JVC CA-HXZ9 User manual

GVT0099-012A
[UW]
INSTRUCTIONS
MANUAL DE INSTRUCCIONES
INSTRUÇÕES
CA-HXZ9
For Customer Use:
Enter below the Model No. and Serial No.
which are located either on the rear, bot-
tom or side of the cabinet. Retain this
information for future reference.
Model No.
Serial No.
COMPACT COMPONENT SYSTEM
SISTEMAS DE COMPONENTES COMPACTOS
SISTEMA DE COMPONENTE COMPACTO
Español English
Português
Cover.CA-HXZ9[UW]f.p65 03.2.17, 5:30 PM1

Caution— (standby/on) button!
Disconnect the mains plug to shut the power off
completely. The (standby/on) button in any position
does not disconnect the mains line. The power can be
remote controlled.
Precaución––Interruptor (encendido/apagado)!
Desconectar el cable de alimentación para desactivar la
alimentación totalmente. Cualquier que sea la posición de
ajuste del interruptor (encendido/apagado), la
alimentación no es cortada completamente. La
alimentación puede ser controlada remotamente.
Precaução––Interruptor (esperar/ligar)!
Desconectar o cabo de alimentação para desligar a
alimentação por completo. Qualquer que seja a posição
de ajuste do interruptor (esperar/ligar), a alimentação
não é completamente cortada. A alimentação pode ser
controlada remotamente.
G-1
Warnings, Cautions and Others
Avisos, precauciones y otras notas
Advertências, precauções e outras notas
Safety.CA-HXZ9[UW]f.p65 03.1.30, 11:01 AM1

CAUTION
To reduce the risk of electrical shocks, fire, etc.:
1. Do not remove screws, covers or cabinet.
2. Do not expose this appliance to rain or
moisture.
CAUTION
• Do not block the ventilation openings or holes.
(If the ventilation openings or holes are blocked by a
newspaper or cloth, etc., the heat may not be able to get out.)
• Do not place any naked flame sources, such as lighted
candles, on the apparatus.
• When discarding batteries, environmental problems must be
considered and local rules or laws governing the disposal of
these batteries must be followed strictly.
• Do not expose this apparatus to rain, moisture, dripping or
splashing and that no objects filled with liquids, such as
vases, shall be placed on the apparatus.
PRECAUCIÓN
• No obstruya las rendijas o los orificios de ventilación.
(Si las rendijas o los orificios de ventilación quedan tapados
con un periódico, un trozo de tela, etc., no se podrá disipar
el calor).
• No ponga sobre el aparato ninguna llama al descubierto,
como velas encendidas.
• Cuando tenga que descartar las pilas, tenga en cuenta los
problemas ambientales y observe estrictamente los
reglamentos o las leyes locales sobre disposición de las
pilas.
• No exponga este aparato a la lluvia, humedad, goteos o
salpicaduras. Tampoco ponga recipientes conteniendo
liquidos, como floreros, encima del aparato.
AVISO
• Não obstrua as aberturas e orifícios de ventilação.
(Se os orifícios ou aberturas de ventilação estiverem
obstruídos por qualquer papel ou tecido, não haverá
circulação do ar quente.)
• Não coloque nenhum objeto com chamas, como velas
acesas, sobre o aparelho.
• Ao descartar as baterias, leve em consideração os
problemas que possam ser causados ao meio ambiente e
os regulamentos e leis locais e governamentais sobre
recolhimento dessas baterias devem ser rigorosamente
seguidos.
• Não exponha este aparelho à chuva, umidade, pingos ou
esguichos de água, nem coloque em cima do mesmo
qualquer tipo de recipiente que contenha líquidos, como por
exemplo vasos.
PRECAUCIÓN
Para reducir riesgos de choques eléctricos,
incendio, etc.:
1. No extraiga los tornillos, los cubiertas ni la
caja.
2. No exponga este aparato a la lluvia o a la
humedad.
PRECAUÇÃO
Para reduzir riscos de choques elétricos,
incêndio, etc.:
1. Não remova parafusos e tampas ou
desmonte a caixa.
2. Não exponha este aparelho à chuva nem
à umidade.
G-2
Safety.CA-HXZ9[UW]f.p65 03.1.30, 11:01 AM2

Caution: Proper Ventilation
To avoid risk of electric shock and fire, and to prevent damage, locate the apparatus as follows:
1 Front: No obstructions and open spacing.
2 Sides/ Top/ Back: No obstructions should be placed in the areas shown by the dimensions below.
3 Bottom: Place on the level surface. Maintain an adequate air path for ventilation by placing on a
stand with a height of 10 cm or more.
Precaución: El aparato debe estar bien ventilado
Para evitar posibles riesgos de descargas eléctricas e incendios y prevenir cualquier posible daño, coloque
el aparato del modo siguiente:
1 Parte delantera: No ponga nada delante, deje el espacio libre.
2 Laterales/ parte superior/ parte trasera:
No se debería colocar nada en las áreas y las distancias que se detallan a continuación.
3 Parte inferior: Coloque el aparato sobre una superficie recta. Debe haber buena circulación de
aire; para ello, coloque el aparato sobre una base a una altura mínima de 10 cm.
Precaução: Ventilação adequada
Para evitar riscos de choques elétricos e incêndios, e prevenir avarias, instale o aparelho como segue:
1 Parte frontal: Sem obstruções e espaços abertos.
2 Partes laterais/ Tampa/ Posterior:
Nenhuma obstrução deverá ser colocada entre as áreas cujas dimensões são indicadas
abaixo.
3 Parte inferior: Instale-o sobre uma superfície plana. Deverá ser mantido espaço suficiente para a
ventilação se este for instalado numa posição que tenha uma altura de 10 cm ou mais.
G-3
Front view
Vista frontal
Vista frontal
Side view
Vista lateral
Vista lateral
Safety.CA-HXZ9[UW]f.p65 03.1.30, 11:01 AM3

IMPORTANT FOR LASER PRODUCTS
IMPORTANTE PARA PRODUCTOS LÁSER
IMPOTANTE PARA PRODUTOS LASER
REPRODUCTION OF LABELS / REPRODUCCIÓN DE ETIQUETAS / REPRODUÇÃO DE ETIQUETAS
11
11
1CLASSIFICATION LABEL ON EXTERIOR
SURFACE
11
11
1ETIQUETA DE CLASIFICACIÓN SOBRE LA
SUPERFICIE EXTERIOR
11
11
1ETIQUETA DE CLASSIFICAÇÃO LOCALIZADA NA
SUPERFÍCIE EXTERNA
2WARNING LABEL INSIDE THE UNIT
2ETIQUETA DE ADVERTENCIA DEL INTERIOR DE
LA UNIDAD
2ETIQUETA DE ADVERTÊNCIA LOCALIZADA NA
PARTE INTERNA DA UNIDADE
1. CLASS 1 LASER PRODUCT
2. DANGER:Invisiblelaserradiationwhenopenandinterlock
failed or defeated. Avoid direct exposure to beam.
3. CAUTION: Do not open the top cover. There are no user
serviceable parts inside the Unit; leave all servicing to
qualified service personnel.
1. PRODUCTO LÁSER CLASE 1
2. PELIGRO: En el interior hay radiación láser invisible. Evite
el contacto directo con el haz.
3. PRECAUCIÓN: No abra la tapa superior. En el interior de
la unidad no existen piezas reparables por el usuario; deje
todo servicio técnico en manos de personal calificado.
1. PRODUTO LASER CLASSE 1
2. PERIGO: O laser emite uma rediação invisível que é
perigosa,caso o aparelhoesteja aberto ea trava inoperante
ou danificada. Evite exposição direta ao feixe dos raios.
3. CUIDADO: Não abra a caixa do aparelho. Não existem
peças reparáveis pelo usuário na parte interna da unidade.
Solicite assistência técnica somente a pessoal técnico
qualificado.
G-4
Safety.CA-HXZ9[UW]f.p65 03.2.7, 0:02 PM4

1
English
Introduction
About This Manual
This manual is organized as follows:
•The manual mainly explains operations using the
buttons and controls on the unit. You can also use the
buttons on the remote control if they have the same or
similar names (or marks) as those on the unit.
If operation using the remote control is different from
that using the unit, it is then explained.
• Basic and common information that is the same for many
functions is grouped in one place, and is not repeated in
each procedure. For instance, we do not repeat the
information about turning on/off the unit, setting the
volume, changing the sound effects, and others, which are
explained in the section “Common Operations” on pages 9
to 12.
• The following marks are used in this manual:
Gives you warnings and cautions to prevent
from damage or risk of fire/electric shock.
Also gives you information which is not good
for obtaining the best possible performance
from the unit.
Gives you information and hints you had better
know.
Precautions
Installation
• Install in a place which is level, dry and neither too hot nor
too cold—between 5˚C and 35˚C.
• Install the unit in a location with adequate ventilation to
prevent internal heat buildup in the unit.
• Leave sufficient distance between the unit and the TV.
• Keep the speakers away from the TV to avoid interference
with TV.
DO NOT install the unit in a location near heat
sources, or in a place subject to direct sunlight,
excessive dust or vibration.
We would like to thank you for purchasing one of our JVC products.
Before operating this unit, read this manual carefully and thoroughly to
obtain the best possible performance from your unit, and retain this manual
for future reference.
Power sources
• When unplugging from the wall outlet, always pull the
plug, not the AC power cord.
DO NOT handle the AC power cord with wet hands.
Moisture condensation
Moisture may condense on the lens inside the unit in the
following cases:
• After heating starts in the room
• In a damp room
• If the unit is brought directly from a cold to a warm place
Should this occur, the unit may malfunction. In this case, leave
the unit turned on for a few hours until the moisture evaporates,
unplug the AC power cord, and then plug it in again.
Internal heat
A cooling fan is mounted on the rear panel to prevent heat
buildup inside the unit.
For safety, observe the following carefully:
• Make sure there is good ventilation around the
unit. Poor ventilation could overheat and damage
the unit.
• DO NOT block the cooling fan and the ventilation
openings or holes. If they are blocked by a
newspaper or cloth, etc., the heat may not be
able to get out.
Others
• Should any metallic object or liquid fall into the unit,
unplug the unit and consult your dealer before operating
any further.
• If you are not going to operate the unit for an extended
period of time, unplug the AC power cord from the wall
outlet.
DO NOT disassemble the unit since there are no
user serviceable parts inside.
If anything goes wrong, unplug the AC power cord and
consult your dealer.
EN01-08.CA-HXZ9[UW]f.p65 03.1.30, 10:59 AM1

2
English
Contents
Location of the Buttons and Controls ....................... 3
Front Panel ................................................................. 3
Remote Control .......................................................... 5
Getting Started ............................................................ 6
Supplied Accessories .................................................. 6
Putting the Batteries into the Remote Control ........... 6
Connecting Antennas ................................................. 6
Connecting Speakers .................................................. 7
Connecting Other Equipment ..................................... 8
Adjusting the Voltage Selector ................................... 8
Common Operations .................................................. 9
Turning On or Off the Power ..................................... 9
Canceling the Demonstration ..................................... 9
Turning On or Off the Key-touch Tone ...................... 9
Saving the Power Consumption while on Standby
—Ecology Mode .................................................. 9
Selecting the Sources ................................................... 9
Setting the Clock ...................................................... 10
Adjusting the Volume ............................................... 10
Reinforcing the Bass Sound ..................................... 11
Reinforcing the Heavy Sound .................................. 11
Selecting the Sound Modes ...................................... 11
Creating Your Own Sound Mode—User Mode ....... 12
Setting the AM Tuner Interval Spacing .................... 12
Listening to FM and AM Broadcasts ...................... 13
Tuning in to a Station ............................................... 13
Presetting Stations .................................................... 13
Tuning in to a Preset Station .................................... 13
Playing Back Discs .................................................... 14
Loading Discs........................................................... 14
Playing Back the Entire Discs—Continuous Play ... 15
Basic Disc Operations .............................................. 15
Programming the Playing Order of the Tracks
—Program Play .................................................. 16
Playing at Random—Random Play ......................... 17
Repeating Tracks or Discs—Repeat Play ................ 18
Prohibiting Disc Ejection—Tray Lock .................... 18
Playing Back Tapes ................................................... 19
Playing Back a Tape ................................................. 19
Locating the Beginning of a Song—Music Scan ..... 19
Recording .................................................................. 20
Recording on a Tape ................................................. 20
Synchronized Recording .......................................... 21
Using the Timers ....................................................... 22
Using Daily Timer .................................................... 22
Using Recording Timer ............................................ 24
Using Sleep Timer .................................................... 25
Timer Priority ........................................................... 25
Maintenance .............................................................. 26
Troubleshooting ........................................................ 27
Specifications ............................................................. 28
EN01-08.CA-HXZ9[UW]f.p65 03.1.30, 10:59 AM2

3
English
Location of the Buttons and Controls
Become familiar with the buttons and controls on your unit.
Front Panel
Front Panel
Top view of Indication-lamp panel p
EN01-08.CA-HXZ9[UW]f.p65 03.1.30, 10:59 AM3

4
English
Continued
Display Window
See pages in parentheses for details.
Front Panel
1Disc trays
2(standby/on) button and lamp (9, 12, 23, 24)
3ECO (Ecology) button (9)
4Remote sensor
5Display window
6FM/AM button (9, 13)
Pressing this button also turns on the unit.
7TAPE 23button (9, 19, 20)
Pressing this button also turns on the unit.
8AUX button (9)
Pressing this button also turns on the unit.
9SOUND TURBO button (11)
pIndication-lamp panel
ÅSOUND TURBO lamp (11)
ıSUBWOOFER lamp (11)
ÇREC (recording) lamp (20, 21)
ÎSEA (Sound Effect Amplifier) mode lamps (11)
• ROCK, POP, and CLASSIC lamps
‰Surround mode lamps (11)
• DANCE, HALL, and STADIUM lamps
ÏCD ready lamps (14)
• CD1 READY, CD2 READY, and CD3 READY lamps
qSOUND MODE control (11)
wPRESET + / – control (13)
4/ ¢(reverse skip/forward skip) control
(10, 12, 15 – 17, 22 – 24)
eSUBWOOFER LEVEL + / – buttons (11)
rSetting buttons (9, 10, 12, 13, 16, 17, 22 – 25)
• CANCEL/DEMO and SET/DISPLAY buttons
tREVERSE MODE button (19 – 21)
yCassette holder (19 – 21)
uPHONES ( ) jack (10)
i0(Disc tray open/close) (CD1, CD2, and CD3) buttons
(14, 15, 18)
Pressing one of these buttons also turns on the unit.
oDisc number (CD1, CD2, and CD3) buttons (15 – 17, 21)
Pressing one of these buttons also turns on the unit.
;CD 3/8button (9, 15 – 17)
Pressing this button also turns on the unit.
aTUNING + / – buttons (13)
1/ ¡(reverse search/forward search) buttons (12, 15, 19)
7(stop) button (12, 15 – 21, 24)
sVOLUME + / – control (10)
dDisc play mode buttons (16 – 18)
• REPEAT and CD PLAY MODE buttons
fCLOCK/TIMER button (10, 22 – 25)
gRecording buttons (20, 21, 24)
• REC START/STOP and CD REC START
h0EJECT button for cassette deck (19 – 21)
Display Window
1Timer indicators
• DAILY (Daily Timer), SLEEP (Sleep Timer),
REC (Recording Timer), and (Timer) indicators
2TRACK indicator
3Main display
• Shows the source name, frequency, etc.
4PRGM (program) indicator
5Disc track number (1 – 16) indicators
6RANDOM indicator
7REPEAT (ALL/1/DISC) indicators
8Audio level indicator
When one of the 6 preset sound modes is activated, these
will function as illumination display. For details, see
“Selecting the Sound Modes” on page 11.
9Tuner operation indicators
• MONO and ST (stereo) indicators
pTape operation indicators
•23(tape direction) and (reverse mode) indicators
TRACK
EN01-08.CA-HXZ9[UW]f.p65 03.2.12, 4:58 PM4

5
English
When using the remote control, point it
at the remote sensor on the front panel.
Remote Control Remote Control
1Number buttons (13, 15, 16)
24(1) (reverse skip/reverse search) button
(13, 15, 17, 19)
7(stop) button (16, 17, 19 – 21, 24)
¢(¡) (forward skip/forward search) button
(13, 15, 17, 19)
3Disc number (CD1, CD2, and CD3) buttons (15 – 17)
Pressing one of these buttons also turns on the unit.
4Disc play mode buttons (16 – 18)
• REPEAT, RANDOM, and PROGRAM buttons
5REC START/STOP button (20, 24)
6SOUND TURBO button (11)
7SUBWOOFER LEVEL + / – buttons (11)
8STANDBY/ON button (9)
9SLEEP button (25)
pAUX button (9)
Pressing this button also turns on the unit.
qFM/AM button (9, 13)
Pressing this button also turns on the unit.
wFM MODE button (13)
eCD 3¥8 button (9, 15 – 17)
Pressing this button also turns on the unit.
rPROGRAM CANCEL button (17)
tTAPE 23button (9, 19, 20)
Pressing this button also turns on the unit.
ySOUND MODE button (11)
uBEEP ON/OFF button (9)
iVOLUME + / – button (10)
oFADE MUTING button (10)
COMPACT
DIGITAL AUDIO
P
R
E
S
E
T
CANCEL / DEMO
SET/
DISPLAY REPEAT
EXTENDED SUPER BASS
CD-R / RW PLAYBACK
CD PLAY
MODE
REVERSE
MODE
REC START
/STOP
CD REC
START EDIT
EN01-08.CA-HXZ9[UW]f.p65 03.1.30, 10:59 AM5
