The Next Stage in 4K

DLA-RS67
4K-resolution D-ILA Projector
• Industry’s highest dynamic contrast ratio: 1,500,000:1*
• Industry’s highest native contrast ratio: 150,000:1*
• Brightness: 1,300 lumens
*As of November 1, 2013 JVC data.
DLA-RS57
4K-resolution D-ILA Projector
• Dynamic contrast ratio: 1,200,000:1
• Native contrast ratio: 120,000:1
• Brightness: 1,300 lumens
DLA-RS49
4K-resolution D-ILA Projector
• Dynamic contrast ratio: 600,000:1
• Native contrast ratio: 60,000:1
• Brightness: 1,300 lumens

Conventional device New D-ILA device
New 6th generation
0.7-in. D-ILA device
The exceptional picture quality of JVC projectors is achieved by the
precision technology behind the company’s original D-ILA devices.
The latest device, which has an even narrower gap between pixels and
is planarised, achieves brighter images rich with contrast. The device is
optimally designed to complement ultra-high 4K resolution for precision
image expression with virtually no screen-
door effect.
Newly Developed Proprietary D-ILA Device
Original technologies to realise high-precision and high-denition 4K images
New D-ILA devices
e-shift device
Projection lens
Resolution doubles
in both directions
Enhanced e-Shift 3 Technology
D-ILA optical unit
JVC’s e-Shift technology shifts sub-frames by 0.5 pixel both vertically and
horizontally to achieve 4 times the pixel density of the original content.
Optimised for the new D-ILA device, the latest e-Shift 3 Technology
boosts denition to a higher level.
New e-Shift 3 Technology
High-performance image processing technology is necessary for the
precise reproduction of full HD sources on a 4K projector. JVC improved
its Multiple Pixel Control technology featured on new models. In addition
to wide-range picture detection and high-performance 8-band filtering,
Multiple Pixel Control
Auto Mode has been added that performs frame adaptive filtering and
picture generation to achieve a high-denition image optimal for a variety
of scenes. Multiple Pixel Control lets the user experience immersive 4K
images without complicated picture adjustments.
Each pixel is analyzed with
wide range (21 x 21) detec-
tion.
Multiple Pixel Control equipped with improved high-performance
4K scaling engine
Video signal is automatically
analyzed frame by frame
using 8-band filtering
Based on the detection and
filtering results, dynamic
controls are applied to the
background and foreground
separately for a richer 4K
image.
JVC’s advanced Multiple Pixel
Control reproduces 4K images that
look more natural and dimensional.
2K image
Input
4K resolution
Output
Wide-range picture
element detection
High-performance
filtering
Generate character
optimised images
ConventionalOriginal Image
Multiple Pixel Control
Facial texture is smooth and natural.
Each stand of hair is reproduced
with more precision.
Simulated picture

Conventional projector DLA-RS67
Contrast and colour imaging technologies to recreate images with realistic sensation.
The combination of JVC’s original D-ILA device and an optical engine
equipped with new wire grid to improve polarisation performance results
in the industry’s highest native contrast ratio of 150,000:1*. What’s more,
the industry's highest 1,500,000:1* dynamic contrast range is realised with
the newly developed Intelligent Lens Aperture that optimally adjusts black
level using an original algorithm to analyze the input video source, and
Clear Black that boosts the contrast between light and dark. Enjoy high-
denition video full of reality that can only be achieved with such a high
native contrast ratio.
* As of Nov. 1, 2013, JVC data
The Industry's Highest Dynamic Contrast Ratio of 1,500,000:1* Achieved with the Industry’s Highest 150,000:1 Native Contrast Ratio*
1,300 lumens brightness is achieved by virtue of a new optical engine equipped with new device that uses light more efficiently.
A bright picture with high chromatic purity is realised thanks to optic design that excels in real-life usage situations.
Brightness of 1,300 lumens to Reproduce High Chromatic Purity
Conventional colour temperature
setting
Xenon Mode colour temperature
setting
JVC’s Unique Real Colour Imaging Technology (DLA-RS67/RS57)
• Supports x.v.Colour for Wide Colour Space Reproduction
Featuring a colour space wider than that of Adobe RGB or DCI, the D-ILA
projectors vividly reproduce a fuller spectrum of colours such as the green
of trees, the blue of oceans, etc., which is difcult
to recreate accurately. Even wider “x.v.Colour”
colour space is supported, enabling viewers to
enjoy 4K video with rich colours incorporated in
the original 4K source.
• Xenon-lamp Colour Temperature Setting
Supports a colour temperature setting Xenon Mode, which is equivalent to
that of a Xenon lamp, a popular light source used in cinemas. This setting
allows for the authentic reproduction of colours similar to those of lm in
cinemas, while using highly efcient and economical ultra-high pressure
mercury lamps.
JVC original-development Real Colour Imaging Technology realises wider colour reproducibility and dramatically improves colour rendition with settings
for Xenon lamp colour temperature and new dedicated colour proles. Combined use of picture quality modes and dedicated colour proles results in 23
different ways to enjoy high quality images.
•
Featuring a Photo Mode that Reproduces the Texture of Photographs
Picture Mode now features a new Photo Mode. Subtle textures and colours
contained in still photos are precisely reproduced to enable dynamic
pictures to be enjoyed on the big screen.

RF (Radio Frequency) Method
PK-EM2
RF 3D Synchro Emitter
PK-AG3
RF 3D Glasses
Notes about viewing 3D video content
• The optional 3D Synchro Emitter and 3D glasses are required to view 3D
images from the D-ILA projectors. 3D video software (3D media or output
of 3D broadcasts) and a 3D-compatible video player are also required.
• Perception of 3D images will vary with individual viewers.
• Stop viewing 3D images immediately if any discomfort such as headaches,
dizziness, eye fatigue, etc. occurs.
• Viewing of 3D images by children under the age of five is not recommended.
• Read the Safety Precautions in the User Manual carefully before viewing any
3D source.
Picture adjustment functions and convenient features
Clear Motion Drive: Off Clear Motion Drive: On
Dramatic improvement has been applied to JVC’s original Clear Motion
Drive, including the adoption of a motion detection algorithm and high-
speed LSI to drastically reduce ghosting or afterimage in high-speed
scenes. This function works for 4K and 3D images to recreate clear and
smooth movement in the picture.
Clear Motion Drive 3
A 7-axis matrix of red, green, blue, cyan, magenta, yellow, and orange
ensures the precise adjustment of hue, saturation, and intensity. Selection
of the colour spectrum such as skin tones can be easily performed.
Colour Management System with 7-Axis Matrix
Screen adjustment mode OnScreen adjustment mode Off
The projector selects the best mode to match the screen being used for
images with natural colour balance.*
Screen Adjustment Modes
* Please refer to JVC website for a comparison table of primary screens
and adjustment modes.
The Pixel Adjust function allows users to precisely correct colour deviation
in 1/16-pixel increments. It is also capable of segmenting the entire screen
into 121 points and adjusting them individually to realise clearer video without
colour deviation. Two settings can be stored in the memory.
Pixel Adjust Function
This function stores ten separate lens adjustments for zoom, shift and focus
that can be easily recalled when needed. Memory settings can be switched
between each setup via the remote controller.
Lens Memory Function
Memory 1: Standard 16:9 Memory 2: CinemaScope size
Lens memory examples (when using CinemaScope screen)
Memory 3: CinemaScope size with
subtitles outside of the screen
In addition to JVC’s original Frame Addressing method to reproduce 3D
images with vivid colours, the optical engine featuring a set of new D-ILA
devices is capable of achieving more brightness. Furthermore, 3D image
adjustment functions such as Crosstalk Cancelling are featured to offer the
kind of realistic and exciting 3D images that only D-ILA can provide.
High Quality 3D Images of D-ILA
Using an optical sensor, precise calibration can be performed in just a few
easy steps, to match the installation situation of the projector such as its
location, lens shift/zoom position, etc.
* Exclusive JVC software installed on a PC connected to the projector via a LAN
connection and optical sensor are required to set viewing configurations and auto
calibration. Please visit the JVC website for the details.
Auto-calibration Function*
JVC D-ILA projectors can be controlled from smart devices such as
smartphones and tablets. The smart device remote control app features an
intuitive graphical UI and exclusive controls not found on the projector’s
supplied remote control for easy operation. Additionally, there are built-in
help functions for smoother operation.
Smoothly Control the Projector via a Smart Device
Industry Certied Projectors (DLA-RS67/RS57)
Equipped with ISF (Imaging Science Foundation)
Certified Calibration Controls (C3) mode
THX 3D Display Certification*
* Ideal screen-size performance is 90 inches diagonal (16:9).

3D entry class projector enables high quality viewing even in bright living
rooms by virtue of 1,300 lumens brightness and 50,000:1 native contrast.
*1 This function cannot be used while projecting in 3D mode. *2 50p/60p compatible with 4:2:0 colour base. *3 Requires a commercially available optical sensor and dedicated software as well as PC and LAN cables.
*4 Requires dedicated software as well as PC and LAN cables.
Model DLA-RS67 DLA-RS57 DLA-RS49 DLA-RS46
4K capability*1lll—
4K signal input*2lll—
3D capability llll
2D-3D converter llll
Multiple Pixel Control lll—
Environmental Setting llll
Auto calibration*3lll—
Picture Data In/Out*4lll—
Picture Tone lll—
Pixel Adjust l
(by 1/16-pixel increment, 2 memories) l (by 1/16-pixel increment, 2 memories) l (by 1/16-pixel increment, 2 memories) l (by 1-pixel increment, 1 memory)
Lens Memory l(10 memories) l(10 memories) l(5 memories) l(5 memories)
Clear Motion Drive Ver.3 Ver.3 Ver.3 Ver.2
THX 3D Display Certification l l — —
ISF C3 mode l l — —
MPC Analyser lll—
Real Colour Imaging Technology
l l — —
Colour Management 7-axis 7-axis 7-axis —
Colour Temperature (Xenon-lamp mode)
l l — —
Screen Adjustment Mode 106 Modes (up to 255 modes) 106 Modes (up to 255 modes) 106 Modes (up to 255 modes) 3 modes
Clear Black lll—
Darkness and Lightness Correction
lll—
Digital Keystone*1Vertical direction Vertical direction Vertical direction Both directions
Anamorphic Mode llll
Intelligent Lens Aperture lll—
Lens Aperture — — — l(16 steps)
Automatic Lens Cover l l — —
Feature Comparison
DLA-RS46
D-ILA Projector with 3D Viewing
• Bright picture realised with brightness of 1,300 lumens and
native contrast ratio of 50,000:1
• Bright 3D viewing with reduced crosstalk only possible
with D-ILA
• 6 Picture Modes and 3 Colour Spaces
• Environmental Setting
• 5-mode Lens Memory
• 3 Screen Adjustment Modes
• Pixel Adjust by 1 pixel increment

Projection Distance Chart
*1 Resolution is 1920x1080 at 3D mode.
*2 Measurement, measuring conditions, and method of notation all comply with ISO 21118.
*3 When the video input signal is at 4096 x 2160p, data above 3,840 is not displayed equally on the left and right.
Printed in Belgium
CCZ-3746-12
“JVC” is the trademark or registered trademark of JVC KENWOOD Corporation.
www.jvcpro.euDISTRIBUTED BY
Specifications
• D-ILA is a registered trademark of JVC KENWOOD Corporation. • e-shift is a registered trademark of JVC KENWOOD Corporation. • The projector is equipped with an ultra-high pressure mercury
lamp, which may break, emitting a loud noise, when it is subjected to shock or after it has been used for some length of time. • Please note that, depending on how the projector is used, there can
be considerable difference between individual lamps regarding how many hours they will operate before requiring replacement. • An additional payment is required for installation of a new lamp, if
necessary. • The projector lamp requires periodic replacement and is not covered by warranty. • Please be aware that, because the D-ILA device is manufactured using highly advanced technologies,
0.01% or fewer of the pixels may be non-performing (always on or off).
Design and specifications are subject to change without notice. All pictures on this brochure are simulated. Adobe is a trademark or registered trademark of Adobe Systems Incorporated in the U.S.
and/or other countries. ISF is a registered trademark of Imaging Science Foundation, Inc. THX and THX logo are trademarks of THX Ltd., which may be registered in some jurisdictions. HDMI, the HDMI
logo and High-Definition Multimedia Interface are registered trademarks of HDMI Licensing LLC. All other brand or product names may be trademarks and/or registered trademarks of their respective
owners. Any rights not expressly granted herein are reserved.
Copyright © 2013, JVC KENWOOD Corporation. All Rights Reserved.
*Projection distances are design specifications, so there is ±5% variation.
Connectors
DLA-RS46DLA-RS67/RS57/RS49
Optional Equipment
PK-L2312U
User-replaceable Lamp
PK-AG3
RF Method
3D Glasses
PK-EM2
RF Method
3D Synchro Emitter
Not suitable for household
room illumination
Top Bottom
Rear: DLA-RS46 Rear: DLA-RS67/RS57/RS49
External Dimensions (unit: mm)
Display size (16:9) Projection distance
Screen diagonal
(inch) W (mm) H (mm) Wide (m) Tele (m)
60 1,328 747 1.78 3.66
70 1,549 872 2.09 4.28
80 1,771 996 2.40 4.89
90 1,992 1,121 2.70 5.51
100 2,214 1,245 3.01 6 .13
110 2,435 1,370 3.31 6.75
120 2,656 1,494 3.62 7. 3 6
130 2,878 1,619 3.92 7. 9 8
140 3,099 1,74 3 4.23 8.60
150 3,320 1,868 4.53 9.22
160 3,542 1,992 4.84 9.84
170 3,763 2,117 5.14 10.45
180 3,984 2,241 5.45 11.07
190 4,206 2,366 5.75 11. 6 8
200 4,427 2,490 6.06 12.30
Front Side (left)
DLA-RS67 DLA-RS57 DLA-RS49 DLA-RS46
Device 0.7 inch Full HD D-ILA (1920 x 1080) x3
4K e-shift 3 Technology l-—
Resolution 3840 x 2160*11920 x 1080
Lens x2 Zoom & Focus: Motorised; f=21.4-42.8mm / F3.2-4
Lens Shift ±80% Vertical and ±34% Horizontal (motorised)
Projection Display Size 60 inch – 200 inch (diagonal)
Light Source Lamp NSH 230W (lamp life: approx. 4,000 hours when the lamp is in Low mode)
Brightness 1,300 lumens*2
Contrast
Ratio
Dynamic 1,500,000 :1 1,200,000:1 600,000 :1-—
Native 150,000:1 120,000 :1 60,000 :1 50,000:1
Input
Terminal
Component —
1 (RCA;Y,Pb/Cb,Pr/Cr)
HDMI 2 (3D/Deep Colour/CEC compatible)
Output
Terminals
Trigger 1 (Mini jack, DC12V/100mA)
3D Sync 1 (Mini DIN 3pin)
Control
Terminals
RS-232C 1 (D-sub 9pin)
Remote — 1 (Mini jack)
LAN (RJ-45) 1
Video Input
Signal
Format
Digital 480p, 576p, 720p 60/50, 1080i 60/50, 1080p 60/50/24,
3840 x 2160p 60/50/30/25/24, 4096 x 2160p*3
24
480i/p, 576i/p,
720p 60/50, 1080i 60/50,
1080p 60/50/24
Analogue —480i/p, 576i/p,
720p 60/50,1080i 60/50
PC Input Signal Format
(HDMI)
VGA/SVGA/XGA/WXGA/FWXGA/WXGA+/SXGA/WXGA++/
WSXGA+/WUXGA
VGA/SVGA/XGA/WXGA/
WXGA+/SXGA/WSXGA+/
WUXGA
3D Format
Frame
Packing 720p 60/50, 1080p 24, 1080i 60/50
Side-by-Side
(half) 720p 60/50, 1080p 60/50/24, 1080i 60/50
Top & Bottom 720p 60/50, 1080p/24
Power Consumption 360W (Normal standby: 7W, Eco-mode standby: 0.4W)
330W (Normal standby:
0.8W, Eco-mode
standby: 0.4W)
Fan Noise 21dB (When the lamp is in Low mode)
23dB (When the lamp is in
Low mode)
Power Requirement AC110V-240V, 50/60Hz
Dimensions (W x H x D) 455mm x 179mm x 472mm
Weight (net) 15.0kg 14.7kg 14.8kg
