations.
Audio CD/Video CD/SVCD
Typically, Audio CD discs are divided into separate tracks each
containing one song. Each track is assigned a number. For
example, the third track is Track 3. The same is true for Video CD/
SVCD discs.
However, some discs are not divided into tracks.
JPEG/MP3 Disc (CD-R/RW/ROM)
MP3/JPEG files put in directories nested in several levels on a disc
will be organized as if they were put in single level directories
(groups) by the MP3/JPEG Navigation of this unit. (Apg. 53)
File structure of a disc before starting the MP3/JPEG
Navigation
File structure of the disc after starting the MP3/JPEG
Navigation
Files are automatically grouped as follows and displayed on the
MP3/JPEG Navigation screen. Data is displayed in the
alphabetical order of file name. Files are grouped based on roots.
●This unit can recognise up to 9 hierarchies including directories
and files.
Also, it can recognise up to 250 files in each group, and up to
99 groups on a disc.
NOTES:
●Video CD/SVCD discs that support Playback Control (PBC)
The contents of a disc are recorded into several hierarchies, and
played back according to the instructions on the screen while
navigating through the hierarchies. It is also possible to playback
recorded tracks consecutively without activating the PBC function
even when playing a PBC-compatible disc. (Apg. 27)
●Regarding the contents recorded on discs
Some files may not be played back depending on the file types
and other factors.
DVD-RAM, DVD-RW, DVD-R or DVD VIDEO disc
Title1 Title2
Chapter 1 Chapter 2 Chapter 3 Chapter 1 Chapter 2 Chapter 3
Audio CD/Video CD/SVCD
Tr a c k 1 Tr a ck 2 Tr a ck 3 Tra c k 4
Directory
MP3 file
JPEG file
M100SEK_00.book Page 8 Tuesday, March 22, 2005 5:31 PM

Masterpage:Right+
EN 9
Filename [M100SEK_04DiscInfo.fm]
DISC INFORMATION
DVD VIDEO Marks
Sometimes marks are printed on a DVD disc and/or on its
packaging to indicate information regarding the contents and
functions of the disc. Check the marks indicating the contents and
functions of the disc. Note, however, that in some cases a disc
may not include a mark even for a function it supports.
Marks related to video
Marks related to audio
Placing A Disc
Opening the disc tray
Press Mto open the disc tray.
●Pressing the button again closes the disc tray.
●Use the button to open and close the disc tray.
●Do not block the disc tray with your hand while it is opening or
closing as this may result in hardware failure.
●Do not place unplayable discs or any object other than a disc on
the disc tray.
●Do not press down strongly on the disc tray or place any heavy
objects on it.
Discs without cartridges
Place the disc on the disc tray with the label side facing up. Since
disc size changes depending on the disc to be played back, be
sure to correctly align the disc with the grooves for its size. If the
disc is not in its groove, it may be scratched or otherwise
damaged. To insert an 8 cm disc, place it according to the inner
groove.
DVD-RAM discs contained in cartridges
Double-sided discs:
Remove the disc from the cartridge. Align the disc with the grooves
on the disc tray as shown in the illustration and insert with the side
you wish to play back or record facing down. If you insert the disc
with ASide ABfacing down, programmes are recorded on side A.
Single-sided discs:
Remove the disc from the cartridge. Align the disc with the grooves
on the disc tray as shown in the illustration and insert with the label
side facing up.
Number of subtitles Number of angles
Recorded under the
standard 4:3 aspect
ratio
Screen includes
black bands at the
top and the bottom
of image which has
a standard 4:3
aspect ratio (letter
box)
Video playback is in Wide video mode (16:9)
on wide televisions, but in letter box on
televisions with standard 4:3 aspect ratio.
Video playback is in Wide video mode (16:9)
on wide televisions, but pan and scan is used
on televisions with standard 4:3 aspect ratio
(either the left or right side of the image is cut-
out).
Number of audio tracks
Dolby Digital mark
It has been developed by Dolby Laboratories as
a digital surround system.
DTS (Digital Theater Systems)
You can enjoy DTS audio if you connect an
amplifier with a built-in DTS decoder to the
DIGITAL OUT connector of the unit.
PR
+
F - 1
S - VIDEO VIDEO L(MONO) AUDIO R
DV DV IN
RAM/RW
PR
+
CH
-
PUSH-OPEN
DIGITALDIRECTPROGRESSIVE
Disc tray
Label side facing up
M100SEK_00.book Page 9 Tuesday, March 22, 2005 5:31 PM

Filename [M100SEK_04DiscInfo.fm]
Masterpage:Left+
10 EN DISC INFORMATION
Care And Handling Of Discs
How to handle discs
When handling a disc, do not
touch the surface of the disc.
Since discs are made of
plastic, they are easily
damaged. If a disc gets dirty,
dusty, scratched or warped, the
images and sound will not be
picked up correctly, and such a
disc may cause the unit to malfunction.
Label side:
Do not damage the label side, stick paper to or use any adhesives
on its surface.
Recording side:
Make sure that discs are not scratched and dirty on the recording
side before use. Scratches and dirt on the recording side of a disc
may hinder proper playback and recording. Also be careful that a
DVD-RAM disc may get scratched or dirty when removed from
cartridge then put back in after use.
Storage
Make sure that discs are kept in their cases. If discs are piled on
top of one another without their protective cases, they can be
damaged. Do not put discs in a location where they may be
exposed to direct sunlight, or in a place where the humidity or
temperature is high. Avoid leaving discs in your car!
Maintenance of discs:
If there are fingerprints or other dirt adhering
to a disc, wipe with a soft dry cloth, moving
from the centre outwards.
If a disc is difficult to clean, wipe with a cloth
moistened with water. Never use record
cleaners, petrol, alcohol or any anti-static
agents.
CAUTION:
Sometimes during playback, noise may appear or images may
be garbled. This is sometimes due to the disc. (It may not be up
to industry standards.)
These symptoms are caused by the discs, not by the
malfunction of the unit.
M100SEK_00.book Page 10 Tuesday, March 22, 2005 5:31 PM

Masterpage:Right0
EN 11
Filename [M100SEK_05Name.fm]
INDEX
Front View
AStandby/On Button (STANDBY/ON A)
BInfrared Beam Receiving Window
CDisc tray
DEject Button (M) Apg. 9
ERecord Button (R) Apg. 35
FStop Button (o) Apg. 23
GPlay Button (I) Apg. 23
HFront Display Panel Apg. 13
IS-video Input Connector [S-VIDEO] Apg. 56
JVideo/Audio Input Connectors [VIDEO/AUDIO (L(MONO)/
R)] Apg. 56
KDV Input connector [DV IN (A*)] Apg. 54
*i(i.Link) refers to the IEEE1394-1995 industry specification and
extensions thereof. The ilogo is used for products compliant with the
i.Link standard.
LProgramme Buttons (PR +/–) Apg. 35
STANDBY/ON
RAM/RW
PR+
F - 1
S - VIDEO VIDEO L(MONO) AUDIO R
DV DV IN
CB D E F GA
HI
J K L
To access covered connectors,
press PUSH-OPEN to open the
cover.
PR
+
PR
-
PUSH-OPEN
M100SEK_00.book Page 11 Tuesday, March 22, 2005 5:31 PM

Filename [M100SEK_05Name.fm]
Masterpage:Left+
12 EN INDEX
Rear View
AAntenna Input Connector [ANTENNA IN] Apg. 17
BComponent Video Output Connectors [COMPONENT
VIDEO OUT (Y/P
B /P R )] Apg. 17
CL-1 Input/Output Connector [L-1 IN/OUT] Apg. 17, 57, 58,
60, 61
DL-2 Input/Decoder* Connector [L-2 IN/DECODER] Apg. 57,
58, 60, 61
* The decoder function of this unit is not available in the U.K.
EAudio Output Connector [AUDIO OUT LEFT/RIGHT]
Apg. 17
FDigital Audio Output Connector [DIGITAL OUT (COAXIAL)]
Apg. 55, 61
GRegion Number
HAC Power Cord
IAntenna Output Connector [ANTENNA OUT] Apg. 17
JCooling Fan
●This prevents the temperature from rising inside the unit.
Do not remove it.
●Install the unit so as not to block the area around the fan.
●The unit may become hot when it is turned off, as the cooling
fan on the rear of the unit is not activated. However, the cooling
fan may be activated in the following cases;
^In the Automatic Satellite Programme Recording standby
mode (Apg. 43), slightly before the starting time of VPS/
PDC recording (Apg. 39).
^If you connect the decoder or satellite receiver to [L-2 IN/
DECODER], and if AL-2 SELECTBis set to ADECODERB,
ASAT VIDEO/RGBBor ASAT S-VIDEO/RGBB. (Apg. 59)
^When AJUST CLOCKBis set to AONB(Apg. 69)
(Set AJUST CLOCKBto AOFFBif you mind the noise of the
fan.)
AB C E G
J
H
I
FD
M100SEK_00.book Page 12 Tuesday, March 22, 2005 5:31 PM

Masterpage:Right+
EN 13
Filename [M100SEK_05Name.fm]
INDEX
Front Display Panel
AVideo Indicator (z) Apg. 23
Lights when video mode is selected by pressing TV z.
BDisc Type Indicator
When a disc is loaded, the type of the disc is indicated.
Disc Status Indicator
When a disc is running, the disc marks rotate.
During High-Speed Search:
Rotate faster than normal playback.
During Slow Motion:
Rotate slower than normal playback.
While recording:
Inner red ring lights in the same way as normal playback.
During Instant Timer Recording (ITR), inner red ring slowly
blinks.
While paused:
Disc marks blink when either recording or playing back.
While stopped: Disc marks all light.
While resume stopped: Disc marks all blink.
While the disc tray opened: Disc marks all light out.
No disc on the disc tray: Disc marks all light out.
VR Mode Indicator (VR) Apg. 70
Lights when a DVD-RW disc is formatted in VR mode.
CVPS/PDC Indicator Apg. 39
Lights when checking if the station being received transmits a
VPS/PDC signal.
DLinear PCM Indicator (LPCM)
Lights when AXP MODE REC AUDIOBis set to ALINEAR PCMB
(Apg. 62) for recording with DVD-RAM, DVD-R and DVD-RW
discs, and when Linear PCM audio is played.
ERecording Mode Indicator (XP/SP/LP/EP/FR) Apg. 35
Blinks when recording mode is being set.
While AFRBis blinking, the left 3 digits of the Multi Display
(NO) indicate setting values ranging from A60Bto A480B. After
the value has been set, only AFRBlights.
FGroup/Title Indicator (GRP/TITLE)
AGRPBor ATITLEBlights depending on a disc loaded while the
left 2 digits of the Multi Display (N) indicate the numbers
explained below.
AGRPB: Total number of groups or group number being played
back are displayed on the Multi Display.
ATITLEB: Total number of titles or title number being played
back are displayed on the Multi Display.
GChannel Indicator
Indicates the channel received.
HTrack/Chapter Indicator (TRK/CHAP)
ATRKBor ACHAPBlights depending on a disc loaded while the
3rd and 4th digits from the left of the Multi Display (O) indicate
the numbers explained below.
ATRKB: Total number of tracks or track number being played
back are displayed on the Multi Display.
ACHAPB: Chapter number being played back are displayed on
the Multi Display.
IRandom/Programme Playback Mode Indicator (RND/
PRGM) Apg. 34
ARNDB: Lights when Random Playback mode is set.
APROGB: Lights when Programme Playback mode is set.
JRepeat Mode Indicator (x/1/A-B) Apg. 31, 32
Select Repeat Playback mode on the on-screen bar.
AxB: Whole disc is played back repeatedly.
Ax1B: A single title/chapter/track is played back
repeatedly.
AxA-BB: The selected part (A-B) is played back repeatedly.
No display: Repeat Playback mode is off.
KDISC Timer Indicator Apg. 40
: Lights when a disc set up for On-Disc Timer
Programming is loaded.
: Lights when timer recording other than On-Disc
Timer Programming is on stand-by or being
executed.
: Lights when On-Disc Timer Programming is on
stand-by or being executed.
: Blinks quickly if you press TIMERjin the
following cases;
●Disc is not loaded.
●Clock has not been set.
●There is no programme setting.
LVideo Output Indicator (q) Apg. 64
No display: Indicates that interlace mode is engaged.
q: Indicates that progressive mode is engaged.
(Example) qlights when video output mode is in progressive
mode.
MAutomatic Satellite Programme Recording Indicator
Apg. 43
Lights when the unit is in the Auto Satellite Programme
Recording standby mode.
NGroup/Title Number Display
OTrack/Chapter Number Display
PRemaining Time/Elapsed Time Display Apg. 26, 36
Lights when remaining time of DVD-RAM, DVD-R and
DVD-RW discs is displayed, and lights out when elapsed time
is displayed.
The right 6 digits of the Multi Display (Q) indicate elapsed or
remaining time of each track.
No display: Indicates elapsed time of the disc.
Displayed: Indicates remaining time of the disc.
QRemaining Time/Elapsed Time Display Apg. 26, 36
RMulti Display
Displays clock, received channel, elapsed time, and remaining
time.
Also displays status of the unit.
DVD
VR
- RAM
LPCM DISC
FR
XP SP LP EP
- RW VCD
BADCE KGFH IJ
LMNOP QR
M100SEK_00.book Page 13 Tuesday, March 22, 2005 5:31 PM

Filename [M100SEK_05Name.fm]
Masterpage:Left+
14 EN INDEX
Remote Control
ATV/VIDEO Button
For switching the input of a JVC TV.
BOpen/Close Button (M)
CNumber Keys Apg. 24, 33, 34
DCancel Button (CANCEL) Apg. 34
EAuxiliary Button (AUX)
FSHOWVIEW Button
VIDEO Plus+ Button Apg. 38
GProgramme Button (PROG) Apg. 39
HTop Menu Button (TOP MENU) Apg. 24
ISelection Keys (FGD E)
JMenu Button (MENU) Apg. 24
KReverse Skip Button (S) Apg. 24, 27, 30, 34
LReverse Search Button (O) Apg. 24, 30
Reverse Slow Button (SLOW –) Apg. 25
MRecord Button (R) Apg. 35, 36
NOn-Screen Button (ON SCREEN) Apg. 31
ODisplay Button (DISPLAY) Apg. 26, 36
PRecording Mode Button (REC MODE) Apg. 35, 43
Remain Button (REMAIN) Apg. 26, 36
QAudio Button (AUDIO) Apg. 27
RSubtitle Button (SUBTITLE) Apg. 26
STV/Video Mode Select Button (TV z) Apg. 23
For switching the TV input to video mode (or connected
external mode).
TDVD STANDBY/ON Button (DVD A) Apg. 41
UTV STANDBY/ON Button (TV A)
For turning on/off the power of a JVC TV.
VTV Volume Buttons (TV 8+/–)
For adjusting the volume of a JVC TV.
WProgramme Buttons (PR +/–) Apg. 35,
XMemo Button (MEMO) Apg. 45
Mark Button (MARK) Apg. 26
YTimer Button (TIMERj) Apg. 38, 39
ZAutomatic Satellite Programme Recording Button (SATj)
Apg. 43
aNavigation Button (NAVIGATION) Apg. 44
bEnter Button (ENTER)
cReturn Button (RETURN) Apg. 27
dForward Skip Button (T) Apg. 24, 27, 30, 34
eForward Search Button (N) Apg. 24, 30
Forward Slow Button (SLOW +) Apg. 25
fPlay Button (I) Apg. 23, 24, 29
gPause Button (W) Apg. 23, 30
hStop Button (o) Apg. 23
Clear Button (CLEAR) Apg. 33
iSkip Search Button (v) Apg. 25, 30
jOne Touch Replay Button (w) Apg. 25, 30
kAngle Button (ANGLE) Apg. 26
Live Check Button (LIVE CHECK) Apg. 28, 30
lSet Up Button (SET UP) Apg. 61
mProgressive Scan Button (PROGRESSIVE SCAN) Apg. 33,
64
a
c
d
T
V
U
W
A
C
e
f
g
i
h
m
l
k
j
B
Z
Y
G
Q
R
S
F
I
J
K
L
H
P
O
M
N
X
E
D
b
How To Use
Before use, insert two AA size batteries into the remote control
with the polarity (Fand G) matched correctly as indicated on
the battery compartment or on the lid.
●Point the remote control toward the receiving window.
●The maximum operating distance of the remote control is
about 8 m.
NOTE:
If the remote control doesn’t work properly, remove its batteries,
wait a short time, replace the batteries and then try again.
M100SEK_00.book Page 14 Tuesday, March 22, 2005 5:31 PM

Masterpage:Right+
EN 15
Filename [M100SEK_05Name.fm]
INDEX
Check Contents
CHECK ALL THE CONTENTS SHOWN BELOW
STANDBY/ON
RAM/RW
PR
+
PR
-
PUSH-OPEN
I You are now ready to install your unit. (Apg. 17)
DVD Video Recorder
RF Cable AAABBatteries (x 2)
21-pin SCART Cable
Infrared Remote Control Unit
M100SEK_00.book Page 15 Tuesday, March 22, 2005 5:31 PM

Filename [M100SEK_05Name.fm]
Masterpage:Left+
16 EN INDEX
On-Screen Display
When ON SCREEN on the remote control is pressed, various
operational indicators appear on the TV screen. To clear the
operational indicators, press ON SCREEN twice.
LPCM 2ch
0:01:08
DVD-VIDEO TITLE1
EACH
CHAPTER1
A CB D E
FG
When playing back a recorded title
ADisc type
BAudio mode
CCurrent status (playback)
DPlayback title number
EPlayback chapter number
FCurrent playback point
GElapsed playing time
0:01:23
DVD-RW/VR TITLE14
EACH
CHAPTER1
SP
6:04PM
PR 95
A B C
D E HF G
When recording
ADisc type
BRecording mode
CCurrent time
DRecording point
ECurrent status (recording)
FElapsed recording time
GAudio mode
HRecording channel number
When pressing REC MODE:
XP:
SP:
LP :
EP:
FR:
1:00
2:00
4:01
6:03
2:31 (FR150)
AB
REC QUALITY RECORDABLE TIME
(Appears for eight seconds.)
ARecording mode
BRemaining disc time for each recording speed
0:13
TITLE13
ITR
CHAPTER1
SP
A
During Instant Timer Recording (ITR)
ARecord remaining time
0:13:34
DVD-RAM TITLE2TITLE2 0:12:27
EACH
CHAPTER1
LP
6:36PM
PR 10
A B
C D GE F
When using Live Memory playback
ADisc type
BCurrent time
CBar meter for recording/playback
DRecording mode
ECurrent playback time/Elapsed recording time
FAudio mode
GRecording channel number
DV Dubbing
When capturing images from the external DV
0:00:00
DVD-RW/VR TITLE12
EACH
CHAPTER--
SP
--:--
DV LR
A B
CD GE F
equipment
ADisc type
BCurrent time
CCurrent recording point
DCurrent status (recording)
EElapsed recording time
FSound mode
GRecording channel (DV input)
DV
1 2
AB C
DV
AUDIO 1
DV DUBBING
ADisplays when remote control is set to DV control mode.
BAuto capture button
CSound monitor switch
M100SEK_00.book Page 16 Tuesday, March 22, 2005 5:31 PM

Masterpage:Right0
EN 17
Filename [M100SEK_05Name.fm]
INSTALLING YOUR NEW UNIT
It’s essential that your unit be properly connected.
1Place the unit on a stable, horizontal surface.
2Connect the unit to a TV depending on the TV and cables you
use.
8Basic Connection
To connect to a TV with 21-pin SCART input connector ^
ADisconnect the TV aerial cable from the TV.
BConnect the TV aerial cable to the [ANTENNA IN] connector on
the rear panel of the unit.
CConnect the [ANTENNA OUT] connector on the rear panel of
the unit and the TV’s aerial connector with the supplied RF
cable.
DConnect the [L-1 IN/OUT] connector on the rear panel of the
unit and the TV’s 21-pin SCART connector with a supplied 21-
pin SCART cable.
●The [L-1 IN/OUT] connector accepts and delivers either a
composite signal (regular video signal), Y/C signal or RGB
signal.
●Set your TV to the VIDEO, Y/C, or RGB mode according to the
type of your TV’s SCART connector.
8Component Video Connection
To connect to TV’s component video input connectors ^
APerform steps A-Cof ABasic ConnectionB.
BConnect the unit’s [COMPONENT VIDEO OUT (Y/P
B /P R )]
connectors to the TV’s component video input connectors.
CConnect the unit’s [AUDIO OUT] connectors to the TV’s AUDIO
input connectors.
●You can obtain high-quality component video pictures.
●If your TV is not stereo-capable, use the unit’s [AUDIO OUT]
connectors to connect to an audio amplifier for Hi-Fi stereo
sound reproduction.
●By using the component video connection, you can view the
images in the progressive mode. For switching to the
progressive mode, refer to AScan Mode SetB(Apg. 64).
NOTE:
Select an appropriate option of AL-1 OUTPUTBas follows
(Apg. 58):
When the setting selected is not in accordance with the TV
connected and depending on the type of appliance connected to
the unit, the correct picture will not appear.
3Plug the end of the mains power cord into a mains outlet.
●APLEASEBand AWAITBblink alternately on the front display
panel when the AC plug of the mains power cord is connected
into a mains outlet. And it takes approximately 30 seconds for
the unit to be turned on. This is not a malfunction.
Basic Connection
ATTENTION:
●Your TV must have a 21-pin AV input connector (SCART) for
the basic connection to the unit.
●Connect the AC plug only after all connections to the TV has
been completed.
COAXIAL
Y
P B
P R
IN
OUT
ANTENNA
VIDEO OUT
L-1 L-2
TV aerial cable
Mains outlet
Back of unit
Component
video cable
(not supplied)
TV
Mains power cord
Audio cable
(not supplied)
To
[COMPONENT
VIDEO OUT
(Y/P
B /P R )]
To
[AUDIO
OUT]
To [ANTENNA IN]
To
[ANTENNA
OUT]
RF cable
(supplied)
To [L-1 IN/OUT]
21-pin SCART
cable
(supplied)
To 75 ohm terminal
THESE STEPS MUST BE COMPLETED BEFORE ANY VIDEO
OPERATION CAN BE PERFORMED.
When your TV’s SCART
connector accepts: Set AL-1 OUTPUTBto:
Composite signals ASCART VIDEOB
Y/C signal (separated
luminance (brightness) and
chrominance (colour) signals)
ASCART S-VIDEOB
RGB signal ASCART RGBB
Component video signal ACOMPONENTB
If you possess a satellite receiver, refer to AConnecting To A
Satellite ReceiverBas well. (Apg. 60)
M100SEK_00.book Page 17 Tuesday, March 22, 2005 5:31 PM

Filename [M100SEK_05Name.fm]
Masterpage:Left0
18 EN INITIAL SETTINGS
Auto Channel Set/Auto Clock Set/Auto Guide
Programme Number Set
1Press Aon the unit or DVD Aon the remote control to turn
on the unit. The AUTO SET/T-V LINK display appears on the TV
screen.
2Press selection keys to
select AAUTO SETB,
then press ENTER.
●Auto Channel Set is
performed.
●When Auto Channel Set
is completed, ASCAN
COMPLETEDBappears
on the TV screen.
ATTENTION:
AAUTOBblinks on the front display panel; do NOT press any button
on the unit or remote control until the front display panel shows
clock time, APR1Bor AcBas illustrated on page 20.
●When you have connected the unit to a TV offering T-V Link via a
fully-wired 21-pin SCART cable (Apg. 17) and the TV is turned
on, the unit automatically performs the Preset Download
(Apg. 19) even if you select AAUTO SETBfor Auto Set Up
function.
NOTES:
●In areas where no TV station transmits a PDC (Programme
Delivery Control) signal, the unit can perform neither Auto Clock
Set nor Auto Guide Programme Number Set.
●If there is a power cut, or if you press Aor SET UP while AAuto
Set UpBis in progress, AAuto Set UpBwill be interrupted. Be sure
to turn off the unit power once and try again from step 1.
●Auto Clock Set may not function properly depending on the
reception condition.
Auto Set Up
After the Abutton on the unit (or DVD Aon the remote
control) is pressed for the first time to turn on the unit, the Auto
Set Up function sets the tuner channels, clock and Guide
Programme numbers automatically.
Before starting, make sure of the following:
●The TV aerial cable should be connected to the unit.
●The unit’s mains power cord should be connected to a mains
outlet.
●Turn on the TV and select an input mode such as EXT1.
(FGDE)
ENTER
DVD A
1
Selection Keys
INITIAL SET UP
AUTO SET
INITIAL SET UP / CHANNEL SET
SELECT WITH [CURSORS]
THEN PRESS [ENTER]
T-V LINK
RETURN
OK
SELECT
SET UP
INITIAL SET UP
AUTO SET
INITIAL SET UP / CHANNEL SET
SELECT WITH [CURSORS]
THEN PRESS [ENTER]
T-V LINK
AUTO SET
PLEASE WAIT...
CANCEL
RETURN
OK
SELECT
SET UP
ATTENTION:
Once you have performed AAuto Set UpB, even if the unit’s
memory backup has expired, all the stored stations and their
Guide Programme numbers remain in the unit’s memory and the
unit will not perform AAuto Set UpBagain. Perform clock set
manually after turning on the unit. (Apg. 69)
If you have moved to a different area, perform each setting as
required.
●Tuner setting (Apg. 66)
●Clock setting (Apg. 69)
If a new station starts broadcasting in your area, perform tuner
setting. (Apg. 66)
After AAuto Set UpBis completed, perform AMonitor SetBon
page 22.
M100SEK_00.book Page 18 Tuesday, March 22, 2005 5:31 PM

Masterpage:Right+
EN 19
Filename [M100SEK_05Name.fm]
INITIAL SETTINGS
Auto Channel Set by Downloading from TV/Auto Clock
Set/Auto Guide Programme Number Set
If you have connected the unit to your TV via a 21-pin SCART
cable (Apg. 17), the unit will automatically perform Preset
Download instead of the AAuto Set UpBin step 2on page 18. After
downloading, the unit sets the clock and Guide Programme
numbers automatically.
1Press Aon the unit or DVD Aon the remote control to turn
on the unit. The AUTO SET/T-V LINK display appears on the TV
screen.
2Press selection keys to select AT- V L I N K B, then press ENTER
for confirmation.
●T-V LINK setting is
performed.
●When T-V LINK
setting is completed,
ASCAN
COMPLETEDB
appears on the TV
screen for about 5
seconds, then the
normal screen
resumes.
ATTENTION:
Preset positions on the front display panel increase from
APR1B…APR3B…; do NOT press any button on the unit or remote
control until the front display panel shows clock time, APR1Bor
AcBas illustrated on page 20.
●If you press any button on the unit or remote control while
downloading is in progress, it will be interrupted.
NOTES:
●For details, refer to the instruction manual of your TV.
●In areas where no TV station transmits a PDC (Programme
Delivery Control) signal, the unit can perform neither Auto Clock
Set nor Auto Guide Programme Number Set.
●If there is a power cut, or if you press Aor SET UP while
downloading or set up is in progress, it will be interrupted. Be
sure to turn off the unit power once and try again from the
beginning.
●Auto Clock Set may not function properly depending on the
reception condition.
●On this unit, the characters available for station names (ID) are
A–Z, 0–9, –, Z, + and &(space). Some names of downloaded
stations may differ from those of your TV. (Apg. 68)
Preset Download
ATTENTION:
You can use this function only with a TV offering T-V Link, etc.*
Be sure to use a fully-wired 21-pin SCART cable.
* Compatible with TVs offering T-V Link, EasyLink, Megalogic,
SMARTLINK, Q-Link or DATA LOGIC via a fully-wired 21-pin SCART
cable. The degree of compatibility and available functions may differ by
system.
(FGDE)
ENTER
DVD A
Selection Keys
After APreset DownloadBis completed, perform AMonitor SetBon
page 22.
INITIAL SET UP
AUTO SET
INITIAL SET UP / CHANNEL SET
SELECT WITH [CURSORS]
THEN PRESS [ENTER]
OK
SELECT
SET UP
T-V LINK
RETURN
INITIAL SET UP
AUTO SET
INITIAL SET UP / CHANNEL SET
SELECT WITH [CURSORS]
THEN PRESS [ENTER]
T-V LINK
PLEASE WAIT...
OK
SELECT
SET UP
RETURN
M100SEK_00.book Page 19 Tuesday, March 22, 2005 5:31 PM

Filename [M100SEK_05Name.fm]
Masterpage:Left+
20 EN INITIAL SETTINGS
Results Of Auto Set Up/Preset Download Appearing
On The Front Display Panel
If both Auto Channel Set and
Auto Clock Set have been
performed successfully, the
correct current time is displayed.
Turn on the TV and select an input mode such as EXT1, then make
sure that all necessary stations have been stored in the unit’s
memory by using the PR +/– button(s).
●If station names (ID – Apg. 76) have also been stored in the
unit’s memory, the station name will be displayed at the top right
corner of the TV screen for about 5 seconds when the unit is
tuned to a different station.
●If you want to set the tuner manually such as to add or skip
channels, to change channel positions, or to set or change
station names, see pages 67 and 68.
If Auto Channel Set has
succeeded but Auto Clock Set
has not, APR1B(channel
position) is displayed.
OR
If both Auto Channel Set and Auto Clock Set have failed,
AcBis displayed.
ATurn on the TV and select an input mode such as EXT1, then
make sure that all necessary stations have been stored in the
unit’s memory by using the PR +/– button(s).
●If station names (ID – Apg. 76) have also been stored in the
unit’s memory, the station name will be displayed at the top right
corner of the TV screen for about 5 seconds when the unit is
tuned to a different station.
●If you want to set the tuner manually such as to add or skip
channels, to change channel positions, or to set or change
station names, see pages 67 and 68.
BPerform AClock SetB(Apg. 69).
ATTENTION:
After making sure the cables are connected properly, turn off the
unit’s power once, then turn the unit’s power back on again.
Perform AAuto Set UpB(Apg. 18) or APreset DownloadB(Apg. 19)
again.
IMPORTANT:
●To check if the Guide Programme numbers have been set
correctly, perform the VIDEO Plus+ Timer Programming.
(Apg. 38)
●In certain reception conditions, station names may not be stored
correctly, and Auto Guide Programme Number Set may not work
properly. If the Guide Programme numbers are not set properly
when you timer record a TV programme using the VIDEO Plus+
system, the unit will record a TV programme of a different station.
When programming the timer using the VIDEO Plus+ system, be
sure to check the desired channel is selected correctly.
(Apg. 38)
●Your unit memorises all detected stations even if reception of
some of them is poor. You can delete those stations with an
unacceptable picture. (Apg. 67, ADelete A ChannelB)
INFORMATION
Just Clock
Your unit is equipped with the Just Clock function which provides
accurate time keeping through automatic adjustments at regular
intervals, by reading data from a PDC signal. If you want to take
advantage of this function, simply set AJUST CLOCKBto AONB.
(Apg. 69)
T-V Link Functions
When you connect the unit to your TV via a fully-wired 21-pin
SCART cable (Apg. 17), the following functions are available. You
can use these functions only with a TV offering T-V Link, etc.*
For details, refer to the instruction manual of your TV.
* Compatible with TVs offering T-V Link, EasyLink, Megalogic, SMARTLINK,
Q-Link or DATA LOGIC via a fully-wired 21-pin SCART cable. The degree
of compatibility and available functions may differ by system.
TV Auto Power On
The TV will turn on and be set to an input mode such as EXT1
automatically whenever you start playback.
For details, refer to the instruction manual of your TV.
Unit Auto Standby
You can use your TV’s remote control to turn off the unit.
For details, refer to the instruction manual of your TV.
Direct Rec
You can easily start recording the programme that you are
watching on your TV. When you use this function, set ADIRECT
RECBto AONB. (Apg. 62)
If you have any difficulty with the above procedures call the JVC
Customer Service Hot Line on 0870 330 5000.
