DLA-X Series
DLA-X75R
4K-resolution D-ILA Projector
Powerful combination of 4K-resolution*1images,
natural looking 3D, and native contrast ratio of 90,000:1.
High-end model that lets you enjoy the visual dynamics
of movies.
DLA-X95R
4K-resolution D-ILA Projector
Premium JVC D-ILA projector model that adopts
high-grade hand selected parts, realizes 4K*1resolution
and industry leading* native contrast ratio of 130,000:1.
*As of November 2012

Redefining Excellence
High quality viewing for 2D & 3D, even in bright living rooms with 1300
lumens brightness and 50,000:1 native contrast ratio.
DLA-X35
D-ILA Projector with 3D Viewing
DLA-X55R
4K-resolution D-ILA Projector
Super-high 4K-resolution*1enjoyment offers native contrast ratio of
50,000:1 for bright images, plus a variety of image quality optimization
functions.
*1 3840 x 2160

Beyond JVC, there’s JVC.
Experience the reality of images that seem to oat in mid-air,
as you forget the existence of the screen.
Be totally immersed in the world that is portrayed, as images envelop you.
Beyond 2K is a new world of moving experiences that only 4K can deliver.
JVC’s image processing technologies are able to reproduce the nest
nuances and unique tone of every visual work, enabling you to enjoy
a 4K-resolution* image with extreme realism and presence
in your home theater environment.
* 3840 x 2160

JVC Extreme 4K Resolution Realized by e-shift 2 Technology (DLA-X95R/X75R/X55R)
The original e-Shift device used liquid crystals to shift the
subframes by 0.5 pixel both vertically and horizontally to
achieve 4 times the pixel density of the original content.
e-shift2 features signicant enhancements, including an
all-new optical device. Our new e-shift2 device shifts the
image without the use of liquid crystals, resulting in better
overall resolution linearity and ANSI contrast with dynamic
4K resolution and detail.
Structure of D-ILA optical engine equipped with e-shift 2 Technology
Illustrated representation of pixel shift.
Scaler for the e-shift 2 Technology — Multiple Pixel Control (DLA-X95R/X75R/X55R)
Superior image processing technology is essential in order
to reproduce full HD resolution images on a 4K projector.
By advancing our image processing technology to new levels
based on JVC’s original algorithm, we were able to develop a new
high-performance 4K scaling engine as a part of the e-shift 2
Technology. This makes it possible to reproduce full HD images
with maximum definition and also convert them to even higher
quality 4K-resolution images. With Multiple Pixel Control, the
detection range has been vastly expanded to over ten times that
of conventional models*, making it possible to detect a wide range
of signal bands within the frame.What’s more, based on high-
precision detection results — which uses an improved detector with
rened bandwidth division from a conventional 2 bands to 8 bands
— JVC’s original image quality processing that performs optimum
filtering, dynamically controls the background blur and focus is
applied, resulting in natural, expressive 4K images. Five types
of 4K Profiles are available to apply optimal processing to each
specic type of visual material. It is therefore possible to play back
high-quality images while enjoying the best any source has to offer.
*Compared to DLA-X90R/X70R
Facial tones with unnatural, rough gradations will be
reproduced as smooth and natural facial tones.
Reproduces a scene with more solid contrast.
Lights are brighter and crisper while blacks are
deeper and detailed.
By detecting focused and out-of-focus areas in real time,
it is possible to reproduce images with clear foreground
while adding depth to the background.
-Effects Achieved with the Multiple Pixel Control
-e-shift 2 Technology's Image Processor: Multiple Pixel Control
Inpu t
2K image
JVC’s advanced high-resolution technology
reproduces 4K images that look more natural
and dimensional.
Output
4K-resolutio n
Generation of
character optimized
images
Controls the background blur and
applies focus for each pixel
through results achieved from
wide-range detection and optimum
ltering to generate character
optimized images
Conventional image:
Pixel per pixel
Image with e-shift: 0.5 pixel
shift in the diagonal direction.
Resolution virtually doubles
verticallyand horizontally to
display 4K-resolution
(3,840 x 2,160 pixels) images.

D-ILA 3D Projection
Leaps Further in Quality
Frame Addressing
Image overlapping (crosstalk) is reduced because the shutter on 3D glasses can be left open
longer as the method draws each frame of the picture individually.
As the shutter can be left open for a longer period, crosstalk is not generated as each frame
of the picture is drawn individually without overlap.
Line Addressing
Crosstalk can be generated when shutters are switched between the left and right eyes, and
opened only for a short amount time. This can cause the picture to darken and lose brightness.
Crosstalk generated where left and right eye pictures overlap during which time,
the shutter is closed.
High Quality 3D Images with D-ILA
In addition to JVC’s original Frame Addressing method to reproduce
3D images with vivid colors, we also improved the conversion
accuracy of the optical engine and 3D glasses to achieve a 20%
increase in brightness.* Furthermore, the crosstalk that can occur
with 3D images is dramatically reduced. Enjoy the kind of realistic
and exciting 3D images that only D-ILA can provide.
*Compared to DLA-X90R/X70R/X30
3D Picture Adjustment Functions
• Crosstalk Cancelling for pictures easier on the eyes
• Disparity Adjustment for more natural stereoscopic reproduction
• Depth Adjustment* for matching depth characteristics to source
• Subtitle Adjustment* xes distorted subtitles
Two types of 3D glasses are available — IR (infrared) and RF (radio frequency)
wireless, which provides more exible use.
Full Selection of Optional Accessories to Maximize Your 3D Enjoyment
Notes about viewing 3D video content
• The optional 3D Synchro Emitter and 3D glasses are
required to view 3D images from the D-ILA projectors. 3D
video software (3D media or output of 3D broadcasts) and a
3D-compatible video player are also required.
• Perception of 3D images will vary with individual viewers.
• Stop viewing 3D images immediately if any discomfort such
as headaches, dizziness, eye fatigue, etc. occurs.
• Viewing of 3D images by children under the age of ve is not
recommended.
• Read the Safety Precautions in the User Manual carefully
before viewing any 3D source.
PK-AG3
RF 3D Glasses
• Rechargeable
• Lightweight - 1.34 oz
• Continuous operation
approx. 100H
PK-EM2
RF 3D Synchro Emitter
• Wireless (direct connec-
tion with the projector)
• Weight .7 oz
• Dimensions (WxDxH):
1.93” x .57” x 2.56”
RF (Radio Frequency) Method
• Rechargeable
• Lightweight - 1.41 oz
• Continuous operation
approx. 40H
PK-AG2
IR 3D Glasses
PK-EM1
IR 3D Synchro Emitter
• Supplied with 3m
connection cable
• Weight - 5.64 oz
• Dimensions (WxDxH):
3.15” x 1.97” x 3.54”
(including the stand)
IR (Infrared) Method
*Feature available only during 2D-3D conversion.

Cinema-like Quality Realized by D-ILA
Native Contrast Ratio
Further performance improvements for our optical engine utilizing JVC’s
original D-ILA device and a wire grid have resulted in a high native contrast
ratio. Over a broad dynamic range from peak whites to deep blacks, the image
conveys powerful presence as a result of high native contrast. The DLA-X95R
is capable of achieving industry’s highest native contrast ratio of 130,000:1*
with the adoption of high-grade parts and optimized optical engine.
Conventional projector DLA-X95R *As of November 2012.
Color Management System with 7-Axis Matrix
(DLA-X95R/X75R/X55R)
A 7-axis matrix of red, green, blue, cyan, magenta, yellow, and orange ensures
the precise adjustment of hue, saturation, and intensity. The last axis of
orange helps in enhancing the selection of the color spectrum for skin tones.
And for improved operability, only the color being adjusted will be shown on
the screen while the others are displayed in black and white.
The color being adjusted is
shown in color. Screen adjustment mode O Screen adjustment mode On
Screen Adjustment Modes*
Reective characteristics that differ from screen to screen are precisely
analyzed and the projector selects the best mode to match the screen being
used. With the appropriate mode* selected, the picture displayed will always
be precisely adjusted to ensure excellent image reproduction with natural
color balance.
*Three modes for the DLA-X55R/X35. The DLA-X95R/X75R offers 105 modes
but with a rmware update, it provides a maximum of 255 modes. Please refer to
our corporate website for a comparison table of primary screens and adjustment
modes.
JVC’s Unique Real Color Imaging Technology (DLA-X95R/X75R/X55R)
JVC's original Real Color Imaging Technology precisely interprets the ne color reproduction information in the
image to dramatically improve color rendition in a way that is true to the original image source.
Real Color Imaging Technology also incorporates a Xenon-mode color
temperature setting equivalent to that of a Xenon lamp, a popular light
source used in cinemas. This setting allows for the authentic reproduction
of colors similar to those of lm in cinemas, while using highly efcient and
economical ultra-high pressure mercury lamps.
• Xenon-lamp Color Temperature Setting
(DLA-X95R/X75R)
Conventional
color temperature setting
Xenon-mode
color temperature setting
• Color Space Wider than Adobe RGB
(DLA-X95R/X75R)
Real Color Imaging Technology features a
color space wider than that of Adobe RGB to
vividly reproduce a fuller spectrum of colors
such as the green of trees, the blue of oceans,
etc., which was difcult to recreate accurately
up until now.
DLA-X95R/75R
• Dedicated Color Profile
JVC was able to create a dedicated color prole by focusing on the color
space information that characterizes an image, and accurately understanding
the ne color expression information that an image has. This time, we have
added a new color prole for Film, as well as three* proles exclusively for 3D.
Combined use of picture quality modes and dedicated color proles results in
19* different ways to enjoy high quality images.
*X55R offers two 3D color proles, resulting in 12 different ways.

Environmental Setting
An environmental setting function has been incorporated to minimize the effect of the projection environment on image quality, such as wall color. Simply input
screen size, viewing distance and wall color, and the projector will automatically apply image compensation so that high quality images can be enjoyed in just
about any viewing environment.
Industry Certified Projectors (DLA-X95R/X75R)
The DLA-X95R and X75R are accredited with THX 3D Certication, which
was established to ensure the precise reproduction of picture quality in
home environments for both 2D and 3D content just as the original lmmaker
envisioned. Encompassing more than 400 laboratory tests to evaluate a
projector’s color accuracy, cross-talk, viewing angles and video processing,
this certication helps to guarantee high-denition quality.
*1 Ideal 3D screen-size performance is 90 inches diagonal (16:9).
THX 3D Display Certification*1
The DLA-X95R and X75R are licensed with the ISF C3 (Certied Calibration
Controls) mode, enabling trained dealers to professionally calibrate them to
desired screen surfaces, lighting environments and video sources, and then
securely store these precise settings into the projector. This not only helps
to ensure the reproduction of lm or video content accurate to the source but
also excellent picture quality optimized for specic environments.
Certified by ISF
(Imaging Science Foundation)
Clear Motion Drive*
Utilizing enhanced detection-interpolation technology through high-precision
interpolation algorithms, Clear Motion Drive helps to smooth movement in
the picture by reducing blur that can be generated in high-speed scenes
such as sports events, etc. Additionally, as the amount of picture delay is
very limited, D-ILA projectors are also well suited for playing video games.
Original Picture Tone Function
(DLA-X95R/X75R/X55R)
The Picture Tone function works to balance gamma, contrast, and brightness
settings without affecting the grey scaling of the original source to enable
brightness adjustment that better matches the surrounding environment.
Clear Motion Drive: ON
Clear Motion Drive: OFF
-16 ±0
+16 *Feature not available in 3D mode.

A Variety of Convenient Functions
Automatic Lens Cover (DLA-X95R/X75R)
A unique automatic lens cover opens and closes upon power On/Off
to protect against dust or damage to ensure users of easy, trouble-free
operation via the remote controller, even if the projector is installed on the
ceiling.
Lens cover closed (power off) Lens cover open (power on)
Flexible Installation Guaranteed with
Powered Lens-shift Function
Flexible installation is made possible thanks to the ±80% vertical and ±34%
horizontal powered lens-shift function. The projector also feature a high-
performance 2X zoom lens with motorized focus that can project images
upon a large 100-inch screen at throw distances of between 9.8 and 20 feet.
With the high-performance motor, the once tedious tasks of setting zoom
ratios and focus adjustments are now made simple and effortless. In addition,
the lens-center function makes it easy to return the lens to the default center
position.
The vertical and horizontal lens shift function cannot be set to
the maximum values simultaneously.
Pixel Adjust Function
The Pixel Adjust function allows users to precisely correct color deviation in
1/16-pixel increments*, and it is also capable of segmenting the entire screen
into 121 points and adjust them individually to realize clearer video without
color deviation.
*DLA-X35 enables adjustment in 1-pixel increments.
A Wide Range of Inputs and Outputs
In addition to 3D compatible HDMI inputs, the projector features an array
of other connections, such as an RJ45 connection for projector control,
firmware and configuration updates, and a trigger connection for an
anamorphic lens or motorized screen.
Digital Keystone Function*
Keystone distortion that occurs when the projector is placed on a tilt
position can be adjusted using this function. Digital Keystone can also
adjust to curved screens with its Pincushion Function.
16-step Aperture
A 16-step aperture function enables brightness adjustment to not only
suit user preferences but also operating ambiences, helping to ensure
deeper and truer black levels.
Lens Memory Function
This function stores ten or ve* separate lens adjustments for zoom, shift
and focus that can be easily recalled when needed. Focus, zoom (size) and
shift (display position) characteristics can be recorded for video content
in different aspect ratios such as when using a CinemaScope screen size
(2.35:1) or standard 16:9 screen and easily switched between each setup via
the remote controller.
Lens memory examples (when using CinemaScope screen)
*Ten memories for the
DLA-X95R/X75R. Five memories
for the DLA-X55R/X35.
Memory 1: Standard 16:9 Memory 2: CinemaScope size
Memory 3: CinemaScope size with
subtitles outside of the screen
Anamorphic Mode for Wide Cinematic Films
A 2.35:1 aspect ratio for wide cinematic lms can be enjoyed by combining
the projector with a third-party anamorphic lens to create dynamic picture
reproduction as can be seen in a movie theatre.
Mode off: 16:9 screen Mode on: 2.35:1 screen
When using an anamorphic lens.
*Digital keystone cannot be used in 3D mode.

LINE-UP
• High-denition 4K projection (3840 x 2160)
achieved with e-shift 2 Technology including
Multiple Pixel Control original picture processor
• 50,000:1 high native contrast ratio
• Bright 3D viewing with reduced crosstalk only
possible with D-ILA
• Environmental Setting
• 5-mode Lens Memory
• 3 Screen Adjustment Modes
• Pixel Adjust by 1/16-pixel increment
DLA-X55R
4K-Resolution D-ILA Projector
Super-high 4K-resolution enjoyment offers native
contrast of 50,000:1 for bright images, plus a
variety of image quality optimization functions.
JVC D-ILA projector premium model adopts high-grade
parts, realizes 4K resolution and industry leading* native
contrast of 130,000:1.
*As of November 2012
• High-denition 4K projection (3840 x 2160)
achieved with e-shift 2 Technology including
Multiple Pixel Control original picture processor
• Improved optical engine employing high-grade
parts, realizes industry’s highest
native contrast ratio of 130,000:1
• Bright 3D viewing with reduced crosstalk
only possible with D-ILA
• Equipped with JVC’s original Real Color
Imaging Technology for accurate color
reproduction
• Automatic Lens Cover
DLA-X95R
4K-Resolution D-ILA Projector
Model Native
Contrast
4K
with e-shift 2
Technology
3D
Viewing
2D-3D
Conversion
16-step
Aperture
Clear
Motion Drive*2
Real Color
Imaging
Technology
7-Axis Color
Management
Xenon
Lamp Mode Picture Tone
Darkness/
Lightness
Correction
Pixel Adjust
Screen
Adjustment
Mode
Environmental
Setting
Anamorphic
Mode
Pic. Data
IN/OUT*3Lens Memory Digital
Keystone*2
Lens
Cover
THX
Certified ISF
DLA-X95R 130,000:1
1/16-pixel Max. 255 10 Automatic
DLA-X75R 90,000:1
1/16-pixel Max. 255 10 Automatic
DLA-X55R 50,000:1
1/16-pixel 3 modes 5
DLA-X35 50,000:1
1 pixel 3 modes 5




















































• Bright picture realized with brightness of 1300
lumens and native contrast ratio of 50,000:1
• Bright 3D viewing with reduced crosstalk only
possible with D-ILA
• 6 Picture Modes and 3 Color Spaces
• Environmental Setting
• 5-mode Lens Memory
• 3 Screen Adjustment Modes
• Pixel Adjust by 1 pixel increment
DLA-X35
D-ILA Projector with 3D Viewing
High quality viewing for both 2D & 3D even in
bright living rooms with 1300 lumens brightness
and 50,000:1 native contrast.
Powerful combination of 4K-resolution images, natural
looking 3D, and native contrast of 90,000:1.High-
end model that lets you enjoy the visual dynamics of
movies.
DLA-X75R
4K-Resolution D-ILA Projector
• High-denition 4K projection (3840 x 2160)
achieved with e-shift 2 Technology including
Multiple Pixel Control original picture processor
• 90,000:1 exceptionally high native contrast ratio
• Bright 3D viewing with reduced crosstalk only
possible with D-ILA
• Equipped with JVC’s original Real Color Imaging
Technology for accurate color reproduction
• Various picture correction and adjustment
functions
• Automatic Lens Cover
Model Native
Contrast
4K
with e-shift 2
Technology
3D
Viewing
2D-3D
Conversion
16-step
Aperture
Clear
Motion Drive*2
Real Color
Imaging
Technology
7-Axis Color
Management
Xenon
Lamp Mode Picture Tone
Darkness/
Lightness
Correction
Pixel Adjust
Screen
Adjustment
Mode
Environmental
Setting
Anamorphic
Mode
Pic. Data
IN/OUT*3Lens Memory Digital
Keystone*2
Lens
Cover
THX
Certified ISF
DLA-X95R 130,000:1
1/16-pixel Max. 255 10 Automatic
DLA-X75R 90,000:1
1/16-pixel Max. 255 10 Automatic
DLA-X55R 50,000:1
1/16-pixel 3 modes 5
DLA-X35 50,000:1
1 pixel 3 modes 5



















































*2 Feature not available in 3D mode. *3 Requires a PC and LAN cable.

18
1/2”
3/16”
17
7/8”
1
3/4”
1
3/4”
3
1/2”
7/16”
5”
18
1/2”
7”
1”
2
1/3”
1
3/4”
1
3/4”
7/16”
5”
1
3/4”
1
3/4”
7/16
5”
13
1/4”
11
7/16”
3
9/16”
4
9/16”
2
1/8”
2
1/4”
1
9/16”
1
1/2”
3
1/8”
1
7/8”
11755
48
DLA-X95R DLA-X75R DLA-X55R DLA-X35
Device 0.7 inch Full HD D-ILA (1920 x 1080) x3
4K e-shift 2 Technology Yes −
Resolution 3840 x 2160*1 1920 x 1080
Lens x2 Zoom & Focus: Motorized
f=21.4-42.8mm / F3.2-4
Lens Shift ±80% Vertical and ±34% Horizontal (Motorized)
Light Source Lamp NSH 230W
(lamp life: up to 4000 hours when the lamp is in Low mode)
Brightness*21,200lm 1,300lm
Contrast Ratio (Native) 130,000:1 90,000:1 50,000:1
Connectors
Component 1 (RCA; Y, PB/CB, PR/CR)
HDMI 2 (3D/Deep Color/CEC compatible)
Analog RGB (PC) 1 (D-sub15pin) −
RS-232C 1 (D-sub 9pin)
LAN
(RJ-45) 1
Trigger 1 (Mini jack, DC12V/100mA)
Remote 1 (Mini jack)
3D Sync 1 (Mini Din 3pin)
Video Input
Signal Format
Digital 480i/p, 576i/p, 720p 60/50, 1080i 60/50,
1080p 60/50/24
Analog 480i/p, 576i/p, 720p 60/50, 1080i 60/50
PC Input Signal
Format
HDMI VGA/SVGA/XGA/WXGA/WXGA+/SXGA/WSXGA+/WUXGA
Analog RGB
(D-sub 15 pin)
VGA/SVGA/XGA/WXGA/WXGA+/
SXGA/SXGA+/WSXGA+/
1920x1080/Mac 13”, 16”, 19”
−
3D Format
Frame Packing 720p 60/50, 1080p 24, 1080i 60/50
Side-by-Side
(half) 720p 60/50, 1080p 60/50/24, 1080i 60/50
Top & Bottom 720p 60/50, 1080p/24
Power Requirement AC 110-240V, 50/60Hz
Power Consumption 360W (Standby: 0.4W) 330W
(Standby: 0.4W)
Fan Noise 23dB (When the lamp is in Low mode)
Dimensions (WxHxD) 17 7/8” x 7” x 18 1/2” inches
Weight 33.95 lbs 33.29 lbs 32.63 lbs
Main Features
Projection Distance Chart
Display size (16:9) Projection distance
Screen diagonal (inch) W (mm) H (mm) Wide (m) Tele (m)
60 1,328 747 1.78 3.66
70 1,549 872 2.09 4.28
80 1,771 996 2.40 4.89
90 1,992 1,121 2.70 5.51
100 2, 214 1,245 3.01 6.13
110 2,435 1,370 3.31 6.75
120 2,656 1,494 3.62 7. 3 6
130 2,878 1,619 3.92 7. 98
140 3,099 1,743 4.23 8.60
150 3,320 1,868 4.53 9.22
160 3,542 1,992 4.84 9.84
170 3,763 2,117 5.14 10.45
180 3,984 2,241 5.45 11.07
190 4,206 2,366 5.75 11. 68
200 4,427 2,490 6.06 12 .30
*Projection distances are design specications, so there is ±5% variation.
*1 Feature not available in 3D mode. *2 Requires a PC and LAN cable. *1 Resolution is 1920x1080 at 3D mode.
*2 Measurement, measuring conditions, and method of notation all comply with ISO 21118.
"JVC" is the trademark or registered trademark of JVC KENWOOD Corporation.
JVC Consumer A/V Group | A Division of JVC Americas Corp.
1700 Valley Road, Wayne NJ 07470
DISTRIBUTED BY
Specications
• The projector is equipped with a New Super High Pressure mercury lamp, which may break, emitting a loud noise, when it is subjected to shock or after it has been used for some length of time. • Please
note that, depending on how the projector is used, there can be considerable difference between individual lamps regarding how many hours they will operate before requiring replacement. • An additional
payment is required for installation of a new lamp, if necessary. • The projector lamp requires periodic replacement and is not covered by warranty. • Please be aware that, because the D-ILA device is
manufactured using highly advanced technologies, 0.01% or fewer of the pixels may be non-performing (always on or off).
Design and specications are subject to change without notice. All pictures on this brochure are simulated. Adobe is a trademark or registered trademark of Adobe Systems Incorporated in the U.S. and/
or other countries. ISF is a registered trademark of Imaging Science Foundation, Inc. THX and THX logo are trademarks of THX Ltd., which may be registered in some jurisdictions. HDMI, the HDMI logo
and High-Denition Multimedia Interface are registered trademarks of HDMI Licensing LLC. Microsoft, Windows, Windows Vista are trademarks or registered trademarks of Microsoft Corporation in the U.S.
and other countries. All other brand or product names may be trademarks and/or registered trademarks of their respective owners. Any rights not expressly granted herein are reserved.
Copyright Q 2012, JVC KENWOOD Corporation. All Rights Reserved.
Top Bottom
Rear: DLA-X55R/X35 Rear: DLA-X95R/X75R
External Dimensions (unit: mm)
Connectors
DLA-X55R/X35DLA-X95R/X75R
Optional Equipment
IR 3D Glasses
PK-AG2
Rechargeable
Typ e
RF 3D Glasses
PK-AG3
Rechargeable Type
IR 3D Synchro
Emitter
PK-EM1
RF 3D Synchro
Emitter
PK-EM2
User-replaceable
Lamp
PK-L2312U
RF (Radio Frequency) Method IR (Infrared) Method
DLA-X95R DLA-X75R DLA-X55R DLA-X35
4K Capability −
3D Capability 
2D-3D Converter 
Aperture (16 steps)
Clear Motion Drive*1
Color Management (7-axis) −
Color Temperature
(Xenon-lamp Mode)−
Picture Tone −
Darkness and Lightness
Correction −
Pixel Adjust 
(by 1/16-pixel increment)

(by 1 pixel increment)
Screen Adjustment Mode (Max 255 modes) (3 modes)
Environmental Setting 
THX Certification −
ISF C3 −
Anamorphic Mode −
Picture Data In/Out*2−
Lens Memory (10 memories) (5 memories)
Digital Keystone*1−
Automatic Lens Cover −
