JVC LT-40CF890 User manual

Unpacking Guide
TV
TV Stand Base
Accessories
Pack
Instruction Book
& Quick Start Guide
✔✘
• Keep the protective bag on your TV until you have attached the
stand and positioned the TV.
• The LCD display is very fragile, and must be protected at all times
when installing and removing the base stand. Be sure that no hard
or sharp object, or anything that could scratch or damage the LCD
display, comes into contact with it. DO NOT exert pressure on the
front of the TV at any time because the screen could crack.
Remove the Protective Bag
If you don't have a table
big enough, you can use
the TV box. Lie the box flat,
make sure you place the
polystyrene back in the box
first to give the box some
rigidity and strength.
2 people are required
when unpacking your TV.
Don't lift the TV from the top
Attaching the Neck
1. Ensure the TV is switched off and not connected to the mains power supply.
2. Keep the protective bag on the TV to protect it. You may need to cut the protective bag before fitting the stand.
3. Make sure you have some help, this requires 2 people. Lay the TV down on a flat surface ideally on the edge of a
table so the base of the TV slightly overhangs the edge of the table, with the back side facing up. Please make sure
a soft cushioned material (such as a dry bath towel or thick piece of foam) is placed beneath the screen. Be very
careful not to knock the edges of the TV, the screen is very fragile.
4. Attach the neck using 4 x screws (A) 16mm.
Fitting the Base
5. Attach the base using 4 x screws (B) 16mm. Be careful when attaching the base its heavy.
Table
Cushioned
material
TV Stand Neck
Screws
JVC 40'_49'_55' Amazon Fire LED Smart 4K HDR TV LT-40CF890 LT-49CF890 LT-55CF890 Unpacking Guide.indd 1 21/10/2019 11:14

Remove the stand assembly before mounting the
TV onto the wall.
1. Remove the 4 screws (A) from the neck of the stand
and detach the stand.
Mounting the TV to a Wall
2. This TV is designed to be wall-mounted with a
standard mounting kit (sold separately) designed
for flat-panel TVs. Mount this TV according to the
instructions included in the mounting kit. Due to
space restrictions, we recommend that you make
all connections before mounting on to
the wall.
TV Weight
LT-40CF890 - 7.15kg
LT-49CF890 - 10.4kg
LT-55CF890 - 14.4kg
• If you are wall mounting your TV you may wish to buy a 90° HDMI adapter. This will help with
your cable management.
• If you require additional assistance please call our Call Centre on (UK) 0344 561 1234 or
(Ireland) 1 890 818 575. Our Customer Contact Centre is open Monday-Saturday 8am-8pm
or Sunday 8am-6pm.
If you don't have a table big enough, you can use
the TV box. Make sure you place the polystyrene
back in the box first to give the box some rigidity
and strength.
• 2 people are required when wall mounting large TVs.
• Make sure you hold the TV on the sides do not hold the screen, you may damage the screen.
(UG-LT-40CF890/LT-49CF890/LT-55CF890 -191021V2)
Always check the specification of your wall mount
bracket to make sure its suitable for the weight of
your TV.
HDMI4 HDMI2 (ARC) HDMI3
LAN
ANT.
VGA
Optic.OUT
SPDIF
R L VIDEO
BACKAV
200mm
Four mounting holes
(size M6 screw)
200mm
10-13mm
M6
HDMI4 HDMI2 (ARC) HDMI3
LAN
ANT.
VGA
Optic.OUT
SPDIF
R L VIDEO
BACKAV
100mm
Four mounting holes
(size M4 screw)
100mm
5-8mm
M4
HDMI4 HDMI2 (ARC) HDMI3
LAN
ANT.
VGA
Optic.OUT
SPDIF
R L VIDEO
BACKAV
(A)x4
HDMI4 HDMI2 (ARC) HDMI3
LAN
ANT.
VGA
Optic.OUT
SPDIF
R L VIDEO
BACKAV
200mm
Four mounting holes
(size M6 screw)
200mm
10-13mm
M6
HDMI4 HDMI2 (ARC) HDMI3
LAN
ANT.
VGA
Optic.OUT
SPDIF
R L VIDEO
BACKAV
100mm
Four mounting holes
(size M4 screw)
100mm
5-8mm
M4
HDMI4 HDMI2 (ARC) HDMI3
LAN
ANT.
VGA
Optic.OUT
SPDIF
R L VIDEO
BACKAV
(A)x4
LT-49CF890 & LT-55CF890 models 200 x 200 vesa mount
LT-40CF890 model 100 x 100 vesa mount
