JVC LT-24CA120 User manual

Instruction Manual
24" HD Android TV™
LT-24CA120
GB
Hey Google

Contents
1 Safety Warnings ...........................................................................................................................................................................6
2 Preparation...................................................................................................................................................................................9
Unpacking the TV ...............................................................................................................................................................................................................9
Installing / Removing the Stand..................................................................................................................................................................................10
− Fitting the Stand ...................................................................................................................................................................................................10
Mounting the TV to a Wall.............................................................................................................................................................................................11
Front View and Controls.................................................................................................................................................................................................11
Rear View and Sockets....................................................................................................................................................................................................12
Installing Batteries in the Remote Control ..............................................................................................................................................................13
Remote Control Operation Range..............................................................................................................................................................................13
Remote Control .................................................................................................................................................................................................................14
3 Initial Setup ................................................................................................................................................................................16
Turning the TV On for the First Time .........................................................................................................................................................................16
− Choosing your language, Country and Pairing your Remote Control..............................................................................................17
− Setting up your TV using your Android Phone .........................................................................................................................................18
− Setting up your TV using your Remote Control....................................................................................................................................... 20
− Sign in to your Google Account......................................................................................................................................................................21
− Conrm 'Terms of Service' and Google Setting ........................................................................................................................................21
− TV Setup.................................................................................................................................................................................................................. 23
− Tuning in your TV................................................................................................................................................................................................. 23
Home Screen Overview................................................................................................................................................................................................. 25
Discover Tab....................................................................................................................................................................................................................... 26
Google Assistant.............................................................................................................................................................................................................. 27
− Things to try........................................................................................................................................................................................................... 27
4 Live TV.........................................................................................................................................................................................28
Selecting Live TV.............................................................................................................................................................................................................. 28
− Selecting Live TV using the Input button................................................................................................................................................... 28
− Selecting Live TV using the FPlay button................................................................................................................................................... 28
− Selecting Live TV from the Home Screen................................................................................................................................................... 28
− Channel Selection .............................................................................................................................................................................................. 29
− There are 3 ways to change the channel. ................................................................................................................................................... 29
− Volume Adjustment............................................................................................................................................................................................ 29
− Muting the Volume............................................................................................................................................................................................. 29
Live TV Guide..................................................................................................................................................................................................................... 30
− Accessing the Guide Using the Remote...................................................................................................................................................... 30
− Accessing the Guide From the Home Screen............................................................................................................................................ 30
− Selecting a Programme from the Guide......................................................................................................................................................31
− Selecting a Day in the Programme Guide ...................................................................................................................................................31
− Recommended Programmes...........................................................................................................................................................................31
− Catch up Services..................................................................................................................................................................................................31
− Searching for a Programme in the Guide....................................................................................................................................................31
− Freeview Play ON NOW Guide ........................................................................................................................................................................ 32
Red Button + (Interactive services)........................................................................................................................................................................... 34
− Accessing the Information ............................................................................................................................................................................... 34
Listening to the Radio.................................................................................................................................................................................................... 34
− Viewing Channels with Subtitles ................................................................................................................................................................... 35
Safety
Warnings
PreparationInitial SetupLive TV
Customising
TV Setting
Setting
Menu
Browsing
USB Storage
Google
Assistant
Connecting
Devices
Technical
Information
and Help

Safety
Warnings Preparation Initial Setup Live TV Customising
TV Setting
Setting
Menu
Browsing
USB Storage
Google
Assistant
Connecting
Devices
Technical
Information
and Help
5 Customising TV Settings ...........................................................................................................................................................36
Adjusting the Picture Settings.................................................................................................................................................................................... 36
− Selecting Picture Settings................................................................................................................................................................................ 36
− Picture Settings Table ........................................................................................................................................................................................ 37
Adjusting the Sound Settings..................................................................................................................................................................................... 38
− Selecting Sound Settings................................................................................................................................................................................. 38
Making a Play Next Row................................................................................................................................................................................................ 39
6 Menus..........................................................................................................................................................................................40
Live TV Menus - Channels, TV Options and Record ............................................................................................................................................ 40
Inputs Menu....................................................................................................................................................................................................................... 43
− Selecting the Inputs Menu Using the Input Button on the Remote ................................................................................................ 43
− Changing an Inputs Name ...............................................................................................................................................................................44
− Hiding Inputs......................................................................................................................................................................................................... 44
Settings Menu .................................................................................................................................................................................................................. 45
Network & Internet Menu ............................................................................................................................................................................................ 46
− Connecting to the Internet using Wi-Fi....................................................................................................................................................... 47
Channel Menu .................................................................................................................................................................................................................. 48
Accounts & Sign-In Menu ............................................................................................................................................................................................ 50
Apps Menu .........................................................................................................................................................................................................................51
− Recently opened apps........................................................................................................................................................................................51
− App permissions .................................................................................................................................................................................................. 52
− Special app permissions.................................................................................................................................................................................... 53
Device Preferences Menu ............................................................................................................................................................................................ 54
− About - Settings about your TV...................................................................................................................................................................... 54
− Date & Time - Settings the Correct Date and Time................................................................................................................................. 55
− Timer - Set your TV to Automatically Switch ON and OFF at Set Times.......................................................................................... 56
− Language - Set the Language Menus are Displayed in......................................................................................................................... 57
− Keyboard - Select Which Type of Keyboard you Want to Use............................................................................................................. 57
− Inputs - Rename and Adjust Inputs Setting............................................................................................................................................... 58
− Power - Adjust Switch O Times For Various Modes.............................................................................................................................. 59
− Picture - Adjust Picture Modes and Settings............................................................................................................................................. 60
− Sound - Adjust Sound Styles and Settings................................................................................................................................................. 62
− Storage - See Available Storage Space on the TV or External Device.............................................................................................. 63
− Home Screen - Personalising the Home Screen ......................................................................................................................................64
− Store Mode - Switch Store Mode On ............................................................................................................................................................ 65
− Google Assistant - Personalise Google Assistant Settings................................................................................................................... 66
− Screen Saver - Settings...................................................................................................................................................................................... 67
− Location - Settings .............................................................................................................................................................................................. 68
− Usage & Diagnostics - ON/OFF ....................................................................................................................................................................... 69
− Manufacturer Usage & Diagnostics - ON/OFF........................................................................................................................................... 70
− Accessibility - Switch on/o Accessibility Features................................................................................................................................. 71
− Reset - Factory Reset Your TV.......................................................................................................................................................................... 72
Bluetooth Remotes & Accessories Menu ............................................................................................................................................................... 73
− Add accessories.................................................................................................................................................................................................... 73
− Checking Remote Control Status................................................................................................................................................................... 73
7 Browsing USB Storage...............................................................................................................................................................74
− Viewing Media on a USB Storage Device.....................................................................................................................................................74
− Checking and Formatting a USB Drive ........................................................................................................................................................ 75
− Ejecting a USB Drive ........................................................................................................................................................................................... 75
− Erase and Format a USB Drive......................................................................................................................................................................... 75
8 Google Home Speaker...............................................................................................................................................................76
Using Your Google Home Speaker to Control Your TV.......................................................................................................................................76
− Allowing your TV to power on via your Google Home Speaker.........................................................................................................76
− Linking your TV to your Google Home Speaker........................................................................................................................................76

5
9 Connecting Devices ...................................................................................................................................................................78
Connecting a Soundbar via HDMI (ARC)................................................................................................................................................................. 78
Connecting a USB Storage Device............................................................................................................................................................................. 79
CI (Common Interface)................................................................................................................................................................................................... 80
Connecting to the Internet (Wired) .......................................................................................................................................................................... 81
10 Technical Information and Help ...............................................................................................................................................82
Maintenance...................................................................................................................................................................................................................... 82
Hints and Tips.................................................................................................................................................................................................................... 83
Remote Control Codes................................................................................................................................................................................................... 85
− Sky Codes ............................................................................................................................................................................................................... 85
− Virgin Media Codes (TiVo box) ....................................................................................................................................................................... 85
− BT Vision.................................................................................................................................................................................................................. 85
Declaration of Conformity............................................................................................................................................................................................ 85
Product Fiche and Specications ............................................................................................................................................................................. 86
License Information used with JVC Televisions.................................................................................................................................................... 87
Safety
Warnings
PreparationInitial SetupLive TV
Customising
TV Setting
Setting
Menu
Browsing
USB Storage
Google
Assistant
Connecting
Devices
Technical
Information
and Help

6
1 Safety Warnings
Chapter
1
• Read all the instructions carefully before using the unit
and keep them for future reference.
• Retain the manual. If you pass the unit onto a third
party make sure to include this manual.
• Check that the voltage marked on the rating label
matches your mains voltage.
• WARNING: Never let people (including children) with
reduced physical, sensory or mental capabilities or lack
of experience and / or knowledge use electrical devices
unsupervised.
• To avoid danger of suffocation, keep plastic bags out of
reach of babies, children and domestic animals.
• Carefully attach the stand to the TV. If the stand is
provided with screws, tighten the screws firmly to
prevent the TV from tilting. Do not over tighten the
screws and mount the stand rubbers properly.
Damage
• Please inspect the unit for damage after unpacking.
• Do not continue to operate the unit if you are in any
doubt about it working normally, or if it is damaged
in any way - switch off, withdraw the mains plug and
consult your dealer.
Location of Unit
• The unit must be placed on a flat stable surface and
should not be subjected to vibrations.
• Do not place the unit on sloped or unstable surfaces
as the unit may fall off or tip over causing serious
personal injury or death.
• The mains socket must be located near the unit and
should be easily accessible.
• This unit is designed for indoor, domestic use only.
• Use this TV set at an altitude of less than 2000 meters
above sea level, in dry locations and in regions with
moderate or tropical climates.
Many injuries, particularly to children, can be avoided by
taking simple precautions such as;
• Using cabinets or stands recommended by the
manufacturer of the television set.
• Only use furniture that can safely support the
television set.
• Ensuring the television set is not overhanging the edge
of the supporting furniture.
• Not placing the television set on tall furniture (for
example, cupboards or bookcases) without anchoring
both furniture and the television set to a suitable
support.
• Not standing the television set on cloth or other
materials placed between the television and
supporting furniture.
• Educating children about the dangers of climbing
on furniture to reach the television set or its controls.
If your existing television set is being retained and
relocated, the same considerations as above should be
applied.
Wall Mounting
• Read the TV and wall mount instructions before
mounting your TV on the wall.
• For TVs over 40" in size, wall mounting requires 2
people to lift and position the TV on to the wall mount.
• The wall mount bracket is not supplied, they can be
purchased from your dealer.
• Do not install the TV on a ceiling or an inclined wall.
• Only use the screws supplied with the wall mount
bracket when attaching the TV to the bracket. See your
TV instructions for screw type.
• Tighten the wall mount screw firmly to prevent the TV
from falling. Do not over tighten the screws.
• If you are in any doubt how to mount your TV, contact
a professional.
Temperature
• Avoid extreme degrees of temperature, either hot or
cold. Place the unit well away from heat sources such
as radiators or gas / electric fires.
• Avoid exposure to direct sunlight and other sources of
heat.
Naked Flames
• Never place any type of candle or naked flame on the
top of or near the unit.
Moisture
• To reduce the risk of fire, electric shock or product
damage, do not expose this unit to rain, moisture,
dripping or splashing. No objects filled with liquids,
such as vases, should be placed on the unit.
• If you spill any liquid into the unit, it can cause serious
damage. Switch it off at the mains immediately.
Withdraw the mains plug and consult your dealer.
Ventilation
• To prevent the risk of electric shock or fire hazard
due to overheating, ensure that curtains and other
materials do not obstruct the ventilation vents.
• Do not install or place this unit in a bookcase, built-in
cabinet or in another confined space. Ensure the unit is
well ventilated.
• Make sure that there is a gap of at least 10 cm on both
sides and a gap of 20 cm at the top.
Safety
• Always disconnect the unit from the mains supply
before connecting / disconnecting other devices or
moving the unit.
• Unplug the unit from the mains socket during a
lightning storm and long inactivity periods (going on
holiday).
10 cm 10 cm
20 cm
10 cm
Safety
Warnings

7
1
Safety Warnings
Mains Cable
• Make sure the unit or unit stand is not resting on top of
the mains cable, as the weight of the unit may damage
the mains cable and create a safety hazard.
• A damaged power cord/plug can cause fire or give
you an electric shock. Handle the power cord by the
plug, do not unplug the TV by pulling the power cord.
Never touch the power cord/plug with wet hands
as this could cause a short circuit or electric shock.
Never make a knot in the power cord or tie it with
other cords. If the mains cable is damaged it must be
replaced by the manufacturer, its service agent, or
similarly qualified persons in order to avoid a hazard.
Interference
• Do not place the unit on or near appliances which may
cause electromagnetic interference. If you do, it may
adversely affect the operating performance of the unit,
and cause a distorted picture or sound.
Optimum viewing
• View the unit in moderate light to prevent eye strain. It
is recommended to watch the unit from a distance
3-7 times that of the screen height.
LCD screen
• The LCD screen is manufactured using high-precision
technology. However, some tiny black points and /
or bright points (red, blue or green in colour) may
constantly appear on the LCD screen. These points
are generated in the manufacturing process and are
normal.
Screen Burn
• A characteristic of Plasma and TV Panels is that
displaying the same image for a long time may cause
a permanent after-image to remain on the screen. This
is called screen burn. Most pictures shown on the unit
will be constantly moving and fill the screen.
• Examples of images that you need to watch out for are
as follows (this is not an all-inclusive list):
1. Black Bars: If black bars appear at the left / right or
top / bottom of the screen, it is recommended to
change the format so that the picture fills the entire
screen.
2. TV Channel Logos: e.g. Shopping channel logos
and pricing displays - especially if they are bright
and stationary. Moving or low-contrast graphics are
less likely to cause ageing of the screen.
3. Time Displays
4. Interactive Services: Do not view a stationary
page for long periods of time.
5. TV Menus
6. Pause Mode: Do not leave the screen in pause
mode for long periods of time, e.g. when watching
videos.
• To prevent screen burn if viewing any of the above for
long periods of time, reduce contrast and brightness
when viewing. Once burn-in occurs it will never
disappear completely.
Country Restrictions for Wireless Internet
• This device is intended for home and office use in
all EU countries (and other countries following the
relevant EU directive) without any limitation except for
the countries mentioned below.
Country Restriction
Bulgaria (BG) General authorization required for
outdoor use and public service
France (FR) In-door use only for 2454-2483.5 MHz
Italy (IT) If used outside of own premises, general
authorization is required
Greece (GR) In-door use only for 5470 MHz to 5725
MHz band
Luxembourg
(EL)
General authorization required for
network and service supply(not for
spectrum)
Norway (NO)
Radio transmission is prohibited for the
geographical area within a radius of 20
km from the centre of Ny-Ålesund
Russian
Federation (RU) In-door use only
• The requirements for any country may change at any
time. It’s recommended that user checks with local
authorities for the current status of their national
regulations for both 2.4 GHz and 5 GHz wireless LAN’s.
Earphones
• Listening to loud sounds for prolonged periods of time
may permanently damage your hearing.
• Before putting on earphones, turn the volume down
then put the earphones on and slowly increase the
volume until you reach a comfortable listening level.
Standby
• The button on the remote control does not switch
off the unit completely. The unit will continue to draw
electricity from the mains supply while in standby. In
the interests of safety and to avoid unnecessary energy
consumption, never leave the unit in standby while
unattended for long periods of time, e.g. overnight,
while on holiday or while out of the house. Disconnect
the mains plug from the mains socket.
Batteries
• Batteries used in the remote control for this unit
are easily swallowed by young children and this is
dangerous.
• Keep loose batteries away from young children and
make sure that the battery holder tray is secure in the
remote control. Seek medical advice if you believe a
cell has been swallowed.
• Please dispose of batteries correctly by following the
guidance in this manual.
• Do not dispose of batteries in fire or with hazardous or
flammable materials.
• The batteries shall not be exposed to excessive heat
such as sunshine, fire or the like.
Supervision
• Children should be supervised to ensure that they do
not play with the unit and the remote control.
• Never let anyone especially children push anything
into the holes, slots or any other openings in the case -
this could result in a fatal electric shock.
Safety
Warnings

8
1Safety Warnings
Earthing
• Apparatus connected to the protective earthing of the
building installation through the MAINS connection
or through other apparatus with a connection to
protective earthing - and to a television distribution
system using coaxial cable, may in some circumstances
create a fire hazard. Connection to a television
distribution system has therefore to be provided
through a device providing electrical isolation below a
certain frequency range (galvanic isolator,
see EN 60728-11)
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The lightning flash with arrowhead symbol,
within an equilateral triangle, is intended to
alert the user to the presence of uninsulated
“dangerous voltage”within the unit’s
enclosure that may be of sufficient
magnitude to constitute a risk of electric
shock.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and
maintenance (servicing) instructions in the
manual accompanying the unit.
Service
• To reduce the risk of electric shock, do not remove
screws. The unit does not contain any user-serviceable
parts. Please leave all maintenance work to qualified
personnel.
• Do not open any fixed covers as this may expose
dangerous voltages.
Maintenance
• Ensure to unplug the unit from the mains socket before
cleaning.
• Do not use any type of abrasive pad or abrasive
cleaning solutions as these may damage the unit’s
surface.
• Do not use liquids to clean the unit.
• The wall socket plug is used as a disconnect device, the
disconnect device should be readily accessible.
• This equipment is a Class II or double insulated
electrical appliance. It has been designed in such
a way that it does not require a safety connection
to electrical earth.
To prevent the spread of fire,
keep candles or other open
flames away from this product
at all times.
Safety
Warnings

9
2 Preparation
Thank you for purchasing your new JVC TV.
Your new TV has many features and incorporates the latest technology to enhance your viewing
experience. We recommend that you spend some time reading this instruction manual so that you fully
understand these features. You will also find some hints and tips to help you resolve any issues.
Read all the safety instructions carefully before use and keep this instruction manual for future reference.
Chapter
2
Unpacking the TV
Remove all packaging from the TV. Retain the packaging. If you dispose of it please do so according to local regulations.
The following items are included:
Remote Control /
AAA Batteries x 2
Preparation
• If items are missing, or damaged please contact Partmaster (UK only).
Tel: [phone] for assistance. Parts are available for 7 years after purchase.
Stand screws x2
TV
TV Stand (feet) x 2
Instruction Manual Quick Start Guide
Instruction Manual
24" HD Android TV™
LT-24CA120
GB
Hey Google
Quick Start Guide
24" HD Android TV™
LT-24CA120
Setup in
15mins
Hey Google
Certainservices are subject to change or withdrawal at any time, may not be available in all areas, or in 4K, HDR or DOLBY VISION or DOLBYATMOS and may require separate subscriptions.
JVC24' Android LED Smart HD TV LT-24CA120 Quick Start Guide.indd 1JVC24' Android LED Smart HD TV LT-24CA120 Quick Start Guide.indd 1 14/06/2022 10:4414/06/2022 10:44
OK
TEXT
MENU

2
10
Preparation
Installing / Removing the Stand
The LCD display is very fragile, and must be protected at all times when installing and removing the base stand. Be sure that
no hard or sharp object, or anything that could scratch or damage the LCD display, comes into contact with it. DO NOT exert
pressure on the front of the TV at any time because the screen could crack.
Preparation
Fitting the Stand
1. Ensure the TV is switched off and not connected to the mains power supply.
2. Lay the TV down on a flat surface ideally on the edge of a table so the base of the TV slightly overhangs the edge of the table,
with the back side facing up. Please make sure a soft cushioned material (such as a dry bath towel or thick piece of foam) is
placed beneath the screen.
3. Fit each leg to your TV using the screws supplied.
SPDIF VGA
ANT.
HDMI 2(ARC)
LAN
AVIN
Coax.OUT
SPDIF
Optic.OUT
VGA
ANT.
HDMI2(ARC)
LAN
AVIN
TableCushioned
material
Protective
bag

2
Preparation
11
Front View and Controls
Remove the stand assembly before mounting the TV onto the wall.
• If you are wall mounting your TV you may wish to buy a 90° HDMI adapter. This will help with your cable management.
• Please read this instruction manual carefully while setting up your TV.
• If you require additional assistance please call our Call Centre on (UK) 0344 561 1234 or (Ireland) 1 890 818 575.
Our Customer Contact Centre is open Monday-Saturday 8am-8pm or Sunday 8am-6pm.
Mounting the TV to a Wall
Preparation
1. Remove the screw from each leg and detach.
2. This TV is designed to be wall-mounted
with a standard 75 mm x 75 mm
mounting kit (sold separately) designed
for flat-panel TVs. Mount this TV
according to the instructions included
in the mounting kit. Due to space
restrictions, we recommend that you
make all connections before mounting
on to the wall.
SPDIF
Optic.OUT
VGA
ANT.
HDMI2(ARC)
HDMI3
LAN
AVIN
SPDIF
Optic.OUT
VGA
ANT.
HDMI2(ARC)
HDMI3
LAN
AVIN
75mm
Four mounting holes
(size M4 screw)
75mm
5-8mm
M4
Item Description
1POWER LED Illuminates when the TV is in standby mode. The LED will blink confirming that a timer
recording programme has started in the standby mode.
2 IR (Infrared Receiver) Receives IR signals from the remote control.
Do not put anything near the sensor, as its function may be affected.
3 STANDBY/ON BUTTON Switches the TV into standby and on.
1
3
2

2
12
Preparation
Rear View and Sockets
Preparation
COMMON INTERFACE
USB
5Vdc
Max. 500mA
USB
5Vdc
Max. 500mA
SPDIF
Coax.OUT
VGA
ANT.
HDMI 2(ARC)
HDMI 3
HDMI 1
LAN
AV IN
SPDIF
Coax.OUT
VGA
ANT.
HDMI 2(ARC)
HDMI 3
LAN
AV IN
3
4
2
1
5
6
Item Description
1 HDMI 1, 2 (ARC) & 3 Connects to a High-Definition (HD) signal output device, such as a set-top box, blu-ray
disc player or AV receiver.
2 LAN Connects to the internet for using the Smart hub.
3 SPDIF (Coax. OUT) Coaxial audio out (Digital) - Connects to an audio device via a coaxial cable.
4 VGA Connects to a computer or other devices with VGA interfaces.
5 ANT Connects to the aerial socket on the wall with the RF coaxial cable.
6 AV IN Connects to composite video and AUDIO (L/R) output sockets on external video devices.
Audio inputs (red and white) also used with VGA input.
7 COMMON INTERFACE Allows the insertion of a Common Access Module.
8 USB Allows the insertion of a USB storage device to play video, audio, photo and text files
(USB mode) and record DTV programmes on to a USB storage device.
9 Connects to the headphones.
10 STANDBY/ON SWITCH Switches the TV into standby and on.
7
8
8
1
9
COMMON INTERFACE
USB
5Vdc
Max. 500mA
USB
5Vdc
Max. 500mA
SPDIF
Coax.OUT
VGA
ANT.
HDMI 2(ARC)
HDMI 3
HDMI 1
LAN
AV IN
10

2
Preparation
13
Remote Control Operation Range
The first time you use your remote control, point the remote control
at the TV no more than 5 metres from the remote control sensor on
the TV and within 60° in front of the TV. The operating distance may
vary depending on the brightness of the room. Once the remote
control has connected to the TV via Bluetooth the operating range is
10 meters and you won't need to point it at the TV.
Handling the Batteries
• Improper or incorrect use of batteries may cause
corrosion or battery leakage, which could cause
fire, personal injury or damage to property.
• Only use the battery type indicated in this manual.
• When the batteries are exhausted, the remote will
not function. Replace both batteries at the same
time with new ones.
• Do not install new batteries with used ones and do
not mix different types of batteries.
• Do not dispose of used batteries as domestic
waste. Dispose of them in accordance with local
regulations.
Handling the Remote Control
• Take care of your fingernails when you press and
hold the battery release tab.
• Do not drop or cause impact to the remote control.
• Do not spill water or any liquid on the remote
control.
• Do not place the remote control on a wet object.
• Do not place the remote control under direct
sunlight or near sources of excessive heat.
• Remove the battery from the remote control
when not in use for a long period of time, as it
could cause corrosion or battery leakage and may
result in physical injury and/or property damage
including fire.
Installing Batteries in the Remote Control
1. Press the catch and lift the battery
cover.
2. Insert two AAA size batteries.
Make sure to match the (+) and
( - ) ends of the batteries with the
(+) and ( - ) ends indicated in the
battery compartment.
Preparation
3. Click the battery compartment
back into place.
10M
OK
TEXT
MENU

2
14
Preparation
Remote Control
Preparation
OK
TEXT
MENU
3
6
7
10
13
14
11
45
8
9
12
15
1 2
16
18
20
22
23
17
19
21
1. STANDBY Button
• Press to switch between on and standby.
• Press for 1 second to Power O the TV. This will enter low power
standby mode.
2. Microphone & LED
• Speak into the microphone when using Google Assistant.
• Blue LED lights to indicate your remote is working.
3. NUMBER Buttons
Press to select a Live TV channels.
4. LANGUAGE Button
Press to select an alternative language if available.
5. SUBTITLE Button
Press to access the AUDIO menu where you can switch Audio Description
and Subtitles on and o.
6. MUTE Button
Press to mute or un-mute the volume.
7. VOLUME +/- Buttons
Press to increase and decrease the volume level.
8. PROGRAMME +/- Buttons
• Press to scroll up and down the channel list.
9. GOOGLE ASSISTANT Button
Press the Google Assistant button, when the blue LED ashes on the
remote ask Google a question.
10. HOME Button
• Press to view the home screen.
11. GUIDE Button
Press to view the Live TV Programme Guide.
12. INFORMATION Button
Press when viewing Live TV to see programme information.
13. OK and NAVIGATION ( )Buttons
• Press OK to select items in menus.
• Press to navigate around menus.
14. BACK Button
Press to move back through menus.
15. EXIT Button
Press to exit menus or Apps.
16. NETFLIX Button
Connects to Netix for viewing online TV shows and lms (internet
connection required).
17. YOUTUBE button
Press to access YouTube (internet connection required).
18. FPLAY button
Press to access the Now/Next menu in Live TV.
19. GOOGLE PLAY button
Press to access Google Play (internet connection required).
20. MENU Button
• Press when viewing Live TV to access the Channel, TV Options and
Record menus.
• Press when viewing the Home Screen to accsess the Settings menu.

2
Preparation
15
Preparation
OK
TEXT
MENU
3
6
7
10
13
14
11
45
8
9
12
15
1 2
16
18
20
22
23
17
19
21
21. Input Button
Press to switch between inputs.
22. REWIND - STOP - FAST FORWARD - RECORD - PAUSE/PLAY - TEXT
Buttons
• Press to rewind videos.
• Press to Pause videos.
• Press the fast forward videos.
• Press to Record Live TV, a storage device must be connected.
• Press the play videos.
• Press to Stop videos.
• Press Text to access Red Button services on Live TV if available.
23. COLOURED Buttons
• Press the RED button to access Red button services if available.
• Access the TELETEXT items when viewing Live TV.
• Press the coloured buttons to select Freeview Play options.

16
3 Initial Setup
Turning the TV On for the First Time
Always disconnect the TV from the mains socket when not in use for a long period of time.
The button on the remote control is only used for switching the TV into standby, it does not disconnect the TV from the
mains power. To completely disconnect the mains power, please remove the mains plug from the mains socket.
Chapter
3
Do not connect the TV to the mains
supply until you have completed all
the connections.
Initial Setup
1. Connect one end of the RF coaxial cable to the aerial socket on the wall and the other end of the cable to the ANT socket on
the back of your TV.
2. Insert the power cable into the power socket on the back of the TV, plug the TV into a mains socket and switch on at the
mains.
3. In standby mode, press the button on the remote control to turn the TV on. The LED indicator will flash for a few seconds
then the TV will switch on.
SPDIF
Coax.OUT
VGA
ANT.
HDMI2(ARC)
HDMI3
LAN
AVIN
SPDIF VGA
ANT.
HDMI 2(ARC)
HDMI 3
LAN
AV IN
RF coaxial cable
(not included)
Coax.OUT
Router
(not included)

17
3
Initial Setup
Choosing your language, Country and Pairing your Remote Control
The first time you switch your TV on it will automatically be in the initial setup mode. This will guide you through the whole setup
process of, selecting your desired language, country, paring your remote control connecting to the internet, signing in to your
Google account and tuning in TV channels.
1. Select your Language,
ENGLISH should already be
highlighted then press the
OK button to continue.
2. Select your Country, UNITED
KINGDOM should already be
highlighted then press the
OK button to continue.
Initial Setup
3. Now you’ll see the Initial
Setup, CONTINUE should
already be highlighted press
the OK button to continue.
4. Now you will need to pair
your remote control to
your TV. Press and hold the
SOURCE button for between
5-15 seconds.
5. When you see your remote
on the right side on the
screen highlight it and press
OK. Your remote will now
pair with your TV.

18
3Initial Setup
6. Select your WiFi connection.
7. Confirm your fingerprint.
Initial Setup
Setting up your TV using your Android Phone
The quickest way to setup your TV is by using your Android phone. Your Google account details will be copied from your Android
phone to your TV. If you don’t have an Android phone you can also setup your TV using the remote control. To setup using
remote control refer to 'setting up using a your Remote control'.
1. If you have an Android
phone you can setup your
TV using it. If not then
highlight SKIP and press
OK.
2. On your Android phone open the Google App.
3. Select NEXT.
4. Your phone will now start connecting to your TV.
5. A code will appear on your phone, check its the
same as the code on your TV and select NEXT.

19
3
Initial Setup
10. Enter your account password and select SIGN IN.
11. Now continue setup on your TV.
8. Choose your Google account.
9. Your account will now be copied to your TV.
Now go to the Confirm 'Terms of Service' and Google Setting section on
page 21.
Initial Setup

20
3Initial Setup
Initial Setup
Setting up your TV using your Remote Control
When setting up your TV for the first time you'll be given 2 choices of how you would like to setup your TV. The first choice is to
setup using your Android phone so you'll have to SKIP this. The second choice is setup using the remote control. If you don't have
an Android phone then this is the option you need.
1. To setup using your Remote
Control first you will need
to skip the setup with your
Android phone option.
Highlight SKIP and press OK.
Make sure your TV is as
close to your router as
possible, within 5m and
ideally in the same room
as the TV
Best connection
speed
Maximum distance
5m
Wireless Router Wireless Router
WIRED Connection
• If you have connected your ethernet cable to the LAN socket on the back of your TV, your TV will automatically connect to the
internet.
WIRELESS Connection
• You can connect using a wireless connection via your router.
You'll now be asked to setup your WiFi so make sure your ethernet cable is connected if you're using on and if not make sure you
have your WIFI password.
2. Your TV will automatically scan for your wireless network, then show you a list
of networks that its found. Highlight your network and press the OK button.
3. Enter your Wi-Fi password, then highlight and press the OK button.
In a second or two your TV will show 'Connected to the Internet'.
4. To sign in to your Google account highlight SIGN IN the press the OK button.
