Jvc Sp-at7 User manual

weather proof

DESIGN

Outdoor Bluetooth®

Speakers

SP-AT7

Instruction Manual

Instruksjonsmanual

Instruktionsbok

Käyttöopas

Brugervejledning

SP-AT7_IB_20160412.indd 1 12/4/2016 12:16 PM

SP-AT7_IB_20160412.indd 2 12/4/2016 12:16 PM

Contents

Safety Warnings...................................................................................................................4

Unpacking.............................................................................................................................6

Product Overview ................................................................................................................7

Main Unit.........................................................................................................................................................7

Remote Control ............................................................................................................................................8

Preparation...........................................................................................................................9

Battery Replacement for the Remote Control ..................................................................................9

Remote Control Operation Range.........................................................................................................9

Wall Mounting............................................................................................................................................ 10

Connections........................................................................................................................12

Connecting the Speakers........................................................................................................................12

AUX Connection.........................................................................................................................................12

Connecting an MP3 Player .....................................................................................................................12

Connecting an Amplier and Audio Device with the speaker cables ...................................13

Connecting to the Mains Supply .........................................................................................................14

General Operation.............................................................................................................15

Standby / ON ...............................................................................................................................................15

Selecting Modes.........................................................................................................................................15

Adjusting the Speaker Level Settings and Eects.........................................................................15

AUX IN Operation...............................................................................................................15

Bluetooth® Operation ........................................................................................................16

Maintenance.......................................................................................................................17

Hints and Tips.....................................................................................................................17

Specifications.....................................................................................................................18

SP-AT7_IB_20160412.indd 3 12/4/2016 12:16 PM

GB Safety Warnings

• A minimum distance of 5 cm around the

unit should be maintained to allow for

sucient ventilation.

• Do not install or place this unit in a

bookcase, built-in cabinet or in another

conned space. Ensure the unit is well

ventilated.

Safety

• Always disconnect the unit from the mains

supply before connecting / disconnecting

other devices or moving the unit.

• Unplug the unit from the mains socket

during a lightning storm.

• In the interests of safety and to avoid

unnecessary energy consumption,

never leave the unit switched on while

unattended for long periods of time, e.g.

overnight, while on holiday or while out of

the house. Switch it o and disconnect the

mains plug from the mains socket.

Mains Cable

• Make sure the unit or unit stand is not

resting on top of the mains cable, as the

weight of the unit may damage the mains

cable and create a safety hazard.

• If the mains cable is damaged it must be

replaced by the manufacturer, its service

agent, or similarly qualied persons in

order to avoid a hazard.

Interference

• Do not place the unit on or near appliances

which may cause electromagnetic

interference. If you do, it may adversely

aect the operating performance of the

unit, and cause a distorted picture or

sound.

Batteries

• Batteries used in the unit are easily

swallowed by young children and this is

dangerous.

• Keep loose batteries away from young

children and make sure that the battery

holder tray is secure in the unit. Seek

medical advice if you believe a cell has

been swallowed.

• Please dispose of batteries correctly by

following the guidance in this manual.

• Do not expose the battery to direct

sunlight or sources of excessive heat.

• Do not ingest the battery - Chemical Burn

Hazard.

• Read all the instructions carefully before

using the unit and keep them for future

reference.

• Retain the manual. If you pass the unit

onto a third party make sure to include this

manual.

• Check that the voltage marked on the

rating label matches your mains voltage.

Damage

• Please inspect the unit for damage after

unpacking.

• Do not continue to operate the unit if you

are in any doubt about it working normally,

or if it is damaged in any way - switch o,

withdraw the mains plug and consult your

dealer.

Water Resistance

• In compliance with IP65, this product can

be protected from low pressure water jets

from any direction.

Temperature

• Avoid extreme degrees of temperature,

either hot or cold. Place the unit well away

from heat sources such as radiators or gas /

electric res.

• Avoid exposure to direct sunlight and other

sources of heat.

• The operating temperature of this device

is -20°C ~ 40°C. The device may be

temporarily out of function if it operates

beyond this temperature range.

• Even if your device is resistant to dust and

water (IP65), you should avoid leaving it in

an extreme environment. Please bring the

device back to indoor when the outdoor

temperature is below -20°C.

Naked Flames

• Never place any type of candle or naked

ame on the top of or near the unit.

Moisture

• If you spill any liquid into the unit, it can

cause serious damage. Switch it o at the

mains immediately. Withdraw the mains

plug and consult your dealer.

Ventilation

• To prevent the risk of electric shock or

re hazard due to overheating, ensure

that curtains and other materials do not

obstruct the ventilation vents.

SP-AT7_IB_20160412.indd 4 12/4/2016 12:16 PM

• The remote control supplied with this

product contains a coin/button cell battery.

If the coin/button cell battery is swallowed,

it can cause severe internal burns in just 2

hours and can lead to death.

• Keep new and used battery away from

children.

• If the battery compartment does not close

securely, stop using the product and keep

it away from children.

• If you think batteries might have been

swallowed or placed inside any part of the

body, seek immediate medical attention.

Supervision

• Children should be supervised to ensure

that they do not play with the unit and the

remote control.

• Never let anyone especially children push

anything into the holes, slots or any other

openings in the case - this could result in a

fatal electric shock.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

The lightning ash with arrowhead

symbol, within an equilateral

triangle, is intended to alert the

user to the presence of uninsulated

“dangerous voltage”within the

unit’s enclosure that may be of

sucient magnitude to constitute a

risk of electric shock.

The exclamation point within an

equilateral triangle is intended to

alert the user to the presence of

important operating and

maintenance (servicing)

instructions in the manual

accompanying the unit.

Service

• To reduce the risk of electric shock, do not

remove screws. The unit does not contain

any user-serviceable parts. Please leave all

maintenance work to qualied personnel.

• Do not open any xed covers as this may

expose dangerous voltages.

Maintenance

• Ensure to unplug the unit from the mains

socket before cleaning.

• Do not use any type of abrasive pad or

abrasive cleaning solutions as these may

damage the unit’s surface.

• Do not use liquids to clean the unit.

• This equipment is a Class II or double

insulated electrical appliance. It has

been designed in such a way that it

does not require a safety connection

to electrical earth.

To prevent the

spread of re,

keep candles

or other open

ames away

from this

product at all

times.

SP-AT7_IB_20160412.indd 5 12/4/2016 12:16 PM

Unpacking

Remove all items from the packaging. Retain the packaging. If you dispose of it please do so

according to local regulations.

The following items are included:

Main Unit

Remote Control

(Battery included)

Wall Bracket x 2 Knob x 4

Speaker cable Screw x 4

Instruction Manual

Instruction

Manual

Thank you for purchasing your new JVC Speaker.

We recommend that you spend some time reading this instruction manual

in order that you fully understand all the operational features it oers. You

will also nd some hints and tips to help you resolve any issues.

Read all the safety instructions carefully before use and keep this

instruction manual for future reference.

SP-AT7_IB_20160412.indd 6 12/4/2016 12:16 PM

Product Overview

Main Unit

Front View (right speaker)

1. LED Indicator

2. Speaker

Rear View

1. +/– Socket

2. AUX IN Socket

3. AC Power Switch

4. Mains Cable

SP-AT7_IB_20160412.indd 7 12/4/2016 12:16 PM

1. Button

Switch the unit between On and

Standby mode.

2. Button

Mute the unit or resume the sound.

3. AUX/BT Button

• Switch between AUX IN / BT mode.

• Direct switch to Bluetooth® mode.

• Press and hold to enable Bluetooth®

pairing in Bluetooth® mode.

• If there is an existing connection,

press and hole to disconnect the

paired Bluetooth® device. The unit

will then enter paring mode.

4. TREBLE +/– Buttons

Adjust the treble sound level.

5. VOL +/– Buttons

Adjust the volume.

6. Button

Play / pause / resume playback in

Bluetooth® mode.

Button

Skip forwards to the next track in

Bluetooth® mode.

Button

Skip to the previous track in

Bluetooth® mode.

7. BASS +/– Buttons

Adjust the subwoofer sound level.

Remote Control

SP-AT7_IB_20160412.indd 8 12/4/2016 12:16 PM

Handling the Battery

• Improper or incorrect use of batteries may cause corrosion or battery leakage, which could cause re,

personal injury or damage to property.

• Only use the battery type indicated in this manual.

• Do not install new batteries with used ones and do not mix dierent types of batteries.

• Do not dispose of used batteries as domestic waste. Dispose of them in accordance with local

regulations.

Handling the Remote Control

• Do not drop the remote control.

• Do not allow anything to impact the remote control.

• Do not spill water or any liquid on the remote control.

• Do not place the remote control on a wet object.

• Do not place the remote control under direct sunlight or near sources of excessive heat.

• Remove the battery from the remote control when not in use for a long period of time, as corrosion or

battery leakage may occur and result in physical injury, and / or property damage, and / or re.

• When the battery is exhausted, the remote control will not function.

Preparation

Remove the Plastic Strip from the Remote Control

Remove the plastic strip from the battery if the battery is being used for

the rst time. It is located at the bottom rear of the remote control.

Battery Replacement for the Remote Control

The remote control requires a CR2025, 3V Lithium battery.

1. Slide and hold the battery release tab in the

direction of the arrow.

2. Pull out the battery holder and remove the old

battery.

3. Replace with a new battery.

4. Insert the battery holder back into the remote

control.

SP-AT7_IB_20160412.indd 9 12/4/2016 12:16 PM

Wall Mounting

• Installation must be carried out by qualied personnel only. Incorrect assembly can result in severe

personal injury and property damage (if you intend to install this product yourself, you must check

for installations such as electrical wiring and plumbing that may be buried inside the wall). It is the

installer’s responsibility to verify that the wall will safely support the total load of the speaker.

• Additional tools (not included) are required for the installation.

• Do not overtighten screws.

• Keep this instruction manual for future reference.

• Use an electronic stud nder to check the wall type before drilling and mounting.

• The operating temperature of this device is -20°C ~ 40°C. The device may be temporarily out of

function if it operates beyond this temperature range.

• Even if your device is resistant to dust and water (IP65), you should avoid leaving it in an extreme

environment. Please bring the device back to indoor when the outdoor temperature is below -20°C.

1. Attach the wall brackets (included) to the main unit with the supplied screws.

Remote Control Operation Range

• The remote control sensor on the front unit is sensitive to the

remote control’s commands up to a maximum of 5 metres away

and within a maximum of a 60° arc.

• Please note that the operating distance may

vary depending on the brightness of the room.

Wall Bracket

Knob

30° 30°

Max. 5 m

Front View (right speaker)

SP-AT7_IB_20160412.indd 10 12/4/2016 12:16 PM

2. Drill 2 sets of parallel holes (Ø 3-8 mm each according to wall type) in the wall. Firmly x

1 dowel (not inclued) into each hole in the wall if necessary.

3. Insert 1 screw (included) into each dowel. Be sure to leave a 3 mm gap between the

wall and the screw’s head. Lift the unit over the heads of the screws and slot into place.

Dowel

Solid wall (i.e., Solid brick,

Solid concrete, Solid wood,

Solid wooden battens)

Drywall, Plaster wall,

Lath wall, etc.

3 mm

25-30 mm

120 mm

SP-AT7_IB_20160412.indd 11 12/4/2016 12:16 PM

Ensure to match the colours on the cable plugs to the colours on the input and output sockets.

Connection

Connecting the Speakers

Connect the speakers (L & R) with the cable speakers. Make sure that the red cable is

connected to the + socket and the black cable is connected to the – socket of both

speakers.

Blu-ray Player / DVD

Player / Recorder

Set-top Box

Satellite

Receiver Game

Console

Video

Camera

OR 3.5 mm to 3.5 mm Stereo

Audio Cable (not included)

3.5 mm to RCA Stereo

Audio Cable (not included)

1 2 3

AUX Connection

Use an 3.5 mm to RCA Stereo Audio Cable (not included) / 3.5 mm to 3.5 mm Stereo Audio

Cable (not included) to connect the AUX IN socket to the AUDIO OUT sockets of the

external device.

After connection, press on the remote control to select to play audio from your input

device.

Rear View of the Speaker (R)

SP-AT7_IB_20160412.indd 12 12/4/2016 12:16 PM

Rear View of the Speaker (R)

Connecting an MP3 Player

Use a 3.5mm to 3.5mm stereo audio cable (not included) to connect the AUX IN Socket to

the headphone socket of the external device.

After connection, press AUX/BT button on the remote control to select AUX mode to

play audio from your input device.

3.5mm to 3.5mm Stereo

Audio Cable (not included)

Mobile device

HEADPHONE

SP-AT7_IB_20160412.indd 13 12/4/2016 12:16 PM

GB Connecting to the Mains Supply

• This unit is designed to operate with an AC power supply.

• Connecting the unit to any other power source may cause damage to the unit. Unwind

the mains cable to its full length. Connect the mains plug to a mains socket. Make sure

the mains plug is fully inserted into the mains socket. The unit is now connected and

ready to use.

• To switch the unit o completely, turn the power switch to the OFF position and

unplug the mains plug from the mains socket.

• Ensure all audio connections of the unit are connected before connecting to the mains power socket.

• Please turn the unit o completely to save energy when not in use.

• The mains cable are designed for this JVC speaker only. DO NOT use the mains cable for other

purposes.

To the

mains socket

Rear View of the Speaker (R)

SP-AT7_IB_20160412.indd 14 12/4/2016 12:16 PM

General Operation

Standby / ON

When you rst connect the unit to the mains socket, the unit will be in Standby mode.

• Press on the remote control to switch the unit to ON mode. The LED indicator will

ashes in blue.

• Press on the remote control to switch the unit back to Standby mode. The LED

indicator will light up red.

• Turn the power switch to OFF position and disconnect the mains plug from the mains

socket if you want to switch the unit o completely.

Selecting Modes

Press AUX/BT button on the remote control to switch between AUX IN and Bluetooth®

mode.

Adjusting the Speaker Level Settings and Eects

Adjusting the Volume

• Press VOL +/– to adjust the volume.

• If you wish to turn the sound o, press on the remote control. Press again, or press

VOL +/– on the remote control to resume normal listening.

Adjusting the Bass Volume Level

Press BASS +/– repeatedly to adjust the bass volume level.

Adjusting the Treble Volume Level

Press TREBLE +/– repeatedly to adjust the treble volume level.

AUX IN Operation

1. Before connecting to the mains socket, ensure all the connections are completed.

2. While in the On mode, press AUX/BT button on the remote control to select AUX IN

mode.

3. Operate your audio device directly for playback features.

SP-AT7_IB_20160412.indd 15 12/4/2016 12:16 PM

GB Bluetooth® Operation

Pairing the unit with a Bluetooth®device to listen to music:

First time pairing

1. During On mode, press AUX/BT button on the remote control to select Bluetooth®

mode. The LED indicator will ash in blue.

2. Activate your Bluetooth® device and select the search mode.“SP-AT7” will appear on

your Bluetooth®device list.

3. Select “SP-AT7”and enter “0000”for the password if necessary. After pairing, the LED

indicator will light up in blue.

If your Bluetooth® device supports A2DP, play music via your device.

To disconnect the Bluetooth® function, switch to another function on the unit or disable

the function from your Bluetooth® device. You may also press and hold AUX/BT button

on the remote control to clear all pairing setting. The LED indicator will ash in blue. and

the unit is now ready for pairing. Follow step 2-3 in “First time pairing“ above to pair your

Bluetooth® device.

• The operational range between the unit and the device is approximately 6 metres.

• Before connecting a Bluetooth® device to the unit, ensure you know the device’s capabilities.

• Compatibility with all Bluetooth® devices is not guaranteed.

• Any obstacle between the device and the unit can reduce operational range.

• Keep this player away from other electronic devices that may cause interference.

• The player will also be disconnected when your device is moved beyond the operational range.

SP-AT7_IB_20160412.indd 16 12/4/2016 12:16 PM

Maintenance

Ensure the unit is fully unplugged from the mains socket before cleaning.

• To clean the units, wipe the case with a slightly moist, lint-free cloth.

• Do not use any cleaning uids containing alcohol, ammonia or abrasives.

• Do not spray aerosol at or near the unit.

Hints and Tips

If a problem does occur, it may often be due to something very minor. The following table

contains various tips. If you require additional assistance please click on the link for Support

Centre:

Norway: www.elkjop.no/service Sweden: www.elgiganten.se/service

Denmark: www.elgiganten.dk/service Finland: www.gigantti./huolto

Problem Solution

No power. • Ensure the mains plug is connected.

• Make sure that you select the On mode.

The remote control does

not function.

• Use the remote control near the unit.

• Point the remote control at the remote sensor on the unit.

• Replace the battery in the remote control with a new one.

• Remove any obstacles between the remote control and

the unit.

Loud hum or noise is

heard.

• The plugs and sockets are dirty. Wipe them with a cloth

slightly moistened with alcohol.

The unit does not

respond when pressing

any buttons.

• The unit may freeze up during use. Switch the unit o and

then on again at the mains socket to reset the unit.

I cannot nd

“SP-AT7” on my

Bluetooth® device.

• Ensure the Bluetooth® function is activated on your

Bluetooth® device.

• Ensure you have paired your unit with the Bluetooth®

device.

If any anomaly is encountered, unplug the mains adapter from the mains socket and reconnect it again.

SP-AT7_IB_20160412.indd 17 12/4/2016 12:16 PM

GB Specifications

Brand JVC

Model SP-AT7

Standby Power

Consumption

< 0.5W

Power Supply Input AC110-240V ~ 50-60Hz

Power Consumption 2 × 25 W rms

Bluetooth®Bluetooth® 4.0 (A2DP)

Net Weight 4.06 kg

Dimension 152 mm (W) × 23 mm (H) × 155 mm (D)

IP Rating IP65

Features and specications are subject to change without prior notice.

SP-AT7_IB_20160412.indd 18 12/4/2016 12:16 PM

The symbol on the product or its packaging indicates that this product

must not be disposed of with your other household waste. Instead, it is

your responsibility to dispose of your waste equipment by handing it over

to a designated collection point for the recycling of waste electrical and

electronic equipment. The separate collection and recycling of your waste

equipment at the time of disposal will help conserve natural resources and

ensure that it is recycled in a manner that protects human health and the

environment.

For more information about where you can drop o your waste for

recycling, please contact your local authority, or where you purchased your

product.

Notes for battery disposal

The batteries used with this product contain chemicals that are harmful to

the environment. To preserve our environment, dispose of used batteries

according to your local laws or regulations. Do not dispose of batteries with

normal household waste.

For more information, please contact the local authority or your retailer

where you purchased the product.

All trademarks are the property of their respective owners and all rights are acknowledged.

The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG,

Inc. and any use of such marks by DSG Retail Limited is under license. Other trademarks and

trade names are those of their respective owners and all rights are acknowledged.

The product is distributed and warranted exclusive by DSG Retail Ltd.

“JVC”is the trademark of JVC KENWOOD Corporation,

used by DSG Retail Ltd. under license.

Dear Customer,

This apparatus is in conformance with the valid European directives compatibility and

electrical safety.

European representative of the manufacturer is:

DSG Retail Ltd. (co. no. 504877)

1 Portal Way, London, W3 6RS, UK

IF CONTACT WITH CUSTOMER SERVICE IS REQUIRED

PLEASE HAVE THE MODEL NUMBER READY PRIOR TO THE CALL

CUSTOMER SERVICE - 1-800-289-0984

FOR RECYCLING INFORMATION, PLEASE CONTACT CUSTOMER SERVICE.

CUSTOMER SERVICE - 1-800-289-0984

SP-AT7_IB_20160412.indd 19 12/4/2016 12:16 PM

Innhold

Sikkerhetsadvarsler ......................................................................................................... 20

Pakke opp .......................................................................................................................... 23

Produktoversikt................................................................................................................ 24

Hovedenhet ................................................................................................................................................ 24

Fjernkontroll ............................................................................................................................................... 25

Forberedelse ..................................................................................................................... 26

Fjern plast lmen fra  ernkontrollen ............................................................................................... 26

Skifte batteriet i  ernkontrollen......................................................................................................... 26

Fjernkontrollens virkeområde ............................................................................................................. 27

Veggmontering ......................................................................................................................................... 27

Forbindelser ...................................................................................................................... 29

Koble til høyttalerne................................................................................................................................ 29

AUX Tilkoblinger ....................................................................................................................................... 29

Koble til MP3-spiller................................................................................................................................. 30

Koble til stikkontakten............................................................................................................................ 30

Generell betjening.............................................................................................................31

Ventemodus / På........................................................................................................................................31

Velge modus................................................................................................................................................31
