SERVICE MANUAL
AUDIO/VIDEO CONTROL RECEIVER
No.21002
Jun. 2001
COPYRIGHT 2001 VICTOR COMPANY OF JAPAN, LTD.
RX-8012VSL
RX-8010VBK
RX-8012VSL/RX-8010VBK
UJ U.S.Military
Contents
Safety precautions -----------------------------------------------------------1-2
Disassembly method --------------------------------------------------------1-3
Adjustment method ----------------------------------------------------------1-9
Self-diagnose function -------------------------------------------------------1-10
Description of major ICs ----------------------------------------------------1-12~28
DIGITAL
UW Brazil,Mexico,Peru
Area Suffix
RX-8012VSL
RX-8010VBK
CONTROL
DOWN UP
EFFECT SETTING
DIGITAL
EQ
TV SOUND/DBSVIDEOVCR 2VCR 1DVDDVD MULTI
MIDNIGHT MODEDSP MODE
S-VIDEO VIDEO
VIDEO
L—AUDIO—R
SURROUND ON/OFF
SUBWOOFER OUT ON/OFF
SPEAKERS ON/OFF
FM/AM TUNING FM/AM PRESET FM MODE
MEMORY
PHONES
1
STANDBY
USB AUDIO
PUSH OPEN
INPUT
ANALOG/DIGITAL
INPUT ATT
FM / AMUSB AUDIOTAPE / MDCDRCDPHONO
LEVEL
ADJUST
RX-8012V AUDIO/VIDEO CONTROL RECEIVER
LINE DIRECT
BASS BOOST
MASTER VOLUME
DIGITAL
SURROUND DIGITAL
2
SOUCE NAME
SOUCE NAME
STANDBY/ON
CONTROL
231
564
89
7/P
0+1010
LINE DIF.ECT BOOST EFFECT
MENU
ENTER
SIZE
ROOMBASS
MODE TEST CTRTONE
LIVENESS
MIDNIGHT
SOUND SUBWFR
DIGITALEQ REAR L REAR R
L/R BAL CENTER
MUTING
CH/ LEVEL TV VOL
PLAY
STOP
/REW
DOWN – TUNING – UP
FF/
EXIT
BAL L
BAL R
VOLUME
CATV/DBS
CONTROL
TV/VIDEO
MENU
TEXT
REC
DISPLAY
PAUSE
PAUSE
SET
RETURN FM MODE 10 0+
CONTROL
A/V CONTROL RECEIVER
CATV/ DBS VCR 1 TV AUDIO
DSP
MODE INPUTON/OFF
DVD MUILTIDVD
USB
CD
CDR
TAPE/MD
TV/DBS VIDEO PHONO
FM/AM
VCR 1 VCR 2
SURROUND
ANALOG/DIGITAL SLEEP
RM-SRX8012U
Model Color
RX-8012VSL
RX-8010VBK Black
Silver

RX-8012VSL/RX-8010VBK
1-2
1. This design of this product contains special hardware and many circuits and components specially for safety
purposes. For continued protection, no changes should be made to the original design unless authorized in
writing by the manufacturer. Replacement parts must be identical to those used in the original circuits. Services
should be performed by qualified personnel only.
2. Alterations of the design or circuitry of the product should not be made. Any design alterations of the product
should not be made. Any design alterations or additions will void the manufacturer's warranty and will further
relieve the manufacture of responsibility for personal injury or property damage resulting therefrom.
3. Many electrical and mechanical parts in the products have special safety-related characteristics. These
characteristics are often not evident from visual inspection nor can the protection afforded by them necessarily
be obtained by using replacement components rated for higher voltage, wattage, etc. Replacement parts which
have these special safety characteristics are identified in the Parts List of Service Manual. Electrical
components having such features are identified by shading on the schematics and by ( ) on the Parts List in
the Service Manual. The use of a substitute replacement which does not have the same safety characteristics
as the recommended replacement parts shown in the Parts List of Service Manual may create shock, fire, or
other hazards.
4. The leads in the products are routed and dressed with ties, clamps, tubings, barriers and the like to be
separated from live parts, high temperature parts, moving parts and/or sharp edges for the prevention of
electric shock and fire hazard. When service is required, the original lead routing and dress should be
observed, and it should be confirmed that they have been returned to normal, after re-assembling.
5. Leakage current check (Electrical shock hazard testing)
After re-assembling the product, always perform an isolation check on the exposed metal parts of the product
(antenna terminals, knobs, metal cabinet, screw heads, headphone jack, control shafts, etc.) to be sure the
product is safe to operate without danger of electrical shock.
Do not use a line isolation transformer during this check.
Plug the AC line cord directly into the AC outlet. Using a "Leakage Current Tester", measure the leakage
current from each exposed metal parts of the cabinet, particularly any exposed metal part having a return
path to the chassis, to a known good earth ground. Any leakage current must not exceed 0.5mA AC (r.m.s.).
Alternate check method
Plug the AC line cord directly into the AC outlet. Use an AC voltmeter having, 1,000 ohms per volt or more
sensitivity in the following manner. Connect a 1,500 10W resistor paralleled by a 0.15 F AC-type capacitor
between an exposed metal part and a known good earth ground.
Measure the AC voltage across the resistor with the AC
voltmeter.
Move the resistor connection to each exposed metal part,
particularly any exposed metal part having a return path to
the chassis, and measure the AC voltage across the resistor.
Now, reverse the plug in the AC outlet and repeat each
measurement. Voltage measured any must not exceed 0.75 V
AC (r.m.s.). This corresponds to 0.5 mA AC (r.m.s.).
1. This equipment has been designed and manufactured to meet international safety standards.
2. It is the legal responsibility of the repairer to ensure that these safety standards are maintained.
3. Repairs must be made in accordance with the relevant safety standards.
4. It is essential that safety critical components are replaced by approved parts.
5. If mains voltage selector is provided, check setting for local voltage.
Good earth ground
Place this
probe on
each exposed
metal part.
AC VOLTMETER
(Having 1000
ohms/volts,
or more sensitivity)
1500 10W
0.15 F AC TYPE
!
Burrs formed during molding may
be left over on some parts of the
chassis. Therefore, pay attention to
such burrs in the case of
preforming repair of this system.
In regard with component parts appearing on the silk-screen printed side (parts side) of the PWB diagrams, the
parts that are printed over with black such as the resistor ( ), diode ( ) and ICP ( ) or identified by the " "
mark nearby are critical for safety.
When replacing them, be sure to use the parts of the same type and rating as specified by the manufacturer.
(Except the J&C version)
http://getMANUAL.com

RX-8012VSL/RX-8010VBK
1-3
Remove the four screws Aattaching the top cover
on both sides of the body.
Remove the three screws Bon the back of the body.
Remove the top cover from behind in the direction of
the arrow while pulling both sides outward.
1.
2.
3.
Disassembly method
Removing the top cover (See Fig.1)
Prior to performing the following procedure, remove
the top cover.
Remove the power cord stopper from the rear panel
by moving it in the direction of the arrow.
Remove the thirty four screws Eattaching the each
boards to the rear panel on the back of the body.
Remove the three screws Fattaching the rear panel
on the back of the body.
1.
2.
3.
Removing the rear panel (See Fig.4)
Prior to performing the following procedure, remove
the top cover.
Disconnect the card wire from connector CN400 on
the audio board and CN402 on the power supply
board in the front panel assembly.
Cut off the tie band fixing the harness.
Remove the three screws Cattaching the front panel
assembly.
Remove the four screws Dattaching the front panel
assembly on the bottom of the body. Detach the front
panel assembly toward the front.
1.
2.
3.
4.
Removing the front panel assembly
(See Fig.2 to 3)
Removing the voltage selector
(See Fig.4)
Prior to performing the following procedure, remove
the top cover.
Remove the power cord stopper from the rear panel
by moving it in the direction of the arrow.
Remove the two screws F' attaching the rear panel
on the back of the body.
1.
2.
Fig.1
Fig.2
Fig.3
Fig.4
A 2
A 2
B
Top cover
C
Power
supply
board
Audio board
CN400
Main
board
Tie band
D
E
FE
F
F
Cord stopper
C
Front panel assembly
Front panel assembly
D
Rear panel
CN402
E
EE
F'

RX-8012VSL/RX-8010VBK
1-4
Prior to performing the following procedure, remove
the top cover and the rear panel.
Cut off the tie band fixing the harness.
Disconnect the connect CN501, CN243, CN205,
CN381, CN361 on the DVD board.
Disconnect the harness from connector CN721,
CN722 and CN723.
Disconnect the tuner board and audio input board
from connector CN101 and CN301 on the audio
board.
Disconnect the video audio board and video board
from connector CN303 and CN201 on the audio
board.
Disconnect the S video board from connector CN241
on the audio board.
Disconnect the DSP board from connector CN601 on
the audio board.
Pull out the plastic pin which prevents from coming
out.
1.
2.
3.
4.
5.
6.
7.
8.
Removing each board connected to the
rear side of the audio board
(See Fig.5 to 11)
Fig.5
Fig.6
Fig.8
Tie band
CN101
CN723
CN361
CN381 CN243
Tuner
board
CN501
CN721 CN722
CN205
Fig.9
CN303 CN201 CN241
Audio board
CN731
CN732
Fig.7
DVD board
Audio input
board
Video
board S Video
board
Video audio
board DSP
board
CN301
CN101
Video
board S Video
board
CN244
Video audio
board
CN206
CN416
Plastic pin

RX-8012VSL/RX-8010VBK
1-5
Prior to performing the following procedure, remove
the top cover and the tuner board, audio input board,
video audio board, video board, S-video board, DVD
board and the rear panel.
Removing the audio board
(See Fig.12 to 13)
Disconnect the harness from connector CN813 and
CN814 on the main board.
Disconnect the card wire from connector CN931 and
CN932 on the audio board.
Cut off the tie band fixing the harness.
Disconnect the relay board from the audio board and
the power supply board. (CN71,CN81)
Disconnect the card wire from connector CN831 on
the main board.
Remove the three screws Gattaching the audio
board.
Remove the screw Hattaching the audio board .
1.
2.
3.
4.
5.
6.
7.
Fig.10
Fig.11
Power
supply
board
Power / Fuse
board
Relay board
Audio board
CN71
CN81
H
CN814 CN813
CN931/ 932
Power
transformer
G
G
Tie band
CN831
Main
board
Fig.12
DSP board
CN601
Video
board
S Video
board
Video audio
board
Fig.13
Voltage
select
board

RX-8012VSL/RX-8010VBK
1-6
Remove the ten screws K and four screws L
attaching the heat sink.
Remove the two screws L' attaching the heat sink
from the rear side of main board.
1.
2.
Removing the heat sink
(See Fig.15 to 16)
Prior to performing the following procedure, remove
the top cover, the rear panel and audio board.
Cut off the tie band fixing the harness.
Disconnect the harness from connector CN811 on
the power supply board respectively.
Disconnect the harness from connector CN881 on
the main board.
Remove the four screws Iand the four screws J
attaching the main board.
1.
2.
3.
4.
Removing the main board (See Fig.14)
Prior to performing the following procedures, remove
the top cover and the rear panel.
Cut off the tie band fixing the harness.
Unsolder the six harnesses connected to the power
transformer.
1.
2.
Removing the voltage select board
(See Fig.17)
Fig.14
Main board
rear side
Heat sink
LL
KKK
L'
Fig.15
Fig.16
Main
board
I
CN881
I
JJ
I
I
Tie band
CN811
Power transformer
Solder points
Solder
points
Tie band
Power cord
Voltage select board
Voltage selector
Fig.17
L'
Power
supply
board

RX-8012VSL/RX-8010VBK
1-7
Prior to performing the following procedure, remove
the top cover and the front panel.
Remove the screw O fixing a bonding ground.
Remove the one nut attaching the headphone jack of
the power supply board on the front side of the body.
Remove the front panel assembly. and the screw a
ground.
Disconnect the card wire from connector CN402 on
the power supply board.
Remove the three screws Pattaching the power
supply board and pull out the power supply board
from the front bracket backward.
Unsolder the three harnesses connected to the
power supply board.
1.
2.
3.
4.
5.
6.
Removing the power supply board
(See Fig.19 to 21)
Prior to performing the following procedure, remove
the top cover and the rear panel.
Remove the screw Nattaching the power / fuse
board.
Unsolder the power cord and other harnesses
connected to the power / fuse board.
1.
2.
Removing the power / fuse board
(See Fig.18)
Prior to performing the following procedures, remove
the top cover.
Unsolder the two harnesses connected to the power
transformer.
Disconnect the harness from connector CN55 and
CN56 on the power transformer board.
Remove the four screws Mattaching the power
transformer.
1.
2.
3.
Removing the power transformer
(See Fig.18)
Fig.19
Fig.20
Power supply
board
Nut Headphone
jack
Headphone jack
Tie band
P
P
P
Solder
Hook
Tie band
O
Power supply
board
CN402
Fig.18
Power
supply
board
CN55 / 56
Power
transformer
M
Solder points
M
Solder points
N
Power / fuse board
Power cord
Power
transformer
board

RX-8012VSL/RX-8010VBK
1-8
Prior to performing the following procedure, remove
the top cover and the front panel assembly.
Pull out the volume knob on the front side of the front
panel and remove the nut attaching the system
control board.
Remove the two screws Qattaching the power
switch board.
Remove the two screws Rattaching the switch
board.
Remove the cords from the three hooks a.
Remove the eight screws Sattaching the system
control board on the back of the front panel.
On the back of the front panel, release the four joints
by pushing the joint tabs inward.
Remove the operation switch panel toward the front.
Disconnect the harness from connector CN420 and
CN422 on the system control board.
Release the two hooks battaching the system
control board.
1.
2.
3.
4.
5.
6.
7.
8.
Removing the system control board /
power switch board (See Fig.21 to 23)
Matters that require attention during
replacement of IC400
In case where there is a resistance array:
Both onetime IC and mask IC can be used
In case where there is no resistance array:
Only mask IC can be used
Fig.21
Fig.22
Fig.23
Front panel assembly
Nut
MASTER VOLUME knob
System control board
Power switch
board
SS
CN422
Q
Joint Joint Joint Joint
Hook bHook b
Operation switch panel
R
CN420
Switch
board S
Hook a
Cords
Resistance array

RX-8012VSL/RX-8010VBK
1-9
Adjustment method
<Adjustment method>
1.Set the volume control to minimum during this adjustment.(No signal & No load)
2.Set the surround mode OFF.
2.Turn VR787 and VR788 fully counterclockwise to warm up before adjustment.
If the heat sink is already warm from previous use the correct adjustment can not be made.
3.For L-ch,connect a DC voltmeter between B2204 and B2205 (Lch)
And,connect it between B2213 and B2214(Rch).
4.30 minutes later after power on, adjust VR787 for L-ch, or VR788 for R-ch so that the DC voltmeter
value has 1mV~10mV.
1.Tuner range
FM 87.5MHz~108.0MHz
AM(MW) 531kHz~1710kHz
Tuner section
Power amplifier section
B2213, B2214
VR787 (Lch)
VR788 (Rch)
Heat sink
Adjustment of idling current
Measurement location B2204-B2205(Lch) , B2213-2214(Rch)
Adjustment part VR787(Lch) , VR788(Rch)
Attention
This adjustment does not obtain a correct adjustment value immediately after the amplifier is
used (state that an internal temperature has risen).
Please adjust immediately after using the amplifier after turning off the power supply of the
amplifier and falling an internal temperature.
* It is not abnormal though the idling current might not become 0mA even if it is finished to turn variable
resistance (VR787,VR788) in the direction of counterclockwise.
B2204, B2205

RX-8012VSL/RX-8010VBK
1-10
Pin 2
Micro-computer+5V
Pin 3
Digital+5V
Pin 4
Analog+5V
Pin 5
+12V
Pin 7
Tuner+9V
At abnormal state
(Low voltage)
Analog value
0 - 2.2V
Analog value
0 - 2.2V
Analog value
0 - 2.2V
Analog value
0 - 2.2V
Analog value
0 - 2.2V
At normal state
Analog value
2.2 - 2.8V
Analog value
2.2 - 2.8V
Analog value
2.2 - 2.8V
Analog value
2.2 - 2.8V
Analog value
2.2 - 2.8V
At abnormal state
(High voltage)
Analog value
2.8 - 5.0V
Analog value
2.8 - 5.0V
Analog value
2.8 - 5.0V
Analog value
2.8 - 5.0V
Analog value
2.8 - 5.0V
Self-diagnose function
1. Detection of abnormal power supply and voltage
When the power is turned ON, if an abnormality is detected during the signal input at the A/D port (IC901,
pin 2-5, 7) for one second continuously, the status will become STANDBY mode immediately.
When the power is turned ON again, detection of abnormal power supply and voltage will not be carried out
during the first 4 seconds.
Given below is a list of threshold values at the detection of abnormalities.
2. Initial setting on ship
To gain the initial setting on ship, put the power plug in the socket while pressing DOWN key and UP key
together simultaneously, then turn the power ON.
3. Test mode
To enter the test mode, put the power plug in the socket while pressing EFFECT key and UP key together
simultaneously, then turn the power ON.
Workings of test mode:
All FLs are turned ON for 3 seconds. (the FLs, which are divided in two groups, are turned ON alternatively)
A Faster volume UP/DOWN operation can be achieved with the remote controller.
When the power is turned OFF, the test mode will be released.
The FL display returns to normal after the three seconds. Then the STANDBY LED is turned ON (flashing
ON and OFF for each one second) to show the present status being a test mode.

RX-8012VSL/RX-8010VBK
1-11
Information on VERSION of system microcomputer (IC901)
Example : VER1.1 2000/12/9
Display of communication information on DSP microcomputer (IC581)
Display of communication information on DIR AK4112A (IC551)
Display of communication information on DSP XCA56367 (IC501)
Display of communication information on CODEC AK4527 (IC571)
Information on VERSION of DSP microcomputer (IC581)
Example :VER1.1 2000/12/9
S 0 0 1 1
2 0 0 0 1 2 0 9 0 0
D 0 0
D 0 1
D 0 2
D 0 3
D 0 4 1 1
2 0 0 0 1 2 0 9 0 0
Upper 1 2 3 4 5 digits
Lower 1 2 3 4 5 6 7 8 9 10 digits
4. Self-diagnose
To enter the self-diagnose mode, put the power plug in the socket while pressing SETTING key and UP key
together simultaneously, then turn the power ON. With the UP/DOWN key operation, DSP microcomputer,
ROM No.of system microcomputer as well as working status of DSP can be displayed for five seconds.
While the working status is being displayed, the followings items can be switched with the UP/DOWN key
operation.
VERSION of system microcomputer Local microcomputer CH0
Local microcomputer CH01 Local microcomputer CH2
Local microcomputer CH3 Local microcomputer CH4
When the power is turned OFF, the self-diagnose mode will be released.
During the self-diagnose mode, the STANDBY LED is turned ON .
(flashing ON for one second then OFF for three seconds)
FL transient display will be carried out as follows. When the transient display is not carried out,
normal display/workings are carried out.
FL Display

RX-8012VSL/RX-8010VBK
1-12
AK4112A (IC551) : 96kHz 24bit DIR
2. Block diagram
3. Pin Function
1. Pin Layout
1DVDD
2DVSS
3TVDD
4V/TX
5XTI
6XTO
7PDN
8R
9AVDD
10AVSS
11RX1
12RX2/DEF0
13RX3/DEF1
14
28
27
26
25
24
23
22
21
20
19
18
17
16
15RX4/DEF2
CM0/CDTO
CM1/CDTI
OCKS1/CCLK
OCKS0/CSN
MCKO1
MCKO2
DAUX
BICK
SDTO
LRCK
ERF
FS96
P/SN
AUTO
Top
View
Input
Selector
Clock
Recovery
DAIF
Decoder
System
Control AC-3/MPEG
Detect
Error
Detect
Clock
Generator X'tal Oscillator
96kHz
Detect
Audio
I/F
uP I/F
DEM
RX1
RX2
RX3
RX4
DVDD
DVSS
PDN
V/TX
AVSS
AUTO ERF P/S="L"
AVDD R MCKO1 MCKO2 XTI XTO
FS96
DAUX
TVDD
LRCK
BICK
SDTO
CSN
CCLK
CDTO
CDTI
No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
Pin Name
DVDD
DVSS
TVDD
V
TX
XTI
XTO
PDN
R
AVDD
AVSS
RX1
DIF0
RX2
DIF1
RX3
DIF2
RX4
AUTO
Function
Digital Power Supply Pin, 3.3V
Digital Ground Pin
Input Buffer Power Supply Pin, 3.3V or 5V
Validity Flag Output Pin in parallel mode
Transmit channel (through data)
Output Pin in serial mode
X'tal Input Pin
X'tal Output Pin
Power-down mode Pin
When "L", the AK4112A is powerd-down and reset.
External resister pin
18Kohm +/-1% resistor to AVSS externally.
Analog Power Supply Pin
Analog Ground pin
Receiver Channel 1
This channel is selected in parallel mode
or default of serial mode.
Audio Data Interface format 0 Pin in parallel mode
Receiver Channel 2 in serial mode
Audio Data Interface format 1 Pin in parallel mode
Receiver Channel 3 in serial mode
Audio Data Interface format 2 Pin in parallel mode
Receiver Channel 4 in serial mode
Non-PCM Detect Pin
"L": No detect, "H": Detect
I/O
-
-
-
O
O
I
O
I
-
-
-
I
I
I
I
I
I
I
O
No.
16
17
18
19
20
21
22
23
24
25
26
27
28
Pin Name
P/S
FS96
ERF
LRCK
SDTO
BICK
DAUX
MCKO2
MCKO1
OCKS0
CSN
OCKS1
CCLK
CM1
CDTI
CM0
CDTO
Function
Palrallel/Serial Select Pin
"L": Serial mode, "H": Parallel mode
96kHz sampling detect pin
(RX mode) "H" : fs=88.2kHz or more,
"L" fs=54kHz or Iess.
(X'tal mode) "L" : XFS96=1, "L" : XFS96=0.
Unlock & Parity Error Output Pin
"L": No error, "H": Error
Output Channel Clock Pin
Audio Serial Data Output Pin
Audio Serial Data Clock Pin
Auxiliary audio data input pin
Master Clock #2 Output Pin
Master Clock #1 Output Pin
Output Clock Select 0 Pin in parallel mode
Chip Select Pin in serial mode
Output Clock Select 1 Pin in parallel mode
Control Data Clock Pin in serial mode
Master Clock Operation Mode Pin in parallel mode
Control Date Input Pin in serial mode
Master Clock Source select Pin in parallel mode
Control Date Output Pin in serial mode
I/O
I
O
O
I/O
O
I/O
I
O
O
I
I
I
I
I
I
I
O
Note: All input pins except internal pull-down pins should not be left floating.
Description of major ICs

RX-8012VSL/RX-8010VBK
1-13
1
2
3
4
5
6
7
8
9
10
11
33
32
31
30
29
28
27
26
25
24
23
12 13 14 15 16 17 18 19 20 21 22
44 43 42 41 40 39 38 37 36 35 34
SDOS
OCKS
MIS
BCLK
LRCK
SDTI1
SDTI2
SDTI3
SDTO
DAUX
DFS
DZF2
RIN+
RIN-
LIN+
LIN-
ROUT1
LOUT1
ROUT2
LOUT2
ROUT3
LOUT3
DEM1 DEM0 MCKO DVDD DVSS PD XTS ICKS1 ICKS0 CAD1 CAD0
LOOP1 LOOP0/SDA/CDTI DIF1/SCL/CCLK DIF0/CSN P/S MCLK DZF1 AVSS AVDD VREFH VCOM
1.Pin layout
LIN+
LIN-
RIN+
RIN-
LOUT1
ROUT1
LOUT2
ROUT2
LOUT3
ROUT3
LPF
LPF
LPF
LPF
LPF
LPF
DAC
DAC
DAC
DAC
DAC
DAC
DATT
DATT
DATT
DATT
DATT
DATT
ADC
ADC
HPF
HPF
Audio
I/F
MCLK
BICK
LRCK
SDOUT
SDIN1
SDIN2
SDIN3
SDTO
SDTI1
SDTI2
SDTI3
SDOS
DAUX
Format
Converter
Block Diagram (DIR and AC-3) DSP are external parts)
2.Block diagram
AK4527B (IC571) : A/D,D/A converter

RX-8012VSL/RX-8010VBK
1-14
No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
Pin name
SDOS
OCKS
MIS
BICK
LRCK
SDTI1
SDTI2
SDTI3
SDTO
DAUX
DFS
DEM1
DEM0
MCKO
DVDD
DVSS
PD
XTS
ICKS1
ICKS0
CAD1
CAD0
LOUT3
ROUT3
LOUT2
ROUT2
LOUT1
ROUT1
LIN-
LIN+
RIN-
RIN+
SDTO Source select pin
"L" : Internal ADC output, "H" : DAUX input
ORed with serial control register if P/S="L".
MCKO Clock frequency select pin
"L" : MCLK, "H" : MCLK/2. ORed with serial control register if P/S= "L".
Connect to GND
Audio serial data clock pin
Input/Output channel clock pin
DAC1 Audio serial data input pin
DAC2 Audio serial data input pin
DAC3 Audio serial data input pin
Audio serial data output pin
AUX Audio serial data input pin
Double speed sampling mode pin
"L" : Normal speed, "H" : Double speed, the ADC is powered down.
ORed with serial control register if P/S="L".
De-emphasis pin
ORed with serial control register if P/S="L"
De-emphasis Pin
ORed with serial control register if P/S="L"
Master clock output pin
Digital power supply pin
Digital ground pin
Power-down & Reset pin
When "L", the AK4527 is powered-down and the control registers are reset
to default state. If the state of CAD0-1 changes, then the AK4527
must be reset by PDN.
X'tal oscillator Select/Test mode pin
"H" : X'tal Oscillator selected
"L" : External clock source selected
Input clock select 1 pin
Input clock select 0 pin
Chip address pin
Used during the serial control mode.
Chip address pin
Used during the serial control mode.
Lch #3 analog output pin
Rch #3 analog output pin
Lch #2 analog output pin
Rch #2 analog output pin
Lch #2 analog output pin
Rch #1 analog output pin
Lch analog negative Input Pin
Lch analog positive Input Pin
Rch analog negative Input Pin
Rch analog positive Input Pin
Function
AK4527(1/2)
I/O
I
I
I
I
I/O
I
I
I
O
I
I
I
I
O
-
-
I
I
I
I
I
I
O
O
O
O
O
O
I
I
I
I
3. Pin function (1/2)

RX-8012VSL/RX-8010VBK
1-15
No.
33
34
35
36
37
38
39
40
41
42
43
44
Zero Input detection pin, 2PIN
Common voltage output pin,AVDD/2
Large external capacitor around 2.2uF is used to reduce power-supply noise
Positive voltage reference input pin,AVDD
Analog power supply pin
Analog ground pin
X'tal input pin
X'tal output pin if XTS="H"
External master clock input pin if XTS="L"
Parallel/Serial select pin
"L" : Serial control mode, "H" : Parallel control mode
Audio data interface format pin in parallel mode
Chip select pin in serial mode
Audio data interface format pin in parallel mode
Control data clock pin in serial mode
Loop back mode pin in parallel mode
Enables digital loop-back from ADC to 3 DACs.
Control data input pin in serial mode
Loop back mode pin in parallel mode
Enable all 3 DAC channels to be input from SDTII.
Control data output pin in serial mode
Pin Name
DZF2
VCOM
VREFH
AVDD
AVSS
XTI
XTO
MCKI
P/S
DIF0
CS
DIF1
CCLK
LOOP0
CDTI
LOOP1
CDTO
Function
I/O
O
O
I
-
-
I
O
I
I
I
I
I
I
I
I
I
O
AK4527(2/2)
3.Pin function (2/2)

RX-8012VSL/RX-8010VBK
1-16
1OUT1
2-IN1
3+IN1
4
8
7
6
5VEE
VCC
OUT2
-IN2
+IN2
2
1
-
+-
+
BA15218F (IC303, IC304, IC372, IC385, IC386, IC521, IC522, IC523, IC524, IC525, IC526,
IC527, IC528, IC529) : Op amp.
IN1
CTL A
VOUT 1
VCC
IN2
CTL B
logic
logic
MONITOR OUT
GND
IN5
GND
IN4
CTL E
IN3
CTL D
16
15
14
13
12
11
VOUT 2
CTL C
1
2
3
4
5
6
7
8
A B E MONITOR OUT
LL*IN1
HL*IN2
LH*IN3
H H L IN4
H H H IN5
C D E VOUT1
LL*--
HL*IN2
LH*IN3
H H L IN4
H H H IN5
C D E VOUT2
LL*IN1
HL*--
LH*IN3
H H L IN4
H H H IN5
10
11
BA7625 (IC201, IC242) : Video selector
IN1
CTL A
VOUT 1
VCC
IN2
CTL B
logic
logic
MONITOR OUT
GND
IN5
GND
IN4
CTL E
IN3
CTL D
16
15
14
13
12
11
VOUT 2
CTL C
1
2
3
4
5
6
7
8
A B E MONITOR OUT
LL*IN1
HL*IN2
LH*IN3
H H L IN4
H H H IN5
C D E VOUT1
LL*--
HL*IN2
LH*IN3
H H L IN4
H H H IN5
C D E VOUT2
LL*IN1
HL*--
LH*IN3
H H L IN4
H H H IN5
10
11
BA7626 (IC241) : Video selector

RX-8012VSL/RX-8010VBK
1-17
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
Vss
DATA
CLOCK
LCK
Q0
Q1
Q2
Q3
Q4
Vdd
OE
Q11
Q10
Q9
Q8
Q7
Q6
Q5
CONTROL
CIRCUIT
OUTPUT BUFFER(OPEN DRAIN)
12BIT STRAGE RESISTER
12BIT SHIFT RESISTER
1.Terminal Layout
1
2
3
4
5~16
17
18
Vss
DATA
CLOCK
LCK
Q0~Q11
OE
Vdd
-
I
I
I
O
I
-
Connect to GND
Serial Data input
Shift Clock of Data
Latch Clock of Data
Parallel Data Output
Output Enable
Power Supply
Pin No. Symbol I/O Function
Latch Data L H
OUTPUT ON OFF
2.Pin Function
BU2092(IC402) : Port expander

RX-8012VSL/RX-8010VBK
1-18
MB90088 (IC203) : On screen display controller
28
27
26
25
24
23
22
21
20
19
18
17
16
15
1
2
3
4
5
6
7
8
9
10
11
12
13
14
AVss
YOUT
VOUT
COUT
CS
SIN
SCLK
TEST
BOUT
ROUT
GOUT
VOB
XD
EXD
YIN
VIN
CIN
AVcc
IOUT
VOC
Vcc
EXS
XS
HSYNC
VSYNC
EXHSYN
EXVSYN
Vss
Dot CLK
OSC
CGROM
Output
Control
Video Signal
OSC
Analog SW
4FSC CLK
OSC
VRAM
Display Memory
Control
NTSC/PAL
Signal OSC
H/V Separate
Serial Input
Control
SCLK
SIN
COUT
YOUT
VOUT
VOB
VOC
IOUT
GOUT
ROUT
BOUT
EXD
XD
EXS
XS
CIN
YIN
VIN
CS
VSYNC
HSYNC
EXVSYN
EXHSYN
Each Block
Each Control, Data
Each Block
1.Terminal Layout
2.Block Diagram

RX-8012VSL/RX-8010VBK
1-19
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
pin
no Symbol I/O Function
YIN
VIN
CIN
AVcc
IOUT
VOC
Vcc
EXS
XS
HSYNC
VSYNC
EXHSYN
EXVSYN
Vss
EXD
XD
VOB
GOUT
ROUT
BOUT
TEST
SCLK
SIN
CS
COUT
VOUT
YOUT
AVss
I
I
I
I
I
I
I
I
I
I
I
-
-
-
-
O
O
O
O
O
O
O
O
O
O
O
Lux signal Input terminal for Superinpause indication
Composite video signal input terminal for Superinpause indication
Contrast signal input terminal for Superinpause indication
Analog power supply terminal
Color (Lux) signal output terminal
Character output terminal
Power supply terminal
Clock generater outside circuit terminal for color burst
Horizontal signal output terminal
Vertical signal output terminal
EXT horizontal signal input terminal
EXT vertical signal input terminal
GND
Dot clock generater outside circuit signal terminal for indication
Character & background signal output terminal
Color signal (Green, Red, Blue)
Test signal input terminal
Shift clock input terminal for serial transmission
Serial data input terminal
Chip select terminal
Contrast signal output terminal
Composite video signal output terminal
Lux signal output terminal
Analog GND terminal
3.Functions

RX-8012VSL/RX-8010VBK
1-20
1
2
3
5
4
NJU7241F33(IC411) : Voltage regulator
PIN FUNCTION
1. GND
2. VIN
3. VOUT
4. +NC
5. STB
V+
INPUT +
V-
OUTPUT
A OUT
A -IN
A +IN
V-
1
2
3
4
AB
(TOP VIEW)
8
7
6
5
V+
B -IN
B +IN
B OUT
1.Terminal layout
2.Block diagram
NJM4580D (IC301) : LPF, Mic and h.phone amp.
