JVC DLA-SH4KNL User manual

INSTRUCTION MANUAL
DLA-SH4KNL Projector Lens
GL-MS4015SZG Zoom Lens
GL-MS4011SG Short Focal Length Lens
Safety Precautions
Zoom Lens Short Focal Length Lens
Dimensional Outline Drawing
Thank you for purchasing this product.
Before using, please read through the “Instruction
Manual” to ensure proper use of this product.
In particular, read through the “Safety Precautions” to
ensure safe use of this product.
After you have read through the manual, please store it
carefully and use it as reference whenever necessary.
The manufacturing number is important for quality
control purposes. During purchase, check to ensure
that the manufacturing number is correctly indicated at
the side of the main unit.
Precautions Regarding this Manual
(1) Unauthorized reproduction of this manual without
permission is strictly prohibited.
(2) Specifications and appearance of this product may
be subject to change for improvement without prior
notice.
(3) Please note that some of the pictures and
illustrations may have been abridged, enlarged or
contextualized in order to aid comprehension.
Images may differ from the actual product.
Mass : 3.4 kg
Focus Motor
Focus Motor
182
5.5
113.5
1.2
4.34
Focus Motor
Zoom Motor
Focus Motor
Zoom Motor
182
5.5
113.5
98 98
1.5
2.38
Mass : 3.6 kg
Lens unit ................................................................................................................................... 1 set
Screw ................................................................................................................................... 5 pieces
Lens cap .............................................................................................................................. 2 pieces
●Attached to the lens unit.
Instruction Manual .................................................................................................................. 1 copy
Warranty Card ........................................................................................................................ 1 copy
Maintenance Procedures
Remove dirt from the lens using commercial blowers or lens cleaning papers (for cleaning glasses
and cameras). Do not use fluid-type cleaning agents. This may lead to peeling of the surface coating
film. The lens surface is fragile. Avoid rubbing it hard or knocking it.
Accessories
-To install the lens, special expertise and skills are necessary. Be sure to ask our authorized dealer
(or a technician) to install the lens. Installation by personnel without the necessary expertise and
skills may result in injuries or electric shock.
-Do not look into the projection lens while the illumination lamp is turned on. Exposure of your
eyes to the strong light can result in impaired eyesight. Pay particular attention to keep out of
reach of children.
-Do not modify the lens. Modifying the lens may cause fire or electric shock.
-Connect the power cord only after all necessary equipment has been connected. Connecting the
equipment with the power cord plugged into the outlet may cause electric shock.
This product has been engineered and manufactured to assure your personal safety. But
IMPROPER USE CAN RESULT IN POTENTIAL ELECTRICAL SHOCK OR FIRE HAZARD. In order
not to defeat the safeguards incorporated into this product, observe the following basic rules for its
installation, use and service. Please read carefully before use.
Printed in Japan
© 2008 Victor Company of Japan, Limited 0608TTH-SW-VP LCT2476-002A
C
M
Y
CM
MY
CY
CMY
K
SH4KNL_EN_Lens_sheet-1.pdf 2008/06/04 21:10:15

Positioning Pin
Lens Cap
Lens Sheet
Front Cover
Top Panel
Positioning Pin
CN80Z0CN80F0
Clamp
Zoom Motor Cable
Motor
Lens Cap
Shift Lock Screw
Shift Lock Screw
Mounting the Lens
When a zoom lens is used
When a short focal length lens is used
●When removing the lens cap, pull out without turning it.
●Do not scratch or knock the lens surface.
● Connect the zoom motor cable (3 pin) to “CN80Z0”, and the focus motor cable (2 pin) to “CN80F0”.
● Connect the focus motor cable (2 pin) to “CN80F0”.
●Insert the lens with the motor facing upward.
●Align the positioning pin of the projector (1 each on left and right sides) with the positioning pin
of the lens.
2 Remove the lens sheet attached to the lens mount at the front cover
3 Remove the lens cap of the end to be inserted into the projector
4 Insert lens into the mounting hole
5 Tighten the 5 screws using the hexagonal wrench with a diagonal size of 3 mm (Bondhus
type recommended) to fasten the lens
7 Clamp the motor cable
6 Connect the motor cable
●Retain these shift lock screws for future use during transportation.
8 Unscrew the 2 shift lock screw
NOTE:
●Remove the top panel if possible to
ease the mounting process. For details on
how to remove the top panel, please consult
your authorized dealer or refer to the service
manual.
●Remove the lens cap before projection.
9 Attach the front cover, and fasten using the 6 screws using a Phillips screwdriver
CAUTION: Before attaching the lens, check to make sure that the power of the projector is not turned on and the
power cord is not connected. Failure to do so may cause electric shock or injuries.
1 Unscrew the 6 screws using a Phillips screwdriver to remove the front cover
5
4
1
2
6
7
Focus Motor
Cable CAUTION:
●Keep the cable away from the motor gear
when clamping the motor cable.
