HDTV MULTI-FORMAT MPEG-2 ENCODER
DM-JV600U
MPEG-2 MP@HL/HP@HL 4:2:0/4:2:2
videoencoding
1080/59.94i, 720/59.94P compatible
Video bit rate up to 45 Mbs
ClosedCaptionvia HD-SDI(SMPTE334)
MPEG-1 layer II (ISO/IEC11172-3) audio
plusDolby-Dpass-through
HD-SDI (Video: SMPTE 292M/
Audio: SMPTE 299M) input
AES/EBU (AES3-ID) input
DVB-ASI (MPEG-2 transport stream
[ISO/IEC13818-1]) output
RS-232Cinterface for externalcontrol
JVC’s original MPEG-2 algorithm offers
greater precision for higher quality HDTV encoding
R
DM-JV600.xpr 03.11.5 5:40 PM Page 2

OFFOFF
ONON
POWERPOWER
AC 120VAC 120V〜50/60Hz50/60Hz
RS-232CRS-232C
AES/EBUINAES/EBU IN
ININ MONIMONI 1
OUT
OUT
REFIN(D1)REFIN(D1)
ASIOUTASIOUT
2
HD-
HD-
SDISDI
25 (635) 1 (25)
18-5/16 (465)
19 (482)
1-15/16 (49)
16-15/16 (430)
26-3/16 (665)
1/4 (5) 1-3/4 (44)
Incorporating advanced MPEG-2 encoding technologies exclusive to JVC, the DM-JV600 is a multi-format
HDTV encoder designed for professional use that offers the ease-of-use, installation flexibility, and excellent
cost-performance that JVC products are renowned for. Being combined with JVC D-VHS recorder/player
DM-JV600 provides high-quality Mpeg-2 encoding solution for cost-effective distribution of HD content and
high-definition digital "dailies" in the motion picture industry.
When you need true high-definition quality,
JVC’s original MPEG-2 encoding system is the ideal solution.
Unit: inches (mm)
